LIMITED

WARRANTY

REGISTER YOUR PRODUCT AT SKLZ.COM

TO ENSURE WARRANTY

COVERAGE, GET NEW PRODUCT

INFORMATION AND SPECIAL DEALS

FROM SKLZ

Pro Performance Sports (PPS) / SKLZ warrants to the original consumer purchaser of any

PPS/SKLZ product it manufactures that the product will be free of defects in materials or

workmanship for 90 days (unless specified in alternate warranties) from the date of purchase.

If defective and purchased from a retail store, return the product along with receipt to the

retail store where the product was purchased. If the item was purchased from PPS/SKLZ,

return the product along with the packing slip (proof of purchase) postage prepaid to the

address below for replacement consideration. Label: Attn: Returns

This warranty does not cover damages resulting from accident, misuse, abuse or lost

merchandise. Only valid in the USA. All returns sent to PPS/SKLZ require a Return

Merchandise Authorization number (RMA). For returns to PPS/SKLZ and for all other

Customer Service inquiries, please call toll free, 1-877-225-7275 for a return authorization

number for any exchange.

Made in China. ©2012 Pro Performance Sports, LLC. All rights reserved. Manufactured and distrib-

uted by SKLZ/Pro Performance Sports: 2081 Faraday Avenue, Carlsbad, CA 92008 U.S.A. SKLZ,

SKLZ Pro Grade, SKLZ Chrome and Sport-Brella are registered trademarks of Pro Performance

Sports, LLC., its subsidiaries and affiliates. Product features, appearance, and specifications may

be subject to change without notice. Unauthorized duplication is a violation of applicable local and

international laws.

IDEA SUBMISSION

If you have an idea for a new and innovative sports training product,

visit SKLZ.com to submit your concept. Some restrictions may apply.

SKLZ.COM

INSTRUCTION MANUAL

SHOCKWAVE

SHOCKWAVE IS PERFECT FOR:

» BASEBALL » SOFTBALL

SHOCKWAVE

Thank you for choosing SKLZ SHOCKWAVE. We are dedicated to providing you with the best tools and

instruction possible to help you unleash your athletic potential. If there is anything else we can do to help you

optimize your training, don’t hesitate to drop us an email (customerservice@sklz.com) or give

us a call (1-877-225-7275).

BEFORE YOU BEGIN:

» Read all setup and usage instructions carefully before using. If the setup and/or instructions are not followed

correctly, it could result in injury or damage to the product.

» Adult assembly recommended.

» Make sure you have all of the SHOCKWAVE components. Please contact SKLZ customer service toll free at

1-877-225-7275 if you are missing anything.

WARNING:

Do not climb or hang on the SHOCKWAVE.

Keep away from fire and heat sources.

Not suitable for children under 3 years of age.

Regularly check for wear and tear. Stop using SHOCKWAVE if any part of it breaks or tears. Failure to do so

could result in injury.

SHOCKWAVE is a rebounder and will propel the ball towards the thrower at high speeds. Be sure that the

user and observers are safety positioned before using.

The net will be under extreme tension and must be attached carefully. Adult assembly is

strongly recommended.

To avoid pinching hazards, keep fingers clear when connecting poles and net hooks during assembly, and push

button adjustments on the rear frame.

SH OCK WAVE PARTS:

NET

NET HOOKS

FEMALE L-SHAPED TUBE (2)

A

G H

I

MALE L-SHAPED TUBE (2)

B

CURVED SHAPED TUBE (4)

C

FRAME TO LEG CONNECTOR (2)

DMALE LEG L-SHAPED TUBE

F

FEMALE LEG L-SHAPED TUBE

E

GROUND STAKES (4)

Training Videos & Articles: SKLZ.com

facebook.com/SKLZbaseball

twitter.com/SKLZ

HOW TO

VISIT SKLZ.COM FOR INSTRUCTIONAL VIDEO AND CONTENT

SH OCK WAVE A SSEM BLY

To store, press push button on back leg joint to fold the legs onto the frame.

Do not store outside.

STORE YOUR SHOCKWAVE

STEP 2

BUILD THE FRAME

STEP 4

GROUND STAKES

Assemble the frame by connecting the male ends to the

female ends. Make sure to secure the poles with the push

buttons as seen in the illustration.

When assembling the frame, make sure the concave curve is

on the top of the frame and convex is on the bottom as shown

in the illustration.

Place SHOCKWAVE in the desired location and ensure it is on

level ground. Secure frame with included Ground Stakes (H),

by utilizing hand, foot or mallet.

Lay out all of the frame components

as shown in illustration.

STEP 1

LAY OUT FRAME

1

2

ADJUSTING THE REAR FRAME ANGLE

Adjust the angle of the rear frame by using the push button

on each side of the frame. It is recommended to lay the frame

down on it’s side when adjusting.

SHOCKWAVE

TM

S

H

O

C

K

W

A

W

W

VE

A

A

TM

REBOUNDING PATTERNS

The unique shape of the net allows for a variety of different

throwing and fielding opportunities.

1. By throwing the ball at the top 20% of the net, the player

can practice fielding ground balls.

2. By throwing the ball in the middle 60% of the net, the

player can practice fielding pop flies.

3. By throwing the ball at the bottom 20% of the net, the

player can practice fielding line drives.

Throwing the ball to the outside corner will cause the ball

to bounce in an unexpected manner and force the player to

react quickly to the misdirected.

Adjusting the net in the lower angle secondary position will

provide more pop up practice.

Over time it is normal that the Shockwave net will stretch

slightly, reducing the rebound speed. To increase the rebound

speed adjust the tension of the net by decreasing the net

width by one hex. To do this perform the following steps

along one side of the Shockwave:

1. Starting at the top, pull the second net hex loop toward the

hook and reattach.

2. Repeat this process with the next hook down until one side

of the net has been tightened.

1. 2. 4.

A

A

B

B

C

C

C

C

D

D

F

E

SH OCK WAVE USAGE

CONVEX

(BOWS OUTWARD)

CONCAVE

(BOWS INWARD)

STEP 3

ATTACHING THE NET

1. Once the frame is completely assembled, lay the Net (G)

out to ensure it will be correctly positioned on the frame.

NOTE: Before connecting the Net Hooks (I) to the frame, see

illustration #2 demonstrating the proper way to attach

the Hooks.

2. Identify each corner hex loop. Using 2 hooks attach each

corner hex loop to the frame corner. See illustration #2.

3. After each corner of the net is attached to the frame

begin attaching the rest of the net. Starting with the top

and then move to the bottom of the frame, use the hooks

to connect every other hex loop.

4. Once the net is attached to the top and bottom, begin

attaching the net to the sides of the frame. Attach each

hex loop on the outer edge of the net to the sides of the

frame. See illustration #4.

2.

3. 1.

2.
