KOMPERNASS GMBH
BURGSTRASSE 21 · D-44867 BOCHUM
www.kompernass.com
ID-Nr.: SHMS300A1-04/10-V2
KITCHEN TOOLS
Hand Mixer Set SHMS 300 A1
Hand Mixer Set
Operating instructions
CY
6
CV_53198_SHMS300A1_LB6.qxd 28.05.2010 11:37 Uhr Seite 1
SHMS 300 A1
q
y
a
h
s
o
g
i
t
r
e
w
u
fd
CV_53198_SHMS300A1_LB6.qxd 28.05.2010 11:37 Uhr Seite 4
- 1 -
CONTENT PAGE
Intended Use 2
Technical data 2
Important safety instructions 2
Items supplied 3
Description of Components 3
Unpacking 3
Placing 3
Speed levels 4
Operation 4
Kneading and Whisking..................................................................................................................4
Blending.............................................................................................................................................5
Cleaning 6
Disposal 6
Warranty and Service 7
Importer 7
Read the operating instructions carefully before using the appliance for the first time and preserve this
booklet for later reference. Pass the manual on to whomsoever might acquire the appliance at a later date.
IB_53198_SHMS300A1_LB6 28.05.2010 13:59 Uhr Seite 1
- 2 -
HAND MIXER SET
Intended Use
This Hand mixer set is suitable for kneading dough,
mixing liquids (e.g. fruit juices), whipping cream and
pureeing fruit. It is only suitable for foodstuffs. All other
usages or modifications are regarded as contrary to
the operating instructions and contain a great risk of
accidents. The manufacturer refuses to accept liability
for damage(s) resulting from usage that is contrary
to these instructions. Not for commercial use.
Technical data
Power rating: 230-240V~50Hz
Rated output: 300W
Protection class: II /
CCoonnttiinnuuoouuss
ooppeerraattiinngg ttiimmee: Mixer: 10 min.
Blender: 1 min.
CO Time
The C.O. Time (Continuous Operation) details how
long an appliance may be used without the motor
overheating and being damaged. When the given
C.O. Time has lapsed, the appliance must be switched
off until the motor has cooled itself down.
Important safety instructions
Warning:
• This appliance is not intended for use by individuals
(including children) with restricted physical, physio-
logical or intellectual abilities or deficiences in
experience and/or knowledge unless they are
supervised by a person responsible for their safety
or receive from this person instruction in how the
appliance is to be used.
• Children should be supervised to ensure that
they do not play with the appliance.
• Do not use the hand mixer outdoors. The appliance
is intended exclusively for domestic use indoors.
• Unplug the power cable after every use and
before cleaning, so as to prevent the appliance
from switching itself on inadvertently.
• Before exchanging accessories, ALWAYS remove
the plug from the mains power socket.
• Do not leave the appliance unsupervised.
Should you need to leave the workplace, remove
the plug from the mains power socket.
• When removing the plug from the mains power
socket, always pull the plug itself, never the power
cable.
• Never touch any parts of the appliance that are
in motion, always wait for them to come to a
complete stop.
• Before each use, check the appliance and all
parts for any visible damage. The safety concept
for the appliance can only work when it is in a
faultfree condition.
• Under NO circumstances should you use the ap-
pliance if parts are damaged or missing. If you
do, there will be an increased risk of accidents.
• Arrange for all repairs to be carried out only by
specialists. If need be, approach our Service
Partner responsible for your country.
IB_53198_SHMS300A1_LB6 28.05.2010 13:59 Uhr Seite 2
- 3 -
Do not submerge the blender or the hand mixer
in water. If necessary, clean the lower part of
the blender with the blade under running wa-
ter. The ap-pliance could become irreparably
damaged if it is submerged.
• Arrange for defective power plugs and/or cables
to be replaced at once by qualified technicians
or our Customer Service Department.
Risk of Injuries:
• During use, do not come into contact with the
whisk, the kneading hooks or the knife on the
blender. The blade of the blender is sharp.
Therefore, ALWAYS handle the blender with
care. Do not allow long hair, scarves and such
like to hang over the mixing attachments.
• NEVER attempt to assemble ancillaries with
differing functions at the same time.
Risk of electrical shocks.
• The power cable must never come into close
contact with hot parts of the appliance or other
sources of heat. Do not allow the power cable
to lie on sharp rims or edges.
• Do not fold or crush the power cable.
Items supplied
1 Hand mixer
1 Mixing stand
1 Mixing bowl with lid
2 Kneading hooks
2 Whisks
1 Blender
1 Dough scraper
Operating instructions
Description of Components
1Speed switch
2Fixture for the blender, with safety cover
3Power cable with power plug
4Release button
5Unlocking button
6Mixing stand
7Mixing bowl
8Filler opening
9Lid
0Turbo button
qEjection button
wBlender
eWhisk made of stainless steel
rKneading hooks made of stainless steel
tDough scraper
Unpacking
• Take all components out the packaging.
• Remove all packaging materials and transport
restraints.
• Check that all of the items listed are present and
that they do not show signs of damage.
Placing
• Place the mixer stand 6onto a level surface.
Three suction discs have been fixed to the base
of the mixer stand 6to prevent it sliding during
operation.
• Ensure that the mains power socket is easily
accessible in the event of a risk situation.
IB_53198_SHMS300A1_LB6 28.05.2010 13:59 Uhr Seite 3
- 4 -
Speed levels
0 Appliance is switched off
1 Good starting speed for mixing "soft" ingredients
such as flour, butter, etc.
2 Best speed for blending liquid ingredients
3 Optimum speed for mixing cake and bread
dough
4 For whipping butter to form a fine foam, sugar,
for desserts etc.
5 For beating egg whites, cake glazing, cream etc.
For operating the blender:
Only usable in combination with the turbo button.
Turbo:
• this button allows you to have the full power of
your appliance immediately at your disposal.
• for operating the blender
Operation
Kneading and Whisking
Warning:
Do not operate the mixer for longer than 10 minutes
in one session. After 10 minutes, allow the appliance
to rest until it has cooled itself down.
1. Before the first usage, clean the attachments
(w,e,r), the mixing bowl 7and the lid 9.
2. Insert the whisk eor the kneading hooks r
into the appliance until they securely and audibly
engage.
Always insert the kneading hook ror the whisk e
with the cogged wheel into the predetermined
opening (marked with a cog wheel) on the
handmixer.
3. Release the mixer holder by pressing the release
button for tilting 5and lift the mixer holder up-
wards.
4. Remove the mixing bowl 7and fill it with the
quantities of ingredients to be prepared.
Warning:
• NEVER fill the mixing bowl 7beyond the Max
marking (approx 2.5 l) with ingredients. If you
do, there is a risk they could spill over the edge
during operation.
• Never fill the mixing bowl 7with more than a
total of 1.5 kg of ingredients. Otherwise the
motor may be damaged.
5. Replace the mixing bowl 7onto the mixing
stand 6.
6. Press the release button for tilting 5and lower
the holder downwards.
7. Place the hand mixer on the holder so that it
firmly engages.
8. Slide the lid 9into the guiderails on the mixing
bowl 6so that it is firmly seated.
Note:
Should you wish to add ingredients whilst mixing,
open the filler opening 8and insert them through
it. To avoid a splattering of the ingredients, be sure
to reclose the filler opening 8!
You can also use the hand mixer without the mixing
stand 6. Especially with minor amounts of liquids
you are advised to use the hand mixer without the
mixing stand 6. Otherwise, the liquid may not be
completely captured and thus not mixed thoroughly.
IB_53198_SHMS300A1_LB6 28.05.2010 13:59 Uhr Seite 4
- 5 -
Warning:
Under no circumstance should you use receptacles
made of glass or other very fragile/easily breakable
materials. These containers can be damaged and
then cause potentially serious injuries.
9. Insert the plug 3into a mains power socket.
10. To set the mixer into motion, push the speed
switch 1to the desired speed setting. You
can select between 5 speed settings or the
turbo button 0(see section "Speed levels").
Warning:
Do not operate the mixer for longer than 10 minutes
in one session. After 10 minutes, allow the appliance
to rest until it has cooled itself down.
Note:
If ingredients become stuck to the side of the mixing
bowl 7and they cannot be captured with the
kneading hooks r/ whisks e, switch the hand mixer
off. Remove the lid 9. Use the dough scraper tto
push them back into the middle of the mixing bowl 7.
Replace the lid 9. Switch the hand mixer back on.
11. To remove the bowl contents, switch the appli-
ance off. Pull the lid 9to the side and remove
it. Press the release button for tilting 5, lift the
holder upwards and remove the mixing bowl 7
from the mixing stand 6.
Note:
In the case of larger amounts in the mixing bowl 7,
it is to be recommended that you first remove the
mixer from the holder.
12. Press the release button 4to remove the hand
mixer and the ejection button qto release the
whisks eor the kneading hooks r.
Note:
For safety reasons, the whisks eor the dough
hooks rcan only be released when the speed
switch 1is in the position "0" or " " shows.
Blending
Warning:
Never use the blender wfor hard foodstuffs such as:
coffee beans, ice cubes, sugar, cereals, chocolate,
raw/hard vegetables etc. They could cause serious
damage to the appliance.
Warning:
Under no circumstance should you use receptacles
made of glass or other very fragile/easily breakable
materials. These containers can be damaged and
then cause potentially serious injuries.
1. Open the fixture for the blender 2and hold the
safety cover 2firmly.
Note:
The blender wcan only be utilised when the whisks
eor the kneading hooks rare not installed.
2. Insert the blender wuntil it engages and then
twist it firmly tight.
3. To avoid overflows, the container used for blending
should only be filled to 2/3rds of its capacity.
Select a sufficiently large container.
Tips:
• To ensure an effective blending of the ingredients,
the foodstuffs to be processed should cover at
least the lower section of the blender w.
• First switch the hand mixer on when the blender w
has been inserted into the ingredients to be
blended.
IB_53198_SHMS300A1_LB6 28.05.2010 13:59 Uhr Seite 5
- 6 -
4. Push the speed switch 1into the position "Blender"
(s. section " Speed levels“) and press the Turbo
button 0. Keep the Turbo button 0pressed down
during the whole procedure. The appliance stops
as soon as it is released.
Warning:
Do not operate the blender wfor longer than 1
minute in one session. After one minute, allow the
appliance to rest until it has cooled itself down.
5. When you have finished working with the blen-
der w, place the speed switch 1back into the
position "0" and remove the plug from the mains
power socket.
6. To clean the blender wtwist and remove it from
the retaining mechanism 2.
Warning:
Clean only the lower part of the blender wunder
running water. Under no circumstances may water
permeate into the blender w. This could result in
damage to the appliance.
Cleaning
Warning:
Always remove the power plug before cleaning the
appliance. There is a risk of receiving an electric
shock!
UNDER NO CIRCUMSTANCES may the
hand element be submersed in water or other
liquids! ! This would increase the risk of a
potentially fatal electric shock should liquids
come into contact with powered components.
• Clean the hand element with the electric motor
only with a damp cloth and, if necessary, with
a mild detergent.
• Clean the mixing stand 6only with a moist
cloth and, if required, with a mild cleaning deter-
gent.
• The whisks eand the kneading hooks rcan
be cleaned under running water or in the dish-
washing machine.
Warning:
Clean only the lower part of the blender wunder
running water. Under no circumstances may water
permeate into the blender w. These could result in
damage to the appliance.
• We recommend cleaning the ancillaries directly
after use. Food remnants are then immediately
removed, greatly reducing the risks of bacterial
contamination.
• Clean the mixing bowl 7, the lid 9and the
dough scraper tin warm water with washing-
up liquid.
Disposal
Do not dispose of the appliance in your
normal domestic waste. This product is
subject to the European guideline
2002/96/EC.
Dispose of the appliance through an approved waste
disposal centre or at your community waste facility.
Observe the currently applicable regulations.
In case of doubt, please contact your waste disposal
centre.
Dispose of all packaging materials in an
environmentally friendly manner.
IB_53198_SHMS300A1_LB6 28.05.2010 13:59 Uhr Seite 6
- 7 -
Warranty and Service
The warranty for this appliance is for 3 years from
the date of purchase. The appliance has been ma-
nufactured with care and meticulously examined be-
fore delivery. Please retain your receipt as proof of
purchase. In the event of a warranty claim, please
make contact by telephone with our Service Depart-
ment. Only in this way can a post-free despatch for
your goods be assured.
The warranty covers only claims for material and
maufacturing defects, but not for transport damage,
for wearing parts or for damage to fragile compo-
nents, e.g. buttons or batteries. This product is for
private use only and is not intended for commercial
use. The warranty is void in the case of abusive and
improper handling, use of force and internal tampe-
ring not carried out by our authorized service
branch. Your statutory rights are not restricted in
any way by this warranty.
The warranty period will not be extended by repairs
made under warranty. This applies also to replaced
and repaired parts. Any damage and defects extant
on purchase must be reported immediately after un-
packing the appliance, at the latest, two days after
the purchase date. Repairs made after the expira-
tion of the warranty period are subject to payment.
DES UK LTD
Tel.: 0871 5000 700 (£ 0.10 / minute)
e-mail: support.uk@kompernass.com
Kompernass Service Ireland
Tel.: 1850 930 412 (0,082 EUR/Min.)
Standard call rates apply. Mobile operators may vary.
e-mail: support.ie@kompernass.com
Importer
KOMPERNASS GMBH
BURGSTRASSE 21
44867 BOCHUM, GERMANY
www.kompernass.com
IB_53198_SHMS300A1_LB6 28.05.2010 13:59 Uhr Seite 7

Navigation menu
