Somfy Systems WRTSI mylink Remote Control 1811264 User Manual

Somfy Systems mylink Remote Control 1811264 Users Manual

Users Manual

3
myLink WiFi to Radio Technology Somfy Interface
Part #1811264
Overview:
Connections and Indicators:
The myLink WiFi to Radio Technology Somfy® interface is a WiFi to RTS bridge that can control up to 5 channels of
RTS motorized products using the Somfy myLink apps for iOS and Android devices. Through the app, users can send
immediate RTS commands, create Scenes (a group of motorized products working together) and Schedules (timed
events). Users may access their myLinks from anywhere with the apps’ remote access feature. Though the myLink is
a single-zone controller, multiple myLinks can be joined within the same system for multi-zone control. The myLink
can also serve as an IP to RTS bridge for 3rd party control systems.
2
Features Summary: What’s in the Box:Technical Specifications:
■myLink
■Quick Start Guide
■Control for up to 5 RTS channels per
myLink from iOS and Android devices
■Join multiple myLinks together for
multi-zone control
■Manually activate RTS products
■Automate window coverings with Scenes
and Schedules
■Supports Up/Down/My/Stop commands
and incremental control (tilt/brightness)
■Plug-and-play installation
■Multiple users
■Remote access
■110V AC; 50-60Hz
■Ultra Low Power Wi-Fi (802.11 b/g/n)
■4.11L x 2.23W x 1.52H in.
■Enclosure:
ABS
UL94V-0 ame rating
RoHS compliant
UL listed
■Radio Frequency:
RTS 433.32 MHz
WiFi: 2.4 GHz
■iOS Version: 6 and higher
■Android Version: Jelly Bean and higher
■Shipping Weight: 1lb
1
Allows device to be secured to outlet
Engages setup mode
Solid Red: setup mode and is ready to connect to LAN
Solid Green: connected to LAN
Blinking Green: searching for/connecting to a LAN
Flashing Red: RTS signal transmission
Solid Amber (green & red): Factory reset mode
AC prongs
Hold Down Tab
Setup Button
Status LED
AC Prongs
1
2
3
4
ELEMENT FUNCTION
4
Dimensions:
BUS DISTRIBUTION
MOTOR
USER INTERFACE
Wiring Best Practice:
2.23”
4.11”
1.52”
D-0005 Copyright Somfy Systems, Inc. 9/2014
