Silent Herdsman 2110013 Silent Herdsman Base Station User Manual
Silent Herdsman Limited Silent Herdsman Base Station Users Manual
Users Manual
Silent Herdsman Limited is a limited company registered in Scotland. Company Registration No: SC333487
Registered Offices: Unit 9000, Academy Park, 51 Gower Street, Glasgow, G51 1PR, Scotland
Silent Herdsman® Base Station
Quick Start
Version: 1.3
Silent Herdsman® Base Station User Guide
October 2015
2
Version: 1.3
Silent Herdsman Limited is a limited company registered in Scotland. Company Registration No: SC333487
Registered Offices: Unit 9000, Academy Park, 51 Gower Street, Glasgow, G51 1PR, Scotland
1 Introduction
The Silent Herdsman® Base Station is a unit that provides the gateway between the Silent
Herdsman collars and the Management computer.
Silent
Herdsman®
Management
Computer
Network
Router
Silent
Herdsman® Data
Gathering
Basestation
Silent
Herdsman®
Collar
Figure 1 – Silent Herdsman System overview
The enclosure is mounted on a structure using the 4 mounting lugs and the supplied
antenna is attached to the antenna connector.
The network cable is attached to the Ethernet socket on the enclosure using the connector
supplied to ensure that it is weatherproofed.
Figure 2 – Silent Herdsman Base Station
Ethernet
Antenna
Mounting
Lug
Mounting
Lug
Silent Herdsman® Base Station User Guide
October 2015
3
Version: 1.3
Silent Herdsman Limited is a limited company registered in Scotland. Company Registration No: SC333487
Registered Offices: Unit 9000, Academy Park, 51 Gower Street, Glasgow, G51 1PR, Scotland
EC Declaration of Conformity
Manufacturer: Silent Herdsman Ltd,
Unit 9000, Academy Park,
Glasgow,
G51 1PR
Product / Apparatus: Silent Herdsman Base Station
Type Number: 2110013
Variants include: All country variations
Declaration
I declare that above product is in conformity with the essential requirements and other
relevant requirements of the R&TTE Directive (1999/5/EC), EMC Directive, 2004/108/EC
and the Low Voltage Directive 2006/95/EC. The product is in conformity with the following
standards and/or other normative documents:
EN 300 328 V1.8.1 (2012-06)
EN 55022:2010;
EN 55024:2010;
EN 301 489-1 v1.9.2
EN 301 489-17 v2.2.1:2012
EN60950-1:2006 +A11:2009 +A1:2010 +A12:2011
EN60950-22:2006
Signature: ......................................................................
Name: Alan Faichney
Title: Chief Technology Officer
Date: 26/10/2015
Waste Electric and Electronic Equipment
User Information for Consumer Products Covered by EU Directive 2002/96/EC on
Waste Electric and Electronic Equipment (WEEE)
This document contains important information for users with regards to the proper disposal
and recycling of Silent Herdsman products. Consumers are required to comply with this
notice for all electronic products bearing the ‘bin’ symbol shown:
European Directive 2002/96/EC requires that the equipment bearing this
symbol on the product and/or its packaging must not be disposed of with
unsorted municipal waste. The symbol indicates that this product should be
disposed of separately from regular household waste streams. It is your
Silent Herdsman® Base Station User Guide
October 2015
4
Version: 1.3
Silent Herdsman Limited is a limited company registered in Scotland. Company Registration No: SC333487
Registered Offices: Unit 9000, Academy Park, 51 Gower Street, Glasgow, G51 1PR, Scotland
responsibility to dispose of this and other electric and electronic equipment via designated
collection facilities appointed by the government or local authorities. Correct disposal and
recycling will help prevent potential negative consequences to the environment and human
health. For more detailed information about the disposal of your old equipment, please
contact your local authorities, waste disposal service, or supplier of the product.
FCC warning statement:
Device, FCC ID 2ABHT2110013, complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that
may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. End users must follow the specific operating instructions
for satisfying RF exposure compliance. This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Antenna modifications:
This intentional radiator may only be operated with the antenna types with which it is
authorized:
1. The antenna type, as used, refers to antennas that have similar in-band and
out-of-band radiation patterns.
2. The following list of authorized antenna types:
Rubber Duck/Omni-directional indoor antenna, 9dBi gain, 2400-
2500MHz [NET-WL-ANT009OTC];
Outdoor Omni Antenna, 9dBi gain, 2400-2483MHz [SH-A-RTNC09O];
Outdoor Omni Antenna, 9dBi gain, 2400-2483MHz with 1 meter cable
extension [SH-A-RTNC09O1M];
Outdoor Omni antenna, 15dBi gain, 2400-2500MHz [SH-A-RTNC15O];
Outdoor Omni antenna, 15dBi gain, 2400-2500MHz with 1 meter cable
extension [SH-A-RTNC15O1M];
Any antenna that is of the same type and of equal or less directional gain as an
antenna that is authorized with the intentional radiator may be marketed with, and
used with, this intentional radiator, guarantees that the antenna doesn’t have
standard electrical sockets will be made according to the Unique Antenna
Connection Statement.
Copyright and Trademarks
Silent Herdsman® Base Station User Guide
October 2015
5
Version: 1.3
Silent Herdsman Limited is a limited company registered in Scotland. Company Registration No: SC333487
Registered Offices: Unit 9000, Academy Park, 51 Gower Street, Glasgow, G51 1PR, Scotland
‘Silent Herdsman’ and Embedded Technology Solutions Logo are registered trademarks of
Silent Herdsman Holdings Limited. Other brands and product names are trademarks or
registered trademarks of their respective holders.
© 2007 - 2015 Silent Herdsman Limited. All rights reserved.
See www.silentherdsman.com for further information.
