Skyrocket Toys 01750TX24G MEBO 2.0 User Manual 01750 Mebo2 IM 062117 IR3
Skyrocket Toys LLC MEBO 2.0 01750 Mebo2 IM 062117 IR3
Users Manual
WARNING
• This product is intended primarily for indoor use or on surfaces clear of dirt or water.
• Do not immerse the product in water as this is hazardous and can cause product to malfunction.
• Keep fingers and hands away from all moving parts and joints including arm and wheels.
• Keep the camera clean, and wipe with a lint-free cloth.
• Remove battery when not in use for long periods, it can reduce the life span and performance of the battery.
• When charger is not in use, disconnect it from the power source.
• Do not leave the battery connected to charger for longer than one day. Overcharging may shorten battery life.
• If left unused a fully charged battery will discharge itself over time.
• Charging time may vary in countries where there is major fluctuation.
• Use under adult supervision only. Do not use if there is any visible damage to the cord, housing or other moveable parts.
THIS PRODUCT CONTAINS A LITHIUM-POLYMER BATTERY 7.4V 1350mAh:
• LiPo batteries have a severe risk of fire and injury if they are improperly handled or misused. They may explode, overheat or ignite.
• Read all following precautions and instructions regarding the care and use of LiPo batteries.
• The built-in LiPo battery is only to be used with the toy and charger included with this product.
• Keep away from flammable materials.
• Do not expose to direct sunlight.
• Do not place in fires or leave in hot places.
• Do not drop or make subject to strong impact.
• Keep dry and away from water.
• Remove battery from the compartment if toy is not used for a long period.
• The supply terminals are not to be short circuited.
• Never throw batteries in a fire or attempt to open outer casing.
• LiPo Battery Disposal: LiPo batteries must be recycled or disposed of properly. They should not be disposed of with other household waste.
• Check your local laws and regulations for correct recycling and/or battery disposal.
This device complies with PART 15 of the FCC Rules. Operation is subject to the following two conditions. (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
CAUTION
• Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority
to operate the equipment.
• To prevent axles from binding, do not drive over loose hair or shag carpeting.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or
relocate the receiving antenna - Increase the separation between the equipment and receiver - Connect the equipment into an outlet on a
circuit different from that to which the receiver is connected - Consult the dealer or an experienced radio/TV technician for help.
©2017 Skyrocket LLC, Los Angeles CA 90066 USA. All Rights Reserved. Mebo and Skyrocket and their respective logos are trademarks
and/or registered trademarks of Skyrocket LLC. All other trademarks, logos and copyrights are the property of their respective owners,
and there is no relationship express or implied with Skyrocket LLC. MADE IN CHINA.
Remove all packaging attachments before giving the toy to a child. Not suitable for children under 3 years due to small parts that could
be swallowed. Conforms to product safety standards ASTM F963. Keep instructions for future reference. Do not discard.
Proudly built with open source code. http://skyrocketon.com/open-source/
Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc.
Google Play is a trademark of Google Inc.
BAT T E RY
CONTENTS: MEBO ROBOT,
LIPO BATTERY & CHARGER
SYSTEM REQUIREMENTS:
Works with most Apple iOS
and Android Devices, Wi-Fi Connection.
SMART PHONE OR TABLET
REQUIRED (NOT INCLUDED).
Questions or comments?
Please call 888-674-5650
or visit www.MeboRobot.com
#MeboSpyBot
Hop online and check out
what Mebo’s been up to!
www.MeboRobot.com
IMPORTANT
• Adult supervision is required for charging LiPo battery.
• After use, allow battery to cool down to room temperature
before charging again.
• Charge battery in an isolated area, away from excessive heat
or moisture.
• If you suspect battery is damaged, discontinue use
immediately and discard according to local regulations.
• Do not modify, heat or wet the battery in any way.
• Only recharge with the charger provided.
01750-G1
AGES 8+
4 1
™
Fold Line
DO NOT PRINT
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment .
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
This equipment should be installed and operated with minimum distance 20cm between the radiator&
your body.
your body.
2 3
• If after several attempts you are unable to connect to Mebo through
your device’s Wi-Fi, press RESET for 5 seconds on the underside of
Mebo using the tip of a pin. After reset, try connecting again.
PROBLEM SOLUTION
Mebo is not responding
Mebo’s part(s) aren’t moving
Unable to connect to Mebo
through WiFi
• Ensure battery is charged and properly plugged into connector.
• Check to see if Wi-Fi is enabled on your smart device.
• Mebo may be out of Wi-Fi range.
• Inspect MEBO’s joints, claw and wheels for foreign objects.
TROUBLESHOOTING For more troubleshooting and tips, visit www.MeboRobot.com
2. CHARGING MEBO’s BATTERY
• Plug battery into USB Charger.
• Plug USB Charger into USB port (Not included).
• Charge until battery is completely charged.
(Light on charger will turn green when fully charged.)
• Unplug battery from charger and charger from USB port.
1. ATTACH MEBO’S WHEELS
Mebo’s wheels must be attached before use.
• Carefully align the grooves on the wheels with
the slots on the wheel hubs and snap into place.
(The bigger wheels go in front)
• Pull the treads over one wheel at a time.
GETTING STARTED
3. INSTALLING MEBO’S BATTERY
• Open the battery compartment on the back of Mebo.
• Plug the battery into the enclosed connector. Rest
the battery inside and close the compartment door.
4. DOWNLOAD THE MEBO 2.0 APP
• Download the MEBO 2.0 app and install onto your
smart phone or tablet.
5. TURN MEBO ON
• Flip the power switch, on the back of Mebo, to turn on.
Mebo will light up and flash when turned on.
6. CONNECT WITH YOUR SMART DEVICE
• Enable the Wi-Fi on your phone or tablet and select
MEBO2 - xx-xx-xx (name of connection may differ slightly from
this example on your Wi-Fi network list).
• Mebo will stop flashing when successfully connected to Wi-Fi
and the app.
• Once connected please follow in App instructions.
Eye (Camera Lens)
Speaker
Battery Compartment
ON/OFF
Switch
Wrist
Arm
Reset Button
(on Bottom Panel)
All-Terrain
Tread Drive
Light-up Claw
MEBO SPECS
Microphone
RESET MEBO’S WI-FI CONNECTION
• If Mebo is unresponsive, you may need to press RESET to clear and reset Mebo.
• RESET can also be used to clear a Wi-Fi password if you have forgotten it.
• Use a pin or unfolded paperclip to press the RESET button and hold for 5 seconds.
RESET
*Mebo’s lift capacity should not exceed 250g
Mebo’s wrist has 180°
rotational range!
GREEN LIGHT
= Fully Charged
RED LIGHT
= Charging
