Sony Group SGPT113JP TABLET DEVICE User Manual

Sony Corporation TABLET DEVICE Users Manual

Contents

Users Manual 2

| VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ
詳細操作ガイド
本機を使っていて困ったときやわからないことがあったときに使うマニュアルです。
左の目次から知りたい項目をクリックして選んでください。
ページトップへ
Copyright Sony Corporation
| VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard
Hard
Power
Turning On Your Tablet Device
Shutting Down Your Tablet Device
Notes on Using the AC Adapter
Battery
Charging the Battery
Notes on Using the Battery
Screen
Tablet Device Basic Operation
Notes on the Touch Screen
Notes on LCD Screen
Handling the LCD Screen
Wi-Fi
Starting Wi-Fi Communications
Notes on Using the Wi-Fi Function
Bluetooth
About the Bluetooth Function
Communicating with Another Bluetooth Device
Stopping Bluetooth Communications
Notes on Using the Bluetooth Function
About Bluetooth Security
MemoryCard
Inserting/Removing an SD Memory Card
Notes on Using SD Memory Cards
Cradle
Setting Tablet Device in and Removing from Cradle
Parts_Controls
Parts and Controls (Tablet Device)
Parts & Controls (Cradle)
Model
Check the Supplied Items
Handling Your Tablet Device
Notes on Using Your Tablet Device
Notes on Holding Your Tablet Device
ページトップへ
Copyright Sony Corporation
| VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Soft
Soft
Home
About the Home Screen
Customizing the Home Screen
General
Notifications and Buttons
About the Notification Panel
Rotating the Screen
Quick search
Locking the Screen
Displaying the Recent Applications
Checking and Exiting the Running Applications
Entering Text
Using the Keyboard
Cut and Paste Text
Preinstall Software and Support Center
Settings
About the Settings Menu
Before Use
Sony_Apps
Introduction to Sony Exclusive Applications
ページトップへ
Copyright Sony Corporation
| VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Other
Other
Misc
Trademarks
Specifications
ページトップへ
Copyright Sony Corporation
| VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > 目次一覧
目次一覧
Hard
Power
Turning On Your Tablet Device
Shutting Down Your Tablet Device
Notes on Using the AC Adapter
Battery
Charging the Battery
Notes on Using the Battery
Screen
Tablet Device Basic Operation
Notes on the Touch Screen
Notes on LCD Screen
Handling the LCD Screen
Wi-Fi
Starting Wi-Fi Communications
Notes on Using the Wi-Fi Function
Bluetooth
About the Bluetooth Function
Communicating with Another Bluetooth Device
Stopping Bluetooth Communications
Notes on Using the Bluetooth Function
About Bluetooth Security
MemoryCard
Inserting/Removing an SD Memory Card
Notes on Using SD Memory Cards
Cradle
Setting Tablet Device in and Removing from Cradle
Parts_Controls
Parts and Controls (Tablet Device)
Parts & Controls (Cradle)
Model
Check the Supplied Items
Handling Your Tablet Device
Notes on Using Your Tablet Device
Notes on Holding Your Tablet Device
ページトップへ
Soft
| VAIO 電子マニュアル | ソニー
Home
About the Home Screen
Customizing the Home Screen
General
Notifications and Buttons
About the Notification Panel
Rotating the Screen
Quick search
Locking the Screen
Displaying the Recent Applications
Checking and Exiting the Running Applications
Entering Text
Using the Keyboard
Cut and Paste Text
Preinstall Software and Support Center
Settings
About the Settings Menu
Before Use
Sony_Apps
Introduction to Sony Exclusive Applications
ページトップへ
Other
Misc
Trademarks
Specifications
ページトップへ
Copyright Sony Corporation
| Turning On Your Tablet Device | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Power > Turning On Your Tablet Device
Task
Turning On Your Tablet Device
If you turn on your tablet device for the first time, see “Before Use” [Details].
Note
Before turning on, see “Notes on Using the Power Source” [Details].
1. Press and hold the power button until the status indicator light turns on (green).
Your tablet device will turn on, and the Google Android operating system will
subsequently launch.
Hint
If the tablet device is not used for a certain amount of time, it will automatically
enter Power saving mode. In power saving mode, the LCD screen is turned off and
the status indicator light slowly blinks orange.
By default, your tablet device automatically enters Sleep mode after a certain period
of inactivity while running on AC power [Details].
If you hold down the power button for more than 4 seconds, your tablet device will
not turn on. Press the power button lightly, and release it immediately to turn on
the tablet device.
ページトップへ
Copyright Sony Corporation
| Shutting Down Your Tablet Device | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Power > Shutting Down Your Tablet Device
task
Shutting Down Your Tablet Device
Note
Before shutting down your tablet device, see “Notes on Using the AC
Adapter” [Details].
1. Press and hold the power button until a list appears.
2. Touch [Power off] - [Yes].
The tablet device will automatically turn off in a few seconds, and the status
indicator light (green) will turn off.
Note
To avoid losing unsaved data or causing your tablet device to malfunction, be sure
to shut down your tablet device properly as described above.
After shutting down your tablet device, wait at least 30 seconds before turning it on
again.
To disconnect your tablet device from an AC power source, turn off the tablet device
and unplug the power cord.
ページトップへ
Copyright Sony Corporation
| Notes on Using the AC Adapter | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Power > Notes on Using the AC Adapter
Reference
Notes on Using the AC Adapter
If you do not intend to use your tablet device for an extended period of time, place
the tablet device into Hibernate mode, or turn it off.
Notes on AC adapter
Use the AC adapter supplied with your tablet device or a genuine Sony AC adapter.
Do not use any other AC adapter as it may cause malfunctions.
Do not connect the AC adapter to a power conversion device such as a travel power
converter. Doing so may cause overheating or a malfunction.
If the AC adapter cable becomes damaged or broken, do not use it.
Use the AC adapter supplied with your tablet device when using a Sony cradle (sold
separately).
Notes on turning on
Because your tablet device contains magnetic components, keep magnetic storage
media such as magnetic cards away from it as magnetic components may cause
data corruption.
Magnetic fields near your tablet device may cause it to enter Sleep mode (at default
setting). Keep magnetic objects away from your tablet device.
ページトップへ
Copyright Sony Corporation
| Charging the Battery | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Battery > Charging the Battery
task
Charging the Battery
The battery is charged when your tablet device is plugged in, regardless of whether it is
turned on or not. The charging time will vary depending on your usage.
1. Connect the AC adaptor to the charge connector of your tablet device.
2. Plug the AC adaptor to an AC outlet.
Hint
If you use a dedicated cradle (sold separately), you can charge the battery easily
[Details].
ページトップへ
Copyright Sony Corporation
| Notes on Using the Battery | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Battery > Notes on Using the Battery
Reference
Notes on Using the Battery
About the battery
For your safety, use only the supplied power cord for battery charging.
For safety reasons, battery charging may be suspended at exceptionally high or low
temperatures.
The tablet device is not fully charged when shipped.
Heat builds up in the battery while it is in use or being charged. This is normal and
is not cause for concern.
About battery discharge
After charging, the battery gradually loses its charge even if it is not used. If it is left
unused for a long time, the battery charge may be depleted. We recommend
recharging the battery before use.
About battery life
Battery life varies depending on usage, settings, and temperatures.
About battery deterioration
The battery eventually will need replacement. Its capacity gradually declines
through repeated recharging and discharging. As a result, the battery life may
become short or the battery may not perform optimally even when fully charged.
When using the Power saving mode
If the battery runs out of power during Sleep mode, all data not saved before
entering Sleep mode will be lost and unable to be restored. Be sure to save all data
before entering Sleep mode.
In Hibernate mode, all data and status (window position, size, etc.) are written to
the hard disk drive or SSD, so no data is lost should the battery run out. If you do
not intend to plug your tablet device in, use Hibernate mode.
When the battery is beginning to run down
If the battery runs out of power while you are away, the tablet device will turn off
and any data you are working on will be lost. While running on battery power, save
data frequently and put the tablet device in Hibernate mode manually if necessary.
ページトップへ
Copyright Sony Corporation
| Tablet Device Basic Operation | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Screen > Tablet Device Basic Operation
Concept
Tablet Device Basic Operation
Touch
Selects or opens an icon or option.
Touch & hold
Opens an option menu.
Drag & drop
Moves an item.
Drag/Flick
Scrolls a page slowly/quickly.
Pinch/Double tap
Zooms in or out.
ページトップへ
Copyright Sony Corporation
| Notes on the Touch Screen | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Screen > Notes on the Touch Screen
Reference
Notes on the Touch Screen
Touch the touch screen with your fingertip. Do not scratch it or touch with sharp
tools such as a stylus, a pen, or nails.
Remove the screen protection film before using your tablet device.
Do not touch the touch screen with gloved fingers.
Do not operate your tablet device with objects on the touch screen.
Do not put the touch screen close to other electrical devices. Electrostatic discharges
can make the touch screen malfunction.
Do not put the touch screen close to water. The touch screen may malfunction in
humid conditions or when exposed to water.
ページトップへ
Copyright Sony Corporation
| Notes on LCD Screen | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Screen > Notes on LCD Screen
Reference
Notes on LCD Screen
Do not leave the LCD screen facing the sun. Be sure to block direct sunlight when
using your tablet device near a window.
Do not scratch the surface of the LCD screen or exert excessive pressure on it.
Using your tablet device in low temperature conditions may produce a residual
image on the LCD screen. This does not indicate a malfunction. The screen will
return to normal when the tablet device returns to normal temperature.
A residual image may appear on the LCD screen if the same image is displayed for
an extended period of time. The residual image will eventually disappear. You can
use a screen saver to prevent residual images.
The LCD screen becomes warm during operation. This is normal and does not
indicate a malfunction.
The LCD screen is manufactured using high-precision technology. You may,
however, see tiny black points and/or bright points (red, blue, or green) on the LCD
screen. This is a normal result of the manufacturing process and does not indicate a
malfunction.
Do not exert excessive pressure on the LCD screen lid with the lid closed as doing so
may scratch or dirty the LCD screen.
Do not use the device if the screen is cracked or broken.
ページトップへ
Copyright Sony Corporation
| Handling the LCD Screen | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Screen > Handling the LCD Screen
Reference
Handling the LCD Screen
Use a soft, dry cloth to wipe the surface of the LCD screen. Rubbing the surface
may damage the screen.
Do not use chemicals or detergents.
ページトップへ
Copyright Sony Corporation
| Starting Wi-Fi Communications | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Wi-Fi > Starting Wi-Fi Communications
Task
Starting Wi-Fi Communications
You first need to establish Wi-Fi communications between your tablet device and an
access point. Make sure an access point is set up. See the operating instructions
supplied with your access point for more information.
After setting up the Wi-Fi communications, follow the steps below to turn on the Wi-Fi
setting on your tablet device.
1. Touch @(Apps) - [@ Settings] - [Wireless & networks] - [Wi-Fi].
Note
To save the battery consumption, turn off the Wi-Fi power when not in use.
To stop Wi-Fi communications
1. Operate step 1 above again to turn off the Wi-Fi setting on your tablet device.
To find networks in your range
1. Touch @(Apps) - [@ Settings] - [Wireless & networks] - [Wi-Fi Settings].
2. Touch [Wi-Fi] to turn on and scan for networks. If [Wi-Fi Settings] is already on,
touch [Menu @] - [Scan].
The list of the networks found within your range is displayed.
Hint To check the MAC address of your tablet device or other Wi-Fi details, touch
[Menu @] - [Advanced].
3. Touch a desired network.
4. When needed, enter [Network SSID], [Security], and [Wireless password].
Hint
When you are in range and [Wi-Fi] is on, your tablet device will automatically
reconnect to available networks which have been connected before.
ページトップへ
Copyright Sony Corporation
| Notes on Using the Wi-Fi Function | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Wi-Fi > Notes on Using the Wi-Fi Function
Reference
Notes on Using the Wi-Fi Function
Use of Wi-Fi products may be restricted by local regulations in some countries or
regions.
Wi-Fi devices work on the 2.4 GHz band, which is used by a variety of devices. Wi-Fi
devices use technology to minimize radio interference from other devices that use
the same band. However, radio interference may still cause slower data transfer
speeds, reduce communications range or cause communications failure.
If both the Bluetooth function and the 2.4 GHz Wi-Fi function of your tablet device
are enabled, interference may occur and cause slower data transfer speeds or other
problems.
To communicate via Wi-Fi while traveling, you may need to contract with a Wi-Fi
connection service provider.
If your tablet device uses IEEE 802.11b/g/n, note that outdoor use of the 5 GHz Wi-
Fi function is prohibited by law.
Data transfer speed and communications range may vary depending on the
following conditions:
Distance between devices
Presence of obstacles between devices
Device configuration
Signal conditions
Surrounding environment (wall material, etc.)
Software in use
Communications may be cut off depending on signal conditions.
The data transfer rate specified in the specification is the theoretical maximum, and
may not reflect actual data transfer rate.
Actual data transfer speed may not be as fast as the speed displayed on your tablet
device.
Communications is not available between the 2.4 GHz and 5 GHz Wi-Fi frequency
bands.
The data transfer rate for IEEE 802.11g and IEEE 802.11n (2.4 GHz) devices may
be affected by interference when used with IEEE 802.11b products. Also, products
using IEEE 802.11g and IEEE 802.11n automatically lower the transfer rate to
maintain compatibility with IEEE 802.11b products. The normal transfer rate may
be regained by changing the channel settings of your access point.
When the data transfer speed is not as fast as expected, changing the wireless
channel on the access point may increase the speed.
ページトップへ
Copyright Sony Corporation
| About the Bluetooth Function | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Bluetooth > About the Bluetooth Function
Concept
About the Bluetooth Function
You can establish wireless communications between your tablet device and other
Bluetooth(R) devices such as a computer, a mobile phone, digital still camera, headset
or mouse.
You can transfer data between these devices without cables at a range of up to 33
feet / 10 meters in an open area. One Bluetooth device can connect with up to 7
devices via wireless network to exchange data.
When a device requires connection to another device, it sends out an inquiry to
neighboring Bluetooth devices. If any device responds to the inquiry, the two devices
can connect with each other.
ページトップへ
Copyright Sony Corporation
| Communicating with Another Bluetooth Device | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Bluetooth > Communicating with Another Bluetooth Device
Task
Communicating with Another Bluetooth Device
You can connect Bluetooth devices to your tablet device.
Depending on the device, the procedure to establish connection may vary. Refer to the
operating instructions of the Bluetooth device together.
For details on Bluetooth communication, see “About the Bluetooth Function” [Details].
To turn on the Bluetooth feature
1. Touch @(Apps) - [@ Settings] - [Wireless & networks] - [Bluetooth].
Note
To save the battery consumption, turn off the Bluetooth power when not in use.
The Bluetooth Enhanced Audio setting is not recommended for older Bluetooth
headsets as it may not deliver acceptable sound quality.
To make your tablet device discoverable
You can allow a Bluetooth device to discover your tablet device when the Bluetooth is
turned on.
1. Touch @(Apps) - [@ Settings] - [Wireless & networks] - [Bluetooth settings].
2. Touch [Discoverable],
To pair with another Bluetooth device
To connect with a new Bluetooth device, you need to pair with it when the Bluetooth is
turned on.
You only need to do this once for your tablet device and the new Bluetooth device-to
connect again, just turn on the device.
1. Make sure the Bluetooth device you are pairing with is in discoverable mode.
Note Refer to the operating instructions supplied with the Bluetooth devices for
details.
2. Touch @(Apps) - [@ Settings] - [Wireless & networks] - [Bluetooth settings].
3. Touch [Find nearby devices].
The Paired devices list is displayed.
4. Touch a device to connect.
5. Touch [Pair], or enter the device passkey (like 0000) to connect to the Bluetooth
device, if necessary.
When the device is connected, the Bluetooth indicator appears in the status panel.
To reconnect devices
To reconnect your tablet device with the paired device, touch the device name in the
Paired devices list.
ページトップへ
Copyright Sony Corporation
| Stopping Bluetooth Communications | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Bluetooth > Stopping Bluetooth Communications
Task
Stopping Bluetooth Communications
1. Touch the name of a paired device from in the devices list, that you want to
disconnect your tablet device.
2. Touch [Menu @] - [Disconnect].
Hint
To save the battery consumption, turn off the Bluetooth power when not in use.
ページトップへ
Copyright Sony Corporation
| Notes on Using the Bluetooth Function | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Bluetooth > Notes on Using the Bluetooth Function
Reference
Notes on Using the Bluetooth Function
Use of Bluetooth function may be restricted by local regulations in some countries or
regions.
The Bluetooth function may not work with some devices, depending on the
manufacturer or the software version employed by the manufacturer. Check the
system requirements of the Bluetooth device before purchasing.
For information on Bluetooth devices supported by Sony tablet devices, visit the
support web site.
Some Bluetooth devices require authentication (pairing) before establishing a
connection with another device.
Perform the authentication process before connecting to such a device.
Bluetooth devices use technology to minimize radio interference from other devices
that use the same band. However, radio interference may still cause slower data
transfer speeds, reduce communications range or cause communications failure.
Data transfer speed and communications range may vary depending on the
following conditions:
Distance between communicating devices
Presence of obstacles between devices
Surrounding environment that includes presence of walls and materials of such
walls
Device configuration
Software in use
Signal conditions
Communications may be cut off depending on signal conditions.
Interference may occur if your tablet device is equipped with Bluetooth Core
Specification Version 2.1 + EDR and both the Bluetooth function and the 2.4 GHz
Wi-Fi function are enabled. That will result in slower data transfer speeds or other
problems.
High-speed communications between your tablet device and Bluetooth devices is
available when they are compliant with Bluetooth Core Specification Version 3.0 +
HS. For high-speed communications, enable both the Wi-Fi and Bluetooth functions
on your tablet device.
Large files may occasionally be corrupted during continuous transfer due to
limitations of the Bluetooth standard and ambient electromagnetic interference.
Connecting multiple Bluetooth devices to your tablet device may cause channel
congestion, resulting in poor device performance. This is normal with Bluetooth
technology and does not indicate a malfunction.
Video and audio may not be synchronized if you play videos on your tablet device
with audio output from a connected Bluetooth device. This is a frequent occurrence
with Bluetooth technology and does not indicate a malfunction.
All Bluetooth devices must be certified through procedures stipulated by Bluetooth
SIG to ensure that they comply with the Bluetooth standard.
Even if the Bluetooth standard is complied with, individual device performance,
specifications, and operation procedures can vary.
Using your tablet device or accessory while driving may cause distraction and may
be illegal. Always obey the laws and drive safely.
ページトップへ
Copyright Sony Corporation
| About Bluetooth Security | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Bluetooth > About Bluetooth Security
Reference
About Bluetooth Security
Bluetooth wireless technology has an authentication function that allows you to
determine with whom you choose to communicate.
With the authentication function, you can prevent any anonymous Bluetooth devices
from accessing your tablet device.
The first time two Bluetooth devices communicate, a common passkey (a password
required for authentication) should be determined for both devices to be registered.
Once a device is registered, there is no need to re-enter the passkey.
Your tablet device can prevent other Bluetooth devices from finding it and control which
devices are allowed to connect with it.
ページトップへ
Copyright Sony Corporation
| Inserting/Removing an SD Memory Card | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > MemoryCard > Inserting/Removing an SD Memory Card
Task
Inserting/Removing an SD Memory Card
Your tablet device is equipped with an SD memory card slot. You can use this slot to
transfer data to and from digital cameras, camcorders, music players, and other audio/
video devices.
The SD memory card slot on your tablet device can accommodate the following memory
cards:
SD memory card
SDHC memory card
SDXC memory card
To insert an SD memory card
1. Open the cover of the card slot.
2. Locate the SD memory card slot.
3. Hold the SD memory card with the arrow pointing toward the SD memory card slot.
4. Carefully slide the SD memory card into the slot until it clicks into place.
The SD memory card icon will appear in a window on your tablet device after
you insert the card into the slot.
Note
Be careful not to insert an SD memory card at the wrong orientation. If you force it
into the slot upside down, the slot may be damaged. For details, refer to the manual
of the SD memory card.
Hint
When you insert the SD memory card into the slot for the first time, you may be
prompted to install driver software. If prompted, follow the on-screen instructions to
install the software.
The SD memory card access indicator light will be lit while the SD memory card is
being read or written to.
To remove an SD memory card
1. Locate the SD memory card slot.
2. Make sure the SD memory card access indicator light is not lit.
3. Push in the SD memory card all the way and release.
The SD memory card ejects.
4. Pull the SD memory card out of the slot.
ページトップへ
Copyright Sony Corporation
| Notes on Using SD Memory Cards | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > MemoryCard > Notes on Using SD Memory Cards
Reference
Notes on Using SD Memory Cards
Keep away from children. SD memory cards are harmful if swallowed.
Do not touch the contacts with fingers or metal objects.
SD memory cards contain delicate electronic components. Do not subject them to
excessive force, bend or drop them.
Do not disassemble or modify.
Avoid moisture.
Do not use or store in the following locations:
Places with high temperature, such as inside an enclosed car in the sunshine
Places exposed to direct sunlight
Humid or corrosive environments
Excessively dusty places
Be sure to use SD memory cards that are compliant with the standards supported
by your tablet device. A wrong-size card may become jammed in the slot, causing
damage to your tablet device.
You cannot write data to an SD memory card that is write-protected.
It is recommended that you make a backup copy of important data.
To avoid losing stored data, observe the following:
Do not remove an SD memory card or turn off your tablet device while the Media
Access indicator light is lit.
Keep SD memory cards away from static electricity or electrical noise that may
interfere with the card.
When carrying SD memory cards, be sure to put them in their case to avoid static
electricity damage.
Before using an SD memory card with a device other than a tablet device, such as a
digital camera or a portable audio, format (initialize) the SD memory card using the
device.
Some devices may not support the file format for tablet devices and show you a
message that recommends you to format the card. In this case, copy data from the
card to your tablet device (or to other devices via the network) and format the card
using the device. Note that formatting a card will delete all current data contained in
it. For more details, refer to the manual of the device.
Do not insert foreign objects into the SD memory card slot.
The SD memory card slot can be used for reading/writing supported cards only, and
it cannot be used for other purposes.
Notes on SD memory cards
SD memory cards (up to 2 GB), SDHC memory cards (up to 32 GB) and SDXC
memory cards (up to 64 GB) available as of May 2010 have been tested and found
compatible with your tablet device. However, this does not guarantee that all SD
memory cards, SDHC memory cards or SDXC memory cards will be compatible with
your tablet device.
ページトップへ
Copyright Sony Corporation
| Setting Tablet Device in and Removing from Cradle | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Cradle > Setting Tablet Device in and Removing from Cradle
Task
Setting Tablet Device in and Removing from Cradle
Using a cradle (sold separately) lets you charge your tablet device easily or hold it at an
easy-to-read angle.
Setting your tablet device in a cradle
1. Plug the AC adaptor in to the power cord connector at the bottom of a cradle.
2. Plug the AC adaptor in to the AC outlet.
3. Align the charge connector of your tablet device with that inside the upper slot of
the cradle.
4. Place the tablet device in the upper slot of the cradle.
Removing your tablet device from a cradle
Lift your tablet device up in a straight line.
ページトップへ
Copyright Sony Corporation
| Parts and Controls (Tablet Device) | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Parts_Controls > Parts and Controls (Tablet Device)
Reference
Parts and Controls (Tablet Device)
Front
1. Microphone
2. IR sensor
3. Ambient light sensor
4. Touch screen
5. Front camera lens
Side
1. Status indicator
2. @ (Power) button
3. Charge indicator
4. VOL + / - (Volume) buttons
5. Reset button hole
6. Built-in speaker (R)
Rear
| Parts and Controls (Tablet Device) | VAIO 電子マニュアル | ソニー
1. Rear camera lens
2. @ (Headphone) jack
3. Micro USB connector
4. SD memory card slot
5. SIM card slot
6. SIM card eject hole
7. SD memory card access indicator
8. Built-in speaker (L)
9. Charge connector
ページトップへ
Copyright Sony Corporation
| Parts & Controls (Cradle) | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Parts_Controls > Parts & Controls (Cradle)
Reference
Parts & Controls (Cradle)
1. Power cord connector
2. Charge connector (inside the upper slot)
ページトップへ
Copyright Sony Corporation
| Check the Supplied Items | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Model > Check the Supplied Items
Reference
Check the Supplied Items
AC adaptor
Strap
Quick Start Guide
Safety Regulations
SLA/EULA (TBD)
Warranty card
ページトップへ
Copyright Sony Corporation
| Handling Your Tablet Device | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Model > Handling Your Tablet Device
Reference
Handling Your Tablet Device
To care for your tablet device, follow as below.
Tablet device
Clean the cabinet with a soft, dry or lightly moistened cloth with a mild detergent
solution. Do not use an abrasive pad, scouring powder, or solvent such as alcohol or
benzine, as these may damage the finish of your tablet device.
If your tablet device is exposed to water such as rain or extreme humidity, wipe
your tablet device with a soft dry cloth, not dry with an oven or dryer.
Make sure you unplug the AC adapter and remove the battery pack before cleaning
your tablet device.
Make sure you close the battery and any connector covers and keep them secure.
LCD screen
Use a soft, dry cloth to wipe the surface of the LCD screen. Rubbing the surface
could damage the screen.
Do not use chemicals or detergents.
Built-in camera
Clean the lens protection cover of the built-in camera with a blower brush or a soft
brush. If the cover is extremely dirty, wipe it off with a soft dry cloth. Do not rub
the cover, as it is sensitive to pressure.
ページトップへ
Copyright Sony Corporation
| Notes on Using Your Tablet Device | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Model > Notes on Using Your Tablet Device
Reference
Notes on Using Your Tablet Device
If you need more information about your tablet device, see ----URL----.
ページトップへ
Copyright Sony Corporation
| Notes on Holding Your Tablet Device | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Hard > Model > Notes on Holding Your Tablet Device
Reference
Notes on Holding Your Tablet Device
In case of landscape orientation, hold your tablet device as such that the front
camera lens is arranged at the upper side.
In case of portrait orientation, hold your tablet device as such that the front camera
lens is arranged at the left side. Be careful not to hold an ambient light sensor.
ページトップへ
Copyright Sony Corporation
| About the Home Screen | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Soft > Home > About the Home Screen
Reference
About the Home Screen
You can start various applications from the Home screen.
To start an application, touch the application icon.
You can also customize the Home screen as you like.
1. Application launcher icon
Touch to display the Application launcher. You can start all applications from the
Application launcher.
Also, you can sort the icons on the Application launcher in some methods.
Flick up/down on the Application launcher to see more application/widget icons.
2. Quick launcher
Touch the application icon you want to start immediately. This is convenient for the
frequently using applications.
3. Summary view icon
Touch to display the Summary view. In the Summary view, thumbnails of recently
arriving content such as videos, photos, music, books, games are displayed. When
you touch the thumbnail, the detailed information is displayed and you can start
playback easily.
4. Work space
You can place application/widget icons and such here. Also, you can display the
Summary view and the Application launcher, by touching each icons at the right top
of the screen.
The Work space consists of the five pages and you can scroll them when you flick
the screen left/right.
ページトップへ
Copyright Sony Corporation
| Customizing the Home Screen | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
| Customizing the Home Screen | VAIO 電子マニュアル | ソニー
トップ > Soft > Home > Customizing the Home Screen
Task
Customizing the Home Screen
Application launcher
To uninstall an application from the Application launcher
1. On the Application launcher, touch and hold the application icon that you want to
uninstall.
2. Follow the instructions displayed on the screen.
To sort icons on the Application launcher
1. On the Application launcher, touch one of the following icons at the right top of the
screen. @(Custom) : Sort by the rule you have customized.
@(Name) : Sort by name.
@(Date) : Sort by date of update.
To customize the rule of sort
1. On the Application launcher, touch @(Custom) and then @(Edit) at the right top of
the screen.
2. Drag and drop the icons as you desired.
Hint
To classify the icons on the Application launcher, drag and drop @(|) at the right
top of the screen to begin a new line in step 2.
Quick launcher
To add an icon to the Quick launcher
1. xxxx
To remove an icon from the Quick launcher
1. On the Quick launcher, touch and hold the icon and select xxx from the displayed
menu.
Summary view
To edit items on the Summary view
1. On the Summery view, touch @(Edit) at the right top of the screen.
To add an item, touch it from the displayed item list.
To move an item, drag and drop the thumbnail to the desired location.
To disappear an item, touch x on the thumbnail.
Work space
To add an icon to the Work space
1. On the Work space, touch + at the right top of the screen.
The screen for adding an icon is displayed.
2. Touch the arrow under the screen you want to add an icon.
3. Touch the tab and then the icon that you want to add.
To remove an icon from the Work space
1. On the Work space, touch and hold the icon and select [xxx] from the displayed
menu.
ページトップへ
Copyright Sony Corporation
| Notifications and Buttons | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Soft > General > Notifications and Buttons
Reference
Notifications and Buttons
Notifications and buttons for basic operations appear at the bottom of the screen.
@(Home) : Touch to display the Home screen.
@(Back) : Touch to return to the previous screen.
@(Recent Apps) : Touch to display recent applications [Details].
Digital clock : Touch to display the notification panel [Details].
ページトップへ
Copyright Sony Corporation
| About the Notification Panel | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Soft > General > About the Notification Panel
Reference
About the Notification Panel
illust. (notification panel)
Notification panel is displayed when you touch the digital clock on the right bottom of
the screen. Touch the icon on the notification panel or the panel itself to check the
status or messages. On the notification panel, you can also change the settings of your
tablet device.
ページトップへ
Copyright Sony Corporation
| Rotating the Screen | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Soft > General > Rotating the Screen
Reference
Rotating the Screen
The screen rotates when you turn your tablet device sideways.
Note
Some applications may not support to rotate the screen.
The screen can be rotated to portrait so that the front camera lens side comes to
left only.
Not to rotate the screen
1. Touch @(Apps) - [@ Settings] - [Screen] - [Auto-rotate screen].
ページトップへ
Copyright Sony Corporation
| Quick search | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Soft > General > Quick search
Task
Quick search
Quick search box appears on the left top of the Home screen.
To search by texts, touch the box and enter keywords, and then touch .
To search by voice, touch and speak keywords after prompt.
ページトップへ
Copyright Sony Corporation
| Locking the Screen | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Soft > General > Locking the Screen
Task
Locking the Screen
You can lock the screen of your tablet device in some ways to prevent from the
accidental touch. If you activate the lock function, the screen is locked when you left the
screen for a while or press the power button.
To activate the lock function
1. Touch @(Apps) - [@ Settings] - [Location & security] - [Configure lock screen].
To select the unlock method
You can select unlock method to be returned from the locked screen.
1. Touch @(Apps) - [@ Settings] - [Location & security] - [Change lock screen].
2. Select the method to unlock the screen.
Pattern lock : Draw a pattern.
PIN : Enter a PIN code.
Set password : Enter a password.
3. Follow the displayed instructions.
ページトップへ
Copyright Sony Corporation
| Displaying the Recent Applications | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Soft > General > Displaying the Recent Applications
Task
Displaying the Recent Applications
Touch @(Recent Apps) on the bottom left of the screen.
ページトップへ
Copyright Sony Corporation
| Checking and Exiting the Running Applications | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Soft > General > Checking and Exiting the Running Applications
Task
Checking and Exiting the Running Applications
xxx
ページトップへ
Copyright Sony Corporation
| Entering Text | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Soft > General > Entering Text
Task
Entering Text
An on-screen keyboard is displayed on the screen when needed.
Enter text using the keyboard [Details].
ページトップへ
Copyright Sony Corporation
| Using the Keyboard | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Soft > General > Using the Keyboard
Task
Using the Keyboard
Each time you press the two keys at the lower left corner on the keyboards as shown,
the keyboards are changed as follows.
Hint
You can also display independent numerical keypad. xxxxx
ページトップへ
Copyright Sony Corporation
| Cut and Paste Text | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Soft > General > Cut and Paste Text
Task
Cut and Paste Text
To cut or copy text
1. Select and hold the text, and then touch [Cut] or [Copy].
To paste text
1. Touch the location to paste, and then touch [Paste].
ページトップへ
Copyright Sony Corporation
| Preinstall Software and Support Center | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Soft > General > Preinstall Software and Support Center
Reference
Preinstall Software and Support Center
Your tablet device has the following preinstall software. For details, contact each
support center.
xxxxx
ページトップへ
Copyright Sony Corporation
| About the Settings Menu | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Soft > Settings > About the Settings Menu
Task
About the Settings Menu
In the settings menu, you can configure various settings of your tablet device.
Touch @(Apps) - [@ Settings] and the desired items, and then select the items or
follow the displayed instructions.
The menu items are as follows:
@ Wireless & Networks : xxx
@ Sound : xxx
@ Screen : xxx
@ Location & security : xxx
@ Applications : xxx
@ Accounts & sync : xxx
@ Privacy : xxx
@ Storage : xxx
@ Language & input : xxx
@ Accessibility : xxx
@ Date & time : xxx
@ About tablet : xxx
ページトップへ
Copyright Sony Corporation
| Before Use | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Soft > Settings > Before Use
Task
Before Use
When you use your tablet device for the first time, you must register your tablet device
and sign in.
1. After turning on your tablet device, select a language and touch [Start].
2. Connect your tablet device via Wi-Fi [Details] or 3G.
3. Follow the displayed instructions to sign in with your Google account.
ページトップへ
Copyright Sony Corporation
| Introduction to Sony Exclusive Applications | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Soft > Sony_Apps > Introduction to Sony Exclusive Applications
Reference
Introduction to Sony Exclusive Applications
You can download all kinds of Sony exclusive applications from the following sites.
Site name1 URL1
Site name2 URL2
Site name3 URL3
ページトップへ
Copyright Sony Corporation
| Trademarks | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Other > Misc > Trademarks
Reference
Trademarks
xxxxx
ページトップへ
Copyright Sony Corporation
| Specifications | VAIO 電子マニュアル | ソニー
VAIO 電子マニュアル
文字サイズ
印刷
Hard
Soft
Other
目次一覧
トップ > Other > Misc > Specifications
Reference
Specifications
xxxxx
ページトップへ
Copyright Sony Corporation

Navigation menu
