User Manual(DECH-3000A, DECH-S3000A)

DECH-2500A / DECH-S2500A 4-258-960-13 (1)
Debugging Station (for PlayStation®3)
Instruction Manual / 使⽤說明書
DECH-3000A / DECH-S3000A 4-000-000-00(1)
EN
WARNINGS
• To avoid electrical shock, do not open the cabinet. Refer servicing to qualified
personnel only.
• CAUTION
– Use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
– The use of optical instruments with this product will increase eye hazard.
• This appliance is classifi ed as a CLASS 1 LASER product under IEC60825-1:2007.
CLASS 1 LASER PRODUCT
LASER KLASE 1
LUOKAN 1 LASER LAITE
KLASS 1 LASERAPPARAT
Photosensitivity/Epilepsy/Seizures
A very small percentage of individuals may experience epileptic seizures or blackouts
when exposed to certain light patterns or fl ashing lights. Exposure to certain patterns or
backgrounds on a television screen or when playing video games may trigger epileptic
seizures or blackouts in these individuals. These conditions may trigger previously
undetected epileptic symptoms or seizures in persons who have no history of prior
seizures or epilepsy. If you, or anyone in your family, has an epileptic condition or has
had seizures of any kind, consult your physician before playing.
IMMEDIATELY DISCONTINUE use and consult your physician before resuming
gameplay if you or your child experience any of the following health problems or
symptoms:
• dizziness,
• altered vision,
• eye or muscle twitches,
• loss of awareness,
• disorientation,
• seizures, or
• any involuntary movement or convulsion.
RESUME GAMEPLAY ONLY ON APPROVAL OF YOUR PHYSICIAN.
Use and handling of video games to reduce the likelihood of a seizure
• Use in a well-lit area and keep as far away as possible from the television screen.
• Avoid large screen televisions. Use the smallest television screen available.
• Avoid prolonged use of the system. Take a 15-minute break during each hour of play.
• Avoid playing when you are tired or need sleep.
Radio waves
Radio waves may affect electronic equipment or medical devices (for example,
pacemakers), which may cause malfunctions and possible injuries.
• If you use a pacemaker or other medical device, consult your physician or the
manufacturer of your medical device before using the wireless networking feature.
• Do not use the wireless networking feature in the following locations:
– Areas where wireless network use is prohibited, such as in hospitals. Abide by
medical institution regulations when using the system on their premises.
– Areas near fire alarms, automatic doors and other types of automated equipment.
3D images
Some people may experience discomfort (such as eye strain, eye fatigue, or nausea)
while watching 3D video images or playing stereoscopic 3D games on 3D televisions. If
you experience such discomfort you should immediately discontinue use of your
television until the discomfort subsides.
SCE recommends that all viewers take regular breaks while watching 3D video, or
playing stereoscopic 3D games. The length and frequency of necessary breaks may
vary from person to person – please take breaks that are long enough to allow any
feelings of discomfort to subside. If symptoms persist, consult your physician.
When using any 3D enabled device with your PlayStation®3 system you should read the
instruction manual for that device.
For customers in the U.S.A. and Canada
This equipment complies with FCC/IC radiation exposure limits set forth for uncontrolled
environment and meets the FCC radio frequency (RF) Exposure Guidelines in
Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules.
This equipment should be installed and operated with at least 20 cm (8 in) and more
between the radiator and person’s body (excluding extremities: hands, wrists, feet and
ankles).
This transmitter must not be co-located or operated in conjunction with any other
antenna or transmitter.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
You are cautioned that any changes or modifi cations not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
If you have questions about this product, visit http://www.scedev.net, email Developer
Support at dev_tools@playstation.sony.com or write to:
Sony Computer Entertainment America
Developer Support
919 East Hillsdale Boulevard
Foster City, CA 94404-2175 USA
Declaration of Conformity
Trade Name : SONY
Model No. : DECH-3000A, DECH-S3000A
Responsible Party : Sony Electronics Inc.
Address : 16530 Via Esprillo
San Diego, CA 92127 U.S.A.
Telephone No. : 858-942-2230
This device complies with Part 15 of the FCC Rules and RSS-Gen of IC Rules.
Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation of this device.
Pour les utilisateurs aux États-Unis et au Canada
Cet équipement est conforme aux limites d'exposition aux radiofréquences IC établies
pour un environnement non contrôlé et se conforme aux exigences de conformité pour
l'exposition aux RF IC, dans le supplément C à OET65 et CNR- 102. Cet équipement
doit être installé et opéré à au moins 20 cm (8 po.) d'écart entre le radiateur et la
personne physique (extrémités du corps non prises en compte : mains, poignets, pieds
et chevilles).
Ce transmetteur ne doit pas être utilisé conjointement ou placé avec tout autre
transmetteur ou antenne.
Remarque
Cette unité a été testée et il a été déterminé qu’elle se conforme aux normes stipulées
par l’article 15 des règlements de la FCC pour un appareil numérique de catégorie B.
Ces normes sont établies afi n d’offrir une protection raisonnable contre toute possibilité
de brouillage préjudiciable dans une installation résidentielle. Cette unité produit, utilise
et peut émettre une énergie radioélectrique, et si elle n’est pas installée et utilisée
conformément aux instructions, pourrait causer un brouillage préjudiciable à la
radiocommunication. Il est toutefois impossible de garantir qu’il n’y aura pas de
brouillage préjudiciable dans une installation donnée. Si cette unité cause un brouillage
préjudiciable à la réception radio ou télévisuelle, ce qui peut être déterminé en activant
ou désactivant l’appareil, l’utilisateur est encouragé à tenter de corriger le brouillage en
prenant l’une ou plusieurs des mesures proposées suivantes :
– Réorienter ou déplacer l’antenne de réception.
– Éloigner l’unité du récepteur.
– Connecter l’appareil à une prise sur un autre circuit que celui auquel le récepteur
est connecté.
– Demander de l’aide au détaillant ou à un technicien radio/télévision spécialisé.
Aucun changement ou modifi cation n’est permis sans avoir été approuvé par les parties
responsables des règlementations qui est en droit de refuser l’autorisation de l’utilisateur
à utiliser ce produit.
Pour toute question concernant ce produit, visitez http://www.scedev.net, envoyez un
courriel au service d’Assistance aux développeurs à l’adresse
dev_tools@playstation.sony.com ou envoyez un courrier à :
Sony Computer Entertainment America
Developer Support
919 East Hillsdale Boulevard
Foster City, CA 94404-2175 USA
Déclaration de Conformité
Nom commercial : SONY
N° de modèle : DECH-3000A, DECH-S3000A
Partie responsable : Sony Electronics Inc.
Adresse : 16530 Via Esprillo
San Diego, CA 92127 U.S.A.
N° de téléphone : 858-942-2230
Cet appareil est conforme aux stipulations de l’article 15 des règlements de la FCC
et CNR-Gen des règles IC. Son opération est sous réserve des deux conditions
suivantes : (1) cet appareil ne peut pas causer de brouillage préjudiciable et (2) cet
appareil doit accepter le brouillage préjudiciable reçu, y compris un brouillage qui
pourrait causer son fonctionnement irrégulier.
For customers in the U.S.A.
The lithium coin memory back-up battery inside this product contains Perchlorate.
The following statement is required by the State of California, USA:
Perchlorate Material – special handling may apply. See
http://www.dtsc.ca.gov/hazardouswaste/perchlorate
For customers in Europe
This equipment has been tested and found to comply with the limits set out in the
R&TTE Directive using a connection cable shorter than 3 metres. Do not use cables
longer than 3 metres.
Where you see this symbol on any of our electrical products/packaging in Europe, it
means that at end of life the product/battery must be disposed of in accordance with
any applicable laws or requirements for the separate disposal of electrical equipment/
batteries. This symbol may be used on batteries in combination with additional chemical
symbols. The chemical symbols for mercury (Hg) or lead (Pb) will appear if the battery
contains more than 0.0005% mercury or more than 0.004% lead. Accordingly at end of
life we will arrange for separate disposal of our loan equipment including without
limitation development kits which remain at all times the property of Sony Computer
Entertainment Europe. If you would like assistance with the disposal of any other
electrical products which we have supplied to you for business use, we can arrange a
take-back service on request. Please check https://www.tpr.scee.net for more
information.
This product contains a battery which is permanently built-in for safety, performance or
data integrity reasons. The battery should not need to be replaced during the lifetime of
the product and should only be removed by skilled service personnel. To ensure the
correct waste treatment of the battery, please dispose of this product as electrical
waste.
The manufacturer of this product is Sony Computer Entertainment Inc., 1-7-1 Konan,
Minato-ku, Tokyo, 108-0075, Japan.
The Authorised Representative for EMC and product safety is Sony Deutschland
GmbH, Hedelfi nger Strasse 61, 70327 Stuttgart, Germany.
Distributed in Europe by Sony Computer Entertainment Europe Ltd, 10 Great
Marlborough Street, London, W1F 7LP, United Kingdom.
For customers in the United Kingdom
A molded plug complying with BS1363 is fi tted to this equipment for your safety and
convenience. Should the fuse in the plug supplied need to be replaced, a 5AMP fuse
approved by ASTA or BSI to BS1362, (i.e., marked with or ) must be used. If the
plug supplied with this equipment has a detachable fuse cover, be sure to attach the
fuse cover after you change the fuse. Never use the plug without the fuse cover. If you
should lose the fuse cover, please contact your nearest Sony service station.
Precautions
Safety
This product has been designed with the highest concern for safety. However, any
electrical device, if used improperly, has the potential for causing fi re, electrical shock or
personal injury. To help ensure accident-free operation, follow these guidelines:
• Observe all warnings, precautions and instructions.
• Regularly inspect the AC power cord for damage.
• Stop use, unplug the AC power cord from the electrical outlet and disconnect any
other cables immediately if the device functions in an abnormal manner, produces
unusual sounds or smells or becomes too hot to touch.
Use and handling
• Do not connect cables other than a USB cable while the AC power cord is plugged
into the electrical outlet.
• Do not touch the system or connected cables or accessories during an electrical
storm.
• Do not use the system or accessories near water.
• Do not allow liquid, small particles or other foreign objects to get into the system or
accessories.
• Do not touch the connectors of the system or accessories.
• Do not expose the system or accessories to dust, smoke or steam. Also, do not place
the system in an area subject to excessive dust or cigarette smoke. Dust build-up or
cigarette smoke residue on the internal components (such as the lens) may cause
the system to malfunction.
• Do not expose the system or accessories to high temperatures, high humidity or
direct sunlight.
• Do not place the system or accessories on surfaces that are unstable, tilted or
subject to vibration.
• Do not set the system other than in the vertical or horizontal position. When setting
the system in the vertical position, use the vertical stand (sold separately) for this
model of the system. Also, do not change the position while the system is turned on.
• Be careful when carrying the system. If you do not have a good grip, the system may
drop causing potential damage or injury.
• Do not move or change the position of the system with a disc inserted. The vibration
may result in scratching of the disc or the system.
• Do not stand on or put objects on the system, and do not stack the system with other
devices.
• Do not place the system and connected accessories on the fl oor or in a place where
they may cause someone to trip or stumble.
• Do not allow bodily contact with the system or air from the system vents for an
extended period of time while in use. Extended contact under these conditions may
cause low-temperature burns.
• When connecting the system to a plasma or projection* TV, do not leave a still image
on the TV screen for an extended period of time, as this may leave a faint image
permanently on the screen.
* Except LCD screen types
• When using the motion sensor function of the wireless controller, be cautious of the
following points. If the controller hits a person or object, this may cause accidental
injury or damage.
– Before using, check that there is plenty of space around you.
– When using the controller, grip it firmly to make sure it cannot slip out of
your hand.
– If using a controller that is connected to the debugging station with a
USB cable, make sure there is enough space for the cable so that the
cable will not hit a person or object. Also, take care to avoid pulling the
cable out of the debugging station while using the controller.
Vents
Do not block any vents. To maintain good ventilation, follow the guidelines below:
• Place the system at least 10 cm (4 in) away from a wall surface.
• Do not place on a carpet or rug with long fi bers.
• Do not place in a narrow or cramped space.
• Do not cover with cloth.
• Do not allow dust to build up on the vents.
AC power cord use
• Do not use a power cord other than the supplied AC power cord. Do not modify the
cord.
• Do not touch the plug of the AC power cord with wet hands.
• Protect the AC power cord from being walked on or pinched particularly at plugs,
expansion receptacles and the point where the cord exits from the system.
• Do not place heavy items on the cord.
• Do not place the AC power cord near heating equipment and do not expose the cord
to heat.
• Do not allow dust or foreign matter to build up around the AC IN connector. Before
connecting or plugging in the AC power cord, check that there is no dust or foreign
matter in or on the power plug or connecting end of the cord, the electrical outlet or
the AC IN connector on the system rear. If the plug or connector becomes dirty, wipe
off with a dry cloth before connecting.
• Unplug the AC power cord from the electrical outlet before cleaning or moving the
system, or when you do not intend to use the system for an extended period of time.
• When disconnecting, grasp the power cord by the plug and pull straight out of the
electrical outlet. Never pull by the cord and do not pull out at an angle.
• Do not connect the AC power cord to a voltage transformer or inverter. Connecting
the AC power cord to a voltage transformer for overseas travel or an inverter for use
in an automobile may cause heat to build up in the system and may cause burns or a
malfunction.
Never disassemble or modify the system or
accessories
Use the debugging station and accessories according to the instructions in the product
documentation. No authorization for the analysis or modifi cation of the system, or the
analysis and use of its circuit confi gurations, is provided. Unauthorized modifi cation of
the system will void your warranty. There are no user serviceable components inside
the debugging station. Additionally, there is a risk of exposure to laser radiation as well
as to electrical shock.
Network - wired connection
Use only an Ethernet cable compatible with 10BASE-T, 100BASE-TX or 1000BASE-T
networks. Do not use a cord for a standard residential telephone line or cables of types
other than those mentioned here. Using the wrong type of cord or cable can cause
more electrical current than necessary to fl ow through the LAN connector, which may
lead to heat build-up, fi re or malfunction.
Moisture condensation
If the system or disc is brought directly from a cold location to a warm one, moisture
may condense on the lens inside the system or on the disc. Should this occur, the
system may not operate properly. In this case, remove the disc and turn off and unplug
the system. Do not put the disc back in until the moisture evaporates (this may take
several hours).
Hard disk
This system is equipped with a hard disk (a recording device for storing software, data,
etc.). Follow the instructions below to help prevent software or data loss or corruption or
damage to the hard disk.
• Do not place the system on an unstable surface or a surface that is subject to
vibration.
• Do not move the system while it is turned on.
• Do not subject the system to physical shock.
DECH-2500A / DECH-S2500A 4-258-960-13 (1)
© 2010 Sony Computer Entertainment Inc. All rights reserved. Printed in Japan
• Do not turn off the system while data is being saved on or loaded from the hard disk.
• Do not place the system close to magnetic fields produced by magnets or
loudspeakers.
If for any reason software or data loss or corruption occurs, it may not be possible to
restore or repair the software or data. Sony Computer Entertainment Inc. and its
subsidiaries and affi liates will not be held liable for damage or injury related to software
or data loss or corruption.
Wireless networking feature
The 2.4 GHz range of radio waves used by the wireless networking feature of this
product is a range shared by various devices. This product has been designed to
minimize the effect of other devices using the same range. However, in some cases
interference from other devices may reduce the connection speed or shorten the signal
range, or cause the connection to be terminated unexpectedly.
Specifi cations
Design and specifi cations are subject to change without notice.
Debugging Station (for PlayStation®3)
Power 100 - 240 V AC, 50/60 Hz
Power consumption Approx. 230 W
External dimensions
(excluding maximum projecting
part)
Approx. 290 × 65 × 290 mm
(11.5 × 2.6 × 11.5 in)
(width × height × length)
Mass Approx. 3.0 kg (6.6 lb)
Operating temperature 5°C - 35°C (41°F - 95°F)
Inputs/outputs on the system front Hi-Speed USB (conforms to USB 2.0) × 2
Inputs/outputs on the system rear HDMI OUT connector × 1
LAN connector × 1
Digital out (optical) connector × 1
AV MULTI OUT connector × 1
AC IN connector × 1
Supplied accessories AV cable × 1
USB cable × 1
AC power cord for use in Oceania × 1
AC power cord for use in Europe x 1
AC power cord for use in Korea x 1
(DECH-2500A only)
AC power cord for use in UK × 1
AC power cord for use in USA and Canada × 1
AC power cord for use in Taiwan x 1
(DECH-2500A only)
Instruction manual × 1
Laser Typ e : Semiconductor, continuous
BD Wavelength: 400 - 410 nm
Power: Max. 17.5 mW
DVD Wavelength: 655 - 664 nm
Power: Max. 2.6 mW
CD Wavelength: 770 - 800 nm
Power: Max. 4.0 mW
Supplied AV cable and USB cable
AV cable Company: SONY
Parts No.: 1-838-149-11
USB cable Company: SONY
Parts No.: 1-833-625-12
Contact information
For more information on this product, visit your local technical support Web site or
contact your local service dealer.
Limitations of liability
This product is supplied pursuant to and subject to the terms of the tool loan agreement
with Sony Computer Entertainment Inc. or its affi liates. Other than as expressly set forth
by SCEI and/or any of its affi liates, except to the extent prohibited by applicable laws,
SCEI and/or any of its affi liates shall not be liable for any damages, including special,
incidental or consequential damages, or fees arising out of the use or inability to use
this product.
About national export control
This product may fall within the scope of national export control legislation. You must
comply fully with the requirements of such legislation and of all other applicable laws of
any jurisdiction in relation to this product.
CT
警告
• 為避免觸電，請勿打開外殼擅⾃分解。維修僅能由專業的維修⼈員進⾏。
• 注意
– ⾮依指定⽅式⽽進⾏的操作、調整以及執⾏動作可能會導致放射線洩漏。
– 使⽤本產品時若搭配光纖，可能會增加眼睛受損的危險。
• 依據 IEC60825-1:2007，本家電⽤品隸屬 CLASS 1 LASER 產品分類。
CLASS 1 LASER PRODUCT
LASER KLASE 1
LUOKAN 1 LASER LAITE
KLASS 1 LASERAPPARAT
光敏感 / 癲癇 / 突發性疾病
有極少數⼈，當看到某些亮光或閃光時，可能會有癲癇發作或暫時性眩暈的情形。如果
這些⼈看到電視螢幕上的某些圖案或背景，或者在打電玩時，可能會引發癲癇或暫時性
眩暈。
某些從未有過癲癇的⼈，也可能在這些情況下被引發出來。如果您或您的家⼈有癲癇狀
況或任何突發性疾病，在打電玩前請先洽詢醫⽣。
如果您或您的孩⼦有以下任何⼀種健康問題或症狀，請⽴即停⽌使⽤，必須先洽詢醫⽣，
才能繼續打電玩 :
• 頭暈，
• 視覺障礙，
• 眼睛或肌⾁抽動，
• 意識不清，
• 精神恍惚，
• 突發性疾病，或者
• 不⾃主的動作或肌⾁抽動。
必須經醫⽣許可才能繼續打電玩。
減少發病可能性的電玩遊戲使⽤和操作注意事項
• 請在光線良好的地⽅使⽤，並且盡量與電視螢幕保持遠距離。
• 避免使⽤⼤螢幕電視機。請使⽤尺⼨最⼩的電視螢幕。
• 避免⾧時間使⽤主機。每玩⼀⼩時請休息 15 分鐘。
• 避免在您疲勞或需要睡眠時遊玩。
無線電波
無線電波可能會影響電⼦設備或醫療裝置（例如⼼律調整器） ，且可能會導致這些設備
或裝置故障或損壞。
• 若您有使⽤⼼律調整器或其他醫療裝置，請在使⽤無線網路機能前，先詢問您的主治
醫⽣或您⾝上之醫療裝置的製造廠商。
• 請勿在下列場所使⽤無線網路功能：
– 禁⽌使⽤無線網路的場所，如：醫院。在醫院中使⽤主機時，請遵守其規定。
– 接近⽕災警報器、⾃動⾨或其他類型之⾃動化設備的場所。
3D影像
有些⼈在使⽤ 3D 電視機觀看 3D 影像或遊玩 3D ⽴體遊戲時，可能會感到不舒服（例如眼
睛疲勞、噁⼼等）。若您感到不舒服，請⽴即停⽌使⽤您的電視機，直⾄不舒服的症狀消退。
SCE 建議所有使⽤者在觀看 3D 影像或遊玩 3D ⽴體遊戲時，應該定時休息。休息的時間和
次數因⼈⽽異，請休息⾜夠時間，直⾄不舒服的症狀消退。如果症狀持續存在，請⽴即就醫。
使⽤ PlayStation®3 主機時若同時使⽤任何⽀援 3D 的裝置，請先閱讀該裝置的使⽤說明書。
依據低功率電波輻射性電機管理辦法
第⼗⼆條 經型式認證合格之低功率射頻電機，⾮經許可，公司、商號或使⽤者均不得擅
⾃變更頻率、加⼤功率或變更原設計之特性及功能。
第⼗四條 低功率射頻電機之使⽤不得影響⾶航安全及⼲擾合法通信；經發現有⼲擾現象
時，應⽴即停⽤，並改善⾄無⼲擾時⽅得繼續使⽤。
前項合法通信，指依電信法規定作業之無線電通信。低功率射頻電機須忍受合法通信或
⼯業、科學及醫療⽤電波輻射性電機設備之⼲擾。
使⽤前須知事項
關於安全
本產品是在充分重視安全性能的情況下設計的。但如果使⽤不當，任何電器產品都有可
能引起⽕災觸電或⼈⾝傷害的潛在危險。爲確保安全操作，請遵循以下各項規則：
• 遵守所有警告條⽂注意事項及使⽤說明。
• 定期檢查交流電源線是否有損壞。
• 如果裝置出現動作不正常，或者發出異常聲⾳或氣味時，請⽴即停⽌使⽤，並從電源
插座中拔掉交流電源線插頭及所有的其他連接線。
使⽤和保養
• 交流電源線插⼊插座時，請勿連接 USB 連接線以外的連接線。
• 請勿在雷⾬天氣中，觸摸主機、連接線或附屬品。
• 切勿在靠近⽔的場所使⽤主機或附屬品。
• 請勿讓液晶、⼩顆粒或其他異物掉⼊主機或附屬品中。
• 請勿觸摸主機或附屬品的端⼦部分。
• 請勿將主機或附屬品暴露在灰塵、煙霧或蒸氣中。此外，請勿將主機放置在有很多灰
塵或⾹煙煙霧的場所。在內部零件（例如透鏡）中堆積的灰塵或⾹煙煙霧，可能會導
致主機故障。
• 請勿將主機或附屬品放在⾼溫、濕氣極重或受⽇光直射的地⽅。
• 請勿將主機或附屬品放在傾斜、不平穩或易受振動的地⽅。
• 請勿以垂直或⽔平以外的⽅式放置主機。此外，亦請勿於啟動主機電源後，變更主機
的擺放位置。
• 請⼩⼼搬運主機。若您未確實持有主機，可能會導致主機掉落並有造成損壞或⼈⾝傷
害的潛在性危險。
• 將光碟插⼊主機時，請勿移動或改變主機位置。振動可能刮傷光碟或主機。
• 請勿於主機上站⽴或放置物品，且請勿在主機上堆放其他裝置。
• 請勿將主機和與其連接的附屬品放置在地板或可能絆倒⼈的地⽅。
• 請勿讓⾝體⾧時間接觸使⽤中的主機或從主機通⾵孔排出的氣體。⾧時間接觸這些可
能導致低溫灼傷。
• 主機與電漿電視 (Plasma TV) 或投影 *電視機連接時，切勿讓畫⾯⾧時間顯⽰靜態影像，
否則可能會導致模糊影像的永久殘留。
* LCD 螢幕類型除外
• 使⽤無線控制器的動態感測（Motion Sensor）機能時，請注意以下事項。控制器若撞
擊到⼈體或物品，可能會導致意外、傷害或損傷。
– 使⽤前，請檢查您周圍是否有⾜夠的空間。
– 使⽤該控制器時，請確實握住並確認它不會從您⼿中滑出。
– 使⽤經由 USB 連接線與測試機相連的控制器時，請確認連接線有⾜夠空
間並且連接線不會撞擊到⼈體或物品。同時應避免在使⽤控制器時從測
試機拔除連接線。
通⾵孔
請勿阻塞任何通⾵孔。爲維持良好的通⾵，請遵循以下各項規則：
• 將主機放置在距離牆壁⾄少 10 cm 以上的場所。
• 切勿放置在有⾧纖維的地毯或⽑毯上。
• 切勿放置在狹窄或擁擠的空間中。
• 請勿⽤布覆蓋。
• 切勿讓灰塵堆積在通⾵孔中。
使⽤交流電源線
• 請勿使⽤隨附之交流電源線以外的其他電源線。且切勿改造該電源線。
• 請勿⽤濕⼿觸摸交流電源線的端⼦。
• 請避免誤踩或掐擠交流電源線，尤其是插頭、轉接⽤的插座與電源線等⾃主機延伸出
來的組件更需注意。
• 請勿在電線上放置重物。
• 請勿將交流電源線放置在靠近加熱設備的場所，且切勿讓電源線暴露於⾼溫中。
• 請勿讓灰塵或異物堆積於交流電源線的連接端周圍。在連接或插⼊交流電源線前，需
確認是否有灰塵或異物堆積於交流電源線插頭、連接線末端之端⼦部位、電源插座或
主機背⾯的交流電源輸⼊端⼦。插頭或端⼦變髒時，請使⽤乾淨軟布擦拭。
• 當您準備開始清潔、移動，或打算⾧時間不使⽤主機時，請⾃電源插座中拔出交流電源線。
• 在拔下交流電源線時，請捉住電源插頭筆直地將插頭從電源插座拔出。切勿拉扯連接
線或強制朝特定⽅向拔取。
• 請勿將交流電源線插⼊變壓器或反相器。將交流電源線插⼊海外旅⾏者使⽤的變壓器
或汽⾞專⽤的反相器，可能會導致交流電轉換器發熱，並造成灼傷或故障。
切勿分解、改造主機或附屬品
使⽤測試機與附屬品時務必請遵守產品基本⽂書記載的指⽰說明。嚴禁擅⾃分解或改造
主機，並禁⽌分解和使⽤其電路結構。擅⾃改造主機將喪失所有保證權益。切勿擅⾃維
修測試機內部的零件，否則可能會有遭受雷射輻射或觸電的危險。
網路 - 線路連接
僅對應與 10BASE-T、100BASE-TX 或 1000BASE-T 網路相容的⼄太網路連接線。切勿使⽤
⼀般家庭的標準電話線或上述類型以外的連接線。使⽤類型錯誤之連接線連接，可能會
造成超過 LAN 連接時需要量的電流通過，並可能會導致過熱、⽕災或是故障。
結露現象
若把主機從寒冷的地⽅直接搬放到溫暖的場所，機內的透鏡或光碟可能會凝結⽔氣。此
種現象可能會導致主機無法正常運作。這時，請把光碟取出，關閉電源，並拔掉主機電
源插頭。在⽔氣尚未蒸發前，切勿再次插⼊光碟（⽔氣蒸發可能需要數⼩時）。
硬碟
主機具有硬碟（儲存軟體、資料等的錄製裝置）。
請按照以下指⽰操作，以免軟體或資料遺失、硬碟損壞。
• 請勿將主機放在不平穩的表⾯或會受到振動的表⾯。
• 請勿在主機開啟時移動主機。
• 請勿讓主機受到物理撞擊。
• 請勿在硬碟保存或載⼊資料時關閉主機的電源。
• 請勿將主機靠近磁鐵或擴⾳器等產⽣的磁場。
無論理由為何，軟體或資料⼀旦遺失或毀損，可能無法復原或修理。Sony Computer
Entertainment Inc. 與其⼦公司、關係企業對於因遊戲或資料的遺失、毀損⽽造成之損害，
概不承擔任何責任。
無線網路功能
本產品之無線網路功能使⽤的 2.4 GHz 無線電波範圍乃屬各種裝置共⽤分享。本產品的
設計會降低使⽤相同範圍之其他裝置的作⽤。然⽽，來⾃其他裝置的⼲擾仍可能會降低
連線速度、縮短訊號範圍，或導致連線忽然意外中⽌。
規格
本公司保留在沒有事先通知情況下，變更設計或規格之權利。
Debugging Station (for PlayStation®3)
商品名 測試機
型號 DECH-2500A / DECH-S2500A
電源 100 - 240 V AC, 50/60 Hz
耗電量 約 230 W
額定輸⼊電流 2.3 - 1.0A
外殼尺⼨（不包括最⼤突出部分） 約 290 × 65 × 290 mm
(11.5 × 2.6 × 11.5 in)
（寬×⾼×⾧）
重量 約 3.0 kg (6.6 lb)
操作溫度 5° C - 35° C
主機正⾯的輸⼊ / 輸出 Hi-Speed USB ( 符合 USB 2.0) × 2
主機背⾯的輸⼊ / 輸出 HDMI 輸出端⼦ × 1
LAN 連接埠 × 1
光纖數碼輸出端⼦ × 1
AV 多重輸出端⼦ × 1
交流電源輸⼊端⼦ × 1
隨附配件 AV 連接線 × 1
USB 連接線 × 1
⼤洋洲專⽤交流電源線 × 1
歐洲專⽤交流電源線 × 1
韓國專⽤交流電源線 × 1（僅限 DECH-2500A）
英國專⽤交流電源線 × 1
美國和加拿⼤專⽤交流電源線 × 1
台灣專⽤交流電源線 × 1（僅限 DECH-2500A）
使⽤說明書 × 1
雷射規格 類別： 半導體，連續式
BD 波⾧：400 - 410 nm
功率：最⼤ 17.5 mW
DVD 波⾧：655 - 664 nm
功率：最⼤ 2.6 mW
CD 波⾧：770 - 800 nm
功率：最⼤ 4.0 mW
製造年份 請⾒產品本體標⽰
製造號碼 請⾒產品本體標⽰
⽣產國別 ⽇本
製造商 Sony Computer Entertainment Inc.
進⼝商 台灣索尼電腦娛樂股份有限公司
地址 台北市中⼭北路⼆段 44 號 9 樓
隨附的 AV 連接線和 USB 連接線
AV連接線 公司: SONY
零件號: 1-838-149-11
USB連接線 公司: SONY
零件號: 1-833-625-12
聯絡資訊
對於本產品若有相關疑問，請洽詢 SCE Taiwan 負責⼈員或 SCEK Developer Support。
SCET 聯絡電話 :+886-2-2537-5366、SCEK Developer Support:+82-2-6230-3596( 專線 )
責任範圍
本產品根據與 Sony Computer Entertainment Inc. 或其⼦公司之間的⼯具借貸協議提供
並受此協議條款約束。除了相關法律禁⽌以外，除⾮ SCEI 和 / 或其⼦公司明確規定，否
則對於因使⽤或無法使⽤本產品所造成的任何損害（包括特殊、附帶或間接損害）或費⽤，
SCEI 和 / 或其任何⼦公司概不負責。
關於國家出⼝控制
本產品可能因各國⽴法之規定⽽被列爲限制出⼝商品。請嚴格遵守相關法條及任何與本
產品之管轄權有關之法律規定。
廢電池請回收
（僅適⽤於台灣）
“ ” and “PlayStation” are registered trademarks of Sony Computer Entertainment Inc.
“SONY” and “ ” are registered trademarks of Sony Corporation.

Navigation menu
