SmartThings STH-ETH200 Home Automation Gateway User Manual
SmartThings, Inc. Home Automation Gateway Users Manual
Users Manual
AC Plug
Power Adapter
Power
Connector
Network
Connector
SmartThings
Product Information Guide
SmartThings
Hub
Hub
DOC-HV2-R001
Power Reset USB Network
(ethernet)
Status LED
Product Information Guide
This guide contains information regarding setup, safety, handling, disposal and
recycling, regulatory, and warranty for the SmartThings Hub.
SmartThings Hub Setup
The SmartThings Hub works best if installed in a central location to where your
SmartThings will be connected. The recommended separation distance from the
user for this equipment is 7.6 inches (20 cm).
• Connect your SmartThings Hub to your Internet router using the included
Ethernet cable.
• Connect your SmartThings Hub to power using the provided power supply.
• Continue setting up your Hub by going to www.smartthings.com/start on you
smart phone and following the on screen instructions.
Disconnect the network cable and power adapter or any other connected
peripherals if any of the following conditions exist:
• The power cord or connector is damaged or frayed.
• You want to clean the Hub (see Important Safety Instructions).
• The Hub or attached cables are exposed to rain, water/fluids,
or excessive moisture.
• The Hub Power Adapter is damaged or had be dropped and you suspect it
needs to be serviced.
Battery Backup Installation
Disconnect the network cable and power adapter or any other connected
peripherals before installing batteries (4xAA):
• Slide bottom cover off.
• Insert 4 AA batteries.
• Slide bottom cover on till it snaps in to place.
NOTE: Hub does not recharge batteries.
Front
Back
Avoid installing the SmartThings Hub near or inside sources
of metal, radio or electromagnetic interference.
Vermeiden Sie die Installation des SmartThings Hubs in oder
in der Nähe von Metall, Funkantennen oder anderen elektro-
magnetischen Störsendern
Éviter l’installation du Hub SmartThings a à proximité ou a à
l’intérieur d’objets métalliques ou de sources d’interférences
radioélectriques ou électromagnétiques.
WARNING: No user-serviceable parts inside. Refer all servic-
ing to qualified service personnel.
Warnung: Keine Wartung einzelner Teile durch den Nutzer.
Wenden Sie sich nur an qualifiziertes Servicepersonal für
Wartungen
Attention: l’équipement SmartThings ne doit être en aucun
cas ouvert par l’utilisateur luimême. Pour l’entretien et/ou la
maintenance, contacter le personnel qualifié.
12
3 4
Certifications
Certified under FCC Part 15.
Certified in Canada by IC to RSS-210.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
SmartThings Hub Model: STH-ETH200, FCC ID: R3Y-STH-ETH200, IC:
10734A-STHETH200, M/N: PGC431-D , Contains FCC ID: D87-ZM5304-U, IC: 11263A-
ZM5304, M/N: ZM5304AU,
CE version contains M/N: ZM5304AE.
FCC Statement
This device complies with Part 15 of the FCC rules. Operation is subject to the following
two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that
may cause undesired operation.
Canada Statement
This device complies with Industry Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference, and (2)
this device must accept any interference, including interference that may cause undesired
operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils
radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes
: (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
Information to the User
Changes or modifications not expressly approved by SmartThings, Inc. could void your
authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
One (1) Year Limited Warranty
SmartThings Inc. warrants this product (the “Product”) against defects in materials and/or
workmanship under normal use for a period of ONE (1) YEAR from the date of purchase
by the original purchaser (“Warranty Period”). If a defect arises and a valid claim is
received within the Warranty Period, then as your sole remedy (and SmartThings‘ sole
liability), SmartThings will at its option either 1) repair the defect at no charge, using new
or refurbished replacement parts, or 2) replace the Product with a new product that is
functionally equivalent to the original, in each case within 30 days following receipt of the
returned Product. A replacement product or part assumes the remaining warranty of the
original Product. When a Product or part is exchanged, any replacement item becomes
your property and the replaced Product or part becomes SmartThings’ property.
Obtaining Service: To obtain warranty service, visit support.smartthings.com to speak with
a service agent or open a service request. Please be prepared to describe the Product that
needs service and the nature of the problem. A purchase receipt is required. The Product
must be insured, and shipped freight prepaid and securely packaged. You must contact
support for a Return Material Authorization Number (“RMA Number”) before shipping any
Product, and include the RMA Number, a copy of your purchase receipt and a description
of the problem you are experiencing with the Product. Any claim under this Limited
Warranty must be submitted to SmartThings before the end of the Warranty Period.
Exclusions: This warranty does not apply to: a) damage caused by failure to follow
instructions relating to the Product’s use or the installation of components; b) damage
caused by accident, abuse, misuse, transport, neglect, fire, floods, earthquake or other
external causes; c) damage caused by service performed by anyone who is not an
authorized representative of SmartThings; d) accessories used in conjunction with a
covered Product; e) a Product or part that has been modified to alter functionality or
capability; f) items intended to be periodically replaced by the purchaser during the normal
life of the Product, including, without limitation, batteries, bulbs or cables; g) a Product
that is used commercially or for a commercial purpose, in each case as determined by
SmartThings.
EXCEPT FOR BODILY INJURY, SMARTTHINGS SHALL NOT BE LIABLE FOR (I) ANY LOST
PROFITS, COST OF PROCUREMENT OF SUBSTITUTE PRODUCTS, OR ANY INCIDENTAL
OR CONSEQUENTIAL DAMAGES, OR (II) ANY AMOUNTS IN EXCESS OF THE PURCHASE
PRICE FOR THE PRODUCT, IN EACH CASE WHETHER RESULTING FROM THE USE
OF OR INABILITY TO USE THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF
THIS WARRANTY, EVEN IF COMPANY HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION
OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION AND
EXCLUSIONS MAY NOT APPLY TO YOU.
TO THE EXTENT PERMITTED BY APPLICABLE LAW, SMARTTHINGS DISCLAIMS ANY
AND ALL STATUTORY OR IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION,
WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND
WARRANTIES AGAINST HIDDEN OR LATENT DEFECTS. IF SMARTTHINGS CANNOT
LAWFULLY DISCLAIM STATUTORY OR IMPLIED WARRANTIES, THEN TO THE EXTENT
PERMITTED BY LAW, ALL SUCH WARRANTIES SHALL BE LIMITED IN DURATION TO THE
WARRANTY PERIOD. SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU.
This warranty gives you specific legal rights and you may also have other rights, which
vary from state to state. To exercise your rights under this warranty, please follow the
instructions above under the heading “Obtaining Service”, or contact SmartThings at
SmartThings, Inc., 1000 Potomac St NW #120, Washington, DC 20007.
Tested to Comply With FCC Standards
FOR HOME OR OFFICE USE
DOC-HV2-R001
Important Safety Instructions
• Read, keep and follow these instructions.
• Heed all warnings.
• Do not use this product near water or expose the product to dripping or
splashing of any water or liquid.
• Clean only with a dry cloth.
• Do not install near any heat sources such as radiators, heat registers, stoves
or other apparatus (including amplifiers) that produce heat.
• Only use attachments and accessories specified by the manufacturer.
• Read our Product Usage Guidelines at: http://SmartThings.com/guidelines
Wichtige
• Lesen, behalten und folgen Sie diesen Anweisungen.
• Beachten Sie alle Warnhinweise.
• Verwenden Sie das Produkt nicht in der Nähe von Wasser und vermeiden Sie
Tropfen oder Spritzer von Flüssigkeiten jeder Art.
• Säubern Sie das Gerät ausschliesslich mit einem trockenen Tuch
• Vermeiden Sie die Installation in der Nähe von Wärmequellen wie Heizungen,
Öfen oder anderen Geräten (inkl. Verstärkern), die Hitze produzieren.
• Verwenden Sie nur Hersteller zertifiziertes Zubehör.
Règles de sécurité:
• Lire, conserver et suivre ces instructions.
• Respecter toutes les consignes de sécurité.
• Nettoyer l’appareil uniquement avec un chiffon sec.
• Ne pas utiliser à proximité et éviter tout contact avec l’eau ou un quelconque
liquide.
• Ne pas installer a proximité d’une source de chaleur telle que radiateur,
poêle ou autres appareils (incluant les amplificateurs) qui produisent de la
chaleur.
• Utiliser uniquement des accessoires recommandées par le fabricant.
