SR24NP-User Manual-2016-05-31
INTRODUCTION
SR24NP module is a highly- integrated, single-chip, 2.4G wireless transceiver. It is equiped with
two antennas which can overcome the disadvantages of the single directional antenna as well as
enhance signal stability and transmission distance. It also has two serial ports to connect with
corresponding serial devices. it can be flexibly configured for RF front-end transmitter or receiver
in the model aircraft system. Its transmitter power can be set from 0dB to 4.5dBm by software.
the operation mode of the antenna with two transmitters and two receivers .
SPECIFICATIONS:
Dimension：20.5mm*30.15mm*0.8mm
Electrical Characteristics：
ITEM TEST REQUIREMENT REMARKS
Voltage supply 2.0－3.6V DC
Center frequency 2400－2483.5MHz Programmable
Frequency error 50KHz
Modulation DSSS-OQPSK
Output power 0-4.5dBm Programmable
Receiving sensitivity -97dBm @250Kbps data rate
Receiving current 29.6mA
Transmitting current 39.6mA Po=4.5dBm
Sleep consumption 0.4mA
1uA
Power Mode 1
Power Mode 3
Data rate 250kbps typical
Transmit distance 100M At open area
Antenna SISO, Dipole Antenna Gain:1dBi
Size 20.5*31.5mm
Operation temperature -30 to+85°C Base on crystal performance
OPERATIONS：
STEP 1}: Connected to a 3.3V DC power supply
STEP 2): Connect to main control board through UART port.
NOTICE: It can be used as transmitter module as well as receiving module, realizing
intercommunication.
FCC STATEMENT:
This equipment has been tested and found to comply with the limits for Part 15 of the
FCC rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Any changes or modications not expressly approved by the party
responsible for compliance could void the user's authority to operate this equipment.
RF EXPOSURE WARNING
• This equipment must be installed and operated in accordance with provided
instructions and the antenna(s) used for this transmitter must be installed to provide a
separation distance of at least 20 cm from all persons and must not be co-located or
operating in conjunction with any other antenna or transmitter. End-users and
installers must be provide with antenna installation instructions and transmitter
operating conditions for satisfying RF exposure compliance.
IC RADIATION EXPOSURE STATEMENT FOR CANADA
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference
that may cause undesired operation of the device.
Le présentappareilestconforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitationestautorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de
l'appareildoit accepter tout brouillageradioélectriquesubi, mêmesi le brouillageest
susceptible d'encompromettre le fonctionnement.
This equipment complies with IC RSS-102 radiation exposure limit set forth for an
uncontrolled environment.
Cetéquipementrespecte les limitesd'exposition aux rayonnements IC dénies pour un
environnement non contrôlé
CE WARNING STATEMENT
Wi-Fi function of this device is restricted only to indoor use when operating in the
5150-5250MHz frequency range.
NCC WARNING STATEMENT
Without permission, any company, firm or user shall not alter the frequency, increase
the power, or change the characteristics and functions of the original design of the
certified lower power frequency electric machinery. The application of low power
frequency electric machineries shall not affect the navigation safety nor interfere a
legal communication, if an interference is found, the service will be suspended until
improvement is made and the interference no longer exists.
CUSTOMER SERVICE
Manufacturer:
Yuneec International (China) Co., Ltd.
Production Address:
East Zhengwei Road No.388, Jinxi Town, Kunshan City, Jiangsu Province
Distributor:
CN: Youyu (Shanghai) Digital Technology Co.,Ltd.
US: Yuneec USA Inc.
Address: 5555 Ontario Mills Parkway, Ontario, CA91764, USA 1 855
2848888
Phone: 1-909-259-5113
EU: Yuneec Europe GmbH
Address: Niklaus–Otto-Strasse 4, 24568 Kaltenkirchen, Germany.
