Signal Technology RTC2400 Remote Telemetry Transmitter User Manual RTG Manual
Signal Technology Corporation Remote Telemetry Transmitter RTG Manual
Contents
- 1. User Manual
- 2. user manual
user manual
1
2
Information in this document, including URL and internet website references, is subject to change without
notice. Complying with all applicable copyright laws is the responsibility of the user. Without limiting the
rights under copyright, no part of this document may be reproduced, stored or introduced into a retrieval
system, or transmitted in any for or by any means (electronic, mechanical, photocopying, recording or
otherwise), or for any purpose, without the express written permission of Crane WMS. Crane WMS may
have patents, patent applications, trademarks, copyrights or other intellectual property rights covering
subject matter in this document. Except as expressly provided in any written license agreement from Crane
WMS, the furnishing of this document does not give you any license to these patents, trademarks,
copyrights, or other intellectual property.
©2007 Crane WMS. All right reserved.
Crane WMS & VantedgePoint are registered trademarks of Signal Technology in the United States and other
countries.
3
Table of Contents:
SPECIFICATIONS............................................................................................4
REGULATORY INFORMATION.....................................................................6
LIMITED WARRANTY .....................................................................................7
WIRELESS REMOTE TELEMETRY CONTROLLER ............................................7
SAFETY INFORMATION.................................................................................8
Follow Instructions to Avoid Interference Problems ...........................8
Pacemakers.............................................................................................8
Hearing Aids ...........................................................................................8
CONTACT INFORMATION.............................................................................9
4
Specifications
9
Some digital devices may interfere with some hearing aids. In the event of such
interference, you may want to consult your hearing aid manufacturer or physician to
discuss alternatives.
Contact Information
Visit us online: www.cranewms.com
Call our office: (972) 964-5178
Fax our office: (972) 964-5968
Email us: sales@cranewms.com
support@cranewms.com
8
Wireless Remote Telemetry Gateway Software
The seller makes no warranty or representation that its software products will meet
Customer’s requirements or work in combination with any hardware or software
applications products provided by third parties, that the operation of the software
products will be uninterrupted or error free, or that all defects in the software products
will be corrected
Safety Information
1. Do not use this apparatus near water.
2. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
3. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized
plug has two blades with one wider than the other. A grounding-type plug has two
blades and a third grounding prong. The wide blade or the third prong is provided for
your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
4. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
5. Only use attachments/accessories specified by the manufacturer.
6. Refer all servicing to qualified service personnel. Servicing is required when the unit
has been damaged in any way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the unit, the unit has been exposed to rain
or moisture, does not operate normally, or has been dropped.
7. No open flame sources, such as lighted candles, should be placed on the apparatus.
8. The unit shall not be exposed to dripping or splashing. No objects filled with liquids,
shall be placed on the unit.
9. The unit is for indoor use only. Operation outside requires the use of an appropriate
sealed enclosure.
Warnings
Follow Instructions to Avoid Interference Problems
Turn off your device in any location where posted notices instruct you to do so. These
locations include any facility that may be using equipment that is sensitive to external
RF energy.
Pacemakers
If you have a pacemaker, consult your physician before using this device.
Persons with pacemakers should observe the following precautions:
o ALWAYS keep the device more than 20 centimeters (8 inches) from your
pacemaker when the device is turned ON.
o Turn OFF the device immediately if you have any reason to suspect that
interference is taking place.
Hearing Aids
5
6
7
Regulatory Information
This device complies with Part 15 of the FCC Rules subject to the following two
conditions; (1) This device may not cause harmful interference and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. The antennas should be installed and operated with
minimum distance 25cm from all persons and must not be co-located or operating in
conjunction with any other antenna or transmitter. End-users and installers must be
provided with antenna installation instructions and transmitter operating conditions for
satisfying RF exposure compliance.
Caution: FCC approved RF operation of this equipment is permitted only with the
approved antennas, cable and connectors provided with this product. Use of
unauthorized antennas, modifications or attachments could damage the device and/or
may result in your device not complying with local regulatory requirements in your
country.
Wireless LAN antenna installation:
FCC regulates that this product may be used with a 5.5 dBi (or less) Omni directional
antennae. User should only use antennas supplied by Crane WMS.
Cellular antenna installation:
This device contains a certified cellular radio module (FCC ID QIPTC63) with GSM and
GPRS Class 12 functions in the 900 and 1800MHz Band which are not operational in
U.S. Territories. This device is to be used only for mobile and fixed applications. The
antenna(s) used for this transmitter must be installed to provide a separation distance
of at least 25cm from all persons. Antennas used for the cellular radio module must not
exceed 2.98dBi (GSM850) and 8.4dBi gain (GSM 1900) for mobile and fixed operating
configurations.
FCC Notice: Changes or modifications to this device not expressly approved by the
manufacturer could void the user’s authority to operate the equipment.
For more details on legal combinations of power levels and antennas, contact Crane
WMS.
Limited Warranty
Wireless Remote Telemetry Controller
The seller warrants to the end user (Customer) that this hardware product will be free
from defects in workmanship and materials, under normal use and service, for 1 year
from the date of purchase from the seller or its authorized reseller. The seller’s sole
obligation under this express warranty shall be, at the seller’s option and expense, to
repair the defective product or part, deliver to Customer an equivalent product or part to
replace the defective item, or if neither of the two foregoing options is reasonably
available, The seller may, in its sole discretion, refund to the Customer the purchase
price paid for the defective product. All products that are replaced will become the
property of the seller. Replacement products may be new or reconditioned.
