Skyrocket Toys 01165RX49 Illumivor RC Shark User Manual MechaShark Instr OutsideREV2
Skyrocket Toys LLC Illumivor RC Shark MechaShark Instr OutsideREV2
User Manual
Adult supervision recommended.
Works best when used on solid, at surfaces. Not
recommended for use on carpeting.
AVOID COLLISIONS WITH WALLS AND HARD
OBJECTS. HIGH SPEED CRASHES MAY CAUSE
DAMAGE TO MECHA-SHARK
WARNINGS!
HELPFUL HINTS
Remove all packaging attachments before giving the toy to a child
Not suitable for children under 4 yrs. old
Contains small parts that could be swallowed
Keep ngers, hair and loose clothing away from tires and wheels when
Mecha-Shark is turned on
Do not pick up Mecha-Shark when it is in motion
Do not drive Mecha-Shark toward people, animals, walls, furniture or
breakable objects. Collision with Mecha-Shark at high speed may cause
damage and/or injuries.
Do not operate near stairs or in areas that may result in a high fall as
damage may occur.
6+ Contents: R/C Shark Vehicle, Remote
Control and Instructions
Keep these instructions for future reference. Do not discard.
BATTERY CAUTIONS
• Do not use rechargeable batteries.
• Non-rechargeable batteries are not to be recharged.
• Different types of batteries or new and old batteries are not to be mixed.
• Batteries are to be inserted using correct polarity.
• Remove exhausted batteries as soon as possible and discard properly.
• Remove all batteries from compartment if toy is not used for a long
period (seven months).
• The supply terminals are not to be short circuited.
PROBLEM SOLUTION
Make sure both the vehicle and remote have fresh batteries
installed and the power switch (on both) is switched to ON.
Turn the steering trim knob on the back of the vehicle slightly to
one direction or the other until the vehicle drives straight.
Interference may be caused by electronic signals from another
source. Turn both the vehicle and remote off for 30 seconds. Turn
both units back on and try again.
Vehicle will not run.
Vehicle is running slow.
Lights are dim.
Vehicle turns to the left or right while the
steering knob is not engaged.
Vehicle lights start blinking erratically or
sound fx start to skip.
This device complies with PART 15 of the FCC Rules. Operation is subject to the
following two conditions. (1) This device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation. CAUTION: Changes or modifications not expressly approved by
the party responsible for compliance could void the user’s authority to operate
equipment. NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by running the
equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures: Reorient or relocate the receiving antenna - Increase
the separation between the equipment and receiver - Connect the equipment into an
outlet on a circuit different from that to which the receiver is connected - Consult the
dealer or experienced radio/TV technician for help.
TROUBLESHOOTING
Questions or Comments?
www.illumivor.com/support
support@skyrockettoys.com
1-888-674-5650
©2012 Skyrocket Toys, LLC, Venice CA 90291 USA. All Rights Reserved.
Illumivor, Skyrocket and the Skyrocket logo are trademarks of
Skyrocket Toys LLC. Conforms to product safety
standards ASTM F963. MADE IN CHINA
STABILIZER FINS: Mecha-Shark is equipped with advanced rear wheel steering! This allows him to make quick
aggressive turns, but may cause him to tip over in extreme conditions. If not already installed,
you can attach the stabilizer fins for better control!
CARRIER FREQUENCY 27.145 MHz FIELD STRENGTH: 79.8dBuV/m, at 3m
TM
™
™
Art Release for Production (Mechanical)
Mecha-Shark Instructions - Outside
File Name: MechaShark_Instr_OutsideREV2.ai
Revision: 2
Licensor Approval Date:
Production Release Date: 07-10-12
Production Artist: Melissa Rahardjo
Colors: PANTONE 540 C
Trim Size:
Notes:
AA
6 x
1 x
9 Volt
GETTING STARTED CONTROLLING THE BEAST
INSTALLING BATTERIES:
(Adult Assistance Required)
POWER UP!
Turn on both Mecha-Shark and the
remote by flipping both power switches
to ON.
ATTACK!!!!
Press the Attack button to send
Mecha-Shark into a feeding frenzy!
ANTENNA
STEERING KNOB
THROTTLE TRIGGER
(Forward/Backward)
POWER
ON/OFF
SOUND FX
MUTE
ATTACK BUTTON
MECHA-SHARK REMOTE CONTROL
MOVING
FORWARD
MOVING
BACKWARD
TURNING
RIGHT
TURNING
LEFT
STEERING TRIM
ADJUSTMENT
POWER
ON/OFF
Ask an adult to help install batteries. Use a Phillips screwdriver to open the battery
covers and install fresh new alkaline batteries as shown (not included). Replace the
battery covers and screw them securely closed.
