CXN5001 Users Manual

Oct 1, 2009

SONY corp.

Semiconductor business group

HSS div. Information device dept.

1. Connect the USB cable mini-B connector to the CXN5001.

2. Connect the module and the coupler(antenna) with the U.FL coax cable.

3. Apply DC power supply +5V to the module through the USB cable.

Fixed transmitting power module(S/N:1003/1004)

0. Preparation

- Linux Fedora core8 installed PC

- USB cable(A –mini B)

1. Powered on the PC

2. Select Fedora

3. Input the account and pass word

4. Tie the CXN5001 and the coupler(antenna) with the U.FL coax cable

5. Connect the CXN5001 to the PC with an USB cable

6. Click the “raptor_tool” on the desk top

7. In the shell, enter No.1 & 80 to set the TX power output

or set to the minimum power

8. If “80” is selected, variable TX power setting is available,

to increase the TX power, input “1”,

to decrease the TX power, input “2”.

Variable transmitting power module(S/N:1001/1002) operation
