Sky Phone SKYF1C Feature Phone User Manual F1C Englishx
Sky Phone LLC Feature Phone F1C Englishx
User manual
-1-
Content
1. General Information 3
1.1. Profile 3
1.2. Safety Information 3
1.3. Safety warning and Attentions 3
2. Your phone 6
1.1. Phone overview 6
1.2. Functions of Keys 6
1.3. Technical specifications 7
3. Getting started 8
1.1. Installing the SIM Card and the Battery 8
1.2. Installing T-Flash Card 10
1.3. Charging the Battery 10
1.4. Powering On/Off the Mobile Phone 13
1.5. Linking to the Network 13
1.6. Dialing Calls 13
1.7. Using the Headset 13
-2-
4. Input method 14
1.1. Key for Input Methods 14
1.2. To Shift Entry Methods 14
1.3. Numeric Input 14
1.4. English input and numeric input: 14
1.5. Inserting a Symbol 16
5. Using the Menus 17
1.1. Phonebook 17
1.2. Call logs 17
1.3. Multimedia 18
1.4. Contacts 20
1.5. Audio 20
1.6. Message 20
1.7. File manager 21
1.8. Application 22
1.9. Settings 23
1.13. Profiles 25
6. Appendix 26
-3-
1. General Information
1.1. Profile
Please read this pamphlet carefully in order to make your phone in perfect condition.
Our company may change this mobile phone without prior written notice and reserves the final right to
interpret the performance of this mobile phone.
Due to different software and network operators, display on your phone may be different, refer to your
phone for details.
1.2. Safety Information
If your phone has lost or been stolen, notify the telecommunication office the SIM card is disabled
(network support is required). This can avoid economic loss caused by unauthorized use.
Please take measures as following to avoid your phone being unauthorized used:
· Set PIN code of SIM card
· Set phone password
1.3. Safety warning and Attentions
Safety warning
➢ ROAD SAFETY COMES FIRST
Do not use a hand-held phone while driving. Use hands-free fittings when calls are unavoidable while
driving. In some countries, dialing or receiving calls while driving is illegal!
-4-
➢ SWITCH OFF IN AIRCRAFT
Wireless devices can cause interference in aircraft. Using a mobile phone in flight is illegal and risky.
Please make sure that your mobile phone is powered off in flight.
➢ SWITCH OFF BEFORE ENTERING RISKY AREAS
Strictly observe the relevant laws, codes, and regulations on the use of mobile phones in risky areas. Turn
off your mobile phone before entering a place susceptible to explosion, such as an oil station, oil tank, chemical
plant or a place where a blasting process is under way.
➢ OBSERVE ALL SPECIAL REGULATIONS
Follow any special regulations in force in any area such as hospitals and always switch off your phone
whenever it is forbidden to use it or, when it may cause interference or danger. Properly use your mobile phone
near medical apparatuses, such as pacemakers, hearing aids and some other electronic medical devices, as it
may cause interference to such apparatus.
Follow any special regulation in force in any area such as hospital and always switch off your phone
whenever it is forbidden to use it or, when it may cause interference or danger. Properly use your mobile phone
near medial apparatuses, such as pacemakers, hearing-aids and some other electronic medical devices, as or
may cause interference to such apparatuses.
➢ INTERFERENCE
The conversation quality of any mobile phone may be affected by radio interference. An antenna is built
inside the mobile phone and located below the microphone. Do not touch the antenna area during a
conversation, lest that the conversation quality deteriorate.
➢ QUALIFIED SERVICE
Only qualified personnel may install or repair phone equipment. Installing or repairing the mobile phone
on your own may bring great danger and violate the warranty rules.
-5-
➢ ACCESSORIES AND BATTERIES
Use only approved accessories and batteries.
➢ USE SENSIBLY
Use only in a normal and proper manner.
➢ EMERGENCY CALLS
Ensure the phone is switched on and in service, enter the emergency number, e.g. 112, then press the Dial
key. Give your location and state your situation briefly. Do not end the call until told to do so.
Note: Just like all other mobile phones, this mobile phone does not necessarily support all the features
described in this manual due to network or radio transmission problems. Some networks even do not support
the emergency call service. Therefore, do not rely solely on the mobile phone for critical communications such
as first aid. Please consult the local network operator. Just like all other mobile phones, this mobile phone
does not necessarily support all the features described in this manual due to network or radio transmission
problems. Some network even do not support the emergency call service
Precaution
This mobile phone is well designed with fine art. Please exercise special care when using it. The
following suggestions will help your mobile phone survive the warranty period and extend its service life:
➢ Keep the mobile phone and all its fittings beyond children's reach.
➢ Keep the mobile phone dry. Keep away from rain, moisture, liquid or other substances that may corrode
electronic circuits.
➢ Do not use or store the mobile phone in dusty place, lest that active parts of the mobile phone be damaged.
➢ Do not store the mobile phone in a high-temperature place. High temperature will shorten the life of
-6-
electronic circuits and damage the battery and some plastic parts.
➢ Do not store the mobile phone in a chilly place. Otherwise, moisture will be formed inside the mobile
phone to damage electronic circuits when the mobile phone is moved to a constant temperature place.
➢ Do not throw, knock or shock the mobile phone, as that will destroy the internal circuit and high precision
components of the mobile phone.
2. Your phone
1.1. Phone overview
The phone has many powerful function and good appearance.
1.2. Functions of Keys
◆ Dial1 key
Press dial 1 to originate a call by entering the called number or selecting a contact from the phonebook;
or press dial 1 to receive an incoming call; or press it in standby state to show the latest call records.
◆ End key
Press it to end a call being dialed or end an ongoing call; or press it to exit the menu and return to
the standby state. You can hold it for two or three seconds can power on/off the mobile phone
-7-
◆ Direction key
Press them to scroll the options when browsing a function list. In edit state, press direction keys
to navigate.
◆ Dial 1 key and Right soft key
The bottom line on the screen displays the functions of the dial 1 key and Right soft key.
◆ OK key
Press it to confirm a selection.
◆ Number keys, * key and # key
Press number keys 0 through 9 to input or edit state to input numbers and characters;
In idle screen, you can press left soft key then press * to lock/unlock keypad.
Press two times the key * to input "+" in standby interface. When the symbol "+" appears,Press
the * key quickly to input "P" or "W" starting the second word,"P" and "W" are used for calling the
extension; "+" are used for dialing an international call.
1.3. Technical specifications
Phone Dimensions:112.1mm*49.6mm*13.7mm (W×D×H):
Weight: 67.5g
Lithium battery: Yes
Rated capacity: 800mah
Continuous standby duration: 72 hours (Relates to network status)
Continuous conversation duration: 3~4 hours (Relates to network status)
-8-
3. Getting started
1.1. Installing the SIM Card and the Battery
A SIM card carries useful information, including your mobile phone number, PIN (Personal Identification
Number), PIN2, PUK (PIN Unlocking Key), PUK2 (PIN2 Unlocking Key), IMSI (International Mobile
Subscriber Identity), network information, contacts data, and short messages data.
Note:
After powering off your mobile phone, wait for a few seconds before removing or inserting a SIM card.
Exercise caution when operating a SIM card, as friction or bending will damage the SIM card.
Properly keep the mobile phone and its fittings such as the SIM card beyond children's reach.
Installation
◆ Hold the End key for a while to power off the mobile phone.
◆ Take the back cover above the battery away.
◆ Take the battery away.
◆ Insert the SIM card into the SIM card slot lightly with the corner cutting of the card aligning to the notch
of the slot and the gold plate of the card facing download, till the SIM card cannot be further pushed in.
◆ With the metallic contacts of the battery facing the metallic contacts in the battery slot, press the battery
down until it locks into place.
-9-
Using code
The mobile phone and the SIM card support sorts of passwords, in order to prevent the phone and the
SIM card from being misused. When you are prompted to input any of the codes mentioned below, just input
the correct code and then press the OK key. If you input a wrong code, clear it and then input the correct code.
◆ Phone lock code
The phone lock code may be set to prevent your mobile phone from being misused. In general, this code
is provided along with the mobile phone by the manufacturer. The initial phone lock code is set to 0000 by the
manufacturer. If the phone lock code is set, you need to input the phone lock code when powering on the mobile
phone.
◆ PIN
The PIN (Personal identification number, 4 to 8 digits) code prevents your SIM card from being used by
unauthorized people. In general, the PIN is supplied with SIM card by the network operator. If PIN check is
enabled, you need to input the PIN each time when you power on your mobile phone. The SIM card will be
locked if you input wrong PIN code for three times.
Unlocking methods as follows:
-Input the correct PUK according to the screen tips to unlock the SIM card.
-Then input the new PIN and press the OK key.
-Input the new PIN again and then press the OK key.
-If the input PUK is correct, the SIM card will be unlocked and the PIN will be reset.
Note: The SIM card will be locked if you input wrong PIN code for three times. To unlock the SIM card,
you need to input the PUK. In general, the PUK can be obtained from the network operator.
◆ PUK
The PUK code (Personal Unlocking Key) is required to change a blocked PIN. It is supplied with SIM
-10-
card. If not, contact your network operator. If you input wrong PUK code for 10 times, SIM card will be invalid.
Please contact the network operator to replace the SIM card.
◆ Barring code
A barring code is required for setting the call barring function. You can obtain this code from the network
operator to set the call barring function.
1.2. Installing T-Flash Card
The T-Flash card is a pluggable mobile storage card inside the mobile phone.
uInsert the T-Flash card into the T-Flash card slot lightly with the corner cutting of the card aligning to
the notch of the slot and the gold plate of the card facing download, till the T-Flash card cannot be further
pushed in.
Note:
1. The mobile phone cannot automatically identify the T-flash card being inserted when the mobile phone
is powered on. You must power off the mobile phone and then power it on, so that the phone can identify the T-
Flash card.
2. The T-Flash card is a miniature object. Keep it out of the reach of children for fear that children swallow it!
1.3. Charging the Battery
The lithium battery delivered with the mobile phone can be put into use immediately after being unpacked.
Battery level indication:
◆ Your mobile phone can monitor and display the battery state.
◆ Normally the remaining energy of the battery is indicated by the battery level icon at the upper right
corner of the display screen.
-11-
◆ When the battery energy is insufficient, the mobile phone prompts "Battery low". If you have set an alert
tone, an alert tone will be given off when the battery level is too low.
◆ A charging animation appears when the battery is being charged. When the charging is complete, the
animation disappears.
Using a travel adapter:
◆ Install the battery into the mobile phone before charging the battery.
◆ Connect the adapter of the travel charger with the charging slot in the mobile phone. Ensure that the
adapter is fully inserted.
◆ Insert the plug of the travel charger to an appropriate power outlet.
◆ During the charging, the battery level grid in the battery icon keep flickering till the battery is fully
charged.
◆ It is normal when the battery becomes hot during the charging period.
◆ The battery icon does no longer flicker when the charging process ends.
Note:
Ensure that the plug of the charger, the plug of the earphone
Before the charging, ensure that the standard voltage and frequency of the local mains supply match the
rated voltage and power of the travel charger.
Using the Battery
The performance of a battery is subject to multiple factors: radio network configuration, signal strength,
ambient temperature, chosen functions or settings, phone fittings, and the voice, data or other application mode
you choose to use.
-12-
To guarantee the optimal performance of your battery, please stick to the following rules:
◆ Use only the battery provided by the vendor. Otherwise, damages or even injuries could be caused during
the charging.
◆ Power off the mobile phone before removing the battery.
◆ The charging process lasts a longer time for a new battery or a battery not in use for long. If the battery
voltage is too low to enable the mobile phone to be powered on, charge the battery for a longer time. In
this case, the battery icon does not flicker until a long time after the battery enters the charge status.
◆ During the charging, ensure the battery is placed in a room temperature environment or in an
environment close to room temperature.
◆ Immediately stop using the battery if the battery produces odor, overheat, cracks, distort or has other
damage, or if the electrolyte leaks.
◆ The battery wears out with use. A longer charging time is required as the battery is put into use for a long
time. If the total conversation duration decreases but the charging time increases even though the battery
is properly charged, purchase a standard battery from the OEM or use a battery approved by our
company. Using any poor-quality fittings will cause harm to your mobile phone or even incur danger!
Note: To guarantee your personal safety and protect the environment, do not litter the battery! Return the
old battery to the mobile phone manufacturer or place it in specified battery reclamation areas. Do not litter
any battery with other rubbish.
Warning: Short-circuits of the battery may cause explosion, fire, personal injury or other severe
consequences!
-13-
1.4. Powering On/Off the Mobile Phone
Hold the End key for a while to power on the mobile phone. A power-on animation appears on the display
screen.
Input the phone lock code and press the OK key if the mobile phone prompts you to input the phone lock
code. The original code is 0000
Input the PIN and press the OK key if the mobile phone prompts you to input the PIN. The PIN is provided
by the network operator for new opening SIM card.
Enter the standby interface.
To power off the mobile phone, hold the End key for a while.
1.5. Linking to the Network
After the SIM card and the mobile phone are successfully unlocked, the mobile phone automatically
searches for an available network. After finding a network, the mobile phone enters the standby state. When
the mobile phone is registered in the network, the name of the network operator is displayed on the screen.
Then you can dial or receive a call.
1.6. Dialing Calls
In the standby interface, press Dial-pad enter virtual dial pad, press number keys to input the area code
and the telephone number, and then press the dial key to dial a call.
1.7. Using the Headset
It would enter headset mode automatically when you insert headset to the slot. Make sure of inserting it
at the bottom of the slot, or you can’t use it normally.
-14-
4. Input method
This mobile phone provides English input, smart English input and numeric input method. You can use
these input methods when editing the contacts, short messages, files and greeting text.
1.1. Key for Input Methods
After you enter an edit window such as a window for editing the contacts, short messages or the
memorandum, an icon is displayed to indicate the current input method:
Numeric input:“123”
English input:“ABC, abc, Abc”
1.2. To Shift Entry Methods
Press the # key to switch between input methods.
1.3. Numeric Input
You can input numbers with the numeric input method. Press a number key to input the corresponding
number.
1.4. English input and numeric input:
The keyboards for English input and numeric input are defined in the following table:
Key Character or Function Remarks
-15-
Number key 1 . , - ? ! ’@ : # $ /_ 1
Number key 2 ABCabc2
Number key 3 DEFdef3
Number key 4 GHIghi4
Number key 5 JKLjkl5
Number key 6 MNOmno6
Number key 7 PQRSpqrs7
Number key 8 TUVtuv8
Number key 9 WXYZwxyz9
Number key 0 0
# key Press it to switch between input
methods
Left direction
key Press it to move to the left
-16-
Right direction
key Press it to move to the right
Left soft key Equivalent to OK or Options
Right soft key Equivalent to Back or Clear
End key Press it to return to the standby interface
English input:
■ Each key is used to represent multiple characters. Quickly and continuously press a key till the
character you want appears. Input the next character after the cursor moves.
■ Press the # key to switch between input methods
■ To input a blank, press number key 0.
■ To clear wrong inputs, press the Right soft key.
1.5. Inserting a Symbol
Press * key to enter the Select symbol interface, use direction keys or number keys to select a symbol you
want.
-17-
5. Using the Menus
1.1. Phonebook
1.2. Call logs
All calls
All calls will be in the list.
Missed Calls
You can view a list of the latest missed calls.
Note: When the mobile phone indicates that some calls are missed, you can select Read to enter the
missed calls list. Navigate to a missed call and then press the Dial key to dial the number that originated that
call.
Dialed Calls
You can view the latest dialed calls. Choose dialed calls and then select a dialed call to delete, save, dial,
or edit (or send a short message to it).
Received Calls
You can view the latest received calls. Choose received calls and then select a received call to delete,
save, dial, or edit (or send a short message to it).
-18-
Rejected Calls
You can view the latest rejected calls. Choose rejected calls and then select a rejected call to delete, save,
dial, or edit (or send a short message to it).
Delete All
You can delete all the latest call records.
Call Timers
Choose Call timers to view the last call time, the total time of all dialed calls, the total time of all received
calls and the total time of call history or to reset all the time.
1.3. Multimedia
Camera
The phone is provided with a camera, which supports the photographing functions. In the capture
interface, roll the phone to align the camera to the picture and then press OK key to capture photos. Pictures
will be saved in the file system of the memory card
Image Viewer
You can view the pictures in the T-card by this function. Press the direction key to choose them and left
soft key edit the pictures. Press right soft key to return last interface.
Video recorder
-19-
This function enables you to record dynamic pictures. In the capture interface, press OK key to capture
videos clip.
Video Player
Use this function to play video files. By pressing the direction key can you control the playing process of
video player: play/pause（OK key）, fast forward (press and hold right direction key) and rewind (press and
hold left direction key). In video player interface, you can press * and # key to control volume.
Audio Player
You can use this function to play audio files. By pressing the direction key you can control the playing
process of audio player: play/pause（OK key）, switch to last song/next song （press left or right direction
key）, fast forward (press and hold right direction key) and rewind (press and hold left direction key). In audio
player interface, you can press * and # key to control volume.
Recorder
The phone support WAV and AMR. The AMR takes the compression algorithm. So in the same memory
condition, it has longer recording time than WAV.
FM radio
You can use the application as a traditional FM radio with automatic tuning and saved channels. Before
using it, you should insert the earphone as antenna. In FM radio interface, left or right direction key to search
channels manually, OK key to play/pause the playing process of the current channel.
-20-
1.4. Contacts
The mobile phone can store up to 500 telephone numbers. The telephone numbers that a SIM card can
store depends on the storage capacity of the SIM card. The telephone numbers stored in the mobile phone and
in the SIM card form a phonebook. The phonebook search function enables you to view contacts. You can
search a contact as required from the phonebook. Select this option, in the edit interface, input the name of the
contact you want to search or the first letter(s) of the name. All the contacts meeting the search condition are
listed. Press the Up and Down direction keys to browse the contacts and select contact. Press right direction
key to view other groups: family, friends, business, classmates and so on, you can view other group when the
contacts must be save in DUT , not save Sim Card
1.5. Audio
You can use this function to play audio files. By pressing the direction key you can control the playing
process of audio player: play/pause（OK key）, switch to last song/next song （press left or right direction
key）, fast forward (press and hold right direction key) and rewind (press and hold left direction key). In audio
player interface, you can press * and # key to control volume.
1.6. Message
If the short message memory is full, a blinking message icon appears on the top of the screen. To normally
receive short messages, you need to delete some of the existing short messages.
If the destination user has received the short message you sent and the short message delivery report
function is activated, the phone will give off a message report alert tone.
-21-
Write message
Access this menu to create a text message.
Inbox
Received Messages are listed in this menu.
Outbox
The messages which are sent failed are stored in the Outbox.
Drafts
Draft messages are listed in this menu.
Sent
Sent messages are listed in this menu.
Templates
You can create pre-defined messages in this interface.
1.7. File manager
The phone supports the memory card. The capacity of the memory card is selectable. You can use the file
manager to conveniently manage various directories and files on the memory card or the phone.
Choose this option to enter the root directory of the memory. The root directory will list the default folders,
new folders and user files. When the mobile phone is powered on for the first time or when you have not
changed the directory, the root directory contains the default folders only.
-22-
1.8. Application
Bluetooth
You can transfer data, such as music to other device using Bluetooth. Search the device and
receive/transfer data. The received data is automatically stored in the directory.
Alarm
You can set three alarms through this function.
Calendar
Once you enter this menu, there is a monthly-view calendar for you to keep track of important
appointments, etc. Days with events entered will be marked.
Calculator
The calculator can add, subtract, multiply and divide.
World time
You can view and set your phone time by choose different time zones.
Torch
You can turn on/off the flashlight by this function.
-23-
1.9. Settings
Phone settings
◆ Date & time: Set the time, set the date, time format, date format and detail time of the location.
Note: If you remove the battery from the mobile phone or if the battery energy was exhausted a long time
ago, you may need to reset the date and time when re-inserting the battery or powering on the mobile phone
after recharging.
◆ Language settings: Select the display language and writing language for the mobile phone.
◆ Shortcut settings: Select preferred function as shortcut on screen direction key as needed.
◆ Auto power on/off: Set the time when the mobile phone will be automatically powered on or off.
◆ Power management: you can view you battery statue through this function.
◆ Restore factory settings: You can cancel the setting you set. The original code is 0000
Display
Users can access this item to set Wallpaper, Idle display settings, Contrast, Backlight and Keypad
backlight time etc.
Call Settings
◆ Single-SIM:
◆ Call Divert: this network function enables you to forward incoming calls to another number you
have previously specified.
◆ Call Waiting: After you choose Activate, the mobile phone will contact the network. A moment later, the
network will make a response and send a message to acknowledge your operation. If the call waiting
-24-
function is activated, the network will alert you and the mobile phone screen will display the incoming
call number if others are calling you while you are already in a conversation.
◆ Call Barring: The call barring function enables you to bar calls as needed. When setting this function,
you need to use a network barring code, which can be obtained from the network operator. If the code is
wrong, an error message will be prompted on the screen. After selecting a call barring option, continue to
select Activate or Deactivate. The mobile phone will prompt you to input the call barring code and then
contact the network. A moment later, the network will make a response and send the operation results to
the mobile phone.
◆ Hide ID: You can select hide ID, display own ID and or display ID by network.
◆ Others: You can set auto record, vibration when connected through this function.
◆ Security Settings
This function provides you with related settings about safety use
◆ PIN: To activate PIN lock, you need to input the correct PIN code. If you set PIN lock to On, you need to
input the PIN each time you power on the mobile phone. In the case you input a wrong PIN for three
consecutive times; you need to input the PIN Unblocking Key (PUK). The PUK is used to unlock and
change the locked PIN. To obtain the PUK, contact the network operator.
◆ Modify PIN2: To change PIN2 code of PIN code.
◆ Phone locked: The function enables you to lock/unlock the phone. Entering password to switch on or off
the phone. Password is required when the phone is locked. The initial password is 0000.
◆ Modify the cell phone password: to change phone password.
◆ Privacy: You can set password to protect your date security, the initial password is 0000
◆ Auto keypad lock: The function enables you to lock/unlock the keypad. Set the auto locking time, 5s,
15s, 30s, 1min and 5mins are available.
-25-
◆ Lock screen by end-key: You can select to turn on/off this function.
◆ Theft proof: You can set password to protect your cell phone.
◆ Fixed dialing: you can only dial the number in the list.
◆ Connections
◆ Network selection: Set Network selection mode to Automatic or Manual. Automatic is recommended.
When Network selection mode is set to Automatic, the mobile phone will prefer the network where the
SIM card is registered. When Network selection mode is set to Manual, you need to select the network
operator's network where the SIM card is registered.
1.13. Profiles
The mobile phone provides multiple user profiles, so that you can customize some settings to adapt to the
specific events and environments.
Customize the user profiles according to your preference and then activate the user profiles. The user
profiles fall into five scenarios:Normal, Silent, meeting, Indoor, outdoor. you can also save the Profiles if
you like. In the standby mode long press # can switch scenarios.
15. Services No internetO INTERNETs NO INTERNET
STK
STK service is the tool kit of SIM card. This phone supports the service function .The specific items are
depended by SIM card and network. Service menu will be auto added to the phone menu when supported by
network and SIM card.
-26-
6. Appendix
Appendix 1：Troubleshooting
If you find exceptions when operating the mobile phone, restore the factory settings and then refer to the
following table to solve the problem. If the problem persists, contact the distributor or service provider.
Fa
ult C
ause Solution
SIM card
error
The SIM
card is
damaged. Contact your network service provider
The SIM
card is not in
position. Check the SIM card
The
metal face of
the SIM card
is polluted.
Clean the SIM card with a clean cloth
-27-
Poor
received signal
quality
Signals
are obstructed.
For instance,
radio waves
cannot be
effectively
transmitted
nearby a high
building or in
a basement.
Move to a place where signals can be effectively
transmitted
Line
congestions
occur when
you use the
mobile phone
in high-traffic
hours
Avoid using the mobile phone in high-traffic hours
-28-
The
mobile phone
cannot be
powered on
The
battery energy
is exhausted. Charge the battery
Calls
cannot be
dialed
Call
barring is
activated Cancel call barring
The
mobile phone
cannot connect
the network
The SIM
card is invalid Contact your network service provider
-29-
The
mobile phone
is not in a
service area of
the GSM
network
Move to the network operator's service area
The
signal is weak Move to a place where the signal quality is high
The
battery cannot
be charged
The
charging
voltage does
not match the
voltage range
indicated on
the charger
Ensure the charging voltage matches the voltage range
indicated on the charger
-30-
An
improper
charger is used Use the charger specially designed for the mobile phone
Poor
contact Ensure the charger plug is in good contact with the
mobile phone
-31-
FCC Statement
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired
operation.
2. Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
SAR Information Statement
-32-
Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the
emission limits for exposure to radiofrequency (RF) energy set by the Federal Communications Commission
of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of
RF energy for the general population. The guidelines are based on standards that were developed by
independent scientific organizations through periodic and thorough evaluation of scientific studies. The
standards include a substantial safety margin designed to assure the safety of all persons, regardless of age
and health. The exposure standard for wireless mobile phones employs a unit of measurement known as the
Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. * Tests for SAR are
conducted with the phone transmitting at its highest certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while
operating can be well below the maximum value. This is because the phone is designed to operate at multiple
power levels so as to use only the power required to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power output. Before a phone model is available for sale to the
public, it must be tested and certified to the FCC that it does not exceed the limit established by the
government adopted requirement for safe exposure. The tests are performed in positions and locations (e.g.,
at the ear and worn on the body) as required by the FCC for each model. The highest SAR value for this
model phone when tested for use at the ear is 0.977W/Kg and when worn on the body, as described in this
user guide, is 0.486W/Kg(Body-worn measurements differ among phone models, depending upon available
accessories and FCC requirements). While there may be differences between the SAR levels of various
phones and at various positions, they all meet the government requirement for safe exposure. The FCC has
granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in
compliance with the FCC RFexposure guidelines. SAR information on this model phone is on file with the
FCC and can be found under the Display Grant section of http://www.fcc.gov/ oet/fccid after searching on
FCC ID: 2ABOSSKYF1C Additional information on Specific Absorption Rates (SAR) can be found on the
Cellular Telecommunications Industry Asso-ciation (CTIA) web-site at http://www.wow-com.com. * In the
United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg)
averaged over one gram of tissue. The standard incorporates a sub-stantial margin of safety to give additional
protection for the public and to account for any variations in measurements.
-33-
Body-worn Operation
This device was tested for typical body-worn operations. To comply with RF exposure requirements, a
minimum separation distance of 10mm must be maintained between the user’s body and the handset,
including the antenna. Third-party belt-clips, holsters, and similar accessories used by this device should not
contain any metallic components. Body-worn accessories that do not meet these requirements may not
comply with RF exposure requirements and should be avoided. Use only the supplied or an approved
antenna.
