08 user guide part 2
14 Getting started
To go directly to a main menu
•From standby select Menu and press
– , , or .
To use navigation key shortcuts
•From standby press , , or
to go directly to a function.
To edit a navigation key shortcut
1From standby select Menu > Settings
> the General tab > Shortcuts.
2Scroll to an option and select Edit.
3Scroll to a menu option and select
Shortc.
Activity menu
The activity menu gives you quick
access to certain functions.
To open the activity menu
•Press .
Activity menu tabs
•New events – missed calls and new
messages.
•Running apps – applications that are
running in the background.
•My shortcuts – add your favourite
functions to access them quickly.
•Internet – quick access to the
Internet.
Memory card
Your phone supports Memory Stick
Micro™ (M2™) memory card adding
more storage space to your phone. It
can also be used as a portable memory
card with other compatible devices.
You can use the file manager to move
files between the memory card and the
phone memory. See To move a file in
the file manager on page 60.
To insert a memory card
•Open the cover and insert the memory
card with the gold-coloured contacts
facing up.
The Main menu layout must be set to
Grid. See To change the main menu
layout on page 64.
You may have to purchase a memory card
separately.
15Getting started
To remove a memory card
•Open the cover and press the edge
of the memory card to release and
remove it.
To view memory card options
1From standby select Menu > Organizer
> File manager > the On memory card
tab.
2Select Options.
Phone language
You can select a language to use
in your phone.
To change the phone language
1From standby select Menu > Settings
> the General tab > Language > Phone
language.
2Select an option.
Entering text
You can use multitap text input or T9™
Text Input to enter text. The T9 Text
Input method uses a built-in dictionary.
To change text input method
•When you enter text, press and hold
down .
To shift between capitals and lower-
case letters
•When you enter text, press .
To enter numbers
•When you enter text, press and hold
down – .
To enter full stops and commas
•When you enter text, press .
To enter a symbol
1When you enter text, select Options
> Add symbol.
2Scroll to a symbol and select Insert.
To enter text using T9™ Text Input
1From standby select, for example,
Menu > Messaging > Write new > Text
message.
2If is not displayed, press and hold
down to change to T9 Text Input.
16 Imaging
3Press each key only once, even if the
letter you want is not the first letter on
the key. For example, to write the word
“Jane”, press , , , .
Write the whole word before looking
at the suggestions.
4Use or to view suggestions.
5Press to accept a suggestion.
To enter text using multitap
1From standby select, for example,
Menu > Messaging > Write new > Text
message.
2If is displayed, press and hold down
to change to multitap text input.
3Press – repeatedly until the
desired letter appears.
4When a word is written, press
to add a space.
To add words to the built-in dictionary
1When you enter text using T9 Text
Input, select Options > Spell word.
2Write the word using multitap input
and select Insert.
Imaging
Camera and video recorder
You can take pictures and record video
clips to view, save or send. You find
your saved pictures and video clips
in Media > Photo > Cam. album and
File manager.
Viewfinder and camera keys
1 Zoom in or out
2 Take pictures/Record video
1
2
17Imaging
Using the camera
Your Cyber-shot™ phone has 3.2 MP
with auto-focus, face detection and
photo light. You can use photo light
when taking pictures and recording
videos.
To activate the camera
•From standby press .
To take a picture
1Activate the camera and press or
to scroll to .
2Press halfway down to use auto
focus or face detection.
3When the dot and focus frame are
green, press fully down to take
a picture. The picture is automatically
saved on the memory card, if a memory
card is inserted. If not, the picture
is saved in the phone memory.
Face detection
You can use face detection to bring an
off-centre face into focus. The camera
automatically detects up to three faces,
indicated by white frames. A green
frame shows which face has been
selected when auto-focus is used.
As a rule, focus is set to the face closest
to the camera.
To set face detection
•From standby select Menu >
Cyber-shot™ > > Focus > Face
detection.
To record a video clip
1Activate the camera and press or
to scroll to .
2Press fully down to start recording.
To stop recording
1Press .
2The video clip is automatically saved
on the memory card, if a memory card
is inserted. If not, the video clip is saved
in the phone memory.
Do not record with a strong light source
in the background. Use a support or the
self-timer to avoid a blurred picture.
18 Imaging
To use zoom
•Press the volume keys up or down.
To adjust brightness
•Press or .
Getting more from the camera
You can improve an under-exposed
picture with Photo fix.
To improve a picture with Photo fix
1Activate the camera and press or
to scroll to .
2Make sure Review is set to On. Select
> Settings > Review > On.
3Take a picture.
4During review, select Options
> Photo fix.
To view pictures and video clips
1Activate the camera and press or
to scroll to .
2Scroll to the item.
3To view a video clip, press the centre
navigation key.
Camera icons and settings
Icons on the screen show what the
current setting is. More camera settings
are available in Settings.
When taking a picture, zoom is available
in VGA mode only.
Icon Description
Shoot mode
Scenes – predefined
settings for common
picture situations,
including landscape,
portrait and sport
White balance – to adjust
colour tones to the lighting
conditions
Metering mode
Focus
Light
Picture size
Video length – for picture
messages, the length is
limited
Microphone
Night mode
Video: recording
19Imaging
To change settings
•Activate the camera and select .
To view information about settings
•Scroll to a setting and select .
Camera shortcuts
Transferring pictures
Transfer to and from your computer
You can use Bluetooth™ wireless
technology and the USB cable to
transfer pictures and video clips
between your computer and phone.
See Bluetooth wireless technology on
page 52 and Transferring content to
and from a computer on page 39
for more information.
You can view, enhance and organize
your pictures and video clips on your
computer by installing the Adobe™
Photoshop™ Album Starter Edition.
It is included on the CD that comes
with your phone and is available for
download at
www.sonyericsson.com/support.
Picture and video blog
A blog is a personal Web page. If your
subscription supports this service,
you can send pictures or video clips
to a blog.
Zoom
Auto focus
Focus frame
Camera: remaining
pictures
Key Shortcut
Camera: Shoot mode
Video: Video length
Camera: Scenes
Video: Night mode
Self-timer
Light
Camera key guide
Web services may require a separate
license agreement between you and the
service provider. Additional regulations
and charges may apply. Contact your
service provider.
20 Imaging
To send camera pictures to a blog
1From standby select Menu > Media
> Photo > Cam. album.
2Scroll to a month and a picture.
Select View.
3Select Options > Send > To blog.
4Enter a title and text and select OK.
5Select Publish.
To send video clips to a blog
1From standby select Menu > Media
> Video.
2Scroll to a video clip.
3Select Options > Send > To blog.
4Enter a title and text and select OK.
5Select Publish.
To go to a blog address from contacts
1From standby select Menu > Contacts.
2Scroll to a contact and select a Web
address.
3Select Go to.
Camera printing
You can print camera pictures
using the USB cable connected
to a compatible printer.
To print camera pictures using the
USB cable
1From standby select Menu > Media
> Photo > Cam. album.
2Scroll to a month and a picture.
3Select Options > Print.
4Select an option.
5Connect the USB cable to the phone.
6Connect the USB cable to the printer.
7Wait for feedback in the phone and
select OK.
8Enter printer settings, if required, and
select Print.
Pictures
You can view and tag your pictures
in Media.
To view pictures in a slide show
1From standby select Menu > Media
> Photo > Cam. album.
2Scroll to a month and a picture.
Select View.
3Select Options > Slide show.
4Select a mood.
You can also print using a Bluetooth
compatible printer.
You should disconnect and re-connect
the USB cable if there is a printer error.
21Imaging
Viewing pictures on a map
Location data is included when you
take pictures with the camera. This
allows you to view the approximate
location of where a picture was taken.
To view pictures on a map
1From standby select Menu > Media
> Photo > Cam. album.
2Scroll to a month and a picture.
Select View.
3Select Options > View on map.
To turn off location data for pictures
•From standby select Menu >
Cyber-shot™ > > Add position
> Off.
Photo tags
You can tag pictures to categorize
them. They are saved in Photo tags.
To tag pictures
1From standby select Menu > Media
> Photo > Cam. album.
2Scroll to a month and a picture.
Select View.
3Press and scroll to a tag.
4Press the centre navigation key.
5For each picture you want to tag, use
or to scroll to the picture and
press the centre navigation key.
To create a new photo tag
1From standby select Menu > Media
> Photo > Cam. album.
2Scroll to a month and a picture.
Select View.
3Press and select Options > New tag.
4Enter a name and select OK.
5Select an icon.
6Press the centre navigation key to tag
the picture.
Using pictures
You can add a picture to a contact, use
it during phone startup, as a wallpaper
in standby or as a screen saver.
To use pictures
1From standby select Menu > Media
> Photo > Cam. album.
2Scroll to a month and a picture.
Select View.
3Select Options > Use as.
4Select an option.
PhotoDJ™ and VideoDJ™
You can edit pictures and video clips.
To edit and save a picture
1From standby select Menu > Media
> Photo > Cam. album.
2Scroll to a month and a picture.
Select View.
22 Calling
3Select Options > Edit in PhotoDJ™.
4Edit the picture.
5Select Options > Save picture.
To edit and save a video clip
1From standby select Menu > Organizer
> File manager > Videos.
2Scroll to a video clip and select
Options > Edit in VideoDJ™.
3Edit the video clip.
4Select Options > Save.
To trim a video clip
1From standby select Menu > Organizer
> File manager > Videos.
2Scroll to a video clip and select Options
> Edit in VideoDJ™ > Edit > Trim.
3Select Set to set the starting point and
select Start.
4Select Set to set the ending point and
select End.
5Select Trim > Options > Save.
Calling
Making and receiving calls
You need to turn on your phone and
be within range of a network.
To make a call
1From standby enter a phone number
(with international country code and
area code, if applicable).
2Press .
See Video call on page 24.
To end a call
•Press .
To make international calls
1From standby press and hold down
until a “+” sign appears.
2Enter the country code, area code
(without the first zero) and phone
number.
3Press .
You can call numbers from your contacts
and call list. See Contacts on page 24,
and Call list on page 27. You can also
use your voice to make calls. See Voice
control on page 28.
23Calling
To re-dial a number
•When Retry? appears select Yes.
To answer a call
•Press .
To reject a call
•Press .
To change the ear speaker volume
during a call
•Press the volume key up or down.
To mute the microphone during a call
1Press and hold down .
2Press and hold down again
to resume.
To turn the loudspeaker on during
a call
•Select SpkrOn.
To view missed calls from standby
•Press to open the call list.
Networks
Your phone switches automatically
between GSM and 3G (UMTS)
networks depending on availability.
Some network operators allow you
to switch networks manually.
To switch networks manually
1From standby select Menu > Settings
> the Connectivity tab > Mobile
networks > GSM/3G networks.
2Select an option.
Emergency calls
Your phone supports international
emergency numbers, for example, 112
and 911. These numbers can normally
be used to make emergency calls in
any country, with or without the SIM
card inserted, if a 3G (UMTS) or GSM
network is within range.
To make an emergency call
•From standby enter 112 (the
international emergency number)
and press .
Do not hold your phone to your ear when
waiting. When the call connects, your
phone gives a loud signal.
Do not hold your phone to your ear when
using the loudspeaker. This could damage
your hearing.
In some countries, other emergency
numbers may also be promoted. Your
network operator may therefore have
saved additional local emergency
numbers on the SIM card.
24 Calling
To view your local emergency
numbers
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Special numbers
> Emergency nos.
Video call
See a person on the screen during
calls. Both parties need a subscription
that supports the 3G (UMTS) service,
and you need to be within range of
a 3G (UMTS) network. 3G (UMTS)
service is available when appears.
To make a video call
1From standby enter a phone number
(with international country code and
area code if applicable).
2Select Options > Make video call.
To use the zoom with an outgoing
video call
•Press or .
To view video call options
•During the call, select Options.
Contacts
You can save names, phone numbers
and personal information in Contacts.
Information can be saved in the phone
memory or on the SIM card.
Default contacts
You can choose which contact
information is shown as default. If
Phone contacts is selected as default,
your contacts show all the information
saved in Contacts. If you select SIM
contacts as default, your contacts show
names and numbers saved on the SIM
card.
To select default contacts
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Advanced > Default contacts.
3Select an option.
Phone contacts
Phone contacts can contain names,
phone numbers and personal
information. They are saved in the
phone memory.
To add a phone contact
1From standby select Menu > Contacts.
2Scroll to New contact and select Add.
3Enter the name and select OK.
4Scroll to New number: and select Add.
5Enter the number and select OK.
6Select a number option.
7Scroll between tabs and select the
fields to add information.
8Select Save.
25Calling
Calling contacts
To call a phone contact
1From standby select Menu > Contacts.
2Scroll to a contact and press .
To go directly to the contacts list
•From standby press and hold down
– .
To call with Smart search
1From standby press –
to enter a contact name or a phone
number. All entries which match the
sequence of digits or letters are shown
in a list.
2Scroll to a contact or a phone number
and press .
To turn Smart search on or off
1From standby select Menu > Settings
> the Calls tab > Smart search.
2Select an option.
Editing contacts
To add information to a phone contact
1From standby select Menu > Contacts.
2Scroll to a contact and select Options
> Edit contact.
3Scroll between the tabs and select Add
or Edit.
4Select an option and an item to add
or edit.
5Select Save.
To copy names and numbers to phone
contacts
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Advanced > Copy from SIM.
3Select an option.
To copy names and numbers to the
SIM card
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Advanced > Copy to SIM.
3Select an option.
To automatically save names and
phone numbers on the SIM card
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Advanced > Auto save on
SIM.
3Select an option.
If your subscription supports Calling Line
Identification (CLI) service, you can
assign personal ringtones and pictures
to contacts.
When you copy all contacts from your
phone to the SIM card, all existing SIM
card information is replaced.
26 Calling
To save contacts on a memory card
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Advanced > Back up to
m. card.
SIM contacts
SIM contacts can contain names and
numbers only. They are saved on the
SIM card.
To add a SIM contact
1From standby select Menu > Contacts.
2Scroll to New contact and select Add.
3Enter the name and select OK.
4Enter the number and select OK.
5Select a number option and add more
information, if available.
6Select Save.
To call a SIM contact
1From standby select Menu > Contacts.
2Scroll to a contact and press .
Deleting contacts
To delete all contacts
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Advanced > Delete all
contacts.
3Select an option.
Memory status
The number of contacts you can save
in your phone or on the SIM card
depends on available memory.
To view memory status
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Advanced > Memory status.
Synchronizing contacts
The Sony Ericsson PC Suite is designed
to work with the following programs:
•Windows Contact (Vista Contacts
Manager)
•Windows Calendar (Vista Calendar)
•Microsoft® Outlook® 2007
•Microsoft Outlook 2003
•Microsoft Outlook 2002
•Microsoft Outlook 2000
•Lotus Notes™ 7
•Lotus Notes 6.5
•Lotus Notes 6
•Lotus Notes 5
•Windows Address Book (Outlook
Express)
•Sony Ericsson PC Suite proprietary
contact & calendar manager
For more information see
Synchronizing on page 55.
27Calling
Groups
You can create a group of phone
numbers and email addresses from
Phone contacts to send messages to.
See Messaging on page 32. You can
also use groups (with phone numbers)
when you create accepted callers
lists. See Accept calls on page 31.
To create a group of numbers and
email addresses
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Groups.
3Scroll to New group and select Add.
4Enter a name for the group and select
Continue.
5Scroll to New and select Add.
6For each contact phone number
or email address you want to mark,
scroll to it and select Mark.
7Select Continue > Done.
Call list
You can view information about recent
calls.
To call a number from the call list
1From standby press and scroll to
a tab.
2Scroll to a name or a number and
press .
To add a call list number to contacts
1From standby press and scroll to
a tab.
2Scroll to the number and select Save.
3Select New contact to create a new
contact or select an existing contact
to add the number to.
Speed dial
Speed dialling lets you select nine
contacts that you can dial quickly.
The contacts can be saved in
positions 1-9.
To add contacts to speed dial
numbers
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Speed dial.
3Scroll to a position number and select
Add.
4Select a contact.
To speed dial
•From standby enter the position number
and press .
Voicemail
If your subscription includes an
answering service, callers can leave
a voicemail message when you cannot
answer a call.
28 Calling
To enter your voicemail number
1From standby select Menu > Messaging
> Settings > Voicemail number.
2Enter the number and select OK.
To call your voicemail service
•From standby press and hold down
.
Voice control
By creating voice commands you can:
•Voice dial – call someone by saying
their name.
•Answer and reject calls when you
use a handsfree.
To record a voice command using
voice dialling
1From standby select Menu > Settings
> the General tab > Voice control
> Voice dialling > Activate.
2Select Yes > New voice command and
select a contact. If the contact has more
than one number, select the number to
add the voice command to.
3Record a voice command such as
“John mobile”.
4Follow the instructions that appear.
Wait for the tone and say the command
to record. The voice command is played
back to you.
5If the recording sounds OK, select Yes.
If not, select No and repeat steps
3 and 4.
Voice dialling
You can hear your recorded contact
name when you receive a call from that
contact.
To voice dial
1From standby press and hold down
a volume key.
2Wait for the tone and say a recorded
name, for example “John mobile”.
The name is played back to you and
the call is connected.
Voice answering
When you use a handsfree, you can
answer or reject incoming calls with
your voice.
Voice commands are saved in the phone
memory only. They cannot be used in
another phone.
29Calling
To activate voice answering and
record voice answer commands
1From standby select Menu > Settings
> the General tab > Voice control
> Voice answer > Activate.
2Follow the instructions that appear and
select Cont. Wait for the tone and say
“Answer”, or another word.
3Select Yes to accept or No for a new
recording.
4Follow the instructions that appear and
select Cont. Wait for the tone and say
“Busy”, or another word.
5Select Yes to accept or No for a new
recording.
6Follow the instructions that appear and
select Cont.
7Select where your voice answering
is to be activated.
To answer a call using voice
commands
•Say “Answer”.
To reject a call using voice commands
•Say “Busy”.
Diverting calls
You can divert calls, for example,
to an answering service.
To divert calls
1From standby select Menu > Settings
> the Calls tab > Divert calls.
2Select a call type and a divert option.
3Select Activate.
4Enter the number to divert calls to and
select OK.
More than one call
You can handle more than one call at
a time. For example, you can put an
ongoing call on hold, while you make
or answer a second call. You can also
switch between the two calls. You
cannot answer a third call without
ending one of the first two calls.
Call waiting
When call waiting is used, you hear
continuous beep if you receive
a second call.
When Restrict calls is used, some
divert call options are not available.
See Restricted dialling on page 31.
30 Calling
To activate call waiting
•From standby select Menu > Settings
> the Calls tab > Manage calls > Call
waiting > Activate.
To make a second call
1During the call, select Options > Hold
call. This puts the ongoing call on hold.
2Select Options > Add call.
3Enter the number to call and press .
To answer a second call
•During the call, press . This puts the
ongoing call on hold.
To reject a second call
•During the call, press and continue
with the ongoing call.
To end an ongoing call and answer
a second call
•During the call, select Replace active
call.
Handling two voice calls
You can have calls ongoing and on hold
at the same time.
To switch between two calls
•During the call, press .
To join two calls
•During the call, select Options > Join
calls.
To connect two calls
•During the call, select Options >
Transfer call. You are disconnected
from both calls.
To end an ongoing call and return
to the call on hold
•First press and then .
Conference calls
With a conference call, you can have a
joint conversation with up to five people.
To add a new participant
1During the call, select Options > Hold
call. This puts the joined calls on hold.
2Select Options > Add call.
3Enter the number to call and press .
4Select Options > Join calls to add the
new participant.
5Repeat this task to add more
participants.
To release a participant
1Select Options > Release party.
2Select the participant to release.
To have a private conversation
1During the call, select Options > Talk to
and select the participant to talk to.
2To resume the conference call, select
Options > Join calls.
31Calling
My numbers
You can view, add and edit your own
phone numbers.
To check your phone numbers
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Special numbers > My
numbers.
3Select an option.
Accept calls
You can choose to receive calls from
certain phone numbers only.
To add numbers to the accepted
callers list
1From standby select Menu > Settings
> the Calls tab > Manage calls > Accept
calls > Only from list.
2Scroll to New and select Add.
3Select a contact or Groups.
To accept all calls
•From standby select Menu > Settings
> the Calls tab > Manage calls > Accept
calls > All callers.
Restricted dialling
You can restrict outgoing and incoming
calls. A password from your service
provider is required.
Restrict calls options
Standard options are:
•All outgoing – all outgoing calls
•Outgoing intl – all outgoing
international calls
•Outgoing intl roam. – all outgoing
international calls except to your
home country
•All incoming – all incoming calls
•Inc. when roaming – all incoming
calls when you are abroad
To restrict calls
1From standby select Menu > Settings
> the Calls tab > Manage calls
> Restrict calls.
2Select an option.
3Select Activate.
4Enter your password and select OK.
See Groups on page 27.
If you divert incoming calls, you cannot
use some restrict calls options.
32 Messaging
Call time and cost
During a call, the duration of the call
is shown. You can check the duration
of your last call, outgoing calls and the
total time of your calls.
To check the call time
•From standby select Menu > Settings
> the Calls tab > Time & cost > Call
timers.
Showing or hiding your phone
number
You can decide to show or hide your
phone number when you make a call.
To hide your phone number
1From standby select Menu > Settings
> the Calls tab > Show/hide my no.
2Select Hide number.
Messaging
Receiving and saving messages
You are notified when you receive a
message. Messages are automatically
saved in the phone memory. When the
phone memory is full, you can delete
messages or save them on a memory
card or on the SIM card.
To save a message on a memory card
•From standby select Menu > Messaging
> Settings > General > Save to
> Memory card.
To save a message on the SIM card
1From standby select Menu > Messaging
and select a folder.
2Scroll to a message and select Options
> Save message.
To view a message from the inbox
1From standby select Menu > Messaging
> Inbox.
2Scroll to the message and select View.
33Messaging
Text messages
Text messages can contain simple
pictures, sound effects, animations,
and melodies.
Before you use messaging
You must have a service centre number.
The number is supplied by your service
provider and is usually saved on the
SIM card. If the number to your service
centre is not saved on your SIM card,
you must enter the number yourself.
To enter a service centre number
1From standby select Menu > Messaging
> Settings > Text message and scroll to
Service centre. The number is shown if
it is saved on the SIM card.
2If there is no number shown,
select Edit.
3Scroll to New ServiceCentre and
select Add.
4Enter the number, including the
international “+” sign and country code.
5Select Save.
To write and send a text message
1From standby select Menu > Messaging
> Write new > Text message.
2Write the message and select Continue
> Contacts look-up.
3Select a recipient and select Send.
To copy and paste text in a text
message
1When you write the message, select
Options > Copy & paste.
2Select Copy all or Mark & copy. Scroll
to and mark text in the message.
3Select Options > Copy & paste > Paste.
To add an item to a text message
1When you write the message, select
Options > Add item.
2Select an option and then an item.
To call a number in a text message
•When you view the message, scroll
to the phone number and press .
To turn long messages on
1From standby select Menu > Messaging
> Settings > Text message.
2Select Max. msg length > Max.
available.
Picture messages
Picture messages can contain text,
pictures, slides, sound recordings, video
clips, signatures and attachments. You
can send picture messages to a mobile
phone or an email address.
If you send a text message to a group,
you will be charged for each member.
See Groups on page 27.
34 Messaging
Before you use picture messaging
You must set an MMS profile and the
address of your message server. If no
MMS profile or message server exists,
you can receive all the settings
automatically from your network
operator or at
www.sonyericsson.com/support.
To select an MMS profile
1From standby select Menu > Messaging
> Settings > Picture message > MMS
profile.
2Select a profile.
To set the message server address
1From standby select Menu > Messaging
> Settings > Picture message.
2Scroll to MMS profile and select Edit.
3Select Options > Edit.
4Scroll to Message server and select
Edit.
5Enter the address and select OK
> Save.
To create and send a picture message
1From standby select Menu > Messaging
> Write new > Picture msg.
2Enter text. To add items to the message,
press , scroll and select an item.
3Select Continue > Contacts look-up.
4Select a recipient and select Send.
Receiving picture messages
You can select how to download your
picture messages. Standard options
when you download picture messages
are:
•Always – automatic download.
•Ask in roaming – ask to download
when not in home network.
•Not in roaming – do not download
when not in home network.
•Always ask – ask to download.
•Off – new messages appear in the
Inbox.
To set automatic download
1From standby select Menu > Messaging
> Settings > Picture message > Auto
download.
2Select an option.
Message options
You can set standard options for all
messages or choose specific settings
each time you send a message.
To set text message options
1From standby select Menu > Messaging
> Settings > Text message.
2Scroll to an option and select Edit.
35Messaging
To set picture message options
1From standby select Menu > Messaging
> Settings > Picture message.
2Scroll to an option and select Edit.
To set message options for a specific
message
1When the message is ready and a
recipient is selected, select Options
> Advanced.
2Scroll to an option and select Edit.
Voice messages
You can send and receive a sound
recording as a voice message.
To record and send a voice message
1From standby select Menu > Messaging
> Write new > Voice message.
2Record the message and select Stop
> Send > Contacts look-up.
3Select a recipient and select Send.
Email
You can use standard email functions
and your computer email address
in your phone.
Before you use email
You can use the setup wizard to check
if settings are available for your email
account or you can enter them
manually. You can also receive settings
at www.sonyericsson.com/support.
To create an email account
1From standby select Menu > Messaging
> Email > Accounts.
2Scroll to New account and select Add.
To write and send an email message
1From standby select Menu > Messaging
> Email > Write new.
2Select Add > Enter email address.
Enter the email address and select OK.
3To add more recipients, scroll to To:
and select Edit.
4Scroll to an option and select Add
> Enter email address. Enter the email
address and select OK. When you are
ready, select Done.
5Select Edit and enter a subject.
Select OK.
6Select Edit and enter the text.
Select OK.
The sender and recipient must have
a subscription supporting picture
messaging.
If you enter settings manually, you can
contact your email provider for more
information.
36 Messaging
7Select Add and choose a file to attach
(if you want to include a file).
8Select Cont. > Send.
To receive and read an email message
1From standby select Menu > Messaging
> Email > Inbox > Options > Check new
email.
2Scroll to the message and select View.
To save an email message
1From standby select Menu > Messaging
> Email > Inbox.
2Scroll to the message and select View
> Options > Save message.
To reply to an email message
1From standby select Menu > Messaging
> Email > Inbox.
2Scroll to the message and select
Options > Reply.
3Write the reply and select OK.
4Select Cont. > Send.
To view an attachment in an email
message
•When you view the message, select
Options > Attachments > Use > View.
To save an attachment in an email
message
•When you view the message, select
Options > Attachments > Use > Save.
Synchronizing email
Email can be synchronized with a
Microsoft Exchange Server (Microsoft
Outlook). For more information see
Synchronizing on page 55.
Active email account
If you have several email accounts,
you can change which one is active.
To change the active email account
1From standby select Menu > Messaging
> Email > Accounts.
2Select an account.
Push email
You can receive notification in your
phone from your email server that
you have new email messages.
To turn on push email notification
•From standby select Menu > Messaging
> Email > Settings > Push email.
37Messaging
My friends
You can connect and log in to the My
friends server to communicate online
with chat messages.
Before you use My friends
If no settings exist in your phone, you
need to enter server settings. Your
service provider can provide standard
settings information such as:
•Username
•Password
•Server address
•Internet profile
To enter My friends server settings
1From standby select Menu > Messaging
> My friends > Configure.
2Scroll to a setting and select Add.
To log in to the My friends server
•From standby select Menu > Messaging
> My friends > Log in.
To log out of the My friends server
•Select Options > Log out.
To add a chat contact
1From standby select Menu > Messaging
> My friends > the Contacts tab.
2Select Options > Add contact.
To send a chat message
1From standby select Menu > Messaging
> My friends > the Contacts tab.
2Scroll to a contact and select Chat.
3Write the message and select Send.
Status
You can show your status, for example,
Happy or Busy, to your contacts only.
You can also show your status to all
users on the My friends server.
To show my status
1From standby select Menu > Messaging
> My friends > Options > Settings
> Show my status.
2Select an option.
To update your own status
1From standby select Menu > Messaging
> My friends > the My status tab.
2Edit the information.
3Select Options > Save.
38 Messaging
Chat group
A chat group can be started by your
service provider, by an individual My
friends user or by yourself. You can
save chat groups by saving a chat
invitation or by searching for a specific
chat group.
To create a chat group
1From standby select Menu > Messaging
> My friends > the Chat groups tab.
2Select Options > Add chat group
> New chat group.
3Select who to invite from your contacts
list and select Cont.
4Enter a short invitation text and select
Cont. > Send.
To add a chat group
1From standby select Menu > Messaging
> My friends > the Chat groups tab
> Options > Add chat group.
2Select an option.
To save a conversation
1From standby select Menu > Messaging
> My friends > the Conversations tab.
2Enter a conversation.
3Select Options > Advanced > Save
conversation.
Area and cell information
Area and cell information are text
messages about, for example,
local traffic reports that are sent to
subscribers within a certain network
area.
To turn area information on
1From standby select Menu > Messaging
> Settings > Area info.
2Scroll to Reception and select Edit
> On.
Conversation history is saved between
log out and when you log in again to
let you return to chat messages from
previous conversations.
39Media player and music
Media player and music
You can listen to music, audio books
and podcasts. Use Sony Ericsson
Media Manager to transfer content
to your phone.
Transferring content to and
from a computer
Required operating systems
You need one of these operating
systems to use the software included
on the CD:
•Microsoft Windows Vista™ 32 bit
and 64 bit versions of: Ultimate,
Enterprise, Business, Home
Premium, Home Basic
•Microsoft Windows XP (Pro or
Home), Service Pack 2 or higher
To install Media Manager
1Turn on your computer and insert the
CD. The CD starts automatically and
the installation window opens.
2Select a language and click OK.
3Click Install Sony Ericsson Media
Manager and follow the instructions.
To transfer content using Media
Manager
1Connect the phone to a computer with
a USB cable supported by your phone.
2Computer: Start/Programs/
Sony Ericsson/Media Manager.
3Phone: Select Media transfer.
4Computer: Wait until the phone
appears in Media Manager.
5Move files between your phone and
the computer in Media Manager.
Sony Ericsson Media Manager software
is included on the CD that comes with
your phone and available for download
at www.sonyericsson.com/support.
Do not remove the USB cable from your
phone or computer during transfer, as
this may corrupt the memory card or the
phone memory.
For details on transferring music, refer
to Media Manager Help. Click in the
top right corner of the Media Manager
window.
40 Media player and music
Stereo portable handsfree
To use the handsfree
•Connect the portable handsfree.
Music stops when you receive a call
and resumes when the call has ended.
Music player
To play music
1From standby select Menu > Media
> Music.
2Scroll to a title and select Play.
To stop playing music
•Press the centre navigation key.
To fast forward and rewind
•Press and hold down or .
To move between tracks
•Press or .
To change the volume
•Press the volume keys up or down.
Browsing files
Music is saved and categorized.
•Artists – list music by artist.
•Albums – list music by album.
•Tracks – list all music tracks.
•Playlists – create your own lists
of tracks.
•Audio books – list audio books you
have transferred from your computer.
•Podcasts – list all podcasts.
Playlists
You can create playlists to organize
music files. Files can be added to more
than one playlist.
Deleting a playlist, or a file from a
playlist, does not delete the file from
the memory, just that reference to
the file.
To create a playlist
1From standby select Menu > Media
and scroll to Music > Playlists.
2Scroll to New playlist and select Add.
3Enter a name and select OK.
4For each track you want to add, scroll
to the track and select Mark.
5Select Add to add the tracks to the
playlist.
41Media player and music
To add files to a playlist
1From standby select Menu > Media
and scroll to Music > Playlists.
2Select a playlist.
3Scroll to Add music and select Add.
4For each track you want to add, scroll
to the track and select Mark.
5Select Add to add the tracks to the
playlist.
To remove tracks from a playlist
1From standby select Menu > Media
and scroll to Music > Playlists.
2Select a playlist.
3Scroll to the track and press .
To view information about a track
•Scroll to a track and select Options
> Information.
Audio books
You can listen to audio books that you
have transferred to your phone from
a computer using Media Manager.
To play audio books
1From standby select Menu > Media
> Music > Audio books.
2Select an audio book.
3Scroll to a chapter and select Play.
PlayNow™
You can connect to PlayNow™ to
download ringtones, games, music,
themes and wallpapers. You can
preview or listen to content before
you purchase and download it to
your phone.
Before you use PlayNow™
You must have the required Internet
connection settings in your phone.
See Settings on page 52.
To use PlayNow™
1From standby select Menu
> PlayNow™.
2Scroll the PlayNow™ Web site and
follow the instructions to preview and
purchase content.
TrackID™
TrackID™ is a music recognition
service. You can search for song titles,
artists and album names.
It may take a few minutes before
a transferred audio book appears
in the list of available audio books.
Audio books in other formats than M4B
or audio books that do not have ID3v2
chapter tags can be found in the Tracks
folder.
This service is not available in all countries.
42 Entertainment
To search for song information
•When you hear a song through a
loudspeaker, from standby select
Menu > Entertainment > TrackID™
> Start.
•When the radio is playing select
Options > TrackID™.
Online music and video clips
You can view video clips and listen to
music by streaming them to your phone
from the Internet. If settings are not
already in your phone, see Settings on
page 52. For more information, contact
your network operator or go to
www.sonyericsson.com/support.
To select a data account for
streaming
1From standby select Menu > Settings
> the Connectivity tab > Streaming
settings > Connect using:.
2Select the data account to use.
3Select Save.
To stream music and video clips
1From standby select Menu > Internet.
2Select Options > Go to > Bookmarks.
3Select a link to stream from.
Entertainment
Video player
To play videos
1From standby select Menu > Media
> Video.
2Scroll to a title and select Play.
To stop playing videos
•Press the centre navigation key.
Radio
To listen to the radio
1Connect the handsfree to the phone.
2From standby select Menu > Radio.
To change the volume
•When the radio is playing, press the
volume keys up or down.
To automatically search for channels
•When the radio is playing, select
Search.
To manually search for channels
•When the radio is playing, press
or .
For cost information contact your service
provider.
Do not use your phone as a radio
in places where this is prohibited.
43Entertainment
Saving channels
You can save up to 20 preset channels.
To save channels
1When you have found a radio channel
select Options > Save.
2Scroll to a position and select Insert.
To select saved channels
1From standby select Menu > Radio
> Options > Channels.
2Select a radio channel.
To switch between saved channels
•When the radio is playing, press
or .
Ringtones and melodies
To set a ringtone
1From standby select Menu > Settings
> the Sounds & alerts tab > Ringtone.
2Find and select a ringtone.
To set the ringtone volume
1From standby select Menu > Settings
> the Sounds & alerts tab > Ring
volume.
2Press or to change the volume.
3Select Save.
To turn the ringtone off
•From standby press and hold down
.
To set the vibrating alert
1From standby select Menu > Settings
> the Sounds & alerts tab > Vibrating
alert.
2Select an option.
MusicDJ™
You can compose and edit your own
melodies to use as ringtones. A melody
consists of four types of tracks – Drums,
Basses, Chords and Accents. A track
contains a number of music blocks. The
blocks consist of pre-arranged sounds
with different characteristics. The blocks
are grouped into Intro, Verse, Chorus
and Break. You compose a melody
by adding music blocks to the tracks.
To compose a melody
1From standby select Menu
> Entertainment > MusicDJ™.
2Select to Insert, Copy or Paste blocks.
3Use , , or to scroll between
the blocks.
4Select Options > Save melody.
All sounds, except the alarm, are silenced
with this key.
44 Entertainment
Sound recorder
You can record a voice memo or
a sound. Recorded sounds can also
be set as ringtones.
To record a sound
•From standby select Menu
> Entertainment > Record sound
> Record.
To listen to a recording
1From standby select Menu > Organizer
> File manager.
2Scroll to Music and select Open.
3Scroll to a recording and select Play.
Games
Your phone contains preloaded games.
You can also download games. Help
texts are available for most games.
To start a game
1From standby select Menu > Media
> Games.
2Select a game.
To end a game
•Press .
Applications
You can download and run Java™
applications. You can also view
information or set different permissions.
Before you use Java™ applications
If settings are not already entered in
your phone, see Settings on page 52.
To select a Java application
1From standby select Menu > Organizer
> Applications.
2Select an application.
To view information about a Java
application
1From standby select Menu > Organizer
> Applications.
2Scroll to an application and select
Options > Information.
To set permissions for a Java
application
1From standby select Menu > Organizer
> Applications.
2Scroll to an application and select
Options > Permissions.
3Set permissions.
45Internet
Java application screen size
Some Java applications are designed
for a specific screen size. For more
information, contact the application
vendor.
To set the screen size for a Java
application
1From standby select Menu > Organizer
> Applications.
2Scroll to an application and select
Options > Screen size.
3Select an option.
Internet profiles for Java applications
Some Java applications need to
connect to the Internet to receive
information. Most Java applications use
the same Internet settings as your Web
browser.
Internet
To start browsing
1From standby select Menu > Internet.
2Select Options > Go to.
3Select an option.
To exit the browser
•While browsing the Internet, select
Options > Exit browser.
Bookmarks
You can create and edit bookmarks as
quick links to your favourite Web pages.
To create a bookmark
1While browsing the Internet, select
Options > Tools > Add bookmark.
2Enter a title and an address. Select
Save.
To select a bookmark
1From standby select Menu > Internet.
2Select Options > Go to > Bookmarks.
3Scroll to a bookmark and select Go to.
If your connection to the Internet does
not work, see Settings on page 52 or
contact your operator.
46 Internet
History pages
You can view Web pages you have
browsed.
To view history pages
•From standby select Menu > Internet
> Options > Go to > History.
To use pan and zoom on a Web page
1While browsing the Internet, press .
2Use the navigation key to move the
frame.
3Press Zoom.
4To switch back to pan, press .
To turn off Smart-fit
•While browsing the Internet, select
Options > Advanced > Smart-Fit > Off.
To make a call while browsing
•While browsing the Internet press .
To save a picture from a Web page
1While browsing the Internet, select
Options > Tools > Save picture.
2Select a picture.
To find text on a Web page
1While browsing the Internet, select
Options > Tools > Find on page.
2Enter text and press Find.
To send a link
1While browsing the Internet, select
Options > Tools > Send link.
2Select a transfer method.
Internet security and
certificates
Your phone supports secure browsing.
Certain Internet services, such as
banking, require certificates in your
phone. Your phone may already contain
certificates when you buy it or you can
download new certificates.
To view certificates in the phone
•From standby select Menu > Settings
> the General tab > Security
> Certificates.
To use pan and zoom, you need to turn
off Smart-fit.
Make sure the receiving device supports
the transfer method you select.
47Internet
Web feeds
You can subscribe to and download
frequently updated content, such as
news, podcasts or photos, using Web
feeds.
To add new feeds for a Web page
1When you browse a page on the
Internet that has Web feeds, indicated
by the icon, select Options > Web
feeds.
2For each feed you want to add, scroll
to the feed and select Mark.
3Select Options > Continue.
To download content via feeds
1From standby select Menu > Media
> Web feeds.
2Scroll to a feed and select View or .
3Select a heading to expand.
4Select an icon depending on content,
to open a Web page, to
download an audio podcast, to
download a video podcast or
to download a photo.
Updating Web feeds
You can manually update your feeds,
or schedule updates. When there are
updates, appears on the screen.
To schedule Web feed updates
1From standby select Menu > Media
> Web feeds.
2Scroll to a feed and select Options
> Schedule update.
3Select an option.
To update Web feeds manually
1From standby select Menu > Media
> Web feeds.
2Scroll to a feed and select Options
> Update.
3Select an option.
Web feeds in standby
You can show news updates on the
standby screen.
To show Web feeds in standby
1From standby select Menu > Media
> Web feeds.
2Scroll to a feed and select Options
> Settings > Standby ticker > Show in
standby.
You can also subscribe to and download
content to a computer via feeds using
Sony Ericsson Media Manager. You can
then transfer the content to your phone.
See Transferring content to and from a
computer on page 39.
Frequent updates may be costly.
48 GPS
To access Web feeds from standby
1From standby select Ticker.
2To read more about a feed, press
or to scroll to a headline and select
Go to.
Podcasts
Podcasts are files, for example, radio
programs or video content, that you
can download and play. You subscribe
to and download podcasts using Web
feeds.
To access audio podcasts
•From standby select Menu > Media
> Music > Podcasts.
To access video podcasts
•From standby select Menu > Media
> Video > Podcasts.
Photo feeds
You can subscribe to Photo feeds and
download photos. To start using Photo
feeds, see Web feeds on page 47.
To access photo feeds
•From standby select Menu > Media
> Photo > Photo feeds.
GPS
Your phone is equipped with a GPS
receiver that uses satellite signals
to calculate your location.
Using the GPS
Make sure you have a clear view of the
sky when using features that require
the GPS receiver to find your location.
If your location is not found after a few
minutes, move to another location. To
facilitate the search, stand still and do
not cover the GPS antenna.
Some GPS features use the Internet.
49GPS
Assisted GPS
With Assisted GPS (A-GPS) it takes
less time to calculate a location.
Google Maps™ for mobile
Google Maps™ lets you view maps
and satellite imagery, find locations
and calculate routes.
To use Google Maps
•From standby select Menu > Location
services > Google Maps.
To view help about Google Maps
•When you use Google Maps, select
Options > Help
Driving directions
Wayfinder Navigator™ guides you
to your destination using voice
instructions. A free three-month trial
version of Wayfinder Navigator is
included in the phone.
To start Wayfinder Navigator
•From standby select Menu > Location
services > Navigation.
More GPS features
Save locations
All saved locations are found in
My favourites.
To save your current location
1From standby select Menu > Location
services > My favourites > Add new
place.
2Select Edit and enter the title.
Select OK.
3Scroll to Description: and select Add.
Enter the description and select OK.
4Scroll to Position: and select Add
> Current position.
To view a saved location
1From standby select Menu > Location
services > My favourites.
2Scroll to a location and select Go to.
Contact your network operator for more
information.
Sony Ericsson does not warrant the
accuracy of any directional services
including but not limited to turn-by-turn
navigational services.
When you use Google Maps you can
press to access your favourites.
50 GPS
Status information
When your location is found you
can view available satellites and get
information about your current speed
and altitude.
To view GPS status
1From standby select Menu > Location
services > Status info.
2Scroll between the tabs.
Location requests
External services may ask for your
location.
To change permission for external
services
1From standby select Menu > Location
services > Settings > Privacy.
2Select an option.
Turn off the GPS
The GPS receiver is automatically
turned off when it is no longer used.
You can also manually turn off the GPS
receiver. This saves battery power
when using features that do not require
the GPS receiver to find your location.
To turn the GPS on or off manually
1From standby select Menu > Location
services > Settings.
2Select an option.
Tracker
Tracker is a GPS-based sports
application which allows you to keep
track of your speed, distance, route and
energy consumption during training.
You can base the training on how long
time you want to train or on what
distance you want to cover. You can
also base it on a previous training route
which has GPS data.
To start a training session
1From standby select Menu > Location
services > Tracker > Start training.
2Select a training type.
3Scroll to an item, select Edit and enter
the data.
4Select Done to save.
5Select Start to start training.
To compare results during training
1From standby select Menu > Location
services > Tracker > Start training.
2Select Route based.
Information provided by use of the
Tracker application is approximate.
Sony Ericsson makes no warranty of any
kind with respect to the accuracy of the
Tracker application. Any serious health
and fitness concerns should be referred
to a health care professional.
51GPS
3Scroll to Route:, select Edit and select
a route.
4Scroll to Live compare and select Edit.
5Scroll to the result you want to compare
with and select Compare.
6Select Done and then Start.
To switch between training views
•During a training session, press
or to view information on training
duration, progress and live comparison
with a previous session.
To end a training session manually
•During a training session, select Pause
> End.
Results
The training result is shown after a
session is ended. You can view past
results anytime, and compare them
if they have GPS data.
To view a training result
•From standby select Menu > Location
services > Tracker > Results. If you
have used laps, press or to view
result per lap.
To compare results
1From standby select Menu > Location
services > Tracker > Results.
2Scroll to a result and select Options
> Compare.
3Select a result to compare with.
Energy consumption
To calculate and view the energy
consumption for a session you must
first set your personal profile. You can
see the energy consumption in the
result view.
To set the personal profile
1From standby select Menu > Location
services > Tracker > Settings
> Personal profile.
2Select an item, enter data and
press OK.
3When finished, select Options > Save
profile.
To turn on energy consumption
•From standby select Menu > Location
services > Tracker > Settings > Energy
consumption > On.
52 Connectivity
Connectivity
Settings
Before you synchronize with an Internet
service, use the Internet, PlayNow™,
My friends, Java, picture messaging,
email and picture blog you need to have
settings in your phone.
If settings are not already entered, you
can download settings using the setup
wizard or by going to
www.sonyericsson.com/support.
To download settings using the
Setup wizard
1From standby select Menu > Settings
> the General tab > Setup wizard
> Settings download.
2Follow the instructions that appear.
To download settings using
a computer
1Go to
www.sonyericsson.com/support.
2Follow the instructions on the screen.
Phone name
You can enter a name for your phone
that is shown to other devices when
using, for example, Bluetooth wireless
technology.
To enter a phone name
1From standby select Menu > Settings
> the Connectivity tab > Phone name.
2Enter the phone name and select OK.
Bluetooth wireless technology
The Bluetooth function makes wireless
connection to other Bluetooth devices
possible. For example, you can:
•Connect to handsfree devices.
•Connect to several devices at the
same time.
•Connect to computers and access
the Internet.
•Exchange items and play multiplayer
games.
Contact your network operator or service
provider for more information.
We recommend a range within 10 metres
(33 feet), with no solid objects in between,
for Bluetooth communication.
53Connectivity
Before you use Bluetooth wireless
technology
You must turn on the Bluetooth function
to communicate with other devices.
You may also have to pair your phone
with other Bluetooth devices.
To turn the Bluetooth function on
•From standby select Menu > Settings
> the Connectivity tab > Bluetooth
> Turn on.
To receive an item
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth
> Turn on.
2When you receive an item, follow the
instructions that appear.
To pair the phone with a device
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth
> My devices.
2Scroll to New device and select Add
to search for available devices.
3Select a device.
4Enter a passcode, if required.
To allow connection to the phone
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth
> My devices.
2Select a device from the list.
3Select Options > Allow connection.
4Select Always ask or Always allow.
To pair the phone with a Bluetooth
handsfree for the first time
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth
> Handsfree.
2Scroll to a device and select Yes.
3Enter a passcode, if required.
To pair the phone with more than one
Bluetooth handsfree
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth
> Handsfree > My handsfree > New
handsfree.
2Select a device from the list.
3Enter a passcode, if required.
Make sure that the device you want to
pair your phone with has the Bluetooth
function activated and Bluetooth visibility
set to on.
This is only possible with devices that
require access to a secure service.
54 Connectivity
Power saving
You can save battery power with the
Power save function. You can only
connect with one Bluetooth device at a
time when using Power save. You must
turn this function off if you want to
connect with more than one Bluetooth
device at the same time.
To turn Powersave on
•From standby select Menu > Settings
> the Connectivity tab > Bluetooth
> Powersave > On.
Transferring sound to and from
a Bluetooth handsfree
You can transfer the sound to and from
a Bluetooth handsfree using a phone
key or the handsfree key.
To transfer sound
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth
> Handsfree > Incoming call.
2Select an option. In phone transfers
sound to the phone. In handsfree
transfers sound to the handsfree.
To transfer sound during a call
1During a call, select Sound.
2Select from the list.
Using the USB cable
You can connect your phone to a
computer with the USB cable to transfer
files, synchronize and use your phone
as a modem. For more information
go to the Getting started section at
www.sonyericsson.com/support.
Before you use the USB cable
See Required operating systems
on page 39.
Only use a USB cable supported by your
phone. Do not remove the USB cable
from your phone or computer during file
transfer as this may corrupt the phone
memory or the memory card.
55Connectivity
To disconnect the USB cable safely
1Right-click the removable disk icon
in Windows Explorer.
2Select Eject.
3Disconnect the USB cable when the
following message is shown in the
phone: Mass storage session ended. It
is now safe to remove the USB cable.
Drag and drop content
You can drag and drop content
between your phone or memory card
and a computer in Microsoft Windows
Explorer.
To drag and drop content
1Connect your phone to a computer
using the USB cable.
2Phone: Select Media transfer. The
phone will remain activated during
file transfer.
3Computer: Wait until an external
device icon appears in My Computer
and then double click to open. Phone
memory and memory card will appear
as external drives.
4Drag and drop selected files between
the phone and the computer.
Synchronizing
You can synchronize in two different
ways:
•You can use the USB cable or Bluetooth
wireless technology to synchronize
phone contacts, appointments,
bookmarks, tasks and notes with a
computer program such as Microsoft
Outlook.
•You can synchronize with an Internet
service using SyncML™ or a Microsoft
Exchange Server using Microsoft
Exchange ActiveSync™.
For more information go to the
Getting started section at
www.sonyericsson.com/support.
Synchronizing using a computer
Before synchronizing you need to
install the Sony Ericsson PC Suite.
See Required operating systems
on page 39.
Use only one of the synchronization
methods at a time with your phone.
Sony Ericsson PC Suite software
is included on the CD with your
phone and available for download
at www.sonyericsson.com/support.
56 Connectivity
To install the Sony Ericsson PC Suite
1Turn on your computer and insert the
CD. The CD starts automatically and
the installation window opens.
2Select a language and click OK.
3Click Install Sony Ericsson PC suite
and follow the instructions on the
screen.
To synchronize using the PC Suite
1Computer: Start PC Suite from Start/
Programs/Sony Ericsson/PC Suite.
2Follow the instructions in the PC Suite
for how to connect.
3Phone: Select Phone mode.
4Computer: When you are notified that
the Sony Ericsson PC Suite has found
your phone, you can start
synchronizing.
Synchronizing using an Internet
service
You can synchronize online using
SyncML or Microsoft Exchange
ActiveSync. If Internet settings are
not in your phone, see Settings on
page 52.
SyncML
You can synchronize remote data and
personal information using SyncML.
Before you synchronize using SyncML
You must enter settings for SyncML
synchronization and register a
synchronization account online with
a service provider. Required settings:
•Server address – server URL
•Database name – database
to synchronize with
To enter settings for SyncML
1From standby select Menu > Organizer
> Synchronization.
2Scroll to New account and select Add
> SyncML.
3Enter a name for the new account and
select Cont.
4Select Server address. Enter the
required information and select OK.
5Enter Username and Password, if
required.
6Scroll to the Applications tab and mark
applications to synchronize.
7Scroll to the App. settings tab and
select an application.
For usage details, see the Sony Ericsson
PC Suite Help section once the software
has been installed on your computer.
57Connectivity
8Select Database name and enter the
required information.
9Scroll to the Advanced tab to enter
additional settings for synchronizing
and select Save.
To synchronize using SyncML
1From standby select Menu > Organizer
> Synchronization.
2Scroll to an account and select Start.
Microsoft Exchange ActiveSync
You can access and synchronize
corporate exchange information such
as email, contacts and calendar entries
using Microsoft Exchange Server with
Microsoft Exchange ActiveSync.
Before you synchronize using
Microsoft Exchange ActiveSync
You must enter settings for Microsoft
Exchange ActiveSync to access a
Microsoft Exchange Server. Required
settings:
•Server address – server URL
•Domain – server domain
•Username – account username
•Password – account password
To enter settings for Microsoft
Exchange ActiveSync
1From standby select Menu > Organizer
> Synchronization.
2Scroll to New account and select Add
> Exchange ActiveSync.
3Enter a name for the new account and
select Cont.
4Enter the required settings.
5Scroll between the tabs to enter
additional settings.
6Select Save.
To synchronize using Microsoft
Exchange ActiveSync
1From standby select Menu > Organizer
> Synchronization.
2Scroll to an account and select Start.
Update service
You can update your phone with
the latest software. You do not lose
personal or phone information.
For more information on synchronization
settings, contact your IT administrator.
Before you start to synchronize with
Exchange ActiveSync you must enter the
correct time zone in your phone.
58 Connectivity
There are two ways to update your
phone:
•Over the air using your phone
•Using the provided USB cable and
an Internet-connected computer
Before you use the Update service
If settings are not in your phone see
Settings on page 52.
To change Internet settings
•From standby select Menu > Settings
> the General tab > Update service
> Settings > Internet settings.
To view the current software in the
phone
1From standby select Menu > Settings
> the General tab > Update service.
2Select Software version.
To use Update service using the
phone
1From standby select Menu > Settings
> the General tab > Update service.
2Select Search for update and follow
the instructions that appear.
To use Update service using a USB
cable
1Go to www.sonyericsson.com/support
or click the Sony Ericsson Update
service in the PC Suite software if
installed on your computer. See To
install the Sony Ericsson PC Suite
on page 56.
2Select a region and country.
3Follow the instructions on the screen.
To set a reminder to use Update
service
1From standby select Menu > Settings
> the General tab > Update service
> Settings > Reminder.
2Select an option.
Update service requires data access
such as GPRS, 3G or HSDPA.
59More features
More features
Flight mode
In Flight mode the network and radio
transceivers are turned off to prevent
disturbance to sensitive equipment.
When the flight mode menu is
activated you are asked to select
a mode the next time you turn on
your phone:
•Normal mode – full functionality
•Flight mode – limited functionality
To activate the flight mode menu
•From standby select Menu > Settings
> the General tab > Flight mode
> Show at startup.
To select flight mode
1When the flight mode menu is activated,
turn off your phone.
2Turn on your phone and select
Flight mode.
File manager
You can use the file manager to handle
files saved in the phone memory or on
a memory card.
Handling files
You can move and copy files between
your phone, a computer and a memory
card. See Transferring content to and
from a computer on page 39. Files are
saved on the memory card first and then
in the phone memory. Unrecognized
files are saved in the Other folder.
You can create subfolders to move or
copy files to. You can select more than
one or all the files in a folder at the same
time for all folders except Games and
Applications.
If the memory is full, delete some
content to create space.
You can use the Bluetooth function
in Flight mode.
You are not allowed to exchange some
copyright-protected material. A protected
file has a icon.
60 More features
File manager tabs
The file manager is divided into three
tabs, and icons indicate where the
files are saved.
To view information about files
1From standby select Menu > Organizer
> File manager.
2Find a file and select Options
> Information.
To move a file in the file manager
1From standby select Menu > Organizer
> File manager.
2Find a file and select Options > Manage
file > Move.
3Select Memory card or Phone.
4Open a folder.
5Select Paste.
To select more than one file
in a folder
1From standby select Menu > Organizer
> File manager.
2Scroll to a folder and select Open.
3Select Options > Mark > Mark several.
4For each file you want to mark, scroll
to the file and select Mark.
Alarms
You can set a sound or the radio as an
alarm signal. The alarm sounds even if
the phone is turned off. When the alarm
sounds you can silence it or turn it off.
To set the alarm
1From standby select Menu > Organizer
> Alarms.
2Scroll to an alarm and select Edit.
3Scroll to Time: and select Edit.
4Enter a time and select OK > Save.
To set the recurrent alarm
1From standby select Menu > Organizer
> Alarms.
2Scroll to an alarm and select Edit.
3Scroll to Recurrent: and select Edit.
4Scroll to a day and select Mark.
5To select another day, scroll to the day
and select Mark.
6Select Done > Save.
To set the alarm signal
1From standby select Menu > Organizer
> Alarms.
2Scroll to an alarm and select Edit.
3Scroll to the tab.
4Scroll to Alarm signal: and select Edit.
5Find and select an alarm signal. Select
Save.
61More features
To silence the alarm
•When the alarm sounds, press any key.
•To repeat the alarm, select Snooze.
To turn off the alarm
•When the alarm sounds, press any key
and select Turn off.
To cancel the alarm
1From standby select Menu > Organizer
> Alarms.
2Scroll to an alarm and select Turn off.
The alarm in silent mode
You can set the alarm not to sound
when the phone is in silent mode.
To set an alarm to sound or not
in silent mode
1From standby select Menu > Organizer
> Alarms.
2Scroll to an alarm and select Edit.
3Scroll to the tab.
4Scroll to Silent mode: and select Edit.
5Select an option.
Calendar
The calendar can be synchronized with
a computer calendar, with a calendar
on the Web or with a Microsoft
Exchange Server (Microsoft Outlook).
For more information see Synchronizing
on page 55.
Default view
You can choose whether month, week
or day view will appear first when you
open the calendar.
To set default view
1From standby select Menu > Organizer
> Calendar.
2Select Options > Advanced > Default
view.
3Select an option.
Appointments
You can add new appointments
or reuse existing appointments.
To add an appointment
1From standby select Menu > Organizer
> Calendar.
2Select a date.
3Scroll to New appointment and
select Add.
4Enter the information and confirm each
entry.
5Select Save.
To view an appointment
1From standby select Menu > Organizer
> Calendar.
2Select a date.
3Scroll to an appointment and select
View.
62 More features
To edit an appointment
1From standby select Menu > Organizer
> Calendar.
2Select a date.
3Scroll to an appointment and select
View.
4Select Options > Edit.
5Edit the appointment and confirm
each entry.
6Select Save.
To view a calendar week
1From standby select Menu > Organizer
> Calendar.
2Select a date.
3Select Options > Change view to
> Week.
To set when reminders should sound
1From standby select Menu > Organizer
> Calendar.
2Select a date.
3Select Options > Advanced
> Reminders.
4Select an option.
Notes
You can make notes and save them.
You can also show a note in standby.
To add a note
1From standby select Menu > Organizer
> Notes.
2Scroll to New note and select Add.
3Write a note and select Save.
To show a note in standby
1From standby select Menu > Organizer
> Notes.
2Scroll to a note and select Options
> Show in standby.
To hide a note from standby
1From standby select Menu > Organizer
> Notes.
2Scroll to a note and select Options
> Hide in standby.
Tasks
You can add new tasks or reuse
existing tasks.
To add a task
1From standby select Menu > Organizer
> Tasks.
2Select New task and select Add.
3Select an option.
4Enter details and confirm each entry.
A reminders option set in calendar
affects a reminders option set in tasks.
63More features
To view a task
1From standby select Menu > Organizer
> Tasks.
2Scroll to a task and select View.
To set when reminders should sound
1From standby select Menu > Organizer
> Tasks.
2Scroll to a task and select Options
> Reminders.
3Select an option.
Profiles
You can change settings such as the
ring volume and vibrating alert to suit
different locations. You can reset all
profiles to the phone’s original settings.
To select a profile
1From standby select Menu > Settings
> the General tab > Profiles.
2Select a profile.
To view and edit a profile
1From standby select Menu > Settings
> the General tab > Profiles.
2Scroll to a profile and select Options
> View and edit.
Time and date
To set the time
1From standby select Menu > Settings
> the General tab > Time & date
> Time.
2Enter the time and select Save.
To set the date
1From standby select Menu > Settings
> the General tab > Time & date > Date.
2Enter the date and select Save.
To set the time zone
1From standby select Menu > Settings
> the General tab > Time & date > My
time zone.
2Select the time zone you are in.
Theme
You can change the appearance of the
screen through items such as colours
and wallpaper. You can also create
new themes and download them.
For more information, go to
www.sonyericsson.com/support.
A reminders option set in tasks affects
a reminders option set in calendar.
You cannot rename the Normal profile.
If you select a city, My time zone also
updates the time when daylight saving
time changes.
64 More features
To set a theme
1From standby select Menu > Settings
> the Display tab > Theme.
2Scroll to a theme and select Set.
Main menu layout
You can change the layout of the
icons in the main menu.
To change the main menu layout
1From standby select Menu > Options
> Main menu layout.
2Select an option.
Locks
SIM card lock
This lock only protects your
subscription. Your phone will work with
a new SIM (Subscriber Identity Module)
card. If the lock is on, you have to enter
a PIN (Personal Identity Number).
If you enter your PIN incorrectly three
times in a row, the SIM card is blocked
and you need to enter your PUK
(Personal Unblocking Key). Your PIN
and PUK are supplied by your network
operator.
To unblock the SIM card
1When PIN blocked appears, enter your
PUK and select OK.
2Enter a new four-to-eight-digit PIN and
select OK.
3Re-enter the new PIN and select OK.
To edit the PIN
1From standby select Menu > Settings
> the General tab > Security > Locks
> SIM protection > Change PIN.
2Enter your PIN and select OK.
3Enter a new four-to-eight-digit PIN and
select OK.
4Re-enter the new PIN and select OK.
To use the SIM card lock
1From standby select Menu > Settings
> the General tab > Security > Locks
> SIM protection > Protection.
2Select an option.
3Enter your PIN and select OK.
If Codes do not match appears, you
entered the new PIN incorrectly.
If Wrong PIN appears, followed by Old
PIN:, you entered your old PIN incorrectly.
65More features
Phone lock
You can stop unauthorized use of your
phone. Change the phone lock code
(0000) to any four-to-eight-digit
personal code.
To use the phone lock
1From standby select Menu > Settings
> the General tab > Security > Locks
> Phone protection > Protection.
2Select an option.
3Enter the phone lock code and
select OK.
To unlock the phone
•Enter your code and select OK.
To change the phone lock code
1From standby select Menu > Settings
> the General tab > Security > Locks
> Phone protection > Change code.
2Enter the old code and select OK.
3Enter the new code and select OK.
4Repeat the code and select OK.
Keypad lock
You can set this lock to avoid
accidental dialling. Incoming calls
can be answered without unlocking
the keypad.
To use the automatic keylock
1From standby select Menu > Settings
> the General tab > Security
> Automatic keylock.
2Select an option.
To lock the keypad manually
•From standby press and select
Lock.
To unlock the keypad manually
•From standby press and select
Unlock.
IMEI number
Keep a copy of your IMEI (International
Mobile Equipment Identity) number in
case your phone is stolen.
To view your IMEI number
•From standby press , , ,
, .
It is important that you remember your
new code. If you forget it, you have
to take your phone to your local
Sony Ericsson retailer.
Calls to the international emergency
number 112 can still be made.
66 Troubleshooting
Troubleshooting
Some problems will require you to call
your network operator.
For more support go to
www.sonyericsson.com/support.
Common questions
I have problems with memory
capacity or the phone is working
slowly
Restart your phone every day to free
memory or do a Master reset.
Master reset
If you select Reset settings, the
changes that you have made to settings
will be deleted.
If you select Reset all, in addition to
your changes to settings, all contacts,
messages, personal data, and content
that you have downloaded, received
or edited will also be deleted.
To reset the phone
1From standby select Menu > Settings
> the General tab > Master reset.
2Select an option.
3Follow the instructions that appear.
I cannot charge the phone or battery
capacity is low
The charger is not properly connected
or the battery connection is poor.
Remove the battery and clean the
connectors.
The battery is worn out and needs to
be replaced. See Charging the battery
on page 8.
No battery icon appears when I start
charging the phone
It may take a few minutes before the
battery icon appears on the screen.
Some menu options appear in grey
A service is not activated. Contact
your network operator.
I cannot use SMS/text messages
on my phone
Settings are missing or incorrect.
Contact your network operator to
find out the correct SMS service
centre setting. See Text messages
on page 33.
I cannot use picture messages on
my phone
Your subscription does not include
data capability. Settings are missing or
incorrect. Please contact your network
operator.
67Troubleshooting
See Help in your phone on page 8 or
go to www.sonyericsson.com/support
to order settings and follow the
instructions on the screen. See
Settings on page 52.
I cannot use the Internet
Your subscription does not include
data capability. Internet settings are
missing or incorrect. Please contact
your network operator.
See Help in your phone on page 8 or
go to www.sonyericsson.com/support
to order Internet settings, and follow
the instructions on the screen. See
Settings on page 52.
The phone does not ring or rings too
softly
Make sure that Silent mode has not
been set to On. See To turn the
ringtone off on page 43.
Check the ringtone volume. See To set
the ringtone volume on page 43.
Check the profile. See To select a
profile on page 63.
Check the divert call options. See
To divert calls on page 29.
The phone cannot be detected by
other devices using Bluetooth
wireless technology
You have not turned the Bluetooth
function on. Make sure that the visibility
is set to show phone. See To turn the
Bluetooth function on on page 53.
I cannot synchronize or transfer data
between my phone and my computer,
when using the USB cable.
The cable or software that came with
your phone has not been properly
installed. Go to
www.sonyericsson.com/support to
read Getting started guides which
contain detailed installation instructions
and troubleshooting guides.
I have forgotten my code memo
passcode
If you forget your passcode, you must
reset the code memo. This means that
all entries in the code memo are
deleted. The next time you enter the
code memo, you must proceed as
if you are opening it for the first time.
68 Troubleshooting
To reset code memo
1From standby select Menu > Organizer
> Code memo.
2Enter any passcode to access the code
memo. The checkword and codes that
are then shown are incorrect.
3Select Options > Reset.
4Reset code memo? appears.
5Select Yes.
Where can I find the regulatory
information such as my IMEI number
if I cannot turn on my phone?
Error messages
Insert SIM
There is no SIM card in your phone
or you may have inserted it incorrectly.
See To insert the SIM card on page 6.
The SIM card connectors need
cleaning. If the card is damaged,
contact your network operator.
Insert correct SIM card
Your phone is set to work only with
certain SIM cards. Check if you are
using the correct operator SIM card.
Wrong PIN/Wrong PIN2
You have entered your PIN or PIN2
incorrectly.
Enter the correct PIN or PIN2 and
select Yes. See To insert the SIM card
on page 6.
PIN blocked/PIN2 blocked
You have entered your PIN or PIN2
code incorrectly three times in a row.
To unblock, see SIM card lock
on page 64.
Codes do not match
Codes that you have entered do not
match. When you want to change a
security code, for example your PIN,
you have to confirm the new code.
See SIM card lock on page 64.
69Important information
No netw. coverage
Your phone is in flight mode. See
Flight mode on page 59.
Your phone is not receiving any network
signal, or the received signal is too
weak. Contact your network operator
and make sure that the network has
coverage where you are.
The SIM card is not working properly.
Insert your SIM card in another phone.
If this works, it is probably your phone
that is causing the problem. Please
contact the nearest Sony Ericsson
service location.
Emerg. calls only
You are within range of a network,
but you are not allowed to use it.
However, in an emergency, some
network operators allow you to call the
international emergency number 112.
See Emergency calls on page 23.
PUK blocked. Contact operator.
You entered your personal unblocking
key code (PUK) incorrectly 10 times
in a row.
Important information
Sony Ericsson Consumer Web site
On www.sonyericsson.com/support is a support
section where help and tips are only a few clicks
away. Here you will find the latest computer software
updates and tips on how to use your product more
efficiently.
Service and support
From now on you will have access to a portfolio
of exclusive service advantages such as:
•Global and local Web sites providing support.
•A global network of Call Centers.
•An extensive network of Sony Ericsson service
partners.
•A warranty period. Learn more about the warranty
conditions in this User guide.
On www.sonyericsson.com, under the support
section in the language of your choice, you will find
the latest support tools and information, such as
software updates, Knowledge base, phone setup
and additional help when you require it.
For operator-specific services and features, please
contact your network operator for more information.
You can also contact our Call Centers. Use the phone
number for the nearest Call Center in the list below.
If your country/region is not represented in the list,
please contact your local dealer. (The phone numbers
below were correct at the time of going to print.
On www.sonyericsson.com you can always find the
latest updates.)
70 Important information
In the unlikely event that your product needs service
please contact the dealer from whom it was
purchased, or one of our service partners. Save your
original proof of purchase, you will need it if you need
to claim warranty.
You will be charged for a call to one of our Call
Centers according to national rates, including local
taxes, unless the phone number is a toll-free number.
Support
Argentina 800-333-7427 questions.AR@support.sonyericsson.com
Australia 1-300650-600 questions.AU@support.sonyericsson.com
Belgique/België 02-7451611 questions.BE@support.sonyericsson.com
Brasil 4001-04444 questions.BR@support.sonyericsson.com
Canada 1-866-766-9374 questions.CA@support.sonyericsson.com
Central Africa +27 112589023 questions.CF@support.sonyericsson.com
Chile 123-0020-0656 questions.CL@support.sonyericsson.com
Colombia 18009122135 questions.CO@support.sonyericsson.com
Česká republika 844550 055 questions.CZ@support.sonyericsson.com
Danmark 33 31 28 28 questions.DK@support.sonyericsson.com
Deutschland 0180 534 2020 questions.DE@support.sonyericsson.com
ǼȜȜȐįĮ 801-11-810-810
210-89 91 919 questions.GR@support.sonyericsson.com
España 902 180 576 questions.ES@support.sonyericsson.com
France 0 825 383 383 questions.FR@support.sonyericsson.com
Hong Kong/ 8203 8863 questions.HK@support.sonyericsson.com
Hrvatska 062 000 000 questions.HR@support.sonyericsson.com
India/ 39011111 questions.IN@support.sonyericsson.com
Indonesia 021-2701388 questions.ID@support.sonyericsson.com
Ireland 1850 545 888 questions.IE@support.sonyericsson.com
Italia 06 48895206 questions.IT@support.sonyericsson.com
Lietuva 8 70055030 questions.LT@support.sonyericsson.com
Magyarország +36 1 880 4747 questions.HU@support.sonyericsson.com
Malaysia 1-800-889900 questions.MY@support.sonyericsson.com
México 01 800 000 4722 questions.MX@support.sonyericsson.com
Nederland 0900 899 8318 questions.NL@support.sonyericsson.com
New Zealand 0800-100150 questions.NZ@support.sonyericsson.com
Norge 815 00 840 questions.NO@support.sonyericsson.com
Österreich 0810 200245 questions.AT@support.sonyericsson.com
Pakistan 111 22 55 73
(92-21) 111 22 55 73 questions.PK@support.sonyericsson.com
71Important information
Guidelines for Safe and
Efficient Use
Please follow these guidelines. Failure
to do so might entail a potential health
risk or product malfunction. If in doubt
as to its proper function, have the
product checked by a certified service
partner before charging or using it.
Recommendations for care and safe
use of our products
•Handle with care and keep in a clean and dust-free
place.
•Warning! May explode if disposed of in fire.
•Do not expose your product to liquid or moisture
or humidity.
•Do not expose to extreme
temperatures. Do not expose the
battery to temperatures above +60°C
(+140°F).
•Do not expose to flames or lit tobacco
products.
•Do not drop, throw or try to bend your
product.
•Do not paint or attempt to disassemble
or modify your product. Only
Sony Ericsson authorised personnel
should perform service.
•Consult with authorized medical staff
and the instructions of the medical
device manufacturer before using your product
near pacemakers or other medical devices or
equipment.
Philippines/Pilipinas 02-6351860 questions.PH@support.sonyericsson.com
Polska 0 (prefiks) 22 6916200 questions.PL@support.sonyericsson.com
Portugal 808 204 466 questions.PT@support.sonyericsson.com
România (+4021) 401 0401 questions.RO@support.sonyericsson.com
Ɋɨɫɫɢɹ 8 (495) 787 0986 questions.RU@support.sonyericsson.com
Schweiz/Suisse/Svizzera 0848 824 040 questions.CH@support.sonyericsson.com
Singapore 67440733 questions.SG@support.sonyericsson.com
Slovensko 02-5443 6443 questions.SK@support.sonyericsson.com
South Africa 0861 6322222 questions.ZA@support.sonyericsson.com
Suomi 09-299 2000 questions.FI@support.sonyericsson.com
Sverige 013-24 45 00 questions.SE@support.sonyericsson.com
Türkiye 0212 473 77 71 questions.TR@support.sonyericsson.com
ɍɤɪɚʀɧɚ (+0380) 44 590 1515 questions.UA@support.sonyericsson.com
United Kingdom 08705 23 7237 questions.GB@support.sonyericsson.com
United States 1-866-7669347 questions.US@support.sonyericsson.com
Venezuela 0-800-100-2250 questions.VE@support.sonyericsson.com
43 919880 questions.AE@support.sonyericsson.com
4008100000 questions.CN@support.sonyericsson.com
02-25625511 questions.TW@support.sonyericsson.com
02-2483030 questions.TH@support.sonyericsson.com
72 Important information
•Discontinue use of electronic devices or disable the
radio transmitting functionality of the device where
required or requested to do so.
•Do not use where a potentially explosive atmosphere
exists.
•Do not place your product or install wireless
equipment in the area above an air bag in your car.
•Caution: Cracked or broken displays may create
sharp edges or splinters that could be harmful upon
contact.
•Do not use your Bluetooth Headset in positions
where it is uncomfortable or will be subject to
pressure.
CHILDREN
Warning! Keep out of the reach of
children. Do not allow children to play
with mobile phones or accessories.
They could hurt themselves or others.
Products may contain small parts that could become
detached and create a choking hazard.
Power supply (Charger)
Connect the charger to power sources as marked
on the product. Do not use outdoors or in damp
areas. Do not alter or subject the cord to damage
or stress. Unplug the unit before cleaning it. Never
alter the plug. If it does not fit into the outlet, have
a proper outlet installed by an electrician. When
power supply is connected there is a small drain of
power. To avoid this small energy waste, disconnect
the power supply when the product is fully charged.
Use of charging devices that are not Sony Ericsson
branded may impose increased safety risks.
Battery
New or idle batteries can have short-term reduced
capacity. Fully charge the battery before initial use.
Use for intended purpose only. Charge the battery
in temperatures between +5°C (+41°F) and +45°C
(+113°F). Do not put the battery into your mouth.
Do not let the battery contacts touch another metal
object. Turn off the product before removing the
battery. Performance depends on temperatures,
signal strength, usage patterns, features selected
and voice or data transmissions. Only Sony Ericsson
service partners should remove or replace built-in
batteries. Use of batteries that are not Sony Ericsson
branded may pose increased safety risks.
Personal medical devices
Mobile phones may affect implanted medical
equipment. Reduce risk of interference by keeping
a minimum distance of 15 cm (6 inches) between
the phone and the device. Use the phone at your
right ear. Do not carry the phone in your breast
pocket. Turn off the phone if you suspect
interference. For all medical devices, consult
a physician and the manufacturer.
Driving
Some vehicle manufacturers forbid the use of phones
in their vehicles unless a handsfree kit with an external
antenna supports the installation. Check with your
vehicle manufacturer’s representative to be sure
that your mobile phone or Bluetooth handsfree will
not affect the electronic systems in your vehicle.
Full attention should be given to driving at all times
and local laws and regulations restricting the use of
wireless devices while driving must be observed.
73Important information
GPS/Location based functions
Some products provide GPS/Location based
functions. Location determining functionality is
provided “As is” and “With all faults”. Sony Ericsson
does not make any representation or warranty as
to the accuracy of such location information.
Use of location-based information by the device may
not be uninterrupted or error free and may additionally
be dependent on network service availability. Please
note that functionality may be reduced or prevented
in certain environments such as building interiors
or areas adjacent to buildings.
Caution: Do not use GPS functionality in a manner
which causes distraction from driving.
Emergency calls
Calls cannot be guaranteed under all conditions.
Never rely solely upon mobile phones for essential
communications. Calls may not be possible in all
areas, on all networks, or when certain network
services and/or phone features are used.
Antenna
Use of antenna devices not marketed by
Sony Ericsson could damage your phone, reduce
performance, and produce SAR levels above the
established limits. Do not cover the antenna with
your hand as this affects call quality, power levels
and can shorten talk and standby times.
Radio frequency (RF) exposure and
Specific Absorption Rate (SAR)
When your phone or Bluetooth handsfree is turned
on, it emits low levels of radio frequency energy.
International safety guidelines have been developed
through periodic and thorough evaluation of scientific
studies. These guidelines establish permitted levels
of radio wave exposure. The guidelines include
a safety margin designed to assure the safety
of all persons and to account for any variations
in measurements.
Specific Absorption Rate (SAR) is used to measure
radio frequency energy absorbed by the body when
using a mobile phone. The SAR value is determined
at the highest certified power level in laboratory
conditions, but because the phone is designed to
use the minimum power necessary to access the
chosen network, the actual SAR level can be well
below this value. There is no proof of difference
in safety based on difference in SAR value.
Products with radio transmitters sold in the US
must be certified by the Federal Communications
Commission (FCC). When required, tests are
performed when the phone is placed at the ear and
when worn on the body. For body-worn operation,
the phone has been tested when positioned
a minimum of 15 mm from the body without any
metal parts in the vicinity of the phone or when
properly used with an appropriate Sony Ericsson
accessory and worn on the body.
For more information about SAR and radio frequency
exposure go to: www.sonyericsson.com/health.
Malware
Malware (short for malicious software) is software
that can harm your mobile phone or other computers.
Malware or harmful applications can include viruses,
worms, spyware, and other unwanted programs.
While your device does employ security measures
to resist such efforts, Sony Ericsson does not warrant
or represent that your device will be impervious to
introduction of malware. You can however reduce
the risk of malware attacks by using care when
downloading content or accepting applications,
refraining from opening or responding to messages
from unknown sources, using trustworthy services
to access the Internet, and only downloading content
to your mobile phone from known, reliable sources.
74 Important information
Accessories
Use only Sony Ericsson branded original accessories
and certified service partners. Sony Ericsson does
not test third-party accessories. Accessories may
influence RF Exposure, radio performance, sound
loudness, electric safety and other areas. Third-
party accessories and parts may pose a risk to your
health or safety or decrease performance.
Accessible Solutions/Special Needs
In the US, compatible Sony Ericsson phones may
offer compatibility with TTY terminals (with use of
necessary accessory). For more information call the
Sony Ericsson Special Needs Center on 877 878
1996 (TTY) or 877 207 2056 (voice), or go to
www.sonyericsson-snc.com.
Disposal of old electrical
and electronic equipment
Electronic equipment and batteries
should not be included as household
waste but should be left at an
appropriate collection point for recycling. This
helps prevent potential negative consequences
for the environment and human health. Check local
regulations by contacting your local city office, your
household waste disposal service, the shop where
you purchased the product or calling a Sony Ericsson
Call Center.
Disposing of the battery
Check local regulations or call
a Sony Ericsson Call Center for
information. Never use municipal
waste.
Memory card
If your product comes complete with a removable
memory card, it is generally compatible with the
mobile phone purchased but may not be compatible
with other devices or the capabilities of their memory
cards. Check other devices for compatibility before
purchase or use. If your product is equipped with
a memory card reader, check memory card
compatibility before purchase or use.
Memory cards are generally formatted prior to
shipping. To reformat the memory card, use
a compatible device. Do not use the standard
operating system format when formatting the memory
card on a PC. For details, refer to the operating
instructions of the device or contact customer
support.
WARNING:
If your device requires an adapter for insertion into
the mobile phone or another device, do not insert
the card directly without the required adapter.
Precautions on Memory Card Use
•Do not expose the memory card to moisture.
•Do not touch terminal connections with your hand
or any metal object.
•Do not strike, bend, or drop the memory card.
•Do not attempt to disassemble or modify the
memory card.
•Do not use or store the memory card in humid or
corrosive locations or in excessive heat such as
a closed car in summer, in direct sunlight or near
a heater, etc.
•Do not press or bend the end of the memory card
adapter with excessive force.
•Do not let dust or foreign objects get into the insert
port of any memory card adapter.
75Important information
•Check you have inserted the memory card correctly.
•Insert the memory card as far as it will go into any
memory card adapter needed. The memory card
may not operate properly unless fully inserted.
•We recommend that you make a backup copy of
important data. We are not responsible for any loss
or damage to content you store on the memory card.
•Recorded data may be damaged or lost when you
remove the memory card or memory card adapter,
or turn off the power while formatting, reading or
writing data, or when you use the memory card in
locations subject to static electricity or high electrical
field emissions.
Protection of personal information
Erase personal data before disposing of the product.
To delete data, perform a master reset. Deleting
data from the phone memory does not ensure that
it cannot be recovered. Sony Ericsson does not
warrant against recovery of information and does
not assume responsibility for disclosure of any
information even after a master reset.
LOUDNESS WARNING:
Avoid volume levels that may be harmful to your
hearing.
End User Licence Agreement
Software delivered with this device and its media is
owned by Sony Ericsson Mobile Communications
AB, and/or its affiliated companies and its suppliers
and licensors.
Sony Ericsson grants you a non-exclusive limited
license to use the Software solely in conjunction
with the Device on which it is installed or delivered.
Ownership of the Software is not sold, transferred
or otherwise conveyed.
Do not use any means to discover the source code
or any component of the Software, reproduce and
distribute the Software, or modify the Software.
You are entitled to transfer rights and obligations
to the Software to a third party, solely together with
the Device with which you received the Software,
provided the third party agrees in writing to be bound
by the terms of this License.
This license exists throughout the useful life of this
Device. It can be terminated by transferring your
rights to the Device to a third party in writing.
Failure to comply with any of these terms and
conditions will terminate the license immediately.
Sony Ericsson and its third party suppliers and
licensors retain all rights, title and interest in and to
the Software. Sony Ericsson, and, to the extent that
the Software contains material or code of a third
party, such third party, shall be entitled third party
beneficiaries of these terms.
This license is governed by the laws of Sweden.
When applicable, the foregoing applies to statutory
consumer rights.
In the event Software accompanying or provided
in conjunction with your device is provided with
additional terms and conditions, such provisions
shall also govern your possession and usage of the
Software.
Limited Warranty
Sony Ericsson Mobile Communications AB, SE-221
88 Lund, Sweden, (Sony Ericsson) or its local affiliated
company, provides this Limited Warranty for your
mobile phone, original accessory delivered with
your mobile phone, and/or your mobile computing
product (hereinafter referred to as “Product”).
Should your Product need warranty service, please
return it to the dealer from whom it was purchased,
or contact your local Sony Ericsson Call Center
(national rates may apply) or visit
www.sonyericsson.com to get further information.
76 Important information
Our warranty
Subject to the conditions of this Limited Warranty,
Sony Ericsson warrants this Product to be free from
defects in design, material and workmanship at the
time of its original purchase by a consumer. This
Limited Warranty will last for a period of one (1) year
as from the original date of purchase of the Product.
What we will do
If, during the warranty period, this Product fails
to operate under normal use and service, due
to defects in design, materials or workmanship,
Sony Ericsson authorized distributors or service
partners, in the country* where you purchased the
Product, will, at their option, either repair or replace
the Product in accordance with the terms and
conditions stipulated herein.
Sony Ericsson and its service partners reserve the
right to charge a handling fee if a returned Product
is found not to be under warranty according to the
conditions below.
Please note that some of your personal settings,
downloads and other information may be lost when
your Sony Ericsson Product is repaired or replaced.
At present Sony Ericsson may be prevented by
applicable law, other regulation or technical
restrictions from making a backup copy of certain
downloads. Sony Ericsson does not take any
responsibility for any lost information of any kind
and will not reimburse you for any such loss. You
should always make backup copies of all the
information stored on your Sony Ericsson Product
such as downloads, calendar and contacts before
handing in your Sony Ericsson Product for repair
or replacement.
Conditions
1This Limited Warranty is valid only if the original
proof of purchase for this Product issued by a
Sony Ericsson authorized dealer specifying the
date of purchase and serial number**, is presented
with the Product to be repaired or replaced.
Sony Ericsson reserves the right to refuse warranty
service if this information has been removed or
changed after the original purchase of the Product
from the dealer.
2If Sony Ericsson repairs or replaces the Product, the
repair for the defect concerned, or the replaced
Product shall be warranted for the remaining time
of the original warranty period or for ninety (90) days
from the date of repair, whichever is longer. Repair
or replacement may involve the use of functionally
equivalent reconditioned units. Replaced parts
or components will become the property of
Sony Ericsson.
3This warranty does not cover any failure of the
Product due to normal tear and wear, or due to
misuse, including but not limited to use in other than
the normal and customary manner, in accordance
with the Sony Ericsson instructions for use and
maintenance of the Product. Nor does this warranty
cover any failure of the Product due to accident,
software or hardware modification or adjustment,
acts of God or damage resulting from liquid.
A rechargeable battery can be charged and
discharged more than a hundred times. However,
it will eventually wear out – this is not a defect and
corresponds to normal wear and tear. When the
talk-time or standby time is noticeably shorter,
it is time to replace your battery. Sony Ericsson
recommends that you use only batteries and chargers
approved by Sony Ericsson.
77Important information
Minor variations in display brightness and colour
may occur between the phones. There may be tiny
bright or dark dots on the display. These are called
defective pixels and occur when individual dots
have malfunctioned and can not be adjusted.
Two defective pixels are deemed acceptable.
Minor variations in camera image appearance may
occur between phones. This is nothing uncommon
and is not regarded as a defective camera module.
4Since the cellular system on which the Product is to
operate is provided by a carrier independent from
Sony Ericsson, Sony Ericsson will not be responsible
for the operation, availability, coverage, services or
range of that system.
5This warranty does not cover Product failures caused
by installations, modifications, or repair or opening
of the Product performed by a non-Sony Ericsson
authorised person.
6The warranty does not cover Product failures which
have been caused by use of accessories or other
peripheral devices which are not Sony Ericsson
branded original accessories intended for use with
the Product.
7Tampering with any of the seals on the Product will
void the warranty.
8THERE ARE NO EXPRESS WARRANTIES,
WHETHER WRITTEN OR ORAL, OTHER THAN
THIS PRINTED LIMITED WARRANTY. ALL
IMPLIED WARRANTIES, INCLUDING WITHOUT
LIMITATION THE IMPLIED WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE, ARE LIMITED TO
THE DURATION OF THIS LIMITED WARRANTY.
IN NO EVENT SHALL SONY ERICSSON OR ITS
LICENSORS BE LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES OF ANY NATURE
WHATSOEVER, INCLUDING BUT NOT LIMITED
TO LOST PROFITS OR COMMERCIAL LOSS;
TO THE FULL EXTENT THOSE DAMAGES CAN
BE DISCLAIMED BY LAW.
Some countries/states do not allow the exclusion
or limitation of incidental or consequential damages,
or limitation of the duration of implied warranties,
so the preceding limitations or exclusions may not
apply to you.
The warranty provided does not affect the
consumer’s statutory rights under applicable
legislation in force, nor the consumer’s rights
against the dealer arising from their sales /
purchase contract.
*Geographical scope of the warranty
If you have purchased your Product in a country
member of the European Economic Area (EEA) or
in Switzerland or the Republic of Turkey, and such
Product was intended for sale in the EEA or in
Switzerland or in Turkey, you can have your Product
serviced in any EEA country or in Switzerland or in
Turkey, under the warranty conditions prevailing in
the country in which you require servicing, provided
that an identical Product is sold in such country by
an authorised Sony Ericsson distributor. To find out
if your Product is sold in the country you are in,
please call the local Sony Ericsson Call Center.
Please observe that certain services may not be
possible elsewhere than in the country of original
purchase, for example due to the fact that your
Product may have an interior or exterior which
is different from equivalent models sold in other
countries. Please note in addition that it may
sometimes not be possible to repair SIM-locked
Products.
** In some countries/regions additional information
(such as a valid warranty card) may be requested.
78 Important information
FCC Statement
This device complies with Part 15 of
the FCC rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful
interference, and
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
Any change or modification not expressly approved
by Sony Ericsson may void the user’s authority to
operate the equipment.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and on, the
user is encouraged to try to correct the interference
by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment
and receiver.
-- Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV
technician for help.
Industry Canada Statement
This device complies with RSS-210 of Industry
Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including
interference that may cause undesired operation of
the device.
This Class B digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la classe B est conforme
à la norme NMB-003 du Canada.
79Important information
Declaration of Conformity for
C702 Cyber-shot™
We, Sony Ericsson Mobile Communications AB of
Nya Vattentornet
SE-221 88 Lund, Sweden
declare under our sole responsibility that our
product
Sony Ericsson type AAD-3052081-BV
and in combination with our accessories, to which
this declaration relates is in conformity with the
appropriate standards EN 301 511:V9.0.2,
EN 301 908-1:V2.2.1, EN 301 908-2:V2.2.1,
EN 300 328:V1.7.1, EN 300 440-1:V1.7.1,
EN 300 440-2:V1.1.2, EN 301 489-3:V1.4.1,
EN 301 489-7:V1.3.1, EN 301 489-17:V1.2.1,
EN 301 489-24:V1.3.1, EN 60 950-1:2006
following the provisions of, Radio Equipment and
Telecommunication Terminal Equipment directive
1999/5/EC.
We fulfil the requirements of the R&TTE Directive
(1999/5/EC).
Lund, December 2007
Shoji Nemoto,
Head of Product Business Group GSM/UMTS
80 Index
Index
A
activity menu ........................................ 14
adding
notes ............................................ 62
alarms .................................................. 60
answering service ................................ 27
applications .......................................... 44
appointments ....................................... 61
assembly ................................................ 6
audio book ........................................... 41
B
battery
charging ......................................... 8
inserting ......................................... 6
use and care ................................ 72
blog
video ............................................ 20
Bluetooth
visibility ........................................ 53
Bluetooth wireless technology ............. 52
bookmarks
creating ........................................ 45
selecting ....................................... 45
C
calendar ..........................................61–62
call divert .............................................. 29
call list ...................................................27
call numbers in message ......................33
call time .................................................32
caller-specific ringtones ........................25
calls
accepting ......................................31
answering and rejecting ................23
emergency ....................................23
handling two calls .........................30
international ..................................22
making and receiving ....................22
putting on hold ..............................29
recording .......................................44
video .............................................24
camera
settings .........................................18
code memo ...........................................67
conference calls ....................................30
contacts
adding phone contacts .................24
default contacts ............................24
groups ...........................................27
synchronizing ................................55
D
date .......................................................63
declaration of conformity ......................79
downloading music ...............................41
81Index
E
email ..................................................... 35
emergency numbers ............................ 23
entering text ......................................... 15
F
face detection ...................................... 17
file manager .......................................... 59
flight mode ........................................... 59
G
games ................................................... 44
Google Maps ........................................ 49
GPS ...................................................... 48
groups .................................................. 27
H
handsfree ....................................... 28, 40
Bluetooth technology ................... 53
help ........................................................ 8
hiding number ...................................... 32
history
Web pages ................................... 46
I
IMEI number ......................................... 65
Internet
bookmarks ................................... 45
security and certificates ............... 46
settings ......................................... 52
J
Java ...................................................... 44
K
keypad lock .......................................... 65
automatic ..................................... 65
manual ......................................... 65
keys ........................................................ 9
L
language ............................................... 15
location services .................................. 48
lock
keypad ......................................... 65
phone ........................................... 65
M
master reset ......................................... 66
Media Manager .................................... 39
media transfer ................................ 39, 55
memory card ........................................ 14
memory status ..................................... 26
menu overview ..................................... 11
menus .................................................. 13
messages
area and cell information .............. 38
email ............................................. 35
picture .......................................... 33
text ............................................... 33
voice ............................................. 35
82 Index
microphone .......................................... 23
MMS See picture messages
music player ......................................... 40
MusicDJ™ ............................................ 43
My friends ............................................ 37
my numbers ......................................... 31
N
navigating menus ................................. 13
notes .................................................... 62
adding .......................................... 62
showing in standby ...................... 62
P
pan and zoom
Web pages ................................... 46
PC Suite
synchronizing ............................... 55
phone mode ......................................... 56
phone name ......................................... 52
photo feeds .......................................... 48
photo fix ............................................... 18
photo tags ............................................ 21
PhotoDJ™ ............................................ 21
photos
improving ..................................... 18
photo fix ....................................... 18
picture messages ................................. 33
pictures .................................................20
editing ...........................................21
improving ......................................18
photo fix ........................................18
PIN code
changing .......................................64
unblocking ......................................7
playlists .................................................40
PlayNow™ ............................................41
podcasts ...............................................48
profiles ..................................................63
PUK .................................................64, 69
push email .............................................36
R
ringtones ...............................................43
RSS feeds See Web feeds
RSS ticker .............................................47
S
safety guidelines ...................................71
search
on Web pages ...............................46
selection keys .......................................13
settings
Internet ..........................................52
Java ..............................................45
shortcuts ...............................................13
83Index
SIM card ............................................... 64
copying to/from ............................ 25
locking .......................................... 64
unblocking .................................... 64
SMS See text messages
SOS See emergency numbers
sound recorder ..................................... 44
speed dialling ....................................... 27
standby .................................................. 7
notes ............................................ 62
startup screen ........................................ 7
submenus ............................................. 13
synchronizing ....................................... 55
T
T9 Text Input ........................................ 15
tasks ............................................... 62–63
text messages ...................................... 33
theme ................................................... 63
time ...................................................... 63
time zone .............................................. 63
Tracker ................................................. 50
training ................................................. 50
transfer method
Bluetooth technology ................... 52
USB .............................................. 54
transferring
camera pictures ........................... 19
files ............................................... 54
music ............................................ 39
sound ........................................... 54
turning on/off
Bluetooth function ........................ 53
keypad lock .................................. 65
phone lock ................................... 65
SIM lock protection ...................... 64
U
update
Web feeds .................................... 47
Update service ..................................... 57
V
video
blog .............................................. 20
editing .......................................... 21
video player .......................................... 42
video recorder ...................................... 16
VideoDJ™ ............................................ 21
visibility ................................................. 53
voice answering ................................... 28
voice commands .................................. 28
84 Index
voice control ........................................ 28
voice messages ................................... 35
voicemail .............................................. 27
volume
ear speaker .................................. 23
ringtone ........................................ 43
W
warranty ............................................... 75
Web
search .......................................... 46
Web feeds ............................................ 47
showing in standby ...................... 47
update .......................................... 47
Web pages
history .......................................... 46
pan and zoom .............................. 46
Z
zoom .................................................... 18
