Wireless Audio Transmitter for PC
AIR-PC10T
Operating Instructions
WARNING
The available scientific evidence does not show that any health problems
are associated with using low power wireless devices. There is no proof,
however, that these low power wireless devices are absolutely safe. Low
power wireless devices emit low levels of radio frequency energy (RF) in
the microwave range while being used. Whereas high levels of RF can
produce health effects (by heating tissue), exposure to low-level RF that
does not produce heating effects causes no known adverse health effects.
Many studies of low-level RF exposures have not found any biological
effects. Some studies have suggested that some biological effects might
occur, but such findings have not been confirmed by additional research.
This equipment has been tested and found to comply with FCC radiation
exposure limits set forth for an uncontrolled equipment and meets the
FCC radio frequency (RF) Exposure Guidelines in Supplement C to
OET65.
This equipment must not be co-located or operated in conjunction with
any other antenna or transmitter.
NOTE:
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
CAUTION
You are cautioned that any changes or modifications not expressly
approved in this manual could void your authority to operate this
equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.
When you use the AIR-PC10T connected to a notebook PC with the
wireless function (wireless LAN, etc.), switch off the wireless function, or
place the AIR-PC10T with supplied cradle attached more than 20cm (7 7/8
feet) away from your computer.
“S-AIR” and its logo are trademarks of Sony Corporation.
“S-AIR Cast” is a trademark of Sony Corporation.
SonicStage is a trademark of Sony Corporation.
Microsoft, Windows, Windows Vista and Windows Media are
trademarks or registered trademarks of Microsoft Corporation in the
United States and/or other countries.
iTunes is a registered trademark of Apple Inc.
Apple, Macintosh and Mac OS are trademarks of Apple Inc., registered
in the U.S. and other countries.
All other trademarks and registered trademarks are of their respective
holders. In this manual, TM and marks are not specified.
About the S-AIR
AIR-PC10T is compatible with the Sony’s S-AIR products, which allows
transmission of sound between S-AIR products wirelessly.
S-AIR (Sony Audio Interactive Radio frequency)
Recent times have seen the rapid spread of DVD media, Digital
Broadcasting, and other high-quality media.
To ensure that the subtle nuances of these high-quality media are
transmitted with no deterioration, Sony has developed a technology
called “S-AIR” for the radio transmission of digital audio signals with
no compression, and has incorporated this technology into the
AIR-PC10T.
This technology transfers digital audio signals with no compression
using the 2.4 GHz band range of ISM band (Industrial, Scientific, and
Medical band), such as wireless LANs and Bluetooth applications.
About S-AIR products
There are two types of S-AIR product.
S-AIR main unit (this unit): This is for transmitting sound.
S-AIR sub unit: This is for receiving sound (speaker, music receiver,
etc.).
By connecting the AIR-PC10T to a USB port of your computer, the
AIR-PC10T can transmit music stored on your computer to an S-AIR sub
unit for playback.
Furthermore, if you install the supplied application software S-AIR Cast
on your computer and select Remote Mode or Advanced Remote Mode,
you can also control the contents on an S-AIR sub unit. For example, you
can install S-AIR sub units, one in the study room and the other in the
bedroom, and then install your computer with the AIR-PC10T connected
in the living room. You can then listen to music from the computer by
controlling the S-AIR sub unit.
AIR-PC10T
S-AIR sub unit
(music receiver, etc.)
Computer
Supplied
CD-ROM
S-AIR sub unit
(speaker, etc.)
Establishing sound transmission between the AIR-PC10T
and the S-AIR sub unit (ID setting)
Simply by matching the ID of the AIR-PC10T and the S-AIR sub unit, you
can establish sound transmission.
Identifying the AIR-PC10T with a specific S-AIR sub unit
(Pairing operation)
It is easy to set the same ID for the AIR-PC10T and the S-AIR sub unit to
establish sound transmission.
However, neighbors may also receive your systems sound if IDs are the
same, or you may receive sound from your neighbors. To prevent this, you
can identify the AIR-PC10T with a specific S-AIR sub unit by performing
the pairing operation. To perform the pairing operation, you need to install
the supplied S-AIR Cast software. For details, refer to the S-AIR Cast
installation instructions.
About AIR-PC10T manual
AIR-PC10T contains the following manuals. Refer to them as required by
the operation.
Window screen illustrations depicted in the manuals below may differ
from the actual screens.
AIR-PC10T Operating Instructions (this manual)
This manual explains the operations of the AIR-PC10T.
S-AIR Cast Installation Instructions
This PDF manual, which is copied to your computer when the S-AIR Cast
software is installed, explains how to install and set up the supplied S-AIR
Cast software on your computer.
S-AIR Cast Help
This help manual can be used only after the S-AIR Cast software is
installed.
It explains the operations of the S-AIR Cast software included on the same
CD-ROM.
Index to parts
Wireless audio transmitter
AIR-PC10T
S-AIR indicator
PAIRING indicator
Cover
Cradle
USB plug
Note
This cradle is for the AIR-PC10T. Do not use it for other USB devices.
About indicators on the wireless audio transmitter
Indicator Lights up Status
S-AIR
Off Connection with S-AIR sub unit not available.
Amber Waiting for connection with S-AIR sub unit.
Green Connected with one or more S-AIR sub unit.
PAIRING
Off Pairing is off. (Only S-AIR ID setting is made.)
Yellow (flash) Pairing is in progress.
Yellow Pairing is on.
For details, refer to the S-AIR Cast Help.
Connecting the system
1 Connect the cradle to your computer.
2 Plug wireless audio transmitter to the cradle.
Before connecting, detach the cover from the wireless audio
transmitter.
1
2
Tip
You can connect the wireless transmitter directly to your computer without using
the cradle, but as this connection may be easily affected by the environment, we
recommend using the wireless transmitter with a cradle.
When the connection finishes, you can then listen to music contents on
the connected computer from the S-AIR sub unit. To listen to music,
check the following:
Connect an S-AIR Sub unit.
Set the S-AIR ID of the connected S-AIR sub unit to “A.
Set the sound playback device property on your computer to
[AIR-PC10T]. To select the sound playback device property, click in the
following sequence:
Windows Vista (in Classic View):
[Start] – [Control Panel] – [Sound] – [Playback]
Windows XP (in Classic View):
[Start] – [Control Panel] – [Sound and Audio Devices] – [Audio]
At this time, you cannot perform playback operation on the S-AIR sub
unit. To control the playback operation on the S-AIR sub unit, install
S-AIR Cast. For details, see “Installing S-AIR Cast software.” For details
on S-AIR sub unit connection, refer to the operating instructions
supplied with the S-AIR sub unit.
Installing S-AIR Cast software
To operate contents of your computer using S-AIR sub unit, you must first
install the supplied S-AIR Cast software on your computer.
For details on the setting and operation, refer to the S-AIR Cast
Installation Instructions contained on the supplied CD-ROM.
What is S-AIR Cast?
With S-AIR Cast installed, you can control the media player on your
computer using buttons on the S-AIR sub unit (speaker, music receiver,
etc.). You can also compile or manage the contents on your computer, and
change the settings of the AIR-PC10T.
S-AIR Cast can be switched to the following 3 modes: Standard Mode,
Remote Mode, and Advanced Remote Mode. To use Remote Mode and
Advanced Remote Mode, S-AIR Cast needs to be installed on your
computer.
When you use the AIR-PC10T in Standard Mode, you do not need to
install S-AIR Cast, but you need to install S-AIR Cast when you change
S-AIR connection settings (S-AIR ID setting, pairing, etc.).
Mode Playback
method
S-AIR Cast
installation
Sound from sub
unit
Operation on
the sub unit
Standard
Application for
playback music
Not
required
System sound of
your computer
will be output as
well
Not available
Remote
iTunes or
Windows
Media Player
Required
System sound of
your computer
will be output as
well
Available
Advanced
Remote
Dedicated
module plays at
background
Required Playback music
sound only Available
For details on S-AIR Cast operation, refer to the S-AIR Cast Help.
For details on S-AIR sub unit operation, refer to the operating instructions
supplied with the S-AIR sub unit.
Overview of each mode procedure
Standard Mode
This mode is for using an S-AIR sub unit as a PC speaker. By connecting
AIR-PC10T to your computer, computer sound is output from the S-AIR
sub unit. Note that all system sounds of your computer (incoming
message alerts, alarm beeps, etc.) will also be output from the S-AIR sub
unit. In this mode, you can use this system without installing S-AIR Cast,
but installation is necessary if you want to change the S-AIR connection
settings.
1 Connect AIR-PC10T to your computer.
2 Turn on the S-AIR sub unit, and then set the AIR-PC10T and S-AIR
sub unit to the same S-AIR ID.
3 Start playing music on the media player of your computer.
Notes
In this mode, you cannot perform playback operation from the S-AIR sub unit.
“PC” is displayed on the S-AIR sub units front panel display. The connecting
S-AIR main units name (AIR-PC10T) may be displayed depending on your S-AIR
sub unit.
Tips
If you want to perform a pairing operation, install S-AIR Cast on your computer.
If AIR-PC10T cannot connect to the S-AIR sub unit, change the S-AIR ID. To
change the S-AIR ID, install S-AIR Cast on your computer.
Remote Mode
You can connect an S-AIR sub unit wirelessly to your computer as a
speaker and listen to music contents registered in iTunes or Windows
Media Player by operating the S-AIR sub unit. Note that all system sounds
of your computer (incoming message alerts, alarm beeps, etc.) will also be
output from the S-AIR sub unit. To use this mode, S-AIR Cast needs to be
installed on your computer.
1 Install S-AIR Cast on your computer.
2 Perform the S-AIR Cast settings on your computer in accordance
with the [S-AIR Cast Configuration] wizard.
Select Remote Mode and specify the media player to playback
(iTunes or Windows Media Player).
Connect AIR-PC10T to your computer.
Set the AIR-PC10T and S-AIR sub unit to the same S-AIR ID.
When the S-AIR connection between AIR-PC10T and the S-AIR
sub unit is established, “PC” appears on the S-AIR sub unit’s front
panel display.
3 Press (play)on the S-AIR sub unit.
AIR-PC10T and S-AIR sub unit are connected. Playback starts and the
playback sound is output from the S-AIR sub unit.
Notes
When (play) on the S-AIR Sub unit is pressed and iTunes is selected, iTunes
window is displayed on your computer, but if Windows Media Player is selected,
Windows Media Player window is not displayed.
If you operate iTunes on your computer, you may not be able to operate it on the
S-AIR sub unit. In this case, exit and restart iTunes.
Tips
Playback operation on the S-AIR sub unit may differ depending on your S-AIR
sub unit.
Playing status, contents information, this units name (AIR-PC10T), etc., are
displayed on the S-AIR sub units front panel display. Displayed items are different
depending on the S-AIR sub unit.
If you register a Podcast or radio station on the playlist, you can choose it from the
S-AIR sub unit.
For details on the operations of the S-AIR sub unit, refer to the S-AIR Cast
Installation Instructions.
Advanced Remote Mode
With S-AIR Cast installed, you can gather music files on your computer,
generate original channels, control the contents via the S-AIR sub unit
without hearing system sounds output from the S-AIR sub unit. So you
can enjoy music uninterrupted and choose your favorite song from the
S-AIR sub unit easily.
1 Install S-AIR Cast on your computer.
2 Perform the S-AIR Cast settings on your computer in accordance
with the [S-AIR Cast Configuration] wizard.
Select Advanced Remote Mode and perform the Advanced Remote
Mode settings.
Connect AIR-PC10T to your computer.
Set the AIR-PC10T and S-AIR sub unit to the same S-AIR ID.
When the S-AIR connection between AIR-PC10T and the S-AIR
sub unit is established, contents title is displayed on the S-AIR sub
units front panel display.
3 Press DISPLAY on the S-AIR sub unit to select the desired channel
group.
4 Press (play) on the S-AIR sub unit.
Playback starts.
5 Press S-AIR CH–/+ on the S-AIR sub unit to select the channel
you want to playback.
For example, when an album name is displayed on the S-AIR sub units
front display, you can change to a different album by pressing S-AIR
CH–/+.
Tips
Playback operation on the S-AIR sub unit may differ depending on your S-AIR
sub unit.
Playing status, contents information, this units name (AIR-PC10T), etc., are
displayed on the S-AIR sub units front panel display. Displayed items are different
depending on the S-AIR sub unit.
For details on the operations of the S-AIR sub unit, refer to the S-AIR Cast
Installation Instructions.
System Requirements
The following software and hardware are required to run S-AIR Cast.
Notes
S-AIR Cast will not run in any Mac OS.
English is the only language available for S-AIR Cast.
The following systems are not supported:
- Any 64 bit operating system.
- Personally assembled PCs or operating systems.
Operations are not guaranteed for all the recommended computer environments
mentioned below.
Operating systems
Windows Vista Home Basic (SP1 or without SP)
Windows Vista Home Premium (SP1 or without SP)
Windows Vista Ultimate (SP1 or without SP)
Windows Vista Business (SP1 or without SP)
Windows XP Home Edition (SP2, SP3)
Windows XP Professional (SP2, SP3)
Windows XP Media Center Edition 2004 (SP2, SP3)
Windows XP Media Center Edition 2005 (SP2, SP3)
Hardware environments
CPU: Pentium 1GHz or higher, Celeron 1 GHz or higher, or better
equipment/CPU.
RAM: 512 MB or more.
In the case of high music content, operating speed may decrease.
For smooth operation, 2GHz or higher CPU is recommended.
Hard Disk Drive: 206MB or more (S-AIR Cast related module: 60MB /
Microsoft related module: 146MB)
CD-ROM or DVD drive (for software installation)
Display: Screen Resolution: 1,024 × 768 pixels (or higher), Colors:
65,536 colors (or higher)
Mouse
Keyboard
USB port: USB 1.1 or 2.0 port
Sound card
Software: Internet Explore 6.0 or higher.
AIR-PC10T US. 4-134-954-11(1)
AIR-PC10T US. 4-134-954-11(1)
4 Click [Install S-AIR Cast] first, then click [Install Now].
Tip
If you click [About S-AIR Cast], then click [Read Document], the details of the
product are displayed. If you click [View Manual], then click [Read Manual],
S-AIR Cast Installation Instructions is displayed.
5 Installation starts.
If you click [Cancel], installation is canceled.
6 After the installation is completed, click [Restart Now] to restart
your computer.
After restarting your computer, the [S-AIR Cast Configuration] wizard
appears automatically. For details, refer to “Setting S-AIR Cast” in the
Installation Instructions.
To uninstall S-AIR Cast
If you want to remove the S-AIR Cast from your computer, follow the
uninstall procedure described below.
1 Close S-AIR Cast on the task tray.
Right-click the task tray icon, then click [Exit]. The task tray icon
disappears.
2 Uninstall S-AIR Cast in the following sequence.
Windows Vista (in Classic View):
Click [Start] - [Control Panel]- [Programs and Features], in that order.
Windows XP (in Classic View):
Click [Start] - [Control Panel] - [Add or Remove Programs], in that
order.
3 Select [S-AIR Cast], and click [Uninstall] (Windows Vista) or
[Change/Remove] (Windows XP).
Note
For Windows Vista, the [User Account Control] (UAC) window appears. Click
[Allow]. If you click [Cancel], you will not be able to uninstall.
4 Restart the computer.
Precautions
As the S-AIR function transmits sound by radio waves, sound may skip
when radio waves are obstructed. This is a characteristic of radio waves
and is not malfunction.
As the S-AIR function transmits sound by radio waves, equipment that
generates electromagnetic energy, such as a microwave oven, may
interfere with sound transmission.
As the S-AIR function uses the radio waves that share the same
frequency as other wireless systems, such as wireless LAN or Bluetooth,
interference or poor transmission may result. In this case, take the
following steps:
- Do not install the system near other wireless systems.
- Do not use the system and the other wireless systems at the same
time.
The transmission distance differs depending on the usage environment.
Find a location where transmission between the AIR-PC10T and the
S-AIR sub unit is most effective, and install the AIR-PC10T and the
S-AIR sub unit there.
Troubleshooting
1 Make sure the power of your computer and S-AIR sub unit is on.
2 Find your problem in the checklist below, and take the indicated
corrective action.
If the issue persists, contact your nearest Sony dealer.
When bringing the AIR-PC10T in for repairs, be sure to bring in the
entire system (Wireless audio transmitter, cradle, and the S-AIR sub
unit).
This product is a system product, and the entire system is needed to
determine the location requiring repair.
Your computer does not recognize the AIR-PC10T as a
USB device.
Disconnect and reconnect the AIR-PC10T.
The S-AIR indicator does not light when connecting the
AIR-PC10T and the S-AIR sub unit.
Check that the power of your computer is on.
Check if your computer is in sleep mode, and if so, exit sleep mode.
Connect the unit directly to the USB port of your computer, without
using a hub.
If you use electronic equipment of 2.4 GHz frequency (wireless LAN,
Bluetooth, etc.), turn off this equipment, or place it as far as possible
from the AIR-PC10T.
User privileges
S-AIR Cast can be used only by users with administrator privileges.
S-AIR Cast does not support the Fast User Switching function.
You can connect one AIR-PC10T to a computer. You cannot connect
multiple AIR-PC10T to a computer at the same time.
You can use up to 10 S-AIR sub units with the AIR-PC10T.
Only one playable source can be output from the S-AIR sub unit at the
same time.
Media Player
To use Remote Mode or Advanced Remote Mode, media player needs to
be installed on your computer. The following media players are compliant
with S-AIR Cast:
Apple iTunes 8.0 (Remote Mode, Advanced Remote Mode)
Windows Media Player 10, 11 (Remote Mode, Advanced Remote Mode)
Media Manager 1.2 (Advanced Remote Mode)
SonicStage 4.3 (Advanced Remote Mode)
Format
The music file format that is compliant with S-AIR Cast is as follows:
MP3 (.mp3)
ATRAC (.oma) *
ATRAC DRM (.oma) *
AAC (.m4a)
AAC DRM (.m4p, .m4a) **
WMA (.wma)
WMA DRM (.wma) **
WAV (.wav)
* You cannot play back this format in Remote Mode.
** You cannot play back this format in Advanced Remote Mode.
Notes
Playback of Remote Mode is dependant on the controlled media player format.
Playback of Advanced Remote Mode conforms to the players specifications that
are installed on your computer.
To use WMA format in Advanced Remote Mode, Windows Media Player needs to
be installed on your computer.
Note that playback of the above music file formats may not be possible in some
cases.
Installing S-AIR Cast
Installation may take some time depending on the environment. A
progress bar is displayed while installation is underway. Wait until the
installation is finished.
To confirm the installation procedure and the S-AIR Cast settings, select
[View Manual] in Step 4.
1 Turn on your computer and log in as an administrator.
Wait for Windows to load.
2 Insert the supplied CD-ROM into the CD-ROM drive of your
computer.
(Windows Vista users only)
The [Auto Play] window appears.
Click [Run setup.exe] to install the program.
(Windows Vista users only)
The [User Account Control] (UAC) window appears.
Click [Continue]. If you click [Cancel], you will not be able to start the
installation.
The [S-AIR Cast Setup] wizard appears.
Exit all applications and click [Next].
Note
If the wizard does not open, double-click the [CD-ROM Setup.exe] icon.
3 Read the license agreement.
Check [I have read and accept the license terms.] and click [Next].
Tip
If you do not accept the license agreement, check [I do not accept the license
terms.] and click [Cancel]. The wizard will turn off.
Set RF change to OFF on the installed S-AIR Cast software. If the issue
persists after RF setting, change the S-AIR ID of the AIR-PC10T and
S-AIR sub unit. For details on RF change, refer to S-AIR Cast Help.
If another S-AIR main unit such as Sony’s wireless home theater system
using S-AIR is placed near the AIR-PC10T, turn off the power of that
S-AIR main unit, or place it as far as possible from the AIR-PC10T.
Check that the USB cable of the cradle is connected securely to the USB
port of your computer.
If the issue persists, the AIR-PC10T may be at fault. Contact your
nearest Sony dealer.
Connecting the AIR-PC10T and the S-AIR sub unit is not
possible.
Confirm the S-AIR IDs of the AIR-PC10T and the S-AIR sub unit.
Cancel pairing once, then try to pair again.
If you use electronic equipment of 2.4 GHz frequency (wireless LAN,
Bluetooth, etc.), turn off this equipment, or place it as far as possible
from the AIR-PC10T.
Set RF change to OFF on the installed S-AIR Cast software. If the issue
persists after RF setting, change the S-AIR ID of the AIR-PC10T and
S-AIR sub unit. For details on RF change, refer to S-AIR Cast Help.
The S-AIR sub unit is connected to another S-AIR main unit. Change
the S-AIR ID of the S-AIR sub unit to another one, and set the
AIR-PC10T’s ID to the same one as the S-AIR sub unit, or pair the
AIR-PC10T with the S-AIR sub unit you are using.
Check that the AIR-PC10T is not connected to anything other than the
computer on which you performed the S-AIR Cast settings.
Select Remote Mode or Advanced Remote Mode. When the S-AIR Cast
is installed on your computer, you can set S-AIR settings although
Standard Mode is selected.
The connected S-AIR sub unit is turned off. Make sure the power cord
is connected, then turn on the S-AIR sub unit.
If you use another S-AIR main unit, place it more than 8 m (26 1/4 feet)
away from the AIR-PC10T.
S-AIR settings (S-AIR ID, Pairing, RF CHANGE) are not
available.
To perform the S-AIR settings, the supplied software S-AIR Cast is
required. Install S-AIR Cast, and change S-AIR Cast settings. (For
details, refer to “Changing Settings” in the S-AIR Cast Installation
Instructions.)
When S-AIR connection settings are stored on your computer (S-AIR
Advanced settings), you cannot change S-AIR ID, Pairing, and RF
change settings. In this case, clear them from your computer. (For
details, refer to “Changing Settings” in the S-AIR Cast Installation
Instructions).
There is noise, no sound, or the sound skips.
Select the sound playback device property on your computer to
[AIR-PC10T] (Standard Mode, Remote Mode), or anything except
[AIR-PC10T] (Advanced Remote Mode). Click in the following
sequence:
Windows Vista (in Classic View):
[Start] – [Control Panel] – [Sound] – [Playback]
Windows XP (in Classic View):
[Start] – [Control Panel] – [Sound and Audio Device] – [Audio]
If you use electronic equipment of 2.4 GHz frequency (wireless LAN,
Bluetooth, etc.), turn off this equipment, or place it as far as possible
from the AIR-PC10T.
Set RF change to OFF on the installed S-AIR Cast software. If the issue
persists after RF setting, change the S-AIR ID of the AIR-PC10T and
S-AIR sub unit. For details on RF change, refer to S-AIR Cast Help.
Adjust the volume of your computer.
If you use another S-AIR main unit, place it more than 8 m (26 1/4 feet)
away from the AIR-PC10T.
Place the AIR-PC10T and the S-AIR sub unit closer together.
Stop using any equipment that generates electromagnetic waves such as
a microwave oven.
When in Remote Mode, remove the unplayable contents from media
players (iTunes or Windows Media Player) you are using, then close the
media player and restart.
Turn off your computer and S-AIR sub unit, and then turn them on
again.
Check that headphones are not connected to the headphone jack on
your computer.
Do not place a mobile phone near the AIR-PC10T or the S-AIR sub
unit, as this may result in noise.
The S-AIR indicator on the AIR-PC10T lights up in amber.
No S-AIR sub unit is connected to the AIR-PC10T. When one or more
S-AIR sub units are connected, the indicator lights up in green.
The PAIRING indicator on the AIR-PC10T lights up in
yellow.
The AIR-PC10T is pairing with an S-AIR sub unit. If pairing is
canceled, the indicator turns off.
Buttons on the S-AIR sub unit are not functional.
S-AIR Cast does not boot, or Standard Mode is selected. Boot S-AIR
Cast, then select Remote Mode or Advanced Remote Mode.
If you use electronic equipment of 2.4 GHz frequency (wireless LAN,
Bluetooth, etc.), turn off this equipment, or place it as far as possible
from the AIR-PC10T.
Set RF change to OFF on the installed S-AIR Cast software. If the issue
persists after RF setting, change the S-AIR ID of the AIR-PC10T and
S-AIR sub unit. For details on RF change, refer to S-AIR Cast Help.
The Bluetooth mouse does not move during S-AIR
connection.
Connect the AIR-PC10T to your computer using a cradle.
Place the mouse and the AIR-PC10T as far apart as possible.
Specifications
Output: 40 mW
Frequency band: 2.4000 GHz - 2.4835 GHz
Modulation method: DSSS
Power requirements: DC 5.0 V, 500 mA
Dimensions (w/h/d): 26 × 13.2 × 87 mm (1 1/32 × 1/2 × 3 7/16 in)
Mass: 21.5 g (0.758 oz)
Supplied accessories:
Cradle (AIR-PCST1) (1)
Cap for the USB connector (1)
Application software S-AIR Cast (CD-ROM) (1)
Operating Instructions (1)
Design and specifications are subject to change without notice.
To stabilize S-AIR reception
To use S-AIR products (AIR-PC10T and the S-AIR sub unit)
Before using S-AIR products, have the following ready.
Confirm the wireless transceiver on the S-AIR sub unit (if
applicable) is inserted correctly.
Insert the wireless transceiver firmly to the depth into the slot of the
S-AIR sub unit (if applicable).
Insert firmly
Confirm that the S-AIR IDs of the AIR-PC10T and the S-AIR sub
unit are the same.
The default setting of the S-AIR IDs of the AIR-PC10T and the S-AIR
sub unit is “A.” You can set the S-AIR ID using the supplied S-AIR Cast
software. There are several ways to set the S-AIR ID of the S-AIR sub
unit (using the S-AIR ID switch, setup menu, etc.)
For details, refer to the operating instructions of each S-AIR product.
Same S-AIR ID
About environments where S-AIR products (AIR-PC10T and
the S-AIR sub unit) are used
S-AIR products use a radio frequency of 2.4 GHz. Certain electronic
equipment or other factors may cause lost connection or instability in
S-AIR reception.
Electronic equipment influence
The following may cause interference or cross talk.
- Cellular phones, cordless phones
- Wireless LAN, personal computers
- Game machines using radio signals
- Microwave ovens
Other factors
The following may cause poor reception.
- Materials or structures, such as walls and floors
- The location where an S-AIR product is placed
When you use the AIR-PC10T connected to a notebook PC with the
wireless function (wireless LAN, etc.), switch off the wireless function, or
place the AIR-PC10T with supplied cradle attached more than 20cm (7 7/8
feet) away from your computer.
When using S-AIR sub units, place them as far as possible from the above
electronic equipment, or place where S-AIR reception is stable.
When S-AIR reception is poor
Check the following.
Keep cords that are connected to the S-AIR product (power supply cord,
power cord, antennas or other cords) away from the wireless transceiver
and slot.
Keep as much space as possible around S-AIR products.
Avoid placing S-AIR products on top of, or directly below, other electronic
equipment.
Avoid placing S-AIR products in a closed rack, metal rack, or under a
table.
Adjust the location (height, orientation, and place in the room) of S-AIR
products until reception is the most stable.
Place so that the AIR-PC10T and the S-AIR sub unit are closer.
Place so that S-AIR products are separated from other wireless devices.
Place so that S-AIR products are separated from metal doors or tables.
If you cannot improve S-AIR reception, change the “RF change” setting.
For details, refer to the operating instructions of each S-AIR product.

Navigation menu
