Skytech II 1001T Fireplace Remote Transmitter User Manual
Skytech II, Inc. Fireplace Remote Transmitter
User Manual
SKY-1001LCD
INTRODUCTION
SKYTECH’S remote control system was developed to provide a safe, reliable, and
user-friendly remote control system for gas heating appliances. Its battery operation
allows the system to operate independently of household current. The system operates
on radio frequencies with nondirectional. The SYSTEM’s operating range is
approximately 80 feet with 255 security codes programmed at the factory.
OPERATING
The transmitter operates on a 12V battery made specifically for remote controls and
electronic lighters. Before using the transmitter, remote the insulation tab protecting
one end of the battery in the battery compartment.
The transmitter has ON and OFF functions that are activated by pressing either button
on the face of the transmitter. When ON button on the transmitter is pressed, the
security code of 303.875MHZ will send to the receiver. Meanwhile, transmitter’s
LCD will display . Otherwise, the OFF is pressed then the LCD will show no .
When ON/OFF are pressed at the same time, the temperature display will change the
ºC or ºF option function.
GENERAL INFORMATION
BATTERY LIFE
Life expectancy of alkaline batteries in the SKYTECH-1001LCD should be at least
12 months. When the transmitter no longer operates the receiver from a distance it did
previously (i.e. the transmitter’s range has decreased), the batteries should be checked.
1. 3V battery for LCD display ( Fig.1)
2. 12V battery for transmitter frequency ( Fig.2)
3. The battery mark of LCD shows flash or unclear, please change
3V battery
4. The LCD shows no action while press the button. Please change
the 12V battery.
BATTERIES: Transmitter 12V (A23)
BATTERIES OF LCD: 3V (2032)
OPERATING FREQUENCY: 303.875 MHz
ONE YEAR BATTERY LIFE
Caution :changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
