Wireless Speaker
4-727-168-11(1)
10) Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or
sold with the apparatus. When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of
time.
14) Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
Precautions
On safety
The nameplate and important information concerning safety are located the bottom of
the main unit and on the surface of the AC adaptor.
Before operating the unit, be sure that the operating voltage of the unit is identical with
that of your local power supply.
Where purchased Operating voltage
All countries/regions 100 V – 240 V AC, 50 Hz/60 Hz
Notes on the AC adaptor
Use only the supplied AC adaptor. To avoid damaging the unit, do not use any other AC
adaptor.
Polarity of the plug
On placement
Do not set the unit in an inclined position.
Do not leave the unit in a location near heat sources, or in a place subject to direct
sunlight, excessive dust, or mechanical shock.
Do not use or leave the unit in a car.
Do not use the unit in a sauna.
On cleaning
Do not use alcohol, benzine, or thinner to clean the cabinet.
About the Voice Guidance
IMPORTANT: THE SOUND GUIDANCE IS AVAILABLE IN THIS PRODUCT ONLY IN ENGLISH
Depending on the status of the unit, the voice guidance outputs from the unit as
followings.
When setting the unit to the pairing mode; “Bluetooth pairing”
When pressing and holding the (call) button to check the battery power during the
unit is turned on; “Fully charged/About 70%/About 50%/About 20%/Please charge”
When the battery power is low; “Please charge”
When changing the L/R on SongPal during the Speaker Add function; “Left/Right”
On Copyrights
“ ” is a mark of the Wi-Fi Alliance.
Wi-Fi®, Wi-Fi Protected Access® and Wi-Fi Alliance® are registered marks of the Wi-Fi
Alliance.
Wi-Fi CERTIFIED™, WPA™, WPA2™ and Wi-Fi Protected Setup™ are marks of the Wi-Fi
Alliance.
The BLUETOOTH® word mark and logos are owned by the Bluetooth SIG, Inc. and any
use of such marks by Sony Corporation is under license.
The N Mark is a trademark or registered trademark of NFC Forum, Inc. in the United
States and in other countries.
Android™, Google Play, Google Play logo, and Chromecast are trademarks of Google Inc.
Other trademarks and trade names are those of their respective owners.
Notes on the update
The software of this unit will be automatically updated to the latest software while
connected to the Internet via a Wi-Fi network.
The software update will be delivered from time to time when, for example, a new feature
becomes available or the update is required for stable use.
Such automatic software feature may not be disabled. Also, previous versions of the
software cannot be retrievable.
Do not turn off power of this unit while updating. The unit may not be operational while
updating.
To use this product, a Wi-Fi environment and Google Account are necessary, as well as
your consent to Google Terms of Use and/or Privacy Policy. By using this product, you
agree to Sony’s EULA. Software for this product is automatically updated from time to time
and you cannot choose or refuse to load such automatic software.
Notes on water resistant feature
(Read before using the unit)
Water resistant performance of the unit
This unit has a water resistant specification*1 of IPX3*2 as specified in “Degrees of
protection against ingress of water” of the IEC60529 “Ingress Protection Rating (IP Code).”
However, this unit is not completely water-tight.
Do not drop the unit into water or purposely use it in water.
Liquids that the water resistant performance specifications apply to
Applicable : fresh water, tap water
Not applicable : liquids other than the above (soapy water, water with
detergent or bath agents, shampoo, hot spring water,
pool water, seawater, etc.)
*1 The supplied accessories are not water resistant.
*2 IPX3 (Protected against spraying water.): For details, refer to Help Guide.
The water resistant performance of the unit is based on our measurements
under the conditions herein described. Note that malfunctions as a result of
water immersion caused by misuse by the customer are not covered by the
warranty.
To avoid the deterioration of the water resistant performance
Check the following and use the unit correctly.
Do not use or leave the unit in an extremely hot or cold environment (temperature
outside the range of 5 °C – 35 °C (41 °F – 95 °F)). If the unit is used or left in outside the
above range, the unit may automatically stop to protect internal circuitry.
Be careful not to drop the unit or subject it to mechanical shock. Deformation or damage
may cause deterioration of the water resistant performance.
Do not use the unit in a location where large amount of water or hot water may splash
on it. The unit does not have a design that is resistant to water pressure. Use of the unit
in the above location may cause a malfunction.
Do not pour high-temperature water or blow hot air from a hair dryer or any other
appliance on the unit directly. Also, never use the unit in high temperature locations such
as in saunas or near a stove.
How to care for the unit when wet
If the unit gets wet, first remove the water from the unit, and then wipe off the moisture
on the unit using a soft, dry cloth. Especially in cold regions, leaving moisture on its surface
may cause the unit to freeze and malfunction. Be sure to wipe off the moisture after using
the unit.
Put the unit on towel or dry cloth. Then leave it at room temperature and dry the unit until
no moisture remains.
Notice on GNU GPL/LGPL applied software
This product contains software that is subject to the following GNU General Public
License (hereinafter referred to as “GPL”) or GNU Lesser General Public License
(hereinafter referred to as “LGPL”). These establish that customers have the right to
acquire, modify, and redistribute the source code of said software in accordance with
the terms of the GPL or LGPL supplied. The source code for the above-listed software
is available on the Web.
To download, please access the following URL then select the model name “LF-S50G”.
URL: http://oss.sony.net/Products/Linux/
Please note that Sony cannot answer or respond to any inquiries regarding the content
of the source code.
Disclaimer regarding services offered by third parties
Services offered by third parties may be changed, suspended, or terminated without
prior notice. Sony does not bear any responsibility in these sorts of situations.
LF-S50G
English Wireless Speaker
Before operating the unit, please read this guide thoroughly and retain it for future
reference.
Owner’s Record
The serial number is located on the bottom of the product.
Record the serial number in the space provided below. Refer to them whenever you call
upon your Sony dealer regarding this product.
Model No. LF-S50G
Serial No.
WARNING
To reduce the risk of fire or electric shock, do not expose the AC adaptor to rain
or moisture.
To reduce the risk of fire, do not cover the ventilation opening of the appliance with
newspapers, tablecloths, curtains, etc.
Do not expose the appliance to naked flame sources (for example, lighted candles).
To reduce the risk of fire or electric shock, do not expose the AC adaptor to dripping or
splashing, and do not place objects filled with liquids, such as vases, on the AC adaptor.
Do not install the appliance in a confined space, such as a bookcase or built-in cabinet.
Do not expose the batteries (battery pack or batteries installed) to excessive heat such as
sunshine, fire or the like for a long time.
As the main plug of AC Adaptor is used to disconnect the AC adaptor from the mains,
connect it to an easily accessible AC outlet. Should you notice an abnormality in it,
disconnect it from the AC outlet immediately.
The unit is not disconnected from the AC power source (mains) as long as it is connected
to the wall outlet.
CAUTION
You are cautioned that any changes or modifications not expressly approved in this
manual could void your authority to operate this equipment.
For customers in the USA
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC/IC radiation exposure limits set forth for an
uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines
and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low
levels of RF energy that is deemed to comply without maximum permissive exposure
evaluation (MPE). But it is desirable that it should be installed and operated keeping the
radiator at least 20 cm or more away from person’s body.
This equipment must not be co-located or operated in conjunction with any other antenna
or transmitter.
If your skin touches the AC adaptor or this product for a long time when the power is on, it
may cause a low temperature injury.
For customers in Canada
CAN ICES-3 B/NMB-3 B
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to
the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
High-power radars are allocated as primary users (i.e. priority users) of the bands
5250-5350 MHz and 5650-5850 MHz and that these radars could cause interference and/
or damage to LE-LAN devices.
Compliance with FCC requirement 15.407(c)
Data transmission is always initiated by software, which is the passed down through the
MAC, through the digital and analog baseband, and finally to the RF chip. Several special
packets are initiated by the MAC. These are the only ways the digital baseband portion will
turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the
transmitter will be on only while one of the aforementioned packets is being transmitted.
In other words, this unit automatically discontinues transmission in case of either absence
of information to transmit or operational failure.
Frequency Tolerance: ±12ppm
5150-5350 MHz band is restricted to indoor operation only.
5.47-5.725 GHz band is restricted to indoor operations only.
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings.
Install in accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the third prong are provided for
your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
Specifications
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION:
(The United States model only)
With 3 ohm load driven, from 120 Hz – 10,000 Hz; rated 30 watts minimum RMS power, with no more than 0.7%
total harmonic distortion from 250 milliwatts to rated output.
Speaker section
Speaker system Satellite 48 mm
Subwoofer 53 mm
Enclosure type Satellite: Closed type
Subwoofer: Bass reflex type
Network
Compatible standards IEEE802.11 a/b/g/n
Radio frequency 2.4/5 GHz band
BLUETOOTH
Communication System
BLUETOOTH Specification version 4.2
Output BLUETOOTH Specification Power Class 1
Maximum communication range
Line of sight approx. 10 m (30 ft)*1
Frequency band 2.4 GHz band (2.4000 GHz - 2.4835 GHz)
Modulation method FHSS
Compatible BLUETOOTH Profiles*2
A2DP (Advanced Audio Distribution Profile)
AVRCP (Audio Video Remote Control Profile)
Supported Codec*3 SBC*4
Transmission range (A2DP)
20 Hz - 20,000 Hz (Sampling frequency 44.1 kHz)
*1 The actual range will vary depending on factors such as obstacles between devices, magnetic fields around a
microwave oven, static electricity, reception sensitivity, antenna’s performance, operating system, software
application, etc.
*2 BLUETOOTH standard profiles indicate the purpose of BLUETOOTH communication between devices.
*3 Codec: Audio signal compression and conversion format
*4 Subband Codec
Microphone
Type MEMS (Micro Electronics Mechanical System) Type
Directional characteristic
Omni directional
Effective frequency range
@@ Hz - @@ Hz
General
Power DC 15 V (using the supplied AC adaptor connected to AC 100 V - 240 V, 50Hz/60 Hz power
supply)
Power consumption @@ W
Power consumption (during standby mode)
Less than @.@ W
Power consumption (during BLUETOOTH/network standby mode)
Less than @.@ W
Dimensions (including projecting parts and controls)
Approx. 110 mm X 162 mm (@@ in × @@ in) (φ/h)
Mass Approx. 710 g (@@ oz)
Supplied accessories
AC adaptor (AC-E1525 or AC-E1525M)
Operating Instructions (1)
Reference Guide (this document) (1)
Warranty card (1)
Reference Guide
Guide de référence
Guía de referencia
©2018 Sony Corporation Printed in China
http://www.sony.net/
LF-S50G_UC [U/C/E] 4-727-168-11(1)
