Somfy Systems TELIS4 Telis Transmitter TELIS4 User Manual 2500014a

Somfy Systems Telis Transmitter TELIS4 2500014a

Contents

User Manual

DESCRIPTION
ORDERING INFORMATION
The Telis Transmitters (single or four channel) are hand-held radio transmitters compatible with
Somfy RTS Motors and external RTS receivers such as the Universal Receiver and MultiLink. Each
transmitter can operate any number of motors or receivers, while each motor or receiver will
memorize up to 12 transmitters. The four channel transmitter can be used for group and
individual control of window treatments.
MECHANICAL SPECIFICATIONS
3 3 3
Overall Dimensions: L: 4 / in. W: 1 / in. D: / in.
4 4 4
o o
Operating Temperature: 41 F to 104 F
Typical Range (Optimal Conditions): 65 ft.
ELECTRICAL SPECIFICATIONS
Power: 3V Lithium battery, Cr2430
Frequency: 433.42 Mhz
GENERAL OPERATING INSTRUCTIONS
NOTE: Please Consult RTS Motor or Receiver Instructions for Specific
Product Details.
1. Place the RTS Motor or Receiver in Programming Mode as described in the
Operating Instructions.
2. Press the programming button on the back of the Telis transmitter to program
it in the memory of the RTS Motor or Receiver.
3. Pressing the UP button will raise the window covering, while pressing the
DOWN button will lower it. To stop the window covering, simply press the
STOP button.
4. Pressing the Channel Selector button on the four channel transmitter will
switch between channels 1 through four and the group (or fifth) channel.
The corresponding LEDs will light to indicate the channel selected.
Description
Telis Pure Single Channel)
Telis4 Pure Transmitter (Four Channel)
Transmitter (
Part Number
1810632
1810633
Telis Soliris
Patio Transmitter
my
Channel
Selector
Programming
Button
UP
STOP
DOWN
FRONT BACK
TELIS TRANSMITTERS
Ref. No. 2500014a SOMFY SYSTEMS, INC. 10/07
C
SOMFY SYSTEMS, INC.
47 Commerce Drive
Cranbury, NJ 08512
SOMFY CANADA
6315 Shawson Drive, Unit #1
Mississauga, Ontario L5T1J2
SOMFY MEXICO S.A. De C.V.
Temazcal 19-B, La Loma
Tlalnepantla, Edo de Mex.
Mexico 54130
SOMFY SYSTEMS, INC. reserves the right to change,
update or improve this document without prior notice.
NOTE: This equipment has been tested and found to comply with the limits for a CLASS B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try and correct the interference by one or more of the following measures:
1. Reorient or relocate the receiving antenna
2. Increase the separation between the equipment and receiver
3. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
4. Consult the dealer or experienced radio/TV technician for help.
WARNING: Changes or modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment.
FCC INFORMATION
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.
Description
Telis Patio, Telis4 Patio
Telis Lounge, Telis4 Lounge
Telis Silver, Telis4 Silver
Part Number
1810643, 1810645
1810650, 1810652
1810639, 1810641
