SA9065XS freestanding cooker, 90cm wide

ID300712

Code SA9065XS

dimensions: 900mmW x 600mmD x 900mmH

NB: height excludes fitted 63mmH rear splashguard.

NB: actual overall height can be adjusted — from 785mm without supplied telescopic legs to a maximum 925mm height with

telescopic legs fitted. The cooker can be positioned on a kitchen cabinet plinth.

Canali knobs

90cm giant electric oven and five-burner gas hob with flame failure device

EAN 8017709101121

OVEN

•126 litre oven

•108 litre net cooking capacity

• ve cooking functions

• twin fan forced — 2 x 2000 watt rear wall

elements

• full programmable — digital

time of day

fully automatic cooking

semi automatic cooking

minute minder

manual override

• double glazed, thermo-reective door

• forced air door cooling

•Ever Clean enamel

• safety-notch trays and shelves

• 41 litre full-width storage compartment

• insulated control panel dials and door handle

NB 63mm high rear splashguard supplied for

optional tment

Option: stainless steel splashback:

650mmH x 900mmW, code 14202

HOB

• spacious ve-burner hob, 43.3mj/hr maximum

• three heavy-duty cast-iron trivets

• ame failure device (FFD) tted to each burner

• automatic electronic ame ignition

• ultra-rapid triple-crown all-purpose burner (wok)

• rapid burner

• two semi-rapid burners

• one low-simmer auxiliary burner

• single-pressed stainless steel hob with rolled edging

• no metal joins eliminates difcult grime

accumulation

• satin stainless steel nish

• set for natural gas, regulator supplied

• ULPG adaptable, test point supplied

• 60mm high splashguard supplied (optional tment

to rear of cooktop zone)

• burner skirts, burner caps removable for easy

maintenance





bakers function

static grill

fan grill

fan forced

convection

SA9065XS freestanding cooker, 90cm wide

ID300712

Code SA9065XS

WARNING: technical specifications and product sizes can be varied by the manufacturer, without notice.

Cutouts for appliances should only be by physical product measurements. The above information is

indicative only.

height minimum 785mm without legs, maximum 925mm

with legs fully extended and excluding 63mmH

rear splashguard

width 898mm

depth 600mm

net weight 74kg

gross weight 80kg

OVEN

internal oven dimensions 350mmH x 770mmW x 450mmD = 121.3 litres

net cooking dimensions 340mmH x 750mmW x 420mmD = 107.8 litres

storage compartment 760mmW x 450mmD x 120mmH = 41 litres

electricity supply 240 volt, 50 Hz

electrical connection hard-wired single phase

maximum current 18.67 amp

HOB 43.3 mj/hour maximum over five burners

supplied • three heavy-duty cast-iron trivets for full gas

hob cover

• 60mmH x 898mmW splashguard for rear of

hob, optional fitment

• baking/grill tray

• two chromed-wire shelves

• one teflon biscuit tray

• 4 x telescopic legs

gas connection ½” BSP gas inlet connection

½” BSP 1.0 kPa natural gas, regulator supplied

adapt for ULPG — test point supplied

element roof floor rear wall rear wall

fan (2)

cooling

fan light (2) maximum

wattage current ampinner outer

wattage 1600 1200 1800 1500x2 25x2 20 15x2

static grill - - - - 2850 11.88

fan grill - - - - - 2900 12.09

convection - - - - 3050 12.71

fan forced - - - - 3080 12.84

bakers function 700 700 - - - - 4480 18.67





NB: drawings are not to scale — they are to be used as a guide only.

min 80

max 140

785
