Sonic Innovations AUITE312 Hearing Aid Module User Manual COMPANY LETTER HEAD

Sonic Innovations, Inc. Hearing Aid Module COMPANY LETTER HEAD

installation guide sonic

Sonic Radio Model - Quick Installation Guide
Radio Model Name:
Aurora ITE
1
The Aurora ITE radio model contains a radio transceiver running at 3.84 MHz and a transceiver running at 2400MHz-2483MHz implemented on a
single hardware platform.
The 3.84 MHz radio is a low power, short range, inductive radio transceiver working at a single channel at 3.84 MHz using MSK modulation with
320 kbit/s data rate and connected to a small coil antenna.
The radio model is implemented in an engine module mounted on the main PCB with connections to the antennas, the microphones, the speaker
and the battery terminals. The radio model can be seen in in the picture below:
Main PCB
Battery chamber
3,84 MHz coil antenna
Microphone
Microphone
2,4 GHz Antenna
Sonic Radio Model - Quick Installation Guide
Radio Model Name:
Aurora ITE
2
The Aurora ITE radio model requires only a single cell battery (size 13 or size 312) to be attached and a customized plastic shell, holding
everything together, in order to be operational as a fully functional hearing aid.
An example is shown here:
Battery chamber
Microphone
Speaker
Microphone
Main PCB
Coil antenna
2,4 GHz Antenna
Sonic Radio Model - Quick Installation Guide
Radio Model Name:
Aurora ITE
3
The Aurora ITE radio model is intended to be installed in Sonic wireless ITE hearing aid devices (In-The-Ear) styles.
4
Sonic Radio Model - Regulatory Label Information for USA & Canada
The following information will be part of the User Manual for the final product:
Radio Model Name: Aurora ITE 13 / Aurora ITE 312
If size 13 battery is used:
Contains:
FCC ID:
ZTOAUITE13
IC:
9799A-AUITE13
If size 312 battery is used:
Contains:
FCC ID:
ZTOAUITE312
IC:
9799A-AUITE312
