Sirius XM Radio SA10177 SATELLITE RADIO RECEIVER AND FM TRANSMITTER User Manual RoadyXT manual layout xm
Sirius XM Radio Inc. SATELLITE RADIO RECEIVER AND FM TRANSMITTER RoadyXT manual layout xm
USERS MANUAL
RoadyXT_manual layout xm 7/13/05 8:11 AM Page 1
Table of Contents
3
A Brief History· · · · · · · · · · · · · · · · · · · · · · · · · 4
About Delphi· · · · · · · · · · · · · · · · · · · · · · · · · 5
About XM· · · · · · · · · · · · · · · · · · · · · · · · · · · · · 5
Let’s Get Started· · · · · · · · · · · · · · · · · · · · · · 6
First, some important
reminders · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 6
Controls · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 7
Display· · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 8
Remote Control · · · · · · · · · · · · · · · · · · · · · 9
Activating Your
roadyXT · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 10
Listening to XM · · · · · · · · · · · · · · · · · · · · · · · 11
Selecting channels · · · · · · · · · · · · · · · · · 11
Searching for channels
by category· · · · · · · · · · · · · · · · · · · · · · · · · · · 12
Searching for channels
by scanning · · · · · · · · · · · · · · · · · · · · · · · · · · 13
Using presets· · · · · · · · · · · · · · · · · · · · · · · · 14
Memory and jump · · · · · · · · · · · · · · · · · 15
Personalizing Your roadyXT · · · · · · · 16
Making any FM radio an
XM radio · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 16
Screen color· · · · · · · · · · · · · · · · · · · · · · · · · · 17
Contrast · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 17
Audio level · · · · · · · · · · · · · · · · · · · · · · · · · · · 17
Aiming the antenna · · · · · · · · · · · · · · · 18
TuneSelect™· · · · · · · · · · · · · · · · · · · · · · · · · · 18
Stock Ticker · · · · · · · · · · · · · · · · · · · · · · · · · · 19
Info Extras · · · · · · · · · · · · · · · · · · · · · · · · · · · · 20
Changing display information · · 21
Direct Tune · · · · · · · · · · · · · · · · · · · · · · · · · · · 21
Auto-On · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 21
Auto-Off and “sleep” timer · · · · · 22
Resetting to factory default · · · · · 22
Other Things You
Should Know · · · · · · · · · · · · · · · · · · · · · · · · · · 23
Care · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 23
Accessories (sold separately) · · · 23
Troubleshooting · · · · · · · · · · · · · · · · · · · · 24
Contacting Technical Support · · 28
Technical Information · · · · · · · · · · · · · 28
Warranty · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 29
Delphi Limited Consumer
Warranty · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 29
How you (the Customer)
can get service · · · · · · · · · · · · · · · · · · · · · · 31
How state law relates to
the warranty · · · · · · · · · · · · · · · · · · · · · · · · · 31
FCC ID: RS2SA10177
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interference that may cause undesired operation.
The Delphi XM®roadyXT Satellite Radio Receiver incorpo-
rates an FM transmitter and is therefore classified as an
intentional transmitter. Changes or modifications to the unit
not expressly approved by Delphi can void your authority to
operate this equipment.
Warning: The FCC and FAA have not certified the Delphi
XM roadyXT Satellite Radio Receiver for use in any aircraft
(neither portable nor permanent installation). Therefore,
Delphi cannot support this type of application or installation.
This is the safety alert symbol. It is used to
alert you to potential personal injury hazards.
Obey all safety messages that follow this
symbol to avoid possible injury or death.
Table of ContentsTable of Contents
RoadyXT_manual layout xm 7/13/05 8:11 AM Page 2
A Brief History
5
About Delphi
Delphi is a worldwide leader in mobile electronics, vehicle components,
and audio technology. Delphi created the first in-dash car radio in 1936 and
continues its strong tradition of innovation in the audio industry. Now
Delphi technology has helped make satellite radio a reality, and Delphi con-
tinues to expand its in-vehicle and consumer electronics technologies. With
its exciting line of satellite radio products, Delphi offers a broad portfolio of
products to answer a wide variety of information and entertainment
needs—in the vehicle, home, office, or virtually anywhere.
About XM
XM Satellite Radio is the nation’s leading provider of satellite radio with
more than 4 million subscribers. XM offers more than 150 digital radio
channels: 67 commercial-free music channels, ranging from hip hop to
opera, rock to bluegrass, big band to reggae; 64 talk radio channels, includ-
ing news, sports, comedy, and children’s programming; and 21 channels of
round-the-clock traffic and weather reports. Subscribers pay $12.95 a
month for the XM service, which was named Best Radio Service by the
music industry’s leading magazine Billboard at the 2004 Digital
Entertainment Awards. Exclusive programming on XM includes Major
League Baseball®games for every team, all season long. You can listen to
XM on a variety of satellite radio receivers for the vehicle, home, and
portable use. In-dash XM radios are available in more than 120 vehicle
models for the 2005 model year. XM is broadcast via satellite from coast to
coast, so you can listen to XM continuously as you travel across the country.
A Brief History
4
A Brief History
The new Delphi roadyXT Satellite Radio Receiver—smaller, lighter, and
more versatile than the best-selling Roady2®.
• Dock your roadyXT into cradles that are easily installed in your vehicles
or your home. One simple motion connects your roadyXT’s power, audio,
and antenna.
• A built-in FM transmitter allows you to hear XM programming on any
nearby FM radio, using any unused frequency on the FM band.
• Exclusive Info Extras and Stock Ticker bring you personalized stock
information, sports scores, and more.
• TuneSelect™alerts you when your favorite song is being played on
any XM channel.
*To receive the XM service, you must subscribe to XM. Available in the continental United States and Canada
only. Satellite radio reception depends on the ability of the antenna to receive a signal. The signal may not be
available in buildings or if obstructed (e.g., by mountains, trees, bridges, etc).
RoadyXT_manual layout xm 7/13/05 8:11 AM Page 4
Let’s Get Started
7
Let’s Get Started
First, some important reminders
We know you’re eager to turn on your new roadyXT and listen to XM.
Please take a moment to remember the following:
Warning: This manual contains important safety
and operating information. Please read, understand, and
follow the instructions in this manual. Failure to do so
could result in personal injury, death, and/or damage to
your roadyXT, accessories, and/or to your vehicle or
property.
Caution: Use your roadyXT only with the enclosed
components or approved accessories. Do not modify
wires or other connectors in any way; you could cause
a malfunction, which could damage your roadyXT and
will void your warranty.
Warning: When using this product it is always
important to keep your eyes on the road and your
hands on the wheel. Not doing so could result in
injury and/or death to yourself or to others and/or in
property damage.
Let’s Get Started
6
Caution: Refrain from using food or drinks near your
roadyXT. Spilling food or drinks on the unit can dam-
age it. Also, improperly installing the antenna cable
can cause leaks, which can damage your roadyXT
and/or your vehicle.
Controls
disp – change
what you see on
the display
up and down arrows,
select – change chan-
nels, choose menu
options, TuneSelect™
jump – return to
previous channel;
press and hold to
select one of last
six FM frequencies
used for transmitter
numbers – enter a
channel directly or
select favorite presets
menu – access
advanced features
and configuration
options
pre/dir – select
between direct
channel entry or
up to 30 presets
search – look up channels
by category or scan all
channels
memory – save
and recall up to
20 artist names
or song titles
power
RoadyXT_manual layout xm 7/13/05 8:11 AM Page 6
Let’s Get Started
9
Let’s Get Started
8
Display Remote Control*
signal strength –
1 to 3 bars
search by scanning
all channels
display
modes 1-5
search channels
by category channel selection
mode – direct
entry or preset
banks A, B, or C
additional info – channel
name, channel number,
artist, song title, Stock
Ticker, and Info Extras
up and down arrows, select –
change channels, choose
menu options, TuneSelect
power
memory – save and recall
up to 20 artist names or
song titles
disp – change what you
see on the display; show
artist name, song title,
channel number, stock
quotes, or Info Extras
pre/dir – select between
direct channel entry or
up to 30 presets
search – look up channels
by category or scan all
channels
jump – return to previous channel;
press and hold to select one of
last six FM frequencies used for
modulator
menu – access advanced
features and configuration
options
numbers – enter a channel
directly or select favorite presets
+ and - – change channels, or
control volume if roadyXT is
placed in a Delphi Audio System
*Sold separately
RoadyXT_manual layout xm 7/13/05 8:11 AM Page 8
Listening to XM
11
Activating Your roadyXT
10
Activating Your roadyXT
Use the arrow buttons to find channel 0, then push the “select” button to
choose it. You should see an 8-character XM Radio ID in the display. (The
XM Radio ID should also be on the bottom of your roadyXT, and on the
package.) Write the ID here:
Activate your XM Satellite Radio service by contacting XM at
http://activate.xmradio.com or by calling 1.800.XM.RADIO (1.800.967.2346).
You will need the XM Radio ID and a major credit card.
XM will send a signal from the satellites to activate the full channel lineup.
Activation normally takes 10 to 15 minutes, but during peak busy periods,
you may need to keep your roadyXT on for up to an hour to complete the
activation process. When you can access the full channel lineup on your
roadyXT, you’re done!
Listening to XM
Selecting channels
Select a channel directly by entering its channel number. Press the
“pre/dir” button (step 1) until appears on the screen. Then press the
number buttons (step 2) corresponding to the channel. Channel 12 can be
entered as “1,” then by “2,” or as “0,” “1,” and “2.”
Or press the up and down arrows to quickly step through each channel.
When you find one you like, press the “select” button.
Warning: When using this product it is always
important to keep your eyes on the road and your hands
on the wheel. Not doing so could result in injury and/or
death to yourself or to others and/or in property damage.
Warning: Failure to properly follow all installa-
tion instructions may result in personal injury, death,
and/or damage to your roadyXT, accessories, and/or to
your vehicle or property.
Warning: When using this product it is always important to keep your eyes on the road and your hands on the
wheel. Not doing so could result in injury and/or death to yourself or to others and/or in property damage.
Note: Carefully check your XM Radio ID. The letters I, O, S, and F are not used.
Step
1
Step
2
RoadyXT_manual layout xm 7/13/05 8:11 AM Page 10
Listening to XM
13
Searching for channels by scanning
Your roadyXT can also scan through each channel, pausing long enough to
hear the programming before moving on to the next one.
Press the “menu” button (step 1), go to “Search Mode,” and select “By
Scanning” (step 2).
Press the “search” button to begin scanning (step 3). Each channel plays
for about 5 seconds. While scanning channels, blinks in the display.
Press the “search” button again to stop on a channel.
Listening to XM
12
Searching for channels by category
XM channels are arranged by categories, or neighborhoods. This allows
you to see all channels in the “Rock” category, for example.
Press the “menu” button (step 1), go to “Search Mode,” and select “By
Category.”
Each press of the “search” button (step 2) tunes you to the first channel of
a new category.
Notice that the icon is highlighted in the display.
Use the arrow buttons (step 3) to sample the channels within a category.
Press the “select” button to choose a channel.
If you do nothing for 10 seconds, the radio automatically returns to the
normal channel selection method.
Step
1
Step
2
Step
3
Step
1
Step
3
Step
2
RoadyXT_manual layout xm 7/13/05 8:11 AM Page 12
Listening to XM
15
Listening to XM
14
Using presets
Your roadyXT can store up to 30 of your favorite channels as presets.
The presets are organized into three banks (A, B, or C) that each contain
10 presets.
Press the “pre/dir” button one or more times to select bank A, B, or C (step 1).
After you’ve tuned to your desired channel, press and hold a number
button to save the channel into that preset (step 2).
Whenever you want to quickly tune to that channel, simply press that
button again.
You can use the preset banks to organize your channels in different
ways: Store your favorite channels in bank A, and someone else’s favorite
channels in bank B. Or use one bank for music, another for news.
Memory and jump
Press the “memory” button to remember a song’s artist or title. Your
roadyXT can remember up to 20 entries. (After 20, any new entry replaces
the oldest entry in memory.)
To recall the list of songs, press and hold the “memory” button, then use
the up and down arrow buttons to step through the list.
Press the “jump” button to return to the previous channel you were
listening to.
You can press and hold the “jump” button for FM presets. See page 16
for more information.
Step
1
Step
2
RoadyXT_manual layout xm 7/13/05 8:11 AM Page 14
Personalizing Your roadyXT
17
Personalizing Your roadyXT
16
Screen color
To change the color of the display, press the “menu” button and select
“Screen Color.” Use the arrow and the “select” buttons to choose a color;
to cancel, press the “menu” button.
Contrast
To vary the contrast of the display, press the “menu” button and select
“Contrast.” Use the arrow buttons to adjust the contrast, and press the
“select” button to confirm.
Audio level
You may adjust roadyXT’s audio output level if it is too high (causing
distortion) or too low. Choose a setting so that the XM audio matches your
other audio sources, such as your CD player or FM radio. To change the
audio output level, press the “menu” button and select “Audio Level.” Use
the arrow buttons to adjust the level and the “select” button to confirm.
Press the “menu” button to exit.
Most users should NOT need to change this level from the factory setting.
This is not a volume control; you should set the volume using the audio
system that is connected to your roadyXT.
Personalizing Your roadyXT
You can easily adapt your roadyXT to suit your listening habits. Simply
press the “menu” button to see the options you can customize. If you ever
get lost or decide not to change anything, press the “menu” button several
times to return to normal operation. Or just wait about 15 seconds and
roadyXT automatically cancels whatever you’re doing.
Making any FM radio an XM radio
Your roadyXT contains a built-in FM transmitter that sends the XM audio
signal to a car, home, or marine FM radio.
1. Turn on your FM radio, and turn off your roadyXT.
2. Unplug any cassette adaptor or audio cable from the roadyXT cradle.
If you are using the Delphi FM Direct Adaptor (model SA10112, sold
separately), connect it to the vehicle cradle.
3. Find an FM frequency that is not being used by any commercial FM
station. Tune your FM radio through the FM band and note which
frequency has no FM station or the least amount of interference.
4. Turn on your roadyXT.
5. Press the “menu” button and select “FM Frequency.”
6. Match the FM frequency that you found in step 3.
7. You should now hear XM programming on your FM radio. If the sound
isn’t clear or you hear noise or static, try another FM frequency. If you’re
traveling, you may need to retune periodically; this is due to the differ-
ences in signal strength of local FM stations and is not a problem with
your roadyXT.
8. Pressing and holding the “jump” button for 2 seconds pulls up a list of
the last six FM frequencies you selected. This allows you to quickly tune
to unused FM frequencies when using the FM transmitter. Use the arrow
buttons and the “select” button to choose the frequency you want.
RoadyXT_manual layout xm 7/13/05 8:11 AM Page 16
Personalizing Your roadyXT
19
Personalizing Your roadyXT
18
Stock Ticker
You can track up to 20 stock symbols and see their prices and movements
right on the roadyXT’s display.*
TO ADD A STOCK SYMBOL:
1. Press the “menu” button, select “Stock Ticker,” and select “Add Stocks.”
2. Use the arrow buttons to add each letter of the desired stock symbol.
Press the “select” button after choosing each letter. (Your roadyXT has a
list of more than 9,000 stock symbols, and will not only help you complete
each entry but prevents you from entering incorrect symbols.)
3. When you’ve entered all your desired stock symbols, press the “menu”
button several times (or simply wait a few seconds) until your roadyXT
returns to normal operation.
4. Press the “disp” button until you see “Stocks” and a ticker across the
bottom of the screen.**
TO ERASE A STOCK SYMBOL:
1. Press the “menu” button , select “Stock Ticker,” and select “Erase Stocks.”
2. Choose “Erase All” or “Erase Some.”
3. If you’re erasing some stocks, press the arrow buttons to select the stock to
be deleted. Press the “select” button to erase the chosen stock symbol.
4. Press the “menu” button several times to return to normal operation.
*Quotes are provided by ComStock, Inc. and cover most stocks listed on the NYSE, AMEX, or NASDAQ.
Market information is delayed by approximately 25 minutes.
** Extreme cold temperatures can affect the performance of the LCD in “Scroll” mode. We recommend you
change to the “Pages” mode until the temperature rises.
Aiming the antenna
Note: For use with the Home Kit, sold separately.
Your roadyXT can help you choose the best antenna position and
orientation.
1. Press the “menu” button. Use the arrow and “select” buttons to choose
“Antenna Aiming.”
2. Slowly turn and tilt the antenna. The signal bars on the display will
change. Find the position that gives at least two bars on either “satellite”
or “terrestrial.”
3. The antenna aiming screen remains as long as it’s needed to help you
position the antenna. When you’ve found the best position, press the
“menu” button twice to return to normal operation.
TuneSelect™
TuneSelect can alert you whenever one of your favorite songs or artists is
playing on any XM channel.
1. Press the “menu” button and select the “TuneSelect” option, then select
“Song or Artist.” You can choose to select “By Song” (factory default) or
“By Artist.” Press the “menu” button again to return to normal operation.
2. When you hear one of your favorite songs or artists, press and hold the
“select” button until you hear a beep. This indicates that roadyXT has
saved the song or artist information to its TuneSelect list. The list holds
up to 20 entries; when it is full, any new entry replaces the oldest song
in the list.
3. When any song or artist on the list is currently playing on any XM channel,
your roadyXT beeps and flashes “Artist / Song Found” on its display.
4. Press the “select” button to switch to that channel.
5. To edit the list, press the “menu” button and choose the “TuneSelect”
option, then the “Erase” option. You can either erase specific songs or
artists on the list, or erase all songs and artists.
RoadyXT_manual layout xm 7/13/05 8:11 AM Page 18
Personalizing Your roadyXT
21
Personalizing Your roadyXT
20
Changing display information
The Stock Ticker and Info Extras can either be scrolled (moving from right
to left in the display) or paged (one symbol at a time). To switch from one
option to the other:
1. Press the “menu” button and select “Display Mode.”
2. Choose either “Pages” or “Scroll.” Press the “select” button to confirm.
Direct Tune
Normally as you press the arrow buttons, you can preview what’s playing
on other XM channels before actually selecting a channel. To automatically
tune to a channel without having to press the “select” button, set the
following option:
1. Press the “menu” button.
2. Select “Direct Tune.”
3. Select “On.” To return to the factory-default method, select “Off.”
Auto-On
When you use your roadyXT in a car or truck, it normally turns on when
you switch on the vehicle’s ignition. If you prefer to manually turn on your
roadyXT using its power button, set the following option:
1. Press the “menu” button.
2. Select “Auto-On.”
3. Select “On.” To return to the factory default, select “Off.”
You should also set this option to “Off” if your roadyXT is connected to a
power source that is always live.
Info Extras
XM Satellite Radio will broadcast information such as sports scores and
other features at various times.*
Press the “menu” button and select “Info Extras” (step 1). Use the arrow
buttons to see what’s available (step 2).
Press the “select” button to add or remove the Info Extras item (step 3).
“-” indicates that you have not yet selected the item; “+” means you’ve
chosen the item.
To view the Info Extras that you chose, press the “disp” button until you
see the Info Extras items at the bottom of the screen (display mode 5).
*Sports scores are provided by Stats, Inc.
Step
1
Step
3
Step
2
RoadyXT_manual layout xm 7/13/05 8:11 AM Page 20
Other Things You Should Know
23
Personalizing Your roadyXT
22
Other Things You Should Know
Care
You should be able to use your roadyXT during most of your daily
activities. However, you should remember:
• If your roadyXT does get dirty, wipe the case with a soft cloth (lightly
moistened with water if necessary), then wipe dry with another cloth.
Avoid chemicals such as paint thinner, alcohol, or abrasive cleansers.
• It is best to keep your roadyXT out of direct sunlight or other sources of
extreme heat.
Accessories (sold separately)
We’re always developing useful and clever accessories for your
roadyXT such as a Home Kit. Check our web sites, www.xmradio.com
or www.delphi.com, or your favorite electronics retailers.
Caution: Refrain from using food or drinks near the roadyXT. Spilling food or drinks on the unit could damage
it. Also, improper antenna cable installation can cause a leak that could result in damage to your roadyXT
and/or your vehicle.
Auto-Off and “sleep” timer
You can set your roadyXT to shut off the radio 1 to 3 hours after being
turned on. Set this option if you have connected your roadyXT to a
power source in your vehicle that is always live. Your roadyXT will then
automatically shut off and prevent you from draining your vehicle’s battery.
You can also use this feature as a “sleep” timer.
1. Press the “menu” button.
2. Select “Auto-Off.”
3. Select the desired time interval. Choose “Off” if you do not want to use
the sleep timer.
Resetting to factory default
You can return your roadyXT to the state it was shipped from the factory.
Be careful: this will erase all settings, including Stock Ticker, Info Extras,
presets, display options, and audio options.
1. Press the “menu” button.
2. Select “Factory Default.”
3. Select “Yes” to restore your roadyXT to the factory settings.
RoadyXT_manual layout xm 7/13/05 8:11 AM Page 22
Other Things You Should Know
25
Other Things You Should Know
24
If you see this on the display:
UPDATING
Cause: Your roadyXT is being updated with
the latest encryption code.
---
Cause: You may have tried to tune to a
channel that you have blocked or that
you cannot receive with your subscription
package.
You should:
Simply wait a few seconds until the update
is done.
To receive that channel, contact XM
Satellite Radio at 1.800.967.2346.
Troubleshooting
Your roadyXT should provide you with trouble-free performance without
needing any servicing. If it does not appear to be working properly, first try
to remedy the problem by following these steps:
1. Attach all connections firmly and securely.
2. Ensure the cigarette lighter adaptor or auxiliary power socket is clean
and free of corrosion.
3. Check the adaptor fuse by unscrewing the ribbed end of the adaptor. If
required, replace with a 2-amp fuse only. If your cigarette lighter adaptor
does not have a removable end cap, then it is equipped with an internal
fuse that resets itself after it is left unpowered for a period of time.
If you see this on the display:
NO SIGNAL
Cause: The XM
signal is being blocked.
ANTENNA
Cause: Possible problem with XM antenna.
ANTENNA
Cause: When using home stand or
vehicle cradle, home or car antenna is
not plugged in.
OFF AIR
Cause: The channel selected is not
currently broadcasting.
You should:
Move your roadyXT away from the
obstructed area (e.g., an underground
garage).
Connect the antenna. Make sure the cable
and connectors are not damaged or kinked.
Make sure the home or car antenna is
plugged into the home stand or vehicle
cradle.
Tune to another channel.
RoadyXT_manual layout xm 7/13/05 8:11 AM Page 24
Other Things You Should Know
27
Other Things You Should Know
26
If this happens:
Audio has static while listening through an
FM radio.
Audio on XM instant traffic and weather
channels sounds different from other XM
channels.
You should:
Change to another FM frequency (see page
16). If the problem persists and you are
using the wireless FM transmitter in a
vehicle, use the Delphi FM Direct Adaptor
(model SA10112, sold separately).
Nothing is wrong with your roadyXT.
These channels use a different audio
technology than the other XM channels.
If this happens:
The display is blank; nothing happens
when you push the power button.
You do not receive all XM channels you
have subscribed to.
Audio sounds distorted when using the
built-in FM transmitter.
Audio is too soft when using the built-in
FM transmitter.
No audio from your audio system.
You cannot tune to a channel.
No song title or artist name displayed.
No audio when listening through an FM
radio.
You should:
Check the power connections to your
roadyXT.
Your roadyXT may not be activated.
Contact XM Satellite Radio (see page 10).
Reduce audio output level (see page 17).
Increase audio output level (see page 17).
Check whether your audio system can play
a CD, or regular AM or FM stations. Then
check the audio connections between your
audio system and your roadyXT.
Contact XM Satellite Radio at 1.800.967.2346.
Verify that you are authorized to receive that
channel as part of your XM subscription,
and that you have not asked XM Satellite
Radio to block that channel.
Nothing is wrong with your roadyXT. That
information may be in the process of being
updated. On some sports and news chan-
nels, there is no title or artist information.
Make sure that the FM radio and your
roadyXT are set to the same frequency
(see page 16).
RoadyXT_manual layout xm 7/13/05 8:11 AM Page 26
Warranty
29
Other Things You Should Know
28
Warranty
Delphi Limited Consumer Warranty
Delphi Product and Service Solutions (“Delphi”) warrants all XM Satellite
Radio Products sold by Delphi (each “Product”) to be free of defects in
material and workmanship, subject to the following conditions:
The duration of Delphi’s warranty with respect to each Product is limited to
one (1) year from the date of sale to the original consumer purchaser.
No other express warranties are made with respect to any Product. All implied
warranties, including warranties of merchantability and fitness for a particular
purpose are limited to the warranty period set forth above. This warranty is not
transferable and applies only to the original consumer purchaser of the
Product.
Delphi will, as its sole obligation under this warranty, replace or repair, at its
option, any Product that does not conform to this warranty. Products may
be repaired or replaced with new or with refurbished items. This limited
warranty does not cover defects in appearance, cosmetic or decorative items,
including any non-operative parts. Under no circumstances will Delphi be
liable for any incidental or consequential damages under this warranty or
any implied warranties. These remedies are the customer’s exclusive remedies
for breach of warranty. This limited warranty only extends to customers who
purchase the Products in the United States.
Delphi will not be responsible for damage resulting from any (i) deviation of
Delphi’s operating instructions as printed in Delphi’s catalog or on any
packaging, labels or other literature provided with a Product, (ii) installation of
a Product in a manner which is inconsistent with Delphi’s written instructions,
Contacting Technical Support
For additional information in solving problems with your roadyXT,
contact Delphi Technical Support at 1.877.GO DELPHI (1.877.463.3574),
8:00 a.m.— 8:00 p.m. Eastern Time, Monday — Friday.
Technical Support is also available at www.delphi.com.
Technical Information
DIMENSIONS
receiver, without cradle: 2.25 in (H) x 3.7 in (W) x 0.7 in (D)
5.7 cm (H) x 9.4 cm (W) x 1.8 cm (D)
remote: 3.7 in (H) x 1.7 in (W) x 0.6 in (D)
9.4 cm (H) x 4.3 cm (W) x 1.5 cm (D)
WEIGHT
receiver, without cradle: 2.6 oz
76 g
remote: 1 oz
30 g
POWER
receiver: 5 V, 2000 mA maximum current, positive polarity
remote: 1 CR2032 3 V cell
INPUTS AND OUTPUTS
antenna: 1 RF SMB connector
audio: 3.5 mm diameter mini-stereo jack
RoadyXT_manual layout xm 7/13/05 8:11 AM Page 28
Warranty
31
How you (the Customer) can get service
To obtain warranty service during the first thirty (30) days after the date of
purchase, you must return the defective Product with the original receipt to
the original place of purchase. To obtain warranty service during the first
thirty (30) days for Products purchased from www.delphi.com and for all
Products for the remainder of the limited warranty period, you must contact
Delphi by phone at 1.877.GO DELPHI (1.877.463.3574) or by fax at
1.866.790.3675. When contacting Delphi by fax, please include a letter
detailing your complaint and a daytime telephone number where you can
be reached. If further clarification or additional information is required from
Delphi, you may call Delphi at 1.877.GO DELPHI (1.877.463.3574).
If warranty service is needed at any time during the warranty period, the
purchaser will be required to furnish a sales receipt/proof of purchase
indicating the date of purchase, amount paid, and place of purchase.
Customers who fail to provide such proof of purchase will be charged
for the repair or replacement of any Product.
How state law relates to the warranty
Some states do not allow limitations on the duration of implied warranties,
or the exclusion or the limitation of incidental or consequential damages.
So the above limitations or exclusions may not apply to you. This warranty
gives you specific legal rights. You may also have other rights that may
vary from state to state. NO PERSON IS AUTHORIZED BY DELPHI TO
MODIFY OR ADD TO THIS LIMITED WARRANTY.
Warranty
30
(iii) alteration or modification of a Product, (iv) misuse, (v) neglect, (vi) abuse,
(vii) accident, (viii) normal wear and tear, (ix) commercial use, (x) improper
storage, (xi) environmental conditions, including excessive temperature or
humidity, (xii) service by anyone other than a Delphi authorized repair facility,
(xiii) other improper application, installation or operation of this Product, or
(xiv) defects or malfunctions of which Delphi is not advised within ten (10)
days of the expiration of the limited warranty period.
RoadyXT_manual layout xm 7/13/05 8:11 AM Page 30
Delphi Corporation
1441 West Long Lake Road
Troy, Michigan 48098-5090
U.S.A.
Customer Service: [1] 877.GO DELPHI
www.delphi.com
Printed on Recycled Paper
©2005 Delphi Corporation. All rights reserved.
DPSS-05-E050
roadyXT, the XM name, TuneSelect, Roady2 and related
logos are trademarks of XM Satellite Radio Inc.
RoadyXT_manual layout xm 7/13/05 8:11 AM Page 32
