Sony Group NSZGT1 INTERNET TV BOX User Manual NSZ GT1 Reference Guide

Sony Corporation INTERNET TV BOX NSZ GT1 Reference Guide

Contents

Manual with rev indoor NII statement

NSZ-GT1
4-196-880-11(1)
C:\work\btv\ReferenceGuide\Eagle\4196880111\4196880111NSZGT1\010
COV.fm
masterpage:Right
Reference Guide
NSZ-GT1
Internet TV
010COV.book Page 1 Monday, May 31, 2010 11:49 AM
2
NSZ-GT1
4-196-880-11(1)
C:\work\btv\ReferenceGuide\Eagle\4196880111\4196880111NSZGT1\020
WAR.fm
masterpage:Left
To reduce the risk of fire or electric shock,
do not expose this apparatus to rain or
moisture.
The AC power cord must be changed only
at a qualified service shop.
Batteries or batteries installed apparatus
shall not be exposed to excessive heat
such as sunshine, fire or the like.
CAUTION
The use of optical instruments with this
product will increase eye hazard. As the
laser beam used in this Internet TV Box is
harmful to eyes, do not attempt to
disassemble the cabinet. Refer servicing
to qualified personnel only.
This label is located on the laser protective
housing inside the enclosure.
This symbol is intended to alert
the user to the presence of
uninsulated “dangerous
voltage” within the product’s
enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
This symbol is intended to alert
the user to the presence of
important operating and
maintenance (servicing)
instructions in the literature
accompanying the appliance.
These graphical symbols are located on
the AC adapter.
NOTE
This equipment has been tested and found
to comply with the limits for a Class B
digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment generates,
uses, and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in
a particular installation. If this equipment
does cause harmful interference to radio or
television reception, which can be
determined by turning the equipment off
and on, the user is encouraged to try to
correct the interference by one or more of
the following measures:
– Reorient or relocate the receiving
antenna.
– Increase the separation between the
equipment and receiver.
– Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced
radio/TV technician for help.
Precautions
• To prevent fire or shock hazard, do not
place objects filled with liquids, such as
vases, on the apparatus.
• The set is not disconnected from the AC
power source (mains) as long as it is
connected to the wall outlet, even if the
set itself has been turned off.
• Install this unit so that the AC power cord
can be unplugged from the wall socket
immediately in the event of trouble.
• The nameplate is located on the bottom
of the unit.
Installing
• Do not install this equipment in a
confined space, such as a bookshelf or
similar unit.
FCC WARNING
You are cautioned that any changes or
modifications not expressly approved in
this manual could void your authority to
operate this equipment.
This transmitter must not be co-located or
operated in conjunction with any other
antenna or transmitter.
The shielded Interface cable must be used
with the equipment in order to comply with
the limits for a digital device pursuant to
Subpart B of Part 15 of FCC Rules.
FCC Radiation Exposure
Statement:
This equipment complies with FCC
radiation exposure limits set forth for
uncontrolled equipment and meets the
FCC radio frequency (RF) Exposure
Guidelines in Supplement C to OET65. This
equipment should be installed and
operated with at least 20 cm and more
between the radiator and person's body
(excluding extremities: hands, wrists, feet
and ankles).
This device is restricted to indoor use when
operated in the 5.15 to 5.25 GHz frequency
range.
This product contains FCC ID: GT3FC009
Owner's Record
The model and serial numbers are located
at the bottom of the unit. Record the serial
number in the space provided below.
Refer to them whenever you call upon your
Sony dealer regarding this product.
Model No.______________
Serial No.______________
For Customers in the USA
If this product is not working properly,
please call 1-800-222-7669.
WARNING
Operation is subject to the following two
conditions;
(1) this device may not cause
interference, and
(2) this device must accept any
interference received,
including interference that may cause
undesired operation of the device.
010COV.book Page 2 Monday, May 31, 2010 11:49 AM
3
NSZ-GT1
4-196-880-11(1)
C:\work\btv\ReferenceGuide\Eagle\4196880111\4196880111NSZGT1\020
WAR.fm
masterpage:Right
Important Safety
Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near
water.
6) Clean only with dry cloth.
7) Do not block any ventilation
openings. Install in accordance with
the manufacturer’s instructions.
8) Do not install near any heat sources
such as radiators, heat registers,
stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of
the polarized or grounding-type
plug. A polarized plug has two
blades with one wider than the other.
A grounding type plug has two
blades and a third grounding prong.
The wide blade or the third prong are
provided for your safety. If the
provided plug does not fit into your
outlet, consult an electrician for
replacement of the obsolete outlet.
10)Protect the power cord from being
walked on or pinched particularly at
plugs, convenience receptacles,
and the point where they exit from
the apparatus.
11)Only use attachments/accessories
specified by the manufacturer.
12)Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used, use
caution when moving the cart/
apparatus combination to avoid
injury from tip-over.
13)Unplug this apparatus during
lightning storms or when unused for
long periods of time.
14)Refer all servicing to qualified
service personnel. Servicing is
required when the apparatus has
been damaged in any way, such as
power-supply cord or plug is
damaged, liquid has been spilled or
objects have fallen into the
apparatus, the apparatus has been
exposed to rain or moisture, does
not operate normally, or has been
dropped.
Precautions
On placement
• Place the unit in a location with
adequate ventilation to prevent heat
build-up in the unit.
• Do not place the unit on a soft surface
such as a rug that might block the
ventilation holes.
• Do not place the unit and AC adapter
in a location near heat sources, or in a
place subject to direct sunlight,
excessive dust, or mechanical shock.
• Do not place the unit outdoors, in
vehicles, on ships, or on other vessels.
• If the unit is brought directly from a
cold to a warm location, or is placed in
a very damp room, moisture may
condense on the lenses inside the
unit. Should this occur, the unit may
not operate properly. In this case,
remove the disc and leave the unit
turned on for about half an hour until
the moisture evaporates.
• Do not install the unit in an inclined
position. It is designed to be operated
in a horizontal position only.
• Do not place metal objects in front or
on the left side of the unit. It may limit
reception of radio waves.
• Do not place the unit in a place where
medical equipment is in use. It may
cause a malfunction of medical
instruments.
• If you use a pacemaker or other
medical device, consult your
physician or the manufacturer of your
medical device before using the
wireless LAN function.
• Do not place heavy or unstable
objects on the unit.
• Do not insert any objects other than
discs inside the disc slot. Doing so
may cause damage to the unit or the
object.
• Take out any discs when you move the
unit. If you don’t, the disc may be
damaged.
• Disconnect the AC power cord and all
other cables from the unit when you
move the unit.
• During operation the AC adapter has
to be placed on a surface with LED
side up and label side down.
010COV.book Page 3 Monday, May 31, 2010 11:49 AM
4
NSZ-GT1
4-196-880-11(1)
C:\work\btv\ReferenceGuide\Eagle\4196880111\4196880111NSZGT1\020
WAR.fm
masterpage:Left
On power sources
• Disconnect the unit from the wall outlet
if you are not going to use the unit for
a long time. To disconnect the AC
power cord, grasp the plug itself;
never pull the cord.
• Observe following points to prevent
the AC power cord being damaged.
Do not use the AC power cord if it is
damaged, as doing so may result in
an electric shock or fire.
– Do not pinch the AC power cord
between the unit and wall, shelf, etc.
– Do not put anything heavy on the AC
power cord or pull on the AC power
cord itself.
• Use the supplied AC adapter for the
unit, as other AC adapters may cause
a malfunction.
On adjusting volume
Do not turn up the volume while listening
to a section with very low level inputs or
no audio signals. If you do, your ears
and the speakers may be damaged
when a peak level section is played.
On cleaning
Clean the cabinet, panel, and controls
with a soft cloth. Do not use any type of
abrasive pad, scouring powder or
solvent such as alcohol or benzine.
On cleaning discs, disc/lens
cleaners
Do not use cleaning discs or disc/lens
cleaners (including wet or spray types).
These may cause the apparatus to
malfunction.
On replacement of parts
In the events that this unit is repaired,
repaired parts may be collected for
reuse or recycling purposes.
On connecting to the HDMI jack
Observe the following as improper
handling may damage the HDMI jack
and the connector.
• Carefully align the HDMI jack on the
rear of the unit and the HDMI
connector by checking their shapes.
Make sure the connector is not upside
down or tilted.
• Be sure to disconnect the HDMI cable
when moving the unit.
• Hold the HDMI connector straight
when connecting or disconnecting the
HDMI cable. Do not twist or force the
HDMI connector into the HDMI jack.
Notes About the Discs
• To keep the disc clean, handle the
disc by its edge. Do not touch the
surface.
Dust, fingerprints, or scratches on the
disc may cause it to malfunction.
• Do not expose the disc to direct
sunlight or heat sources such as hot
air ducts, or leave it in a car parked in
direct sunlight as the temperature may
rise considerably inside the car.
• After playing, store the disc in its case.
• Clean the disc with a cleaning cloth.
Wipe the disc from the center out.
• Do not use solvents such as benzine,
thinner, commercially available disc/
lens cleaners, or anti-static spray
intended for vinyl LPs.
• If you have printed the disc’s label, dry
the label before playing.
• Do not use the following discs.
– A lens cleaning disc.
– A disc that has a non-standard
shape (e.g., card, heart).
– A disc with a label or sticker on it.
– A disc that has cellophane tape or
sticker adhesive on it.
• Do not resurface the playing side of a
disc to remove surface scratches.
If you have any questions or problems
concerning your unit, please consult
your nearest Sony dealer.
IMPORTANT NOTICE
Caution: This unit is capable of
holding a still video image or
on-screen display image on your
television screen indefinitely. If you
leave the still video image or
on-screen display image displayed
on your TV for an extended period
of time you risk permanent damage
to your television screen. Plasma
display panel televisions and
projection televisions are
susceptible to this.
010COV.book Page 4 Monday, May 31, 2010 11:49 AM
5
NSZ-GT1
4-196-880-11(1)
C:\work\btv\ReferenceGuide\Eagle\4196880111\4196880111NSZGT1\030
SPC.fm
masterpage:Right
Specifications
*1 For details on USB devices that can be connected to the unit, see "Help Guide" (http://esupport.sony.com/internettv/helpguide).
*2 Since the Blu-ray Disc specifications are new and evolving, some discs may not be playable depending on the disc type and
the version.
The audio output differs depending on the source, connected output jack, and selected audio settings.
*3 BD-R and BD-RE discs cannot be played.
*4 A CD or DVD disc will not play if it has not been correctly finalized. For more information, refer to the operating instructions
supplied with the recording device.
*5 A DVD-R and DVD-RW disc recorded in VR mode (Video Recording format) cannot be played.
System
Laser Semiconductor laser
Input/Output jacks
HDMI IN HDMI 19-pin standard connector
Video: 480p, 720p, 1080i, 1080p
Audio: Linear PCM (2ch: Up to 48kHz)
HDMI OUT HDMI 19-pin standard connector
Video: 720p, 1080i, 1080p, 1080/24p
Audio: DTS bitstream, DTS HD Master Audio bit stream, DTS HD High Resolution Audio bit stream,
Dolby Digital bitstream, Dolby Digital Plus bit stream, Dolby TrueHD bit stream, Linear PCM (2ch:
Up to 192kHz), Linear PCM (6ch: Up to 192kHz), Linear PCM (8ch: Up to 96kHz)
DITIAL AUDIO OUT (OPTICAL) Optical output jack/-18dBm (wave length 660 nm)
PCM/DTS/Dolby Digital optical signal
LAN 1000BASE-T/100BASE-TX/10BASE-T Terminal
USB USB jack Type A*1
IR Blaster Mini jack (For connecting the IR Blaster cable)
Power and others
Power requirements AC adapter: 120 V AC, 1.0 A, 60 Hz (the unit: DC 19.5 V, 2.0 A)
Power consumption 43 W
Dimensions (approx.) 330 mm × 58.5 mm × 249 mm (13.00 in. × 2.31 in. × 9.81 in.)
(width/depth/height) incl. projecting parts
Mass (approx.) 2.4 kg (5.3 lb.)
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 25% to 80%
Wireless
Wireless LAN standard IEEE 802.11a/b/g/n
Frequency range 2.4 GHz band: Channels 1-11
5 GHz band: Channels 36-64, 100-140, 149-165
Modulation DS-SS Modem and OFDM Modem
Accessories
Supplied accessories Keypad (1)/Size AA batteries (2)/AC adapter NSG-AC19V (1)/AC power cord (1)/HDMI cable (1)/IR
Blaster cable (1)/Quick Setup Guide (1)/Reference Guide (1)/End User License Agreement (1)/
Warranty card (1)
Playable Discs
Blu-ray Disc*2*3 BD-ROM
DVD*4 DVD-ROM
DVD-R*5/DVD-RW*5
DVD+R/DVD+RW
CD*4 CD-DA (Music CD)
010COV.book Page 5 Monday, May 31, 2010 11:49 AM
6
NSZ-GT1
4-196-880-11(1)
C:\work\btv\ReferenceGuide\Eagle\4196880111\4196880111NSZGT1\040
ADD.fm
masterpage:Left
Additional
Information
Discs that cannot be played
• BDs with cartridge
• BD-Rs/BD-REs
•DVD-RAMs
• HD DVDs
• AVC HD on DVD discs
• DVD Audio discs
• HD layer on Super Audio CDs
• PHOTO CDs
• Data part of CD-Extras
• VCDs/Super VCDs
• Audio material side on DualDiscs
• A disc recorded in a color system
other than NTSC, such as PAL (this
unit conforms to the NTSC color
system).
Note on Discs
This unit is designed to playback
discs that conform to the Compact
Disc (CD) standard. DualDiscs and
some of the music discs encoded
with copyright protection
technologies do not conform to the
Compact Disc (CD) standard,
therefore, these discs may not be
playable by this unit.
Note on playback operations of BDs/
DVDs
Some playback operations of BDs/
DVDs may be intentionally set by
software producers. Since this unit
plays BDs/DVDs according to the
disc contents the software producers
designed, some playback features
may not be available.
Note about double-layer BDs/DVDs
The playback pictures and sound
may be momentarily interrupted
when the layers switch.
Region code (BD-ROM/DVD VIDEO
only)
Your unit has a region code printed
on the bottom of the unit and will only
play BD-ROMs/DVD-ROMs labeled
with identical region codes or .
About wireless LAN security
Since communication via the wireless
LAN function is established by radio
waves, the wireless signal may be
susceptible to interception. To
protect wireless communication, this
unit supports various security
functions. Be sure to correctly
configure the security settings in
accordance with your network
environment.
No Security
Although you can easily make
settings, anyone can intercept
wireless communication or intrude
into your wireless network, even
without any sophisticated tools. Keep
in mind that there is a risk of
unauthorized access or interception
of data.
WEP
WEP applies security to
communications to prevent outsiders
from intercepting communications or
intruding into your wireless network.
WEP is a legacy security technology
that enables older devices, which do
not support TKIP/AES, to be
connected.
WPA-PSK (TKIP), WPA2-PSK (TKIP)
TKIP is a security technology
developed to correct for the
deficiencies of WEP. TKIP assures a
higher security level than WEP.
WPA-PSK (AES), WPA2-PSK (AES)
AES is a security technology that
uses an advanced security method
that is distinct from WEP and TKIP.
AES assures a higher security level
than WEP or TKIP.
Pairing the keypad with the unit
1Make sure that the batteries are
correctly inserted.
2Press the CONNECT button on the
unit for two seconds or more to
display the pairing screen.
3Hold down the Fn and Enter keys
following the instructions on the
screen until the pairing screen
disappears.
ALL
Region code
010COV.book Page 6 Monday, May 31, 2010 11:49 AM
7
NSZ-GT1
4-196-880-11(1)
C:\work\btv\ReferenceGuide\Eagle\4196880111\4196880111NSZGT1\040
ADD.fm
masterpage:Right
Trademark
Information
• “Blu-ray Disc” and the "Blu-ray Disc"
logo are trademarks of Blu-ray Disc
Association.
• “DVD+RW,” “DVD-RW,” “DVD+R,”
“DVD-R,” “DVD VIDEO,” and “CD”
logos are trademarks.
• “AVCHD” and the “AVCHD” logo are
trademarks of Panasonic Corporation
and Sony Corporation.
• MPEG Layer-3 audio coding
technology and patents licensed from
Fraunhofer IIS and Thomson.
• Windows Media is either a registered
trademark or trademark of Microsoft
Corporation in the United States and/
or other countries.
• HDMI, the HDMI Logo, and
High-Definition Multimedia Interface
are trademarks or registered
trademarks of HDMI Licensing LLC in
the United States and other countries.
• Manufactured under license from
Dolby Laboratories. Dolby and the
double-D symbol are trademarks of
Dolby Laboratories.
• Manufactured under license under
U.S. Patent #’s: 5,451,942; 5,956,674;
5,974,380; 5,978,762; 6,487,535 &
other U.S. and worldwide patents
issued & pending. DTS and the
Symbol are registered trademarks &
the DTS logos are trademarks of DTS,
Inc.
©DTS, Inc. All Rights Reserved.
• Java and all Java-based trademarks
and logos are trademarks or
registered trademarks of Sun
Microsystems, Inc. in the U.S. and
other countries.
• Music and video recognition
technology and related data are
provided by Gracenote®. Gracenote
is the industry standard in music
recognition technology and related
content delivery. For more information,
please visit www.gracenote.com.
CD, DVD, Blu-ray Disc, and music and
video-related data from Gracenote,
Inc., copyright © 2000-present
Gracenote. Gracenote Software,
copyright © 2000-present Gracenote.
One or more patents owned by
Gracenote apply to this product and
service. See the Gracenote website
for a nonexhaustive list of applicable
Gracenote patents. Gracenote,
CDDB, MusicID, MediaVOCS, the
Gracenote logo and logotype, and the
“Powered by Gracenote” logo are
either registered trademarks or
trademarks of Gracenote in the United
States and/or other countries.
• This product contains software which
is licensed by Fluendo
(http://www.fluendo.com).
• Other system and product names are
generally trademarks or registered
trademarks of the manufacturers. ™
and ® marks are not indicated in this
document.
010COV.book Page 7 Monday, May 31, 2010 11:49 AM
NSZ-GT1
4-196-880-11(1)
C:\work\btv\ReferenceGuide\Eagle\4196880111\4196880111NSZGT1\050
BCO.fm
masterpage:Left
Printed in China
4-196-880-11(1)
© 2010 Sony Corporation
For Your Convenience
The Help Guide gives you detailed information on how to use the Internet TV
Box as follows:
– Basics of the Internet TV Box
– How to use applications
– Details on how to use the Keypad
– Customizing settings
– Software Updates
From your Internet TV Box
Select “Help Guide” from the Applications List.
Or, press (SEARCH) and type “help” in the Quick Search Box. Help Guide
appears in the search results.
From a PC browser
Access the following:
http://esupport.sony.com/internettv/helpguide/
010COV.book Page 8 Monday, May 31, 2010 11:49 AM

Navigation menu
