Signal Path Peachtree Audio DECCO125 Integrated amplifier User Manual
Signal Path International DBA Peachtree Audio Integrated amplifier
User Manual
125
USB
OPT
PHONO
AUX
The Spotify software is subject to third party licenses found here:
www.spotify.com/connect/third-party-licenses
IMPORTANT SAFETY INSTRUCTIONS
B Read these instructions – All the safety and operating instructions should be read before this
product is operated.
C Keep these instructions – The safety and operating instructions should be retained for future
reference.
D Heed all warnings – All warnings on the appliance and in the operating instructions should be
adhered to.
E Follow all instructions.
F Do not use this apparatus near water – The appliance should not be used near water or
moisture – for example, in a wet basement or near a swimming pool, and the like.
G Clean only with dry cloth.
H Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
I Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including ampliers) that produce heat.
J Do not defeat the safety purpose of the polarized or grounding plug. A polarized plug has two
blades with one wider than the other. A grounding plug has two blades and a third grounding
prong. The wide blade or the third prong is provided for your safety. If the provided plug does
not t into your outlet, consult an electrician for replacement of the obsolete outlet.
K Protect the power cord from being walked on or pinched particularly at the plugs, convenience
receptacles, and at the point where they exit from the apparatus.
L Only use attachments/accessories specied by the manufacturer.
M Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer,
or sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
N Unplug this apparatus during lightning storms or when unused for long periods of time.
O Refer all servicing to qualied personnel. Servicing is required when the apparatus has been
damaged in any way such as the power cord or plug is damaged. Other damage may occur
if liquid or objects have been dropped or spilled into the apparatus. Dropping the apparatus,
exposure to rain, and excessive moisture may cause additional damage.
P Please keep the unit in a good ventilation environment.
Q CAUTION: These servicing instructions are for use by qualied service personnel only. To
reduce the risk of electric shock, do not perform any servicing other than that contained in the
operating instructions unless you are qualied to do so.
R WARNING: To reduce the risk of re or electric shock, do not expose this apparatus to rain or
moisture. The apparatus shall not be exposed to dripping or splashing and objects lled with
liquids, such as vases, shall not be placed on apparatus.
S WARNING: The mains plug/appliance coupler is used as disconnect device, the disconnect
device shall remain readily operable.
T The lightning ash with arrowhead symbol within
an equilateral triangle is intended to alert the user
to the presence of non-insulated “dangerous
voltage” within the product’s enclosure that may
be of sufcient magnitude to constitute a risk of
electric shock.
WARNING: To reduce the risk of electric shock, do not remove cover (or back), as there are no
user-serviceable parts inside. Refer servicing to qualied personnel.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance instructions in the literature accompanying the appliance.
U No naked ame sources, such as lighted candles, should be placed on the apparatus.
V Batteries are included for the remote control. Do not expose these batteries to direct sunlight
or excessive heat such as a re. Care should be taken in the act of battery disposal as they
include toxic materials that may harm the environment. Please refer to your local recycling
and hazardous waste center for advise with battery disposal.
W WARNING: The terminals marked with symbol of “+/-” may be of sufcient magnitude
to constitute a risk of electric shock. The external wiring connected to the terminals
requires installation by an instructed person or the use of ready- made insulated
leads or cords.
X Correct disposal of this product. This marking indicates that this product should not be
disposed with other household wastes throughout the EU. To prevent possible harm to the
environment or human health from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources. To return your used device, please use
the return and collection systems or contact the retailer where the product was purchased.
They can take this product for environmentally safe recycling.
Unpacking and Warranty
B Please keep all packing materials for any potential shipping needs.
C Please keep a copy of the sales receipt and note the serial number on it for warranty and
insurance purposes.
D Please register your product online at www.peachtreeaudio.com.
Marking by the “CE” symbol (shown left) indicates compliance of this device with the
EMC (Electromagnetic Compatibility) and LVD (Low Voltage Directive) standards of
the European Community.
Note: This equipment has been tested and found to comply with the limits for a class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
The equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and the receiver
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
Caution: Any changes or modifications to this device not explicitly approved by
manufacturer could void your authority to operate this equipment.
To comply with FCC RF exposure compliance requirements, this grant is applicable to
only mobile configurations. The antennas used for this transmitter must be installed to
provide a separation distance of at least 20 cm from all persons and must not be co-
located or operating in conjunction with any other antenna or transmitter.
125
Introduction
Back Panel
Front Panel
Remote Control
Wireless Network
Spotify connect
Useful Tips
Troubleshooting
Warranty and Repair
Specications
(Rev. 6/2017)
INTRODUCTION
Thank you for choosing the decco125! The original decco that Peachtree Audio
launched over a decade ago was a ground-breaking product that featured a USB input
and built-in DAC to facilitate audio streaming from a computer. The whole concept of
“computer audio” was cutting-edge at the time and other brands eventually followed
Peachtree Audio’s lead and built-in USB DACs became an industry standard over time.
The new decco takes the integrated amplier concept another step further and
addresses the most critical component in a Hi-Fi system; the speaker. The amplier
inside the decco is designed to drive virtually any pair of traditional speakers, but when
it is paired with the optional duet speakers, it becomes a 3-way, fully-active, Hi-Fi
system that easily outperforms much larger and more expensive systems.
A portion of the decco rear panel is modular. As shipped from Peachtree, the rear
panel is congured to drive a pair of traditional loudspeakers. When the optional duet
speakers are added, the rear panel is replaced with a new one that congures the
decco to drive the speakers in a fully active conguration including individually amplied
drivers, active crossovers and equalization.
The new decco carries on the Peachtree tradition of form follows function. The front
panel is machined out of a single piece of aluminum and designed to emulate an old
car radio with a single row of buttons and a volume knob. Simply select the desired
input and adjust the volume to easily enjoy all of your music! The chassis is wrapped
in a beautiful real-wood cabinet that has been a calling card of Peachtree Audio since
the original decco was launched over a decade ago.
The new decco is designed to handle a wide range of inputs. There is a USB input for
a computer along with an optical input for another digital audio source like a streamer
or a disc player. There are two analog inputs as well. One for a turntable (with a MM
cartridge) and a second for a cassette deck or other “line-level” analog source device.
The decco also includes an optional wireless input to facilitate audio streaming directly
from mobile devices and Internet streaming services. On the front panel, there is a
headphone output capable of driving a wide range of headphones for enjoying your
music without disturbing others.
Please take the time to read this manual to get familiar with the decco125 and visit www.
peachtreeaudio.com to register your purchase. We will extend the standard warranty
if you do and your information will not be shared with anyone. We will only contact you
with news that is relevant to your decco purchase! If you have additional questions or
feedback, please contact your Peachtree dealer or us directly.
We sincerely hope that you love your decco and that it brings you many years of
enjoyment. It represents a new standard for value, exibility and innovation in the
market. Thank you again for choosing Peachtree and happy listening!
- Your friends at Peachtree Audio
BACK PANEL
B C DEFGHI
AC~IN
RoHS
CAU TI ON
RISK O F ELECTRIC S HOCK
TO REDUCETHE RISK OF ELECTRIC SHOCK,
DO NOTEXPOSETHIS EQUIPMENT
TO RAIN OR MOISTURE !
DO NOT O PEN
WARN IN G
ANT-1 ANT-2
Gnd.
SERV ICE
SERV ICE
ONLY
OPTIC AL
INP UT
USB-B
INPUT
SPEAKER
OUTPUT
RIGHT
SPEAKER
OUTPUT
LEFT
L
L
L
R
R
R
PHONO
PREOUT
AUX
Seria l Numb erMADE IN CHINA
DESIGNED IN CANADA Type: IntegratedAmplifier
Model: Decco125
Maximum power consumption is 400W
125
J K
B AC INPUT: For connection to a 100-240VAC 50/60Hz AC outlet using the included
power cord.
C ANT-1 & 2: RF antenna inputs for use with wireless input equipped units. Connect both
antennas if the decco is or will be located in a spot where the wireless network signal
strength is weaker. Check this by placing a mobile device in the spot the decco is or
will be located and reading the wireless network signal strength. If all “bars” are lit, you
shouldn’t need to utilize the antennas. If fewer “bars” are lit, utilized the antennas to
ensure optimal wireless performance.
D SERVICE ONLY: This is NOT a USB audio input! Reserved for service use.
E USB-B INPUT: Accepts digital audio input up to 24-bit/96kHz PCM from a computer.
F GROUND: Accepts the ground connection from a phonograph/turntable.
G OPTICAL INPUT: Accepts S/PDIF digital audio input from an optical (Toslink style)
output up to 96kHz. Optical digital audio outputs are common on digital audio sources
including; streaming audio devices, disc players, cable boxes and HDTVs.
H AUX ANALOG INPUT (L) (R): Accepts line level input from devices with analog outputs.
If the device also has a digital audio output, it may provide better sound quality.
I PHONO INPUT (L) (R): Accepts input from a phonograph/turntable with a moving
magnet (MM) cartridge.
J PRE-OUT: Provides analog audio output to connect to a powered subwoofer or an
external power amplier. Note: the RIGHT and LEFT speaker outputs remain active
when the PRE OUT is used and both sets of outputs are automatically muted when the
mute function is engaged or when headphones are connected to the front panel.
K RIGHT & LEFT SPEAKER OUTPUTS: Speaker binding post outputs that accept
banana style, spade or bare wire speaker cable terminations. The binding posts are
clearly marked RIGHT and LEFT with red (+) and black (-) for proper connections with
the speakers. Please check that all of the ends of the speaker cables are connected
with the correct polarity; positive-to-positive and negative-to-negative. Wiring positive-
to-negative or negative-to-positive should not cause any damage but it does alter
the phase and therefore the sound the speakers create. Note: the RIGHT and LEFT
speaker outputs are automatically muted when the mute function is engaged or when
headphones are connected to the front panel.
FRONT PANEL
USB
OPT
PHONO
AUX
B C DEFGHIJ
B On/Standby Button: With the AC power cord connected, this button toggles the unit
between On mode (which selects the last input used) and Standby mode which lights
the LED red.
C USB Button: This button selects the USB input and lights the LED blue.
D OPT Button: This button selects the OPT input and lights the LED blue.
E PHONO Button: This button selects the PHONO input and lights the LED blue.
F AUX Button: This button selects the AUX input and lights the LED blue.
G Wireless Button: This button selects the optional Wireless network input and lights the
LED. This button does not function if the wireless network feature is not enabled. For
more information on the wireless network input, please refer to that section.
H IR Receiver: Window for receiving Infra-Red (IR) commands from the included remote
control or third-party remote control systems.
I Volume Knob: Rotate clockwise to increase and counter-clockwise to decrease output
level. Note: the volume level will be indicated for ~2 seconds utilizing the 5 blue input
LEDS on the front panel. Each one represents ~20% of the volume range.
J Headphone Output: 1/4” headphone output connection. Inserting a headphone
connection automatically mutes the RIGHT & LEFT Speaker outputs. Removing a
headphone connection automatically un-mutes the RIGHT & LEFT Speaker outputs.
Caution: Please lower the output level when inserting or removing headphone
connections as headphone sensitivity varies widely and a comfortable speaker listening
level may be extremely loud when switching to headphones.
REMOTE
B On/Standby Button: With the AC power cord
connected, this button toggles the unit between
On mode (which selects the last input used) and
Standby mode which lights the LED red. Note:
the input LEDs will ash white in a sequence
when the unit goes into on or standby mode.
C BASS +/-: Increases or decreases the BASS
(low frequencies).
D VOL /: Increases and decreases the output
level. Note: the volume level will be indicated for
~2 seconds using the 5 blue input LEDS on the
front panel. Each LED represents ~20% of the
entire volume range.
E Wireless Network
F Transport Control Buttons: Controls playback
of compatible sources connected. selects
the previous track or the beginning of the
current track if playback is in progress.
toggles between play mode and pause mode.
selects the next track in the current queue
or list. Please note that some USB capable
devices and wireless streaming applications
may not support these controls. This is not a
malfunction of the remote control. If the source
does not respond to these commands, it does
not support them.
G USB Button: This button selects the USB-B input and lights the LED blue.
H OPT Button: This button selects the OPT input and lights the LED blue.
I 1 2 3 4: Reserved for wireless network use.
J MUTE Button: Mutes and un-mutes the RIGHT & LEFT Speaker and headphone
outputs. Note: the currently selected input LED will ash white while the output is muted.
K TREB Button +/-: Increases or decreases the TREBle (high frequencies).
L FLAT Button: Sets the bass and treble control to “FLAT” (no increase or decrease
applied).
M PHONO Button: This button selects the PHONO input and lights the LED blue.
N AUX Button: This button selects the AUX input and lights the LED blue.
B
C
D
E
F
G
H
I
M
N
J
K
L
WIRELESS NETWORK
The decco125 offers an optional IEEE 802.11b/g/n wireless network input optimized for
audio. If equipped, this input can be selected by pressing the [insert waves logo here]
button on the front panel or remote control. It can also be selected by starting an audio
stream using the MUZO Player application on the compatible phone or tablet.
To setup the mobile device, please download the MUZO Player application on your
compatible phone or tablet from the App Store (iOS devices) or Google Play (Android
devices).
To setup the decco for wireless streaming, please use one of the following methods:
Setup method 1 - Internet interface
1. Open the Wi-Fi settings on the mobile device and connect to the
decco125_xxxx network
2. Open a web browser and enter 10.10.10.254 in the address bar
3. A settings page will load. Select the desired wireless network and
enter the password (if necessary)
4. Once the decco125 is connected to the wireless network, “forget” or
delete the decco125_xxxx network from the mobile device used to
set it up.
5. Make sure the mobile device is put on to the same network as the
decco125
Setup method 2 - WPS switch on router
1. Press and hold the WPS switch on the router until it enters pairing
mode
2. Press and hold the wireless network input button on the decco125 for
more than 3 seconds
3. The router and the decco125 should nd each other and complete the
setup automatically
Once the decco125 is connected to the wireless network, utilize the MUZO Player
application to select and control playback. The the MUZO Player application can also
control the decco125 volume and the following input selections: USB, OPT and AUX.
Please visit peachtreeaudio.com for any other tips and updates on setting up and using
the wireless input feature.
SPOTIFY CONNECT
You’ll need Spotify Premium to use Connect, see details overleaf.
1. Add your new device to the same wi network as your phone, tablet or
PC (see product user instructions for details).
2. Open the Spotify app on your phone, tablet or PC, and play any song.
3. If you’re using the app on a phone - tap the song image in the bottom
left of the screen. For tablet and PC move to step 4.
4. Tap the Connect icon
5. Pick your device from the list. If you can’t see it, just check it’s
connected to the same wi network as your phone, tablet or PC.
All done! Happy listening.
Licenses
The Spotify Software is subject to third party licenses found here:
www.spotify.com/connect/third-party-licenses.
USEFUL TIPS
At Peachtree Audio we believe all products should be easy to use, but sometimes getting the
audio to stream out of a computer’s USB port requires a few extra steps. See instructions
below. Some minor changes may occur with Windows or Apple OS updates, but the basics
are the usually the same.
USB Connections
Windows PC
B Connect the USB-B input on the decco to an open USB port on your computer.
C Your computer should “recognize” the decco as a USB device. You might even get a pop-
up window notifying you.
D Right click the speaker icon on your screen.
E Select the “AUDIO” tab.
F Using the drop-down menu, choose the Peachtree Audio option.
G Click “OK.”
Launch your music application and enjoy!
Mac
B Open System Preferences.
C Click on Sound.
D In the output tab you should see Peachtree as one of the choices.
E Select it.
Launch iTunes or other music application and enjoy!
Once you set up your computer using the instructions above, it should automatically
recognize the decco each time you use it. If you unplug the USB connection or re-boot your
computer, you may have to repeat some of the steps above. This is normal.
Other useful tips...
For the best sound when listening to music from your computer, set your computer and
music program volume controls to maximum and use the decco volume knob or remote
control as the master volume control.
For critical listening to music from your computer, avoid keeping multiple programs open. It
can compromise the sound quality and even cause signal dropouts.
Provide adequate ventilation above the decco so it can “breathe.” It is designed to draw
cooler air in through the vents on the bottom and exhaust warmer air through the vents on
the top.
Please check www.peachtreeaudio.com periodically for additional tips and articles.
Interested in the Green Movement?
• The decco meets European RoHS standards for non-hazardous metals.
• The decco draws less than half a watt of power in standby mode.
• The internal power amplier is set to minimize power consumption when headphones are used.
• We are committed to continue exploring additional methods for making our products even
more environmentally friendly.
TROUBLESHOOTING
ISSUE SOLUTIONS
The decco will not power on.
Check that the AC power cord is connected and
plugged into an actice AC outlet. If it is, the on/
standby LED on the front panel LED should be lit
red. Check that the AC outlet is functioning correctly
by plugging in a lamp or other device to conrm its
operation.
The decco powers on, but there is
no sound or the sound is very low.
Check that the decco is not muted (blinking input
LED) or headphones connected to the front panel
(speaker outputs muted). Be sure your input source
is powered on and playing at a reasonable volume
level. Double-check the connections on the rear
panel. If a phonograph/turntable is accidentally
plugged into the AUX input, the sound will be very
low.
The remote control does not work.
Check the remote control batteries by removing the
cover on the back and trying new ones. Make sure
the remote control has a clear “line of sight” to the
sensor on the front panel. Check that no powerful
light sources, like direct sunlight, is interfering with
the sensor on the front panel.
The USB signal from a computer
is intermittent.
Try re-launching the music application (iTunes, etc.).
If the computer doesn’t recognize the decco, unplug
the USB cable from the computer and the decco,
wait a few seconds, then reconnect the USB cable.
Try re-starting the computer. The decco is designed
to remain locked on USB signals at all times, but
computers drop connections occasionally and may
require prompts to re-connect.
There is hum/noise when using a
computer.
If you have music les available on a laptop
computer, play them while running the computer on
its battery power only. If the hum/noise disappears,
then the ground connection on the computer’s
AC adapter is introducing a “ground loop” into the
system. This is not unusual, but the USB input on
the decco is designed to minimize the potential. If
the issue persists, please contact your reseller or
Peachtree Audio.
There is a “click” or “pop” when
using the front panel controls.
Sometimes static buildup on your hand will discharge
into the unit when touched and cause an audible
click or pop noise. This is normal and happens
most frequently in low humidity environments and in
rooms with carpets. If the unit is behaving erratically
afterwards, power it down completely by turning it
off, letting it sit for a minute or so, then powering it
back on. If the issue persists, please contact your
reseller or Peachtree Audio.
WARRANTY
International Warranty
Peachtree Audio warrants this product for two (2) years, parts and labor, from the
original date of purchase from an authorized Peachtree Audio re-seller. If you register
your product online at www.peachtreeaudio.com/support/product-registration.html/,
the warranty is extended to three (3) years, parts and labor.
Peachtree Audio reserves the right to refuse any warranty claims if coverage cannot be
veried by a valid proof of sale or serial number.
Peachtree Audio assumes no responsibility for product failures caused by accident,
neglect, misuse, modication or unauthorized repair.
Warranty does not cover shipping costs.
Visit www.peachtreeaudio.com for complete warranty details.
Repair Process
In the event that a product fails, please repack it in its original carton and contact an
authorized Peachtree reseller for further instructions. If the reseller is unable to assist,
please contact Peachtree Audio directly at service@peachtreeaudio.com or +1-704-
391-9337 to obtain a Return Authorization (RA) number prior to shipping the product.
Any products received without an RA number may be misdirected and repair delayed.
If a RA number is issued by Peachtree Audio, please ship the product using FedEx or
UPS. Do not ship using a Postal Service.
Peachtree Audio assumes no responsibility for products in transit. Please insure the
shipment for the product’s replacement value in the unlikely event it is lost, stolen or
damaged in transit.
US Shipping Address:
Peachtree Audio
2045 120th Avenue N.E.
Bellevue, WA 98005
USA
RA# __________
www.peachtreeaudio.com
SPECIFICATIONS
SPEAKER OUTPUT Decco125
Compatible Speakers 4-16Ω
Output Power (WPC, 8Ω, <1% THD+N, AES17) 120
Frequency Response (20 - 20kHz) <+/-3dB
Inter-Modulation Distortion (100Hz, 2kHz 4:1 -30dBFS) -60dB
Total Harmonic Distortion (AES17, 1kHz, 4Ω, 1W) 0.03%
Channel Separation (1kHz, 8Ω) 94dB
PREAMP OUTPUT
Output Voltage (rms) 920mV
Output Impedance 100Ω
Signal-to-Noise Ratio (Analog | Digital Source, un-weighted) 100dB
Channel Separation (1kHz) 92dB at 1kHz
Frequency Response (Analog | Digital Source, 8Hz-20kHz) +/- 0.1dB 20-20k
Total Harmonic Distortion 0.007% (1V rms, 1kHz, A-weighted)
Noise (RMS, A-weighted) <7uV
HEADPHONE OUTPUT
Output Power (32Ω, rms) 17mW
Signal-to-Noise Ratio (un-weighted) 107dB
Channel Separation (1kHz) 102dB
Frequency Response (Analog source, 8Hz-100kHz) +/- 0.5dB
Total Harmonic Distortion 0.01%
USB-B Input
Formats 16-24 Bit, 44.1-96kHz PCM
COAX and OPT Inputs
Formats 16-24 Bit, 44.1-96kHz PCM
AUX Inputs
Maximum Voltage (rms | peak-to-peak) 840mV
Impedance 10k
PHONO Input
Maximum Input Voltage (rms) 18mV@1kHz (RIAA Filter +/- 1dB)
Impedance 47k
AC Power
AC Input 100-240VAC, 50/60Hz
Maximum Power Consumption 400W
On Mode (Idle) Power Consumption 18W
Standby Mode Power Consumption <2W
Fuse
100-120VAC: 3.15 A/250V (IEC time lag high
breaking capacity)
Physical
Height (including feet) 89 mm | 3.50 inches
Width 250 mm | 9.84 inches
Depth (Cabinet depth (320mm) plus volume knob (18mm) plus binding posts (25mm)) 363 mm | 14.29 inches
Weight (shipping) 10 lbs (13.5 lbs), 4.8 kg (6.1 kg)
SPEAKER OUTPUT Decco125
Compatible Speakers 4-16Ω
Output Power (WPC, 8Ω, <1% THD+N, AES17) 120
Frequency Response (20 - 20kHz) <+/-3dB
Inter-Modulation Distortion (100Hz, 2kHz 4:1 -30dBFS) -60dB
Total Harmonic Distortion (AES17, 1kHz, 4Ω, 1W) 0.03%
Channel Separation (1kHz, 8Ω) 94dB
PREAMP OUTPUT
Output Voltage (rms) 920mV
Output Impedance 100Ω
Signal-to-Noise Ratio (Analog | Digital Source, un-weighted) 100dB
Channel Separation (1kHz) 92dB at 1kHz
Frequency Response (Analog | Digital Source, 8Hz-20kHz) +/- 0.1dB 20-20k
Total Harmonic Distortion 0.007% (1V rms, 1kHz, A-weighted)
Noise (RMS, A-weighted) <7uV
HEADPHONE OUTPUT
Output Power (32Ω, rms) 17mW
Signal-to-Noise Ratio (un-weighted) 107dB
Channel Separation (1kHz) 102dB
Frequency Response (Analog source, 8Hz-100kHz) +/- 0.5dB
Total Harmonic Distortion 0.01%
USB-B Input
Formats 16-24 Bit, 44.1-96kHz PCM
COAX and OPT Inputs
Formats 16-24 Bit, 44.1-96kHz PCM
AUX Inputs
Maximum Voltage (rms | peak-to-peak) 840mV
Impedance 10k
PHONO Input
Maximum Input Voltage (rms) 18mV@1kHz (RIAA Filter +/- 1dB)
Impedance 47k
AC Power
AC Input 100-240VAC, 50/60Hz
Maximum Power Consumption 400W
On Mode (Idle) Power Consumption 18W
Standby Mode Power Consumption <2W
Fuse 100-120VAC: 3.15 A/250V (IEC time lag high
breaking capacity)
Physical
Height (including feet) 89 mm | 3.50 inches
Width 250 mm | 9.84 inches
Depth (Cabinet depth (320mm) plus volume knob (18mm) plus binding posts (25mm)) 363 mm | 14.29 inches
Weight (shipping) 10 lbs (13.5 lbs), 4.8 kg (6.1 kg)
All specications subject to change without notice
125
AC~IN
RoHS
CAU TI ON
RISK O F ELECTRIC S HOCK
TO REDUCETHE RISK OF ELECTRIC SHOCK,
DO NOTEXPOSETHIS EQUIPMENT
TO RAIN OR MOISTURE !
DO NOT O PEN
WARN IN G
ANT-1 ANT-2
Gnd.
SERV ICE
SERV ICE
ONLY
OPTICAL
INPUT
USB-B
INPUT
SPEAKER
OUTPUT
RIGHT
SPEAKER
OUTPUT
LEFT
L
L
L
R
R
R
PHONO
PREOUT
AUX
Serial NumberMADE IN CHINA
DESIGNED IN CANADA Type: IntegratedAmplifier
Model: Decco125
Maximum power consumption is 400W
125
