User Manual
Since this module is not sold to general end users directly, there is no user manual of
module.
For the details about this module, please refer to the specification sheet of module.
This module should be installed in the host device according to the interface specification
(installation procedure).
The following information must be indicated on the host device of this module;
[for FCC]
Contains Transmitter Module FCC ID: AK8BNSY25
or
Contains FC C ID: AK8BNSY25
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
*If it is difficult to describe this statement on the host product due to the size, please describe
in the User's manual.
The following statements must be described on the user manual of the host device of this
module;
[for FCC]
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
—Consult the dealer or an experienced radio/TV technician for help.
FCC CAUTION
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
For 2.4GHz band
This transmitter must not be co-located or operated in conjunction with any other antenna
or transmitter.
For 5GHz band
5.47-5.725GHz band is restricted to indoor operations only.
Compliance with FCC requirement 15.407(c)
Data transmission is always initiated by software, which is the passed down through the
MAC, through the digital and analog baseband, and finally to the RF chip. Several special
packets are initiated by the MAC. These are the only ways the digital baseband portion will
turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the
transmitter will be on only while one of the aforementioned packets is being transmitted. In
other words, this device automatically discontinue transmission in case of either absence of
information to transmit or operational failure.
Frequency Tolerance: +/- 12 ppm
For Human Exposure
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment and meets the FCC radio frequency (RF) Exposure Guidelines. This
equipment should be installed and operated keeping the radiator at least 20cm or more
away from person’s body.
