Digital Paper System

Quick Start Guide

Help Guide (online manual)

This Quick Start Guide explains how to use the device

for the first time and gives safety precautions. For

further details, refer to the online Help Guide:

http://www.sony.net/dpt-rp1/help

Owner’s Record

The model and serial number are located at the rear of the

device. Record the serial number in the space provided below.

Refer to these numbers whenever you contact your Sony dealer

regarding this product.

Model No. DPT-RP1

Serial No.

You are cautioned that any changes or modifications not

expressly approved in this manual could void your authority to

operate this equipment.

Getting Started

Checking the supplied items

Check the following items are present.

• Digital Paper device (1)

• Stylus (1)

• Replacement tips

– Felt (gray) (1)

– POM (black) (2)

• Tip puller (1)

• USB cable (1)

• Quick Start Guide (this document) (1)

• Warranty (1)

Tip

For approved accessories, refer to the following Digital Paper product page:

https://www.sony.com/electronics/mobile-tablets

Initial setup

Set up the Digital Paper device (hereafter referred to as “the

device”) and your computer according to the instructions

displayed.

1 Turn on the device.

2 Set a stylus according to the instructions on the screen.

3 Turn on the computer and connect to the Internet.

4 Download Digital Paper App from the following site and

install on the computer.

http://www.sony.net/dpapp

Digital Paper App is required to transfer documents (PDF

files).

5 Start Digital Paper App and connect the supplied USB cable

to the micro USB connector of the device and the USB

connector of the computer.

6 Set the computer according to the instructions displayed

by Digital Paper App.

Documents can be transferred only between the device and

the computer.

7 Update the app software if a software update is advised.

Note

Wi-Fi is used only for transferring documents between the device and the

computer. The device cannot display Internet content.

Charging the device and stylus

1 Turn on the computer.

2 Connect the supplied USB cable to the micro USB connector

of the device or stylus and the USB connector of the

computer.

Charge indicator

Notes

• Charge the device and stylus within the recommended temperature range of

5 °C to 35 °C (41 °F to 95 °F). If the room is too hot or cold, disconnect the USB

cable, adjust the room temperature accordingly, then reconnect the USB cable

to charge.

• The device and stylus will not charge if your computer is turned off, enters sleep

mode, standby mode or hibernation mode.

Tip

The Charge indicator lights up in red while charging.

Parts and controls

Digital Paper device

Micro USB connector

Æ (power) button

Charge indicator

RESET button

̘ (N-Mark)

Magnet (for holding the

stylus)

̚ (home) button

Touchscreen

Strap hole

Stylus

Micro USB connector

Strap hole

Charge indicator

Part for holding to the

device

Highlight button

Eraser button

Troubleshooting

The following information will help you remedy problems if you

cannot operate the device.

1 Charge the device and the stylus.

2 Reset the device.

Press the RESET button with a plastic toothpick, clip, etc.

Press the Æ (power) button to restart the device.

Notes

• Content handwritten within documents, created notes, and settings may be

deleted when the device is reset.

• Do not press the RESET button with a fragile object (pencil lead, etc.).

How to use the system and the

support site

For more detailed information on using the Digital Paper

System, see http://www.sony.com/digitalpapersupport

If you cannot recover the device

Consult the Sony Support Center and provide the following

information.

• Model name (specified on the back panel)

• Serial number (specified on the back panel)

• Purchase date

Replacing the stylus tip

The stylus tip may wear out through use. It is recommended to

replace the tip when it becomes shorter than 1.5 mm (1/16 in).

Replacement tips and a tip puller are supplied with the device.

Replace the tip when it becomes

shorter than 1.5 mm (1/16 in)

1 Pinch the tip with the supplied tip puller, then pull it out

straight.

Pinch the base of the tip firmly

2 Check the orientation of the replacement tip, pinch it with

the tip puller, then push it straight into the stylus.

3 Push the tip firmly with your finger.

Notes

• Keep out of reach of children, as the tip may be swallowed. In case the tip is

swallowed, please consult your doctor.

• Pressing on the tip with excessive pressure will wear it out more quickly.

Tips

• Replace the stylus tip periodically to prevent damage to the device and

maintain consistent operation.

• If the stylus tip is lost, contact the Sony Support Center.

Important Information

Safety

Do not expose the battery to fire or heat.

Do not disassemble the battery.

It may cause electric shock. Do not remove the battery yourself.

For battery replacement, internal checking or repair, consult the

Sony Support Center.

Do not charge the device near fire, heat, or leave it in hot

sunlight.

Do not leave coins, keys, jewelry, etc., near the USB

connector or USB cable.

Do not use the device while moving.

Do not operate the device or watch the display while driving a

vehicle, riding a motor cycle, walking, etc.

Do not use the device where it may distract you from

danger; for example at a railroad crossing, road,

construction site, etc.

Be careful not to allow liquid or a foreign object to get into

the device, as doing so may cause electric shock or fire.

If liquid or a foreign object gets into the device, consult the

Sony Support Center.

Keep out of reach of children.

The stylus or replacement tip may be accidentally swallowed. If

the battery is swallowed, consult a doctor immediately. It may

cause choking or damage the stomach.

Never subject the device to high temperature.

Never subject the device to extremes of light, high temperature

(more than 60 °C (140°F)), moisture or vibration.

For example, if the device is left in a car parked in the sun,

excessive heat buildup may result in deformation of the device

casing, or other malfunction.

Do not cover the device with a blanket when turned on.

The device may overheat and deform or catch fire.

If you feel discomfort while using the device, stop using it.

Do not leave the device on an unstable surface.

Do not leave the device on an unstable or sloping surface. Do

not stand the device upright, or turn it upside down. The device

may drop or be damaged.

The device screen is delicate.

If heavy weight or force is applied, the screen may be

damaged.

Precautions

Safety

Handling the device

• If the device causes interference to radio or television

reception, turn the device off and move it away from the radio

or television.

• Refrain from using the device in an aircraft according to the

inflight announcements during taking off or landing.

• When you put the device into a bag, make sure no objects

with sharp or hard edges come into direct contact with the

device.

• Do not drop, or put any heavy object on top of the device or

apply a strong shock to the device. It may cause a

malfunction or damage.

• Never subject the device to extremes of light, temperature,

moisture or vibration.

• If part of the device that generates heat contacts your skin for

a prolonged period, you may suffer burn symptoms, such as

redness, swelling, even if the temperature is moderate. Avoid

prolonged contact, especially if you have sensitive skin.

• Do not leave the device on an unstable surface.

• Do not poke people with the supplied stylus.

• Do not treat or use the supplied stylus roughly, such as

bending it, or scratching the touchscreen with it.

• Use the supplied stylus only for touchscreen operations.

• Do not use the stylus if it is damaged or deformed.

• Do not subject the stylus to shock or vibration.

• Do not apply any excessive pressure to the stylus tip and

stylus button during operation.

• Do not keep the stylus tip pressed while the stylus is not in

use.

• Do not leave the stylus on the touchscreen. It wastes battery

charge.

• If an object is placed on the touchscreen, it may cause a

malfunction. When not in use, leave the device in sleep mode,

or turn it off.

• When using the device another country/region, it is your

responsibility to ensure that it is used in compliance with the

following specifications:

– AC voltage

– Wireless products regulations

– Other safety regulations or requirements

• Be sure not to short-circuit the terminals of the device with

metallic objects.

• Never leave the device exposed to high temperature, such as

in a car parked in the sun or under direct sunlight.

• As the device uses magnets, it may affect medical equipment

such as a cardiac pacemaker, defibrillator, or programmable

shunt valve. Do not put the device close to medical

equipment or people using medical equipment. If you use

medical equipment and feel anxious, consult your doctor

before you use the device.

Avoiding water and moisture

• Note that condensation may form temporarily in cases such

as when the player is moved quickly from a low-temperature

environment to a high temperature environment or used in a

room that has a heater just turned on. Condensation creates a

phenomenon where moisture in the air adheres to surfaces

such as metal panels, etc., and then changes to liquid. If

condensation forms in the device, leave it turned off until the

condensation disappears. If you use the device with

condensation present, a malfunction may result.

• The device is not waterproof. Remember to follow the

precautions below.

– Be careful not to drop the device into a sink or other

container filled with water.

– Do not use the device in humid locations or bad weather,

such as in the rain or snow.

– Do not get the device wet.

If you touch the device with wet hands, or put it in a damp

article of clothing, the device may get wet and this may cause a

malfunction.

Charging the device

• Heat may build up in the device while charging, or if it is used

for an extended period of time.

• Use the supplied USB cable only. Do not use any other USB

cable.

• Never wrap the device in anything when it is being charged.

Heat build-up in the device may cause malfunction or

damage.

• If the battery lasts only half the normal time even after being

fully charged, it may be reaching the end of its life.

Cleaning the device

• Clean the device with a soft cloth, such as a cleaning cloth for

eyeglasses. Make sure that there is no dust or dirt on the soft

cloth, as the device may be damaged.

• Do not use any type of abrasive pad, scouring powder or

solvent, such as alcohol or benzene, as it may mar the finish

of the case.

• Wipe the stylus with a dry cloth when it gets dirty. Tapping or

dragging on the touchscreen using a dirty stylus may damage

the surface.

• Be sure to keep the device away from water or spills.

Regulatory information

This device displays the information below.

• The Declaration of Conformity (DoC) logo and the FCC

Identifier (FCC ID) based on the FCC Rules

• The VCCI mark based on RULES FOR VOLUNTARY CONTROL

MEASURES

• The marks and registration numbers of the radio wave and

radio communication acts

You can display these marks or registration numbers. Press

the (home) button, then tap [Settings] p [Regulatory

Information].

If you cannot display the marks or registration numbers due to

a malfunction, contact the Sony Support Center.

End User License Agreement

• You can display the End User License Agreement from the

[Settings].

Press the (home) button, then tap [Settings] p [System

Information] p [End User License Agreement].

Display

• The display is made of plastic film to be thin and lightweight.

When the device is illuminated, distortion of the plastic film

may occur. This is not a malfunction.

• Do not apply excessive pressure to the touchscreen. The color

or brightness may become uneven and may cause the device

to malfunction.

• When using the device in a cold environment, the screen may

change at a slower speed. This is not a malfunction.

DPT-RP1 4-597-105-11(1)

Security

You can lock the screen lock on the device. When the screen

lock is on, entering the lock password will be required when the

device is turned on or the device is woken from sleep mode.

To set the lock password, press the (home) button, then tap

[Settings] p [Screen Lock] p [Screen Lock] p [Enable]. The lock

password should be between 4 to 20 alphanumeric characters

and symbols.

– Do not create a lock password that other people could easily

guess. Change your password periodically.

– Be sure to remember your lock password. If you forget your

lock password, contact the Sony Support Center. The device

may be unlocked. However, all documents stored on the

device will be deleted.

– When the device is woken from sleep mode, you can unlock

the screen lock with the FeliCa card, cellular phone that

supports FeliCa, smartphone and so on. For details, refer to

the Help Guide.

Wi-Fi connectivity

• The Wireless LAN functionality has passed Wi-Fi certification

and complies with the interoperability specifications

established by WFA (Wi-Fi Alliance).

Wireless feature

• Turn off the wireless feature of the device when you are in a

location where radio communications are prohibited. You

must obtain permission from the appropriate authorities

before enabling the wireless feature in such places.

• Turn off the wireless feature in health care facilities where any

regulations posted in such areas instruct you to do so.

Hospitals or health care facilities may be using equipment

that could be affected by radio frequency (RF) energy which is

generated by wireless communication.

• Do not use your device near medical equipment without first

obtaining permission to do so.

• General notes on using the Wi-Fi (Wireless LAN) function.

In some countries or regions, use of Wi-Fi products may be

restricted by the local regulations (e.g. limited number of

channels).

Usage environment of NFC

If the device is placed on a metal desk, it may not function

properly, such as failing to communicate with the FeliCa card or

devices that support FeliCa. In this case, keep a few centimeters

between the device and the metal desk.

Applications on the device

Disclaimer: In no event will SONY be liable for any financial

damage, or loss of profits, including claims made by third

parties, arising out of the use of the software supplied with this

device.

Sony is not responsible for incomplete recording/downloading

or damaged data due to problems of the device or computer.

• Copyright laws prohibit reproducing the software or the

manual accompanying it in whole or in part, or renting the

software without the permission of the copyright holder.

• Due to continued efforts to improve quality, software

specifications may be changed without notice.

• Operation of this device with software other than that

provided is not covered by the warranty.

• Depending on the types of the text and characters, the text

shown on the device may not be displayed properly. This is

due to:

– The capacity of the device.

– The device is not functioning normally.

– Content information is written in a language or character

that is not supported by the device.

• We do not guarantee all languages will be able to be

displayed properly on your device.

• User-created characters and some special characters may not

be displayed.

Touchscreen

• Do not press the screen or screen frame strongly or rub the

screen. When operating the device, touch it softly.

• You can use the stylus while resting your hands on the

touchscreen. When the stylus is near the touchscreen, the

finger operation is inactive.

The device Disposal Reference

The built-in rechargeable battery of the device is recyclable. Do

not remove the battery yourself; consult the Sony Support

Center.

For customers in the USA

FCC Compliance Statement

NOTE:

This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that interference will not occur

in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of

the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for

help.

This DPT-RP1 has been tested and meets the FCC RF exposure

guidelines when used with the Sony Corporation accessories

supplied or designated for this product. Use of other

accessories may not ensure compliance with FCC RF exposure

guidelines.

If you have any questions about this product, you may call:

Sony Customer Information Center

1-800-222-SONY (7669) or

http://www.sony.com/

The number below is for the FCC related matters only.

Regulatory Information

Declaration of Conformity

Trade Name: SONY

Model No.: DPT-RP1

Responsible Party: Sony Electronics Inc.

Address: 16535 Via Esprillo, San Diego, CA92127 U.S.A.

Telephone Number: 858-942-2230

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1) this

device may not cause harmful interference, and (2) this

device must accept any interference received, including

interference that may cause undesired operation.

• In order to comply with FCC radio-frequency radiation

exposure guidelines for an uncontrolled exposure, this device

and its antenna must not be co-located or operating in

conjunction with any other antenna or transmitter.

FCC Radiation Exposure Statement

This equipment complies with FCC radiation exposure limits set

forth for an uncontrolled environment and meets the FCC radio

frequency (RF) Exposure Guidelines.

This equipment should be installed and operated keeping the

radiator at least 20 cm or more away from person’s body

(excluding extremities: hands, wrists, feet and ankles).

The available scientific evidence does not show that any health

problems are associated with using low power wireless devices.

There is no proof, however, that these low power wireless

devices are absolutely safe. Low power Wireless devices emit

low levels of radio frequency energy (RF) in the microwave

range while being used. Whereas high levels of RF can produce

health effects (by heating tissue), exposure of low-level RF that

does not produce heating effects causes no known adverse

health effects. Many studies of low-level RF exposures have not

found any biological effects. Some studies have suggested that

some biological effects might occur, but such findings have not

been confirmed by additional research. DPT-RP1 has been

tested and found to comply with FCC radiation exposure limits

set forth for an uncontrolled environment and meets the FCC

radio frequency (RF) Exposure Guidelines.

No guarantee for data

Sony is not responsible for damaged (or deleted) data due to

any problem with the device or computer.

Backup

Sony recommends that you make a backup of the contents of

the device in case of operation error or data corruption.

Legal Notice

contents of this manual (illustrations, related documents, etc.)

in whole or in part without the permission of the copyright

holder. Additionally, use of the data of this product or the

contents of this manual is not allowed without Sony’s

permission except for personal use.

• Sony, the Sony logo are either trademarks or registered

trademarks of Sony Corporation.

• Microsoft and Windows are trademarks or registered

trademarks of Microsoft Corporation in the United States and

/ or other countries.

• Macintosh and Mac OS are trademarks of Apple Inc.,

registered in the U.S. and other countries.

• This DPT-RP1 contains Adobe Reader Mobile software under

Adobe and Reader are trademarks of Adobe Systems

Incorporated.

• This product includes software developed by the OpenSSL

Project for use in the OpenSSL Toolkit.

• Wi-Fi, the Wi-Fi CERTIFIED logo, WPA, WPA2 and Wi-Fi

Protected Setup are trademarks or registered trademarks of

Wi-Fi Alliance.

• This software is based in part on the work of the Independent

JPEG Group.

• The N-Mark is a trademark or registered trademark of NFC

Forum, Inc. in the United States and in other countries.

All other system names and product names appearing in this

document are the registered trademarks or trademarks of their

respective owners.

Further, the trademark™ and registered trademark® symbols

are not indicated throughout this document.

Specifications

Model

DPT-RP1

Basic information

Display 338 mm (13.3 in) diagonal

electrophoretic display

1650 × 2200 pixel, 16-level

gray scale

Touchscreen Projected capacitive

touchscreen capable of pen

input

Internal memory capacity (for

data storage)/User available

capacity

16 GB/Approx. 11 GB

Interface Micro USB connector

Power source

Battery Built-in rechargeable battery

Operating/Charging

temperature

5 °C to 35 °C (41 °F to 95 °F)

Dimensions/Mass

Dimensions (w/h/d) Approx. 224 mm ×302.6 mm

× 5.9 mm (8 7/8 in × 12 in ×

1/4 in)

Mass (including battery) Approx. 349 g (12.3 oz)

Stylus

Battery Built-in rechargeable battery

Operating/Charging

temperature

5 °C to 35 °C (41 °F to 95 °F)

Design and specifications are subject to change without notice.

Supported File Types

The following files can be transferred between the device and

the computer. However, depending on the file size and format,

it may not be possible to view some data. File extensions are

shown in parentheses below.

Documents

• PDF files (.pdf)*

* Compliant with PDF 1.7 specifications.

The device does not support PDFs with extended features of Adobe extension

level 1-8.

Sony Group DPTRP1 Digital Paper User Manual DPT RP1

Sony Corporation Digital Paper DPT RP1

(Short-Term Confidential) User Manual

Navigation menu

Namespaces

Views

Navigation
