08 user manual all parts

8VHUJXLGH

;SHULD3XUHQHVV

Important information

Please read the Important information leaflet before you

use your mobile phone.

Experience more. Discover

how.

Congratulations. You now own a classy phone that comes

with first-class support. Wherever you are there's always

help at hand if you need an answer fast about your phone.

Visit www.sonyericsson.com/pureness to find out how to get

in touch with our dedicated specialist teams in your country

and for tips and tricks about how to get the most out of your

phone.

User guide in the phone

An extended User guide is available in your phone.

To access the User guide in your phone

•Select Menu > Settings > User help > User guide.

Phone overview

1 Ear speaker

2 Screen

3 Selection keys

4 Volume key

5 Call key

6 Activity menu key

7 Connector for charger,

handsfree and USB cable

8 End key

9 C key (Clear)

10 Navigation key

11 Phone antenna

12 On/off, reset key

13 Volume key

14 SIM card slot

Getting started

To insert the SIM card

•Open the cover and insert the SIM card with the gold-

coloured contacts facing down.

To remove the SIM card

•Open the cover and press the edge of the SIM card to

release and remove it.

Turning on the phone

To turn on the phone

1On the back of the phone, press and hold down .

2Enter your SIM card PIN (Personal Identification Number),

if requested, and select OK.

3Select a language.

4Follow the instructions that appear.

If you want to correct a mistake when you enter your

PIN, press .

To access the main menu

•When Menu appears on the screen, press the centre

selection key to select Menu.

•If Menu does not appear on the screen, press End key,

and then press the centre selection key to select Menu.

Help

In addition to this User guide, Feature guides and more

information are available at

www.sonyericsson.com/support.

There are also help functions in your phone. See the

following instructions on how to access them.

To view tips and tricks

•Select Menu > Settings > User help > Tips and

tricks.

To view information about functions

•Scroll to a function and select Info, if available. In some

cases, Info appears under Options.

To view the phone status

•Press a volume key. Phone, memory and battery

information is shown.

Making and answering calls

To make a call

1Enter a phone number (with international country code

and area code, if applicable).

2Press the Call key.

You can call numbers from Contacts and your call list.

To end a call

•Press the End key.

To make international calls

1Press and hold down until a “+” sign appears.

2Enter the country code, area code (without the first zero)

and phone number.

3Press the Call key.

To answer a call

•Press the Call key.

To reject a call

•Press the End key.

To change the ear speaker volume during a call

•Press the volume keys up or down.

To mute the microphone during a call

1Press and hold down . appears.

2Press and hold down again to resume.

To turn on the loudspeaker during a call

•Select Spkr on. appears.

Do not hold the phone to your ear when using the

loudspeaker. This could damage your hearing.

2If is not displayed, press and hold down to

change to Quick text input.

3Press each key only once, even if the letter you want is

not the first letter on the key. For example, to write the

word “Jane”, press , , , . Write the

whole word before looking at the suggestions.

4To view word suggestions, press or press the

navigation key downwards.

5Press to accept a suggestion and add a space.

To enter text using the multitap method

1Select, for example, Menu > Messaging > Write new >

Message.

2If is displayed, press and hold down to change

to multitap text input.

3Press – repeatedly until the desired letter

appears.

4Press to add a space.

To add words to the phone dictionary

1When you enter text using Quick text input, select

Options > Spell word.

2Write the word using multitap input and select Save.

Calling

You need to turn on your phone and be within range of a

network.

Messages and contacts are saved in the phone memory,

but you can choose to save them on the SIM card.

Entering text

You can use multitap text input or Quick text input to

enter text. The Quick text input method uses a dictionary

application in your phone.

To change the writing language

•When you enter text, press and hold down .

To change the text input method

•When you enter text, press and hold down .

To shift between upper- and lower-case letters or numbers

•When you enter text, press .

To enter numbers

1When you enter text, press repeatedly until

appears at the top of the screen.

2To enter a number, press .

To enter a number from text input mode, you can

press and hold down – .

To enter punctuation marks and symbols

1When you enter text, press briefly.

2Scroll to a symbol and select Insert.

To select from the most commonly used punctuation

marks, you can also press .

To enter text using Quick text input

1Select, for example, Menu > Messaging > Write new >

Message.

To delete items

•Press to delete items such as numbers, letters,

pictures and sounds.

Shortcuts

You can use the navigation key shortcuts to go directly to

functions from standby.

To use navigation key shortcuts

•Press the navigation key upwards, downwards, left or

right, to go directly to a function.

To edit a navigation key shortcut

1Select Menu > Settings > General > Shortcuts.

2Scroll to an option and select Edit.

3Scroll to a menu option and select Shortc..

Activity menu

The activity menu gives you quick access to:

•New events – missed calls and new messages.

•Running apps – applications that are running in the

background.

•My shortcuts – add your favourite functions to access

them quickly.

To open the activity menu

•Press .

Media memory

You can save content in the Media memory, in the phone

memory and on the SIM card. Pictures, videos and music

are saved in the Media memory. If the Media memory is full,

pictures videos and music are saved in the phone memory.

To charge the battery

1Connect the charger to the phone.

2Remove the charger by tilting the plug upwards.

Maximising battery performance

•Charge your phone often. The battery lasts longer if you

charge it frequently.

•If you are in an area with no coverage, your phone

repeatedly scans for available networks. This consumes

power. If you cannot move to an area with better

coverage, turn off your phone temporarily.

Supported services and features

Some of the services and features described in this

User guide are not supported by all networks and/or

service providers in all areas. Without limitation, this

applies to the GSM International Emergency Number

112. Please contact your network operator or service

provider to determine availability of any specific

service or feature and whether additional access or

usage fees apply.

Charging the battery

The phone battery is partly charged when you buy it.

The phone battery cannot be removed.

•Turn off 3G and Bluetooth™ wireless technology when

you do not need these functions.

•Do not cover the phone antenna when you are engaged

in a call.

Go to

www.sonyericsson.com/support

to learn more

about how to maximise the battery performance.

Navigation

To navigate the phone menus

•Press the navigation key upwards, downwards, left or

right to move through the menus.

To end a function

•Press the End key.

To return to standby

•Press the End key.

Emergency calls

Your phone supports international emergency numbers, for

example, 112 or 911. You can normally use these numbers

to make emergency calls in any country, with or without the

SIM card inserted, if you are within range of a network.

In some countries, other emergency numbers may also

be promoted. Your network operator may therefore

have saved additional local emergency numbers on the

SIM card.

To make an emergency call

•Enter 112 (the international emergency number) and

press the Call key.

To view your local emergency numbers

1Select Menu > Contacts.

2Scroll to New contact and select Options > Special

numbers > Emerg. numbers.

Call list

You can view information about answered , dialled

and missed or rejected calls.

To call a number from the call list

1Press the Call key and scroll to a tab.

2Scroll to a name or a number and press the Call key.

Contacts

You can save names, phone numbers and personal

information in Contacts. Information can be saved in the

phone memory or on the SIM card.

You can synchronise your contacts using the

Sony Ericsson PC Suite.

To add a phone contact

1Select Menu > Contacts.

2Scroll to New contact and select Add.

3Enter the name and select OK.

4Scroll to New number: and select Add.

5Enter the number and select OK.

6Select a number option.

7Scroll between the tabs and add information to the fields.

8Select Save.

Calling contacts

To call with Smart search

1Press – to enter a sequence of (at least two)

digits. All entries which match the sequence of digits or

corresponding letters are shown in a list.

2Scroll to a contact or a phone number and press the Call

key.

To turn on or off Smart search

1Select Menu > Settings > Calls > Smart search.

2Select an option.

Speed dial

Speed dialling lets you select nine contacts that you can dial

quickly from standby. The contacts can be saved in

positions 1-9.

To assign speed dial numbers to contacts

1Select Menu > Contacts.

2Scroll to New contact and select Options > Speed

dial.

3Scroll to a position number and select Add.

4Select a contact.

To speed dial

•Enter the position number and press the Call key.

Messaging

To view a message in the inbox

1Select Menu > Messaging > Messages > Inbox.

2Scroll to the message and select View.

To call a number contained in a message

•When you are viewing the message, scroll to the phone

number and press the Call key.

Sending messages

You can send messages from your phone. The maximum

size of a standard text message is 160 characters (including

spaces) if no other items are added to the message. If you

enter more than 160 characters, a second message is

created. Your messages are sent as one concatenated

message.

To create and send a message

1Select Menu > Messaging > Write new > Message.

2Enter text. To add items to the message, press the

navigation key downwards, scroll by pressing the

navigation key left or right, and select an item.

3Select Continue > Contacts look-up.

4Select a recipient and select Send.

If you send a message to a group, you may be charged

for each member. Contact your service provider for

details.

Conversations

You can choose whether to view your messages in

Conversations or the Inbox. A messaging conversation

shows all messaging communication between you and one

of your contacts.

To view messages in Conversations

•Select Menu > Messaging > Inbox > the

Conversations tab.

•Select Menu > Messaging > Conversations and select

a conversation.

To send a message from Conversations

1Select Menu > Messaging.

2Select Conversations, or select Inbox > the

Conversations tab.

3Select a conversation.

4Write a message and select Send.

Pictures and videos

You can view pictures and videos that you have received or

downloaded to your phone. Saved pictures and videos can

be found in the File manager.

Viewing pictures and videos

To view pictures

1Select Menu > Organiser > File manager > Pictures.

2Scroll to a picture and select View.

3To scroll through the pictures, press the navigation key

left or right.

To play videos

1Select Menu > Organiser > File manager > Videos.

2Scroll to a video and select View.

3Select Play.

Music

You can listen to music, audio books and podcasts. Use

Media Go™ to transfer content to and from your phone. For

more information, see Transferring content to and from a

computer on page 24.

Stereo portable handsfree

To use a handsfree

•Connect a portable handsfree. Music stops when you

receive a call and resumes when the call has ended.

If headphones are not included with the phone, you

may purchase them separately.

Music player

To play music

1Select Menu > Music player.

2Select Options > My music.

3Browse by category using the navigation key.

4Press the centre selection key to play music.

To stop playing music

•Press the centre selection key.

To fast forward and rewind

•Press and hold down the navigation key right or left.

To move between tracks

•Press the navigation key right or left.

To change the volume

•Press the volume keys up or down.

TrackID™ technology

TrackID™ technology is a music recognition service. You

can search for title, artist and album name for a track you

hear playing through a loudspeaker or on the radio in your

phone. If you cannot use TrackID™ technology, see I

cannot use Internet-based services on page 35.

To search for track information

•When you hear a track playing through a loudspeaker,

select Menu > Entertainment > TrackID™ > Start.

•When the radio in your phone is playing, select Options

> TrackID™.

For best results, use TrackID™ in a quiet area.

Radio

To listen to the radio, you need to use wired

headphones that act as an antenna for the radio. The

Bluetooth headset supplied with the phone cannot

function as an antenna. If wired headphones are not

included with the phone, you need to purchase them

separately.

Do not use your phone as a radio in places where this

is prohibited.

To turn on the radio

1Connect a handsfree to the phone.

2Select Menu > Radio.

Saving channels

You can save up to 20 preset channels.

To save channels automatically

•Select Options > Channels > Auto save.

To switch between saved channels

•Press the navigation key upwards or downwards.

You can also select a saved channel by pressing

- .

Transferring and handling

content

You can transfer and handle content such as pictures and

music.

You are not allowed to exchange some copyright-

protected material. identifies a protected item.

Handling content in the phone

You can use File manager in your phone to handle content

saved in the phone memory in the Media memory. Tabs and

icons in File manager show where the content is saved. If

the memory is full, delete some content to create space.

To view memory status

1Select Menu > Organiser > File manager.

2Select Options > Memory status.

3Select Media memory or Phone.

To select more than one item in a folder

1Select Menu > Organiser > File manager.

2Scroll to a folder and select Open.

3Select Options > Mark > Mark several.

4For each item you want to mark, scroll to the item and

select Mark.

To move items between the phone memory and the Media

memory

1Select Menu > Organiser > File manager.

2Find an item and select Options > Manage file >

Move.

3Select Media memory or Phone.

4Scroll to a folder and select Open.

5Select Paste.

Sending content to another phone

You can send content using different transfer methods, for

example, Messages or Bluetooth wireless technology.

To send content

1Scroll to an item and select Options > Send.

2Select a transfer method.

Make sure the receiving device supports the transfer

method you select.

Using a USB cable

You can connect your phone to a computer using a USB

cable. If you are using a computer running Microsoft®

Windows®, where you have not already installed the

necessary USB software, you are asked to install PC

Companion.

You may have to purchase a USB cable separately.

Only use a USB cable supported by your phone. Check

that Autoplay functionality is enabled on your PC.

To disconnect the USB cable safely

Do not disconnect the USB cable when transferring

content as this may corrupt the content.

1Computer: Right-click the Safely Remove Hardware icon

in Microsoft® Windows® Explorer.

2Select the drives you want to disconnect. Select Stop.

3Wait until you are notified that it is safe to remove the

drive. Disconnect the USB cable.

PC Companion

PC Companion lets you:

•Explore content in your phone.

•Use your phone as a modem.

•Install PC software used to synchronise, transfer and

back up phone content.

For more information, including Feature guides, go to

www.sonyericsson.com/support.

To download Mac® compatible software, go to

www.sonyericsson.com/support.

To install PC Companion

If the necessary USB software has not been installed

on your PC, you need to install PC Companion.

Autoplay functionality needs to be enabled on your PC.

1Connect your phone to a computer running Microsoft®

Windows® using a USB cable supported by your phone.

2Computer: Follow the on-screen instructions.

Required operating systems

You need one of these operating systems to use Sony

Ericsson PC software:

•Microsoft® Windows Vista™

•Microsoft® Windows® XP, Service Pack 2 or higher

Transferring content to and from a

computer

You can use Media Go™ to transfer media content between

your phone and a computer. Media Go™ is available for

download through PC Companion or from

www.sonyericsson.com/support.

To download Mac® compatible software, go to

www.sonyericsson.com/support.

Dragging and dropping content

You can drag and drop content between your phone

memory, the Media memory and a computer using

Microsoft® Windows® Explorer.

To drag and drop content

1Connect your phone to a computer using a USB cable.

2Computer: Wait until the phone memory and Media

memory appear as external disks in Microsoft®

Windows® Explorer.

3Drag and drop selected files between the phone and the

computer.

To transfer content using Media Go™

1Connect the phone to a computer with a USB cable

supported by your phone.

2Computer: Select Start/Programs/Sony/Media Go™.

3Select Transfer to or from Device using Media Go™ and

click OK.

4Wait until the phone appears in Media Go™.

5Move files between your phone and the computer in

Media Go™.

Using Bluetooth™ wireless technology

Use Bluetooth™ technology to wirelessly connect to other

devices, free of charge. You can, for example:

•Connect to handsfree devices.

•Connect to several devices at the same time.

•Connect to computers and access the Internet.

•Exchange MP3 files, virtual business cards, photos, and

more.

•Play multiplayer games.

A range of less than 10 metres (33 feet), with no solid

objects in between, is recommended for Bluetooth

communication.

Before using Bluetooth wireless technology

You must turn on the Bluetooth function to communicate

with other devices. You may also have to pair your phone

with other Bluetooth devices.

To turn on the Bluetooth function

•Select Menu > Settings > Connectivity > Bluetooth >

Turn on.

Make sure that the device you want to pair your phone

with has the Bluetooth function activated and

Bluetooth visibility turned on.

To pair the phone with another device

1Select Menu > Settings > Connectivity > Bluetooth >

Add new device.

2Select a device.

3Enter a passcode, if required.

To allow connections to the phone

1Select Menu > Settings > Connectivity > Bluetooth.

2Select a device from the list.

3Select Options > Allow conn..

4Select Always ask or Always allow.

This is only possible with devices that require access

to a secure service.

Backing up and restoring

You can back up and restore contacts, the calendar, tasks,

notes and bookmarks using the Sony Ericsson PC Suite.

Before backing up and restoring, you need to install the

Sony Ericsson PC Suite, which is available through PC

Companion or from www.sonyericsson.com/support.

You can back up and restore contacts in your phone using

the Media memory. You can move content between the

Media memory and the phone memory. See Handling

content in the phone on page 22.

Back up your phone content regularly to make sure

you do not lose it.

To make a backup using the Sony Ericsson PC Suite

1Computer: Start the Sony Ericsson PC Suite from Start/

Programs/Sony Ericsson/Sony Ericsson PC Suite.

2Follow the instructions in the Sony Ericsson PC Suite on

how to connect.

3Go to the backup and restore section in the

Sony Ericsson PC Suite and make a backup of your

phone content.

Updating your phone

You can update your phone with the most recent software

for optimal performance and to get the latest

enhancements. This is done with the Update Service

application. You have two options to update your phone

with the Update Service application:

•Using a computer

•Wireless update

Remember to back up your phone content before

updating with a computer. See Backing up and

restoring on page 27.

Updating your phone using a computer

You can update your phone with the latest software by

connecting it to a computer on which the Update Service

application is installed. You need a USB cable and an

Internet-connected PC.

To learn how, go to

www.sonyericsson.com/update

Internet

If you cannot use the Internet, see I cannot use Internet-

based services on page 35.

To start the web browser

•Select Menu > Entertainment > Internet.

To go back when browsing

•To go back to the previous page, select .

To exit the browser

1When you are browsing the web, select and then

select .

2Select Exit browser.

To access the web browser toolbar

When you are viewing a web page, select . The following

options appear:

No battery icon appears when I start charging the

phone

It may take a few minutes before the battery icon appears

on the screen.

Some menu options appear in grey

A service is not activated. Contact your network operator.

I cannot use Internet-based services

Your subscription does not include data capability. Settings

are missing or incorrect.

You can download settings using the Settings downl. or

from www.sonyericsson.com/support.

To download settings

1Select Menu > Settings > User help > Settings

downl..

2Follow the instructions that appear.

This feature might not be available in all markets.

Contact your network operator or service provider for

more information.

I cannot send messages from my phone

To send messages, you need to set a service centre

number. The number is supplied by your service provider

and is usually saved on the SIM card. If the number of your

service centre is not saved on your SIM card, you must enter

the number yourself.

To send most picture messages, you must set an MMS

(Multimedia Messaging Service) profile and the address of

your message server. If no MMS profile or message server

exists, you can receive all the settings automatically from

I have problems with memory capacity or the phone

is working slowly

Restart your phone every day to free memory or do a

Master reset.

Master reset

If you select Reset settings, the changes that you have

made to settings will be deleted.

If you select Reset all, your settings and content, such as

contacts, messages, pictures, sounds and downloaded

games, will be deleted. You may also lose content that was

in the phone at purchase.

To reset the phone

1Select Menu > Settings > General > Master reset.

2Select an option.

3Follow the instructions that appear.

What do I do if the phone freezes or hangs?

Press and hold down the volume down key and the power

key simultaneously for 10 seconds.

Some problems will require you to call your network

operator.

For more support go to www.sonyericsson.com/support.

Common questions

Where can I find the regulatory information such as

my IMEI number if I cannot turn on my phone?

PIN codes

SIM protection

This lock only protects your subscription. Your phone will

work with a new SIM card. If the lock is on, you have to enter

a PIN (Personal Identity Number).

If you enter your PIN incorrectly three times in a row, the SIM

card is blocked and you need to enter your PUK (Personal

Unblocking Key). Your PIN and PUK are supplied by your

network operator.

To unblock the SIM card

1When PIN blocked appears, enter your PUK and select

OK.

2Enter a new four-to-eight-digit PIN and select OK.

3Re-enter the new PIN and select OK.

To edit the PIN

1Select Menu > Settings > General > PIN codes > SIM

protection > Change PIN.

2Enter your PIN and select OK.

3Enter a new four-to-eight-digit PIN and select OK.

4Re-enter the new PIN and select OK.

If Codes do not match appears, you entered the new

PIN incorrectly. If Incorrect PIN appears, you entered

the old PIN incorrectly.

Troubleshooting

Some problems can be fixed using Update Service. Using

Update Service on a regular basis will optimise the phone’s

performance. See Updating your phone using a

computer on page 28.

•Normal mode – full functionality

•Flight mode – limited functionality

To activate the flight mode menu

•Select Menu > Settings > General > Flight mode >

Continue > Show at startup.

To select flight mode

1When the flight mode menu is activated, turn off your

phone.

2Turn on your phone and select Flight mode.

appears.

Alarms

You can set a sound or the radio as an alarm signal. The

alarm sounds even if the phone is turned off. When the alarm

sounds, you can silence it or turn it off.

To set the alarm

1Select Menu > Alarms.

2Scroll to an alarm and select Edit.

3Scroll to Time: and select Edit.

4Enter a time and select OK > Save.

To silence the alarm

•When the alarm sounds, press any key.

•To repeat the alarm, select Snooze.

To turn off the alarm

•When the alarm sounds, press any key, then select Turn

off.

Calendar

You can synchronise your calendar with a computer

calendar, with a calendar on the web or with a

Icon Function

Pan and zoom the web page

Search the web or enter a web address

Manage your favourite web pages

Manage the files you have downloaded from the

Internet

Web browser shortcuts

You can use the keypad to go directly to a web browser

function.

Key Shortcut

Bookmarks

- Enter text to enter an address, search the

Internet or search in Bookmarks

Zoom

Overview (when Smart-Fit is off)

More features

Flight mode

In Flight mode the network and radio transceivers are

turned off to prevent disturbance to sensitive equipment.

When the flight mode menu is activated you are asked to

select a mode the next time you turn on your phone:

Microsoft® Windows Server® (Outlook®)

application.

Appointments

You can add new appointments or reuse existing

appointments.

To add an appointment

1Select Menu > Organiser > Calendar.

2Select a date.

3Scroll to New entry and select Add.

4Enter the information and confirm each entry.

5Select Save.

To set when reminders should sound

1Select Menu > Organiser > Calendar.

2Select a date.

3Select Options > Advanced > Reminders.

4Select an option.

A reminders option set in Calendar affects a reminders

option set in Tasks.

Ringtones

To set a ringtone

1Select Menu > Settings > Sounds & alerts >

Ringtone.

2Find and select a ringtone.

To turn off the ringtone

•Press and hold down . appears.

The alarm signal is not affected.

your network operator, using the Settings download, or go

to www.sonyericsson.com/support.

To enter a service centre number

1Select Menu > Settings > Connectivity > Message

settings > Text message and scroll to Service centre.

The number is shown if it is saved on the SIM card.

2If there is no number shown, select Edit.

3Scroll to New serv. centre and select Add.

4Enter the number, including the international “+” sign and

country code.

5Select Save.

To select an MMS profile

1Select Menu > Settings > Connectivity > Message

settings > Multimedia msg.

2Select an existing profile or create a new one.

To set the message server address

1Select Menu > Settings > Connectivity > Message

settings > Multimedia msg.

2Scroll to a profile and select Options > Edit.

3Scroll to Message server and select Edit.

4Enter the address and select OK > Save.

I cannot synchronise or transfer content between

my phone and the computer, when using a USB

cable.

The software or the USB drivers have not been properly

installed. Go to www.sonyericsson.com/support to read

Feature guides which contain detailed installation

instructions and troubleshooting sections.

Error messages

Insert SIM

There is no SIM card in your phone or you may have inserted

it incorrectly.

See To insert the SIM card on page 5.

The SIM card connectors need cleaning. If the card is

damaged, contact your network operator.

Insert correct SIM card

Your phone is set to work only with certain SIM cards.

Check if you are using the correct operator SIM card.

Incorrect PIN/Incorrect PIN2

You have entered your PIN or PIN2 incorrectly.

Enter the correct PIN or PIN2 and select OK.

PIN blocked/PIN2 blocked

You have entered your PIN or PIN2 code incorrectly three

times in a row.

To unblock, see SIM protection on page 32.

No network

•Your phone is in flight mode. See Flight mode on

page 29.

•Your phone is not receiving any network signal, or the

received signal is too weak. Contact your network

operator and make sure that the network has coverage

where you are.

•The SIM card is not working properly. Insert your SIM

card in another phone. If this works, it is probably your

phone that is causing the problem. Please contact the

nearest Sony Ericsson service location.

Emerg. calls only

You are within range of a network, but you are not allowed

to use it. However, in an emergency, some network

operators allow you to call the international emergency

number 112. See Emergency calls on page 15.

Legal information

Sony Ericsson X5

This User guide is published by Sony Ericsson Mobile Communications

AB or its local affiliated company, without any warranty. Improvements

and changes to this User guide necessitated by typographical errors,

inaccuracies of current information, or improvements to programs and/

or equipment, may be made by Sony Ericsson Mobile Communications

AB at any time and without notice. Such changes will, however, be

incorporated into new editions of this User guide.

©Sony Ericsson Mobile Communications AB, 2009

Publication number: 1231-0121.1

Your mobile phone has the capability to download, store and forward

additional content, e.g. ringtones. The use of such content may be

restricted or prohibited by rights of third parties, including but not limited

to restriction under applicable copyright laws. You, and not

Sony Ericsson, are entirely responsible for additional content that you

download to or forward from your mobile phone. Prior to your use of any

additional content, please verify that your intended use is properly

licensed or is otherwise authorized. Sony Ericsson does not guarantee

the accuracy, integrity or quality of any additional content or any other

third party content. Under no circumstances will Sony Ericsson be liable

in any way for your improper use of additional content or other third party

content.

Bluetooth is a trademark or a registered trademark of Bluetooth SIG Inc.

and any use of such mark by Sony Ericsson is under license.

The Liquid Identity logo, Xperia, pureness and TrackID are trademarks

or registered trademarks of Sony Ericsson Mobile Communications AB.

Sony and "make.believe" are trademarks or registered trademarks of

Sony Corporation.

Media Go is a trademark or registered trademark of Sony Media Software

and Services.

microSD is a trademark or a registered trademark of SanDisk

Corporation.

Ericsson is a trademark or registered trademark of Telefonaktiebolaget

LM Ericsson.

Adobe Photoshop Album Starter Edition is a trademark or registered

trademark of Adobe Systems Incorporated in the United States and/or

other countries.

Mac is a trademark of Apple Computer, Inc., registered in the U.S. and

other countries.

Microsoft, Windows, Outlook, Windows Vista, Windows Server and

ActiveSync are registered trademarks or trademarks of Microsoft

Corporation in the United States and/or other countries.

This product is protected by certain intellectual property rights of

Microsoft. Use or distribution of such technology outside of this product

is prohibited without a license from Microsoft.

Other product and company names mentioned herein may be the

trademarks of their respective owners.

Any rights not expressly granted herein are reserved.

All illustrations are for illustration only and may not accurately depict the

actual phone.

www.sonyericsson.com

Sony Ericsson Mobile Communications AB

SE-221 88 Lund, Sweden

1231-0121.1

www.sonyericsson.com

Sony Ericsson Mobile Communications AB

SE-221 88 Lund, Sweden

1232-8006.2

Important Information

United States & Canada

THIS PHONE MODEL HAS BEEN CERTIFIED IN COMPLIANCE

WITH THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE

TO RADIO WAVES.

The Series mobile phones have been designed to comply with

applicable safety requirements for exposure to radio waves. Your

wireless phone is a radio transmitter and receiver. It is designed to

not exceed the limits* of exposure to radio frequency (RF) energy

set by governmental authorities. These limits establish permitted

levels of RF energy for the general population. The guidelines are

based on standards that were developed by international scientific

organizations through periodic and thorough evaluation of

scientific studies. The standards include a safety margin designed

to assure the safety of all individuals, regardless of age and

health.

The radio wave exposure guidelines employ a unit of

measurement known as the Specific Absorption Rate (SAR). Tests

for SAR are conducted using standardized methods with the

phone transmitting at its highest certified power level in all used

frequency bands. While there may be differences between the SAR

levels of various phone models, they are all designed to meet the

relevant guidelines for exposure to radio waves. For more

information on SAR, please refer to the safe and efficient use

chapter in the User Guide.

The highest SAR value as reported to the authorities for this

phone model when tested for use by the ear is 1.37 W/kg*, and

when worn on the body is 0.76 W/kg* for speech and 0.97 W/kg*

for data calls. Body worn measurements are made while the phone

is in use and worn on the body with a Sony Ericsson accessory

supplied with or designated for use with this phone. It is therefore

recommended that only Ericsson and Sony Ericsson original

accessories be used in conjunction with Sony Ericsson phones.

**Before a phone model is available for sale to the public in the

US, it must be tested and certified by the Federal Communications

Commission (FCC) that it does not exceed the limit established by

Renseignements importants

États-Unis et Canada

CE MODÈLE DE TÉLÉPHONE A ÉTÉ CERTIFIÉ CONFORME AUX

EXIGENCES GOUVERNEMENTALES RELATIVES À L'EXPOSITION

AUX ONDES RADIOÉLECTRIQUES.

Les téléphones mobiles ont été conçus pour répondre aux

normes de sécurité en vigueur en matière d'exposition aux ondes

radioélectriques. Votre téléphone sans fil est un émetteur et un

récepteur radio. Il est conçu de manière à ne pas dépasser les

limites* d'exposition aux signaux radiofréquences (RF) établies par

les autorités gouvernementales. Ces limites fixent les niveaux

maximaux d'énergie radiofréquence auxquels peut être soumis le

grand public. Ces lignes directrices sont basées sur des normes

qui ont été élaborées par des organisations scientifiques

internationales par le biais d'évaluations périodiques et

approfondies des études scientifiques. Ces normes prévoient une

marge de sécurité visant à assurer la protection de toutes les

personnes, quels que soient leur âge et leur état de santé.

Les lignes directrices relatives à l'exposition aux ondes

radioélectriques utilisent une unité de mesure appelée "Débit

d'absorption spécifique" (SAR). Les tests de SAR sont effectués

selon des méthodes standardisées dans lesquelles le téléphone

émet dans toutes les bandes de fréquences utilisées, à la plus

forte puissance pour laquelle il a été homologué. Bien que le débit

d'absorption spécifique puisse être différent d'un modèle de

téléphone à un autre, tous les appareils sont conçus pour

respecter les lignes directrices relatives aux ondes

radioélectriques. Pour en savoir plus sur le débit d'absorption

spécifique, reportez-vous au chapitre sur l'utilisation efficace et

sans danger de ce présent guide.

Le débit d'absorption spécifique le plus élevé relevé par les

autorités pour ce modèle de téléphone est de 1,37 W/kg* lorsqu'il

est testé en utilisation près de l'oreille, et de 0,76 W/kg* (pour les

appels vocaux) et de 0,97 W/kg* (pour les appels de données)

lorsqu'il est porté sur le corps. Lors des mesures de port sur le

corps, le téléphone était maintenu par un accessoire Sony

Información importante

Estados Unidos y Canadá

ESTE MODELO DE TELÉFONO HA SIDO CERTIFICADO Y

CUMPLE CON LOS REQUISITOS GUBERNAMENTALES DE

EXPOSICIÓN A LAS ONDAS DE RADIO.

El teléfono móvil ha sido diseñado para cumplir con los

requisitos de seguridad aplicables de exposición a las ondas de

radio. El teléfono inalámbrico es un transmisor y receptor de radio.

Está diseñado para no superar los límites* de exposición a la

energía de radiofrecuencia (RF) establecidos por las autoridades

gubernamentales. Estos límites establecen los niveles permitidos

de energía de RF para la población en general. Las

especificaciones se basan en los estándares desarrollados por

organizaciones científicas internacionales mediante una

evaluación periódica y minuciosa de estudios científicos. Estos

estándares incluyen un margen de seguridad destinado a

garantizar la seguridad de todas las personas,

independientemente de su edad y condición de salud.

Las especificaciones de exposición a las ondas de radio

emplean una unidad de medición conocida como Tasa específica

de absorción (SAR). Las pruebas de SAR se realizan usando

métodos estandarizados mientras el teléfono transmite al nivel de

potencia más alto certificado en todas las bandas de frecuencia

utilizadas. Si bien puede haber diferencias entre los niveles de SAR

de diversos modelos de teléfono, todos los teléfonos han sido

diseñados para cumplir con las especificaciones pertinentes de

exposición a las ondas de radio. Para obtener más información

acerca de SAR, consulte el capítulo sobre uso seguro y eficaz en la

Guía del usuario.

El mayor valor SAR según lo informado a las autoridades para

este teléfono cuando se evaluó para su uso cerca del oído fue de

1,37 W/kg*, y cuando se utilizó cerca del cuerpo fue de 0,76 W/kg*

para llamadas de voz y 0,97 W/kg* para llamadas de datos. Las

mediciones para el uso cerca del cuerpo se realizan mientras el

teléfono está en uso y ubicado cerca del cuerpo con un accesorio

Sony Ericsson proporcionado con el teléfono o diseñado para su

FCC Statement

Declaration of Conformity

Sony Ericsson X5

UMTS HSPA band 1 GSM GPRS/EDGE 850/900/1800/1900

the government-adopted requirement for safe exposure*. The

tests are performed in positions and locations (i.e., by the ear and

worn on the body) as required by the FCC for each model. The FCC

has granted an Equipment Authorization for this phone model with

all reported SAR levels evaluated as in compliance with the FCC RF

exposure guidelines. While there may be differences between the

SAR levels of various phones, all mobile phones granted an FCC

equipment authorization meet the government requirement for

safe exposure. SAR information on this phone model is on file at

the FCC and can be found under the Display Grant section of

http://www.fcc.gov/oet/fccid after searching on FCC

ID PY7A3880049. Additional information on SAR can be found on

the Cellular Telecommunications & Internet Association (CTIA)

website at http://www.phonefacts.net.

* In the United States and Canada, the SAR limit for mobile

phones used by the public is 1.6 watts/kilogram (W/kg) averaged

over one gram of tissue. The standard incorporates a margin of

safety to give additional protection for the public and to account

for any variations in measurements.

**This paragraph is only applicable to authorities and customers

in the United States.

Ericsson fourni avec ce téléphone ou conçu pour être utilisé avec

l'appareil. Il est par conséquent recommandé de n'utiliser que les

accessoires authentiques Ericsson et Sony Ericsson avec les

téléphones Sony Ericsson.

**Avant qu'un modèle de téléphone ne soit offert au public aux

États-Unis, la FCC (Federal Communications Commission) doit le

tester et certifier qu'il respecte les limites fixées dans les exigences

gouvernementales d'exposition sans danger*. Pour chaque

modèle, les tests sont effectués en position et aux endroits

d'usage (c'est-à- dire près de l'oreille et porté sur le corps), tel que

l'exige la FCC. La FCC a accordé une autorisation d'équipement

(Equipment Authorization) pour ce modèle de téléphone, après

que tous les débits d'absorption spécifique indiqués aient été

évalués et considérés conformes aux lignes directrices de la FCC

en matière d'exposition aux radiofréquences. Même s'il peut y

avoir des différences entre les niveaux de SAR des différents

téléphones, tous les téléphones mobiles auxquels la FCC a

accordé une autorisation d'équipement répondent aux normes

gouvernementales en matière d'exposition sans danger. La FCC

conserve dans ses dossiers l'information relative aux débits

d'absorption spécifique relevés pour ce modèle de téléphone.

Vous pouvez la consulter au http://www.fcc.gov/oet/fccid, sous la

rubrique "Display Grant ", après avoir effectué une recherche sur

FCC ID PY7A3880049 . Vous trouverez des renseignements

supplémentaires concernant le débit d'absorption spécifique

(SAR) sur le site Web de la Cellular Telecommunications & Internet

Association (CTIA) au http://www.phonefacts.net.

*Aux États-Unis et au Canada, la limite de débit d'absorption

spécifique (SAR) des téléphones mobiles utilisés par le public est

de 1,6 watt/kg (W/kg) en moyenne sur un gramme de tissus. Cette

norme comporte une marge importante de sécurité afin d'assurer

une protection supplémentaire et de tenir compte de toute

variation dans les mesures.

**Ce paragraphe ne concerne que les autorités et les clients des

États-Unis.

uso con este teléfono. Por lo tanto, se recomienda utilizar sólo

accesorios originales Ericsson y Sony Ericsson en conjunto con los

teléfonos Sony Ericsson.

**Antes de que un modelo de teléfono esté disponible para la

venta al público en los EE.UU., se debe probar y certificar ante la

Comisión Federal de Comunicaciones (FCC) que no supera el

límite establecido por los requisitos gubernamentales de

exposición segura*. Las pruebas se realizan en las posiciones y

lugares (es decir, en el oído y cerca del cuerpo) exigidos por la FCC

para cada modelo. La FCC ha otorgado una Autorización de

equipo para este modelo de teléfono con todos los niveles SAR

informados y que han sido evaluados en cumplimiento con las

especificaciones de exposición de RF de la FCC. Si bien puede

haber diferencias en los niveles SAR entre distintos modelos de

teléfonos móviles, todos los teléfonos móviles que han recibido

una autorización de equipo de la FCC cumplen con los requisitos

gubernamentales de exposición segura. La información de SAR

acerca de este modelo de teléfono está archivada en la FCC y se

puede encontrar en la sección Display Grant de

http://www.fcc.gov/oet/fccid luego de buscar en FCC

ID PY7A3880049. Si desea información adicional acerca de SAR,

puede encontrarla en el sitio Web de la Asociación de

Telecomunicaciones Celulares e Internet (CTIA, Cellular

Telecommunications & Internet Association) en la dirección

http://www.phonefacts.net.

* En los Estados Unidos y Canadá, el límite SAR para teléfonos

móviles utilizados por el público es de 1,6 watts/kilogramo (W/kg)

promediado sobre un gramo de tejido. El estándar incorpora un

margen de seguridad para entregar protección adicional al público

y para representar las variaciones en las mediciones.

**Este párrafo sólo es aplicable a las autoridades y clientes en

los Estados Unidos.

Important Information

Latin & South America

Radio wave exposure and Specific Absorption Rate (SAR)

information

The Series mobile phones have been designed to comply with

applicable safety requirements for exposure to radio waves. These

requirements are based on scientific guidelines that include safety

margins designed to assure the safety of all persons, regardless of

age and health.

The radio wave exposure guidelines employ a unit of

measurement known as the Specific Absorption Rate, or SAR.

Tests for SAR are conducted using standardised methods with the

phone transmitting at its highest certified power level in all used

frequency bands.

While there may be differences between the SAR levels of

various phone models, they are all designed to meet the relevant

guidelines for exposure to radio waves.

For more information on SAR, please refer to the safety chapter

in the User Guide.

SAR data information for residents in countries that have

adopted the SAR limit recommended by the International

Commission on Non-Ionizing Radiation Protection (ICNIRP), which

is 2 W/kg averaged over ten (10) gram of tissue (for example

European Union, Japan, Brazil and New Zealand):

The highest SAR value for this model phone when tested by

Sony Ericsson for use at the ear is 1.60 W/kg (10g).

Informação importante

América do Sul e Latina

Informações sobre SAR (Taxa de Absorção Específica) e

exposição à radiofreqüência

O celular foi projetado para cumprir os requisitos de segurança

aplicáveis para exposição à radiofreqüência. Esses requisitos têm

como base diretrizes científicas que incluem as margens de

segurança para garantir a segurança de todas as pessoas,

independentemente da idade e da saúde.

As diretrizes de exposição à radiofreqüência usam uma unidade

de medida conhecida como SAR ou Taxa de Absorção Específica.

Os testes de SAR são conduzidos por métodos padronizados com

a transmissão telefônica em seu nível certificado de energia mais

alto em todas as faixas de freqüência usadas.

Embora possa haver diferenças entre os níveis de SAR de vários

modelos de telefone, todos foram projetados para atender as

diretrizes relevantes de exposição à radiofreqüência.

Para obter mais informações sobre SAR, consulte o capítulo de

segurança do Guia do Usuário.

Informações sobre os dados de SAR para moradores de países

que adotaram o limite SAR recomendado pelo ICNIRP

(International Commission on Non-Ionizing Radiation Protection)

que é o limite médio de 2 W/kg em dez (10) gramas de tecido (por

exemplo, União Européia, Japão, Brasil e Nova Zelândia).

Quando testado pela Sony Ericsson, o valor de SAR mais alto

para este modelo de telefone para uso junto ao ouvido foi de

1,60 W/kg (10g).

Industry Canada Statement

This device complies with RSS-210 of Industry Canada.

Operation is subject to the following two conditions: (1) this

device may not cause interference, and (2) this device must accept

any interference, including interference that may cause undesired

operation of the device.

This Class B digital apparatus complies with Canadian

ICES-003.

Cet appareil numérique de la classe B est conforme à la norme

NMB-003 du Canada.

Información importante

Latinoamérica y América del Sur

Información acerca de la exposición a ondas de radio y la

Tasa específica de absorción (SAR)

El teléfono móvil ha sido diseñado para cumplir con los

requisitos de seguridad aplicables de exposición a las ondas de

radio. Dichos requisitos se basan en directrices científicas que

establecen márgenes de seguridad con el fin de evitar perjuicos a

todas las personas, independientemente de su edad o estado de

salud.

Las directrices de exposición a ondas de radio utilizan una

unidad de medida denominada coeficiente de absorción específica

o SAR. Las pruebas de SAR se líevan a cabo utilizando métodos

normalizados, con el teléfono transmitiendo en el nivel más

elevado de potencia autoridado en todas las bandas de frecuencia

utilizadas.

Aunque puede existir diferencias entre los niveles de SAR de

diferentes modelos de teléfono, todos han sido diseñados para

cumplir las directrices pertinentes sobre exposición a ondas de

radio.

Para obtener más información sobre el SAR, consulte el capítulo

sobre seguridad en la guía del usuario.

Información sobre datos de SAR para residentes de países en

los que se haya adoptado el limite de SAR recomendado por la

International Commission on Non-Ionizing Radiation Protection

(ICNIRP, Comisión internacional de protección contra la radiación

no ionizantes (ICNIRP, International Commission on Non-Ionizing

Radiation Protection), es 2 W/kg promedio por cada

diez (10) gramos de tejido (por ejemplo, la Unión Europea, Japón,

Brasil y Nueva Zelanda):

El valor de SAR más elevado para este modelo de teléfono

cuando Sony Ericsson realizó la prueba para su uso en la oreja era

de 1,60 W/kg (10g).

FCC Statement

This device complies with Part 15 of the FCC rules.

Operation is subject to the following two conditions: (1)

This device may not cause harmful interference, and (2)

This device must accept any interference received, including

interference that may cause undesired operation.

Any change or modification not expressly approved by Sony

Ericsson may void the user's authority to operate the equipment.

This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a

particular installation.

If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for

help.

Declaration of Conformity for X5

We, Sony Ericsson Mobile Communications AB of

Nya Vattentornet

SE-221 88 Lund, Sweden

declare under our sole responsibility that our product

Sony Ericsson type AAD-3880049-BV

and in combination with our accessories, to which this declaration

relates is in conformity with the appropriate standards EN 301

511:V9.0.2, EN 301 908-1:V3.2.1, EN 301 908-2:V3.2.1, EN 300

328:V1.7.1, EN 301 489-7:V1.3.1, EN 301 489- 17:V2.2.1, EN 301

489-24:V1.4.1,EN 301 489- 3:V1.4.1 following the provisions of,

Radio Equipment and Telecommunication Terminal Equipment

directive 1999/5/EC .

Lund, September 2009

Rikko Sakaguchi,

Corporate Vice President and Head of Creation & Development

We fulfil the requirements of the R&TTE Directive (1999/5/EC).

Ce produit est conforme aux directives de R&TTE (1999/5/EC).

Cumplimos con los requisitos de la Directiva R&TTE – Normas

sobre equipos de terminales de radio y telecomunicaciones (1999/

5/EC).

Atendemos aos requisitos da Diretriz R&TTE (1999/5/EC).

Important information

Sony Ericsson Consumer Web site

At www.sonyericsson.com/support there is a support section

where help and tips are only a few clicks away. Here you will find

the latest computer software updates and tips on how to use

your product more efficiently.

Service and support

You have access to a portfolio of exclusive service advantages

such as:

•Global and local Web sites providing support.

•A global network of Contact Centers.

•An extensive network of Sony Ericsson service partners.

•A warranty period. Learn more about the warranty conditions in

theLimited warrantysection.

At www.sonyericsson.com/support, you can find the latest

support tools and information. For operator-specific services and

features, please contact your network operator.

You can also contact our Contact Centers. If your country/

region is not represented in the list below, please contact your

local dealer. (Calls are charged according to national rates,

including local taxes, unless the phone number is a toll-free

number.)

If your product needs service, please contact the dealer from

whom it was purchased, or one of our service partners. For

warranty claims, save proof of purchase.

Guidelines for Safe and Efficient Use

Please follow these guidelines. Failure to do so might

entail a potential health risk or product malfunction. If in

doubt as to its proper function, have the product

checked by a certified service partner before charging

or using it.

Recommendations for care and safe use of our products

•Handle with care and keep in a clean and dust-free place.

•Warning! May explode if disposed of in fire.

•Do not expose to liquid or moisture or excess humidity.

•For optimum performance, the product should not

be operated in temperatures below -10°C(+14°F) or

above +45°C(+113°F). Do not expose the battery to

temperatures above +60°C(+140°F).

•Do not expose to flames or lit tobacco products.

•Do not drop, throw or try to bend the product.

•Do not paint or attempt to disassemble or modify the

product. Only Sony Ericsson authorised personnel

should perform service.

•Consult with authorised medical staff and the

instructions of the medical device manufacturer

before using the product near pacemakers or other medical

devices or equipment.

•Discontinue use of electronic devices, or disable the radio

transmitting functionality of the device, where required or

requested to do so.

•Do not use where a potentially explosive atmosphere exists.

•Do not place the product, or install wireless equipment, in the

area above an air bag in a car.

•Caution: Cracked or broken displays may create sharp edges

or splinters that could be harmful upon contact.

•Do not use the Bluetooth Headset in positions where it is

uncomfortable or will be subject to pressure.

Children

Warning! Keep out of the reach of children. Do not

allow children to play with mobile phones or

accessories. They could hurt themselves or others.

Products may contain small parts that could become detached

and create a choking hazard.

Power supply (Charger)

Connect the charger to power sources as marked on the

product. Do not use outdoors or in damp areas. Do not alter or

subject the cord to damage or stress. Unplug the unit before

cleaning it. Never alter the plug. If it does not fit into the outlet,

have a proper outlet installed by an electrician. When a power

supply is connected there is a small drain of power. To avoid this

small energy waste, disconnect the power supply when the

product is fully charged. Use of charging devices that are not

Sony Ericsson branded may pose increased safety risks.

Battery

New or idle batteries can have short-term reduced capacity.

Fully charge the battery before initial use. Use for the intended

purpose only. Charge the battery in temperatures between

+5°C(+41°F) and +45°C(+113°F). Do not put the battery into

your mouth. Do not let the battery contacts touch another metal

object. Turn off the product before removing the battery.

Performance depends on temperatures, signal strength, usage

patterns, features selected and voice or data transmissions. Only

Sony Ericsson service partners should remove or replace built-in

batteries. Use of batteries that are not Sony Ericsson branded

may pose increased safety risks. Replace the battery only with

another Sony Ericsson battery that has been qualified with the

product per the standard IEEE-1725. Use of an unqualified

battery may present a risk of fire, explosion, leakage or other

hazard.

Personal medical devices

Mobile phones may affect implanted medical equipment. Reduce

risk of interference by keeping a minimum distance of

15 cm(6 inches) between the phone and the device. Use the

phone at your right ear. Do not carry the phone in your breast

pocket. Turn off the phone if you suspect interference. For all

medical devices, consult a physician and the manufacturer.

Driving

Some vehicle manufacturers forbid the use of phones in their

vehicles unless a handsfree kit with an external antenna supports

the installation. Check with the vehicle manufacturer's

representative to be sure that the mobile phone or Bluetooth

handsfree will not affect the electronic systems in the vehicle.

Full attention should be given to driving at all times and local

laws and regulations restricting the use of wireless devices while

driving must be observed.

GPS/Location based functions

Some products provide GPS/Location based functions. Location

determining functionality is provided “As is” and “With all faults”.

Sony Ericsson does not make any representation or warranty as

to the accuracy of such location information.

Use of location-based information by the device may not be

uninterrupted or error free and may additionally be dependent on

network service availability. Please note that functionality may be

reduced or prevented in certain environments such as building

interiors or areas adjacent to buildings.

Caution: Do not use GPS functionality in a manner which

causes distraction from driving.

Emergency calls

Calls cannot be guaranteed under all conditions. Never rely

solely upon mobile phones for essential communication. Calls

may not be possible in all areas, on all networks, or when certain

network services and/or phone features are used.

Antenna

Use of antenna devices not marketed by Sony Ericsson could

damage the phone, reduce performance, and produce SAR

levels above the established limits. Do not cover the antenna

with your hand as this affects call quality, power levels and can

shorten talk and standby times.

Radio Frequency (RF) exposure and Specific Absorption

Rate (SAR)

When the phone or Bluetooth handsfree is turned on, it emits

low levels of radio frequency energy. International safety

guidelines have been developed through periodic and thorough

evaluation of scientific studies. These guidelines establish

permitted levels of radio wave exposure. The guidelines include a

safety margin designed to assure the safety of all persons and to

account for any variations in measurements.

Specific Absorption Rate (SAR) is used to measure radio

frequency energy absorbed by the body when using a mobile

phone. The SAR value is determined at the highest certified

power level in laboratory conditions, but because the phone is

designed to use the minimum power necessary to access the

chosen network, the actual SAR level can be well below this

value. There is no proof of difference in safety based on

difference in SAR value.

Products with radio transmitters sold in the US must be

certified by the Federal Communications Commission (FCC).

When required, tests are performed when the phone is placed at

the ear and when worn on the body. For body-worn operation,

the phone has been tested when positioned a minimum of

15 mm from the body without any metal parts in the vicinity of

the phone or when properly used with an appropriate

Sony Ericsson accessory and worn on the body.

For more information about SAR and radio frequency

exposure, go to: www.sonyericsson.com/health.

Flight mode

Bluetooth and WLAN functionality, if available in the device, can

be enabled in Flight mode but may be prohibited onboard aircraft

or in other areas where radio transmissions are prohibited. In

such environments, please seek proper authorisation before

enabling Bluetooth or WLAN functionality even in Flight mode.

Malware

Malware (short for malicious software) is software that can harm

the mobile phone or other computers. Malware or harmful

applications can include viruses, worms, spyware, and other

unwanted programs. While the device does employ security

measures to resist such efforts, Sony Ericsson does not warrant

or represent that the device will be impervious to the introduction

of malware. You can however reduce the risk of malware attacks

by using care when downloading content or accepting

applications, refraining from opening or responding to messages

from unknown sources, using trustworthy services to access the

Internet, and only downloading content to the mobile phone from

known, reliable sources.

Accessories

Use only Sony Ericsson branded original accessories and

certified service partners. Sony Ericsson does not test third-party

accessories. Accessories may influence RF exposure, radio

performance, loudness, electric safety and other areas. Third-

party accessories and parts may pose a risk to your health or

safety or decrease performance.

Accessible Solutions/Special Needs

In the US, compatible Sony Ericsson phones may offer

compatibility with TTY terminals (with use of necessary

accessory). For more information call the Sony Ericsson Special

Needs Center on 877 878 1996 (TTY) or 877 207 2056 (voice),

or go to www.sonyericsson-snc.com.

Disposal of old electrical and electronic

equipment

Electronic equipment and batteries should not be

included as household waste but should be left at an

appropriate collection point for recycling. This helps prevent

potential negative consequences for the environment and human

health. Check local regulations by contacting your local city

office, your household waste disposal service, the shop where

you purchased the product or calling a Sony Ericsson Contact

Center. Do not attempt to remove internal batteries. Internal

batteries shall be removed only by a waste treatment facility or

trained service professional.

Disposing of the battery

Check local regulations or call a Sony Ericsson Contact

Center for information. Never use municipal waste.

Memory card

If the product comes complete with a removable memory card, it

is generally compatible with the handset purchased but may not

be compatible with other devices or the capabilities of their

memory cards. Check other devices for compatibility before

purchase or use. If the product is equipped with a memory card

reader, check memory card compatibility before purchase or use.

Memory cards are generally formatted prior to shipping. To

reformat the memory card, use a compatible device. Do not use

the standard operating system format when formatting the

memory card on a PC. For details, refer to the operating

instructions of the device or contact customer support.

Warning!

If the device requires an adapter for insertion into the handset or

another device, do not insert the card directly without the

required adapter.

Precautions on memory card use

•Do not expose the memory card to moisture.

•Do not touch terminal connections with your hand or any metal

object.

•Do not strike, bend, or drop the memory card.

•Do not attempt to disassemble or modify the memory card.

•Do not use or store the memory card in humid or corrosive

locations or in excessive heat such as a closed car in summer,

in direct sunlight or near a heater, etc.

•Do not press or bend the end of the memory card adapter with

excessive force.

•Do not let dirt, dust, or foreign objects get into the insert port

of any memory card adapter.

•Check you have inserted the memory card correctly.

•Insert the memory card as far as it will go into any memory

card adapter needed. The memory card may not operate

properly unless fully inserted.

•We recommend that you make a backup copy of important

data. We are not responsible for any loss or damage to content

you store on the memory card.

•Recorded data may be damaged or lost when you remove the

memory card or memory card adapter, turn off the power while

formatting, reading or writing data, or use the memory card in

locations subject to static electricity or high electrical field

emissions.

Protection of personal information

Erase personal data before disposing of the product. To delete

data, perform a master reset. Deleting data from the phone

memory does not ensure that it cannot be recovered.

Sony Ericsson does not warrant against recovery of information

and does not assume responsibility for disclosure of any

information even after a master reset.

Loudness warning!

Avoid volume levels that may be harmful to your hearing.

End User Licence Agreement

Software delivered with this device and its media is owned by

Sony Ericsson Mobile Communications AB, and/or its affiliated

companies and its suppliers and licensors.

Sony Ericsson grants you a non-exclusive limited licence to

use the Software solely in conjunction with the Device on which

it is installed or delivered. Ownership of the Software is not sold,

transferred or otherwise conveyed.

Do not use any means to discover the source code or any

component of the Software, reproduce and distribute the

Software, or modify the Software. You are entitled to transfer

rights and obligations to the Software to a third party, solely

together with the Device with which you received the Software,

provided the third party agrees in writing to be bound by the

terms of this Licence.

This licence exists throughout the useful life of this Device. It

can be terminated by transferring your rights to the Device to a

third party in writing.

Failure to comply with any of these terms and conditions will

terminate the licence immediately.

Sony Ericsson and its third party suppliers and licensors retain

all rights, title and interest in and to the Software. To the extent

that the Software contains material or code of a third party, such

third parties shall be beneficiaries of these terms.

This licence is governed by the laws of Sweden. When

applicable, the foregoing applies to statutory consumer rights.

In the event Software accompanying or provided in

conjunction with your device is provided with additional terms

and conditions, such provisions shall also govern your

possession and usage of the Software.

Export regulations

Export regulations: This product, including any software or

technical data contained in or accompanying the product, may

be subject to import and export regulations of the European

Union, the United States and other countries. The user and any

possessor of the product agrees to comply strictly with all such

regulations and acknowledges that it is their responsibility to

obtain any required licenses to export, re-export, or import this

product. Without limiting the foregoing, and as an example, the

user and any possessor of the product: (1) must not knowingly

export or re-export Products to destinations identified pursuant

to Articles in Chapter II of European Council Regulation (EC)

1334/2000; (2), must comply with U.S. government Export

Administration Regulations ("EAR", 15 C.F.R. §§ 730-774, http://

www.bis.doc.gov/ ) administered by Department of Commerce,

Bureau of Industry and Security; and (3) must comply with

economic sanctions regulations (30 C.F.R. §§ 500 et. seq.,.,

http://www.treas.gov/offices/enforcement/ofac/) administered by

the U.S. Department of Treasury, Office of Foreign Assets

Control. The user and any possessor of the product may not

transport or deliver the product, its accessories or separate

software to any country, region, entity or person prohibited by

these regulations.

Limited Warranty

Sony Ericsson Mobile Communications AB, SE-221 88 Lund,

Sweden, (Sony Ericsson) or its local affiliated company, provides

this Limited Warranty for your mobile phone, original accessory

delivered with your mobile phone, and/or your mobile computing

product (hereinafter referred to as “Product”).

Should your Product need warranty service, please return it to

the dealer from whom it was purchased, or contact your local

Sony Ericsson Contact Center (national rates may apply) or visit

www.sonyericsson.com to get further information.

Our warranty

Subject to the conditions of this Limited Warranty, Sony Ericsson

warrants this Product to be free from defects in design, material

and workmanship at the time of its original purchase by a

consumer. This Limited Warranty will last for a period of two (2)

years as from the original date of purchase of the Product for

your mobile phone, and for a period of one (1) year following the

original purchase date of the Product for all original accessories

(such as the battery, charger or handsfree kit) which may be

delivered with your mobile phone.

What we will do

If, during the warranty period, this Product fails to operate under

normal use and service, due to defects in design, materials or

workmanship, Sony Ericsson authorised distributors or service

partners, in the country/region* where you purchased the

Product, will, at their option, either repair or replace the Product

in accordance with the terms and conditions stipulated herein.

Sony Ericsson and its service partners reserve the right to

charge a handling fee if a returned Product is found not to be

under warranty according to the conditions below.

Please note that some of your personal settings, downloads

and other information may be lost when your Sony Ericsson

Product is repaired or replaced. At present, Sony Ericsson may

be prevented by applicable law, other regulation or technical

restrictions from making a backup copy of certain downloads.

Sony Ericsson does not take any responsibility for any lost

information of any kind and will not reimburse you for any such

loss. You should always make backup copies of all the

information stored on your Sony Ericsson Product such as

downloads, calendar and contacts before handing in your

Sony Ericsson Product for repair or replacement.

Conditions

1. This Limited Warranty is valid only if the original proof of

purchase for this Product issued by a Sony Ericsson authorised

dealer specifying the date of purchase and serial number**, is

presented with the Product to be repaired or replaced.

Sony Ericsson reserves the right to refuse warranty service if

this information has been removed or changed after the original

purchase of the Product from the dealer.

2. If Sony Ericsson repairs or replaces the Product, the repair for

the defect concerned, or the replaced Product shall be

warranted for the remaining time of the original warranty period

or for ninety (90) days from the date of repair, whichever is

longer. Repair or replacement may involve the use of

functionally equivalent reconditioned units. Replaced parts or

components will become the property of Sony Ericsson.

3. This warranty does not cover any failure of the Product due to

normal wear and tear, or due to misuse, including but not

limited to use in other than the normal and customary manner,

in accordance with the Sony Ericsson instructions for use and

maintenance of the Product. Nor does this warranty cover any

failure of the Product due to accident, software or hardware

modification or adjustment, acts of God or damage resulting

from liquid.

A rechargeable battery can be charged and discharged more

than a hundred times. However, it will eventually wear out –

this is not a defect and corresponds to normal wear and tear.

When the talk-time or standby time is noticeably shorter, it is

time to replace the battery. Sony Ericsson recommends that

you use only batteries and chargers approved by

Sony Ericsson.

Minor variations in display brightness and colour may occur

between phones. There may be tiny bright or dark dots on the

display. These are called defective pixels and occur when

individual dots have malfunctioned and can not be adjusted.

Two defective pixels are deemed acceptable.

Minor variations in camera image appearance may occur

between phones. This is nothing uncommon and is not

regarded as a defective camera module.

4. Since the cellular system on which the Product is to operate is

provided by a carrier independent from Sony Ericsson,

Sony Ericsson will not be responsible for the operation,

availability, coverage, services or range of that system.

5. This warranty does not cover Product failures caused by

installations, modifications, or repair or opening of the Product

performed by a non-Sony Ericsson authorised person.

6. The warranty does not cover Product failures which have been

caused by use of accessories or other peripheral devices which

are not Sony Ericsson branded original accessories intended

for use with the Product.

Sony Ericsson disclaims any and all warranties, whether

express or implied, for failures caused to the Product or

peripheral devices as a result of viruses, trojan horses,

spyware, or other malicious software. Sony Ericsson strongly

recommends that you install appropriate virus protection

software on your Product and any peripheral devices

connected to it, as available, and update it regularly, to better

protect your device. It is understood, however, that such

software will never fully protect your Product or its peripheral

devices and Sony Ericsson disclaims all warranties, whether

express or implied, in case of failure by such antivirus software

to fulfil its intended purpose.

7. Tampering with any of the seals on the Product will void the

warranty.

8. THERE ARE NO EXPRESS WARRANTIES, WHETHER WRITTEN

OR ORAL, OTHER THAN THIS PRINTED LIMITED WARRANTY.

ALL IMPLIED WARRANTIES, INCLUDING WITHOUT

LIMITATION THE IMPLIED WARRANTIES OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR

PURPOSE, ARE LIMITED TO THE DURATION OF THIS LIMITED

WARRANTY. IN NO EVENT SHALL SONY ERICSSON OR ITS

LICENSORS BE LIABLE FOR INCIDENTAL OR

CONSEQUENTIAL DAMAGES OF ANY NATURE WHATSOEVER,

INCLUDING BUT NOT LIMITED TO LOST PROFITS OR

COMMERCIAL LOSS TO THE FULL EXTENT THOSE DAMAGES

CAN BE DISCLAIMED BY LAW.

Some countries/states do not allow the exclusion or limitation of

incidental or consequential damages, or limitation of the duration

of implied warranties, so the preceding limitations or exclusions

may not apply to you.

The warranty provided does not affect the consumer’s

statutory rights under applicable legislation in force, nor the

consumer’s rights against the dealer arising from their sales /

purchase contract.

*Geographical scope of the warranty

If you have purchased your Product in a country member of the

European Economic Area (EEA) or in Switzerland or the Republic

of Turkey, and such Product was intended for sale in the EEA or

in Switzerland or in Turkey, you can have your Product serviced

in any EEA country or in Switzerland or in Turkey, under the

warranty conditions prevailing in the country in which you require

servicing, provided that an identical Product is sold in such

country by an authorised Sony Ericsson distributor. To find out if

your Product is sold in the country you are in, please call the

local Sony Ericsson Contact Center. Please observe that certain

services may not be available outside the country of original

purchase, for example, due to the fact that your Product may

have an interior or exterior which is different from equivalent

models sold in other countries. Please note in addition that it

may sometimes not be possible to repair SIM-locked Products.

** In some countries/regions additional information (such as a

valid warranty card) may be requested.

Trademarks and acknowledgements

The Liquid Identity logo and Xperia are trademarks or registered

trademarks of Sony Ericsson Mobile Communications AB.

Sony is a trademark or a registered trademark of Sony

Corporation.

Ericsson is a trademark or registered trademark of

Telefonaktiebolaget LM Ericsson.

Bluetooth is a trademark or a registered trademark of Bluetooth

SIG Inc. and any use of such mark by Sony Ericsson is under

license.

Other product and company names mentioned herein may be the

trademarks of their respective owners.

Any rights not expressly granted herein are reserved.

Support

Anguilla 1-800-080-9518

(Toll Free)

questions.CO@support.sonyericsson.com

Antigua and

Barbuda

1-800-081-9518

(Toll Free)

questions.CO@support.sonyericsson.com

Argentina 0800-333-7427

(número gratuito)

questions.CO@support.sonyericsson.com

Australia 1300 650-050

(Toll Free)

questions.AU@support.sonyericsson.com

The Bahamas 1-800-205-6062

(Toll Free)

questions.CO@support.sonyericsson.com

Barbados 1-800-082-9518

(Toll Free)

questions.CO@support.sonyericsson.com

Belgique/

België

02-0745 1611 questions.BE@support.sonyericsson.com

Belize AN 815, PIN 5597

(Toll Free)

questions.CO@support.sonyericsson.com

Bermuda 1-800-083-9518

(Toll Free)

questions.CO@support.sonyericsson.com

Bolivia 800-100-542

(número gratuito)

questions.CO@support.sonyericsson.com

Brasil 4001-0444

(ligação gratuita)

questions.BR@support.sonyericsson.com

Canada 1 866 766 9374

(Toll Free / sans

frais)

questions.CA@support.sonyericsson.com

Cayman

Islands

1-800-084-9518

(Toll Free)

questions.CO@support.sonyericsson.com

Central and

Southern

Africa

+27 11 506 0123 questions.CF@support.sonyericsson.com

Česká

republika

844 550 055 questions.CZ@support.sonyericsson.com

Chile 800-646-425

(número gratuito)

questions.CO@support.sonyericsson.com

Colombia 01800-0966-080

(número gratuito)

questions.CO@support.sonyericsson.com

Costa Rica 0 800 011 0400

(número gratuito)

questions.CO@support.sonyericsson.com

Danmark 3331 2828 questions.DK@support.sonyericsson.com

Deutschland 0180 534 2020

(ortsübliche

Gebühren)

questions.DE@support.sonyericsson.com

Dominica 1-800-085-9518

(Toll Free)

questions.CO@support.sonyericsson.com

Ecuador 1-800-0102-50

(número gratuito)

questions.CO@support.sonyericsson.com

Eesti 06 032 032 questions.EE@support.sonyericsson.com

Egypt/ مصر 16727 questions.EG@support.sonyericsson.com

Ελλάδα 801 11 810 810

+30 210 899 19

19 (από κινητό

τηλέφωνο)

questions.GR@support.sonyericsson.com

El Salvador 800-6323 (número

gratuito)

questions.CO@support.sonyericsson.com

España 902 180 576

(tarifa local)

questions.ES@support.sonyericsson.com

France 09 69 32 21 21

09 69 32 21 22

(Xperia™

uniquement)

questions.FR@support.sonyericsson.com

Guatemala 1-800-300-0057

(número gratuito)

questions.CO@support.sonyericsson.com

Haïti/Ayiti AN 193, PIN 5598

(numéro gratuit /

nimewo gratis)

questions.CO@support.sonyericsson.com

Honduras AN 8000122, PIN

5599 (número

gratuito)

questions.CO@support.sonyericsson.com

Hong Kong/香

港

+852 8203 8863 questions.HK@support.sonyericsson.com

Hrvatska 062 000 000 questions.HR@support.sonyericsson.com

India/भारत 1800 11 1800 (Toll

Free)

+91 (011)

39011111

questions.IN@support.sonyericsson.com

Indonesia 021 2701388 questions.ID@support.sonyericsson.com

Ireland 1850 545 888

(Local rate)

questions.IE@support.sonyericsson.com

Italia 06 48895206

(tariffa locale)

questions.IT@support.sonyericsson.com

Jamaica 1-800-442-3471

(Toll Free)

questions.CO@support.sonyericsson.com

Κύπρος/

Kıbrıs

0800 90 909 questions.CY@support.sonyericsson.com

Latvija 67 21 43 01 questions.LV@support.sonyericsson.com

Lietuva 8 700 55030 questions.LT@support.sonyericsson.com

Magyarország 01 880 47 47 questions.HU@support.sonyericsson.com

Malaysia 1800-88-9900

(Toll Free / bebas

tol)

questions.MY@support.sonyericsson.com

Maroc/

المغرب

+212 2 2958 344 questions.MA@support.sonyericsson.com

México 0 1800 000 4722

(número gratuito)

questions.MX@support.sonyericsson.com

Nederland 0900 8998318 questions.NL@support.sonyericsson.com

Nederlandse

Antillen

001-866-509-8660

(gratis nummer)

questions.CO@support.sonyericsson.com

New Zealand 0800-100-150

(Toll Free)

questions.NZ@support.sonyericsson.com

Nicaragua AN 1800-0166,

PIN 5600 (número

gratuito)

questions.CO@support.sonyericsson.com

Norge 815 00 840

(lokaltakst)

questions.NO@support.sonyericsson.com

Österreich 0810 200 245 questions.AT@support.sonyericsson.com

Pakistan/

پاکستان

021 - 111 22 55 73 questions.PK@support.sonyericsson.com

Panamá 00800-787-0009

(número gratuito)

questions.CO@support.sonyericsson.com

Paraguay 009 800 54 20032

(número gratuito)

questions.CO@support.sonyericsson.com

Perú 0800-532-38

(número gratuito)

questions.CO@support.sonyericsson.com

Philippines/

Pilipinas

+63 2 7891860 questions.PH@support.sonyericsson.com

Polska +48 22 22 77 444 questions.PL@support.sonyericsson.com

Portugal 808 204 466

(chamada local)

questions.PT@support.sonyericsson.com

República

Dominicana

1-800-751-3370

(número gratuito)

questions.CO@support.sonyericsson.com

România +40 21 401 0401 questions.RO@support.sonyericsson.com

Saint Kitts

and Nevis

1-800-087-9518

(Toll Free)

questions.CO@support.sonyericsson.com

Saint Vincent

and the

Grenadines

1-800-088-9518

(Toll Free)

questions.CO@support.sonyericsson.com

Schweiz/

Suisse/

Svizzera

0848 824 040 questions.CH@support.sonyericsson.com

Singapore +65 6744 0733 questions.SG@support.sonyericsson.com

Slovenia 01 600 5000 questions.SI@support.sonyericsson.com

Slovensko 02 5443 6443 questions.SK@support.sonyericsson.com

South Africa 0861 632222 questions.ZA@support.sonyericsson.com

South Κorea/

대한민국

(+82) 1588 4170 questions.KO@support.sonyericsson.com

Suomi 09 299 2000 questions.FI@support.sonyericsson.com

Sverige 013 24 45 00

(lokal taxa)

questions.SE@support.sonyericsson.com

Trinidad and

Tobago

1-800-080-9521

(Toll Free)

questions.CO@support.sonyericsson.com

Türkiye +90 212 473 77 77 questions.TR@support.sonyericsson.com

United

Kingdom

08705 237 237

(Local rate)

questions.GB@support.sonyericsson.com

United States 1 866 766 9374 questions.US@support.sonyericsson.com

Uruguay 000-401-787-013

(número gratuito)

questions.CO@support.sonyericsson.com

Venezuela 0-800-1-00-2250

(número gratuito)

questions.CO@support.sonyericsson.com

Việt Nam 1900 1525 (miễn

phí)

questions.VN@support.sonyericsson.com

Беларусь 8 82 00 361 0001 questions.BY@support.sonyericsson.com

България 0800 1 8778 questions.BG@support.sonyericsson.com

Россия +7 (495) 7870986 questions.RU@support.sonyericsson.com

Україна (+380) 44 590

1515

questions.UA@support.sonyericsson.com

الأردن +971 4 3919 880 questions.JO@support.sonyericsson.com

الإمارات العربية المتحدة

+971 4 3919 880

(UAE)

questions.AE@support.sonyericsson.com

الكويت +971 4 3919 880 questions.KW@support.sonyericsson.com

المملكة العربية السعودية

800-8200-727 questions.SA@support.sonyericsson.com

中国 +86 400 810 0000 questions.CN@support.sonyericsson.com

台灣 +886 2 25625511 questions.TW@support.sonyericsson.com

ไทย 02 2483 030 questions.TH@support.sonyericsson.com

www.sonyericsson.com

Sony Ericsson Mobile Communications AB

SE-221 88 Lund, Sweden

1222-9269.2

Sony A3880049 GSM 850/900/1800/1900 GPRS / EDGE / UMTS FDD1 HSPA mobile phone with Bluetooth, FM receiver User Manual A7 42p last page indd

Sony Mobile Communications Inc GSM 850/900/1800/1900 GPRS / EDGE / UMTS FDD1 HSPA mobile phone with Bluetooth, FM receiver A7 42p last page indd

08 user manual all parts

Navigation menu

Namespaces

Views

Navigation
