English Personal Audio System
Before operating the system, please read this guide thoroughly and retain it for
future reference.
Owner’s Record
The model number and the serial number are located on the bottom.
Record the serial number in the space provided below. Refer to them whenever
you call upon your Sony dealer regarding this product.
Model No. ICF-CS20BT
Serial No.
WARNING
DO NOT INGEST BATTERY, CHEMICAL BURN HAZARD
This product contains a coin/button cell battery. If the coin/button cell battery is
swallowed, it can cause severe internal burns in just 2 hours and can lead to
death.
Keep new and used batteries away from children. If the battery compartment
does not close securely, stop using the product and keep it away from children.
If you think batteries might have been swallowed or placed inside any part of the
body, seek immediate medical attention.
This graphical symbol is located on the bottom of the unit.
For customers in the USA:
Please register this product on line at http://www.sony.com/
productregistration.
For Customers in Canada:
Please register this product online at http://productregistration.sony.ca.
Proper registration will enable us to send you periodic updates about new
products, services and other important announcements. Registering your
product will also allow us to contact you in the unlikely event that the product
needs adjustment or modification. Thank you.
WARNING
To reduce the risk of fire or electric shock, do not expose this apparatus to
dripping or splashing, and do not place objects filled with liquids, such as vases,
on the apparatus.
Do not install the appliance in a confined space, such as a bookcase or built-in
cabinet.
As the main plug is used to disconnect the unit from the mains, connect the
system to an easily accessible AC outlet. Should you notice an abnormality in the
system, disconnect the main plug from the AC outlet immediately.
The system is not disconnected from the AC power source (mains) as long as it is
connected to the wall outlet, even if the system itself has been turned off.
Battery may explode if mistreated. Do not recharge, disassemble or dispose of in
fire.
On Copyrights and Licenses
The BLUETOOTH® word mark and logos are owned by the Bluetooth SIG, Inc. and
any use of such marks by Sony Corporation is under license.
The N Mark is a trademark or registered trademark of NFC Forum, Inc. in the
United States and in other countries.
Android and Google Play are trademarks of Google Inc.
iPad, iPhone, iPod, iPod classic, iPod nano, iPod touch and Mac are trademarks of
Apple Inc. registered in the U.S. and other countries.
Lightning is a trademark of Apple Inc.
“Made for iPod,” and “Made for iPhone” mean that an electronic accessory has
been designed to connect specifically to iPod or iPhone, respectively, and has
been certified by the developer to meet Apple performance standards. Apple is
not responsible for the operation of this device or its compliance with safety and
regulatory standards. Please note that the use of this accessory with iPod or
iPhone may affect wireless performance.
No Power No Problem is a trademark of Sony Corporation.
Auto Time Set is a trademark of Sony Corporation.
Other trademarks and trade names are those of their respective owners.
Notes
This system is not specified for use with an iPad via USB connection, and
malfunction may result if used with one.
In the Operating Instructions, “iPod” is used as a general reference to functions
on an iPod, iPhone or iPad, unless otherwise specified by the text or
illustrations.
CAUTION
You are cautioned that any changes or modifications not expressly approved in
this manual could void your authority to operate this equipment.
Danger of explosion if battery is incorrectly replaced. Replace only with the same
or equivalent type.
To reduce the risk of fire or electric shock, do not expose this apparatus to rain or
moisture.
NOTE
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This equipment must not be co-located or operated in conjunction with any other
antenna or transmitter.
The following FCC/IC statement applies only to the version of this model
manufactured for sale in the U.S.A. and Canada. Other versions may not comply
with FCC/IC technical regulations.
This equipment complies with FCC/IC radiation exposure limits set forth for an
uncontrolled environment and meets the FCC radio frequency (RF) Exposure
Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF)
Exposure rules. This equipment has very low levels of RF energy that it deemed to
comply without maximum permissive exposure evaluation (MPE). But it is
desirable that it should be installed and operated keeping the radiator at least 20
cm or more away from person’s body (excluding extremities: hands, wrists, feet
and ankles).
For customers in Canada
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings.
Install in accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding
type plug has two blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long
periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
Precautions
Note when using with a mobile phone
For details on operation of your mobile phone when receiving a telephone call
while transmitting the sound using the BLUETOOTH connection, refer to the
operating instructions supplied with the mobile phone.
On safety
The nameplate indicating Sony trademark, model number and electrical rating is
located on the bottom exterior of this system.
Notes on the AC plug
Plug the AC plug into a nearby wall outlet (mains). In the case of a problem,
unplug it from the wall outlet (mains) immediately.
Do not twist or place heavy objects on the AC plug cord.
To disconnect AC power, grasp the plug itself, not the cord.
On placement
Do not set the speaker in an inclined position.
Do not leave the system in a location near heat sources, or in a place subject to
direct sunlight, excessive dust, moisture, rain or mechanical shock.
Do not expose the battery to excessive heat such as direct sunlight, fire or the
like.
On operation
Do not insert any small objects, etc., into the jacks. The system may short out or
malfunction.
On cleaning
Do not use alcohol, benzine, or thinner to clean the cabinet.
Others
If you have any questions or problems concerning this system that are not
covered in this manual, please consult your nearest Sony dealer.
FOR UNITED STATES CUSTOMERS. NOT APPLICABLE IN CANADA,
INCLUDING IN THE PROVINCE OF QUEBEC.
This symbol is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in
the literature accompanying the appliance
The Caution Marking is put on the Bottom Enclosure.
Getting Started
Connecting to a Power Source
1 Plug the AC plug into a wall outlet firmly.
About the battery as a backup power source
This system contains a CR2032 battery as a backup power source to keep the
clock and the alarm operating during a power interruption. (No Power No
Problem system)
CAUTION
When to replace the battery
When the battery becomes weak, “” lights up in the display.
If a power interruption occurs while the battery is weak, the current time and
alarm will be erased.
Replace the battery with a Sony CR2032 lithium battery. Use of another battery
may cause a fire or explosion.
To replace the battery, see “Replacing the Battery” for details.
Note
If “AM 12:00” flashes in the display when the system is connected to an AC outlet for the first
time, the battery may be weak. In this case, consult your nearest Sony dealer.
Setting the Clock
Right side of the system
Setting the clock for the first time
This system is preset to the current EST (Eastern Standard Time) at the factory,
and is powered by a backup battery. All you need to do the first time is just plug it
in and select your time zone.
1 Plug in the system.
The current EST (Eastern Standard Time) lights up in the display.
2 Press and hold OFF and CLOCK until area number “2”
begins to flash in the display.
3 Press ALARM TIME SET +/– to select the number as
follows:
Area number Time zone
0 Newfoundland Standard Time
1 Atlantic Standard Time
2 (default setting) Eastern Standard Time
3 Central Standard Time
4 Mountain Standard Time
5 Pacific Standard Time
6 Alaska Standard Time
7 Hawaii Standard Time
4 Press DISPLAY/ENTER to confirm.
Notes
To cancel the time zone setting, press OFF instead of DISPLAY/ENTER in step 4.
Though the clock is correctly set at the factory, discrepancies may arise during transport or
storage. If necessary, set the clock to the correct time by referring to “Setting the clock
manually.”
When daylight saving time (DST/summer time) begins
This system automatically adjusts for daylight saving time (summer time).
“” lights up from the beginning of daylight saving time (summer time) and turns
off at the end of the daylight saving time (summer time) automatically.
Daylight saving time (summer time) begins at: 2:00 AM on the second Sunday
of March.
Standard time begins at: 2:00 AM on the first Sunday of November.
To cancel Auto DST/summer time adjustment during the daylight
saving time (summer time) period
The Auto DST/summer time adjustment can be canceled.
While the clock is displayed, press and hold OFF and DISPLAY/ENTER until
“” and “OFF” light up in the display. Auto DST/summer time adjustment has
been canceled, then the display returns to the clock.
To activate Auto DST/summer time adjustment again, press and hold OFF and
DISPLAY/ENTER until “ ” and “On” light up in the display.
Notes
Changes to Auto DST/summer time adjustment by the system (see above) are subject to
circumstances and laws in each country/region. Should this interfere with desired
adjustment, cancel the Auto DST/summer time adjustment and set the DST display manually
as necessary. Customers living in a country/region that does not use daylight saving time
(summer time) must cancel Auto DST/summer time adjustment before using the system.
When Hawaii Standard Time is set, Auto DST/summer time adjustment defaults to off. You
can turn it on by the above operation.
Setting the clock manually
To change the clock setting manually, operate the system as follows.
1 Plug in the system.
2 Press and hold CLOCK until the year digits begin to flash
in the display.
3 Press ALARM TIME SET +/– to select the year, and then
press CLOCK to confirm.
Press and hold ALARM TIME SET +/– to change the year digits quickly.
Once you confirm the setting by pressing CLOCK , the month digits begin
to flash.
4 Repeat step 3 to set the month, day, hour and minute.
The seconds start incrementing from zero.
Notes
If you do not press any button for about 1 minute while setting the clock, the clock setting will
be canceled.
A 100-year calendar (2013 - 2112) is installed in the system. When the date is set, the day of
the week is automatically displayed.
MON = Monday, TUE = Tuesday, WED = Wednesday,
THU = Thursday, FRI = Friday, SAT = Saturday, SUN = Sunday
To change the time format
You can choose the displayed time format between the 12-hour system (default)
or the 24-hour system.
Press and hold OFF and SNOOZE/BRIGHTNESS for about 2 seconds.
The time format toggles between the 12-hour system (“AM 12:00” = midnight) and
the 24-hour system (“0:00” = midnight).
To display the year and date
While the clock is displayed, press CLOCK once to display the month and date,
and press again to display the year. To return to the current time display, press
CLOCK once again; or after a few seconds the display will return automatically.
Connecting the AM Loop Antenna
The shape and length of the antenna is designed to receive AM signals. Do not
dismantle or roll up the antenna.
1 Raise the plastic stand and fit the antenna into the slot of
the stand.
Press the antenna into the
stand until it clicks.
Plastic stand
2 Insert the AM antenna connector in the AM ANTENNA jack
on the rear of the system.
To remove the AM loop antenna
Push and hold down the tab of the antenna terminal clamp, and remove the AM
loop antenna.
How to Make Wireless Connection with
BLUETOOTH Devices
You can enjoy music and hands-free calling with the system wirelessly by using
your device’s BLUETOOTH function.
Choose one of the following three connection methods, best suited for the
BLUETOOTH device. For details on how to operate your device, refer to the
operating instructions supplied with the device.
Pairing with a BLUETOOTH device: see Pattern A
BLUETOOTH devices need to be “paired” with each other beforehand.
Connecting with a paired device: see Pattern B
To listen to music with a BLUETOOTH device that has been paired, see this
pattern.
One-touch connection with a smartphone (NFC):
see Pattern C
Using an NFC compatible smartphone, you can establish BLUETOOTH connection
by just touching the system with it.
For details about NFC, see “About NFC” in Pattern C .
Check the following before operating the system.
Both the system and the device are placed within 1 m (3 ft) of each other.
The system is connected to a power source.
The operating instructions supplied with the device are kept at hand.
Pattern A
Pairing and connecting with a BLUETOOTH device
1 Set the BLUETOOTH function of the BLUETOOTH device to
on.
For details, refer to the operating instructions supplied with the device.
2 Press and hold BLUETOOTH PAIRING on the system
until beeps are heard and “ (BLUETOOTH)” begins to flash
quickly in the display.
Tip
From the factory, pairing information is not stored in the system. In this case, if you only
press BLUETOOTH PAIRING , the system will beep and “ (BLUETOOTH)” starts
flashing quickly in the display.
(BLUETOOTH)
flashes quickly
3 Perform the pairing procedure on the BLUETOOTH device to
detect the system.
If “SONY: ICF-CS20BT” does not appear on the device’s display, repeat from
step 1.
Note
Some devices cannot display a list of detected devices.
4 Select “SONY: ICF-CS20BT” shown in the display of the
BLUETOOTH device.
5 If Passcode* input is required on the display of the
BLUETOOTH device, input “0000.”
The BLUETOOTH connection is established and “ (BLUETOOTH)” in the display
stays on.
* Passcode may be called “Passkey,” “PIN code,” “PIN number,” or “Password.”
Tip
To pair with other BLUETOOTH devices, repeat steps 1 to 5 for each device.
Notes
Pairing mode of the system is canceled after about 5 minutes, and “ (BLUETOOTH)” in the
display flashes slowly. If the pairing mode is canceled while performing this procedure, start
over from step 2.
Passcode of the system is fixed as “0000.” The system cannot be paired with a BLUETOOTH
device whose Passcode is not “0000.”
Once BLUETOOTH devices are paired, there is no need to pair those devices again. However,
in the following cases, you will need to perform the pairing procedure again.
Pairing information is deleted after repair, etc.
The system is paired with 5 or more devices.
The system can be paired with up to 4 BLUETOOTH devices. If a new device is paired after 4
devices have been paired, the device whose latest connection time is the oldest among the
4 paired devices is replaced by the new one.
More than one device can be paired with the system, but sound will be heard from just one
of those devices.
Pattern B
Connecting with a paired BLUETOOTH device
1 Set the BLUETOOTH function of the BLUETOOTH device to
on.
Tips
When BLUETOOTH is pressed, the system tries to establish BLUETOOTH connection
with the BLUETOOTH device connected to the system last time. The BLUETOOTH
connection is established and “ (BLUETOOTH)” in the display stays on.
When “ (BLUETOOTH)” lights up in the display, the system is connected to a BLUETOOTH
device. When you want to connect another BLUETOOTH device, terminate the current
BLUETOOTH connection first by operating the connected BLUETOOTH device.
2 Select “SONY: ICF-CS20BT” shown in the display of the
BLUETOOTH device.
If necessary, select a BLUETOOTH profile that the system supports from the
following: A2DP, HSP or HFP. For details on each profile, see “Listening to
Music by BLUETOOTH Connection with a Smartphone, etc.” or “Using
Hands-free Calling While Listening to Music.”
Note
This step may not be necessary for some devices.
The BLUETOOTH connection is established and “ (BLUETOOTH)” in the display
stays on.
Pattern C
Connecting with a smartphone by One touch (NFC)
By just touching the system with an NFC compatible smartphone, the system
pairs and connects with the smartphone. (After making the BLUETOOTH
connection, the system switches to the BLUETOOTH function automatically.)
Compatible smartphones
Smartphones with the NFC function built-in
(OS: Android 2.3.3 or later, excluding Android 3.x)
Customers in the U.S.A.
Access the following Web site for details:
http://esupport.sony.com/US
Customers in Canada
Access the following Web site for details:
http://esupport.sony.com/CA
About NFC
NFC (Near Field Communication) is a technology enabling short-range wireless
communication between various devices, such as mobile phones and IC tags.
Thanks to the NFC function, data communication can be achieved easily just by
touching the relevant symbol or designated location on NFC compatible devices.
1 Set the NFC function of the smartphone to on.
For details, refer to the operating instructions supplied with the smartphone.
If your smartphone OS is Android 2.3.3 or later, and less than Android 4.1:
proceed to step 2.
If your smartphone OS is Android 4.1 or later: proceed to step 4.
2 Download and install the app “NFC Easy Connect” on the
smartphone.
“NFC Easy Connect” is an original app by Sony for Android phones, and is
available at Google Play Store.
Search for “NFC Easy Connect” or scan the following two-dimensional code to
download and install the free app. Communication fees are required to
download the app.
The App may not be available in some countries and/or regions.
Tip
For some smartphones, One-touch connection may be available without downloading
the app “NFC Easy Connect.” In that case, the operation and specifications may be
different from the description here. For details, refer to the operating instructions
supplied with the smartphone.
By the two-dimensional code:
Use a two-dimensional code reader app.
3 Start the app “NFC Easy Connect” on the smartphone.
Make sure that the application screen is displayed.
4 Touch the system with the smartphone.
Keep touching the smartphone on the N marked part of the system until the
smartphone responds.
Note
If the screen of your smartphone is locked, the smartphone will not function. In this case,
release the lock, then touch the smartphone on the N marked part again.
Smartphone responds (system recognized)
(BLUETOOTH) lights up
Follow the on-screen instructions to establish the connection.
The BLUETOOTH connection is established and “ (BLUETOOTH)” in the display
stays on.
Tips
If it is difficult to establish the connection, try the following.
Activate the app “NFC Easy Connect” and move the smartphone slightly on the N
marked part of the system.
If the smartphone is in a case, remove it.
Touch the system with the smartphone again to disconnect.
If you have multiple NFC compatible devices, just touch the smartphone to a different
device to switch the connection to that device. For example, when your smartphone is
connected with NFC compatible headphones, just touch the smartphone to the system to
change the BLUETOOTH connection to the system.
Indications of the BLUETOOTH function
Status Display
BLUETOOTH function “BLUETOOTH” lights up
Pairing with a device “ (BLUETOOTH)” flashes quickly
Searching for a device “ (BLUETOOTH)” flashes
Connected to a device “ (BLUETOOTH)” lights up
Listening to Music
Listening to Music by BLUETOOTH
Connection with a Smartphone, etc.
You can enjoy listening to music and basic remote control operation of a
BLUETOOTH device via BLUETOOTH connection. The BLUETOOTH device is
required to support the following BLUETOOTH profiles.
A2DP (Advanced Audio Distribution Profile): enables you to enjoy high-quality
audio content wirelessly.
AVRCP (Audio Video Remote Control Profile): enables you to enjoy basic remote
control operation (play, stop, etc.) of a BLUETOOTH device.
Operations may vary depending on the BLUETOOTH device. Refer also to the
operating instructions supplied with your BLUETOOTH device.
1 Make the BLUETOOTH connection between the system and
the device.
For details on the BLUETOOTH connection procedure, see “How to Make
Wireless Connection with BLUETOOTH Devices.” The BLUETOOTH connection is
established and “ (BLUETOOTH)” in the display stays on.
2 Start playback on the BLUETOOTH device, then adjust the
volume.
Set the volume of the BLUETOOTH device to a moderate level, and press
VOLUME –/+ on the system.
After use
Do any of the following to terminate the BLUETOOTH connection.
Set the BLUETOOTH function of the BLUETOOTH device to off. For details, refer
to the operating instructions supplied with the device.
Turn off the BLUETOOTH device.
Touch the system with the smartphone again to disconnect (NFC compatible
smartphones only).
System button functions during music playback
You can operate a BLUETOOTH device that supports AVRCP. Available functions
may vary depending on the BLUETOOTH device. Refer to the operating
instructions supplied with the BLUETOOTH device.
Buttons Functions
(play/pause) Press once to pause/resume playback.
/ (forward/
rewind)
Press once to skip to the next/previous track.
Press and hold to fast-forward/fast-rewind.
VOLUME –/+ Press to adjust the volume.
Listening to Music by Wired Connection
Listening to Music via USB Connection with an
iPhone/iPod
You can enjoy listening to music and play back an iPhone/iPod connected to the
system via USB.
Update your device to the latest software version before use.
USB cable*
(not supplied)
(USB) port on the rear of the system
* USB cable: Use the Lightning to USB Cable or Dock Connector
to USB Cable supplied with your iPhone/iPod.
1 Connect the iPhone/iPod to the (USB) port on the rear of
the system.
2 Press FUNCTION to select “USB.”
Press FUNCTION repeatedly until “USB” lights up in the display.
3 Start playback on the connected iPhone/iPod, then adjust
the volume.
Set the volume of the connected iPhone/iPod to a moderate level, and press
the VOLUME –/+ on the system.
Notes
When a USB device other than an iPhone/iPod is connected to the system, only charging
begins automatically.
Do not connect the multiple devices to the (USB) port of the system.
After use
Press FUNCTION or OFF to deactivate the USB function.
System button functions during music playback
Buttons Functions
(play/pause) Press once to pause/resume playback.
/ (forward/
rewind)
Press once to skip to the next/previous track.
Press and hold to fast-forward/fast-rewind.
VOLUME –/+ Press to adjust the volume.
Listening to Music by Wired Connection with a
Portable Audio Device, etc.
You can enjoy sound from the external device, such as a portable digital music
player, through the speaker of this system. Be sure to turn off the power of the
device before making any connections.
AUDIO IN jack (stereo mini jack)
on the rear of the system
Connecting cord
(not supplied)
1 Connect the device to the AUDIO IN jack on the rear of the
system.
2 Press FUNCTION to select “AUDIO IN.”
Press FUNCTION repeatedly until “AUDIO IN” lights up in the display.
3 Start playback on the connected device, then adjust the
volume.
Set the volume of the connected device to a moderate level, and press the
VOLUME –/+ on the system.
After use
Press FUNCTION or OFF to deactivate the AUDIO IN function. To stop
playback on the connected device, operate the connected device.
Notes when connecting the device by wired connection
The necessary type of cable or connecting cord depends on the device. Be sure to use the
correct type of cable or cord.
When you watching TV or listening to the radio with a device connected to the system, the
reception may be poor.
When you listen to the radio with a device connected, turn off the connected device to
prevent noise. If noise occurs, even when the device is turned off, disconnect and place the
device away from the system.
Tip
You can use hands-free calling while the cable or connecting cord is used with this system.
Listening to Radio
FM wire
antenna
Rear of the system
Right side of the system
Presetting the radio stations automatically - Auto
preset tuning
You can preset receivable radio stations in your area automatically by auto preset
tuning. You can preset up to 20 FM stations and 10 AM stations.
1 Press FUNCTION to select “FM” or “AM.”
Press FUNCTION repeatedly until “FM” or “AM” lights up in the display.
2 Press and hold FUNCTION AUTO PRESET until “AP”
begins to flash in the display.
3 Press DISPLAY/ENTER .
Receivable radio stations will be preset automatically in order of frequency.
Tip
To cancel auto preset tuning, press OFF .
Listening to the radio from preset radio stations
You can listen to the radio simply by selecting a preset number. Although radio
frequencies are preset at the factory, we recommend you to preset receivable
radio stations in your area by auto preset tuning.
1 Press FUNCTION to select “FM” or “AM.”
Press FUNCTION repeatedly until “FM” or “AM” lights up in the display.
2 Press MODE to select “PRESET.”
3 Press PRESET +/– to select the preset number for the
desired radio station.
4 Press VOLUME –/+ to adjust the volume.
To display the preset number and the frequency when listening
to radio
Press DISPLAY/ENTER once to display the preset number, and press again to
display the frequency of the current station. To return to the clock display, press
DISPLAY/ENTER once again; or after a few seconds the display will return
automatically.
After use
Press FUNCTION or OFF to deactivate the radio function.
To improve reception
For FM radio reception, extend the FM wire antenna fully to increase reception
sensitivity.
For AM radio reception, connect the supplied AM loop antenna to the system.
Rotate the antenna horizontally for optimum reception.
If stereo FM reception is noisy, press and hold MODE until “MONO” lights up
in the display. You will lose the stereo effect, but noise will be reduced.
Listening to the radio by manual tuning
1 Press FUNCTION to select “FM” or “AM.”
Press FUNCTION repeatedly until “FM” or “AM” lights up in the display.
2 Press MODE to select “TUNING.”
3 Press and hold TUNE +/– until the frequency digits begin
to change quickly in the display.
The system automatically scans the radio frequencies and stops when it finds
a clear station (automatic tuning mode).
If you cannot tune to a station using the automatic tuning mode, press TUNE
+/– repeatedly to change the frequency step by step.
When an FM stereo broadcast is received, “ST” lights up in the display.
4 Press VOLUME –/+ to adjust the volume.
To preset radio stations manually
You can manually preset a radio station which cannot be preset automatically.
1 Tune to a station you want to preset.
2 Press and hold DISPLAY/ENTER until “PRESET” begins to
flash in the display.
3 Press PRESET +/– to select the preset number, and then
press DISPLAY/ENTER to confirm.
The station is preset and assigned to the selected preset number.
Example: The following displays appear when you preset FM 89.8 MHz to
preset number 2 for FM.
Tip
To cancel the preset number, press OFF instead of DISPLAY/ENTER in step 3.
Notes on radio reception
Do not place the AM loop antenna near the system, power supply or other A/V equipment
during use, as noise may result.
Keep digital music players or mobile phones away from the AM loop antenna or the FM
antenna, as this may lead to reception interference.
When you are listening to radio with a BLUETOOTH device or USB device connected to the
system, interference with radio reception may occur. In this case, terminate BLUETOOTH
connection, or disconnect the USB device from the system.
Tip
You can use hands-free calling while listening to the radio on this system.
Personal Audio System
Operating Instructions
ICF-CS20BT
©2013 Sony Corporation Printed in China
4-468-397-11(1)
ICF-CS20BT [U2] (US) 4-468-397-11(1)
Useful Functions
Using Hands-free Calling While Listening
to Music
You can enjoy hands-free calling via BLUETOOTH connection with a BLUETOOTH
mobile phone that has a music function and supports the BLUETOOTH profile
A2DP (Advanced Audio Distribution Profile), and HFP (Hands-free Profile) or HSP
(Headset Profile).
If your BLUETOOTH mobile phone supports both HFP and HSP, set to HFP.
Operations may vary depending on the BLUETOOTH mobile phone. Refer also to
the operating instructions supplied with your mobile phone.
1 Make the BLUETOOTH connection between the system and
the mobile phone.
For details on the BLUETOOTH connection procedure, see “How to Make
Wireless Connection with BLUETOOTH Devices.” The BLUETOOTH connection is
established and “ (BLUETOOTH)” in the display stays on.
2 Start playback on the BLUETOOTH mobile phone, then
adjust the volume.
Set the volume of the BLUETOOTH mobile phone to a moderate level, and
press VOLUME –/+ on the system.
When the BLUETOOTH device is connected to the system (“ (BLUETOOTH)” is
lit), you can use hands-free calling even if the BLUETOOTH function is not
activated.
When there is an incoming call or outgoing call, the system automatically
changes to the BLUETOOTH function.
To call
Operate the BLUETOOTH mobile phone. Check that a dialing tone is heard on the
system and talk into the system. If no dialing tone is heard, press (call) on
the system for about 2 seconds to change the call device to the system.
To receive a call
When an incoming call arrives, the playback or radio pauses and a ring tone is
heard from the system. Press (call) on the system and talk into the system.
Tips
If no ring tone is heard from the system when an incoming call arrives, stop playback or radio
and press (call) to talk.
You can use the hands-free calling when playback is completed.
During a call, press VOLUME –/+ on the system to adjust the volume. The volume of a call
and that of a playback are set separately.
Note
When using a mobile phone, keep it 50 cm or more away from the system. If they are too
close together, noise may be heard.
To end a call
Press (call) . If you were listening to music with any function when the call
arrived, music will be resumed when the call has finished.
After use
Do any of the following to terminate the BLUETOOTH connection.
Set the BLUETOOTH function of the BLUETOOTH device to off. For details, refer
to the operating instructions supplied with the device.
Turn off the BLUETOOTH device.
Touch the system with the smartphone again to disconnect (NFC compatible
smartphones only).
System button functions during a call
Available functions may vary depending on the BLUETOOTH mobile phone, or the
profiles supported by the BLUETOOTH mobile phone. Refer to the operating
instructions supplied with the BLUETOOTH mobile phone.
Status (call)
Standby Press once to start voice dial (voice dial compatible
mobile phones only).
Press and hold for a few seconds to redial the phone
number that is dialed last time.
Outgoing call Press once to cancel outgoing call.
Press and hold for a few seconds to change call
device between the system and mobile phone.
Incoming call Press once to answer call.
Press and hold for a few seconds to reject call.
During call Press once to finish call.
Press and hold for a few seconds to change call
device between the system and mobile phone.
Using Hands-free Calling with Another BLUETOOTH Mobile Phone
While Listening to Music
You can enjoy hands-free calling with another BLUETOOTH mobile phone while
listening to music with a BLUETOOTH music player.
One-touch connection (NFC) cannot be used in this procedure.
Operations may vary depending on the BLUETOOTH device. This type of
BLUETOOTH connection may not be established depending on the combination
of the BLUETOOTH devices. Refer also to the operating instructions supplied
with your BLUETOOTH devices.
1 Make the BLUETOOTH connections between the system
and a BLUETOOTH music player via A2DP, and between the
system and a BLUETOOTH mobile phone via HFP or HSP.
For details on the BLUETOOTH connection procedure, see “How to Make
Wireless Connection with BLUETOOTH Devices.” The BLUETOOTH connection is
established and “ (BLUETOOTH)” in the display stays on.
Tips
To use only the calling function of a BLUETOOTH mobile phone that also has a music
function, establish BLUETOOTH connection between the system and the mobile phone
via HFP or HSP, not via A2DP.
Depending on the BLUETOOTH mobile phone, while the BLUETOOTH connection is
established via HFP or HSP, the other BLUETOOTH connection via A2DP may also be
occupied by the same BLUETOOTH mobile phone. A BLUETOOTH music player cannot be
connected with this system in this case.
Note
To make the same connection with the same devices after turning the system off, follow
this procedure again.
Setting the Alarm
You can set the alarm mode from the following.
“FM,” “AM”: Set the radio alarm.
“USB”: Set the alarm to sound from an iPhone/iPod via USB connection.
“BLUETOOTH”: Set the alarm to sound from a BLUETOOTH device, such as
smartphone, iPod, etc., via BLUETOOTH connection.
“BUZZER”: Set the buzzer alarm.
Set the clock to the current time before setting the alarm, so that the alarm will
sound at the correct time. (See “Setting the clock for the first time.”)
Right side of the system
You can set alarm A and B. To set the alarm A, use A and ALARM TIME SET
+/– . To set alarm B, use B and ALARM TIME SET +/– .
The following explains how to set the alarm A.
1 Press and hold A until the hour begins to flash in the
display.
“” and “WAKE UP” light up and the hour flashes in the display.
2 Press ALARM TIME SET +/– to select the following setting
items, then press A to confirm.
Each time you press ALARM TIME SET +/– , the currently selected item
begins to flash.
Once you confirm the setting by pressing A , the following setting item
begins to flash.
Hour, minute: Press and hold ALARM TIME SET +/– to change the hour
and minute digits quickly.
Days of the week: Select one of the following three types.
Every day: “MON TUE WED THU FRI SAT SUN”
Week day: “MON TUE WED THU FRI”
Weekend: “SAT SUN”
3 Press ALARM TIME SET +/– to select the alarm mode, then
press A to confirm.
Select one of the following.
“FM,” “AM”: Set the radio alarm. Proceed to step 4.
“USB”: Set the alarm to sound from an iPhone/iPod via USB connection.
Skip step 4, and proceed to step 5.
“BLUETOOTH”: Set the alarm to sound from a BLUETOOTH device, such as
smartphone, iPod, etc., via BLUETOOTH connection. Skip step 4, and proceed
to step 5.
“BUZZER”: Set the buzzer alarm. The alarm setting is completed. The
display returns to clock and “” lights up in the display. You do not need to
do step 4 or later.
4 Press ALARM TIME SET +/– to select the radio station,
then press A to confirm.
Select the desired preset number or “- -.” “- -” is the last station you listened
to.
5 Press ALARM TIME SET +/– to adjust the volume, then
press A to confirm.
The alarm setting is completed. The display returns to clock and “” lights up
in the display.
6 When “USB” or “BLUETOOTH” is selected as the alarm
mode, connect an iPhone/iPod via USB or a BLUETOOTH
device before the alarm sounds.
If the system does not connect to the BLUETOOTH device, at the alarm time,
the system tries to establish BLUETOOTH connection with the BLUETOOTH
device connected to the system last time.
If the system cannot connect to the BLUETOOTH device, or does not connect
to an iPhone/iPod via USB, the alarm will be the buzzer.
If you set “USB” as the alarm mode, and a smartphone is connected via USB,
the alarm will be the buzzer.
To stop the alarm
Press ALARM RESET to turn off the alarm. The alarm will sound again at the
same time the next day.
To doze for a few more minutes – Snooze function
1 Press SNOOZE once while the alarm sounds.
The alarm sound turns off but will automatically come on again after about 10
minutes.
You can change the snooze time as follows by pressing SNOOZE
repeatedly.
To stop the snooze timer, press ALARM RESET .
System button functions for the alarm function
To Do this
Confirm an alarm
time setting Press ALARM TIME SET +/– .
The setting will be displayed for about 4 seconds.
Change an alarm
time setting 1 Press and hold ALARM TIME SET +/– until the
alarm time digits begin to change in the display.
You can change the alarm time step by step by
pressing ALARM TIME SET +/– repeatedly.
2 Release ALARM TIME SET +/– when the desired
alarm time is displayed.
Turn off the alarm
sound once Press SNOOZE once while the alarm sounds.
Stop the alarm Press ALARM RESET .
Deactivate the alarm Press A again.
“” turns off in the display, and the alarm function is
deactivated.
To activate the alarm again, press A again.
Tip
Even if the alarm is deactivated, the alarm will be activated when you change the alarm
setting.
Notes
When “USB” or “BLUETOOTH” is selected as the alarm mode, only the buzzer alarm will sound
if an iPhone/iPod is not connected via USB, or a BLUETOOTH device is not connected, or
music is not stored in the device, or the device is turned off.
When Auto DST/summer time adjustment is set, the alarm sounds as follows:
If the alarm is set between 2:00 AM and 3:00 AM, and daylight saving time begins, the
alarm will sound at 3:00 AM.
If the alarm is set between 1:00 AM and 2:00 AM, and daylight saving time ends, the alarm
will sound twice.
The volume of the buzzer is not adjustable.
If the same alarm time is set for both alarm A and B, alarm A takes priority.
If no operation is performed while the alarm is sounding, the alarm will stop after about 60
minutes.
Notes on the alarm in the event of a power interruption
In the event of a power interruption, the buzzer alarm will last about 5 minutes if the battery is
not weak. However, certain functions will be affected as follows:
The backlight will not light up.
If the alarm mode is set to “USB,” “BLUETOOTH,” “FM” or “AM,” it will change to buzzer
automatically.
If ALARM RESET is not pressed, the alarm will sound for about 5 minutes.
If “” lights up in the display, the alarm will not sound in the event of a power interruption.
Replace the battery if “” lights up.
The snooze function cannot be set during a power interruption.
During a power interruption, each alarm will sound at the set time only once.
Setting the Sleep Timer
You can fall asleep listening to radio or music from the connected device using
the sleep timer. The system stops radio or playback automatically after a preset
duration.
Right side of the system
1 Press SLEEP while listening to radio or music.
“SLEEP” lights up and the sleep time duration begins to flash in the display.
2 Press SLEEP to select the sleep time duration.
You can change the sleep time duration (in minutes) as follows by pressing
SLEEP repeatedly. Only “OFF” does not flash.
The sleep time duration flashes for a few seconds, then the display returns to
the clock. The sleep timer setting is completed and the sleep timer starts.
“SLEEP” lights up in the display, and the system will stop radio or playback
automatically after the setting duration.
To stop listening before the preset time
Press OFF .
To change the sleep timer setting
Press SLEEP . You can change the sleep time duration after the sleep timer has
been activated.
To deactivate the sleep timer
Press SLEEP to select “OFF.”
Notes
Music playback on a device connected to the AUDIO IN jack does not stop automatically. To
stop playback on the connected device, operate the connected device.
When the alarm time is set during the sleep timer duration, the sleep timer will be
deactivated automatically when the alarm sounds.
To Enjoy the Sound Effect Setting
1 Press SOUND to select the sound effect.
The sound effect setting lights up in the display.
You can change the sound effect as follows by pressing SOUND
repeatedly.
Display Sound effect
MEGA BASS High-quality bass sound will be heard.
MEGA BASS
MEGA Xpand
Both high-quality bass and surround sound will be
heard.
MEGA Xpand Surround sound will be heard.
Off The sound effect is off.
Others
Replacing the Battery
1 Keep the AC plug connected to the wall outlet, then open
the battery compartment on the bottom of the system.
1 Fully loosen the screw.
2 Push the tab and
pull up the lid.
2 Remove the old battery and insert a new one in the battery
compartment with the side facing up.
CR2032
3 Replace the battery compartment lid and tighten the
screw.
4 Press FUNCTION, BLUETOOTH or SNOOZE/ BRIGHTNESS
on the system to turn off “” in the display.
Notes
When you replace the battery, do not disconnect the plug from the AC outlet. Otherwise, the
current date, current time, alarm and station presets will be erased.
If you are not going to use the system for a long time, remove the battery to avoid any
damage that may be caused by leakage or corrosion.
Setting the Brightness of the Display
1 Press BRIGHTNESS .
You can change the four levels of brightness as follows by pressing
BRIGHTNESS repeatedly.
High (default)
Low
Off
Middle
Even if brightness level is set to Off, it will change to Low while the alarm is
sounding.
Press and hold BRIGHTNESS to turn off the display directly.
Specifications
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION:
With 5 ohm loads both channels driven, from 150 Hz -
10,000 Hz; rated 2 watts per channel minimum RMS power, with
no more than 10 % total harmonic distortion.
Time display
Switching between 12-hour system (default) and 24-hour system.
Speaker section
Speaker system 50 mm (2 in)
Enclosure type Bass reflex
Amplifier section
Reference output power
2 W + 2 W (10 % T.H.D., 1 kHz, 5 )
Input Stereo mini jack × 1
USB section
Input USB port (type A)
Supported sampling frequencies/bit
USB input: Maximum 44.1 kHz/16 bit
BLUETOOTH
Communication System
BLUETOOTH Specification version 3.0
Output BLUETOOTH Specification Power Class 2
Maximum communication range
Line of sight approx. 10 m (30 ft)*1
Frequency band 2.4 GHz band (2.4000 GHz - 2.4835 GHz)
Modulation method
FHSS
Compatible BLUETOOTH Profiles*2
A2DP (Advanced Audio Distribution Profile)
AVRCP (Audio Video Remote Control Profile)
HSP (Headset Profile)
HFP (Hands-free Profile)
SPP (Serial Port Profile)
Supported Codec*3
SBC*4
Transmission range (A2DP)
20 Hz - 20,000 Hz (Sampling frequency 44.1 kHz)
*1 The actual range will vary depending on factors such as obstacles between
devices, magnetic fields around a microwave oven, static electricity, reception
sensitivity, antenna’s performance, operating system, software application, etc.
*2 BLUETOOTH standard profiles indicate the purpose of BLUETOOTH
communication between devices.
*3 Codec: Audio signal compression and conversion format
*4 Subband Codec
Microphone
Type: Electret condenser
Direction characteristic:
Omni directional
Effective frequency range:
200 Hz – 3,600 Hz
Radio
Frequency range
Band Frequency Frequency step
FM 87.5 MHz - 108 MHz 0.1 MHz
AM 530 kHz - 1,710 kHz 10 kHz
General
Power 120 V AC, 60 Hz, 16 W
For clock back up 3V DC, CR2032 battery (1)
Dimensions Approximately 281 mm × 126 mm × 80 mm
(11 / in × 5 in × 3 / in) (w/h/d)
Mass Approximately 1.3 kg (2 lb 14 oz) including batteries
Supplied accessories
AM loop antenna (1)
BLUETOOTH Startup Guide (1)
Operating Instructions (this document) (1)
Compatible iPhone/iPad/iPod models
The compatible iPhone/iPad/iPod models are as follows.
Update the software of the iPhone/iPad/iPod to the latest version before using it
with this system.
USB works with
iPhone 5
iPhone 4S
iPhone 4
iPod touch (5th generation)
iPod touch (4th generation)
iPod touch (3rd generation)
iPod classic
iPod nano (7th generation)
iPod nano (6th generation)
iPod nano (5th generation)
iPod nano (4th generation)
BLUETOOTH technology works with
iPhone 5
iPhone 4S
iPhone 4
iPhone 3GS
iPad (4th generation)
iPad mini
iPad (3rd generation)
iPad 2
iPad
iPod touch (5th generation)
iPod touch (4th generation)
iPod touch (3rd generation)
iPod nano (7th generation)
Design and specifications are subject to change without notice.
What is BLUETOOTH wireless
technology?
BLUETOOTH wireless technology is a short-range wireless technology that
enables wireless data communication between digital devices, such as a
computer and digital camera. BLUETOOTH wireless technology operates within a
range of about 10 m (30 ft).
Connecting two devices as necessary is common, but some devices can be
connected to multiple devices at the same time.
You do not need to use a cable for connection, nor is it necessary for the devices
to face one another, such is the case with infrared technology. For example, you
can use such a device in a bag or pocket.
BLUETOOTH standard is an international standard supported by thousands of
companies all over the world, and employed by various companies worldwide.
Communication System and Compatible BLUETOOTH Profiles of
the system
Profile is standardisation of the function for each BLUETOOTH device specification.
The system supports the following BLUETOOTH version and profiles:
Communication System:
BLUETOOTH Specification version 3.0
Compatible BLUETOOTH Profiles:
A2DP (Advanced Audio Distribution Profile): Transmitting or receiving audio
content of high-quality.
AVRCP (Audio Video Remote Control Profile): Controlling A/V equipment;
pausing, stopping, or starting playback, etc.
HSP (Headset Profile): Talking on the phone/Operating the phone.
HFP (Hands-free Profile): Talking on the phone/Operating the phone by
hands-free.
SPP (Serial Port Profile): Establishing serial communication with BLUETOOTH
device.
Maximum communication range
Use BLUETOOTH devices within 10 m (about 30 ft) (line of sight) of the system.
Maximum communication range may shorten under the following conditions.
There is an obstacle such as a person, metal, or wall between the system and
BLUETOOTH device.
A wireless LAN device is in use near the system.
A microwave oven is in use near the system.
A device that generates electromagnetic radiation is in use near the system.
Interference from other devices
Because BLUETOOTH devices and wireless LAN (IEEE802.11b/g) use the same
frequency, microwave interference may occur and resulting in communication
speed deterioration, noise, or invalid connection if the system is used near a
wireless LAN device. In such a case, perform the following.
Use the system at least 10 m (about 30 ft) away from the wireless LAN device.
If the system is used within 10 m (about 30 ft) of a wireless LAN device, turn
off the wireless LAN device.
Interference to other devices
Microwaves emitting from a BLUETOOTH device may affect the operation of
electronic medical devices. Turn off the system and other BLUETOOTH devices in
the following locations, as it may cause an accident.
where inflammable gas is present, in a hospital, train, airplane, or a gas
station
near automatic doors or a fire alarm
Notes
To be able to use the BLUETOOTH function, the BLUETOOTH device to be
connected requires the same profile as the system’s.
Note also that even if the same profile exists, devices may vary in function
depending on their specifications.
Due to the characteristic of BLUETOOTH wireless technology, the sound played
on the system is slightly delayed from the sound played on the BLUETOOTH
device during talking on the telephone or listening to the music.
This system supports security capabilities that comply with the BLUETOOTH
standard to provide a secure connection when the BLUETOOTH wireless
technology is used, but security may not be enough depending on the setting.
Be careful when communicating using BLUETOOTH wireless technology.
We do not take any responsibility for the leakage of information during
BLUETOOTH communication.
A device featuring the BLUETOOTH function is required to conform to the
BLUETOOTH standard specified by Bluetooth SIG, and be authenticated. Even if
the connected device conforms to the above mentioned BLUETOOTH standard,
some devices may not be connected or work correctly, depending on the
features or specifications of the device.
Noise or sound skips may occur depending on the BLUETOOTH device
connected with the system, the communication environment or the usage
environment.
Troubleshooting
No sound / Sound from only
one speaker / Low sound
level
Check that both this system and the
connected device are turned on.
Turn up the volume of the system and
the connected device.
Check that the connected device is
being played back.
Check that both plugs of the
connecting cord (not supplied) or both
connectors of the USB cable (not
supplied) are firmly inserted into the
system and the connected device.
If you are connecting a personal
computer to the system, make sure
the audio output setting of the
computer is set for a BLUETOOTH
device.
Pair this system and the BLUETOOTH
device again.
If the connected device is monaural,
sound will only be output from the left
speaker.
Check that the function for the
connected device (“BLUETOOTH,”
“USB” or “AUDIO IN”) is activated.
Distorted sound / Humming
or noise in the system
output
Turn down the volume of the system
and the connected device.
If the connected device has an
equalizer function, set it to off.
Keep the system away from a
microwave oven, wireless LAN, etc.
Bring this system and the BLUETOOTH
device closer together. Remove any
obstacle between this system and the
BLUETOOTH device.
Keep the system away from a TV. Switch the BLUETOOTH connection to
A2DP by operating the BLUETOOTH
device when HFP or HSP is set.
If you connect a device with a built-in
radio or tuner to this system,
broadcasts may not be received, or
sensitivity may be reduced. Locate the
system farther away from the device
and check that you can listen to the
broadcasts satisfactorily.
For BLUETOOTH devices:
Pairing is not possible
Bring this system and the BLUETOOTH
device to within 1 m (3 ft) of each
other.
If the (BLUETOOTH) indicator is not
flashing quickly, press and hold
BLUETOOTH PAIRING on the
system until beeps are heard.
For BLUETOOTH
devices: No voice / Low
voice from recipient
Check that both this system and the
connected device are turned on.
Check that output of the BLUETOOTH
mobile phone is set for the system.
Select HFP or HSP BLUETOOTH
connection by operating the
BLUETOOTH device.
Turn up the volume of the system and
the connected device.
For BLUETOOTH devices:
One-touch connection
(NFC) is not possible
Keep the smartphone close to the
system until the smartphone
responds. If you fail, move the
smartphone slightly on the N marked
part of the system.
Check that the NFC function of the
smartphone is set to on.
Check that the “NFC Easy Connect”
app is displayed on the smartphone.
If the smartphone is in a case, remove
it.
NFC receiving sensitivity depends on
the device. If you fail to connect with a
smartphone by One touch several
times, connect to the system by
on-screen operation.
Alarm does not sound
Check that the alarm indication “” or
“” is properly displayed.
Check that the device set for the alarm
is connected to the system.
Clock is not displayed correctly
When the clock flashes “AM 12:00” or
“0:00” due to a power interruption,
replace the battery with a new one.
If the clock does not employ the
daylight saving time (summer time)
automatically, press and hold OFF and
DISPLAY/ENTER until “ ” and “On”
light up in the display.
