SX-10WAN Users Manual
1/1
April 21, 2009
SX-10WAN Users Manual
1. Hardware specifications/Compliance................................................... 2
2. System Requirements (for the install) .................................................. 5
3. Setup.............................................................................. 5
silex technology,lnc.
１
SX-10WAN Users Manual
2/2
1. Hardware specifications/Compliance
FCC ID：N6C-SX10WAN
NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
This equipment complies with FCC radiation exposure limits set forth for uncontrolled equipment and meets the
FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65. This equipment should be installed and
operated with at least 20cm and more between the radiator and persons body (excluding extremities: hands,
wrists, feet and ankles).
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation
FCC WARNING：
Changes or modifications not expressly approved by the party responsible for compliance could void the users
authority to operate the equipment.
Canada
『This device complies with Part 15 of the FCC Rules and RSS-Gen of the IC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.』
- The device for the band 5150-5250MHz is only for indoor usage to reduce potential for harmful
interference to co-channel Mobile Satellite systems.
- The maximum antenna gain permitted (5250-5350MHz devices) to comply with the EIRP limit.
- Users should also be cautioned to take note that high power radars are allocated as primary users
(meaning they have priority) of 5250-5350MHz and 5650-5850MHz and these radars could cause interference
and/or damage to LELAN devices.
SX-10WAN Users Manual
3/3
Operating environment ： Temperature：+0°C to +70°C, +32F to +140F
Humidity：20% to 90%
Storage environment ： Temperature：-10°C to +80°C, +14F to +158F
Humidity：5% to 90%
supply voltage ： 3.3V ± 0.3V
Host I/F ： miniPCI signal alternative original I/F
IEEE802.11b ： Frequency : 2412MHz~2462MHz
Transmission system ： DS-SS
Transmission speed： 1M/2M/5.5M/11M
Automatic detection
Channel：1−11ch
IEEE802.11g ： Frequency : 2412MHz~2462MHz
Transmission system：OFDM
Transmission speed ：6M/12M/18M/36M/48M/54M
Automatic detection
Channel：1−11ch
IEEE802.11a ： Frequency : 5180MHz~5320MHz 5745MHz~5825MHz
Transmission system：OFDM
Transmission speed ：6M/12M/18M/36M/48M/54M
Automatic detection
Channel：36−64ch 149−165ch
IEEE802.11n(2.4G HT20) : Frequency : 2412MHz~2462MHz
Transmission system：OFDM
Transmission speed ：MCS0~MCS15
Automatic detection
Channel：1−11ch
IEEE802.11n(2.4G HT40) : Frequency : 2422MHz~2452MHz
Transmission system：OFDM
Transmission speed ：MCS0~MCS15
Automatic detection
Channel：3,9ch
SX-10WAN Users Manual
4/4
IEEE802.11n(5G HT20) ： Frequency : 5180MHz~5320MHz 5745MHz~5825MHz
Transmission system：OFDM
Transmission speed ：MCS0~MCS15
Automatic detection
Channel：36−64ch 149−165ch
IEEE802.11n(5G HT40) ： Frequency : 5190MHz~5310MHz 5755MHz~5795MHz
Transmission system：OFDM
Transmission speed ：MCS0~MCS15
Automatic detection
Channel：38−62ch 151−159ch
Antenna interface ： Diversity connector
silex technology,lnc.
3
SX-10WAN Users Manual
5/5
2. System Requirements (for the install)
PC containing:
・32-bit CardBus slot (or Desktop PC with PC Card-PCI adapter)
・miniPCI signal alternative original connector
・32 MB memory or greater
・300 MHz processor or higher
When this module is installed in the host product, you must include a "Contain FCC ID : N6C-SX10WAN"
and a Contain IC: 4908B-SX10WAN in the label of the host product.
3. Setup
It uses Driver and a utility of Atheros Communications. （Atheros client utility）
It completes installation according to setup Wizard
