08 user guide part 2
8Getting started
Phone overview
10
11
12
14
13
3
8
4
5
6
7
2
1
9
1Video call camera
2Ear speaker
3Screen
4Selection keys
5Call key
6Activity menu
7Navigation key
8Keylock key
9Volume, digital zoom keys
10 End key
11 Camera key
12 C key (Clear)
13 Silent key
14 Connector for charger,
handsfree and USB cable
9Getting started
15 On/off key
16
17 Memory card slot
17
16
15
Camera lens
10 Getting started
Menu overview
PlayNow™* Internet* Entertainment
Online services*
Games
TrackID™
VideoDJ™
PhotoDJ™
MusicDJ™
Remote control
Record sound
Demo tour
Camera Messaging Media
Write new
Inbox
Email
Web feeds
Drafts
Outbox
Sent messages
Saved messages
My friends*
Call voicemail
Templates
Manage msgs
Settings
Alarms Contacts Radio
Myself
New contact
11Getting started
Calls** Organizer
All Answered Dialled Missed
File manager**
Applications
Video call
Calendar
Tasks
Notes
Synchronization
Timer
Stopwatch
Calculator
Code memo
Settings**
General
Profiles
Time & date
Language
Update service
Voice control
New events
Shortcuts
Flight mode
Security
Setup wizard
Accessibility*
Phone status
Master reset
Sounds & alerts
Ring volume
Ringtone
Silent mode
Increasing ring
Vibrating alert
Message alert
Key sound
Display
Wallpaper
Themes
Startup screen
Screen saver
Clock size
Brightness
Edit line names*
Calls
Speed dial
Smart search
Divert calls
Switch to line 2*
Manage calls
Video share*
Time & cost*
Show/hide my no.
Handsfree
Connectivity*
Bluetooth
USB
Phone name
Network sharing
Synchronization
Device mgmt
Mobile networks
Internet settings
Streaming settings
Message settings*
Accessories
* Some menus are operator-, network- and subscription-dependent.
** You can use the navigation key to scroll between tabs in submenus. For more information, see Navigation
on page 12.
12 Getting started
Navigation
The main menus are shown as icons.
Some submenus include tabs.
To navigate the phone menus
1From standby select Menu.
2Use the navigation key to move through
the menus.
To scroll between the tabs
•Scroll to a tab by pressing the navigation
key left or right.
To view options for an item
•Select Options to, for example, edit.
To return to standby
•Press .
To end a function
•Press .
To navigate your media
1From standby select Media.
2Use the navigation key to move up,
down, left and right through the menus.
To delete items
•Press to delete items such as
numbers, letters, pictures and sounds.
File manager
You can use the file manager to handle
files saved in the phone memory or on
a memory card.
Handling files
You can move and copy files between
your phone, a computer and a memory
card. Files are saved on the memory
card first and then in the phone memory.
Unrecognized files are saved in the
Other folder.
To move a file in the file manager
1From standby select Menu > Organizer
> File manager.
2Find a file and select Options > Manage
file > Move.
3Select an option.
Centre navigation key You may have to purchase a memory
card separately.
13Getting started
To select more than one file
in a folder
1From standby select Menu > Organizer
> File manager.
2Scroll to a folder and select Open.
3Select Options > Mark > Mark several.
4For each file you want to mark, scroll
to the file and select Mark.
To delete a file from the file manager
1From standby select Menu > Organizer
> File manager.
2Find the file and press .
Phone language
You can select a language to use
in your phone.
To change the phone language
1From standby select Menu > Settings
> the General tab > Language > Phone
language.
2Select an option.
Entering text
You can use multitap text input or T9™
Text Input to enter text. The T9 Text
Input method uses a built-in dictionary.
To change text input method
•When you enter text, press and hold
down .
To shift between capitals and
lower-case letters
•When you enter text, press .
To enter numbers
•When you enter text, press and hold
down – .
To enter full stops and commas
•When you enter text, press .
To enter text using T9™ Text Input
1From standby select, for example,
Menu > Messaging > Write new > Text
message.
2If is not displayed, press and hold
down to change to T9 Text Input.
3Press each key only once, even if the
letter you want is not the first letter
on the key. For example, to write the
word “Jane”, press , , ,
. Write the whole word before
looking at the suggestions.
4Use or to view suggestions.
5Press to accept a suggestion.
14 Calling
To enter text using multitap
1From standby select, for example,
Menu > Messaging > Write new > Text
message.
2If is displayed, press and hold down
to change to multitap text input.
3Press – repeatedly until the
desired letter appears.
4When a word is written, press
to add a space.
To add words to the built-in dictionary
1When you enter text using T9 Text
Input, select Options > Spell word.
2Write the word using multitap input
and select Insert.
Calling
Making and receiving calls
You need to turn on your phone and
be within range of a network.
To make a call
1From standby enter a phone number
with international country code and
area code, if applicable.
2Press .
To make international calls
1From standby press until a “+”
sign appears.
2Enter the country code, area code
(without the first zero) and phone
number.
3Press .
To re-dial a number
•When Retry? appears select Yes.
You can call numbers from your contacts
and call list. See Contacts on page 16,
and Call list on page 19. You can also
use your voice to make calls. See Voice
control on page 20.
Do not hold your phone to your ear
when waiting. When the call connects,
your phone gives a loud signal.
15Calling
To answer a call
•Press .
To reject a call
•Press .
To change the ear speaker volume
during a call
•Press the volume key up or down.
To mute the microphone during a call
1Press and hold down .
2Press and hold down again
to resume.
To turn the loudspeaker on during
a call
•Select SpkrOn.
To view missed calls from standby
•Press and scroll to the New events
tab and select a number.
•Press to open the call list.
Emergency calls
Your phone supports international
emergency numbers, for example,
112 and 911. These numbers can
normally be used to make emergency
calls in any country, with or without
the SIM card inserted, if a 3G (UMTS)
or GSM network is within range.
To make an emergency call
•From standby enter 112 (the
international emergency number)
and press .
To view your local emergency
numbers
1From standby select Menu
> Contacts.
2Scroll to New contact and select
Options > Special numbers >
Emergency nos.
Do not hold your phone to your ear
when using the loudspeaker. This could
damage your hearing.
In some countries, other emergency
numbers may also be promoted.
Your network operator may therefore
have saved additional local emergency
numbers on the SIM card.
16 Calling
Video call
See a person on the screen during calls.
Both parties need a subscription that
supports the 3G (UMTS) service, and
you need to be within range of a 3G
(UMTS) network. 3G (UMTS) service
is available when appears.
To make a video call
1From standby enter a phone number
with international prefix and area code
if applicable.
2
To use the zoom with an outgoing
video call
•Press or .
To view video call options
•During the call, select Options.
Contacts
You can save names, phone numbers
and personal information in Contacts.
Information can be saved in the phone
memory or on the SIM card.
Default contact
You can choose which contact
information is shown as default.
If Phone contacts is selected as default,
your contacts show all the information
saved in Contacts. If you select SIM
contacts as default, your contacts
show names and numbers saved
on the SIM card.
To select default contacts
1From standby select Menu > Contacts.
2Scroll to New contact and select
3Select an option.
Phone contacts
Phone contacts can contain names,
phone numbers and personal
information. They are saved in the
phone memory.
To add a phone contact
1From standby select Menu > Contacts.
2Scroll to New contact and select Add.
3Enter the name and select OK.
4Enter the number and select OK.
5Select a number option.
6Scroll between tabs and select the
fields to add information.
7Select Save.
Options > Advanced > Default contacts.
Select Options > Make video Call.
17Calling
Calling contacts
To call a phone contact
1From standby select Menu > Contacts.
2Scroll to a contact and press .
To call a SIM contact from phone
contacts
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > SIM contacts.
3Scroll to a contact and press .
To call with Smart search
1From standby press –
to enter a contact name or a phone
number. All entries which match the
sequence of digits or letters are shown
in a list.
2Scroll to a contact or a phone number
and press .
To turn Smart search on or off
1From standby select Menu > Settings
> the Calls tab > Smart search.
2Select an option.
Editing contacts
To add information to a phone
contact
1From standby select Menu > Contacts.
2Scroll to a contact and select Options
> Edit contact.
3Scroll between the tabs and select Add.
4Select an option and an item to add.
5Select Save.
To copy names and numbers to the
SIM card
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Advanced > Copy to SIM.
3Select an option.
To automatically save names and
phone numbers on the SIM card
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Advanced > Auto save on SIM.
3Select an option.
To save contacts on a memory card
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Advanced > Back up to
m.card.
To go directly to a contact, from standby
press and hold down – .
If your subscription supports Calling Line
Identification (CLI) service, you can
assign personal ringtones to contacts.
18 Calling
SIM contacts
SIM contacts can contain names and
numbers only. They are saved on the
SIM card.
To add a SIM contact
1From standby select Menu > Contacts.
2Scroll to New contact and select Add.
3Enter the name and select OK.
4Enter the number and select OK.
5Select a number option and add more
information, if available.
6Select Save.
To call a SIM contact
1From standby select Menu > Contacts.
2Scroll to a contact and press .
To copy names and numbers
to phone contacts
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Advanced > Copy from SIM.
3Select an option.
Deleting contacts
To delete a contact
1From standby select Menu > Contacts.
2Scroll to a contact and press .
To delete all phone contacts
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Advanced > Delete all
contacts.
Sending contacts
To send a contact
1From standby select Menu > Contacts.
2Scroll to a contact and select Options
> Send contact.
3Select a transfer method.
Memory status
The number of contacts you can save
in your phone or on the SIM card
depends on available memory.
To view memory status
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Advanced > Memory status.
When you copy all contacts from your
phone to the SIM card, all existing
SIM card information is replaced.
Make sure the receiving device supports
the transfer method you select.
19Calling
Myself
You can enter information about
yourself and, for example, send your
business card.
To enter Myself information
1From standby select Menu > Contacts.
2Scroll to Myself and select Open.
3Scroll to an option and edit the
information.
4Select Save.
Groups
You can create a group of phone
numbers and email addresses from
Phone contacts to send messages to.
See Messaging on page 22. You can
also use groups (with phone numbers)
when you create accepted callers lists.
To create a group of numbers and
email addresses
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Groups.
3Scroll to New group and select Add.
4Enter a name for the group and select
Continue.
5Scroll to New and select Add.
6For each contact phone number
or email address you want to mark,
scroll to it and select Mark.
7Select Continue > Done.
Call list
You can view information about recent
calls.
To call a number from the call list
1From standby press and scroll
to a tab.
2Scroll to a name or a number and
press .
To add a call list number to contacts
1From standby press and scroll
to a tab.
2Scroll to the number and select Save.
3Select New contact to create a new
contact or select an existing contact
to add the number to.
Speed dial
Speed dialling lets you select nine
contacts that you can dial quickly. The
contacts can be saved in positions 1-9.
To add contacts to speed dial
numbers
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Speed dial.
3Scroll to a position number and
select Add.
4Select a contact.
20 Calling
To speed dial
•From standby enter the position
number and press .
Voicemail
If your subscription includes
an answering service, callers can
leave a voicemail message when
you cannot answer a call.
To enter your voicemail number
1From standby select Menu > Messaging
> Settings > Voicemail number.
2Enter the number and select OK.
To call your voicemail service
•From standby press and hold down
.
Voice control
By creating voice commands you can:
•Voice dial – call someone by saying
their name.
•Activate voice dialling by saying
a “magic word”.
•Answer and reject calls when you
use a handsfree.
To record a voice command using
voice dialling
1From standby select Menu > Settings
> the General tab > Voice control
> Voice dialling > Activate.
2Select Yes > New voice comm. and
select a contact. If the contact has
more than one number, select the
number to add the voice command to.
3Record a voice command such as
“John mobile”.
4Follow the instructions that appear.
Wait for the tone and say the command
to record. The voice command is played
back to you.
5If the recording sounds OK, select Yes.
If not, select No and repeat steps 3
and 4.
Voice dialling
You can hear your recorded contact
name when you receive a call from
that contact.
To voice dial
1From standby press and hold down
a volume key.
2Wait for the tone and say a recorded
name, for example “John mobile”.
The name is played back to you and
the call is connected.
Voice commands are saved in the
phone memory only. They cannot
be used in another phone.
21Calling
The magic word
You can record and use a voice
command as a magic word to activate
voice dialling without pressing any keys.
Your handsfree must be connected to
your phone when using the magic word.
To activate and record the magic word
1From standby select Menu > Settings
> the General tab > Voice control
> Magic word > Activate.
2Follow the instructions that appear and
select Continue. Wait for the tone and
say the magic word.
3Select Yes to accept or No for a new
recording.
4Follow the instructions that appear and
select Continue.
5Select where your magic word is to be
activated.
To make a call using the magic word
1In standby make sure is visible.
2Say the magic word.
3Wait for the tone and say a voice
command.
Voice answering
When you use a handsfree, you can
answer or reject incoming calls with
your voice.
To activate voice answering and
record voice answer commands
1From standby select Menu > Settings
> the General tab > Voice control
> Voice answer > Activate.
2Follow the instructions that appear and
select Continue. Wait for the tone and
say “Answer”, or another word.
3Select Yes to accept or No for a new
recording.
4Follow the instructions that appear and
select Continue. Wait for the tone and
say “Busy”, or another word.
5Select Yes to accept or No for a new
recording.
6Follow the instructions that appear and
select Continue.
7Select where your voice answering
is to be activated.
To answer a call using voice
commands
•Say “Answer”.
To reject a call using voice
commands
•Say “Busy”.
You should choose a long, unusual word
or phrase that can easily be distinguished
from ordinary background speech.
Bluetooth handsfree does not support
this feature.
22 Messaging
Messaging
Receiving and saving messages
You are notified when you receive
a message. Messages are automatically
saved in the phone memory. When the
phone memory is full, you can delete
messages or save them on a memory
card or on the SIM card.
To save a message on a memory card
•From standby select Menu
> Messaging > Settings > General
> Save to > Memory card.
To save a message on the SIM card
1From standby select Menu > Messaging
and select a folder.
2Scroll to a message and select Options
> Save message.
Text messages
Text messages can contain simple
pictures, sound effects, animations,
and melodies.
Before you use messaging
You must have a service centre number.
The number is supplied by your service
provider and is usually saved on the
SIM card. If the number to your service
centre is not saved on your SIM card,
you must enter the number yourself.
To enter a service centre number
1From standby select Menu > Messaging
> Settings > Text message and scroll
to Service centre. The number is shown
if it is saved on the SIM card.
2If there is no number shown, select
Edit.
3Scroll to New ServiceCentre and select
Add.
4Enter the number, including the
international “+” sign and country
code.
5Select Save.
To write and send a text message
1From standby select Menu > Messaging
> Write new > Text message.
2Write the message and select Continue
> Contacts look-up.
3Select a recipient and select Send.
To add an item to a text message
1When you write the message, select
Options > Add item.
2Select an option and then an item.
To call a number in a text message
•When you view the message, scroll
to the phone number and press .
If you send a text message to a group,
you will be charged for each member.
See Groups on page 19.
23Messaging
Picture messages
Picture messages can contain text,
pictures, slides, sound recordings,
video clips, signatures and attachments.
You can send picture messages to
a mobile phone or an email address.
Before you use picture messaging
You must set an Internet profile and
the address of your message server.
If no Internet profile or message server
exists, you can receive all the settings
automatically from your network
operator or at
www.sonyericsson.com/support.
To select an MMS profile
1From standby select Menu > Messaging
> Settings > Picture message > MMS
profile.
2Select a profile.
To set the message server address
1From standby select Menu > Messaging
> Settings > Picture message.
2Scroll to MMS profile and select Edit.
3Select Options > Edit.
4Scroll to Message server and select
Edit.
5Enter the address and select OK > Save.
To create and send a picture message
1From standby select Menu > Messaging
> Write new > Picture msg.
2Enter text. To add items to the message,
press , scroll and select an item.
3Select Continue > Contacts look-up.
4Select a recipient and select Send.
Receiving picture messages
You can select how to download your
picture messages. Standard options
when you download picture messages
are:
•Always – automatic download.
•Ask in roaming – ask to download
when not in home network.
•Not in roaming – do not download
when not in home network.
•Always ask – ask to download.
•Off – new messages appear in the
Inbox.
To set automatic download
1From standby select Menu > Messaging
> Settings > Picture message > Auto
download.
2Select an option.
To save an item in a picture message
•When you view a picture message
select Options > Save items and select
an item.
24 Messaging
Email
You can use standard email functions
and your computer email address
in your phone.
Before you use email
You can use the setup wizard to check
if settings are available for your email
account or you can enter them
manually. You can also receive settings
at www.sonyericsson.com/support.
To create an email account
1From standby select Menu > Messaging
> Email > Accounts.
2Scroll to New account and select Add.
To write and send an email message
1From standby select Menu > Messaging
> Email > Write new.
2Select Add > Enter email addr.. Enter
the email address and select OK.
3To enter more recipients, select Edit.
Scroll to an option and select Add
> Enter email addr.. Enter the email
address and select OK. When you
are ready, select Done.
4Scroll to Subject:. Select Edit and enter
a subject.
5Scroll to Tex t: . Select Edit and enter
the text.
6Scroll to Attachments:. Select Add and
select a file to attach.
7Select Continue > Send.
To receive and read an email
message
1From standby select Menu > Messaging
> Email > Inbox > Options > Snd&rec.
2Scroll to the message and select View.
To save an email message
1From standby select Menu > Messaging
> Email > Inbox.
2Scroll to the message and select
Options > Save message.
To reply to an email message
1From standby select Menu > Messaging
> Email > Inbox.
2Scroll to the message and select
Options > Reply.
3Write the reply and select OK.
4Select Continue > Send.
If you enter settings manually, you can
contact your email provider for more
information. An email provider could
be the company that supplied your email
address.
25Messaging
To view an attachment in an email
message
•When you view the message, select
Options > Attachments > View.
To save an attachment in an email
message
•When you view the message, select
Options > Attachments > View > Save.
To delete an email (POP3)
1From standby select Menu > Messaging
> Email > Inbox.
2Scroll to the message and select
Options > Mark for deletion.
To delete an email (IMAP4)
1From standby select Menu > Messaging
> Email > Inbox.
2Scroll to the message and select
Options > Mark for deletion.
3Select Options > Clear inbox.
My friends
You can connect and log in to the My
friends server to communicate online
with chat messages.
Before you use My friends
If no settings exist in your phone,
you need to enter server settings.
Your service provider can provide
standard settings information such as:
•Username
•Password
•Server address
•Internet profile
To enter My friends server settings
1From standby select Menu > Messaging
> My friends > Config..
2Scroll to a setting and select Add.
To log in to the My friends server
•From standby select Menu > Messaging
> My friends > Log in.
To log out of the My friends server
•Select Options > Log out.
To add a chat contact
1From standby select Menu > Messaging
> My friends > the Contacts tab.
2Select Options > Add contact.
To send a chat message
1From standby select Menu > Messaging
> My friends > the Contacts tab.
2Scroll to a contact and select Chat.
3Write the message and select Send.
Marked emails will be deleted when you
next connect to your server.
Marked email messages will be deleted
in the phone and on the server.
26 Imaging
Imaging
Camera and video recorder
You can take pictures and record video
clips to view, save or send.
Viewfinder and camera keys
The screen is your viewfinder when you
use the camera.
Using the camera
To activate the camera
•From standby, press and hold down
.
To take a picture
1Activate the camera and press
or to scroll to .
2Press to take a picture.
3
saved on the memory card.
To record a video clip
1Activate the camera and press
or to scroll to .
2Press to start recording.
To stop recording
1Press .
2The video clip is automatically saved
on the memory card.
To use zoom
•Press the volume key up or down.
To adjust brightness
•Press or .
To view pictures and video clips
1Activate the camera and press
or to scroll to .
2To view your pictures and video
clips, press the centre navigation
key.
1Zoom in or out
2Take pictures/Record video
1
2
Do not record with a strong light source
in the background. Use a support or the
self-timer to avoid a blurred picture.
The picture is automatically
27Imaging
Camera icons and settings
Icons on the screen inform what the
current setting is. More camera settings
are available in Settings.
To change settings
•Activate the camera and select .
To view information about settings
•Scroll to a setting and select .
Transferring pictures
Transfer pictures to and from
your computer
You can use Bluetooth™ wireless
technology and the USB cable
to transfer pictures and video clips
between your computer and phone.
For more information, see Bluetooth™
wireless technology on page 33 and
Using the USB cable on page 34.
You can view, enhance and organize
your pictures and video clips on your
computer by installing the Adobe™
Photoshop™ Album Starter Edition
or the Sony Ericsson Media Manager.
These are included on the CD that
comes with your phone and are
available for download at
www.sonyericsson.com/support.
Picture blog
A picture blog is a personal Web
page. If your subscription supports
this service, you can send pictures
to a blog.
To send camera pictures to a blog
1From standby select Media and scroll
to Photo > Camera album.
2Scroll to a month and a picture. Select
View.
3Select Options > Send > To b lo g.
4Add title and text.
5Select OK > Publish.
To send a picture or video clip
1From standby select Media.
2Scroll to an item and select Options
> Send.
3Select a transfer method.
Web services may require a separate
license agreement between you and the
service provider. Additional regulations
and charges may apply. Contact your
service provider.
Make sure the receiving device supports
the transfer method you select.
28 Entertainment
Pictures
You can view, add, edit or delete
pictures in Media.
Using pictures
You can add a picture to a contact, use
it during phone startup, as a wallpaper
in standby or as a screen saver.
To use pictures
1From standby select Media and scroll
to Photo > Camera album.
2Scroll to a month and a picture. Select
View.
3Select Options > Use as.
4Select an option.
To view pictures in a slide show
1From standby select Media and scroll
to Photo > Camera album.
2Scroll to a month and a picture. Select
View.
3Select Options > Slide show.
4Select a mood.
Entertainment
Stereo portable handsfree
To use the handsfree
•Connect the portable handsfree. Music
stops when you receive a call and
resumes when the call has ended.
Music and video players
To play music
1From standby select Media and scroll
to Music.
2Scroll to a title and select Play.
To navigate your media see Navigation
on page 12.
29Entertainment
To play videos
1From standby select Media and scroll
to Video.
2Scroll to a title and select Play.
Music and video controls
To stop playing music
•Press the centre navigation key.
To resume playing music
•Press the centre navigation key.
To change the volume
•When you listen to music, press the
volume keys up or down.
To move between tracks
•When you listen to music, press
or .
To fast forward and rewind
•When you listen to music, press and
hold down or .
To return to the player menus
•Select Back.
To return to the players
•Select Options > Resume.
To exit the player menus
•Press and hold down .
To send music
1From standby select Media and scroll
to Music.
2Scroll to a title and select Options
> Send.
3Select a transfer method.
TrackID™
TrackID™ is a free music recognition
service. Search for song titles, artists
and album names.
To search for song information
•When you hear a song through
a loudspeaker, from standby select
Menu > Entertainment > TrackID™.
•When the radio is playing select
Options > TrackID™.
Radio
To listen to the radio
1Connect the handsfree to the phone.
2From standby select Menu > Radio.
To change the volume
•When the radio is playing, press the
volume keys up or down.
Make sure the receiving device supports
the transfer method you select.
Do not use your phone as a radio
in places where this is prohibited.
30 Entertainment
To automatically search for channels
•When the radio is playing, select
Search.
To manually search for channels
•When the radio is playing, press
or .
To switch between preset channels
•When the radio is playing, press
or .
Saving channels
You can save up to 20 preset channels.
To save channels
•When you have found a radio channel
select Options > Save.
To select saved channels
1From standby select Menu > Radio
> Options > Channels.
2Select a radio channel.
To save channels in positions 1 to 10
•When you have found a radio channel,
press and hold down – .
To select channels saved in positions
1 to 10
•When the radio is playing, press
– .
PlayNow™
You can listen to music before you
purchase and download it to your
phone.
Before you use PlayNow™
You must have the required settings in
your phone. See Settings on page 32.
To listen to PlayNow™ music
1From standby select Menu
> PlayNow™.
2Select music from a list.
Downloading from PlayNow™
The price appears when you select
to download and save a music file. Your
phone bill or prepay card is debited
when a purchase is accepted.
To download a music file
When you have listened to a music file
preview, you can agree to accept the
conditions.
1Select Yes to download.
2A text message is sent to confirm
payment and the file is made available
to download.
This service is not available in all countries.
In some countries you can purchase
music from some of the world’s top
musical artists.
31Entertainment
Ringtones and melodies
To set a ringtone
1From standby select Menu > Settings
> the Sounds & alerts tab > Ringtone.
2Find and select a ringtone.
To set the ringtone volume
1From standby select Menu > Settings
> the Sounds & alerts tab > Ring
volume.
2To change the volume, press or .
3Select Save.
To turn the ringtone off
•From standby press and hold down
.
To set the vibrating alert
1From standby select Menu > Settings
> the Sounds & alerts tab > Vibrating
alert.
2Select an option.
Sound recorder
You can record a voice memo or a call.
Recorded sounds can also be set as
ringtones.
To record a sound
•From standby select Menu
> Entertainment > Record sound.
To listen to a recording
1From standby select Menu > Organizer
> File manager.
2Scroll to Music and select Open.
3Scroll to a recording and select Play.
All signals except the alarm signal are
affected.
In some countries or states it is required
by law that you inform the other person
before recording the call.
32 Connectivity
Connectivity
Settings
Before you synchronize with an Internet
service, use the Internet, PlayNow™,
My friends, Java, picture messaging,
email and picture blog you need to have
settings in your phone.
If settings are not already entered, you
can download settings using the setup
wizard or by going to
www.sonyericsson.com/support.
To download settings using the setup
wizard
1From standby select Menu > Settings
> the General tab > Setup wizard >
Settings download.
2Follow the instructions that appear.
To send a link
1When you browse the Internet, select
Options > Tools > Send link.
2Select an option.
Using bookmarks
You can create and edit bookmarks
as quick links to your favourite Web
pages.
To create a bookmark
1When you browse the Internet, select
Options > Tools > Add bookmark.
2Enter a title and an address. Select
Save.
To select a bookmark
1From standby select Menu > Internet.
2Select Options > Go to > Bookmarks.
3Scroll to a bookmark and select Go to.
Web feeds
You can receive frequently updated
content, such as podcasts or news
headlines, as Web feeds. You can add
feeds for a page, if it has the icon.
To add new feeds for a Web page
•When you browse a page on the
Internet that has Web feeds, select
Options > Web feeds.
To create a new Web feed
1From standby select Menu > Messaging
> Web feeds > Options > New feed.
2Enter the address and select Go to.
Contact your network operator
or service provider for more information.
33Connectivity
Bluetooth™ wireless
technology
The Bluetooth function makes wireless
connection to other Bluetooth devices
possible. You can, for example:
•Connect to handsfree devices.
•Connect to several devices at the
same time.
•Connect to computers and access
the Internet.
•Exchange items and play multiplayer
games.
Before you use Bluetooth wireless
technology
You must turn on the Bluetooth function
to communicate with other devices.
You must also pair your phone with
other Bluetooth devices.
To turn the Bluetooth function on
•From standby select Menu > Settings
> the Connectivity tab > Bluetooth >
Turn on.
To pair the phone with a device
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth
> My devices.
2Scroll to New device and select Add
to search for available devices.
3Select a device.
4Enter a passcode, if required.
To allow connection to the phone
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth
> My devices.
2Select a device from the list.
3Select Options > Allow connection.
To pair the phone with a Bluetooth
handsfree for the first time
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth
> Handsfree.
2Select Yes.
3Enter a passcode, if required.
To pair the phone with more than
one Bluetooth handsfree
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth
> Handsfree > My handsfree > New
handsfree.
2Scroll to a device and select Add.
We recommend a range within 10 metres
(33 feet), with no solid objects in between,
for Bluetooth communication.
Make sure that the device you want to
pair your phone with has the Bluetooth
function activated and is made visible.
34 Connectivity
Visibility
If you want other Bluetooth devices
to be able to discover your phone,
you can choose to make your phone
visible.
To receive an item
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth
> Visibility > Show phone.
2When you receive an item, follow the
instructions that appear.
Using the USB cable
You can connect your phone to
a computer with the USB cable to
transfer files using Mass storage or
Media transfer. You can also
synchronize, transfer files and
use your phone as a modem using
Phone mode. For more information
go to the Getting started section at
www.sonyericsson.com/support.
Before you use the USB cable
You need one of these operating
systems to transfer files using a USB
cable:
•Windows® 2000
•Windows XP (Pro and Home)
•Windows Vista (32 bit and 64 bit
versions of: Ultimate, Enterprise,
Business, Home Premium, Home
Basic)
Media transfer and Mass storage
You can drag and drop files between
your phone or memory card and
a computer in Microsoft Windows
Explorer.
Only use a USB cable supported by your
phone. Do not remove the USB cable
from your phone or computer during file
transfer as this may corrupt the phone
memory or the memory card.
35Connectivity
To use media transfer and mass
storage mode
1Connect the USB cable to the phone
and the computer.
2Phone: Select Mass storage > Menu
> Settings > the Connectivity tab > USB
> USB mode > Mass storage. The phone
will shut down in this mode and restart
when disconnected from the USB cable.
3Phone: Select Media transfer and the
phone will remain activated during file
transfer.
4Computer: Wait until the phone
memory and memory card appear
as external disks in Windows Explorer.
5Drag and drop selected files between
the phone and the computer.
To disconnect the USB cable safely
1Right-click the removable disk icon
in Windows Explorer.
2Select Eject.
3Disconnect the USB cable when the
following message is shown in the
phone: Mass storage session ended. It
is now safe to remove the USB cable..
Phone mode
Before synchronizing or using your
phone as a modem you must install
the Sony Ericsson PC Suite software
on your computer.
To use phone mode
1Computer: Start PC Suite from Start/
Programs/Sony Ericsson/PC Suite.
2Connect the USB cable to the phone
and the computer.
3Phone: Select Phone mode > Menu
> Settings > the Connectivity tab > USB
> USB mode > Phone mode.
4Computer: When you are notified that
the Sony Ericsson PC Suite has found
your phone, you can start using the
phone mode applications.
Before transferring files you must install
the Sony Ericsson PC Suite software
on your computer.
For usage details, see the Sony Ericsson
PC Suite Help section once the software
has been installed on your computer.
36 Connectivity
Update service
You can update your phone with
the latest software. You do not lose
personal or phone information.
There are two ways to update your
phone:
•Over the air using your phone.
•Using the provided USB cable and
an Internet-connected computer.
Before you use the Update service
If settings are not in your phone see
Settings on page 32.
To view the current software in the
phone
1From standby select Menu > Settings
> the General tab > Update service.
2Select Software version.
To use Update service using the
phone
1From standby select Menu > Settings
> the General tab > Update service.
2Select Search for update and follow
the instructions that appear.
To use Update service using a USB
cable
1Go to www.sonyericsson.com/support
or click the Sony Ericsson Update
service in the PC Suite software
if installed on your computer.
2Select a region and country.
3Follow the instructions on the screen.
Update service requires data access
such as GPRS, 3G or HSDPA.
37Troubleshooting
Troubleshooting
Some problems will require you to call
your network operator.
For more support go to
www.sonyericsson.com/support.
Common questions
I have problems with memory capacity
or the phone is working slowly
Restart your phone every day to free
memory or do a Master reset.
Master reset
If you select Reset settings, the changes
that you have made to settings will be
deleted.
If you select Reset all, in addition to
your changes to settings, all contacts,
messages, personal data, and content
that you have downloaded, received
or edited will also be deleted.
To reset the phone
1From standby select Menu > Settings
> the General tab > Master reset.
2Select an option.
3Follow the instructions that appear.
I cannot charge the phone or battery
capacity is low
The charger is not properly connected
or the battery connection is poor.
Remove the battery and clean the
connectors.
The battery is worn out and needs to
be replaced. See Charging the battery
on page 7.
No battery icon appears when I start
charging the phone
It may take a few minutes before the
battery icon appears on the screen.
Some menu options appear in grey
A service is not activated. Contact your
network operator.
I cannot use SMS/text messages
on my phone
Settings are missing or incorrect.
Contact your network operator to find
out the correct SMS service centre
setting. See Text messages on page 22.
I cannot use picture messages on my
phone
Your subscription does not include
data capability. Settings are missing
or incorrect. Please contact your
network operator.
38 Troubleshooting
See Help in your phone on page 6 or
go to www.sonyericsson.com/support
to order settings and follow the
instructions on the screen. See Settings
on page 32.
How do I turn on and off T9 Text Input
when writing?
When you enter text, press and hold
down . You will see at the
top of the screen when T9 Text Input
is activated.
How do I change phone language?
1From standby select Menu > Settings
> the General tab > Language > Phone
language.
2Select an option.
I cannot use the Internet
Your subscription does not include
data capability. Internet settings are
missing or incorrect. Please contact
your network operator.
See Help in your phone on page 6 or
go to www.sonyericsson.com/support
to order Internet settings, and follow
the instructions on the screen. See
Settings on page 32.
The phone cannot be detected
by other devices using Bluetooth
wireless technology
You have not turned the Bluetooth
function on.
Make sure that the visibility is set
to Show phone.
I cannot synchronize or transfer data
between my phone and my computer,
when using the USB cable.
The cable or software that came with
your phone has not been properly
installed. Go to
www.sonyericsson.com/support to read
Getting started guides which contain
detailed installation instructions and
troubleshooting guides.
Error messages
Insert SIM
There is no SIM card in your phone
or you may have inserted it incorrectly.
See Charging the battery on page 7.
The SIM card connectors need
cleaning. If the card is damaged,
contact your network operator.
39Troubleshooting
Insert correct SIM card
Your phone is set to work only with
certain SIM cards. Check if you are
using the correct operator SIM card.
Wrong PIN/Wrong PIN2
You have entered your PIN or PIN2
incorrectly.
Enter the correct PIN or PIN2 and
select Yes. See To insert the SIM card
on page 5.
PIN blocked/PIN2 blocked
You have entered your PIN or PIN2
code incorrectly three times in a row.
Codes do not match
Codes that you have entered do not
match. When you want to change
a security code, for example your PIN,
you have to confirm the new code.
No netw. coverage
Your phone is in flight mode.
Your phone is not receiving any network
signal, or the received signal is too
weak. Contact your network operator
and make sure that the network has
coverage where you are.
The SIM card is not working properly.
Insert your SIM card in another phone.
If this works, it is probably your phone
that is causing the problem. Please
contact the nearest Sony Ericsson
service location.
Emerg. calls only
You are within range of a network,
but you are not allowed to use it.
However, in an emergency, some
network operators allow you to call the
international emergency number 112.
See Emergency calls on page 15.
PUK blocked. Contact operator.
You entered your personal unblocking
key code (PUK) incorrectly 10 times
in a row.
Charging, alien battery
The battery that you are using is not
a Sony Ericsson-approved battery.
See Battery on page 43.
40 Important information
Important information
Sony Ericsson Consumer Web site
On www.sonyericsson.com/support is a support
section where help and tips are only a few clicks
away. Here you will find the latest computer software
updates and tips on how to use your product more
efficiently.
Service and support
From now on you will have access to a portfolio
of exclusive service advantages such as:
•Global and local Web sites providing support.
•A global network of Call Centers.
•An extensive network of Sony Ericsson service
partners.
•A warranty period. Learn more about the warranty
conditions in this User guide.
On www.sonyericsson.com, under the support
section in the language of your choice, you will
find the latest support tools and information, such
as software updates, Knowledge base, phone setup
and additional help when you require it.
For operator-specific services and features, please
contact your network operator for more information.
You can also contact our Call Centers. See the phone
number for the nearest Call Center in the list below.
If your country/region is not represented in the list,
please contact your local dealer. The phone numbers
below were correct at the time of going to print.
On www.sonyericsson.com you can always find the
latest updates.
In the unlikely event that your product needs
service please contact the dealer from whom
it was purchased or one of our service partners.
Save your original proof of purchase, you will need
it if you need to claim warranty.
For a call to one of our Call Centers you will be
charged according to national rates, including local
taxes, unless the phone number is a toll-free number.
Country Phone number Email address
Argentina 800-333-7427 questions.AR@support.sonyericsson.com
Australia 1-300 650 050 questions.AU@support.sonyericsson.com
Austria 0810 200245 questions.AT@support.sonyericsson.com
Belgium 02-7451611 questions.BE@support.sonyericsson.com
Brazil 4001-0444 questions.BR@support.sonyericsson.com
Canada 1-866-766-9374 questions.CA@support.sonyericsson.com
Central Africa +27 112589023 questions.CF@support.sonyericsson.com
Chile 123-0020-0656 questions.CL@support.sonyericsson.com
China 4008100000 questions.CN@support.sonyericsson.com
Colombia 18009122135 questions.CO@support.sonyericsson.com
Croatia 062 000 000 questions.HR@support.sonyericsson.com
Czech Republic 844 550 055 questions.CZ@support.sonyericsson.com
Denmark 33 31 28 28 questions.DK@support.sonyericsson.com
Finland 09-299 2000 questions.FI@support.sonyericsson.com
France 0 825 383 383 questions.FR@support.sonyericsson.com
41Important information
Germany 0180 534 2020 questions.DE@support.sonyericsson.com
Greece 801-11-810-810 questions.GR@support.sonyericsson.com
210-89 91 919 (from mobile)
Hong Kong 8203 8863 questions.HK@support.sonyericsson.com
Hungary +36 1 880 4747 questions.HU@support.sonyericsson.com
India 39011111 questions.IN@support.sonyericsson.com
(Add STD code when dialling from a GSM connection)
Indonesia 021-2701388 questions.ID@support.sonyericsson.com
Ireland 1850 545 888 questions.IE@support.sonyericsson.com
Italy 06 48895206 questions.IT@support.sonyericsson.com
Lithuania 8 700 55030 questions.LT@support.sonyericsson.com
Malaysia 1-800-889900 questions.MY@support.sonyericsson.com
Mexico 01 800 000 4722 questions.MX@support.sonyericsson.com
Netherlands 0900 899 8318 questions.NL@support.sonyericsson.com
New Zealand 0800-100150 questions.NZ@support.sonyericsson.com
Norway 815 00 840 questions.NO@support.sonyericsson.com
Pakistan 111 22 55 73 questions.PK@support.sonyericsson.com
Outside Karachi: (92-21) 111 22 55 73
Philippines 02-6351860 questions.PH@support.sonyericsson.com
Poland 0 (prefix) 22 6916200 questions.PL@support.sonyericsson.com
Portugal 808 204 466 questions.PT@support.sonyericsson.com
Romania (+4021) 401 0401 questions.RO@support.sonyericsson.com
Russia 8(495) 787 0986 questions.RU@support.sonyericsson.com
Singapore 67440733 questions.SG@support.sonyericsson.com
Slovakia 02-5443 6443 questions.SK@support.sonyericsson.com
South Africa 0861 632222 questions.ZA@support.sonyericsson.com
Spain 902 180 576 questions.ES@support.sonyericsson.com
Sweden 013-24 45 00 questions.SE@support.sonyericsson.com
Switzerland 0848 824 040 questions.CH@support.sonyericsson.com
Taiwan 02-25625511 questions.TW@support.sonyericsson.com
Thailand 02-2483030 questions.TH@support.sonyericsson.com
Turkey 0212 47 37 777 questions.TR@support.sonyericsson.com
Ukraine (+380) 44 590 1515 questions.UA@support.sonyericsson.com
United Arab Emirates 43 919880 questions.AE@support.sonyericsson.com
United Kingdom 08705 23 7237 questions.GB@support.sonyericsson.com
United States 1-866-766-9374 questions.US@support.sonyericsson.com
Venezuela 0-800-100-2250 questions.VE@support.sonyericsson.com
42 Important information
Guidelines for Safe and
Efficient Use
Please read this information before
using your mobile phone.
These instructions are intended for
your safety. Please follow these
guidelines. If the product has been
subject to any of the conditions listed below or you
have any doubt as to its proper function make sure
you have the product checked by a certified service
partner before charging or using it. Failure to do
so might entail a risk of product malfunction or even
a potential hazard to your health.
Recommendations for safe use
of product (mobile phone, battery,
charger and other accessories)
•Always treat your product with care and keep it in
a clean and dust-free place.
•Warning! May explode if disposed of in fire.
•Do not expose your product to liquid or moisture
or humidity.
•Do not expose your product to
extreme high or low temperatures.
Do not expose the battery to
temperatures above +60°C (+140°F).
•Do not expose your product to open
flames or lit tobacco products.
•Do not drop, throw or try to bend your product.
•Do not paint your product.
•Do not attempt to disassemble
or modify your product. Only
Sony Ericsson authorised personnel
should perform service.
•Do not use your product near medical
equipment without requesting permission from your
treating physician or authorized medical staff.
•Do not use your product when in, or around aircraft,
or areas showing the sign “turn off two-way radio”.
•Do not use your product in an
area where a potentially explosive
atmosphere exists.
•Do not place your product or install
wireless equipment in the area above
an air bag in your car.
•Caution: Cracked or broken displays may create
sharp edges or splinters that could be harmful upon
contact.
CHILDREN
KEEP OUT OF CHILDRENS REACH.
DO NOT ALLOW CHILDREN TO PLAY
WITH YOUR MOBILE PHONE OR ITS
ACCESSORIES. THEY COULD HURT
THEMSELVES OR OTHERS, OR COULD
ACCIDENTALLY DAMAGE THE MOBILE PHONE
OR ACCESSORY. YOUR MOBILE PHONE OR ITS
ACCESSORY MAY CONTAIN SMALL PARTS THAT
COULD BECOME DETACHED AND CREATE
A CHOKING HAZARD.
Power supply (Charger)
Connect the AC power adapter only to designated
power sources as marked on the product. Make sure
the cord is positioned so that it will not be subjected
to damage or stress. To reduce risk of electric shock,
unplug the unit from any power source before
attempting to clean it. The AC power adapter must
not be used outdoors or in damp areas. Never alter
the cord or plug. If the plug does not fit into the
outlet, have a proper outlet installed by a qualified
electrician.
Use only Sony Ericsson branded original chargers
intended for use with your mobile phone. Other
chargers may not be designed to the same safety
and performance standards.
43Important information
Battery
We recommend that you fully charge the battery
before you use your mobile phone for the first time.
A new battery or one that has not been used for
a long time could have reduced capacity the first
few times it is used. The battery should only be
charged in temperatures between +5°C (+41°F)
and +45°C (+113°F).
Use only Sony Ericsson branded original batteries
intended for use with your mobile phone. Using
other batteries and chargers could be dangerous.
Talk and standby times depend on several different
conditions such as signal strength, operating
temperature, application usage patterns, features
selected and voice or data transmissions when the
mobile phone is being used.
Turn off your mobile phone before removing the
battery. Do not put the battery into your mouth.
Battery electrolytes may be toxic if swallowed.
Do not let the metal contacts on the battery touch
another metal object. Doing this could short-circuit
and damage the battery. Use the battery for the
intended purpose only.
Personal medical devices
Mobile phones may affect the operation
of pacemakers and other implanted equipment.
Please avoid placing the mobile phone over the
pacemaker, e.g. in your breast pocket. When using
the mobile phone, use it at the ear on the opposite
side of the body to the pacemaker. If a minimum
distance of 15 cm (6 inches) is kept between
the mobile phone and the pacemaker, the risk
of interference is limited. If you have any reason
to suspect that interference is taking place,
immediately turn off your mobile phone. Contact
your cardiologist for more information.
For other medical devices, please consult your
physician and the manufacturer of the device.
Driving
Please check if local laws and regulations restrict
the use of mobile phones while driving or require
drivers to use handsfree solutions. We recommend
that you use only Sony Ericsson handsfree solutions
intended for use with your product.
Please note that because of possible interference to
electronic equipment, some vehicle manufacturers
forbid the use of mobile phones in their vehicles
unless a handsfree kit with an external antenna has
been installed.
Always pay full attention to driving and pull off the
road and park before making or answering a call
if driving conditions so require.
Emergency calls
Mobile phones operate using radio signals, which
cannot guarantee connection in all conditions. You
should therefore never rely solely upon any mobile
phone for essential communications (e.g. medical
emergencies).
Emergency calls may not be possible in all areas,
on all cellular networks, or when certain network
services and/or mobile phone features are in use.
Check with your local service provider.
Antenna
This phone contains a built-in antenna. Use of
antenna devices not marketed by Sony Ericsson
specifically for this model could damage your
mobile phone, reduce performance, and produce
SAR levels above the established limits (see below).
Efficient use
Hold your mobile phone as you would any other
phone. Do not cover the top of the phone when
it is in use, as this affects call quality and may cause
the phone to operate at a higher power level than
needed, thus shortening talk and standby times.
44 Important information
Radio frequency (RF) exposure and
Specific Absorption Rate (SAR)
Your mobile phone is a low-power radio transmitter
and receiver. When it is turned on, it emits low levels
of radio frequency energy (also known as radio waves
or radio frequency fields).
Governments around the world have adopted
comprehensive international safety guidelines,
developed by scientific organizations, e.g.
ICNIRP (International Commission on Non-Ionizing
Radiation Protection) and IEEE (The Institute
of Electrical and Electronics Engineers Inc.),
through periodic and thorough evaluation
of scientific studies. These guidelines establish
permitted levels of radio wave exposure for the
general population. The levels include a safety
margin designed to assure the safety of all persons,
regardless of age and health, and to account for
any variations in measurements.
Specific Absorption Rate (SAR) is the unit
of measurement for the amount of radio frequency
energy absorbed by the body when using a mobile
phone. The SAR value is determined at the highest
certified power level in laboratory conditions,
but the actual SAR level of the mobile phone while
it is operating can be well below this value. This
is because the mobile phone is designed to use the
minimum power required to reach the network.
Variations in SAR below the radio frequency exposure
guidelines do not mean that there are variations
in safety. While there may be differences in SAR
levels among mobile phones, all Sony Ericsson
mobile phone models are designed to meet radio
frequency exposure guidelines.
For phones sold in the US, before a phone model
is available for sale to the public, it must be tested
and certified by the Federal Communications
Commission (FCC) that it does not exceed the
limit established by the government-adopted
requirement for safe exposure. The tests are
performed in positions and locations (that is,
at the ear and worn on the body) as required by the
FCC for each model. For body-worn operation, this
phone has been tested and meets FCC RF exposure
guidelines when the handset is positioned a minimum
of 15 mm from the body without any metal parts
in the vicinity of the phone or when used with
the original Sony Ericsson accessory intended
for this phone and worn on the body. Use of other
accessories may not ensure compliance with FCC
RF exposure guidelines.
A separate leaflet with SAR information about this
mobile phone model is included with the material
accompanying this mobile phone. This information
can also be found, together with more information
on radio frequency exposure and SAR, on:
www.sonyericsson.com/health.
Accessible Solutions/Special Needs
For phones sold in the US, you can use your TTY
terminal with your Sony Ericsson mobile phone
(with the necessary accessory). For information
on Accessible Solutions for individuals with special
needs call the Sony Ericsson Special Needs Center
on 877 878 1996 (TTY) or 877 207 2056 (voice),
or visit the Sony Ericsson Special Needs Center at
www.sonyericsson-snc.com.
45Important information
Disposal of old electrical
and electronic equipment
This symbol indicates that all electrical
and electronic equipment included shall
not be treated as household waste.
Instead it shall be left at the appropriate collection
point for recycling of electrical and electronic
equipment. By ensuring this product is disposed
of correctly, you will help prevent potential negative
consequences for the environment and human
health, which could otherwise be caused by
inappropriate waste handling of this product.
The recycling of materials will help to conserve
natural resources. For more detailed information
about recycling this product, please contact your
local city office, your household waste disposal
service or the shop where you purchased the
product.
Disposing of the battery
Please check local regulations for
disposal of batteries or call your
local Sony Ericsson Call Centre for
information.
The battery should never be placed in municipal
waste. Use a battery disposal facility if available.
Memory Card
Your product is equipped with a memory card
reader. Check memory card compatibility before
purchase or use.
Memory cards are generally formatted prior to
shipping. To reformat the memory card, use
a compatible device. Do not use the standard
operating system format when formatting the
memory card on a PC. For details, refer to the
operating instructions of the device or contact
customer support.
WARNING:
If your device requires an adapter for insertion into
the handset or another device, do not insert the
card directly without the required adapter.
Precautions on Memory Card Use
•Do not expose the memory card to moisture.
•Do not touch terminal connections with your hand
or any metal object.
•Do not strike, bend, or drop the memory card.
•Do not attempt to disassemble or modify the
memory card.
•Do not use or store the memory card in humid
or corrosive locations or in excessive heat such
as a closed car in summer, in direct sunlight or near
a heater, etc.
•Do not press or bend the end of the memory card
adapter with excessive force.
•Do not let dirt, dust, or foreign objects get into the
insert port of any memory card adapter.
•Check you have inserted the memory card correctly.
•Insert the memory card as far as it will go into any
memory card adapter needed. The memory card
may not operate properly unless fully inserted.
•We recommend that you make a backup copy
of important data. We are not responsible for any
loss or damage to content you store on the memory
card.
•Recorded data may be damaged or lost when you
remove the memory card or memory card adapter,
turn off the power while formatting, reading or
writing data, or use the memory card in locations
subject to static electricity or high electrical field
emissions.
46 Important information
Protection of personal information
To safeguard your privacy and prevent information
being accessible to a third party, you should erase
all personal data before selling or disposing of the
product. To delete personal data, perform a master
reset. DELETION OF MATERIAL FROM THE
PHONE MEMORY DOES NOT ENSURE THAT
SAID INFORMATION CANNOT BE RECOVERED
BY A SUBSEQUENT USER. SONY ERICSSON
DOES NOT WARRANT AGAINST A SUBSEQUENT
USER OF THE DEVICE ACCESSING YOUR
INFORMATION AND DOES NOT ASSUME ANY
RESPONSIBILITY FOR SUBSEQUENT
DISCLOSURE OF SAID INFORMATION EVEN IF
A MASTER RESET HAS BEEN PERFORMED. If you
are concerned about such potential disclosure retain
your device or secure its permanent destruction.
Accessories
Sony Ericsson recommends use of Sony Ericsson
original accessories for safe and efficient use
of its products. Use of third-party accessories
may decrease performance or pose a risk to your
health or safety.
LOUDNESS WARNING:
Please adjust the audio volume cautiously when
using third-party audio accessories to avoid volume
levels that may be harmful to your hearing.
Sony Ericsson does not test use of third-party audio
accessories with this mobile phone. Sony Ericsson
recommends using only Sony Ericsson original audio
accessories.
End User Licence Agreement
This wireless device, including without limitation
any media delivered with the device, (“Device”)
contains software owned by Sony Ericsson Mobile
Communications AB and its affiliated companies
(“Sony Ericsson”) and its third party suppliers and
licensors (“Software”).
As user of this Device, Sony Ericsson grants you
a non-exclusive, non-transferable, non-assignable
license to use the Software solely in conjunction
with the Device on which it is installed and/or
delivered with. Nothing herein shall be construed
as a sale of the Software to a user of this Device.
You shall not reproduce, modify, distribute, reverse
engineer, decompile, otherwise alter or use any
other means to discover the source code of the
Software or any component of the Software. For
avoidance of doubt, you are at all times entitled
to transfer all rights and obligations to the Software
to a third party, solely together with the Device with
which you received the Software, provided always
that such third party agrees in writing to be bound
by these rules.
You are granted this license for a term of the useful
life of this Device. You can terminate this license
by transferring all your rights to the Device on which
you have received the Software to a third party
in writing. If you fail to comply with any of the terms
and conditions set out in this license, it will terminate
with immediate effect.
Sony Ericsson and its third party suppliers and
licensors are the sole and exclusive owner of and
retain all rights, title and interest in and to the
Software. Sony Ericsson, and, to the extent that
the Software contains material or code of a third
party, such third party, shall be entitled third party
beneficiaries of these terms.
The validity, construction and performance of this
license shall be governed by the laws of Sweden.
The foregoing shall apply to the full extent permitted
by, when applicable, statutory consumer rights.
47Important information
Limited Warranty
Sony Ericsson Mobile Communications AB, SE-221
88 Lund, Sweden, (Sony Ericsson) or its local
affiliated company, provides this Limited Warranty
for your mobile phone and original accessory
delivered with your mobile phone (hereinafter
referred to as “Product”).
Should your Product need warranty service, please
return it to the dealer from whom it was purchased,
or contact your local Sony Ericsson Call Centre
(national rates may apply) or visit
www.sonyericsson.com to get further information.
Our warranty
Subject to the conditions of this Limited Warranty,
Sony Ericsson warrants this Product to be free from
defects in design, material and workmanship at the
time of its original purchase by a consumer. This
Limited Warranty will last for a period of one (1)
year as from the original date of purchase of the
Product.
What we will do
If, during the warranty period, this Product fails
to operate under normal use and service, due
to defects in design, materials or workmanship,
Sony Ericsson authorized distributors or service
partners, in the country* where you purchased the
Product, will, at their option, either repair or replace
the Product in accordance with the terms and
conditions stipulated herein.
Sony Ericsson and its service partners reserve the
right to charge a handling fee if a returned Product
is found not to be under warranty according to the
conditions below.
Please note that some of your personal settings,
downloads and other information may be lost when
your Sony Ericsson Product is repaired or replaced.
At present Sony Ericsson may be prevented
by applicable law, other regulation or technical
restrictions from making a backup copy of certain
downloads. Sony Ericsson does not take any
responsibility for any lost information of any kind
and will not reimburse you for any such loss.
You should always make backup copies of all the
information stored on your Sony Ericsson Product
such as downloads, calendar and contacts before
handing in your Sony Ericsson Product for repair
or replacement.
Conditions
1This Limited Warranty is valid only if the original
proof of purchase for this Product issued by
a Sony Ericsson authorized dealer specifying the
date of purchase and serial number**, is presented
with the Product to be repaired or replaced.
Sony Ericsson reserves the right to refuse warranty
service if this information has been removed
or changed after the original purchase of the
Product from the dealer.
2If Sony Ericsson repairs or replaces the Product,
the repair for the defect concerned, or the replaced
Product shall be warranted for the remaining time
of the original warranty period or for ninety (90)
days from the date of repair, whichever is longer.
Repair or replacement may involve the use
of functionally equivalent reconditioned units.
Replaced parts or components will become the
property of Sony Ericsson.
48 Important information
3This warranty does not cover any failure of the
Product due to normal tear and wear, or due
to misuse, including but not limited to use
in other than the normal and customary manner,
in accordance with the Sony Ericsson instructions
for use and maintenance of the Product. Nor does
this warranty cover any failure of the Product due
to accident, software or hardware modification
or adjustment, acts of God or damage resulting
from liquid.
A rechargeable battery can be charged and
discharged more than a hundred times. However,
it will eventually wear out – this is not a defect and
corresponds to normal wear and tear. When the
talk-time or standby time is noticeably shorter,
it is time to replace your battery. Sony Ericsson
recommends that you use only batteries and
chargers approved by Sony Ericsson.
Minor variations in display brightness and colour
may occur between the phones. There may be tiny
bright or dark dots on the display. These are called
defective pixels and occur when individual dots
have malfunctioned and can not be adjusted.
Two defective pixels are deemed acceptable.
Minor variations in camera image appearance may
occur between phones. This is nothing uncommon
and is not regarded as a defective camera module.
4Since the cellular system on which the Product
is to operate is provided by a carrier independent
from Sony Ericsson, Sony Ericsson will not be
responsible for the operation, availability, coverage,
services or range of that system.
5This warranty does not cover Product failures caused
by installations, modifications, or repair or opening
of the Product performed by a non-Sony Ericsson
authorised person.
6The warranty does not cover Product failures which
have been caused by use of accessories or other
peripheral devices which are not Sony Ericsson
branded original accessories intended for use with
the Product.
7Tampering with any of the seals on the Product will
void the warranty.
8THERE ARE NO EXPRESS WARRANTIES,
WHETHER WRITTEN OR ORAL, OTHER THAN
THIS PRINTED LIMITED WARRANTY.
ALL IMPLIED WARRANTIES, INCLUDING
WITHOUT LIMITATION THE IMPLIED
WARRANTIES OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE,
ARE LIMITED TO THE DURATION OF THIS
LIMITED WARRANTY. IN NO EVENT SHALL
SONY ERICSSON OR ITS LICENSORS BE LIABLE
FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES
OF ANY NATURE WHATSOEVER, INCLUDING BUT
NOT LIMITED TO LOST PROFITS OR COMMERCIAL
LOSS; TO THE FULL EXTENT THOSE DAMAGES
CAN BE DISCLAIMED BY LAW.
Some countries/states do not allow the exclusion
or limitation of incidental or consequential damages,
or limitation of the duration of implied warranties,
so the preceding limitations or exclusions may not
apply to you.
The warranty provided does not affect the
consumer's statutory rights under applicable
legislation in force, nor the consumer’s rights
against the dealer arising from their sales /
purchase contract.
49Important information
*Geographical scope of the warranty
If you have purchased your Product in a country
member of the European Economic Area (EEA)
or in Switzerland or the Republic of Turkey, and
such Product was intended for sale in the EEA
or in Switzerland or in Turkey, you can have
your Product serviced in any EEA country or in
Switzerland or in Turkey, under the warranty
conditions prevailing in the country in which
you require servicing, provided that an identical
Product is sold in such country by an authorised
Sony Ericsson distributor. To find out if your Product
is sold in the country you are in, please call the local
Sony Ericsson Call Centre. Please observe that
certain services may not be possible elsewhere than
in the country of original purchase, for example due
to the fact that your Product may have an interior
or exterior which is different from equivalent models
sold in other countries. Please note in addition
that it may sometimes not be possible to repair
SIM-locked Products.
** In some countries/regions additional information
(such as a valid warranty card) may be requested.
FCC Statement
This device complies with Part 15 of
the FCC rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful
interference, and
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
Declaration of Conformity
We, Sony Ericsson Mobile Communications AB of
Nya Vattentornet
SE-221 88 Lund, Sweden
declare under our sole responsibility that our
product
Sony Ericsson type AAD-3022101-BV
and in combination with our accessories,
to which this declaration relates is in conformity
with the appropriate standards 3GPP TS 51.010-1,
EN 301908-1, EN 301908-2, EN 301489-7,
EN 301489-24, EN 300328, EN 301489-17 and
EN 60950, following the provisions of, Radio
Equipment and Telecommunication Terminal
Equipment directive 99/5/EC with requirements
covering EMC directive 89/336/EEC, and Low
Voltage directive 73/23/EEC.
We fulfil the requirements of the R&TTE Directive
(99/5/EC).
Lund, May 2007
Shoji Nemoto,
Head of Product Business Group GSM/UMTS
50 Index
Index
A
answering service ................................ 20
assembly ................................................ 5
automatic redialling .............................. 14
B
battery
charging ......................................... 7
inserting ......................................... 5
use and care ................................ 43
Bluetooth™ wireless technology ......... 33
C
call list .................................................. 19
call numbers in message ..................... 22
caller-specific ringtones ....................... 17
calls
answering and rejecting ............... 15
emergency ................................... 15
international ................................. 14
making and receiving ................... 14
recording ...................................... 31
video ............................................ 16
camera
overview ....................................... 26
settings ........................................ 27
contacts
adding phone contacts .................16
default contacts ............................16
groups of .......................................19
D
declaration of conformity ......................49
E
email ......................................................24
entering text ..........................................13
F
file manager ..........................................12
G
groups ...................................................19
H
handsfree ........................................20, 28
Bluetooth technology ....................33
help .........................................................6
I
Internet
bookmarks ....................................32
settings .........................................32
51Index
K
keys ........................................................ 8
L
language ............................................... 13
limited warranty .................................... 47
M
M2™ ..................................................... 45
magic word .......................................... 21
master reset ......................................... 37
memory card ........................................ 45
memory status ..................................... 18
menu overview ..................................... 10
menus ................................................... 12
messages
email ............................................. 24
picture .......................................... 23
microphone .......................................... 15
MMS See picture messages
music player ......................................... 28
My friends ............................................ 25
N
navigating menus ................................. 12
P
picture messages ................................. 23
pictures ................................................ 28
PlayNow™ ............................................ 30
R
ringtones .............................................. 31
S
safety guidelines .................................. 42
sending
music ............................................ 29
pictures ........................................ 27
settings
Internet ......................................... 32
SIM card
copying to/from ...................... 17, 18
SMS ..................................................... 22
sound recorder ..................................... 31
speed dialling ....................................... 19
standby .................................................. 6
submenus ............................................. 12
T
T9™ Text Input .................................... 13
transfer method
Bluetooth technology ................... 33
USB .............................................. 34
transferring
camera pictures ........................... 27
files ............................................... 34
turning on/off
Bluetooth ...................................... 33
52 Index
U
update service ..................................... 36
V
video player .......................................... 29
video recorder ...................................... 26
voice answering ................................... 21
voice control ........................................ 20
voicemail .............................................. 20
volume
ear speaker .................................. 15
ringtone ........................................ 31
W
Web feeds ............................................ 32
Z
zoom .................................................... 26
