Minew Technologies
D34 iBeacon / Eddystone
Datasheet V1.0
Digital Broadcasting Device
D
Da
at
ta
as
sh
he
ee
et
t
V
V1
1.
.0
0
Model
Description
D34
White casing, CE certified module, includes 1pc 1000mAh CR2477 coin
battery, RoHS
The Digital Broadcasting Device D34 is a modern iBeacon with ARM core chipset nRF51822 and leverage
BLE 4.0 technology; it has a cone shape case, accurate hardware and robust firmware. It is designed for the
commercial advertising and indoor location-based service.
The Digital Broadcasting Device broadcasts 2.4GHz radio signals at regular and adjustable intervals. The
Digital Broadcasting Device can be heard and interpreted by iOS and Android BLE-enabled devices that are
equipped with many mobile apps.
TEL: +86-755-8886 8480 FAX: +86-755-2982 5342 EMAIL: sales@minewtech.com URL: www.minewtech.com
Page 2
Minew Technologies
D34 iBeacon / Eddystone
Datasheet V1.0
FEATURES
- Programmed standard firmware
- Included 1pc 1000mAh coin battery
- The max. 100 meters advertising distance
- Ultra-low power consumption chipset nRF51822 with ARM core
- Easy to print the logo on the center of top case;
SPECIFICATION
D34 Digital Broadcasting Device
Compatibility
- Supported iOS 7.0+ and Android 4.3+ system;
- Compatible with Apple iBeaconTM standard;
- Compatible with all Bluetooth 4.0 (BLE) devices;
Long Battery Lifetime and Battery Level
- 12 months, with the default settings;
- LED will be flashing when battery low;
- Easy to get the real-time battery level notification;
Soft-reboot
- Reboot the device via command without any tools;
OTA and J-Link
- Supported upgrade via Over-The-Air;
- Reserved J-Link port on the board for programming;
Connection Mode
- Advertising mode, non-connectable;
- Configuration mode, connectable;
Configurable Parameters
- UUID, Major, Minor, Device Name, Password etc.
- Special Configuration APP;
Transmission Power Levels
- 8 adjustable levels, range from 0 to 7
- Transmission power range: -30dBm to +4dBm;
Long Range
- The max. Range 100 meters in the open space;
- The range depends on the physical environment;
Security
- 8 characters password (Lock/Unlock parameters);
- Broadcast the encrypted data if needed;
- AES HW encryption
Mounting
- 3M branded adhesive for direct mounting to wall;
TEL: +86-755-8886 8480 FAX: +86-755-2982 5342 EMAIL: sales@minewtech.com URL: www.minewtech.com
Page 3
Minew Technologies
D34 iBeacon / Eddystone
Datasheet V1.0
CONFIGURABLE PARAMETERS
Item
Default Settings
UUID
E2C56DB5-DFFB-48D2-B060-D0F5A71096E0 (Proximity)
Major
0
Minor
0
Measured Power
-59 (0xC5)
Transmission Power
6 (0dBm)
Change Password
minew123 (Must be 8 characters)
Broadcasting Interval
9(900mS)
Serial ID
Random (Unique serial ID for beacon)
iBeacon Name
MiniBeacon_ (the maximum 14 characters)
Connection Mode
0 (connectable, configuration mode)
Soft Reboot
minew123 (it is same as the value of Change Password)
ELECTRONIC PARAMETERS
Item
Value
Remarks
Case Color
white
Battery Model
1 x CR2477
1pc CR2477 coin battery, 1000mAh, 3.0V
Operation Voltage
1.8-3.6V
DC
Transmission Circuit
10.5mA (Max.)
Tested at 0dBm transmission power
Transmission Range
100 meters
Maximum
Antenna
50ohm
On board / PCB Antenna
Accessories
Double adhesive
1pc, high-strength, 3M brand;
Net Weight
25.0g
With battery
Size
Ø 48.4 x 19.1 mm
Null
APPDENDIX
1. J-LINK Programmer Kit;
2. Over-the-Air Function;
DECLARATION
The contents of this datasheet are subject to change without prior notice for further improvement. Minew
team reserves the right to explain all the terms of this datasheet. <END>
