Users Manual
VAIO® Computer
Notes on Use
PCG-SRX77, PCG-SRX77P
Notes on Use
2
Notice to Users
© 2002 Sony Electronics Inc. All rights reserved. This manual and the software described herein, in
whole or in part, may not be reproduced, translated, or reduced to any machine-readable form without
prior written approval.
SONY ELECTRONICS INC. PROVIDES NO WARRANTY WITH REGARD TO THIS
MANUAL, THE SOFTWARE, OR OTHER INFORMATION CONTAINED HEREIN AND
HEREBY EXPRESSLY DISCLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR ANY PARTICULAR PURPOSE WITH REGARD TO THIS MANUAL, THE
SOFTWARE, OR SUCH OTHER INFORMATION. IN NO EVENT SHALL SONY
ELECTRONICS INC. BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, OR SPECIAL
DAMAGES, WHETHER BASED ON TORT, CONTRACT, OR OTHERWISE, ARISING OUT OF
OR IN CONNECTION WITH THIS MANUAL, THE SOFTWARE, OR OTHER INFORMATION
CONTAINED HEREIN OR THE USE THEREOF.
Sony Electronics Inc. reserves the right to make any modification to this manual or the information
contained herein at any time without notice. The software described herein is governed by the terms
of a separate user license agreement.
This product contains software owned by Sony and licensed by third parties. Use of such software is
subject to the terms and conditions of license agreements enclosed with this product. Some of the
software may not be transported or used outside the United States. Software specifications are subject
to change without notice and may not necessarily be identical to current retail versions.
Updates and additions to software may require an additional charge. Subscriptions to online service
providers may require a fee and credit card information. Financial services may require prior
arrangements with participating financial institutions.
The International ENERGY STAR® Office Equipment Program is an international program that
promotes energy saving through the use of computers and other office equipment. The program backs
the development and dissemination of products with functions that effectively reduce energy
consumption. It is an open system in which business proprietors can participate voluntarily. The
targeted products are office equipment such as computers, displays, printers, facsimiles and copiers.
Their standards and logos are uniform among participating nations. ENERGY STAR is a U.S.
registered mark.
Sony, DVgate, Handycam, i.LINK, Mavica, MagicGate™ Memory Stick and , Memory Stick
and , MovieShaker, PictureGear, PictureToy, VAIO, and the VAIO logo are trademarks of
Sony Corporation. Microsoft, Windows Media, Windows, Windows NT, and the Windows logo are
As an ENERGY STAR® Partner, Sony Corporation has determined that this
product meets the ENERGY STAR® guidelines for energy efficiency.
MEMORY STICK TM
Notice to Users
3
registered trademarks of Microsoft Corporation. Intel, SpeedStep, and Pentium are trademarks or
registered trademarks of Intel Corporation. PS/2 is a registered trademark of IBM. Acrobat Reader,
Photoshop, Photoshop Elements, and Premiere are trademarks of Adobe Systems Incorporated.
PowerPanel is a trademark of Phoenix Technologies Ltd.
This product incorporates copyright protection technology that is protected by method claims of
certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and
other rights owners. Use of this copyright protection technology must be authorized by Macrovision
Corporation, and is intended for home and other limited viewing uses only unless otherwise
authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited. i.LINK is
a trademark of Sony used only to designate that a product contains an IEEE 1394 connection. The
i.LINK connection may vary, depending on the software applications, operating system, and
compatible i.LINK devices. All products with an i.LINK connection may not communicate with each
other. Please refer to the documentation that came with your compatible i.LINK device for
information on operating conditions and proper connection. Before connecting compatible i.LINK
PC peripherals to your system, such as a CD-RW or hard disk drive, confirm their operating system
compatibility and required operating conditions.
All other trademarks are trademarks of their respective owners.
Owner’s Record
The model number and serial number are located on the bottom of your Sony VAIO Notebook. Refer
to the model and serial number when you call your Sony Service Center.
Model Numbers: PCG-441L
Serial Number:________________________
Registering Your Notebook
Sony is proud to offer you state-of-the-art multimedia computing technology. In order for Sony to
provide you with the highest caliber of technical support and inform you of new product
developments and upgrades, please take a few moments to register your notebook.
Safety Information
WARNING
❑To prevent fire or shock hazard, do not expose your notebook computer to rain or moisture.
❑To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only.
❑Never install modem or telephone wiring during a lightning storm.
❑Never install telephone jacks in wet locations unless the jack is specifically designed for wet
locations.
Notes on Use
4
❑Never touch uninsulated telephone wire or terminals unless the telephone line has been
disconnected at the network interface.
❑Use caution when installing or modifying telephone lines.
❑Avoid using the modem during an electrical storm.
❑Do not use the modem or a telephone to report a gas leak in the vicinity of the leak.
❑A socket outlet should be as close as possible to the unit and easily accessible.
❑i.LINK, PC Card, and USB connectors are not supplied with Limited Power Sources.
AVERTISSEMENT
❑Pour prévenir tout risque d’incendie ou d’électrocution, garder cet appareil à l’abri de la pluie et
de l’humidité.
❑Pour prévenir tout risque d’électrocution, ne pas ouvrir le châssis de cet appareil et ne confier
son entretien qu’à une personne qualifiée.
❑Ne jamais effectuer l’installation de fil modem ou téléphone durant un orage électrique.
❑Ne jamais effectuer l’installation d’une prise téléphonique dans un endroit mouillé à moins que
la prise soit conçue à cet effet.
❑Ne jamais toucher un fil téléphonique à découvert ou un terminal à moins que la ligne
téléphonique n’ait été débranché de l’interface réseau.
❑Soyez très prudent lorsque vous installez ou modifiez les lignes téléphoniques.
❑Évitez d’utiliser le modem durant un orage électrique.
To change the backup battery, please contact your nearest Sony Service
Center.
Caution: The use of optical instruments with this product will increase eye
hazard. As the laser beam used in this product is harmful to the eyes, do not
attempt to disassemble the cabinet. Refer servicing to qualified personnel
only.
(For CD-RW/DVD Combo Drive, CD-ROM drive, DVD-ROM drive) Danger:
Visible and invisible laser radiation when open. Avoid direct exposure to
beam.
Caution: To reduce the risk of fire, use only No. 26 AWG or larger
telecommunication line cord.
Notice to Users
5
❑N'utilisez pas le modem ni le téléphone pour prévenir d'une fuite de gaz vous êtes près de la
fuite.
❑L’appareil doit être le plus près possible d’une prise murale pour en faciliter l’accès.
❑Des connecteurs i.LINK, PC Card, et USB ne sont pas fournis avec des Sources d’Énergie
Limitées.
If you have questions about this product, you can reach the Sony Customer Information Service
Center at 1-888-4-SONY-PC; or write to the Sony Customer Information Service Center at 12451
Gateway Blvd., Ft. Myers, FL 33913 or find Sony Customer Service on the Web at:
http://www.sony.com/pcsupport.
Pour changer la pile de rechange, veuillez contacter votre centre de service
Sony le plus près.
Avertissement: L'utilisation d'instruments optiques avec ce produit
augmente les risques pour les yeux. Puisque le faisceau laser utilisé dans ce
produit est dommageable pour les yeux, ne tentez pas de désassembler le
boîtier. Adressez-vous à un agent de service qualifié.
(Pour le lecteur Combo de CD-RW/DVD, le lecteur CD-ROM, le lecteur DVD-
ROM) Danger: Radiation laser visible et invisible si ouvert. Évitez
l’exposition directe au faisceau.
Attention : Afin de réduire les risques d'incendie, n'utilisez qu'un cordon de
communication N0. 26 AWG ou plus gros.
Notes on Use
6
Regulatory Information
Declaration of Conformity
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
❑Reorient or relocate the receiving antenna.
❑Increase the separation between the equipment and the receiver.
❑Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
❑Consult the dealer or an experienced radio/TV technician for help.
You are cautioned that any changes or modifications not expressly approved in this manual could
void your authority to operate this equipment.
Only peripherals (computer input/output devices, terminals, printers, etc.) that comply with FCC
Class B limits may be attached to this computer product. Operation with non-compliant peripherals is
likely to result in interference to radio and television reception.
Trade Name: Sony
Model No.: PCG-441L
Responsible Party: Sony Electronics Inc.
Address: 680 Kinderkamack Road
Oradell, NJ 07649
Telephone:
(For FCC-related matters only.) 201-930-6972
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions:
(1)This device may not cause harmful interference.
(2)This device must accept any interference received, including interference that may cause
undesired operation.
Notice to Users
7
All cables used to connect peripherals must be shielded and grounded. Operation with cables,
connected to peripherals, that are not shielded and grounded, may result in interference to radio and
television reception.
FCC Part 68
This equipment complies with Part 68 of the FCC rules. On the bottom of this equipment is a label
that contains, among other information, the FCC Ringer Equivalency Number (REN) for this
equipment. If requested, this information must be provided to the telephone company.
This modem uses the USOC RJ-11 telephone jack.
The REN is used to determine the quantity of devices which may be connected to the telephone line.
Excessive RENs on the telephone line may result in the devices not ringing in response to an
incoming call. In most, but not all areas, the sum of the RENs should not exceed five (5.0). To be
certain of the number of devices that may be connected to the line, as determined by the total RENs,
contact the telephone company to determine the maximum REN for the calling area.
If the terminal equipment causes harm to the telephone network, the telephone company will notify
you in advance that temporary discontinuance of service may be required. But if advance notice is not
practical, the telephone company will notify the customer as soon as possible. Also, you will be
advised of your right to file a complaint with the FCC if you believe it is necessary.
The telephone company may make changes in its facilities, equipment, operations or procedures that
could affect the operations of the equipment. If this happens, the telephone company will provide
advance notice in order for you to make the necessary modifications in order to maintain
uninterrupted service.
If trouble is experienced with this equipment, you can reach the Sony Customer Information Service
Center at 1-888-4-SONY-PC; or write to the Sony Customer Information Service Center at 12451
Gateway Blvd., Ft. Myers, FL 33913 or find Sony Customer Service on the Web at:
http://www.sony.com/pcsupport.
Repair of this equipment should be made only by a Sony Service Center or Sony authorized agent.
For the Sony Service Center nearest you, call 1-888-4-SONY-PC (1-888-476-6972).
This equipment cannot be used on public coin service provided by the telephone company.
Connection to Party Line Service is subject to state and possible provincial tariffs. (Contact the state
or provincial utility service commission, public service commission, or corporation commission, for
information.)
Telephone Consumer Protection Act of 1991 (United States)
The Telephone Consumer Protection Act of 1991 makes it unlawful for any person to use a computer
or other electronic device to send any message via a telephone facsimile machine unless such
message clearly contains, in a margin at the top or bottom of each transmitted page or on the first page
of the transmission, the date and time it is sent and an identification of the business, other entity, or
individual sending the message, and the telephone number of the sending machine or such business,
other entity, or individual.
Notes on Use
8
In order to program this information into your facsimile machine, see your fax software
documentation.
Telephone Consumer Guidelines (Canada)
Please refer to your telephone directory under ‘Privacy Issues’ and/or ‘Terms of Service.’ For more
detailed information, please contact:
CRTC
Terrasses de la Chaudiére, Tour centrale 1 promenade du Portage, 5 étage Hull PQ K1A 0N2.
This Class B digital apparatus complies with Canadian ICES-003.
Cet àppareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
8
FCC Radio-Frequency Exposure (United States)
This Equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator and
body (excluding extremities:hands, wrists and feet).
Users are not permitted to make changes or modify the system in any way.
10
IC RSS-210 (Canada)
Operation is subject to the following two conditions; (1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation
of the device.
To prevent radio interference to the licensed service, this device is intended to be operated indoors and
away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed
outdoors is subject to licensing.
L'utilisation de ce dispositif est autorisee seulement aux conditions suivantes : (1) il ne doit pas produire
de brouillage et (2) l'utilisateur du dispositif doit etre pret a accepter tout brouillage radioelectrique recu,
meme si ce brouillage est susceptible de compromettre le fonctionnement du dispositif.
Pour empecher que cet appareil cause du brouillage au service faisant l'objet d'une licence, il doit etre utilise
a l'interieur et devrait etre place loin des fenetres afin de fournir un ecran de blindage maximal. Si le materiel
(ou son antenne d'emission) est installe a l'exterieur, il doit faire l'objet d'une licence.
Notice to Users
9
RECYCLAGE DES ACCUMULATEURS AUX IONS DE LITHIUM
RECYCLAGE DES ACCUMULATEURS
AUX IONS DE LITHIUM
Les accumulateurs aux ions de lithium sont
recyclables.
Vous pouvez contribuer à préserver
l’environnement en rapportant les piles usées
dans un point de collection et recyclage le plus
proche.
Pour plus d’informations sur le recyclage des accumulateurs, téléphonez le numéro gratuit 1-800-
822-8837 (Etats-Units et Canada uniquement), ou visitez http://www.rbrc.org/.
Avertissment: Ne pas utiliser des accumulateurs aux ions de lithium qui sont endommagées ou qui
fuient.
Do not handle damaged or leaking lithium ion batteries.
Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type recommended by the manufacturer. Discard used
batteries according to the manufacturer’s instructions.
The battery pack used in this device may present a fire or chemical burn
hazard if mistreated. Do not disassemble, heat above 140°F (60°C) or
incinerate. Dispose of used battery promptly. Keep away from children.
Ne pas utiliser des batteries au lithium ionisé qui sont endommagées ou qui
fuient.
Une batterie non conforme présente un danger d'explosion. La remplacer
seulement par une batterie identique ou de type équivalent recommandé par
le fabricant. Évacuer les batteries usées selon les directives du fabricant.
La manutention incorrecte du module de batterie de cet appareil présente un
risque d'incendie ou de brûlures chimiques. Ne pas démonter, incinérer ou
exposer à une température de plus de 60°C. Évacuer promptement la batterie
usée. Garder hors de portée des enfants.
Notes on Use
10
INDUSTRY CANADA NOTICE
NOTICE: The Industry Canada label identifies certified equipment. This certification means that the
equipment meets certain telecommunications network protective, operational and safety requirements
as prescribed in the appropriate Terminal Equipment Technical Requirements document(s). The
Department does not guarantee the equipment will operate to the user’s satisfaction.
Before installing this equipment, users should ensure that it is permissible to be connected to the
facilities of the local telecommunications company. The equipment must also be installed using an
acceptable method of connection.
The customer should be aware that compliance with the above conditions may not prevent
degradation of service in some situations.
Repairs to certified equipment should be coordinated by a representative designated by the supplier.
Equipment malfunctions or any repairs or alterations made by the user to this equipment may give the
telecommunications company cause to request that the user disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections of the power
utility, telephone lines and internal metallic water pipe system, if present, are connected together. This
precaution may be particularly important in rural areas.
Caution: Users should not attempt to make such connections themselves, but should contact the
appropriate electric inspection authority, or electrician, as appropriate.
NOTICE: The Ringer Equivalency Number (REN) assigned to each terminal device provides an
indication of the maximum number of terminals allowed to be connected to a telephone interface. The
termination on an interface may consist of any combination of devices subject only to the requirement
that the sum of the RENs of all the devices does not exceed 5. The REN for this equipment is 0.2.
AVIS DE L’INDUSTRIE CANADA
AVIS: L’étiquette d’Industrie Canada identifie le matériel homologué.
Cette étiquette certifie que le matériel est conforme aux normes de protection, d’exploitation et de
sécurité des réseaux de télécommunications, comme le prescrivent les documents concernant les
exigences techniques relatives au matériel terminal. Le Ministère n’assure toutefois pas que le
matériel fonctionnera à la satisfaction de l’utilisateur.
Avant d’installer ce matériel, l’utilisateur doit s’assurer qu’il est permis de le raccorder aux
installations de l’entreprise locale de télécommunication. Le matériel doit également être installé en
suivant une méthode acceptée de raccordement. L’abonné ne doit pas oublier qu’il est possible que la
conformité aux conditions énoncées ci-dessus n’empêche pas la dégradation du service dans certaines
situations.
Les réparations de matériel homologué doivent être coordonnées par un représentant désigné par le
fournisseur. L’entreprise de télécommunications peut demander à l’utilisateur de débrancher un
appareil à la suite de réparations ou de modifications effectuées par l’utilisateur ou à cause de
mauvais fonctionnement.
Notice to Users
11
Pour sa propre protection, l’utilisateur doit s’assurer que tous les fils de mise à la terre de la source
d’énergie électrique, des lignes téléphoniques et des canalisations d’eau métalliques, s’il y en a, sont
raccordés ensemble. Cette précaution est particulièrement importante dans les régions rurales.
Avertissement: L’utilisateur ne doit pas tenter de faire ces raccordements lui-même; il doit avoir
recours à un service d’inspection des installations électriques, ou à un électricien, selon le cas.
AVIS: L’indice d’équivalence de la sonnerie (IES) assigné à chaque dispositif terminal indique le
nombre maximal de terminaux qui peuvent être raccordés à une interface.
La terminaison d’une interface téléphonique peut consister en une combination de quelques
dispositifs, à la seule condition que la somme d’indices d’équivalence de la sonnerie de tous les
dispositifs n’excède pas 5. L’indice d’équivalence de la sonnerie de ce matériel est de 0.2.
Notes on Use
12
Ergonomic Considerations
Your notebook is a portable device and can be used in a variety of environments.
Whenever possible, you should apply the following ergonomic considerations for
both stationary and portable environments.
❑Position of your notebook — Place the notebook directly in front of you as
you work. Keep your forearms horizontal, with your wrists in a neutral,
comfortable position while using the keyboard, touchpad, or external mouse.
Let your upper arms hang naturally at your sides. Take breaks during
sessions with your notebook. Excessive use of the notebook may strain
muscles or tendons.
❑Furniture and posture — Sit in a chair with good back support and
armrests. Adjust the level of the chair so your feet are flat on the floor. A
footrest may make you more comfortable. Sit in a relaxed, upright posture
and avoid slouching forward or leaning far backward.
❑Viewing angle of the notebook’s display — Use the display’s tilting
feature to find the best viewing angle. Also try adjusting the brightness
Ergonomic Position
Notebook positioned
directly in front of you
Wrists relaxed
and flat
Arms at desk
level
Ergonomic Considerations
13
setting of the display. Following these suggestions can reduce eye strain and
muscle fatigue.
❑Lighting — Choose a location where windows and lights do not create glare
and reflection on the display. Use indirect lighting to avoid bright spots on
the display. You can also purchase accessories for your display that help
reduce glare. Proper lighting adds to your comfort and work effectiveness.
❑Placement of an external display — When using an external display, set
the display at a comfortable viewing distance. Make sure the display screen
is at eye level or slightly lower when you are sitting in front of the monitor.
Notes on Setup
❑Do not place your notebook in a location subject to:
❑Heat sources, such as radiators or air ducts
❑Direct sunlight
❑Excessive dust
❑Moisture or rain
❑Mechanical vibration or shock
❑Strong magnets or speakers that are not magnetically shielded
❑Ambient temperature of more than 95º F (35º C) or less than 40º F
(5º C)
❑High humidity
❑Do not place electronic equipment near your notebook. The notebook’s
electromagnetic field may cause a malfunction.
❑Provide adequate air circulation to prevent internal heat buildup. Do not
place your notebook on porous surfaces such as rugs or blankets, or near
materials such as curtains or draperies that may block its ventilation slots.
Leave a space of at least 8 inches (20 cm) behind the back panel of the
notebook.
❑If the notebook is brought directly from a cold location to a warm one,
moisture may condense inside your notebook. In this case, allow at least an
hour before turning on your notebook. If any problems occur, unplug your
notebook, and contact your Sony Service Center.
❑The notebook uses high-frequency radio signals and may cause interference
to radio or TV reception. Should this occur, relocate the notebook a suitable
distance away from the set.
Notes on Use
14
❑Use only specified peripheral equipment and interface cables; otherwise,
problems may result.
❑Do not use cut or damaged connection cables.
❑If the telephone company makes a service call to your home or office and
determines that your notebook is responsible for a problem, the telephone
company may bill you for the service call. Also, if you do not disconnect
your notebook when it is adversely affecting the telephone line, the
telephone company has the right to disconnect your service until you correct
the problem.
Handling Your Notebook
❑Clean the cabinet with a soft, dry cloth or a soft cloth lightly moistened with
a mild detergent solution. Do not use any type of abrasive pad, scouring
powder, or solvent such as alcohol or benzine, as these may damage the
finish of your notebook.
❑Should any solid object or liquid fall into the notebook, shut down your
notebook and then unplug it. You may want to have the notebook checked by
qualified personnel before operating it any further.
❑Do not drop the notebook or place heavy objects on top of the notebook.
Cleaning Your Notebook
❑Make sure to disconnect the power cord before cleaning the notebook.
❑Avoid rubbing the LCD screen as this can damage the screen. Use a soft, dry
cloth to wipe the LCD screen.
❑Clean the notebook with a soft cloth lightly moistened with a mild detergent
solution. Do not use any type of abrasive pad, scouring powder or solvent,
such as alcohol or benzine.
Handling the LCD Screen
❑Do not leave the LCD facing the sun as it can damage the LCD. Be careful
when using the notebook near a window.
❑Do not scratch the LCD or exert pressure on it. This could cause a
malfunction.
❑Using the notebook in low temperature conditions may produce a residual
image on the screen. This is not a malfunction. When the notebook returns to
normal temperature, the screen returns to normal.
❑The screen becomes warm during operation. This is normal and does not
indicate a malfunction.
❑The LCD is manufactured using high-precision technology. You may,
however, see tiny black points and/or bright points (red, blue, or green) that
continuously appear on the LCD. This is a normal result of the
manufacturing process and does not indicate a malfunction.
© 2002 Sony Electronics Inc. Reproduction in whole or in part without written permission is
prohibited. All rights reserved. Sony, VAIO, the VAIO logo, Memory Stick, MagicGate
Memory Stick, DVgate, Handycam, MovieShaker, PictureGear, PictureBook, and i.LINK are
trademarks of Sony. All other trademarks are trademarks or registered trademarks of their
respective owners.
Printed in Japan X-XXX-XXX-XX
