Sony 68552B GSM/WCDMA/LTE Phone with BT, DTS/UNII a/b/g/n/ac, GPS & NFC User Manual Sony Mobile Communications AB

Sony Mobile Communications Inc GSM/WCDMA/LTE Phone with BT, DTS/UNII a/b/g/n/ac, GPS & NFC Sony Mobile Communications AB

PY7-68552B_user_guide

Device basics
SIM
3
1
4
2
6
5
8
9
7
1Charging/Notification light
2 NFC
3 Volume/Zoom key
4 Power key/Fingerprint sensor
5 Nano SIM/Memory card slot
6 Camera key
7 Charger/USB Type-C™ cable port
8 Tray 2 for SIM card 2 or memory card
9 Tray 1 for SIM card 1
To insert either two nano SIM cards or
a nano SIM card and a memory card
SIM
Using two SIM cards and a memory card at the same
time is not possible. Tray 2 allows you to use either a
second SIM card or an additional memory card. Do not
cut your SIM cards, as this may damage your device.
1Drag out tray 2 and tray 1.
2Place the main SIM card securely in tray 1, as shown in
the illustration.
3Place either the second SIM card or the memory card
securely in tray 2, as shown in the illustration.
4Gently push first tray 1, then tray 2, back into their slots
until they fit into place.
To turn on your device
It is important to use the USB Type-C cable provided
when charging your device, as other types of USB cables
can damage your device. It is recommended to charge
the battery for at least 30 minutes before you turn on
your device for the first time.
1Press and hold down the power key until your device
vibrates.
2Wait a moment for your device to start.
To activate the screen
•Briefly press the power key .
Screen protection
Before using your device, remove the protection film by
pulling up on the protruding tab.
Screen covers and protectors may help you protect your
device against damage. We recommend you use only those
screen covers intended for your Xperia™ device. The use of
third party screen protection accessories may prevent your
device from working correctly by covering sensors, lenses,
speakers, or microphones and can invalidate the warranty.
Support for you
You can access our support website directly from your
device by visiting
support.sonymobile.com
to find user
guides, downloadable content, troubleshooting tips and
contact information.
Even if you don’t have a network connection, you can
access support contact information on your device.
Depending on the country or region where you
purchased your device, you can find this information
using the Support application.
To access the Support application
1From your Home screen, tap .
2Find and tap .
Connect to the internet when using the Support
application for the best available support.
Warranty, SAR and usage guidelines
For information about warranty, SAR (Specific Absorption
Rate) and safety guidelines, please read the Important
information provided under Settings > System > About
phone > Legal information on your device.
Transferring contacts and content
If you need help with transferring contacts, messages,
photos or other data from an old device to your new
device, we recommend that you use the Xperia™ Transfer
application. Visit
www.sonymobile.com/xperiatransfer
for
more information.
To view the CE marking and the FCC ID
TYPE: XX-0000-XX
FCC ID: XX0-00000X
IC: 0000X-00000X
Sony Mobile Communications
Inc, 4-12-3 Higashi-Shinagawa
Shinagawa-ku Tokyo 140-0002
1Drag out tray 2.
2Drag out the label strip in the same way.
To see the full text of the EU declaration of conformity,
visit:
http://www.compliance.sony.de/
To view the regulatory compliance
mark
•Open the phone dialer, then enter *#07#.
Legal information
Publication number: 1309-7838.1
This Startup guide is published by Sony Mobile Communications Inc. or its local aliated company,
without any warranty. Improvements and changes to this Startup guide necessitated by typographical
errors, inaccuracies of current information, or improvements to programs and/or equipment, may be
made by Sony Mobile Communications Inc. at any time and without notice. Such changes will, however,
be incorporated into new editions of this Startup guide. All illustrations are for illustration only and may
not accurately depict the actual device.
See regulatory information such as the device CE marking in the relevant label tray in the device.
All product and company names mentioned herein are the trademarks or registered trademarks of their
respective owners. Any rights not expressly granted herein are reserved.
Visit
www.sonymobile.com/global-en/legal/
for more information.
Manufacturer: Sony Mobile Communications Inc., 4-12-3 Higashi-Shinagawa, Shinagawa-ku, Tokyo,
140-0002 Japan. For EU product compliance: Sony Belgium, bijkantoor van Sony Europe Limited, Da
Vincilaan 7-D1, 1935 Zaventem, Belgium.
© 2017 Sony Mobile Communications Inc. All rights reserved.
Supported frequency bands
Some frequency bands might be turned o in certain markets or by certain operators.
G8342
UMTS HSPA+ (Bands 1, 2, 4, 5, 6, 8, 19) GSM GPRS/EDGE 850, 900, 1800, 1900 LTE (Bands 1, 2, 3, 4, 5, 7, 8,
12, 13, 17, 19, 20, 25, 26, 28, 29, 32, 38, 39, 40, 41, 66) WLAN, 2.4G/5G, NFC
You can find your model number under Settings > System > About phone.
GSM 850/900 : Power Class 4, DCS(1800)/PCS(1900) : Power Class 1, UMTS : Power Class 3,
LTE : Power Class 3, 2.4GHz : 100mW, 5.15-5.35GHz : 200mW, 5.47-5.725GHz : 500mW, NFC 13.56MHz
Startup guide
Xperia™ XZ1
G8342
1309-7838.1
