Reference Tool
Instruction Manual
DECR-1400A 4-140-137-11(1)
WARNINGS
• To avoid electrical shock, do not open the cabinet. Refer servicing to qualifi ed personnel only.
• CAUTION
– Use of controls or adjustments or performance of procedures other than those specified herein may
result in hazardous radiation exposure.
– The use of optical instruments with this product will increase eye hazard.
• This appliance is classifi ed as a CLASS 1 LASER product under IEC60825-1+A2:2001.
CLASS 1 LASER PRODUCT
LASER KLASE 1
LUOKAN 1 LASER LAITE
KLASS 1 LASERAPPARAT
Photosensitivity/Epilepsy/Seizures
A very small percentage of individuals may experience epileptic seizures or blackouts when exposed to
certain light patterns or flashing lights. Exposure to certain patterns or backgrounds on a television
screen or when playing video games may trigger epileptic seizures or blackouts in these individuals.
These conditions may trigger previously undetected epileptic symptoms or seizures in persons who
have no history of prior seizures or epilepsy. If you, or anyone in your family, has an epileptic condition
or has had seizures of any kind, consult your physician before playing.
IMMEDIATELY DISCONTINUE use and consult your physician before resuming gameplay if you or your
child experience any of the following health problems or symptoms:
• dizziness,
• altered vision,
• eye or muscle twitches,
• loss of awareness,
• disorientation,
• seizures, or
• any involuntary movement or convulsion.
RESUME GAMEPLAY ONLY ON APPROVAL OF YOUR PHYSICIAN.
Use and handling of video games to reduce the likelihood of a seizure
• Use in a well-lit area and keep as far away as possible from the television screen.
• Avoid large screen televisions. Use the smallest television screen available.
• Avoid prolonged use of the system. Take a 15-minute break during each hour of play.
• Avoid playing when you are tired or need sleep.
Radio waves
Radio waves may affect electronic equipment or medical devices (for example, pacemakers), which may
cause malfunctions and possible injuries.
• If you use a pacemaker or other medical device, consult your physician or the manufacturer of your
medical device before using the wireless networking feature.
• Do not use the wireless networking feature in the following locations:
– Areas where wireless network use is prohibited, such as in hospitals. Abide by medical institution
regulations when using the system on their premises.
– Areas near fire alarms, automatic doors and other types of automated equipment.
For customers in the U.S.A. and Canada
• NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
– Consult the dealer or an experienced radio/TV technician for help.
• You are cautioned that any changes or modifi cations not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
• This transmitter must not be co-located or operated in conjunction with any other antenna or
transmitter.
• This equipment complies with FCC/IC radiation exposure limits set forth for uncontrolled equipment
and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and
RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment should be installed and
operated with at least 20cm (8 in) and more between the radiator and person’s body (excluding
extremities: hands, wrists, feet and legs).
If you have questions about this product, visit http://www.scedev.net, call Developer Support at
1-650-655-5566 or write to:
Sony Computer Entertainment America
Developer Support
919 East Hillsdale Boulevard
Foster City, CA 94404-2175 USA
Declaration of Conformity
Trade Name : SONY
Model No. : DECR-1400A
Responsible Party : Sony Electronics Inc.
Address : 16530 Via Esprillo, San Diego, CA 92127 U.S.A.
Telephone No. : 858-942-2230
This device complies with Part 15 of the FCC Rules and RSS-Gen of IC Rules. Operation is
subject to the following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation of this device.
• The lithium coin memory back-up battery inside this product contains Perchlorate.
The following statement is required by the State of California, USA:
Perchlorate Material – special handling may apply. See
http://www.dtsc.ca.gov/hazardouswaste/perchlorate
For customers in Europe
• This equipment has been tested and found to comply with the limits set out in the R&TTE Directive using
a connection cable shorter than 3 metres. Do not use cables longer than 3 metres.
Where you see this symbol on any of our electrical products/packaging in Europe, it means that at end of
life the product/battery must be disposed of in accordance with any applicable laws or requirements for the
separate disposal of electrical equipment/batteries. Accordingly at end of life we will arrange for separate
disposal of our loan equipment including without limitation development kits which remain at all times the
property of Sony Computer Entertainment Europe. If you would like assistance with the disposal of any
other electrical products which we have supplied to you for business use, we can arrange a take-back
service on request. Please check http://www.devtoolrec.scee.net for more information.
This product contains a battery which is permanently built-in for safety, performance or data integrity
reasons. The battery should not need to be replaced during the lifetime of the product and should only be
removed by skilled service personnel. To ensure the correct waste treatment of the battery, please dispose
of this product as electrical waste.
The manufacturer of this product is Sony Computer Entertainment Inc., 2-6-21 Minami-Aoyama, Minato-ku
Tokyo, 107-0062 Japan. The Authorised Representative for EMC and product safety is Sony Deutschland
GmbH, Hedelfi nger Strasse 61, 70327 Stuttgart, Germany.
Distributed in Europe by Sony Computer Entertainment Europe Ltd, 10 Great Marlborough Street, London,
W1F 7LP.
For customers in the United Kingdom
A molded plug complying with BS1363 is fi tted to this equipment for your safety and convenience. Should
the fuse in the plug supplied need to be replaced, a 5AMP fuse approved by ASTA or BSI to BS1362, (i.e.,
marked with or ) must be used. If the plug supplied with this equipment has a detachable fuse cover,
be sure to attach the fuse cover after you change the fuse. Never use the plug without the fuse cover. If
you should lose the fuse cover, please contact your nearest Sony service station.
Precautions
Safety
This product has been designed with the highest concern for safety. However, any electrical
device, if used improperly, has the potential for causing fi re, electrical shock or personal injury.
To help ensure accident-free operation, follow these guidelines:
• Observe all warnings, precautions and instructions.
• Regularly inspect the AC power cord for damage.
• Stop use, unplug the AC power cord from the electrical outlet and disconnect any other
cables immediately if the device functions in an abnormal manner, produces unusual sounds
or smells or becomes too hot to touch.
Use and handling
• Do not connect cables other than a USB cable while the AC power cord is plugged into the
electrical outlet.
• Do not touch the system or connected cables or accessories during an electrical storm.
• Do not use the system or accessories near water.
• Do not allow liquid, small particles or other foreign objects to get into the system or
accessories.
• Do not touch the connectors of the system or accessories.
• Do not expose the system or accessories to dust, smoke or steam. Also, do not place the
system in an area subject to excessive dust or cigarette smoke. Dust build-up or cigarette
smoke residue on the internal components (such as the lens) may cause the system to
malfunction.
• Do not expose the system or accessories to high temperatures, high humidity or direct
sunlight.
• Do not place the system or accessories on surfaces that are unstable, tilted or subject to
vibration.
• Do not set the system other than in the vertical or horizontal position. Also, do not change
the position while the system is turned on.
• Be careful when carrying the system. If you do not have a good grip, the system may drop
causing potential damage or injury.
• Do not move or change the position of the system with a disc inserted. The vibration may
result in scratching of the disc or the system.
• Do not stand on or put objects on the system, and do not stack the system with other
devices.
• Do not place the system and connected accessories on the fl oor or in a place where they
may cause someone to trip or stumble.
• Do not allow bodily contact with the system or air from the system vents for an extended
period of time while in use. Extended contact under these conditions may cause low-
temperature burns.
• When connecting the system to a plasma or projection* TV, do not leave a still image on the
TV screen for an extended period of time, as this may leave a faint image permanently on
the screen.
* Except LCD screen types
• When using the motion sensor function of the wireless controller, be cautious of the following
points. If the controller hits a person or object, this may cause accidental injury or damage.
– Before using, check that there is plenty of space around you.
– When using the controller, grip it firmly to make sure it cannot slip out of your hand.
– If using a controller that is connected to the debugging station with a USB cable, make
sure there is enough space for the cable so that the cable will not hit a person or object.
Also, take care to avoid pulling the cable out of the debugging station while using the
controller.
Vents
Do not block any vents. To maintain good ventilation, follow the guidelines below:
• Place the system at least 10 cm (4 in) away from a wall surface.
• Do not place on a carpet or rug with long fi bers.
• Do not place in a narrow or cramped space.
• Do not cover with cloth.
• Do not allow dust to build up on the vents.
![](/img.php?id=1067664&img=bg2.png)
DECR-1400A 4-140-137-11 (1)
AC power cord use
• Do not use a power cord other than the supplied AC power cord. Do not modify the cord.
• Do not touch the plug of the AC power cord with wet hands.
• Protect the AC power cord from being walked on or pinched particularly at plugs, expansion
receptacles and the point where the cord exits from the system.
• Do not place heavy items on the cord.
• Do not place the AC power cord near heating equipment and do not expose the cord to heat.
• Do not allow dust or foreign matter to build up around the AC IN connector. Before connecting
or plugging in the AC power cord, check that there is no dust or foreign matter in or on the
power plug or connecting end of the cord, the electrical outlet or the AC IN connector on the
system rear. If the plug or connector becomes dirty, wipe off with a dry cloth before
connecting.
• Unplug the AC power cord from the electrical outlet before cleaning or moving the system, or
when you do not intend to use the system for an extended period of time.
• When disconnecting, grasp the power cord by the plug and pull straight out of the electrical
outlet. Never pull by the cord and do not pull out at an angle.
• Do not connect the AC power cord to a voltage transformer or inverter. Connecting the AC
power cord to a voltage transformer for overseas travel or an inverter for use in an automobile
may cause heat to build up in the system and may cause burns or a malfunction.
Never disassemble or modify the system or accessories
Use the debugging station and accessories according to the instructions in the product
documentation. No authorization for the analysis or modifi cation of the system, or the analysis
and use of its circuit confi gurations, is provided. Unauthorized modifi cation of the system will
void your warranty. There are no user serviceable components inside the debugging station.
Additionally, there is a risk of exposure to laser radiation as well as to electrical shock.
Network - wired connection
Use only an Ethernet cable compatible with 10BASE-T, 100BASE-TX or 1000BASE-T
networks. Do not use a cord for a standard residential telephone line or cables of types other
than those mentioned here. Using the wrong type of cord or cable can cause more electrical
current than necessary to fl ow through the LAN connector, which may lead to heat build-up, fi re
or malfunction.
Moisture condensation
If the system or disc is brought directly from a cold location to a warm one, moisture may
condense on the lens inside the system or on the disc. Should this occur, the system may not
operate properly. In this case, remove the disc and turn off and unplug the system. Do not put
the disc back in until the moisture evaporates (this may take several hours).
Hard disk
This system is equipped with a hard disk (a recording device for storing software, data, etc.).
Follow the instructions below to help prevent software or data loss or corruption or damage to
the hard disk.
• Do not place the system on an unstable surface or a surface that is subject to vibration.
• Do not move the system while it is turned on.
• Do not subject the system to physical shock.
• Do not turn off the system while data is being saved on or loaded from the hard disk.
• Do not place the system close to magnetic fi elds produced by magnets or loudspeakers.
If for any reason software or data loss or corruption occurs, it may not be possible to restore or
repair the software or data. Sony Computer Entertainment Inc. and its subsidiaries and
affiliates will not be held liable for damage or injury related to software or data loss or
corruption.
Wireless networking feature
The 2.4 GHz range of radio waves used by the wireless networking feature of this product is a
range shared by various devices. This product has been designed to minimize the effect of
other devices using the same range. However, in some cases interference from other devices
may reduce the connection speed or shorten the signal range, or cause the connection to be
terminated unexpectedly.
Specifi cations
Design and specifi cations are subject to change without notice.
Reference Tool system
Power 100 - 240 V AC, 50/60 Hz
Power consumption Approx. 290 W
External dimensions
(excluding maximum projecting
part)
Approx. 325 × 98 × 274 mm
(12.8 × 3.86 × 10.79 in)
(width × height × length)
Mass Approx. 4.7 kg (10.4 lb)
Operating temperature 5°C - 35°C (41°F - 95°F)
Inputs/outputs on the system front Hi-Speed USB (conforms to USB 2.0) × 4
Inputs/outputs on the system rear HDMI OUT connector × 1
LAN connector × 1
Dev LAN connector × 1
Digital out (optical) connector × 1
AV MULTI OUT connector × 1
AC IN connector × 1
Other Security lock slot × 1
Supplied accessories AV cable × 1
USB cable × 1
AC power cord for use in Oceania × 1
AC power cord for use in Europe and Korea × 1
AC power cord for use in UK × 1
AC power cord for use in USA and Canada × 1
AC power cord for use in Taiwan × 1
Instruction manual × 1
For details on the settings and use of this product, refer to the “PLAYSTATION®3 Runtime
Library SDK Documentation” package, which can be downloaded from the PLAYSTATION®3
Developer Network website.
Supplied AV cable and USB cable
AV cable Company: SONY
Parts No.: 1-834-231-11
USB cable Company: SONY
Parts No.: 1-833-625-12
Contact information
For more information on this product, visit your local technical support Web site or contact your
local service dealer.
Limitations of liability
This product is supplied pursuant to and subject to the terms of the tool loan agreement with
Sony Computer Entertainment Inc. or its affi liates. Other than as expressly set forth by SCEI
and/or any of its affi liates, except to the extent prohibited by applicable laws, SCEI and/or any
of its affi liates shall not be liable for any damages, including special, incidental or consequential
damages, or fees arising out of the use or inability to use this product.
About national export control
This product may fall within the scope of national export control legislation. You must comply
fully with the requirements of such legislation and of all other applicable laws of any jurisdiction
in relation to this product.
Notice about U.S. Export Administration Regulations
This product contains software that is subject to certain restrictions under the U.S. Export
Administration Regulations, and may not be exported or re-exported to U.S. embargoed
destinations. In addition this product may not be exported or re-exported to persons and
entities prohibited by the U.S. Export Administration Regulations.
“ ” and “PLAYSTATION” are registered trademarks of Sony Computer Entertainment Inc.
“SONY” and “ ” are registered trademarks of Sony Corporation.
© 2008 Sony Computer Entertainment Inc. All rights reserved. Printed in Japan
