User Manual 1 of 2
CECH-ZCM1U D
CECH-ZCM1E D
Motion controller for Reference Tool
WARNING
Carefully read this instruction manual and the instruction manual
for the compatible hardware (Development/Verification Tool for
PlayStation3) before using this product. The compatible hardware’s
instruction manual contains safety precautions for the prevention of
accidents, and instructions for the use and handling of the hardware.
Do not allow the battery to come into contact with fire or subject it
to extreme temperatures such as in direct sunlight, in a vehicle
exposed to the sun or near a heat source.
•When using the motion controller, avoid holding the controller
closer than 8 inches from the face or eyes.
Caution
•Attach the supplied strap and wear it on your wrist.
•Hold the controller firmly and avoid swinging it with excessive
force, especially when using it with another controller.
•Before use, make sure there is plenty of space around you.
For Customers in the U.S.A. / Notice réservée aux utilisateurs
résidant aux États-Unis
This equipment complies with FCC radiation exposure limits set
forth for uncontrolled equipment and meets the FCC radio frequency
(RF) Exposure Guidelines in Supplement C to OET65. This
equipment has very low levels of RF energy that are deemed to
comply without testing of specific absorption ratio (SAR). This
transmitter must not be co-located or operated in conjunction with
any other antenna or transmitter.
NOTE:
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
–Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
–Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
–Consult the dealer or an experienced radio/TV technician for help.
Instruction Manual SCE CONFIDENTIAL
You are cautioned that any changes or modifications not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
If you have questions about this product, call our technical support
line at 1-800-345-7669, or write to:
Sony Computer Entertainment America
Consumer Services/Technical Support
PO Box 5888, San Mateo, CA 94402-0888 U.S.A.
Declaration of Conformity
Trade Name: SONY
Model No.: CECH-ZCM1U D
Responsible Party: Sony Electronics Inc.
Address: 16530 Via Esprillo, San Diego, CA 92127
U.S.A.
Telephone No.: 858-942-2230
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation of this device.
For customers in Canada
This Class B digital apparatus complies with Canadian ICES-003.
This device complies with RSS-Gen of IC Rules. Operation is subject
to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment complies with IC radiation exposure limits set forth
for uncontrolled equipment and meets RSS-102 of the IC radio
frequency (RF) Exposure rules. This equipment has very low levels
of RF energy that it is deemed to comply without testing of specific
absorption ratio (SAR).
Pour les clients du Canada
Cet équipement numérique de Classe B est conforme à la norme
canadienne NMB-003.
Cet appareil est conforme aux stipulations CNR-Gen des règles IC.
Son opération est sous réserve des deux conditions suivantes : (1) cet
appareil ne peut pas causer de brouillage préjudiciable et (2) cet
appareil doit accepter le brouillage préjudiciable reçu,y compris un
brouillage qui pourrait causer son fonctionnement irrégulier.
Cet équipement est conforme aux limites d’exposition aux radiations
imposées pour tout équipement non contrôlé, et est conforme aux
règles IC d’exposition des radiofréquences (RF) définies par CNR-
102. Cet équipement émet des niveaux très bas de RF jugés
conformes sans avoir subi le test de débit d’absorption spécifique
(SAR).
For customers in Europe
The manufacturer of this product is Sony Computer Entertainment
Inc., 2-6-21 Minami-Aoyama, Minato-ku Tokyo, 107-0062 Japan.
The Authorised Representative for EMC and product safety is Sony
Deutschland GmbH, Hedelfinger Strasse 61, 70327 Stuttgart,
Germany.
Distributed in Europe by Sony Computer Entertainment Europe Ltd,
10 Great Marlborough Street, London, W1F 7LP, United Kingdom.
4-194-160-11(1)
Where you see this symbol on any of our electrical products/
packaging in Europe, it means that at end of life the product/
battery must be disposed of in accordance with any applicable laws
or requirements for the separate disposal of electrical equipment/
batteries. This symbol may be used on batteries in combination
with additional chemical symbols. The chemical symbols for
mercury (Hg) or lead (Pb) will appear if the battery contains more
than 0.0005% mercury or more than 0.004% lead. Accordingly at
end of life we will arrange for separate disposal of our loan
equipment including without limitation development kits which
remain at all times the property of Sony Computer Entertainment
Europe. If you would like assistance with the disposal of any other
electrical products which we have supplied to you for business use,
we can arrange a take-back service on request. Please check
https://www.tpr.scee.net for more information.
This product contains a battery which is permanently built-in for
safety, performance or data integrity reasons. The battery should
not need to be replaced during the lifetime of the product and
should only be removed by skilled service personnel. To ensure the
correct waste treatment of the battery, please dispose of this
product as electrical waste.
This product may fall within the scope of national export control
legislation. You must comply fully with the requirements of such
legislation and of all other applicable laws of any jurisdiction in
relation to this product.
Description
This product is designed only for use with the Development/
Verification Tool for PlayStation3. For detailed instructions on
use, refer to the instruction manual of the compatible hardware or
visit your local technical support Web site.
Battery (supplied)
•Charge in an environment where the temperature range is
between 10°C - 30°C (50°F - 86°F). Charging may not be as
effective when performed in other environments.
•Battery duration may vary depending on the usage condition and
environmental factors.
•The battery has a limited lifespan. Battery charge duration
gradually decreases with repeated usage and age. Battery life also
varies depending on the storage method, usage state,
environment and other factors.
When disposing of the motion controller
When disposing of the motion controller, remove the battery and
follow local regulations regarding disposing of batteries.
© 2010 Sony Computer Entertainment Inc. All rights reserved.Strap
Printed in China
Notice
Other than when disposing of the motion controller, never remove
the screws and never remove the battery from the motion
controller.
Caution
Do not handle damaged or leaking Lithium-Ion batteries.
Specifications
Compatible hardware
Development/Verification Tool for
PlayStation3
*
Power consumption DC 5 V, 800 mA
Operating temperature 5°C - 35°C (41°F - 95°F)
Mass Approx. 145 g (5.1 oz )
(without the cable)
External dimensions Approx. 200 mm × 46 mm
(excluding maximum (7.9 in. × 1.8 in.)
projecting part) (height × diameter)
Supplied items Instruction manual × 1
Strap × 1
*For details on the Development/Verification Tool, visit your local
technical support Web site.
Design and specifications are subject to change without notice.
Contact information
For more information on this product, visit your local technical
support Web site or contact your local service dealer.
Limitations of liability
This product is supplied pursuant to and subject to the terms of the
tool loan agreement with Sony Computer Entertainment Inc. or its
affiliates. Other than as expressly set forth by SCEI and/or any of
its affiliates, except to the extent prohibited by applicable laws,
SCEI and/or any of its affiliates shall not be liable for any damages,
including special, incidental or consequential damages, or fees
arising out of the use or inability to use this product.
" " and "PlayStation" are registered trademarks of Sony
Computer Entertainment Inc.
"SONY" and " " are registered trademarks of Sony Corporation.
