Socket Mobile D600 Cordless Handheld Scanner User Manual
Socket Mobile, Inc. Cordless Handheld Scanner Users Manual
Users Manual
Bluetooth® wireless technology
NFC/RFID Reader & Writer
Model D600
www.socketmobile.com
DURASCANTM
D600 USERGUIDE
socketmobile.com
Battery Warning Statements 27
Bluetooth Connection Modes 11
Bluetooth Device Canada 24
Bluetooth Device Europe 25
Bluetooth Device JAPAN 26
Bluetooth Device United States 23
Bluetooth ReConnection 13
Bluetooth Unpairing 12
Configuration Cards 31
Helpful Resources 20
Limited Warranty 30
Optional Charging Accessories 8
Package Contents 4
Power Adapter 7
Powering on/off 9
Product Information 5
Product Specifications 18
Regulatory Compliance 29
Safety and Handling Information 21
Scanning Tags 10
Status Indicators 14
TABLE OF CONTENTS
TABLE OF CONTENTS
©2017 Socket Mobile, Inc. All rights reserved. Socket, the Socket logo, and SocketScan
are registered trademarks or trademarks of Socket Mobile, Inc. The
Bluetooth word mark and logo are registered trademarks of the Bluetooth SIG, Inc.
USA, and any use by Socket Mobile, Inc. is under license. All other trademarks and
trade names contained herein may be those of their respective owners.
USB A to USB
Type-C Cable
Lanyard
DuraScan
D600
Thank you for choosing Socket Mobile!
Let’s get started!
PACKAGE CONTENTS
PRODUCT INFORMATION
5
The D600 has a protection rating of IP54 for dust and water protection. It is also
made with antimicrobial to help provide protection against bacteria.
*Also used to display the on-screen keyboard in Basic Mode (iOS only).
NFC Antenna
Product label
Lanyard Eyelet
Read Indicator Light
Trigger button
Power button*
Battery Light (Green/Yellow/Red)
Bluetooth Light (Blue)
Pins for
charging
cradle
Power Connector Stand Attachment
Attach the Lanyard (optional)
1. Detach the string loop of the tether from the lanyard.
2. Feed the string loop through the eyelet.
3. Pull the tether through the string loop.
4. Pull tight so the string loop is secure.
5. Reattach the string loop’s tether to the lanyard.
READER SETUP
6
The reader must be fully charged before rst use. Please allow 6 hours
uninterrupted charging for the initial battery charge.
Lift the rubber ap to access the power connector.
• Yellow Light = Charging
• Green Light = Fully charged
Important: Charging from a computer USB port is not reliable and
not recommended.
CHARGE THE BATTERY
Rubber Flap
To open
Power Adapter
7
Powering On:
Press and hold down the small
power button until the Battery
light turns on and the reader beeps
twice (low-high).
Powering Off/ Disconnecting:
Press and hold down the small
power button until the reader
beeps twice (high-low) and all
lights turn off.
The reader will power off
automatically if device is not con-
nected within 5 minutes. Reader
connected to a device will power
off within 2 hours if idle/inactive.
POWERING ON/OFF
Power button
9
Tag
Aim the read beam straight
across the entire tag.
Scanning Tags
1. Hold the reader within two inches of the card, tag or smart device
2. The card, tag, or smart device should be parallel to the D600 antenna
3. Press and hold the trigger button
By default, the reader will beep, vibrate, and the read indicator will
ash green to conrm a successful read.
READING TAGS
10
BLUETOOTH CONNECTION MODES
11
Note: This procedure will put the reader in discoverable mode.
Step 1: Unpairing the reader: Delete the Bluetooth Pairing
If the reader is paired with a device, unpair it before trying to
connect to a different device.
1. Power on the reader.
2. Press the trigger button then power button and hold both until you hear
3 beeps.
The reader will unpair and automatically power off. The next time you
power on the reader, it will be discoverable.
Step 2: Remove or forget the reader from the Bluetooth list on the
host device
Important: Both steps above must be done to complete
the unpairing.
12
BLUETOOTH UNPAIRING
Automatic Reconnections
Each time you power on the reader, it will automatically try to
connect to the last device it was connected to.
• Make sure the device is in range with Bluetooth turned on.
• Pressing the trigger button will initiate the attempts to connect.
• If using Application Mode, make sure the Reader-enabled
Application is launched or running.
• If a connection is made, the blue light will stop blinking and turn
solid.
• If a connection is not made after several attempts, the reader will
emit a long beep (and the blue light will turn off).
• Press the trigger button to re-initiate the connection process.
BLUETOOTH RECONNECTION
13
STATUS INDICATORS
Battery Charging
when plugged
into Power
Supply
LED Activity Meaning
Blinking Yellow Charging the battery
Solid Green Battery is 100% full
Battery Status
When not
connected to
power supply
LED Activity Meaning
Solid Green Battery capacity from 100%
to 25%
Solid Yellow Battery capacity from 25%
to 10%
Solid Red Warning - Battery capacity
below 10%
Blinking Red
Charge immediately!
The battery level is
critically low. Alternatively,
if battery capacity is
unknown battery status will
blink red until the power
is applied & reader is fully
charged.
14
STATUS INDICATORS (CONTINUED)
Bluetooth LED Activity Meaning
Bluetooth
Quick Blinking Blue
(2 blinks every
second)
Discoverable - waiting for a
host Bluetooth connection.
Slow Blinking Blue
(1 blink every second)
Attempting to connect to
a paired device. Searching
the last known Host.
Note: Will STOP attempting
after approx. 1 minute.
No Light - No Activity
Reader has attempted to
connect and failed. Press
trigger button to try again.
Solid Blue Reader is connected
Scan/Read LED Activity Meaning
Scan/Read
Solid Orange Reader is poling for an RFID
Blink Green Once Good Scan/Read
Blink Red Once Bad Scan/Read
Solid Red - for as long
as power button is
pressed
Power Button Pressed
Quick Blinking Green
(2 blinks every
second)
Reader is in bootloader
mode during rmware
upgrade.
15
STATUS INDICATORS (CONTINUED)
Beep Pattern Sound Meaning
Low-High Tone Power On
High-Low Tone Power Off
High-High Tone Power Supply detected and reader started
charging
1 Low Beep Reader has toggled on-screen keyboard or keyboard
toggle feature is enabled (iOS devices only)
1 Beep Reader connected to device and is ready to scan
tags
1 Beep Data successfully read
2 Beeps (same
tone)
Reader disconnected
1 Long Beep Reader gave up searching for a host
3 Beeps
(escalating tone)
Reader has been recongured (the conguration
card successfully)
3 Beeps (escalat-
ing tone followed
by long tone)
The conguration card did NOT work! (Verify if the
conguration card used is valid for your reader and
try again)
16
STATUS INDICATORS (CONTINUED)
Vibrate Meaning
Vibrate Data successfully read.
Command Tags are available on pages 43-46 to modify the LED,
beep, and vibrate settings.
If you are using a reader-enabled application, typically the applica-
tion provides settings for LED, beep, and vibrate settings.
Conguration Settings
Time after powering on Reader Bluetooth mode
0-5 minutes Discoverable and connectable
5 minutes If connection is not made, reader
powers off
2 hours If your reader is connected but not
used it will power off in 2 hours.
When trigger button is pressed the
timer is reset.
17
PRODUCT SPECIFICATIONS
Specications D600
Dimensions (L x W x H) 5.2” x 1.5” x 1.6” (132.2 x 37.1 x 40.1 mm)
Total Mass 3.8 oz (108 g)
Antimicrobial Antimicrobial additive in external surfaces
Battery 1400 mAh Lithium - Ion Battery
Charge Time 6 Hours
Battery Life -
Per Full Charge
Standby time: over 30 hours
Active Read Time: 70,000 reads within 9 hours
(based on 2 reads every 1 second) or 14,000
reads within 16 hours (calculation based on 1
read every 4 seconds)
Note: Battery life varies depending on
operating conditions.
Bluetooth Version Bluetooth Low Energy v4.2
Wireless Range 330ft (100 m) line of sight
Reader Type NFC/RFID (13.56 MHz)
HF RFID Tags
Supported:
ISO15693: ICode SL2, LRI512, my-d, Tag-It HF-I
Proprietary: ICode SL1, PicoTag (no anti-colli-
sion), Tag-It HF ISO/IEC 14443 A and B compliant
tags with all variants (Mifare, Sony FeliCA)
Compliant with EPC GEN 2 HF and ISO 18000-
3 mode 3 NFC: NFCIP-1, ISO/IEC 18092) in 2
modes: reader and peer-to-peer, initiator, passive
18
PRODUCT SPECIFICATIONS
19
Specications D600
Maximum RFID Read
Range:
0.4” - 2” (10 - 50 mm)
NFC/RFID front-end: NXP CLRC663 m,
Carrier frequency: 13.56 MHz (RFID HF, NFC)
Card/tag Read/Write
Speed:
264 kbps (ISO 15693), 1064kbps (ISO 14443,
212/424kbps (ISO 18092)
Antenna: Integrated, 28mm x 14mm, balanced
Systems/Battery
Charging Requirement USB Type 5V 1A
Ambient Light From 0 to 100 000 lux
From pitch black to direct sun light
Operating
Temperature
-4° to 122° F (-20° to 50° C)
Storage Temperature -40° to 158° F (-40° to 70° C)
Relative Humidity 95% at 140° F (60° C) (non-condensing), 4 days
Sealing IP54 (Ingress Protection rating for dust and
water) EN60529
Drop Specications Multiple 5 ft. drops to concrete
Tumble Specication 250 cycles at 1.64 ft. (0.5 m) (500 drops),
IEC60062-2-31
HELPFUL RESOURCES
Technical Support & Product Registration:
https://support.socketmobile.com
Phone: 800-279-1390 +1-510-933-3020 (worldwide)
Warranty Checker:
https://www.socketmobile.com/support/warranty-checker
Socket Mobile Developer Program:
Learn more at: http://www.socketmobile.com/developers
The User’s Guide (full installation and usage instructions) and Command
Tags (Advanced Reader Congurations) can be download at:
https://www.socketmobile.com/support/downloads
20
WARNING: Failure to follow these safety instructions could result in
re or other injury or damage to the tag readers or other property.
Carrying and Handling the DuraScan NFC/RFID Reader:
The Socket Mobile tag reader contains sensitive components. Do not disas-
semble, open, crush, bend, deform, puncture, shred, microwave, inciner-
ate, paint, or insert foreign objects into this unit.
Do not attempt to disassemble the product. Should your unit need
service, contact Socket Mobile technical support at
https://support.socketmobile.com/
Changes or modications of this product, not expressly approved by
Socket Mobile may void the user’s authority to use the equipment.
Do not charge the DuraScan tag reader using an AC adapter when operat-
ing the unit outdoors, or in the rain.
Operating Temperature - this product is designed for a maximum ambient
temperature of 50° degrees C or 122° degrees F.
Pacemaker Disclaimer: For now, we do not have specic information on
the effect(s) of vibration or Bluetooth devices on pacemakers.
Socket Mobile cannot provide any specic guidance.
Individuals who are concerned with using the tag reader should immedi-
ately turn the device off.
21
SAFETY AND HANDLING INFORMATION
FCC ID: LUBD600
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: To assure continued compliance, any changes or
modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
(Example - use only shielded interface cables when connecting to
computer or peripheral devices).
22
BLUETOOTH DEVICE UNITED STATES
FCC Radiation Exposure Statement
This equipment complies with FCC RF radiation exposure limits set forth
for an uncontrolled environment. This equipment should be installed and
operated with a minimum distance of 20 centimeters between the radia-
tor and your body. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesired operation
23
BLUETOOTH DEVICE UNITED STATES
IC ID: 2925A-D600
This device complies with Industry Canada license exempt RSS
standard(s). Operation is subject to the following two conditions: (1) this
device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation
of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux
deux conditions suivantes: (1) l’appareil ne doit pas produire de
brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
24
BLUETOOTH DEVICE CANADA
CE Marking & European Union Compliance
Products intended for sale within the European Union are marked with a
CE Mark, which indicates compliance to applicable Directives and Euro-
pean Normes (EN), as follows. Amendments to these Directives or ENs are
included: Normes (EN), as follows:
Applicable Directives:
• Bluetooth Products: R&TTE Directive 2014/53EW
• Low Voltage Directives: 2014/35/EU, and 2006/95/EC
• EMC Directive: 2004/108/EU
• Rotts Directive: 2011/65/EU
• WEEE Directive: 2012/19/EU
SAFETY: EN 60950-1: 2006/A11
:2009/A1
:2010/A12
:2011/A2:2013
BLUETOOTH DEVICE EUROPE
25
Telec Marking Compliance
Products intended for sale within the country of Japan are marked with a
Telec mark, which indicates compliance to applicable Radio Laws, Articles
and Amendments.
BLUETOOTH DEVICE JAPAN
26
R 211-161214
BATTERY WARNING STATEMENTS
This device contains a rechargeable Lithium-Ion battery.
Stop charging DuraScan tag readers if charging isn’t completed
within the normal specied time (approx. 6 hours).
Stop charging the battery if the DuraScan tag reader case becomes abnor-
mally hot, or shows signs of odor, discoloration, deformation, or abnormal
conditions is detected during use, charge, or storage.
Stop using the DuraScan tag reader if the enclosure is cracked, swollen or
shows any other signs of mis-use. Discontinue immediately and promptly
dispose of unit.
Your device contains a rechargeable Lithium-Ion battery which may
present a risk of re or chemical burn if mistreated. Do not charge or use
the unit in a car or similar place where the inside temperature may be
over 60 degrees C or 140 degrees F.
• Never throw the battery into a re, as that could cause the battery to
explode.
• Never short circuit the battery by bringing the terminals in contact
with another metal object. This could cause personal injury, or re,
and could also damage the battery.
• Never dispose of used batteries with other ordinary solid wastes.
Batteries contain toxic substances.
27
BATTERY WARNING STATEMENTS
• Dispose of used batteries in accordance with the prevailing
community regulations that apply to the disposal of batteries.
• Never expose this product or the battery to any liquids.
• Do not shock the battery by dropping it or throwing it.
If this unit shows any type of damage, such as bulging, swelling or
disgurement, discontinue use and promptly dispose.
Product Disposal
Your device should not be placed in municipal waste. Please check local
regulations for disposal of electronic products.
28
REGULATORY COMPLIANCE
CE MARKING AND EUROPEAN UNION COMPLIANCE
Testing for compliance to CE requirements was performed by an
independent laboratory. The unit under test was found compliant with all
the applicable Directives, 2004/108/EC and 2006/95/EC.
WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT
The WEEE directive places an obligation on all EU-based
manufacturers and importers to take-back electronic products at the end
of their useful life.
RoHS STATEMENT OF COMPLIANCE
This product is compliant to Directive 2011/95/EC.
NON-MODIFICATION STATEMENT
Changes or modications not expressly approved by
the party responsible for compliance.
29
WEEE
LIMITED WARRANTY
30
Socket Mobile Incorporated (Socket) warrants this product against
defects in material and workmanship, under normal use and service,
for one (1) year from the date of purchase. Product must be purchased
new from a Socket Authorized Distributor or Reseller. Used products and
products purchased through non-authorized channels are not eligible for
this warranty support.
Warranty benets are in addition to rights provided under local
consumer laws. You may be required to furnish proof of purchase details
when making a claim under this warranty.
Consumables such as batteries, removable cables, cases, straps,
and chargers: 90 day coverage only
For more warranty information, please visit:
https://www.socketmobile.com/support/downloads
Scan conguration card(s) to quickly congure the Reader.
31
CONFIGURATION CARDS
