Coder Light OPOS is the ideal solution for
advance ticket sale! SKIDATA's entry level
model for new users of ticket printers. This
compact, economically priced device im-
prints and encodes tickets in one go.
This coder can be placed anywhere
• Thanks to its compact design, this coder is easy to
integrate and install.
Coder Light OPOS also ts into your advance
ticket ofce.
• The new power pack does not need a fan, therefore
it is small and silent. Thanks to the long power cable,
the power pack does not need to be placed near the
coder.
Convenient and reliable
• Additional advantage for the production of RFID
tickets: Before it is issued, the produced ticket is read
for control purposes.
• Coder Light OPOS provides maximum reliability,
because it contains hardly any moving parts. It can
easily be cleaned and maintained by the operator.
Enhance the appeal of your destination
• Because more tickets are sold in advance via Coder
Light OPOS, waiting time at pay stations in the skiing
area is reduced.
• With the option to buy tickets in advance, your
customers get right to the slopes without delay and
can fully enjoy their skiing pleasure.
One printer for all media
• All barcode and 13.56 MHz tickets of the current
SKIDATA portfolio can be processed. In addition,
there is a recessed antenna for the RFID data carriers
KeyWristBand ISO and Swatch Snowpass 13 MHz.
• Thanks to the USB interface, the coder can be
connected to most PCs.
Coder Light ‘OPOS’
95 (3.740")
132 (5.197")
168 (6.614") 161 (6.339")
© 2011 SKIDATA AG. All rights reserved.
The content provided herein is subject to change and possible editorial errors. Country-specic versions may vary. SKIDATA® is a registered
trademark of SKIDATA AG in the USA, the European Union and other countries. Terms and conditions of the authorized SKIDATA distributor
apply. The operator is fully responsible for compliance with any legal provisions applicable to the operation of the products.
• RFID data carriers are imprinted, encoded and
veried in one go
• Low noise emission in the ofce
(57 dBA during the printing procedure)
• Requires little maintenance
• Easy cleaning by means of special cleaning card; no
tools required
Properties
• Desktop unit with external power pack and USB
connector
• Internal RFID antenna for tickets inserted at the front
• External RFID antenna with data carrier rest
• Barcode imprint for tickets inserted at the front
• Ticket imprint 48 mm x 48 mm / 1.89" x 1.89" with a
resolution of 200 DPI
• Custom dened bitmaps can be printed
Technical Specifications
Dimensions Printer: 161 mm x 132 mm x 168 mm / 6.34" x 5.2" x 6.61" (w x h x d)
Power pack: 85 mm x 41 mm x 170 mm / 3.37" x 1.61" x 6.69" (w x h x d)
Weight Printer: 1.55 kg (3.2 lbs); power pack: 0.9 kg (2 lbs)
Power supply External desktop power pack 24 V DC with wide input range, silent (no fan)
Power consumption max.180 W
Temperature range 10 °C to 35 °C (+50 °F to +95 °F), 25–80 % humidity (non condensing)
Enclosure color RAL 9007 (Gray Aluminium), SKIDATA Yellow (approximates Pantone 114U)
Data carriers
(ISO 15693)
keycard iso, keycard iso-dual, keycard-eco iso-dual, keyticket iso-dual,
keycard unlimited, keycard basic, keyticket iso-dual, keyticket light,
KeyWristBand ISO, Swatch Snowpass 13 MHz
RFID Tags:
(ISO 15693)
EM 4036/4034/4233, Texas Instruments Tag IT HF-I 2k, Inneon my-d® SRF55V02P,
NXP ICode SLI-S
Barcode data carriers TL360, TK Unlimited
Barcode format Interleaved 2/5 crosswise (only imprint, no control reading)
Interfaces USB 2.0 compatible
USB driver XP(e)/W2000/SRV2003/Vista (x86 only), W7(e)/W2k8R2 (x86+x64)
Time for imprint 3.5 s
Time for RFID encoding
and imprint
7 s
Volume of the printer
during operation
max. 57 dBA during the production of tickets
Ticket feed manual
Declarations /
Certications
CE, FCC, IC, C-Tick
SKIDATA AG • Untersbergstraße 40 • A-5083 Grödig/Salzburg
[t] +43 6246 888-0 • [f] +43 6246 888-7 • [e] info@skidata.com [w] www.skidata.com • Version 1.6 • 27.03.2012
all dimensions in mm
