C9GMXA freestanding cooker, 90cm wide
ID160512
Code C9GMXA
dimensions: 900mmW x 600mmD x 900mmH
NB: height excludes fitted 63mmH rear splashguard.
NB: actual overall height can be adjusted — from
812mm without supplied telescopic legs to a maximum
912mm height with telescopic legs fitted. The cooker can
be positioned on a kitchen cabinet plinth.
Canali knobs
fan forced
grill (without rotisserie)
fan grill
classic convection
defrost
super cook
base heat only
rotisserie
90cm giant electric oven and six-burner gas hob with flame failure device
EAN 8017709121419
OVEN
•126 litre
•seven cooking functions plus defrost
•twin fan forced — 2 x 2000 watt rear wall
elements
•full programmable — digital
time of day
fully automatic cooking
semi automatic cooking
minute minder
manual override
• double glazed, thermo-reective door
•forced air door cooling
•easy cleaning oven enamelling — AA anti acid
•safety-notch trays and shelves
•41 litre full-width storage compartment
•insulated control panel dials and door handle
NB 63mm high rear splashguard supplied for
optional tment
Option: stainless steel kickplate, code KITZOC9
COOKTOP
• spacious six-burner hob, 50.6mj/hr maximum
• three heavy-duty cast-iron trivets
• ame failure device (FFD) tted to each burner
• automatic electronic ame ignition
• ultra-rapid triple-crown all-purpose burner (wok)
• rapid burner
• two semi-rapid burners
• two low-simmer auxiliary burners
• single-pressed stainless steel hob with rolled edging
• no metal joins eliminates difcult grime
accumulation
• satin stainless steel nish
• set for natural gas, regulator supplied
• ULPG adaptable, test point supplied
• 60mm high splashguard supplied (optional tment
to rear of cooktop zone)
• burner skirts, burner caps removable for easy
maintenance
C9GMXA freestanding cooker, 90cm wide
ID160512
Code C9GMXA
WARNING: technical specifications and product sizes can be varied by the manufacturer, without notice.
Cutouts for appliances should only be by physical product measurements. The above information is
indicative only.
height minimum 812mm without legs, maximum 912mm
with legs fully extended and excluding 63mmH
rear splashguard
width 898mm
depth 600mm
net weight 74kg
gross weight 80kg
OVEN
internal oven dimensions 350mmH x 770mmW x 450mmD = 121.3 litres
net cooking dimensions 340mmH x 750mmW x 420mmD = 107.8 litres
storage compartment 760mmW x 450mmD x 120mmH = 41 litres
electricity supply 240 volt, 50 Hz
electrical connection hard-wired single phase
maximum current 18.67 amp
HOB 50.6 mj/hour maximum over six burners
supplied • three heavy-duty cast-iron trivets for full gas
hob cover
• 60mmH x 898mmW splashguard for rear of
hob, optional fitment
• baking/grill tray
• two chromed-wire shelves
• one teflon biscuit tray
• 4 x telescopic legs
options stainless steel kickplate, code KITZOC9
gas connection ½” BSP gas inlet connection
½” BSP 1.0 kPa natural gas, regulator supplied
adapt for ULPG — test point supplied
912 max : 872* min
600
900
63
* includes legs at
minimum
60mm height
element roof floor rear wall rear wall
fan (2)
cooling
fan light (2) rotisserie maximum
wattage current ampinner outer
wattage 1600 1200 1800 1500x2 25x2 20 15x2 10
static grill - - - - 2850 11.88
fan grill - - - - - 2900 12.09
convection - - - - 3050 12.71
fan forced - - - - 3080 12.84
super cook 700 700 - - - - 4480 18.67
base heat only - - - 2154 8.98
rotisserie - - - - - 2914 12.14
defrost - - - 104 0.43
rear splashguard
260
½” BSP gas inlet connection
><
50
optionally-fitted
telescopic feet
> <
100 145
hard-wiring
connection
fixed base
560
600
V
V
63
40
> <
>
60-100
27
>
> <
42
812
872 min : 912 max
745
fixed base
><
50
>
22
195
100
4 x supplied and optionally-
fitted telescopic feet, net
height 60mm 100mm
REAR UTILITIES
gas electric
