08 user manual part 2
S302
User guide
2
Thank you for purchasing a Sony Ericsson S302. For
additional phone content, go to www.sonyericsson.com/fun.
Register now to get free online storage and special offers at
www.sonyericsson.com/myphone. For product support, go to
www.sonyericsson.com/support.
Instruction symbols
The following appear in this User guide:
> Use the navigation key to scroll and select
Press the centre selection key
Press the navigation key up
Press the navigation key down
Press the navigation key to the left
Press the navigation key to the right
Note
Tip
Warning
Indicates that a service or function is network- or
subscription-dependent. All menus or functions may
not be available in your phone. Consult your network
operator for more information.
3
SIM card
The SIM (Subscriber Identity Module) card, which you
get from your network operator, contains information
about your subscription. Always turn off your phone
and detach the charger and the battery before you
insert or remove the SIM card.
PIN code (SIM card lock)
The PIN (Personal Identification Number) code is a SIM card
lock that protects your subscription, but not the phone itself.
If the card is locked, you have to enter the PIN code when you
turn on your phone. To change your PIN code, see SIM card
lock on page 36.
Each PIN digit appears as *, unless it starts with emergency
number digits, for example, 112 or 911. You can call an
emergency number without entering a PIN.
You can save contacts on the SIM card before removing it
from your phone. You can also save contacts in the phone
memory. See Contacts on page 22.
If you enter the wrong PIN three times in a row, PIN
blocked appears. To unblock it, you need to enter your
PUK (Personal Unblocking Key).
4
Charging the battery
The phone battery is partly charged when you buy it. It takes
approximately 2.5 hours to fully charge the battery.
To charge the battery
1Connect the charger to the phone with the power icon on
the charger facing upwards. Press a key to illuminate the
screen and see the charging status.
2To remove the charger, tilt and pull the plug upwards.
The battery icon on the screen may not appear until the
phone has charged for 30 minutes.
You can use the phone during charging. You can charge
the battery for more or less than 2.5 hours. Interrupted
charging will not damage the battery.
5
Memory Stick Micro™
Your phone supports Memory Stick Micro™ (M2™). A memory
card adds more storage space to your phone, for example,
music, ringtones, video clips and pictures. You can share your
saved information by moving or copying it to other memory
card compatible devices.
To insert Memory Stick Micro™ (M2™)
•Open the cover and insert the memory card (with the gold-
coloured contacts facing down).
To remove a Memory Stick Micro™ (M2™)
•Press the edge to release and remove.
6
Turning on the phone
To turn on the phone
1Press and hold down .
2Enter your SIM card PIN, if
requested.
3Select Yes to use the setup
wizard.
Standby
After you have turned on the phone and entered your PIN, the
name of your operator appears on the screen. This is called
standby. You can now make and receive calls.
To turn the phone off
•Press and hold down .
If you make a mistake when you enter your PIN, you can
press to delete numbers from the screen.
If your phone cannot turn on, attach the charger and
charge the phone for 2.5 hours.
If your phone turns itself off when being transported, turn
the automatic keylock on. This prevents things in your
pocket or bag from activating the on/off key accidentally.
7
Network coverage
The network bars show the strength of the GSM network in
your area. Move to another location if you have problems
calling and network coverage is poor. No network means you
are not in range of a network.
Battery status
= Good network coverage
= Average network coverage
= The phone battery is fully charged
= The phone battery is empty
If you cannot turn on the phone, attach the charger
properly and try charging the phone until it has finished
charging.
Battery status
Network
coverage
14
Radio
To listen to the radio
1Connect the handsfree to the phone.
2From standby select Menu > Radio.
To control the radio
•Press or to search for FM radio channels.
To save an FM radio channel
•Select Options > Save.
•Scroll to a position and press Select.
To listen to a saved FM radio channel
•When the FM radio is on, press – .
To exit the FM radio
1Select Back or press .
2Minimise radio? appears. Select No.
To turn the FM radio off when minimised
1Select Menu > Radio.
2Select Back or press .
3Minimise radio? appears. Select No.
To view FM radio options
•When the FM radio is on, select Options.
Do not use your phone as a radio in places where
it is prohibited.
13
Settings**
General
Profiles
Time & date
Phone language
Shortcuts
Flight mode
Security
Phone status
Reset all
Sounds & alerts
Ring volume
Ringtone
Silent mode
Vibrating alert
Message alert
Key sound
Display
Wallpaper
Themes
Startup screen
Screen saver
Brightness
Calls
Speed dial
Divert calls
Manage calls
Time & cost*
Show/hide no.
Handsfree
Connectivity
Bluetooth
USB
Synchronisation
Mobile networks
Internet settings
*Some menus are operator-, network- and subscription-dependent.
** You can use the navigation key to scroll between tabs in submenus.
For more information, see Navigation on page 11.
12
Menu overview
PlayNow™*
Internet*
Homepage, Enter address,
Bookmarks, History, Saved
pages, Internet settings
Entertainment Games, TrackID™, Video player,
Record sound
Camera
Messaging
Write new, Inbox, Email, Drafts,
Outbox, Sent messages, Call
voicemail, Templates, Settings
Music player
File manager** All files, On mem. card, In phone
Contacts New contact
Radio
Calls**
All Dialled Missed Answered
Organiser
Alarm, Applications, Calendar,
Tasks, Synchronisation, Timer,
Stopwatch, Light, Calculator
11
Navigation
The main menus are shown as icons. Some submenus
include tabs.
To navigate the phone menus
1From standby select Menu.
2Use the navigation key to move through the menus.
To scroll between the tabs
•Press the navigation key left or right.
To go back one step in the menu
•Select Back.
To return to standby
•Press .
To lock the keypad
•Press and select Lock.
To unlock the keypad
•Press and select
Unlock.
To set the phone to silent
•Press and hold down .
To call your voicemail service
•Press and hold down .
To end a function
•Press .
9
Phone overview
3
1
210
1 Ear speaker
2 Music key
3 Screen
4 Selection keys
5 Call key
6 Shortcuts menu key
7
Connector for
charger, handsfree
and USB cable
8 Navigation key
9 Centre selection key
10 Volume keys/camera
zoom keys
11 On/off key
End call key
12 C key (Clear)
13 Camera key/video
recorder key
14 Silent key
4
5
6
11
12
13
8
7
14
9
8
Screen icons
These icons may appear on the screen.
Icon Description
Ongoing call
Missed call
Handsfree connected
Phone set to silent
Predictive text input activated
Text message received
Picture message received
Email message received
Voice message received
FM radio playing
Alarm activated
Bluetooth function activated
10
Key
Go to the main menus or select items
Scroll between the menus and tabs
Select options shown immediately above these keys
on the screen
Delete items, such as pictures, sounds and contacts.
On the side:
Press to stop or play music when in the Music player
mode
Press to mute or unmute the radio. Works only if an
audio accessory is connected
Press to move between the Music player and standby
My shortcuts – add your favourite functions to access
them quickly
From standby press to activate Camera and video
recorder
Press and hold down to turn the phone on/off
Press to end a call
Press to make a call after you gave entered the phone
number
15
Imaging
Camera and video recorder
You can take pictures and record video clips to view, save
or send. You can find your saved pictures and video clips
in Menu > File manager > Camera album.
To take a picture
1Activate the camera.
2Use the navigation key to select .
3Press to take a picture.
4Select to take another picture.
1Zoom in or out, works
only in VGA mode
2Press to take another
3Take pictures/Record
video clips
4 Screen options
16
To use the zoom
•Press the volume keys up or down.
Camera settings
You can select different settings before you take a picture
or record a video clip.
1When the camera is activated, select .
2Use the navigation key to select camera settings.
To record a video clip
1Activate the camera.
2Use the navigation key to select .
3Press fully down to start recording. The video clip is
automatically saved on the memory card, if a memory card
is inserted. If not, the video clip is saved in the phone
memory.
To stop recording
•Press . The video clip is automatically saved on the
memory card.
Do not record with a strong light source in the background.
Use a support or the self-timer to avoid a blurred picture.
When taking a picture, zoom is available in VGA mode only.
To use the camera light you must turn it on manually.
To stop using the camera light you turn it off manually.
17
To delete pictures and video clips
1From standby select Menu > File manager > Camera
album.
2Scroll to an item and press .
Photo fix
You can improve an under-exposed picture with Photo fix.
To improve a picture with Photo fix
1Activate the camera.
2Take a picture.
3Find the picture in Camera album.
4Select Options > Photo fix.
Picture blog
A picture blog is a personal Web page. If your subscription
supports this service, you can send pictures to a blog.
To send camera pictures to a blog
1From standby select Menu > File manager > Camera
album.
2Scroll to a picture and select Options > Send > To blog.
3Add title and select Edit.
4Add text and select Edit.
5Select OK > Publish.
Web services may require a separate license agreement
between you and the service provider. Additional
regulations and/or charges may apply. Contact your
service provider.
18
To go to a blog address from contacts
1From standby select Menu > Contacts.
2Select a contact.
3Scroll to a Web address and select Go to.
To transfer pictures to and from your computer
You can use Bluetooth™ wireless technology and the USB
cable to transfer pictures and video clips between your
computer and phone. See Bluetooth™ on page 31 and
To transfer files on page 26 for more information.
Pictures and video clips
You can add a picture of a contact, use it during phone-start
up, as a wallpaper in standby or as a screen saver.
To use pictures
1From standby select Menu > File manager > Pictures.
2Scroll to a picture and select Options > Use as.
3Select an option.
Make sure the receiving device supports the transfer
method you select.
19
Calling
You must turn on the phone and be within range of a network.
To make a call
1From standby enter a phone number (with international
country code and area code, if applicable).
2Press .
To end a call
•Press .
To answer a call
•Press .
To reject a call
•Press .
To change the ear
speaker volume during
a call
•Press the volume key up or down.
To turn the loudspeaker on during a call
•Select Speaker.
You can call numbers from your contacts and call list.
See Contacts on page 22, and Call list on page 20.
Do not hold the phone to your ear when using the
loudspeaker. This could damage your hearing.
20
To make international calls
1From standby press and hold down until a + sign
appears on the screen.
2Enter the country code, area code (without the first zero)
and phone number.
3Press .
To view missed calls from standby
•When Missed calls: is displayed, select View. To call back
scroll to the number and press .
Call list
You can view information about recent calls.
To call a number from the call list
1From standby press .
2Scroll to the name or number and press .
To delete a number from the call list
1From standby press .
2Scroll to the name or number and press > Yes.
21
Internet
You need the correct Internet settings in your phone. If the
settings are not in your phone, you can:
•Get them in a text message from the network operator.
•On a computer, go to www.sonyericsson.com/support and
request a text message with the settings.
To select an Internet profile
1From standby select Menu > Internet > Internet settings
> Accounts.
2Select an account.
To start browsing
1From standby select Menu > Internet.
2Select an option:
Homepage – go to the predefined homepage.
Enter address – enter a Web address.
Bookmarks – go directly to a saved Web page.
History – show previously visited pages.
Saved pages – go directly to a saved Web page.
Internet settings – select options such as accounts,
connection time, White list.
To stop browsing
•When you are browsing, press and hold down .
22
Contacts
You can save contacts in the phone memory or on the SIM
card. You can copy contacts from the phone memory to the
SIM card or from the SIM card to the phone memory.
Default contacts
You can choose which contact information is shown as
default. If Phone contacts is selected as default, your contacts
show all the information saved in Contacts. If you select SIM
contacts as default, your contacts show names and numbers
saved on the SIM card.
To select default contacts
1From standby select Menu > Contacts > Options > More
> Default contacts.
2Select an option.
Contacts memory
The number of entries you can save in Contacts depends
on the capacity of your SIM card.
To check the Contacts memory status
•From standby select Menu > Contacts > Options
> Memory status.
See Entering text on page 33.
23
Phone contacts
Phone contacts can contain names, phone numbers and
personal information. They are saved in the phone memory.
To add a phone contact
1From standby select Menu > Contacts > New contact.
2Scroll to Last name: and select Add.
3Enter the name and select OK.
4Scroll to First name: and select Add.
5Enter the name and select OK.
6Scroll to New number: and select Add.
7Enter the number and select OK.
8Select Save.
To call a contact
1From standby select Menu > Contacts.
2Scroll to, or enter the first few letters of, the contact.
3Press .
To edit a contact
1From standby select Menu > Contacts.
2Select a contact.
3Select Options > Edit contact.
4Edit the information and select Save.
Enter the + sign and country code with all phonebook
numbers. Then you can use them abroad or at home.
See To make international calls on page 20.
24
To delete a contact
1From standby select Menu > Contacts.
2Select a contact.
3Select Options > Delete.
To copy contacts to the SIM card
1From standby select Menu > Contacts.
2Scroll to a contact.
3Select Options > Options > Copy to SIM.
To view your own phone number
•From standby select Menu > Contacts > Options
> My numbers.
Emergency calls
Your phone supports international emergency numbers, for
example, 112 and 911. These numbers can normally be used
to make emergency calls in any country, with or without the
SIM card inserted, if a GSM network is within range.
To make an emergency call
•From standby enter the international emergency number, for
example 112 and press .
In some countries, other emergency numbers may also
be promoted. Your network operator may therefore have
saved additional local emergency numbers on the SIM
card.
25
Music player
The file types supported are: MP3, MP4, 3GP, AAC, AMR,
MIDI, IMY, EMY and WAV (16 kHz maximum sample rate).
You can also use streamed files that are 3GPP compatible.
Transferring music
You can transfer music from your computer to your phone
memory or Memory Stick Micro™ (M2™). There are two ways
to connect the phone to a computer:
•using a USB cable
•with a Bluetooth wireless technology connection
You can drag and drop files between your phone or memory
card and a computer in Microsoft® Windows Explorer.
To connect your phone to a computer using a USB cable
1Make sure your phone is turned on.
2Connect the USB cable to your phone and the computer.
3Phone: Select Mass storage.
4Computer: Wait for the drivers to be installed (this is done
automatically). The first time you connect your phone to the
computer, you may need to identify and name the phone.
Memory card
Phone memory
26
To transfer files
1Connect the USB cable to the phone and the computer.
2Phone: From standby select Menu > Settings > the
Connectivity tab > USB > Mass storage.
3Computer: Wait until the phone memory and memory card
appear as external disks in Microsoft Windows Explorer.
4Computer: On the computer desktop, double-click the My
Computer icon.
5Computer: To view the phone memory and memory card
folders, double-click the icon representing your phone
under Devices with removable storage. Double-click on the
removable disk to view M2 folders.
6Copy and paste your file, or drag and drop it, into the folder
you want on your computer, in your phone memory or on
your memory card.
7To safely disconnect the USB cable in File transfer mode,
right-click the Removable Disk icon in Windows Explorer
and select Eject.
Do not remove the USB cable from the phone or computer
during transfer, as this may corrupt the memory card and
the phone memory. You cannot view the transferred files
in your phone until you have removed the USB cable from
the phone.
More information about transferring files to your phone is
available at www.sonyericsson.com/support.
27
To Play Music
1From standby select Menu > Music player > Options
> My music > Tracks.
2Scroll to a title and select Play.
To stop playing music
•Press the centre navigation key.
To move between track
•Press or .
Browsing files
From standby select Menu > Music player > Options
> My music. Music is saved and categorized:
•Artists – list music by artist.
•Albums – list music by album.
•Tracks – list all music tracks.
•My playlists – create own lists of tracks.
•Onl.channels – list of bookmarks with streaming video
or music.
Playlists
To organise the media files that are saved in File manager, you
can create playlists.
To create a playlist
1From standby select Menu > Music player > Options
> My music > My playlists > New playlist.
2Enter a name and select OK.
3Scroll to a track and select OK.
28
PlayNow™
With PlayNow™ you can preview, buy and download music via
the Internet. You can find PlayNow™ in Menu > PlayNow™.
TrackID™
TrackID™ is a music recognition service. You can search for
song titles, artists and album names.
To search for song information
•When you hear a song through a loudspeaker, from standby
select Menu > Entertainment > TrackID™ > Start.
•When the radio is playing select Options > TrackID™.
You need the correct Internet settings in your phone
to use this function. See Internet on page 21.
You need the correct Internet settings in your phone
to use this function. See Internet on page 21.
35
Voicemail
Callers can leave a voicemail message when you cannot
answer. You can get your voicemail number from your network
operator.
To enter your voicemail number
1From standby select Menu > Messaging > Settings
> Voicemail no.
2Scroll to the voicemail number and select OK.
3Enter the voicemail number that you get from your service
provider and press OK.
To call your voicemail service
•From standby press and hold down .
Flight mode
In Flight mode the network and radio transceivers are turned
off to prevent disturbance to sensitive equipment. When the
flight mode menu is activated you are asked to select a mode
the next time you turn on your phone:
•Normal – full functionality.
•Flight mode – limited functionality. Only Music player.
To activate the flight mode menu
•From standby select Menu > Settings > the General tab
> Flight mode > Show at startup.
34
To enter text using multitap
•Press – until the character you want appears.
•Press to add a space.
•Press to enter full stops and commas.
•Press to shift between upper-case and lower-case
letters.
•Press and hold down – to enter numbers.
To change text input methods
•When you write the message, press and hold down .
To add items in a text message
•When you write the message, select Options > Insert item.
•Select an option.
To delete characters
•Select .
To change writing language
•When you write the message, press and hold down .
Automatic keylock
The keypad is locked after a short while.
To turn on the automatic keylock
•From standby select Menu > Settings > the General tab
> Security > Automatic keylock > On.
Calls to the international emergency number 112 can still
be made, even when the keypad is locked.
33
More functions
Shortcuts
The shortcut menu gives you quick access to certain functions.
To open the shortcut menu
•Press .
Entering text
There are two methods you can use to enter text: multitap or
predictive text input.
To enter text using predictive text input
1For example, write the word “Jane”, press
.
2You now have several options:
•If the word shown is the one you want, press to accept
and add a space.
•To accept a word without adding a space, press . If the
word shown is not the one you want, press or
repeatedly to view alternative words.
•To accept a word and add a space, press .
•To enter full stops and commas, press and then
or repeatedly.
By using predictive text input you only have to press each
key once. Continue writing a word even if it appears to be
wrong. The phone uses the dictionary to recognise the
word when all letters are entered.
32
To pair a device with your phone
1To search for available devices, from standby select Menu
> Settings > the Connectivity tab > Bluetooth > My
devices > New device.
2Select a device from the list.
3Enter a passcode, if required.
To pair your phone with a Bluetooth handsfree
1To search for available handsfree devices, from standby
select Menu > Settings > the Connectivity tab > Bluetooth
> My devices > New device.
2Scroll to a device and select Yes.
3Enter a passcode, if required.
To receive an item
1From standby select Menu > Settings > the Connectivity
tab > Bluetooth > Turn on.
2When you receive an item, follow the instructions that
appear.
To send an item using Bluetooth
1From standby select, for example, Menu > File manager
> Camera album.
2Scroll to a picture and select Options > Send > Bluetooth.
30
Picture messages (MMS)
Picture messages can contain text, sound and images. They
are sent using MMS to a mobile phone. You need the correct
Internet settings in your phone to use this function. See
Internet on page 21.
To create a picture message
1From standby select Menu > Messaging > Write new
> Picture msg.
2Select an option to create the message.
To send a picture message
1When the message is ready, select Cont.
2Select an option.
3Select OK > Send.
Sending and receiving phones must have subscriptions
that support picture messaging. Make sure that you have
a phone subscription that supports data transmission,
and the correct settings in your phone.
29
Messaging
Text messages (SMS)
You must have a service centre number, which is supplied
by your service provider and saved on the SIM card. You may
have to enter the number yourself.
To write and send a text message
1From standby select Menu > Messaging > Write new
> Text message.
2Write the message and select Cont.
3Select an option.
4Select OK > Send.
To view a received text message
1New message from: appears. Select View.
2Select the unread message.
To view messages saved in the inbox
•Select Menu > Messaging > Inbox.
To get delivery status of a sent message
1From standby select Menu > Messaging > Settings > Text
message > Delivery report.
2Select On. You are notified when a message has been
successfully delivered.
Make sure you have a valid service centre number in your
phone.
See Entering text on page 33.
31
Bluetooth™
Bluetooth™ wireless technology allows wireless connection
to other Bluetooth devices, for example, a Bluetooth headset.
You can:
•connect to several devices at the same time.
•exchange items.
To turn the Bluetooth function on
•From standby select Menu > Settings > the Connectivity
tab > Bluetooth > Turn on.
To show or hide your phone
•From standby select Menu > Settings > the Connectivity
tab > Bluetooth > Visibility > Show phone or Hide phone.
The recommended maximum distance between two
Bluetooth devices is 10 metres (33 feet), with no solid
objects in between.
Check if local laws or regulations restrict the use of
Bluetooth wireless technology. If it is not allowed, you
must ensure that the Bluetooth function is turned off.
If the phone cannot be detected by other devices using
Bluetooth wireless technology turned the Bluetooth
functionality on. Make sure that the visibility is set to Show
phone. If set to Hide phone, other device will not be able
to identify your phone using Bluetooth wireless
technology.
Sony Ericsson Mobile Communications AB
SE-221 88 Lund, Sweden
www.sonyericsson.com
1212-6360.1
Printed in XXXX
36
SIM card lock
Your PIN and PUK are supplied by your network
operator.
To unblock your SIM card
1When PIN blocked is displayed, select Unlock.
2Enter your PUK and select OK.
3Enter a new PIN and select OK.
4To confirm re-enter the new PIN and select OK.
To turn the SIM card lock on
1From standby select Menu > Settings > the General
tab > Security > Locks > SIM protection > Protection.
2Enter your PIN and select OK.
3Select On.
To edit your PIN
1From standby select Menu > Settings > the General
tab > Security > Locks > SIM protection
> Change PIN.
2Enter your PIN and select OK.
3Enter a new PIN and select OK.
4To confirm re-enter the new PIN and select OK.
If the message Wrong PIN Attempts remaining:
appears when you edit your PIN, you entered the PIN
or PIN2 incorrectly.
37
Phone lock
The phone lock protects the phone against unauthorised
use. You can change the phone lock code (0000 by
default) to any four-digit code.
To turn the phone lock on
1From standby select Menu > Settings > the General
tab > Security > Locks > Phone protection.
2Select View code, enter the current code and
select OK.
To edit your phone lock code
1From standby select Menu > Settings > the General
tab > Security > Locks > Phone protection
> Change code.
2Enter the current code and select OK.
3Enter a new code and select OK.
4To confirm, re-enter the new code and select OK.
If the phone lock is set to Off, you do not need to
enter your phone lock code unless a different SIM
card is inserted in the phone.
The Phone protection must be activated to enable
the protection code to be changed.
If you forget the new code, you have to take the
phone to your local Sony Ericsson retailer.
38
To unlock the phone
1From standby select Menu > Settings > the General
tab > Security > Locks > Phone protection
> View code.
2Enter your phone lock code and select OK.
3Select Off.
Master reset
If you experience problems with your phone, such as
screen flickering, or freezing and navigation problems,
you should reset the phone.
From standby select Menu > Settings > the General tab
> Reset all > Cont. > Cont.
Reset all deletes all user data such as contacts,
messages, pictures and sounds in your phone.
Restart your phone every day to free memory or do
a Master reset if you have problems with memory
capacity or the phone is working slowly.
39
The Liquid Identity logo, PlayNow and TrackID are trademarks or
registered trademarks of Sony Ericsson Mobile Communications
AB. Sony, M2, Memory Stick Micro, and WALKMAN are
trademarks or registered trademarks of Sony Corporation.
Ericsson is a trademark or registered trademark of
Telefonaktiebolaget LM Ericsson. All other trademarks are property
of their respective owners. MPEG Layer-3 audio decoding
technology licensed from Fraunhofer IIS and Thomson.
Export Regulations: This product, including any software or
technical data contained in or accompanying the product, may
be subject to U.S. export control laws, including the U.S. Export
Administration Act and its associated regulations and the U.S.
sanctions programs administered by the U.S. Treasury
Department’s Office of Foreign Assets Control, and may be
additionally subject to export or import regulations in other
countries. The user and any possessor of the product agrees to
comply strictly with all such regulations and acknowledges that it
is their responsibility to obtain any required licenses to export, re-
export, or import this product. Without limitation this product,
including any software contained therein, may not be downloaded,
or otherwise exported or re-exported (i) into, or to a national or
resident of, or an entity in, Cuba, Iraq, Iran, North Korea, Sudan,
Syria (as such listing may be revised from time to time) or any
country to which the U.S. has embargoed goods; or (ii) to any
person or entity on the U.S. Treasury Department’s list of Specially
Designated Nationals or (iii) any person or entity on any other
export prohibition list that may be maintained from time to time by
the United States Government, including but not limited to the U.S.
Commerce Department’s Denied Persons List or Entity List, or the
U.S. State Department’s Nonproliferation Sanctions List.
40
Declaration of conformity for S302
We, Sony Ericsson Mobile Communications AB of
Nya Vattentornet
SE-221 88 Lund, Sweden
declare under our sole responsibility that our product
Sony Ericsson type AAC-1052121-BV
and in combination with our accessories, to which this declaration relates
is in conformity with the appropriate standards EN 301 511:V9.0.2,
EN 300 328:V1.7.1, EN 301 489-7:V1.3.1, EN 301 489-17:V1.2.1 and
EN 60950-1:2006, following the provisions of, Radio Equipment and
Telecommunication Terminal Equipment Directive 1999/5/EC.
We fulfil the requirements of the R&TTE Directive (1999/5/EC).
FCC Statement
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
Any change or modification not expressly approved by Sony Ericsson
may void the user’s authority to operate the equipment. This equipment
has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Lund, March 2008
Shoji Nemoto, Head of Product Business Unit GSM/UMTS
41
Industry Canada Statement
This device complies with RSS-210 of Industry Canada. Operation is
subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device. This
Class B digital apparatus complies with Canadian ICES-003. Cet appareil
numérique de la classe B est conforme à la norme NMB-003 du Canada.
Sony Ericsson W302
GSM 850/900/1800/1900
This User guide is published by Sony Ericsson Mobile Communications
AB or its local affiliated company, without any warranty. Improvements
and changes to this User guide necessitated by typographical errors,
inaccuracies of current information, or improvements to programs and/or
equipment, may be made by Sony Ericsson Mobile Communications AB
at any time and without notice. Such changes will, however, be
incorporated into new editions of this User guide.
All rights reserved.
© Sony Ericsson Mobile Communications AB, 2008
Please note: Some of the services in this User guide are not supported
by all networks. This also applies to the GSM International Emergency
Number 112. Please contact your network operator or service provider if
you are in doubt whether you can use a particular service or not. Please
read the Important information before you use your mobile phone. All
illustrations are for illustration only and may not accurately depict the
actual phone.
Your mobile phone has the capability to download, store and forward
additional content, e.g. ringtones. The use of such content may be
restricted or prohibited by rights of third parties, including but not
limited to restriction under applicable copyright laws. You, and not
Sony Ericsson, are entirely responsible for additional content that you
download to or forward from your mobile phone. Prior to your use of
any additional content, please verify that your intended use is properly
licensed or is otherwise authorised. Sony Ericsson does not guarantee
the accuracy, integrity or quality of any additional content or any other
third party content. Under no circumstances will Sony Ericsson be liable
in any way for your improper use of additional content or other third party
content. The Predictive Text Technology is used under license from
Zi Corporation. The Bluetooth word mark and logos are owned by the
Bluetooth SIG, Inc. and any use of such marks by Sony Ericsson is
under license. MPEG Layer-3 audio decoding technology licensed from
Fraunhofer IIS and Thomson. Microsoft is registered trademark of
Microsoft Corporation in the United States and/or other countries.
