22 Walkman™
create a playlist by selecting an area
of tracks.
To create a playlist by mood
1From standby select Menu > Media >
Music.
2Scroll to SensMe™ and select Open.
3Press , , or to preview
different tracks.
4Select Add and press or to
choose an area of tracks.
5Select Create to play the playlist in the
Walkman™ player.
6Select Options > Save playlist and
enter a name and select OK.
Audio books
You can listen to audio books that you
have transferred to your phone from a
computer using Sony Ericsson Media
Manager.
To access audio books
•From standby select Menu > Media >
Music > Audio books.
PlayNow™
You can connect to PlayNow™ to
download ringtones, games, music,
themes and wallpapers. You can
preview or listen to content before you
purchase and download it to your
phone.
If you cannot use PlayNow™, see
Troubleshooting on page 69.
To use PlayNow™
1From standby select Menu >
PlayNow™.
2Scroll the PlayNow™ Web site and
follow the instructions to preview and
purchase content.
TrackID™
TrackID™ is a music recognition
service. You can search for title, artist
For information on how to analyze your
music, see Sony Ericsson Media
Manager Online Help.
It may take a few minutes before a
transferred audio book appears in the list
of available audio books.
You can find audio books in formats
other than M4B and those that do not
have ID3v2 chapter tags in the Tracks
folder.
This service is not available in all
countries.
23Walkman™
and album name for a track you hear
playing through a loudspeaker or on
the radio.
If you cannot use TrackID™, see
Troubleshooting on page 69.
To search for track information
•When you hear a track through a
loudspeaker, from standby select
Menu > Entertainment > TrackID™ >
Start.
•When the radio is playing select
Options > TrackID™.
Online music and video clips
You can view video clips and listen to
music by streaming them to your
phone from the Internet. If you cannot
use the Internet, see Troubleshooting
on page 69.
To select a data account for
streaming
1From standby select Menu > Settings
> the Connectivity tab > Streaming
settings > Connect using:.
2Select the data account to use.
3Select Save.
To stream music and video clips
1From standby select Menu > Internet.
2Select Options > Go to > Bookmarks.
3Select a link to stream from.
Video player
To play videos
1From standby select Menu > Media >
Video > Videos.
2Scroll to a title and press .
To stop playing videos
•Press .
To fast forward and rewind
•Press and hold down or
.
To move between videos
•Press or .
For cost information contact your service
provider.
For best results, use TrackID™ in a quiet
area.
24 Walkman™
Radio
You can use the music keys to control
the radio.
To listen to the radio
1Connect the handsfree to the phone.
2From standby select Menu > Radio.
To search for channels automatically
•Select Search.
To search for channels manually
•Press or .
To change the volume
•Press the volume keys up or down.
To minimize the radio
•When the radio is playing, select
Options > Minimize.
To return to the radio
•From standby select Menu > Radio.
To turn off the radio
•Press .
To resume playing in minimized
mode
•Press .
Saving channels
You can save up to 20 preset
channels.
To save channels
1From standby select Menu > Radio.
2When you have found a radio channel
select Options > Save.
3Scroll to a position and select Insert.
To select saved channels
1Select Options > Channels.
2Select a radio channel.
To switch between saved channels
•Press and hold down or
.
Do not use your phone as a radio in
places where this is prohibited.
The handsfree must be attached to the
phone for the radio to start. turns
on the last used music application, the
radio or the Walkman™ player.
25Walkman™
MusicDJ™
You can compose and edit your own
melodies to use as ringtones. Pre-
arranged sounds with different
characteristics are available.
To compose a melody
1From standby select Menu >
Entertainment > MusicDJ™.
2Select to Insert, Copy or Paste sounds.
3Use , , or to scroll between
the sounds.
4Select Options > Save melody.
Record sound
You can record a voice memo or a
call. Recorded sounds can also be set
as ringtones.
To record a sound
•From standby select Menu >
Entertainment > Record sound >
Record.
To record a call
1During an ongoing call, select Options
> Record.
2Select Save to save the recording.
To listen to a recording
1From standby select Menu > Organizer
> File manager.
2Scroll to Music and select Open.
3Scroll to a recording and select Play.
In some countries or states it is required
by law that you inform the other person
before recording the call.
26 Transferring and handling content
Transferring and
handling content
You can transfer and handle content
such as pictures and music.
Handling content within the
phone
You can use File manager to handle
content saved in the phone memory or
on a memory card. Tabs and icons in
File manager show where the content
is saved. If the memory is full, delete
some content to create space.
To view memory status
1From standby select Menu > Organizer
> File manager.
2Select Options > Memory status.
3Select Memory card or Phone.
To select more than one item in a
folder
1From standby select Menu > Organizer
> File manager.
2Scroll to a folder and select Open.
3Select Options > Mark > Mark several.
4For each item you want to mark, scroll
to the item and select Mark.
To move items between the phone
memory and the memory card
1From standby select Menu > Organizer
> File manager.
2Find an item and select Options >
Manage file > Move.
3Select Memory card or Phone.
4Scroll to a folder and select Open.
5Select Paste.
To view information about content
1From standby select Menu > Organizer
> File manager.
2Find an item and select Options >
Information.
Sending content to another
phone
You can send content, for example, in
messages or using Bluetooth™
wireless technology.
To send content
1Scroll to an item and select Options >
Send.
2Select a transfer method.
You are not allowed to exchange some
copyright-protected material.
identifies a protected file.
Make sure the receiving device supports
the transfer method you select.
27Transferring and handling content
Transferring content to and
from a computer
You can use Sony Ericsson Media
Manager to transfer content between
your phone and a computer.
When you move or copy content from
a computer to your phone
unrecognized content is saved in the
Other folder in the file manager.
Required operating systems
You need one of these operating
systems to use the software included
on the CD:
•Microsoft® Windows Vista™ 32 bit
and 64 bit versions of: Ultimate,
Enterprise, Business, Home
Premium or Home Basic
•Microsoft® Windows XP (Pro or
Home), Service Pack 2 or higher
To install Sony Ericsson Media
Manager
1Turn on your computer and insert the
CD. The CD starts automatically and
the installation window opens.
2Select a language and click OK.
3Click Install Sony Ericsson Media
Manager and follow the instructions.
To transfer content using
Sony Ericsson Media Manager
1Connect the phone to a computer with
a USB cable supported by your
phone.
2Computer: Start/Programs/
Sony Ericsson/Media Manager.
3Phone: Select Media transfer.
4Computer: Wait until the phone
appears in Sony Ericsson Media
Manager.
5Move files between your phone and
the computer in Sony Ericsson Media
Manager.
6For safe disconnection of the USB
cable, right-click the removable disk
icon in Windows Explorer and select
Eject.
Sony Ericsson Media Manager
software is included on the CD that
comes with your phone and available for
download at
www.sonyericsson.com/support.
Do not remove the USB cable from your
phone or computer during transfer, as
this may corrupt the phone memory.
For details on transferring music, refer to
Media Manager Help. Click in the top
right corner of the Sony Ericsson Media
Manager window. You can also go to
www.sonyericsson.com/support to read
Getting started guides.
28 Transferring and handling content
Using the USB cable
You can connect your phone to a
computer with the USB cable to
synchronize, transfer and back up
phone content and use your phone as
a modem. For more information, go to
www.sonyericsson.com/support to
read Getting started guides.
Before you use the USB cable
•See Required operating systems on
page 27.
To disconnect the USB cable safely
1Right-click the removable disk icon in
Windows Explorer.
2Select Eject.
3Disconnect the USB cable when there
is a message saying it is safe to do so
in the phone.
Drag and drop content
You can drag and drop content
between your phone memory and a
computer in Microsoft Windows
Explorer.
To drag and drop content
1Connect your phone to a computer
using the USB cable.
2Phone: Select Media transfer. Wait
until an external device icon appears
in My Computer and then double click
to open. Phone memory and memory
card appear as external disks in
Windows Explorer.
3Computer: Wait until the phone
memory appear as external disks in
Windows Explorer.
4Drag and drop selected files between
the phone and the computer.
Only use a USB cable supported by your
phone. Do not remove the USB cable
from your phone or computer during
transfer as this may corrupt the phone
memory.
Do not copy the files immediately if you
formatted the phone drive on the PC. In
that case, remove the USB cable and
restart the phone first.
29Transferring and handling content
Phone name
You can enter a name for your phone
that is shown to other devices when
using, for example, Bluetooth™
wireless technology.
To enter a phone name
1From standby select Menu > Settings
> the Connectivity tab > Phone name.
2Enter the phone name and select OK.
Using Bluetooth™ wireless
technology
The Bluetooth function makes wireless
connection to other Bluetooth devices
possible. You can, for example:
•Connect to handsfree devices.
•Connect to several devices at the
same time.
•Connect to computers and access
the Internet.
•Exchange items.
•Play multiplayer games.
Before you use Bluetooth wireless
technology
You must turn on the Bluetooth
function to communicate with other
devices. You may also have to pair
your phone with other Bluetooth
devices.
To turn the Bluetooth function on
•From standby select Menu > Settings
> the Connectivity tab > Bluetooth >
Turn on.
To pair the phone with a device
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth > My
devices.
2Scroll to New device and select Add to
search for available devices.
3Select a device.
4Enter a passcode, if required.
To allow connection to the phone
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth > My
devices.
2Select a device from the list.
3Select Options > Allow connection.
A range within 10 metres (33 feet), with
no solid objects in between, is
recommended for Bluetooth
communication.
Make sure that the device you want to
pair your phone with has the Bluetooth
function activated and Bluetooth visibility
set to on.
30 Transferring and handling content
4Select Always ask or Always allow.
To pair the phone with a Bluetooth
handsfree for the first time
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth >
Handsfree.
2Select a device.
3Enter a passcode, if required.
Power saving
You can save battery power with the
Power save function. In Power save
mode you can only connect with a
single Bluetooth device. If you want to
connect with more than one Bluetooth
device at the same time you must turn
this function off.
To turn powersave on
•From standby select Menu > Settings
> the Connectivity tab > Bluetooth >
Powersave > On.
Transferring sound to and from a
Bluetooth handsfree
You can transfer the sound to and
from a Bluetooth handsfree using a
phone key or the handsfree key.
To transfer sound
1From standby select Menu > Settings
> the Connectivity tab > Bluetooth >
Handsfree > Incoming call.
2Select an option. In phone transfers
sound to the phone. In handsfree
transfers sound to the handsfree.
To transfer sound during a call
1During a call, select Sound.
2Select from the list.
Backing up and restoring
You can backup phone content to a
computer using the Sony Ericsson PC
Suite and the Sony Ericsson Media
Manager. With Sony Ericsson PC Suite
you can backup and restore contacts,
calendar, tasks, notes and
bookmarks. With Sony Ericsson Media
Manager you can backup and restore
content such as music, pictures and
video clips.
Before backing up and restoring, you
need to install the Sony Ericsson PC
Suite and the Sony Ericsson Media
Manager.
This is only possible with devices that
require access to a secure service.
Always make a backup before having the
phone upgraded, since upgrading can
clear the user content.
31Transferring and handling content
To make a backup using the Sony
Ericsson PC Suite
1Computer: Start the Sony Ericsson PC
Suite from Start/Programs/Sony
Ericsson/PC Suite.
2Follow the instructions in the Sony
Ericsson PC Suite for how to connect.
3Phone: Select Phone mode.
4Computer: Go to the backup and
restore section in the Sony Ericsson
PC Suite and make a backup.
To restore phone content using the
Sony Ericsson PC Suite
1Computer: Start the Sony Ericsson PC
Suite from Start/Programs/Sony
Ericsson/PC Suite.
2Follow the instructions in the Sony
Ericsson PC Suite for how to connect.
3Phone: Select Phone mode.
Computer: Go to the backup and
restore section in the Sony Ericsson
PC Suite and restore your phone.
To make a backup using the
Sony Ericsson Media Manager
1Connect your phone to the computer
using a USB cable.
2Phone: Select Media transfer mode.
3Computer: Start Sony Ericsson Media
Manager from Start/Programs/Sony
Ericsson/Media Manager.
4Go to the backup section in the
Sony Ericsson Media Manager.
5Select the files you want to backup
and make a back up.
To restore phone content using the
Sony Ericsson Media Manager
1Connect your phone to the computer.
2Phone: Select Media transfer mode.
3Computer: Start Sony Ericsson Media
Manager from Start/Programs/Sony
Ericsson/Media Manager.
4Go to the backup section in the
Sony Ericsson Media Manager.
The Sony Ericsson PC Suite will
overwrite all the phone content during
the restore process. You may damage
your phone if you interrupt the process.
You can also connect your phone to a
computer using Bluetooth.
The Sony Ericsson Media Manager will
compare your phone content with your
computer backup and then restore files
missing in your phone. You may damage
your phone if you interrupt the process.
32 Calling
5Select the files you want to restore
and restore them. Calling
Making and receiving calls
You need to turn on your phone and
be within range of a network.
To make a call
1From standby enter a phone number
(with international country code and
area code, if applicable).
2Press .
To end a call
•Press .
To make international calls
1From standby press and hold down
until a “+” sign appears.
2Enter the country code, area code
(without the first zero) and phone
number.
3Press .
For more information on backing up and
restoring in Sony Ericsson Media
Manager see the Sony Ericsson Media
Manager Getting started guide at
www.sonyericsson.com/support.
You can call numbers from your contacts
and call list. See Contacts on page 34,
and Call list on page 37. You can also
use your voice to make calls. See Voice
control on page 38.
33Calling
To re-dial a number
•When Retry? appears select Yes.
To answer a call
•Press .
To reject a call
•Press .
To change the ear speaker volume
during a call
•Press the volume key up or down.
To mute the microphone during a call
1Press and hold down .
2Press and hold down again to
resume.
To turn the loudspeaker on during a
call
•Select SpkrOn.
To view missed calls from standby
•Press to open the call list.
Networks
Your phone switches automatically
between GSM and 3G (UMTS)
networks depending on availability.
Some network operators allow you to
switch networks manually.
To switch networks manually
1From standby select Menu > Settings
> the Connectivity tab > Mobile
networks > GSM/3G networks.
2Select an option.
Emergency calls
Your phone supports international
emergency numbers, for example, 112
and 911. You can normally use these
numbers to make emergency calls in
any country, with or without the SIM
card inserted, if you are in range of a
network.
To make an emergency call
•From standby enter 112 (the
international emergency number) and
press .
Do not hold your phone to your ear when
waiting. When the call connects, your
phone gives a loud signal.
Do not hold your phone to your ear when
using the loudspeaker. This could
damage your hearing.
In some countries, other emergency
numbers may also be promoted. Your
network operator may therefore have
saved additional local emergency
numbers on the SIM card.
34 Calling
To view your local emergency
numbers
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Special numbers >
Emergency nos..
Video call
You can see a person on the screen
during calls. Both parties need a
subscription that supports the 3G
(UMTS) service, and you need to be
within range of a 3G (UMTS) network.
3G (UMTS) service is available when
appears.
To make a video call
1From standby enter a phone number
(with international country code and
area code if applicable).
2Select Options > Make video call.
To use the zoom with an outgoing
video call
•Press or .
To view video call options
During the call, select Options.
Contacts
You can save names, phone numbers
and personal information in Contacts.
Information can be saved in the phone
memory or on the SIM card.
Default contacts
You can choose which contact
information is shown as default. If
Phone contacts is selected as default,
your contacts show all the information
saved in Contacts. If you select SIM
contacts as default, your contacts
show names and numbers saved on
the SIM card.
To select default contacts
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Advanced > Default contacts.
3Select an option.
Phone contacts
Phone contacts can contain names,
phone numbers and personal
information. They are saved in the
phone memory.
To add a phone contact
1From standby select Menu > Contacts.
2Scroll to New contact and select Add.
3Enter the name and select OK.
4Scroll to New number: and select Add.
You can synchronize your contacts using
the Sony Ericsson PC Suite.
35Calling
5Enter the number and select OK.
6Select a number option.
7Scroll between the tabs and add
information to the fields.
8Select Save.
Calling contacts
To call a phone contact
1From standby select Menu > Contacts.
2Scroll to a contact and press .
To go directly to the contacts list
•From standby press and hold down
– .
To call with Smart search
1From standby press – to
enter a sequence of (at least two)
digits. All entries which match the
sequence of digits or corresponding
letters are shown in a list.
2Scroll to a contact or a phone number
and press .
To turn Smart search on or off
1From standby select Menu > Settings
> the Calls tab > Smart search.
2Select an option.
Editing contacts
To add information to a phone
contact
1From standby select Menu >
Contacts.
2Scroll to a contact and select Options
> Edit contact.
3Scroll between the tabs and select
Add or Edit.
4Select an option and an item to add or
edit.
5Select Save.
To copy names and numbers to
phone contacts
1From standby select Menu >
Contacts.
2Scroll to New contact and select
Options > Advanced > Copy from SIM.
3Select an option.
To copy names and numbers to the
SIM card
1From standby select Menu >
Contacts.
2Scroll to New contact and select
Options > Advanced > Copy to SIM.
If your subscription supports Calling Line
Identification (CLI) service, you can
assign personal ringtones and pictures
to contacts.
36 Calling
3Select an option.
To automatically save names and
phone numbers on the SIM card
1From standby select Menu >
Contacts.
2Scroll to New contact and select
Options > Advanced > Auto save on
SIM.
3Select an option.
SIM contacts
SIM contacts can contain names and
numbers only. They are saved on the
SIM card.
To add a SIM contact
1From standby select Menu >
Contacts.
2Scroll to New contact and select Add.
3Enter the name and select OK.
4Enter the number and select OK.
5Select a number option and add more
information, if available.
6Select Save.
To call a SIM contact
1From standby select Menu >
Contacts.
2Scroll to a contact and press .
Deleting contacts
To delete all contacts
1From standby select Menu >
Contacts.
2Scroll to New contact and select
Options > Advanced > Delete all
contacts.
3Select an option.
Contact memory status
The number of contacts you can save
in your phone or on the SIM card
depends on available memory.
To view contact memory status
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Advanced > Memory status.
Myself
You can enter information about
yourself and, for example, send your
business card.
To enter Myself information
1From standby select Menu > Contacts.
2Scroll to Myself and select Open.
3Scroll to an option and edit the
information.
4Select Save.
When you copy all contacts from your
phone to the SIM card, all existing SIM
card information is replaced.
37Calling
To add your own business card
1From standby select Menu > Contacts.
2Scroll to Myself and select Open.
3Scroll to My contact info and select
Add > Create new.
4Scroll between the tabs and add
information to the fields.
5Enter the information and select Save.
Groups
You can create a group of phone
numbers and email addresses from
Phone contacts to send messages to.
See Messaging on page 43. You can
also use groups (with phone numbers)
when you create accepted callers
lists. See Accept calls on page 41.
To create a group of numbers and
email addresses
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Groups.
3Scroll to New group and select Add.
4Enter a name for the group and select
Continue.
5Scroll to New and select Add.
6For each contact phone number or
email address you want to mark, scroll
to it and select Mark.
7Select Continue > Done.
Call list
You can view information about recent
calls.
To call a number from the call list
1From standby press and scroll to
a tab.
2Scroll to a name or a number and
press .
To add a call list number to contacts
1From standby press and scroll to
a tab.
2Scroll to the number and select Save.
3Select New contact to create a new
contact or select an existing contact
to add the number to.
Speed dial
Speed dialling lets you select nine
contacts you can dial quickly. The
contacts can be saved in positions 1-
9.
To add contacts to speed dial
numbers
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Speed dial.
3Scroll to a position number and select
Add.
4Select a contact.
38 Calling
To speed dial
•From standby enter the position
number and press .
Voicemail
If your subscription includes an
answering service, callers can leave a
voicemail message when you cannot
answer a call.
To enter your voicemail number
1From standby select Menu >
Messaging > Settings > Voicemail
number.
2Enter the number and select OK.
To call your voicemail service
•From standby press and hold down
.
Voice control
By creating voice commands you can:
•Voice dial – call someone by saying
their name
•Answer and reject calls when you
use a handsfree
To record a voice command using
voice dialling
1From standby select Menu > Settings
> the General tab > Voice control >
Voice dialling > Activate.
2Select Yes > New voice command and
select a contact. If the contact has
more than one number, select the
number to add the voice command to.
3Record a voice command such as
“John mobile.”
4Follow the instructions that appear.
Wait for the tone and say the
command to record. The voice
command is played back to you.
5If the recording sounds OK, select
Yes. If not, select No and repeat steps
3 and 4.
To voice dial
1From standby press and hold down a
volume key.
2Wait for the tone and say a recorded
name, for example “John mobile.” The
phone plays the name back to you
and connects the call.
Voice answering
When you use a handsfree, you can
answer or reject incoming calls with
your voice.
Voice commands are saved in the phone
memory only. They cannot be used in
another phone.
39Calling
To activate voice answering and
record voice answer commands
1From standby select Menu > Settings
> the General tab > Voice control >
Voice answer > Activate.
2Follow the instructions that appear
and select Continue. Wait for the tone
and say “Answer”, or say any other
word of your choosing.
3Select Yes to accept or No for a new
recording.
4Follow the instructions that appear
and select Continue. Wait for the tone
and say “Busy”, or say any other word
of your choosing.
5Select Yes to accept or No for a new
recording.
6Follow the instructions that appear
and select Continue.
7Select the environments in which you
want to activate voice answering.
To answer a call using voice
commands
•Say “Answer.”
To reject a call using voice
commands
•Say “Busy.”
Diverting calls
You can divert calls, for example, to
an answering service.
To divert calls
1From standby select Menu > Settings
> the Calls tab > Divert calls.
2Select a call type and a divert option.
3Select Activate.
4Enter the number to divert calls to and
select OK.
More than one call
You can handle more than one call at
a time. For example, you can put an
ongoing call on hold, while you make
or answer a second call. You can also
switch between the two calls. You
cannot answer a third call without
ending one of the first two calls. You
can also join two calls.
Call waiting
You will hear a beep if you receive a
second call while call waiting is active.
When Restrict calls is used, some divert
call options are not available. See
Restricted dialling on page 41.
40 Calling
To activate call waiting
•From standby select Menu > Settings
> the Calls tab > Manage calls > Call
waiting > Activate.
To make a second call
1During the call, select press . This
puts the ongoing call on hold.
2Select Options > Add call.
3Enter the number to call and press
.
To answer a second call
•During the call, press . This puts
the ongoing call on hold.
To reject a second call
•During the call, press and
continue with the ongoing call.
To end an ongoing call and answer a
second call
•During the call, select Replace active
call.
Handling two voice calls
You can have calls ongoing and on
hold at the same time.
To switch between two calls
•During the call, press .
To join two calls
•During the call, select Options > Join
calls.
To connect two calls
•During the call, select Options >
Transfer call. You are disconnected
from both calls.
To end an ongoing call and return to
the call on hold
•First press and then .
Conference calls
With a conference call, you can have a
joint conversation with up to five
people.
To add a new participant
1During the call, press . This puts
the joined calls on hold.
2Select Options > Add call.
3Enter the number to call and press
.
4Select Options > Join calls to add the
new participant.
5Repeat this task to add more
participants.
To release a participant
1Select Options > Release party.
2Select the participant to release.
41Calling
To have a private conversation
1During the call, select Options > Talk to
and select the participant to talk to.
2To resume the conference call, select
Options > Join calls.
My numbers
You can view, add and edit your own
phone numbers.
To check your phone numbers
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Special numbers > My
numbers.
3Select an option.
Accept calls
You can choose to receive calls from
certain phone numbers only.
To add numbers to the accepted
callers list
1From standby select Menu > Settings
> the Calls tab > Manage calls > Accept
calls > Only from list.
2Scroll to New and select Add.
3Select a contact or Groups.
To accept all calls
•From standby select Menu > Settings
> the Calls tab > Manage calls > Accept
calls > All callers.
Restricted dialling
You can restrict outgoing and
incoming calls. A password from your
service provider is required.
Restrict calls options
Standard options are:
• – all outgoing calls.
•Outgoing intl – all outgoing
international calls.
•Outgoing intl roam. – all outgoing
international calls except to your
home country.
•All incoming – all incoming calls.
•Inc. when roaming – all incoming
calls when you are abroad.
To restrict calls
1From standby select Menu > Settings
> the Calls tab > Manage calls >
Restrict calls.
2Select an option.
3Select Activate.
4Enter your password and select OK.
See Groups on page 37.
If you divert incoming calls, you cannot
use some restrict calls options.
42 Calling
Fixed dialling
Fixed dialling allows calls to be made
only to certain numbers saved on the
SIM card. The fixed numbers are
protected by your PIN2.
Partial numbers can be saved. For
example, saving 0123456 allows calls
to be made to all numbers starting
with 0123456.
To use fixed dialling
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Special numbers > Fixed
dialling > Activate.
3Enter your PIN2 and select OK.
4Select OK again to confirm.
To save a fixed number
1From standby select Menu > Contacts.
2Scroll to New contact and select
Options > Special numbers > Fixed
dialling > Fixed numbers > New
number.
3Enter the information and select Save.
Call time and cost
During a call, the phone shows how
long you have been talking. You can
also check on the duration of your last
call, your outgoing calls and the total
time of all your calls.
To check the call time
•From standby select Menu > Settings
> the Calls tab > Time & cost > Call
timers.
Showing or hiding your phone
number
You can decide to show or hide your
phone number when you make a call.
To hide your phone number
1From standby select Menu > Settings
> the Calls tab > Show/hide my no..
2Select Hide number.
When fixed dialling is used, you cannot
view or manage any phone numbers
saved on the SIM card, but you can still
call the international emergency number,
112.
43Messaging
Messaging
Receiving and saving messages
You are notified when you receive a
message. Messages are automatically
saved in the phone memory. When the
phone memory is full, you can delete
messages or save them on the SIM
card.
To save a message on a memory
card
• From standby select Menu >
Messaging > Settings > General > Save
to > Memory card.
To save a message on the SIM card
1From standby select Menu >
Messaging and select a folder.
2Scroll to a message and select
Options > Save message.
To view a message from the inbox
1From standby select Menu >
Messaging > Inbox.
2Scroll to the message and select View.
Text messages
Text messages can contain simple
pictures, sound effects, animations,
and melodies.
To write and send a text message
1From standby select Menu >
Messaging > Write new > Text
message.
2Write the message and select
Continue > Contacts look-up.
3Select a recipient and select Send.
To copy and paste text in a text
message
1When you write the message, select
Options > Copy & paste.
2Select Copy all or Mark & copy. Scroll
to and mark text in the message.
3Select Options > Copy & paste > Paste.
To add an item to a text message
1When you write the message, select
Options > Add item.
2Select an option and then an item.
To call a number in a text message
•When you view the message, scroll to
the phone number and press .
To turn long messages on
1From standby select Menu >
Messaging > Settings > Text message.
If you send a text message to a group,
you will be charged for each member.
See Groups on page 37.
44 Messaging
2Select Max. msg length > Max.
available.
Picture messages
Picture messages can contain text,
pictures, slides, sound recordings,
video clips, signatures and
attachments. You can send picture
messages to a mobile phone or an
email address.
To create and send a picture
message
1From standby select Menu >
Messaging > Write new > Picture msg.
2Enter text. To add items to the
message, press , scroll and
select an item.
3Select Continue > Contacts look-up.
4Select a recipient and select Send.
Receiving picture messages
You can select how to download your
picture messages. Standard options
when you download picture messages
are:
•Always – automatic download.
•Ask in roaming – ask to download
when not in home network.
•Not in roaming – do not download
when not in home network.
•Always ask – ask to download.
•Off – new messages appear in the
Inbox.
To set automatic download
1From standby select Menu >
Messaging > Settings > Picture
message > Auto download.
2Select an option.
Message options
You can set standard options for all
messages or choose specific settings
each time you send a message.
To set text message options
1From standby select Menu >
Messaging > Settings > Text message.
2Scroll to an option and select Edit.
To set picture message options
1From standby select Menu >
Messaging > Settings > Picture
message.
2Scroll to an option and select Edit.
You must have the correct settings to
send a picture message. If you cannot
use picture messages, see
Troubleshooting on page 69.
45Messaging
To set options for a specific message
1When the message is ready and a
recipient is selected, select Options >
Advanced.
2Scroll to an option and select Edit.
Templates
If you often use the same phrases and
pictures in a message, you can save
the message as a template.
To add a text message template
1From standby select Menu >
Messaging > Templates > New
template > Text.
2Insert text or select Options to add
items. Select OK.
3Enter a title and select OK.
To add a picture message template
1From standby select Menu >
Messaging > Templates > New
template > Picture msg.
2Enter text. To add items to the
message, press , scroll and
select an item.
3Select Save, enter a title and select
OK.
To save a message as a template
1From standby select Menu >
Messaging > Inbox.
2Scroll to the message and select View
> Options > Save as template.
Voice messages
You can send and receive a sound
recording as a voice message.
To record and send a voice message
1From standby select Menu >
Messaging > Write new > Voice
message.
2Record the message and select Stop
> Send > Contacts look-up.
3Select a recipient and select Send.
Email
You can use standard email functions
and your computer email address in
your phone.
Before you use email
You can use the setup wizard to check
if settings are available for your email
account or you can enter them
manually. You can also receive
The sender and recipient must have a
subscription supporting picture
messaging.
You can synchronize your email using
Microsoft® Exchange ActiveSync.
46 Messaging
settings at
www.sonyericsson.com/support.
To create an email account
1From standby select Menu >
Messaging > Email > Accounts.
2Scroll to New account and select Add.
To write and send an email message
1From standby select Menu >
Messaging > Email > Write new.
2Select Add > Enter email address.
Enter the email address and select
OK.
3To add more recipients, scroll to To:
and select Edit.
4Scroll to an option and select Add >
Enter email address. Enter the email
address and select OK. When you are
ready, select Done.
5Select Edit and enter a subject. Select
OK.
6Select Edit and enter the text. Select
OK.
7Select Add and choose a file to attach.
8Select Continue > Send.
To receive and read an email
message
1From standby select Menu >
Messaging > Email > Inbox > Options >
Check new email.
2Scroll to the message and select View.
To save an email message
1From standby select Menu >
Messaging > Email > Inbox.
2Scroll to the message and select View
> Options > Save message.
To reply to an email message
1From standby select Menu >
Messaging > Email > Inbox.
2Scroll to the message and select
Options > Reply.
3Write the reply and select OK.
4Select Continue > Send.
To view an attachment in an email
message
•When you view the message, select
Options > Attachments > Use > View.
To save an attachment in an email
message
•When you view the message, select
Options > Attachments > Use > Save.
If you enter settings manually, you can
contact your email provider for more
information. An email provider could be
the company that supplied your email
address.
47Messaging
Active email account
If you have several email accounts,
you can change which one is active.
To change the active email account
1From standby select Menu >
Messaging > Email > Accounts.
2Select an account.
Push email
You can receive notification in your
phone from your email server that you
have new email messages.
To turn on push email notification
•From standby select Menu >
Messaging > Email > Settings > Push
email.
My friends
You can connect and log in to the My
friends server to communicate online
with chat messages.
If you cannot use My friends, see
Troubleshooting on page 69.
Before you use My friends
If no settings exist in your phone, you
need to enter server settings. Your
service provider can provide standard
settings information such as:
•Username
•Password
•Server address
•Internet profile
To enter My friends server settings
1From standby select Menu >
Messaging > My friends > Configure.
2Scroll to a setting and select Add.
To log in to the My friends server
•From standby select Menu >
Messaging > My friends > Log in.
To log out of the My friends server
•Select Options > Log out.
To add a chat contact
1From standby select Menu >
Messaging > My friends > the Contacts
tab.
2Select Options > Add contact.
To send a chat message
1From standby select Menu >
Messaging > My friends > the Contacts
tab.
2Scroll to a contact and select Chat.
3Write the message and select Send.
Status
You can show your status, for
example, Happy or Busy, to your
contacts only. You can also show your
48 Messaging
status to all users on the My friends
server.
To show my status
1From standby select Menu >
Messaging > My friends > Options >
Settings > Show my status.
2Select an option.
To update your own status
1From standby select Menu >
Messaging > My friends > the My status
tab.
2Edit the information.
3Select Options > Save.
Chat group
A chat group can be started by your
service provider, by an individual My
friends user or by yourself. You can
save chat groups by saving a chat
invitation or by searching for a specific
chat group.
To create a chat group
1From standby select Menu >
Messaging > My friends > the Chat
groups tab.
2Select Options > Add chat group >
New chat group.
3Select who to invite from your
contacts list and select Continue.
4Enter a short invitation text and select
Continue > Send.
To add a chat group
1From standby select Menu >
Messaging > My friends > the Chat
groups tab > Options > Add chat
group.
2Select an option.
To save a conversation
1From standby select Menu >
Messaging > My friends > the
Conversations tab.
2Enter a conversation.
3Select Options > Advanced > Save
conversation.
Area and cell information
Area and cell information are
messages, for example, local traffic
reports, that are sent by your service
provider when you are within a certain
network area when you choose to
receive them.
Conversation history is saved between
log out and when you log in again to let
you return to chat messages from
previous conversations.
49Imaging
To turn area information on
1From standby select Menu >
Messaging > Settings > Area info.
2Scroll to Reception and select Edit >
On.
Imaging
You can take pictures and record
video clips to view, save or send. You
find saved pictures and video clips in
Media and in File manager.
Viewfinder and camera keys
Using the camera
To activate the camera
•From standby press .
1Zoom in or out
2Take pictures/Record video clips
1
2
50 Imaging
To take a picture
1Activate the camera and press the
navigation key up or down to scroll to
.
2Press to take a picture.
3The picture is automatically saved.
To record a video clip
1Activate the camera and press the
navigation key up or down to scroll to
.
2Press to start recording.
3To stop recording, press . The
video clip is automatically saved.
To use zoom
•Press the volume key left or right.
To adjust brightness
•Press the navigation key left or right.
To view pictures
1Activate the camera and select .
2Scroll to the item.
More camera features
You can improve an underexposed
picture with Photo fix.
Camera icons and settings
Icons on the screen inform what the
current setting is. More camera
settings are available in Options.
To change settings
•Activate the camera and select .
To view information about settings
•Scroll to a setting and select .
Camera shortcuts
Viewing and tagging pictures
You can view and tag your pictures in
Media.
To view pictures in a slide show
1From standby select Menu > Media >
Photo > Camera album.
2Select a month.
3Scroll to a picture and select View.
Do not record with a strong light source
in the background. Use a support or the
self-timer to avoid a blurred picture.
Key Shortcut
Camera: Shoot mode
Video: Video length
Night mode
Self-timer
Camera key guide
Zoom in
Zoom out
51Imaging
4Select Options > Slide show.
5Select a mood.
Viewing pictures on a map
When is shown on the screen, your
geographical position is saved with
the pictures you take. This is called
geo tagging, and it shows the
approximate location of where a
picture was taken.
To view pictures on a map
1From standby select Menu > Media >
Photo > Camera album.
2Select a month.
3Scroll to a picture and select View.
4Select Options > View on map.
To change the geo tagging setting
1Activate the camera and select .
2Scroll to Settings > Add position.
Photo tags
You can tag pictures to categorize
them in Photo tags. For example, you
can create a vacation tag and add it to
all your vacation photos.
To create a new photo tag
1From standby select Menu > Media >
Photo > Camera album.
2Select a month.
3Scroll to a picture and select View.
4Press and select Options > New
tag.
5Enter a name and select OK.
6Select an icon.
7To tag the picture, press the centre
selection key.
To tag pictures
1From standby select Menu > Media >
Photo > Camera album.
2Select a month.
3Scroll to a picture and select View.
4Press and scroll to a tag.
5Press the centre selection key.
6For each picture you want to tag,
scroll to the picture and press the
centre selection key.
Using pictures
You can add a picture to a contact,
use it during phone startup, as a
wallpaper in standby or as a screen
saver.
To use pictures
1From standby select Menu > Media >
Photo > Camera album.
2Select a month.
3Scroll to a picture and select View.
4Select Options > Use as.
5Select an option.
52 Imaging
To set a Java™ application as a
wallpaper
1From standby select Menu > Settings
> the Display tab.
2Select Wallpaper > Application.
3Select a Java application.
Working with pictures
You can view, enhance and organize
your pictures and video clips on your
computer by installing the Adobe™
Photoshop™ Album Starter Edition. It
is included on the CD that comes with
your phone and available for
download at
www.sonyericsson.com/support.
Use Sony Ericsson Media Manager to
transfer content to and from your
phone. See Transferring content to
and from a computer on page 27 for
more information.
PhotoDJ™ and VideoDJ™
You can edit pictures and video clips.
To edit and save a picture
1From standby select Menu > Media >
Photo > Camera album.
2Select a month.
3Scroll to a picture and select View.
4Select Options > Edit in PhotoDJ™.
5Edit the picture.
6Select Options > Save picture.
To edit and save a video clip
1From standby select Menu > Organizer
> File manager > Camera album.
2Scroll to a video clip and select
Options > Edit in VideoDJ™.
3Edit the video clip.
4Select Options > Save.
To trim a video clip
1From standby select Menu > Organizer
> File manager > Camera album.
2Scroll to a video clip and select
Options > Edit in VideoDJ™ > Edit >
Trim.
3Select OK > Set > Start to set the
starting point.
4Select Set > End to set the end point.
5Select Trim > Options > Save.
Blogging
A blog is a personal Web page that
you can send pictures and video clips
to share with others. If your
subscription supports this service, you
can send pictures or video clips to a
blog.
You can only see the Java™ applications
that have support for wallpaper.
53Imaging
If you cannot use picture or video
blog, see Troubleshooting on page 69.
To send camera pictures to a blog
1From standby select Menu > Media >
Photo > Camera album.
2Select a month.
3Scroll to a picture and select View.
4Select Options > Send > To blog.
5Enter a title and text and select OK.
6Select Publish.
To send video clips to a blog
1From standby select Menu > Media >
Video.
2Scroll to a video clip and select
Options > Send > To blog.
3Enter a title and text and select OK.
4Select Publish.
To go to a blog address from
contacts
1From standby select Menu > Contacts.
2Scroll to a contact and select a Web
address.
3Select Go to.
Printing photos
You can print camera pictures using
the USB cable connected to a
compatible printer.
To print camera pictures using the
USB cable
1Connect the USB cable to the phone.
2Connect the USB cable to the printer.
3Wait for feedback in the phone and
select OK.
4Enter printer settings (if required) and
select Print.
5From standby select Menu > Media >
Photo > Camera album.
6Select a month.
7Scroll to a picture and select Options >
Print.
Web services may require a separate
license agreement between you and the
service provider. Additional regulations
and charges may apply. Contact your
service provider.
You can also send a photo to a blog just
after you have taken it by selecting Send
> To blog.
You can also send a video clip to a blog
just after you have recorded it by
selecting Send > To blog.
You can also print using a Bluetooth
compatible printer that supports the
Object Push Profile.
You should disconnect and re-connect
the USB cable if there is a printer error.
54 Internet
Internet
If you cannot use the Internet, see
Troubleshooting on page 69.
To start browsing
1From standby select Menu > Internet.
2Select Options > Go to.
3Select an option.
To exit the browser
•When you browse the Internet, select
Options > Exit browser.
Bookmarks
You can create and edit bookmarks as
quick links to your favourite Web
pages.
To create a bookmark
1When you browse the Internet, select
Options > Tools > Add bookmark.
2Enter a title and an address. Select
Save.
To select a bookmark
1From standby select Menu > Internet.
2Select Options > Go to > Bookmarks.
3Scroll to a bookmark and select Go to.
History pages
You can view Web pages you have
browsed.
To view history pages
•From standby select Menu > Internet >
Options > Go to > History.
More browser features
To use pan and zoom on a Web page
1When you browse the Internet, press
.
2Use the navigation key to move the
frame.
3Press Zoom.
4To switch back to pan, press .
To make a call when you browse
•Press .
To save a picture from a Web page
1When you browse the Internet, select
Options > Tools > Save picture.
2Select a picture.
To find text on a Web page
1When you browse the Internet, select
Options > Tools > Find on page.
2Enter text and press Find.
To send a link
1When you browse the Internet, select
Options > Tools > Send link.
To use pan and zoom, you need to turn
off Smart-fit: Options > Save > Smart-Fit
> Off.
55Internet
2Select a transfer method.
Internet keypad shortcuts
You can use the keypad to go directly
to an Internet browser function.
To select Internet keypad shortcuts
1From standby select Menu > Internet.
2Select Options > Advanced > Keypad
mode > Shortcuts.
Internet security and
certificates
Your phone supports secure
browsing. Certain Internet services,
such as banking, require certificates in
your phone. Your phone may already
contain certificates when you buy it or
you can download new certificates.
To view certificates in the phone
•From standby select Menu > Settings
> the General tab > Security >
Certificates.
Web feeds
You can subscribe to and download
frequently updated content, such as
news, podcasts or photos, using Web
feeds.
To add new feeds for a Web page
1When you browse a page on the
Internet that has Web feeds, indicated
by , select Options > Web feeds.
2For each feed you want to add, scroll
to the feed and select Mark.
3Select Options > Continue.
To download content via feeds
1From standby select Menu > Media >
Web feeds.
2Scroll to an updated feed and select
View or .
3Select a heading to expand.
Make sure the receiving device supports
the transfer method you select.
Key Shortcut
Bookmarks
- Enter text to Enter
address, Search Internet
or search in Bookmarks
Fullscreen or Landscape
or Normal screen
Zoom
Pan & zoom (when
Smart-Fit is off)
56 Internet
4Select an icon depending on content,
to open a Web page, to
download an audio podcast, to
download a video podcast or to
download a photo.
Updating Web feeds
You can manually update your feeds,
or schedule updates. When there are
updates, appears on the screen.
To schedule Web feed updates
1From standby select Menu > Media >
Web feeds.
2Scroll to a feed and select Options >
Schedule update.
3Select an option.
To update Web feeds manually
1From standby select Menu > Media >
Web feeds.
2Scroll to a feed and select Options >
Update.
3Select an option.
Web feeds in standby
You can show news updates on the
standby screen.
To show Web feeds in standby
1From standby select Menu > Media >
Web feeds.
2Scroll to a feed and select Options >
Settings > Standby ticker > Show in
standby.
To access Web feeds from standby
1From standby select Ticker.
2To read more about a feed, press
or to scroll to a headline and select
Go to.
Podcasts
Podcasts are files, for example, radio
programs or video content, you can
download and play. You subscribe to
and download podcasts using Web
feeds.
To access audio podcasts
•From standby select Menu > Media >
Music > Podcasts.
To access video podcasts
•From standby select Menu > Media >
Video > Podcasts.
You can also subscribe to and download
content to a computer via feeds using
Sony Ericsson Media Manager. You can
then transfer the content to your phone.
See Transferring content to and from a
computer on page 27.
Frequent updates may be costly.
57Synchronizing
Photo feeds
You can subscribe to Photo feeds and
download photos. To start using
Photo feeds, see Web feeds on page
55.
To access photo feeds
•From standby select Menu > Media >
Photo > Photo feeds.
Synchronizing
You can synchronize in two different
ways. You can synchronize your
phone using a computer program or
you can synchronize using an Internet
service.
For more information on
synchronizing, go to
www.sonyericsson.com/support to
read Getting started guides.
Synchronizing using a
computer
You can use the USB cable or
Bluetooth wireless technology to
synchronize phone contacts,
appointments, bookmarks, tasks and
notes with a computer program such
as Microsoft Outlook.
Before synchronizing, you need to
install the Sony Ericsson PC Suite.
Use only one of the synchronization
methods at a time with your phone.
Sony Ericsson PC Suite software is
included on the CD with your phone and
available for download at
www.sonyericsson.com/support.
58 Synchronizing
See Required operating systems on
27.
To install the Sony Ericsson PC Suite
1Turn on your computer and insert the
CD. The CD starts automatically and
the installation window opens.
2Select a language and click OK.
3Click Install Sony Ericsson PC suite
and follow the instructions on the
screen.
To synchronize using the Sony
Ericsson PC Suite
1Computer: Start PC Suite from Start/
Programs/Sony Ericsson/PC Suite.
2Follow the instructions in the Sony
Ericsson PC Suite for how to connect.
3Phone: Select Phone mode.
4Computer: When you are notified that
the Sony Ericsson PC Suite has found
your phone, you can start
synchronizing.
Synchronizing using an
Internet service
You can synchronize with an Internet
service using SyncML™ or a
Microsoft® Exchange Server using
Microsoft Exchange ActiveSync. If you
cannot synchronize with an Internet
service, see Troubleshooting on page
69.
SyncML
You can synchronize remote content
and personal information using
SyncML.
Before you synchronize using
SyncML
You must enter settings for SyncML
synchronization and register a
synchronization account online with a
service provider. You will need:
•Server address – server URL
•Database name – database to
synchronize with
To enter settings for SyncML
1From standby select Menu > Organizer
> Synchronization.
2Scroll to New account and select Add
> SyncML.
3Enter a name for the new account and
select Cont..
4Select Server address. Enter the
required information and select OK.
5Enter Username and Password, if
required.
For usage details, see the Sony Ericsson
PC Suite Help section once the software
has been installed on your computer.
59Synchronizing
6Scroll to the Applications tab and mark
applications to synchronize.
7Scroll to the App. settings tab and
select an application.
8Select Database name and enter the
required information.
9Scroll to the Advanced tab to enter
additional settings for synchronizing
and select Save.
To synchronize using SyncML
1From standby select Menu > Organizer
> Synchronization.
2Scroll to an account and select Start.
Microsoft® Exchange ActiveSync
You can access and synchronize
information such as email, contacts
and calendar entries using Microsoft®
Exchange Server with Microsoft®
Exchange ActiveSync.
Before you synchronize using
Microsoft® Exchange ActiveSync
You must enter settings for Microsoft
Exchange ActiveSync to access a
Microsoft Exchange Server. You will
need:
•Server address – server URL
•Domain – server domain
•Username – account username
•Password – account password
To enter settings for Microsoft®
Exchange ActiveSync
1From standby select Menu > Organizer
> Synchronization.
2Scroll to New account and select Add
> Exchange ActiveSync.
3Enter a name for the new account and
select Cont..
4Enter the required settings.
5Scroll between the tabs to enter
additional settings.
6Select Save.
To synchronize using Microsoft®
Exchange ActiveSync
1From standby select Menu > Organizer
> Synchronization.
2Scroll to an account and select Start.
For more information on synchronization
settings, contact your IT administrator.
Before you synchronize with Exchange
ActiveSync, you must enter the correct
time zone in your phone.
60 More features
More features
Flight mode
In Flight mode the network and radio
transceivers are turned off to prevent
disturbance to sensitive equipment.
When the flight mode menu is
activated you are asked to select a
mode the next time you turn on your
phone:
•Normal mode – full functionality
•Flight mode – limited functionality
To activate the flight mode menu
•From standby select Menu > Settings
> the General tab > Flight mode > Cont.
> Show at startup.
To select flight mode
1When the flight mode menu is
activated, turn off your phone.
2Turn on your phone and select Flight
mode.
Update service
You can update your phone with the
latest software using your phone or a
PC.
To view the current software in the
phone
1From standby select Menu > Settings
> the General tab > Update service.
2Select Software version.
Update service using the phone
You can update your phone over the
air using your phone. You do not lose
personal or phone information.
To select update settings
•From standby select Menu > Settings
> the General tab > Update service >
Settings > Internet settings.
To use Update service using the
phone
1From standby select Menu > Settings
> the General tab > Update service.
2Select Search for update and follow
the instructions that appear.
Update service using your phone
requires data access such as GPRS, 3G
or HSDPA.
61More features
Update service using a PC
You can update your phone using the
provided USB cable and an Internet
connected PC.
To use Update service using a PC
•Go to www.sonyericsson.com/
support.
Location services
You can get help to find your way and
save your favourite locations. With
information from mobile towers near
you, you may be able to view your
approximate location on a map.
To use Google Maps™ for mobile
•From standby select Menu >
Entertainment > Location services >
Google Maps.
To learn more about Google Maps
•When you use Google Maps, select
Options > Help.
To view your approximate location
•When you use Google Maps, press
.
To view a saved location
1From standby select Menu >
Entertainment > Location services > My
favourites.
2Scroll to a location and select Go to.
Alarms
You can set a sound or the radio as an
alarm signal. The alarm sounds even if
the phone is turned off. When the
alarm sounds you can silence it or turn
it off.
To set the alarm
1From standby select Menu > Organizer
> Alarms.
2Scroll to an alarm and select Edit.
3Scroll to Time: and select Edit.
4Enter a time and select OK > Save.
Make sure all personal data saved on
your phone’s memory is backed up. All
user data and settings will be overwritten
during the update using a PC. Data
saved on a memory stick will not be
affected.
You can get more exact information
about your location with a GPS
accessory supported by your phone.
Some features of Location services use
the Internet.
When you use Google Maps you can
press to access your favourites.
62 More features
To set the recurrent alarm
1From standby select Menu > Organizer
> Alarms.
2Scroll to an alarm and select Edit.
3Scroll to Recurrent: and select Edit.
4Scroll to a day and select Mark.
5To select another day, scroll to the day
and select Mark.
6Select Done > Save.
To set the alarm signal
1From standby select Menu > Organizer
> Alarms.
2Scroll to an alarm and select Edit.
3Scroll to the tab.
4Scroll to Alarm signal: and select Edit.
5Find and select an alarm signal. Select
Save.
To silence the alarm
•When the alarm sounds, press any
key.
•To repeat the alarm, select Snooze.
To turn off the alarm
•When the alarm sounds, press any key
and select TurnOff.
To cancel the alarm
1From standby select Menu > Organizer
> Alarms.
2Scroll to an alarm and select TurnOff.
The alarm in silent mode
You can set the alarm not to sound
when the phone is in silent mode.
To set an alarm to sound or not in
silent mode
1From standby select Menu > Organizer
> Alarms.
2Scroll to an alarm and select Edit.
3Scroll to the tab.
4Scroll to Silent mode: and select Edit.
5Select an option.
To set the snooze duration
1From standby select Menu > Organizer
> Alarms.
2Scroll to an alarm and select Edit.
3Scroll to Snooze duration: and select
Edit.
4Select an option.
Calendar
The calendar can be synchronized
with a computer calendar, with a
calendar on the Web or with a
Microsoft® Exchange Server
(Microsoft® Outlook®).
For more information see
Synchronizing on page 57.
63More features
Default view
You can choose whether month, week
or day view will appear first when you
open the calendar.
To set default view
1From standby select Menu > Organizer
> Calendar.
2Select Options > Advanced > Default
view.
3Select an option.
Appointments
You can add new appointments or
reuse existing appointments.
To add an appointment
1From standby select Menu > Organizer
> Calendar.
2Select a date.
3Scroll to New appointment and select
Add.
4Enter the information and confirm
each entry.
5Select Save.
To view an appointment
1From standby select Menu > Organizer
> Calendar.
2Select a date.
3Scroll to an appointment and select
View.
To edit an appointment
1From standby select Menu > Organizer
> Calendar.
2Select a date.
3Scroll to an appointment and select
View.
4Select Options > Edit.
5Edit the appointment and confirm
each entry.
6Select Save.
To view a calendar week
1From standby select Menu > Organizer
> Calendar.
2Select Options > Change view to >
Week.
To set when reminders should sound
1From standby select Menu > Organizer
> Calendar.
2Select a date.
3Select Options > Advanced >
Reminders.
4Select an option.
Notes
You can make notes and save them.
You can also show a note in standby.
A reminders option set in calendar
affects a reminders option set in tasks.
64 More features
To add a note
1From standby select Menu > Organizer
> Notes.
2Scroll to New note and select Add.
3Write a note and select Save.
To show a note in standby
1From standby select Menu > Organizer
> Notes.
2Scroll to a note and select Options >
Show in standby.
To hide a note from standby
1From standby select Menu > Organizer
> Notes.
2Scroll to the note shown in standby.
This will be marked with an icon.
Select Options > Hide in standby.
Tasks
You can add new tasks or reuse
existing tasks.
To add a task
1From standby select Menu > Organizer
> Tasks.
2Select New task and select Add.
3Select an option.
4Enter details and confirm each entry.
To view a task
1From standby select Menu > Organizer
> Tasks.
2Scroll to a task and select View.
To set when reminders should sound
1From standby select Menu > Organizer
> Tasks.
2Scroll to a task and select Options >
Reminders.
3Select an option.
Profiles
You can change settings such as the
ring volume and vibrating alert to suit
different locations. You can reset all
profiles to the phone's original
settings.
To select a profile
1From standby select Menu > Settings
> the General tab > Profiles.
2Select a profile.
To view and edit a profile
1From standby select Menu > Settings
> the General tab > Profiles.
A reminders option set in tasks affects a
reminders option set in calendar.
65More features
2Scroll to a profile and select Options >
View and edit.
Time and date
To set the time
1From standby select Menu > Settings
> the General tab > Time & date >
Time.
2Enter the time and select Save.
To set the date
1From standby select Menu > Settings
> the General tab > Time & date > Date.
2Enter the date and select Save.
To set the time zone
1From standby select Menu > Settings
> the General tab > Time & date > My
time zone.
2Select the time zone you are in.
Theme
You can change the appearance of the
screen through items such as colours
and wallpaper. You can also create
new themes and download them. For
more information, go to
www.sonyericsson.com/fun.
To set a theme
1From standby select Menu > Settings
> the Display tab > Theme.
2Scroll to a theme and select Set.
Main menu layout
You can change the layout of the
icons in the main menu.
To change the main menu layout
1From standby select Menu > Options >
Main menu layout.
2Select an option.
Ringtones
To set a ringtone
1From standby select Menu > Settings
> the Sounds & alerts tab > Ringtone.
2Find and select a ringtone.
To set the ringtone volume
1From standby select Menu > Settings
> the Sounds & alerts tab > Ring
volume.
2Press or to change the volume.
3Select Save.
You cannot rename the Normal profile.
If you select a city, My time zone also
updates the time when daylight saving
time changes.
66 More features
To turn off the ringtone
•From standby press and hold down
.
To set the vibrating alert
1From standby select Menu > Settings
> the Sounds & alerts tab > Vibrating
alert.
2Select an option.
Screen orientation
You can change between landscape
and portrait orientation, or select Auto
rotate to have the orientation change
when you rotate the phone.
To change screen orientation in
Media
1From standby select Menu > Media >
Settings > Orientation.
2Select an option.
Games
Your phone contains preloaded
games. You can also download
games. Help texts are available for
most games.
To start a game
1From standby select Menu > Media >
Games.
2Select a game.
To end a game
•Press .
Applications
You can download and run Java
applications. You can also view
information or set different
permissions.
Internet profiles for Java applications
Some Java applications need to
connect to the Internet to receive
information. Most Java applications
use the same Internet settings as your
Web browser. If you cannot use Java
applications, see Troubleshooting on
page 69.
To select a Java application
1From standby select Menu > Organizer
> Applications.
2Select an application.
To view information about a Java
application
1From standby select Menu > Organizer
> Applications.
All signals except the alarm signal are
affected.
67More features
2Scroll to an application and select
Options > Information.
To set permissions for a Java
application
1From standby select Menu > Organizer
> Applications.
2Scroll to an application and select
Options > Permissions.
3Set permissions.
Java application screen size
Some Java applications are designed
for a specific screen size. For more
information, contact the application
vendor.
To set the screen size for a Java
application
1From standby select Menu > Organizer
> Applications.
2Scroll to an application and select
Options > Screen size.
3Select an option.
Locks
SIM card lock
This lock only protects your
subscription. Your phone will work
with a new SIM card. If the lock is on,
you have to enter a PIN (Personal
Identity Number).
If you enter your PIN incorrectly three
times in a row, the SIM card is blocked
and you need to enter your PUK
(Personal Unblocking Key). Your PIN
and PUK are supplied by your network
operator.
To unblock the SIM card
1When PIN blocked appears, enter your
PUK and select OK.
2Enter a new four-to-eight-digit PIN
and select OK.
3Re-enter the new PIN and select OK.
To edit the PIN
1From standby select Menu > Settings
> the General tab > Security > Locks >
SIM protection > Change PIN.
2Enter your PIN and select OK.
3Enter a new four-to-eight-digit PIN
and select OK.
4Re-enter the new PIN and select OK.
To use the SIM card lock
1From standby select Menu > Settings >
the General tab > Security > Locks >
SIM protection > Protection.
If Codes do not match appears, you
entered the new PIN incorrectly.
If Wrong PIN appears, followed by Old
PIN:, you entered your old PIN
incorrectly.
68 More features
2Select an option.
3Enter your PIN and select OK.
Phone lock
You can stop unauthorized use of your
phone. Change the phone lock code
(0000) to any four-to-eight-digit
personal code.
To use the phone lock
1From standby select Menu > Settings >
the General tab > Security > Locks >
Phone protection > Protection.
2Select an option.
3Enter the phone lock code and select
OK.
To unlock the phone
•Enter your code and select OK.
To change the phone lock code
1From standby select Menu > Settings >
the General tab > Security > Locks >
Phone protection > Change code.
2Enter the old code and select OK.
3Enter the new code and select OK.
4Repeat the code and select OK.
Keypad lock
You can set this lock to avoid
accidental dialling. Incoming calls can
be answered without unlocking the
keypad.
To use the automatic keylock
1From standby select Menu > Settings >
the General tab > Security > Automatic
keylock.
2Select an option.
To lock the keypad manually
•From standby press and select
Lock.
To unlock the keypad manually
•From standby press and select
Unlock.
IMEI number
Keep a copy of your IMEI (International
Mobile Equipment Identity) number in
case your phone is stolen.
To view your IMEI number
•From standby press , , ,
, .
It is important that you remember your
new code. If you forget it, you have to
take your phone to your local
Sony Ericsson retailer.
Calls to the international emergency
number 112 can still be made.
69Troubleshooting
Troubleshooting
Some problems will require you to call
your network operator.
For more support go to
www.sonyericsson.com/support.
Common questions
I cannot synchronize with an Internet
service, use the Internet, PlayNow™,
TrackID™, My friends, Java, picture
messaging, email, or blogging
Your subscription does not include
data capability. Settings are missing
or incorrect.
You can download settings using the
setup wizard or by going to
www.sonyericsson.com/support.
To download settings using the
Setup wizard
1From standby select Menu > Settings
> the General tab > Setup wizard >
Settings download.
2Follow the instructions that appear.
I have problems with memory
capacity or the phone is working
slowly
Restart your phone every day to free
memory or do a Master reset.
Master reset
If you select Reset settings, the
changes that you have made to
settings will be deleted.
If you select Reset all, your settings
and content, such as contacts,
messages, pictures, sounds and
downloaded games, will be deleted.
You may also lose content that was in
the phone at purchase.
To reset the phone
1From standby select Menu > Settings
> the General tab > Master reset.
2Select an option.
3Follow the instructions that appear.
I cannot charge the phone or battery
capacity is low
The charger is not properly connected
or the battery connection is poor.
Remove the battery and clean the
connectors.
Contact your network operator or
service provider for more information.
70 Troubleshooting
The battery is worn out and needs to
be replaced. See Charging the battery
on page 9.
No battery icon appears when I start
charging the phone
It may take a few minutes before the
battery icon appears on the screen.
Some menu options appear in grey
A service is not activated. Contact
your network operator.
I cannot use SMS/text messages on
my phone
You must have a service centre
number. The number is supplied by
your service provider and is usually
saved on the SIM card. If the number
to your service centre is not saved on
your SIM card, you must enter the
number yourself.
To enter a service centre number
1From standby select Menu >
Messaging > Settings > Text message
and scroll to Service centre. The
number is shown if it is saved on the
SIM card.
2If there is no number shown, select
Edit.
3Scroll to New ServiceCentre and select
Add.
4Enter the number, including the
international “+” sign and country
code.
5Select Save.
I cannot use picture messages on my
phone
You must set an MMS profile and the
address of your message server. If no
MMS profile or message server exists,
you may receive the settings from your
network operator or at
www.sonyericsson.com/support.
To select an MMS profile
1From standby select Menu >
Messaging > Settings > Picture
message > MMS profile.
2Select a profile.
To set the message server address
1From standby select Menu >
Messaging > Settings > Picture
message.
2Scroll to MMS profile and select Edit.
3Select Options > Edit.
4Scroll to Message server and select
Edit.
5Enter the address and select OK >
Save.
71Troubleshooting
The phone does not ring or rings too
softly
Make sure that Silent mode has not
been set to On. See To turn off the
ringtone on page 66.
Check the ringtone volume. See To set
the ringtone volume on page 65.
Check the profile. See To select a
profile on page 64.
Check the divert call options. See To
divert calls on page 39.
The phone cannot be detected by
other devices using Bluetooth
wireless technology
You have not turned the Bluetooth
function on. Make sure the visibility is
set to show phone. See To turn the
Bluetooth function on on page 29.
I cannot synchronise or transfer
content between my phone and my
computer, when using the USB
cable.
The cable or software that came with
your phone has not been properly
installed. Go to
www.sonyericsson.com/support to
read Getting started guides which
contain detailed installation
instructions and troubleshooting
guides.
I have forgotten my code memo
passcode
If you forget your passcode, you must
reset the code memo. This means that
all entries in the code memo are
deleted. The next time you enter the
code memo, you must proceed as if
you are opening it for the first time.
To reset code memo
1From standby select Menu > Organizer
> Code memo.
2Enter an incorrect password 3 times.
3Reset Code memo? appears.
4Select Yes.
72 Troubleshooting
Where can I find the regulatory
information such as my IMEI number
if I cannot turn on my phone?
Error messages
Insert SIM
There is no SIM card in your phone or
you may have inserted it incorrectly.
See To insert the SIM card on page 9.
The SIM card connectors need
cleaning. If the card is damaged,
contact your network operator.
Insert correct SIM card
Your phone is set to work only with
certain SIM cards. Check if you are
using the correct operator SIM card.
Wrong PIN or Wrong PIN2
You have entered your PIN or PIN2
incorrectly.
Enter the correct PIN or PIN2 and
select Yes. See PIN on page 7.
PIN blocked or PIN2 blocked
You have entered your PIN or PIN2
code incorrectly three times in a row.
To unblock, see SIM card lock on
page 67.
Codes do not match
Codes that you have entered do not
match. When you want to change a
security code, for example, your PIN,
you have to confirm the new code.
See SIM card lock on page 67.
No netw. coverage
Your phone is in flight mode. See
Flight mode on page 60.
Your phone is not receiving any
network signal, or the received signal
is too weak. Contact your network
operator and make sure that the
network has coverage where you are.
The SIM card is not working properly.
Insert your SIM card in another phone.
If this works, it is probably your phone
that is causing the problem. Please
73Important information
contact the nearest Sony Ericsson
service location.
Emerg. calls only
You are within range of a network, but
you are not allowed to use it.
However, in an emergency, some
network operators allow you to call the
international emergency number 112.
See Emergency calls on page 33.
PUK blocked. Contact operator.
You entered your personal unblocking
key code (PUK) incorrectly 10 times in
a row.
Important information
Sony Ericsson Consumer Web site
On www.sonyericsson.com/support there is a
support section where help and tips are only a few
clicks away. Here you will find the latest computer
software updates and tips on how to use your
product more efficiently.
Service and support
You have access to a portfolio of exclusive service
advantages such as:
• Global and local Web sites providing support
• A global network of Call Centers
• An extensive network of Sony Ericsson service
partners
• A warranty period. Learn more about the warranty
conditions in the Important information.
On www.sonyericsson.com, you will find the latest
support tools and information. For operator-
specific services and features, please contact your
network operator.
You can also contact our Call Centers. If your
country/region is not represented in the list below,
please contact your local dealer. (Calls are charged
according to national rates, including local taxes,
unless the phone number is a toll-free number.)
If your product needs service, please contact the
dealer from whom it was purchased, or one of our
service partners. For warranty claims, save proof of
purchase.
74 Important information
Support
75Important information
Guidelines for Safe and
Efficient Use
Please follow these guidelines. Failure
to do so might entail a potential
health risk or product malfunction. If
in doubt as to its proper function,
have the product checked by a
certified service partner before
charging or using it.
Recommendations for care and safe
use of our products
• Handle with care and keep in a clean and dust-free
place.
• Warning! May explode if disposed of in fire.
• Do not expose your product to liquid or moisture or
excess humidity.
• Do not expose to extreme
temperatures. Do not expose the
battery to temperatures above +60°C
(+140°F).
• Do not expose to flames or lit tobacco
products.
• Do not drop, throw or try to bend your product.
• Do not paint or attempt to
disassemble or modify your product.
Only Sony Ericsson authorized
personnel should perform service.
• Consult with authorized medical staff
and the instructions of the medical
device manufacturer before using your product
near pacemakers or other medical devices or
equipment.
76 Important information
• Discontinue use of electronic devices or disable the
radio transmitting functionality of the device where
required or requested to do so.
• Do not use where a potentially
explosive atmosphere exists.
• Do not place your product or install
wireless equipment in the area above
an air bag in your car.
• Caution: Cracked or broken displays
may create sharp edges or splinters that could be
harmful upon contact.
• Do not use your Bluetooth Headset in positions
where it is uncomfortable or will be subject to
pressure.
Children
Warning! Keep out of the reach of
children. Do not allow children to play
with mobile phones or accessories.
They could hurt themselves or others.
Products may contain small parts that could
become detached and create a choking hazard.
Power supply (Charger)
Connect the charger to power sources as marked
on the product. Do not use outdoors or in damp
areas. Do not alter or subject the cord to damage
or stress. Unplug the unit before cleaning it. Never
alter the plug. If it does not fit into the outlet, have a
proper outlet installed by an electrician. When
power supply is connected there is a small drain of
power. To avoid this small energy waste,
disconnect the power supply when the product is
fully charged. Use of charging devices that are not
Sony Ericsson branded may impose increased
safety risks.
Battery
New or idle batteries can have short-term reduced
capacity. Fully charge the battery before initial use.
Use for intended purpose only. Charge the battery
in temperatures between +5°C (+41°F) and +45°C
(+113°F). Do not put the battery into your mouth.
Do not let the battery contacts touch another metal
object. Turn off the product before removing the
battery. Performance depends on temperatures,
signal strength, usage patterns, features selected
and voice or data transmissions. Only Sony
Ericsson service partners should remove or replace
built-in batteries. Use of batteries that are not Sony
Ericsson branded may pose increased safety risks.
Personal medical devices
Mobile phones may affect implanted medical
equipment. Reduce risk of interference by keeping
a minimum distance of 15 cm (6 inches) between
the phone and the device. Use the phone at your
right ear. Do not carry the phone in your breast
pocket. Turn off the phone if you suspect
interference. For all medical devices, consult a
physician and the manufacturer.
Driving
Some vehicle manufacturers forbid the use of
phones in their vehicles unless a handsfree kit with
an external antenna supports the installation.
Check with your vehicle manufacturer's
representative to be sure that your mobile phone or
Bluetooth handsfree will not affect the electronic
systems in your vehicle. Full attention should be
given to driving at all times and local laws and
regulations restricting the use of wireless devices
while driving must be observed.
GPS/Location based functions
Some products provide GPS/Location based
functions. Location determining functionality is
provided “As is” and “With all faults”. Sony
Ericsson does not make any representation or
warranty as to the accuracy of such location
information.
77Important information
Use of location-based information by the device
may not be uninterrupted or error free and may
additionally be dependent on network service
availability. Please note that functionality may be
reduced or prevented in certain environments such
as building interiors or areas adjacent to buildings.
Caution: Do not use GPS functionality in a manner
which causes distraction from driving.
Emergency calls
Calls cannot be guaranteed under all conditions.
Never rely solely upon mobile phones for essential
communications. Calls may not be possible in all
areas, on all networks, or when certain network
services and/or phone features are used.
Antenna
Use of antenna devices not marketed by Sony
Ericsson could damage your phone, reduce
performance, and produce SAR levels above the
established limits. Do not cover the antenna with
your hand as this affects call quality, power levels
and can shorten talk and standby times.
Radio frequency (RF) exposure and
Specific Absorption Rate (SAR)
When your phone or Bluetooth handsfree is turned
on, it emits low levels of radio frequency energy.
International safety guidelines have been
developed through periodic and thorough
evaluation of scientific studies. These guidelines
establish permitted levels of radio wave exposure.
The guidelines include a safety margin designed to
assure the safety of all persons and to account for
any variations in measurements.
Specific Absorption Rate (SAR) is used to measure
radio frequency energy absorbed by the body when
using a mobile phone. The SAR value is determined
at the highest certified power level in laboratory
conditions, but because the phone is designed to
use the minimum power necessary to access the
chosen network, the actual SAR level can be well
below this value. There is no proof of difference in
safety based on difference in SAR value.
Products with radio transmitters sold in the US
must be certified by the Federal Communications
Commission (FCC). When required, tests are
performed when the phone is placed at the ear and
when worn on the body. For body-worn operation,
the phone has been tested when positioned a
minimum of 15 mm from the body without any
metal parts in the vicinity of the phone or when
properly used with an appropriate Sony Ericsson
accessory and worn on the body.
For more information about SAR and radio
frequency exposure go to:
www.sonyericsson.com/health.
Flight mode
Bluetooth and WLAN functionality, if available in
your device, can be enabled in Flight mode but may
be prohibited onboard aircraft or in other areas
where radio transmissions are prohibited. In such
environments, please seek proper authorization
before enabling Bluetooth or WLAN functionality
even in Flight mode.
Malware
Malware (short for malicious software) is software
that can harm your mobile phone or other
computers. Malware or harmful applications can
include viruses, worms, spyware, and other
unwanted programs. While your device does
employ security measures to resist such efforts,
Sony Ericsson does not warrant or represent that
your device will be impervious to introduction of
malware. You can however reduce the risk of
malware attacks by using care when downloading
content or accepting applications, refraining from
opening or responding to messages from unknown
sources, using trustworthy services to access the
78 Important information
Internet, and only downloading content to your
mobile phone from known, reliable sources.
Accessories
Use only Sony Ericsson branded original
accessories and certified service partners. Sony
Ericsson does not test third-party accessories.
Accessories may influence RF Exposure, radio
performance, sound loudness, electric safety and
other areas. Third-party accessories and parts may
pose a risk to your health or safety or decrease
performance.
Accessible Solutions/Special Needs
In the US, compatible Sony Ericsson phones may
offer compatibility with TTY terminals (with use of
necessary accessory). For more information call the
Sony Ericsson Special Needs Center on 877 878
1996 (TTY) or 877 207 2056 (voice), or go to
www.sonyericsson-snc.com.
Disposal of old electrical
and electronic equipment
Electronic equipment and batteries
should not be included as household
waste but should be left at an
appropriate collection point for recycling. This
helps prevent potential negative consequences for
the environment and human health. Check local
regulations by contacting your local city office, your
household waste disposal service, the shop where
you purchased the product or calling a Sony
Ericsson Call Center.
Disposing of the battery
Check local regulations or call a Sony
Ericsson Call Center for information.
Never use municipal waste.
Memory Card
If your product comes complete with a removable
memory card, it is generally compatible with the
handset purchased but may not be compatible with
other devices or the capabilities of their memory
cards. Check other devices for compatibility before
purchase or use. If your product is equipped with a
memory card reader, check memory card
compatibility before purchase or use.
The memory card is formatted prior to shipping. To
reformat the memory card, use a compatible
device. Do not use the standard operating system
format when formatting the memory card on a PC.
For details, refer to the operating instructions of the
device or contact customer support.
Warning!
If your device requires an adapter for insertion into
the handset or another device, do not insert the
card directly without the required adapter.
Precautions on Memory Card Use
• Do not expose the memory card to moisture.
• Do not touch terminal connections with your hand
or any metal object.
• Do not strike, bend, or drop the memory card.
• Do not attempt to disassemble or modify the
memory card.
• Do not use or store the memory card in humid or
corrosive locations or in excessive heat such as a
closed car in summer, in direct sunlight or near a
heater, etc.
• Do not press or bend the end of the memory card
adapter with excessive force.
• Do not let dirt, dust, or foreign objects get into the
insert port of any memory card adapter.
• Check you have inserted the memory card
correctly.
• Insert the memory card as far as it will go into any
memory card adapter needed. The memory card
may not operate properly unless fully inserted.
79Important information
• We recommend that you make a backup copy of
important data. We are not responsible for any loss
or damage to content you store on the memory
card.
• Recorded data may be damaged or lost when you
remove the memory card or memory card adapter,
turn off the power while formatting, reading or
writing data, or use the memory card in locations
subject to static electricity or high electrical field
emissions.
Protection of personal information
Erase personal data before disposing of the
product. To delete data, perform a master reset.
Deleting data from the phone memory does not
ensure that it cannot be recovered. Sony Ericsson
does not warrant against recovery of information
and does not assume responsibility for disclosure
of any information even after a master reset.
Loudness warning!
Avoid volume levels that may be harmful to your
hearing.
End User License Agreement
Software delivered with this device and its media is
owned by Sony Ericsson Mobile Communications
AB, and/or its affiliated companies and its suppliers
and licensors.
Sony Ericsson grants you a non-exclusive limited
license to use the Software solely in conjunction
with the Device on which it is installed or delivered.
Ownership of the Software is not sold, transferred
or otherwise conveyed.
Do not use any means to discover the source code
or any component of the Software, reproduce and
distribute the Software, or modify the Software.
You are entitled to transfer rights and obligations to
the Software to a third party, solely together with
the Device with which you received the Software,
provided the third party agrees in writing to be
bound by the terms of this License.
This license exists throughout the useful life of this
Device. It can be terminated by transferring your
rights to the Device to a third party in writing.
Failure to comply with any of these terms and
conditions will terminate the license immediately.
Sony Ericsson and its third party suppliers and
licensors retain all rights, title and interest in and to
the Software. Sony Ericsson, and, to the extent that
the Software contains material or code of a third
party, such third party, shall be entitled third party
beneficiaries of these terms.
This license is governed by the laws of Sweden.
When applicable, the foregoing applies to statutory
consumer rights.
Limited Warranty
Sony Ericsson Mobile Communications AB, Nya
Vattentornet, SE-221 88 Lund, Sweden, (Sony
Ericsson) or its local affiliated company, provides
this Limited Warranty for your mobile phone,
original accessory delivered with your mobile
phone, and/or your mobile computing product
(hereinafter referred to as “Product”).
Should your Product need warranty service, please
return it to the dealer from whom it was purchased,
or contact your local Sony Ericsson Call Center
(national rates may apply) or visit
www.SonyEricsson.com to get further information.
Our Warranty
Subject to the conditions of this Limited Warranty,
Sony Ericsson warrants this Product to be free from
defects in design, material and workmanship at the
time of its original purchase by a consumer. This
Limited Warranty will last for a period of one (1)
year as from the original date of purchase of the
Product.
80 Important information
What we will do
If, during the warranty period, this Product fails to
operate under normal use and service, due to
defects in design, materials or workmanship, Sony
Ericsson authorized distributors or service partners,
in the country* where you purchased the Product,
will, at their option, either repair or replace the
Product in accordance with the terms and
conditions stipulated herein.
Sony Ericsson and its service partners reserve the
right to charge a handling fee if a returned Product
is found not to be under warranty according to the
conditions below.
Please note that some of your personal settings,
downloads and other information may be lost when
your Sony Ericsson Product is repaired or replaced.
At present Sony Ericsson may be prevented by
applicable law, other regulation or technical
restrictions from making a backup copy of certain
downloads. Sony Ericsson does not take any
responsibility for any lost information of any kind
and will not reimburse you for any such loss. You
should always make backup copies of all the
information stored on your Sony Ericsson Product
such as downloads, calendar and contacts before
handing in your Sony Ericsson Product for repair or
replacement.
Conditions
1This Limited Warranty is valid only if the original
proof of purchase for this Product issued by a Sony
Ericsson authorized dealer specifying the date of
purchase and serial number**, is presented with the
Product to be repaired or replaced. Sony Ericsson
reserves the right to refuse warranty service if this
information has been removed or changed after the
original purchase of the Product from the dealer.
2If Sony Ericsson repairs or replaces the Product,
the repair for the defect concerned, or the replaced
Product shall be warranted for the remaining time
of the original warranty period or for ninety (90)
days from the date of repair, whichever is longer.
Repair or replacement may involve the use of
functionally equivalent reconditioned units.
Replaced parts or components will become the
property of Sony Ericsson.
3This warranty does not cover any failure of the
Product due to normal tear and wear, or due to
misuse, including but not limited to use in other
than the normal and customary manner, in
accordance with the Sony Ericsson instructions for
use and maintenance of the Product. Nor does this
warranty cover any failure of the Product due to
accident, software or hardware modification or
adjustment, acts of God or damage resulting from
liquid.
A rechargeable battery can be charged and
discharged more than a hundred times. However, it
will eventually wear out – this is not a defect and
corresponds to normal wear and tear. When the
talk-time or standby time is noticeably shorter, it is
time to replace your battery. Sony Ericsson
recommends that you use only batteries and
chargers approved by Sony Ericsson.
Minor variations in display brightness and colour
may occur between the phones. There may be tiny
bright or dark dots on the display. These are called
defective pixels and occur when individual dots
have malfunctioned and can not be adjusted. Two
defective pixels are deemed acceptable.
Minor variations in camera image appearance may
occur between phones. This is nothing uncommon
and is not regarded as a defective camera module.
4Since the cellular system on which the Product is to
operate is provided by a carrier independent from
Sony Ericsson, Sony Ericsson will not be
responsible for the operation, availability, coverage,
services or range of that system.
5This warranty does not cover Product failures
caused by installations, modifications, or repair or
opening of the Product performed by a non-Sony
Ericsson authorised person.
81Important information
6The warranty does not cover Product failures which
have been caused by use of accessories or other
peripheral devices which are not Sony Ericsson
branded original accessories intended for use with
the Product.
7Tampering with any of the seals on the Product will
void the warranty.
8THERE ARE NO EXPRESS WARRANTIES,
WHETHER WRITTEN OR ORAL, OTHER THAN
THIS PRINTED LIMITED WARRANTY. ALL
IMPLIED WARRANTIES, INCLUDING WITHOUT
LIMITATION THE IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED TO THE
DURATION OF THIS LIMITED WARRANTY. IN NO
EVENT SHALL SONY ERICSSON OR ITS
LICENSORS BE LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES OF ANY NATURE
WHATSOEVER, INCLUDING BUT NOT LIMITED
TO LOST PROFITS OR COMMERCIAL LOSS; TO
THE FULL EXTENT THOSE DAMAGES CAN BE
DISCLAIMED BY LAW.
Some countries/states do not allow the exclusion
or limitation of incidental or consequential
damages, or limitation of the duration of implied
warranties, so the preceding limitations or
exclusions may not apply to you.
The warranty provided does not affect the
consumer's statutory rights under applicable
legislation in force, nor the consumer’s rights
against the dealer arising from their sales /
purchase contract.
*Geographical scope of the warranty
If you have purchased your Product in a country
member of the European Economic Area (EEA) or in
Switzerland or the Republic of Turkey, and such
Product was intended for sale in the EEA or in
Switzerland or in Turkey, you can have your
Product serviced in any EEA country or in
Switzerland or in Turkey, under the warranty
conditions prevailing in the country in which you
require servicing, provided that an identical
Product is sold in such country by an authorised
Sony Ericsson distributor. To find out if your
Product is sold in the country you are in, please call
the local Sony Ericsson Call Center. Please observe
that certain services may not be possible elsewhere
than in the country of original purchase, for
example due to the fact that your Product may
have an interior or exterior which is different from
equivalent models sold in other countries. Please
note in addition that it may sometimes not be
possible to repair SIM-locked Products.
** In some countries/regions additional information
(such as a valid warranty card) may be requested.
FCC Statement
This device complies with Part
15 of the FCC rules. Operation is
subject to the following two
conditions:
(1) This device may not cause
harmful interference, and (2)
This device must accept any interference received,
including interference that may cause undesired
operation.
Any change or modification not expressly approved
by Sony Ericsson may void the user's authority to
operate the equipment.
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and
can radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will not occur in a
particular installation.
82 Important information
If this equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment
and receiver.
-- Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
-- Consult the dealer or an experienced radio/TV
technician for help.
Industry Canada Statement
This device complies with RSS-210 of Industry
Canada.
Operation is subject to the following two
conditions: (1) this device may not cause
interference, and (2) this device must accept any
interference, including interference that may cause
undesired operation of the device.
This Class B digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la classe B est conforme
à la norme NMB-003 du Canada.
Declaration of Conformity for
W902
We, Sony Ericsson Mobile Communications AB of
Nya Vattentornet
SE-221 88 Lund, Sweden
declare under our sole responsibility that our
product
Sony Ericsson type AAD-3052121-BV
and in combination with our accessories, to which
this declaration relates is in conformity with the
appropriate standards EN 301 511:V9.0.2, EN 301
489-7:V1.3.1, EN 301 908-1:V2.2.1, EN 301 908-
2:V2.2.1, EN 301 489-24:V1.3.1, EN 300
328:V1.7.1, EN 301 489-17:V1.2.1, EN 60 950-
1:2006 following the provisions of, Radio
Equipment and Telecommunication Terminal
Equipment directive 1999/5/EC.
We fulfil the requirements of the R&TTE Directive
(1999/5/EC).
Lund, June 2008
Shoji Nemoto,
Head of Product Business Group GSM/UMTS
83Index
Index
A
activity menu ........................................ 15
alarms ................................................... 61
answering service ................................ 38
applications .......................................... 66
appointments ....................................... 63
assembly ................................................ 7
audio book ........................................... 22
auto rotate ............................................ 66
B
backing up and restoring ..................... 30
battery
charging ......................................... 9
inserting ......................................... 7
blog
camera ......................................... 53
video ............................................ 53
Bluetooth™ wireless technology ......... 29
bookmarks
creating ........................................ 54
selecting ....................................... 54
business cards ..................................... 37
C
calendar ......................................... 62–63
call divert .............................................. 39
call list .................................................. 37
call numbers in message ..................... 43
call time ................................................ 42
caller-specific ringtones ....................... 35
calls
accepting ..................................... 41
answering and rejecting ............... 33
emergency ................................... 33
handling two calls ........................ 40
international ................................. 32
making and receiving ................... 32
putting on hold ............................. 39
recording ...................................... 25
video ............................................ 34
camera ................................................. 49
activating ...................................... 49
blog .............................................. 53
printing ......................................... 53
settings ......................................... 50
shortcuts ...................................... 50
using ............................................ 49
camera keys ......................................... 49
clear bass ............................................. 20
clear stereo .......................................... 20
code memo .......................................... 71
conference calls ................................... 40
contacts ......................................... 34, 35
adding phone contacts ................ 34
84 Index
default contacts ........................... 34
groups .......................................... 37
synchronizing ............................... 57
D
date ...................................................... 65
declaration of conformity ..................... 82
downloading music .............................. 22
E
email ..................................................... 45
emergency numbers ............................ 33
entering text ......................................... 17
F
file manager ......................................... 26
fixed dialling ......................................... 42
flight mode ........................................... 60
G
games .................................................. 66
Google Maps™ .................................... 61
groups .................................................. 37
H
handsfree ................................. 18, 30, 38
help ........................................................ 8
hiding number ...................................... 42
history, Web pages .............................. 54
I
imaging
camera ..........................................49
video recorder ...............................49
IMEI number ..........................................68
Internet
bookmarks ....................................54
security and certificates ................55
K
keypad lock ...........................................68
automatic ......................................68
keys .......................................................10
L
language ...............................................17
location data .........................................51
location services ...................................61
lock
keypad ..........................................68
phone ............................................68
SIM card .......................................67
M
master reset ..........................................69
Media Manager .....................................27
media transfer .................................27, 28
memory card .........................................15
memory status ................................26, 36
menu overview ......................................12
85Index
messages
area and cell information .............. 48
email ............................................. 45
picture .......................................... 44
text ............................................... 43
voice ............................................. 45
messaging ............................................ 43
microphone .......................................... 33
MMS See picture messages
MusicDJ™ ............................................ 25
My friends ............................................ 47
my numbers ......................................... 41
N
navigating menus ................................. 14
notes .................................................... 63
O
online music, listening .......................... 23
online video clips, viewing ................... 23
P
pan and zoom, Web pages .................. 54
PC Suite ............................................... 57
phone mode ......................................... 58
phone name ......................................... 29
phone, turning on ................................... 8
photo feeds .......................................... 57
photo tags ............................................ 51
PhotoDJ™ ............................................ 52
picture messages ................................. 44
pictures ................................................ 50
PIN code, changing .............................. 67
playlists ................................................ 21
PlayNow™ ........................................... 22
podcasts .............................................. 56
power saving ........................................ 30
profiles ................................................. 64
PUK ...................................................... 67
push email ............................................ 47
R
radio ..................................................... 24
recording, listen to ............................... 25
restricted dialling .................................. 41
ringtones .............................................. 65
S
safety guidelines .................................. 75
screen orientation ................................ 66
search, on Web pages ......................... 54
selection keys ...................................... 14
SensMe™ ....................................... 21, 22
settings, Internet settings ..................... 69
shortcuts .............................................. 14
SIM card
copying to/from ............................ 35
inserting ......................................... 7
locking .......................................... 67
unblocking .................................... 67
86 Index
smart search ........................................ 35
SMS See text messages
SOS See emergency numbers
sound recorder ..................................... 25
speed dialling ....................................... 37
standby .................................................. 8
synchronizing ....................................... 57
T
T9™ Text Input .................................... 17
tasks ..................................................... 64
templates ............................................. 45
text messages ...................................... 43
theme ................................................... 65
time ...................................................... 65
time zone ............................................. 65
TrackID™ ............................................. 22
transferring
camera pictures ........................... 27
music ........................................... 27
sound ........................................... 30
turning on/off
Bluetooth™ function .................... 29
keypad lock .................................. 68
phone lock ................................... 68
SIM lock protection ...................... 67
U
Update service ..................................... 60
USB cable ............................................ 28
V
video
blog ...............................................53
editing ...........................................52
video player ...........................................23
video recorder .......................................49
VideoDJ™ .............................................52
voice answering ....................................38
voice commands ...................................38
voice control .........................................38
voice messages ....................................45
voicemail ...............................................38
volume
ear speaker ...................................33
ringtone .........................................65
W
Walkman™ player ...........................18, 19
warranty ................................................79
Web feeds .............................................55
Web pages, history ...............................54
Z
zoom .....................................................50

Navigation menu
