Start Here
The Bluetooth Vehicle Dock needs to be paired with your vehicle’s audio system. Once paired, you do not need to repeat the pairing process. After the dock is paired, the audio level of the
SiriusXM radio will need to be adjusted.
Some audio systems automatically pair with an available Bluetooth device (Automatic), and some create a list of available Bluetooth devices and you select a device from this list to pair
with (Manual). Follow the steps below for your type of audio system, either Automatic or Manual, and then follow the “Adjusting the Audio Level...” steps.
Automatic Bluetooth Pairing Procedure
A. Place the SiriusXM Radio into the Bluetooth Vehicle Dock, and turn on the Radio. If the Radio does not turn on automatically, press the power button to turn it on.
B. Press and hold the Bluetooth Button for a full 9 seconds until the Bluetooth Indicator LED turns from blue to red and begins alternately fast blinking blue and red (half second blink).
C. Place the vehicle’s audio system in pairing mode. Consult the instruction manual that accompanied your vehicle, or which accompanied the audio system installed in your vehicle, for
instructions on how to do this. The audio system will pair with the Bluetooth dock with no need to enter a PIN code. However, if your vehicle’s audio system prompts for a PIN code,
enter 0000.
D. Once paired, the blinking blue LED will become steady, and you should hear the SiriusXM audio. After about 20 seconds, the blue LED will dim. If pairing fails, repeat these pairing
steps again. If unsuccessful consult the Troubleshooting section.
Manual Bluetooth Pairing Procedure
A. Place the SiriusXM Radio into the Bluetooth Vehicle Dock. If the Radio does not turn on automatically, press the power button to turn it on.
B. Press and hold the Bluetooth Button for 5 seconds until the Bluetooth Indicator LED turns from blue to red and begins alternately blinking blue and red (one second blink).
C. Begin a Bluetooth scan on the vehicle’s audio system. Consult the instruction manual that accompanied your vehicle, or which accompanied the audio system installed in your vehicle,
for instructions on how to do this.
D. Select SiriusXM-XXXXXX for the Bluetooth Dock from the list. The audio system will pair with the Bluetooth dock with no need to enter a PIN code. However, if your vehicle’s audio
system prompts for a PIN code, enter 0000.
E. Once paired, the blinking blue LED will become steady, and you should hear the SiriusXM audio. After about 20 seconds, the blue LED will dim. If pairing fails, repeat these pairing
steps again. If unsuccessful consult the Troubleshooting section.
Adjusting the Audio Level of your SiriusXM Radio
A. Verify that AUX Detect is enabled. If you had previously disabled AUX Detect in your SiriusXM Radio, re-enable AUX Detect. Press Menu, select Factory Settings, and set AUX Detect
to enabled. For radios without Aux Detect, you must manually turn off the FM feature in your SiriusXM Radio or your audio will be too low.
B. Access Audio Level in SiriusXM Radio menu settings and adjust the Audio Level to the maximum volume setting. (You can then lower the Audio Level from maximum if the Bluetooth
audio is louder than other audio sources, such as the AM/FM radio.)
Pairing the Bluetooth Vehicle Dock and Adjusting the Audio Level
2
When you have paired the Bluetooth Vehicle Dock with
your vehicle’s audio system, the Bluetooth connection
will automatically be restored each time you turn your
vehicle on. Turn on the vehicle’s audio system and
your SiriusXM Radio, and wait a few moments for the
connection to be reestablished.
Note that the Bluetooth Vehicle Dock can only be paired
with one audio system at a time. If you pair it with a new
audio system, the Bluetooth Vehicle Dock forgets the
previous audio system.
To Turn Bluetooth On: Press and hold the Bluetooth
Button for two seconds until the Bluetooth Indicator
LED turns blue.
To Turn Bluetooth Off: Press and hold the Bluetooth
Button for two seconds until the Bluetooth Indicator
LED turns red. Then release the Bluetooth Button and
Bluetooth will turn off.
To Enter Pairing Mode: Turn Bluetooth off. Then press
and hold the Bluetooth Button for 5 seconds (for manual
pairing) or 9 seconds (for automatic pairing) until the
Bluetooth Indicator LED turns from blue to red and
begins alternately blinking blue and red. (One half second
blink rate for automatic pairing, or one second blink rate
for manual pairing.)
To Reconnect to a Paired Audio System: The Bluetooth
Vehicle Dock should automatically reconnect to
previously paired audio system. If the audio system
instructs you to reconnect from the dock, tap the
Bluetooth button on the dock to reconnect.
Using the Bluetooth
Vehicle Dock
3
You’ll need to replace the Vehicle Dock
that is installed in your vehicle with your
new Bluetooth Vehicle Dock.
A. Remove the SiriusXM Vehicle
Dock currently installed in your
vehicle, and disconnect the
attached cables.
B. Using the same mounting method
as the previous Vehicle Dock,
install the Bluetooth Vehicle Dock.
C. Reconnect the power and antenna
cables to the dock. Connect the
power cable to the Red PWR
connector, and the antenna cable
to the Silver ANT connector.
IMPORTANT: If there had been a
connection to the Green Audio
connector and/or the Blue FM
connector, do not reconnect either
of these two cables to the Bluetooth
Vehicle Dock when using the
Bluetooth feature. These cables will
interfere with the Bluetooth function.
Install the
Bluetooth®
Vehicle Dock
1Troubleshooting
The Bluetooth Vehicle Dock has been designed and built to be trouble-free but if you experience an issue, try these solutions.
Issue Solution
I want to pair the Bluetooth
Vehicle Dock with a new audio
system OR forget the audio
system with which it is paired
Press the Bluetooth button on the front of the Vehicle Dock for two seconds until the LED is off. Then
press and hold the Bluetooth button for approximately five seconds until the LED alternately flashes
blue and red. The Vehicle Dock is now ready to be paired with a new audio system.
I can’t hear the SiriusXM
audio from the vehicle’s audio
system
• Increase the SiriusXM Radio’s audio level. In the Menu settings of your SiriusXM Radio, select Audio
Level and confirm the audio level is set to maximum. If not, increase it to the maximum.
• Be sure the vehicle’s audio system is set to the Bluetooth audio source.
• Press pause/play on the vehicle’s audio system to un-mute the Bluetooth audio.
• Verify that the Bluetooth Vehicle Dock is shown as the selected Bluetooth source on the vehicle’s
audio system.
• Verify that an FM Cable is NOT plugged into the FM connector Bluetooth Vehicle Dock. There
should be NO connection to the Blue FM connector on the dock.
• Verify that an Aux In Cable is NOT plugged into the Bluetooth Vehicle Dock. There should be NO
connection to the Green AUDIO connector on the dock.
• Make sure the FM Transmitter is turned off before adjusting the Audio Level setting:
1. If you have a newer SiriusXM Radio make sure that Aux Detect is enabled as this automatically
turns off the FM Transmitter.
2. If your SiriusXM Radio does not support Aux Detect then you must turn off the FM Transmitter
first in the Menu settings, before adjusting the audio level. (The maximum audio level when FM is
on is much lower than the maximum audio when FM is off.)
The Bluetooth Vehicle Dock
paired to vehicle’s audio
system, but now it will not
reconnect after turning the
vehicle off and then on again
• Be sure the vehicle’s audio system input is set to the Bluetooth source. (Some audio systems won’t
reconnect unless the Bluetooth source is re-selected.)
• Confirm your vehicle audio system’s Bluetooth audio source is set to auto-reconnect.
• Tap the Bluetooth button to re-connect the dock to the vehicle’s audio system.
• Use the vehicle audio system’s Bluetooth connection menu to reconnect to the dock.
• Repeat the pairing process with the vehicle’s audio system.
My Sirius Radio won’t dock The Bluetooth Vehicle Dock only supports XM and SiriusXM Radios, not Sirius Radios.
BTD
1V1
Bluetooth
Vehicle Dock
Sirius XM Radio Inc.
1290 Avenue of the Americas
New York, NY 10104
1.866.635.2349
siriusxm.com
© 2017 Sirius XM Radio Inc.
SXBTD1V1QSG 171004b
Self installation instructions and tips are provided for your
convenience. It is your responsibility to determine if you have the
knowledge, skills and physical ability required to properly perform
an installation. SiriusXM shall have no liability for damage or injury
resulting from the installation or use of any SiriusXM or third
party products. It is your responsibility to ensure that all products
are installed in adherence with local laws and regulations and in
such a manner as to allow a vehicle to be operated safely and
without distraction. SiriusXM product warranties do not cover the
installation, removal or reinstallation of any product.
?What’s in the Box?
CAUTION: Do not attempt to install, activate, pair, or
adjust any of the setting options described in this
Quick Start Guide unless your vehicle is parked in a
safe location.
Bluetooth® Vehicle Dock
SiriusXM 12-Month Limited Warranty
What This Warranty Covers
This warranty covers defects in material and workmanship for 12 months from the date of purchase by the original retail purchaser only.
Sirius XM Radio Inc., at its sole option, will repair or replace the product with a new or reconditioned product without charge for parts and
labor. Products replaced under this warranty become the property of SiriusXM. Replacement products are warranted to be free from defects
for 30 days or the remainder of the original warranty, whichever is longer.
What This Warranty Does Not Cover
This warranty does not cover: products sold as used, as is, reconditioned or refurbished; software stored on internal or removable memory;
non-rechargeable batteries, surface preparation cleaners, adhesive pads, fasteners, and ear-buds; costs incurred for installation, removal or
reinstallation of the product; correction of installation problems, such as elimination of externally generated static or noise and antenna placement
and aiming; defects or damage caused by alteration, improper installation or removal, use of third party accessories, mishandling, misuse, neglect,
accident, power surges or acts of nature.
How to Obtain Warranty Service
To obtain warranty service, please call SiriusXM Listener Care at 1-866-635-7191. You will be required to provide proof of purchase and a
description of the defect. You must prepay the cost of shipping the product to an approved service center.
LIMITATIONS OF LIABILITY
THE LIABILITY OF SIRIUSXM UNDER THIS WARRANTY IS LIMITED TO REPAIR OR REPLACEMENT AS PROVIDED ABOVE AND IN NO
EVENT SHALL THE LIABILITY EXCEED THE PURCHASE PRICE PAID FOR THE PRODUCT. ANY IMPLIED WARRANTIES, INCLUDING
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION
OF THIS WRITTEN WARRANTY. ANY ACTION FOR BREACH OF WARRANTY, INCLUDING BREACH OF ANY IMPLIED WARRANTY OF
MERCHANTABILITY, MUST BE BROUGHT WITHIN 48 MONTHS FROM THE DATE OF ORIGINAL PURCHASE. IN NO CASE SHALL SIRIUSXM
BE LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS
OR IMPLIED. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS OR THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU.
This warranty gives you specific legal rights and you may also have other rights, which vary from state to state.
Important Legal Information
© 2017 Sirius XM Radio Inc. Sirius, XM, SiriusXM, and all related marks
and logos are trademarks of Sirius XM Radio Inc. All programming
subject to change. Visit www.siriusxm.com/channellineup for
updates. All other marks and logos are the property of their
respective owners. All rights reserved. The Bluetooth® word mark
and logos are registered trademarks owned by Bluetooth SIG, Inc.
and any use of such marks by Sirius XM Radio Inc is under license.
Our satellite service is available only to those at least 18 and older in
the 48 contiguous USA and DC. Our Sirius satellite service is also
available in PR (with coverage limitations). Our Internet Radio service
is available throughout our satellite service area and in AK and HI.
Certain channels are not available on our Internet Radio service or on
mobile devices. Satellite and Streaming lineups vary slightly.
WARNING: This product contains chemicals known to the State of
California to cause cancer and birth defects or other reproductive
harm.
SpecificationsLED Indicator Status
System
Power Requirements: .....5 V DC, 1 amp (max)
Operating Temperature: ...-4°F to +140°F (-20°C to +60°C)
Audio Output: ...........1.0 Vrms (max)
Bluetooth Vehicle Dock
Dimensions: .............
4.0 in (W) x 2.4 in (H) x 1.2 in (D)
102 mm (W) x 61 mm (H) x 31 mm (D)
Weight: .................
2.02 oz. (37 gm)
Audio Connector: ........1/8 in (3.5 mm) female
Antenna Connector: ......SMB male
FM Connector: ...........2.5 mm female
FCC Statement
!
The user is cautioned that changes or modifications not expressly
approved by Sirius XM Radio Inc. can void the user’s authority to
operate this device.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
installation instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna of the affected receiver.
Increase the separation between the SiriusXM equipment and the
affected receiver.
Connect the SiriusXM equipment into an outlet on a circuit
different from that to which the affected receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
WARNING! The FCC and FAA have not certified this Satellite Radio
Receiver for use in any aircraft (neither portable nor permanent
installation). Therefore, Sirius XM Radio Inc. cannot support this type
of application or installation.
FCC RF Radiation Exposure Statement:
This equipment complies with FCC RF radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated with a minimum distance of 20 centimeters
from your body.
Bluetooth Controls
Bluetooth
Button Bluetooth
Indicator LED
!
The following table describes the status of the LED
indicator on the front of the Bluetooth Vehicle Dock.
Bluetooth
Indicator LED Status LED
Intensity
Blue LED On & not
blinking
On, Paired &
Connected
Bright for
20 sec.
then dim
Blue LED flashing
once every 3
seconds (two
seconds on & one
second off)
On & not Paired Bright for
20 sec.
then dim
Blue and Red LED
flashing alternately
(half second blink)
Ready to be Paired
(Automatic Mode)
Always
bright
Blue and Red LED
flashing alternately
(one second blink)
Ready to be Paired
(Manual Mode)
Always
bright
Blue LED Flashing
once every 4
seconds (one
second blue & 3
seconds off)
Paired and ready
to reconnect when
previously paired
audio system
becomes available
Always
dim

Navigation menu
