Snap on orporated CTBTS861 BLUETOOTH SPEAKER User Manual
Snap-on Incorporated BLUETOOTH SPEAKER
User Manual
Discharging indicator:
Functional Description:
■ IP54 resistant to water and dust infiltration.
■ Premium High- Fi Sound
■ Bluetooth® 5.0
■ Harmonic Distortion 0.25%
■ Design for Mechanic
■ USB Output
■ Work with Snap-on CTB8172BK battery pack
■ Battery indicator:
Discharging:
■ CTB8172BK - Battery pack（Not included）
Output Power: 10W
Frequency Response: 100Hz ~ 15KHz
Power Supply: CTB8172BK battery pack
Bluetooth® working distance: More than 10M
Indicator
Volume Down
Product Description:
Specifications:
CTBTS861R CTBTS861G CTBTS861O CTBTS861HV
14.4V Wireless Bluetooth
® Speaker
Made in China
Replacement Parts:
Previous Play / Pause Next Power / Pair
Volume Up
USB output
Made in China
Snap-on and wrench "S"
are trademarks of Snap-on Incorporated.
The Bluetooth® word mark and logos are
registered trademarks owned by Bluetooth SIG, Inc.
©2018 Snap-on Incorporated.
Printed in China
Snap-on, 2801 80th St., Kenosha, WI 53143
www.snapon.com
Operations:
( I ) Long press the Power/Bluetooth® button for 3 seconds, then the speaker is ON or OFF.
( II ) Short press the Power/Bluetooth® button , disconnect current pair, and go into Bluetooth® search mode.
( III ) Please press power button , then USB output can work.
( IV ) Next, Previous, Play / Pause
( V ) Press to adjust the volume, there is a prompt tone when the volume achieves its maximum.
( VI) If there is no work for 15 minutes, the speaker will be automatically shut down.
WARNING: Any Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures.
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator& your body.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
The product does not have the full features of BT 5.0. No BLE.
■ 1 year warranty covering defects in material and workmanship
■ For service, please send to the appropriate repair center below
Eastern Repair Center (USA)
6320 Flank Dr.
Warrant
y
/Service:
Made in China
Snap-on and wrench "S"
are trademarks of Snap-on Incorporated.
The Bluetooth® word mark and logos are
registered trademarks owned by Bluetooth SIG, Inc.
©2018 Snap-on Incorporated.
Printed in China
Snap-on, 2801 80th St., Kenosha, WI 53143
www.snapon.com
Harrisburg, PA 17112
USA
Toll Free # - USA only:
(800) 848-5067
Telephone: (717) 652-7914
Fax: (717) 652-7123
Northern Repair Center (USA)
3011 E. RT 176, Dock 8
Crystal Lake, IL 60014
USA
Toll Free # - USA only:
(877) 777-4412
Telephone: (815) 479-6850
Fax: (815) 479-6857
Western Repair Center (USA)
3602 Challenger Way
Carson City, NV 89706-0753
USA
Toll Free # - USA only:
(888) 762-7972
Telephone: (775) 883-8585
Fax: (775) 883-8590
