示意圖方式：
正面 反面
515300170947
(客戶): Philips
(材質): 80g銅版紙
(上光方式): NO
(顏色): Black
(尺寸): 210x297mm
(公差): +-1mm
Installation
Instructions
LCN1840
PUSH
Items delivered
Items not delivered / Tools required
Installation Instructions
Instructions d’installation Installationsanweisungen Instrucciones de instalación
Istruzioni per l’installazione Installatie-instructies インストール手順 ȫ̕ϱФ
www.lighting.philips.com4422 107 06951 24 August 2017
Wireless Gateway
LCN1840
1
89 mm (3.5 in)
26 mm
(1.0 in)
89 mm (3.5 in)
-+
5V DC 1A
LAN2
LAN1
2
min
-20 °C
max
50 °C
3
IP20
min
-4 °F
max
122 °F
4422 107 06951_LCN1840_WG_20170824_Fin.indd 1 8/24/17 5:11 PM
2
a
3
1
bInstall the WG-Pro
on a visible location.
The QR-code must
be read during
commissioning (step 7).
4
-+
5VDC/1A
LAN2
LAN1
RJ45 port
5
Power
LAN connection
Cloud connection
Connect
power
LED on =
1
2
6
Luminaire
sensor
Luminaire
sensor
n-Nodes
Min. 0.5 m (1.6 ft)
Max. 10 m (33 ft)
7
