Silex Technology SX10WG Wireless 802.11b/g transmitter module User Manual
Silex Technology, Inc. Wireless 802.11b/g transmitter module Users Manual
Users Manual
Sep 29,2005
1. Hardware specifications/Compliance・・・・・・・・・・・・・・・・・・・・2
2.System Requirements・・・・・・・・・・・・・・・・・・・・・・・・・・・4
3.Setup ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・4
SX-10WG Users Manual
SX-10WG Users Manual
silex technology,lnc.
1
FCC ID:N6C-SX10WG
NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-Consult the dealer or an experienced radio/TV technician for help.
This transmitter must not be co-located or operated in conjunction with any other antenna or
transmitter.
This equipment complies with FCC radiation exposure limits set forth for uncontrolled equipment and
meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65. This equipment
should be installed and operated with at least 20cm and more between the radiator and person’s body
(excluding extremities: hands, wrists, feet and legs).
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation
FCC WARNING:
Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
1 Hardware specifications/Compliance
SX-10WG Users Manual
silex technology,lnc.
2
Operating environment : Temperature:+0°C to +55°C, +32F to +131F
Humidity:20% to 90%
Storage environment : Temperature:-10°C to +60°C, +14F to +140F
Humidity:5% to 90%
supply voltage : 3.3V ± 0.3V
Host I/F : MiniPCI
IEEE802.11b : Frequency : 2.4GHz
Transmission system : DS-SS
Transmission speed: 1M/2M/5.5M/11M
Automatic detection
Channel:1-11ch
IEEE802.11g : Frequency : 2.4GHz
Transmission system:OFDM
Transmission speed :6M/12M/18M/36M/48M/54M
Automatic detection
Channel:1-11ch
Antenna interface : Diversity connector
SX-10WG Users Manual
silex technology,lnc.
3
Laptop/ PC containing:
. 32-bit CardBus slot (or Desktop PC with PC Card-PCI adapter)
. Mini PCI
. 32 MB memory or greater
. 300 MHz processor or higher
It uses Driver and a utility of Atheros Communications. (AR5BMB5 client utility)
It completes installation according to setup Wizard.
silex technology,lnc.
SX-10WG Users Manual
6
SX-10WG Users Manual
silex technology,lnc.
4
2
System
R
equir
e
ments
3 Setup
