Annex B.ii. Photograph: EUT Internal Photo
Cover Off - Top View 1 Cover Off - Top View 2
Battery - Top View Battery - Bottom View
Mainborad With Shielding - Front View Mainborad Without Shielding - Front View
Test Report 15070341-FCC-E
Page 21 of 27
Mainborad With Shielding - Rear View Mainborad Without Shielding - Rear View
LCD – Rear View LCD - Front View
WIFI/BT/BLE - Antenna View GSM/PCS/UMTS-FDD Antenna View
