Sony Ericsson

Vivaz™ pro

User guide

Please read the Important information before you use your

mobile phone.

Experience more. Discover how.

Fill it with pop and let it rock. Share your life in pictures. Or

why not go online for the latest updates? Your new phone is

the key to a wider world. And it’s just around the corner.

Get started with this User guide. And join us online to get the

full picture. Music, games, apps, updates, downloads,

support and more.

All in one place: www.sonyericsson.com/Vivazpro

Don’t forget to update your phone software. See

Updating your phone on page 8.

Help in the phone

An extended User guide is saved on your phone memory

card. You can also access this document at

www.sonyericsson.com/support. Help on most applications

is available from the Organiser in your phone.

To access the extended User guide

1Select Menu > Organiser > File manager.

2Select your memory card and then select the User guide

pdf file.

To view Help when you are in an application

•Select Options > Help.

Getting started

Assembly

Before you start using your phone, you need to insert a SIM

(Subscriber Identity Module) card and the battery.

To insert the SIM card

1Remove the battery cover.

2Put the SIM card into its holder with the gold-coloured

contacts facing down.

To insert the battery

1Insert the battery with the label side up and the

connectors facing each other.

2Put the battery cover into place.

Charging the phone

The phone battery is partly charged when you buy it. The

indicator light is on when you charge the phone.

For more information on how the indicator light

functions, see the extended User guide.

When the battery is completely discharged, it may

take several minutes before the indicator light turns

on, but the charging function will still be running.

To charge the phone using the power adapter

•Connect the phone to a power outlet using the USB cable

provided and the power adapter.

You can use your phone while it is charging. You can

charge the battery at any time and for more or less

than 3 hours using the power adapter. You can

interrupt the charging without damaging the battery.

To charge the phone using a computer

•Connect the phone to a USB port on a computer using

the USB cable provided.

Memory card

Your phone supports memory cards, adding more storage

space to your phone. A memory card used in your phone

can also be used with other compatible devices.

You can move content between your memory card and the

phone memory.

To insert or remove a memory card

1Insert the memory card with the gold-coloured contacts

facing down.

2To release and remove the memory card, press and

select Remove memory card, then press the edge of the

memory card inwards.

Turning on the phone

To turn on the phone

1Press and hold down .

2Enter your SIM card PIN, if requested, and select OK.

3The first time you turn on the phone, follow the

instructions to use the setup wizard for basic settings and

useful tips.

Updating your phone

You can update your phone to the most recent software for

optimal performance and to get the latest enhancements.

You need a USB cable and an Internet-connected PC.

To learn how, go to

www.sonyericsson.com/update

Remember to back up your phone content before

updating. To see how to back up your phone content,

see the Extended User guide pre-loaded on the

memory card. You can also access this document at

www.sonyericsson.com/support

Multitasking

Your phone lets you view and switch between all running

applications.

To view running applications

1Press and hold down the main menu key.

2To switch to a running application, tap it.

Leaving applications running in the background

increases the demand on battery power and reduces

the battery life.

To end a function

•In most cases, select Options > Exit.

To delete items

•In most applications, to delete items such as files, folders,

messages, or media files, select an item, and then select

Options > Delete.

Phone overview

1 Light sensor

2 Ear speaker

3 Connector

for USB

cable

4 3.5 mm

headset

connector

5 Slideout

keyboard

6 Touch

screen

7 End key

8 Main menu

key

9 Call key

10 On/off key

11 Tally light

12 Camera light

13 Camera

14 Volume,

digital zoom

keys

15 Video key

16 Photo key

17 Loud

speaker

Menu overview*

PlayNow™

Internet

Applications

Radio, TrackID™,

Media server, Downl.

chat apps, IM, Conv.

msgng, Web

publishing, Record

sound

Camera

Messaging

Media

Photo, Music, Video

Location services

Google Maps,

Location, Wisepilot

Contacts

Calendar

Log**

Organiser

File manager, Clock,

RoadSync

SonyEricsson Sync

Google, Search,

Notes, Dictionary,

Converter, Calculator,

Adobe PDF,

Quickoffice, Help

Settings

Personal

Profiles, Themes,

Standby

Phone

Date and time,

Language, Display,

Download settings,

Sensor settings,

Touch input,

Accessories,

Application sett.,

Phone management

Application mgr

Installed app.,

Installation files, Install

settings

Telephony

Call sett., Speed

dialling, Voicemail,

Divert calls, Call

barring

Connectivity

Network, Wi-Fi,

Bluetooth, USB,

Destinations,

Connection mgr, Data

transfer, Remote

drives, Admin.

settings

* Some menus are

operator-, network- and

subscription-dependent.

** You can use touch

functionality to scroll

between tabs in

submenus. For more

information, see

Navigation on page 15.

Icons on the

main menu may

change as the

theme changes.

Status icons

Status icons appear at the top of the screen. You can tap

status icons to view more information or change settings.

Battery fully charged

Network signal strength

Messages in the outbox

GSM available

Missed call

Handsfree connected

Call diverted

Text message received

New email received

Headphone inserted

GPS connected

Alarm activated

Bluetooth™ connected

Keylock activated

USB data transferring

Data synchronising

Flight mode activated

Secure Wi-Fi™ network connected

Wi-Fi™ network connected

3G available

HSDPA available

EGPRS available

Navigation

You can move through menus with your fingertips or with a

stylus. Tap or double-tap an item to select or open it. You

can also switch between running applications.

To access the main menu

•Press the main menu key.

To unlock the phone manually

•Press and select Unlock.

To lock the phone manually

•Press twice.

To view running applications

1Press and hold down the main menu key.

2To switch to a running application, tap it.

Leaving applications running in the background

increases the demand on battery power and reduces

the battery life.

To end a function

•In most cases, select Options > Exit.

To delete items

•In most applications, to delete items such as files, folders,

messages, or media files, select an item, and then select

Options > Delete.

Standby

After you have turned on your phone and entered your PIN,

the name of the network operator appears. This view is

called standby. Your phone is now ready to use.

To return to standby

•Press .

Default standby screen

The default standby screen provides five different standby

views:

Favourite contacts view

Twitter view

Flow view

Album view

Shortcuts view

The icon for some standby views, for example, the

Album view, may change according to the content

displayed on the standby screen.

These five views are only available when

Sony Ericsson is selected as the default standby

theme.

To change the standby screen appearance

1Select Menu > Settings > Personal > Standby.

2Change the settings:

•Shortcuts – set shortcuts to applications or

bookmarks.

•Standby theme – change the appearance of the

standby screen.

3To save your changes, select Back.

To change shortcut settings

1Tap .

2Tap .

3Select a shortcut and tap Options > Change.

4When Shortcut type: appears, select Application or

Bookmark.

5Double-tap an item.

6To save your settings, select Back.

Contacts

You can save names, phone numbers and personal

information in Contacts. Information can be saved in the

phone memory or on the SIM card.

You can synchronise your contacts using the

Sony Ericsson PC Suite.

To add a new contact

1Select Menu > Contacts.

2Tap .

3Add contact information. To close the text input window,

tap .

4Select Done.

To select which contacts to display

•Select Menu > Contacts > Options > Settings >

Contacts to display.

To copy contacts between the memory card and the SIM

card

1Select Menu > Contacts.

2Select a contact and then select Options > Mark/

Unmark > Mark.

3To mark more than one contact, repeat step 2.

4Select Options > Copy.

5Select an option.

When you copy contacts from the Phone memory to

the SIM memory, only the contact name, phone

number and email address will be saved to the SIM

card.

To find a contact

•In the search field, enter the first letters of the contact

name. The matching contact or contacts appear.

Entering text

You can enter letters, numbers and special characters using

the slideout keyboard, on-screen keyboards or handwriting

recognition. You can switch between these input methods.

Text input icons

These icons may appear in the text input window.

Tap to accept the text in the input window and

close the on-screen keyboard view

Tap to open the input options menu to change,

for example, the Writing language, or view Help

Tap to switch character cases

Tap to display numbers and symbols

, Tap to move the cursor left or right

Tap to delete a character

Tap to enter a space

Tap to insert a carriage return

Tap to change to another input method: Mini

QWERTY keyboard, Full QWERTY keyboard,

Alphanumeric keypad or Handwriting

When using Mini QWERTY keyboard, touch

and hold to move the input window around the

screen

When using handwriting recognition, tap to open

the symbol table

When using handwriting recognition, tap to

switch to number input mode

Tap to turn predictive text input modes on or off,

change the character case, and switch between

letter and number modes

When using handwriting recognition, tap to

switch character case

To copy and paste text

1Tap to place the cursor at the beginning of the text you

want to select for copying. Then drag your fingertip or

stylus to the end of the text.

2To copy the selected text, tap and select Copy.

3To paste the text within the same text field, move the

cursor to where you want the text be inserted, tap and

select Paste.

To paste the text to another text field, go to that text

field, move the cursor to where you want to insert the

text and select Options > Paste.

Media

You can manage media files in your phone or on your

memory card. You can also manage photos and video clips

in albums on the web.

Viewbar and touchbar

You can use the viewbar and touchbar to navigate through

different views and manage your media files.

•Viewbar – a bar that appears at the top of the screen (in

portrait view) after you select an application in Media.

Using this bar, you can navigate to play view, to various

list views within the same application, or to the main

Media menu.

•Touchbar – a bar at the bottom of the screen where you

can manage your media files or go back to the previous

level.

To get tips for an icon in the bars, touch and hold the

icon.

To update media libraries manually

•Tap in the touchbar.

Your media libraries update automatically when you

use Media for the first time.

To go to the play view

•Tap at the top of the screen.

To view more commands in the touchbar

•Tap in the touchbar.

Mark mode

You can mark several files and manage them in batches.

To mark media files

1When the files are in list or grid view, tap in the

touchbar.

2Tap the files to mark them.

3To exit mark mode, tap .

You can use the icons in the touchbar to manage the

files you mark.


You can view, send and manage photos in your phone and

on your memory card. You can also edit and arrange your

online photo albums.

To view a photo in full screen

1Select Menu > Media > Photo.

2Select a view option and tap a thumbnail to view the

photo.

3To view the next or previous photo, flick left or right.

To edit a photo

1When viewing a photo, tap > .

2Select Options and select an item.

Photo tags

You can manage your photos easily by creating tags for

them.

Only photos with EXIF (Exchangeable Image File

Format) info can be tagged.

To create a tag

1When viewing a photo, tap > .

2Tap , enter a new name and select OK.

3Select a tag icon.

4Select the created tag to add it to your photo.

To tag a photo

1When in play view or mark mode, tap > .

2Select a tag.

Music

You can listen to music, audiobooks, podcasts and your

recordings.

Playback controls

The following playback controls may appear in your music

player and video player:

Pause

Play

Touch and hold to rewind. Tap to go to the previous

track

Touch and hold to fast forward. Tap to go to the next

track

Additional music controls

The following music controls may appear in your music

player:

Turn on shuffle to play tracks in the current playlist

in a random order

Turn off shuffle

Repeat all tracks in the current playlist

Repeat the current track several times

Disable repeating tracks

To play music or other audio tracks

1Select Media in the touchbar of the standby screen >

Music.

2Browse for tracks in Artists, Albums, Tracks, Playlists,

Audiobooks, Podcasts and My recordings.

3Tap a track.

To change the volume

•Press the volume key up or down.

To minimise the music player

1When the music player is open, tap .

2To restore the music player on the screen, tap the

minimised album artwork.

When you minimise the music player, the album

artwork is also minimised.

Playlists

You can create playlists to organise your music. You can

add tracks and folders to a playlist. It may take a few minutes

for the phone to create a playlist.

To create a playlist

1Select Menu > Media > Music > Playlists.

2Tap New playlist.

3Enter a name and select OK.

4To add tracks, select, for example, from the viewbar

and tap .

5Select the tracks you want to add to the playlist and tap

6Select the playlist.

Video

You can browse and play video clips saved in your phone

and on your memory card.

To play a video clip

1Tap in the touchbar of the standby screen and select

Video.

2Select an option.

3Tap a video clip.

Transferring and handling

content

You can transfer and handle your content such as pictures

and music.

You are not allowed to exchange some copyright-

protected material.

Using a USB cable

You can connect your phone to a computer using a USB

cable to synchronise, transfer and back up phone content,

and to use your phone as a modem.

Before using a USB cable

Only use a USB cable supported by your phone. Do not

remove the USB cable from your phone or computer during

transfer as this may corrupt the memory card or the phone

memory.

To use mass storage

1Connect the USB cable to the phone and the computer.

2Phone: Select Mass storage.

3Computer: Wait until your memory card appears as the

external disk in Microsoft® Windows® Explorer.

4Computer: On the computer desktop, double-click the

My Computer icon.

5Computer: To view the memory card folders, double-

click the icon representing your memory card.

6Copy and paste your file, or drag and drop it, into a folder

on your computer or on your memory card.

You cannot view the transferred files in your phone

until you remove the USB cable from the phone.

PC Companion

PC Companion lets you:

•Explore content in your phone.

•Use your phone as a modem.

•Install PC Software used to synchronise, transfer and

back up phone content.

For more information, go to

www.sonyericsson.com/support.

To install PC Companion

1Connect your phone to a PC using a USB cable

supported by your phone.

2Computer: Select Mass storage.

3Computer: Wait until the memory card in your phone

appears as the external disk in Microsoft® Windows®

Explorer.

4Computer: On the computer desktop, double-click the

My Computer icon.

5Computer: To launch the PC Companion installer from

the memory card, double-click the icon representing your

memory card and double-click Startme.exe under the

folder pccompanion.

6Computer: Follow the instructions that appear.

Required operating systems

You need one of these operating systems to use

Sony Ericsson PC software:

•Microsoft® Windows Vista™

•Microsoft® Windows XP, Service Pack 3 or higher

Transferring media files

You can use Media Go™ to transfer media files from CDs

or from your computer to the memory card in your phone.

Media Go™ computer software and USB drivers are

available for download at

www.sonyericsson.com/support

Sending content to another phone

You can send content, for example, using Messaging or

using Bluetooth™ wireless technology.

File manager

You can use File manager in your phone to handle content

saved in the phone memory or on a memory card. If the

memory is full, delete some content to create space.

PlayNow™ application

When you select the PlayNow™ application, you enter the

PlayNow™ online service where you can download music,

games, ringtones, themes and wallpapers. You can preview

or listen to content before you purchase and download it to

your phone.

This service is operator-, network- and subscription-

dependent, and may not be available in all countries.

For extended functionality, you can also access the

PlayNow™ web shop on a computer from

www.sonyericsson.com/playnow. For more information, go

to www.sonyericsson.com/support.

Before you use the PlayNow™ application, you must

have the required Internet connection settings in your

phone.

To use the PlayNow™ application

1Select Menu > PlayNow™.

2Search through the PlayNow™ online service and follow

the instructions to preview and purchase content.

TrackID™ application

The TrackID™ application is a music recognition service.

You can search for the title, artist and album name of a track

you hear playing through a loudspeaker.

Before you use the TrackID™ application, you must

have the required Internet connection settings in your

phone.

To search for track information

•When you hear a track through a loudspeaker outside

your phone, select Menu > Applications > TrackID™ >

Start.

For best results, use the TrackID™ application in a

quiet area.

You get a vibrating alert when the recording is finished

or if the recording fails.

Calls

Making and receiving calls

You need to turn on your phone and be within range of a

network.

The touch screen is disabled automatically during

calls when you place your phone next to your ear.

To make a call

1Select to open the dialler and enter a phone number

(with international country code and area code, if

applicable).

2Press .

You can call numbers from your contacts and call

lists.

To end a call

•Press .

To answer a call

•Press .

To reject a call

•Press .

To change the ear speaker volume during a call

•Press the volume key up or down.

Emergency calls

Your phone supports international emergency numbers, for

example, 112 or 911. You can normally use these numbers

to make emergency calls in any country, with or without the

SIM card inserted, if you are within range of a network.

In some countries, other emergency numbers may also

be promoted. Your network operator may therefore

have saved additional local emergency numbers on the

SIM card.

Call list

You can view information about recent calls.

To call a number from the call list

1Press and select a tab.

2Select a name or a number and press .

Using the camera

Your phone has touch capture, face detection, smile

detection, light, and image stabiliser functions.

To activate the camera

•To activate the photo camera, press .

•To activate the video camera, press .

Viewfinder

1 32

1 Zoom in or out

2 Enter video mode and shoot video clips

3 Enter photo mode and take photos

To turn off the camera

•Press .

To take a photo

1To activate the camera, press .

2To use auto focus, press halfway down. begins to

blink.

3When turns green, press fully down to take the

photo. The photo is saved automatically.

To take a photo more quickly, you can skip step 2 and

press fully down.

Do not take photos when there is a strong light source

in the background. Use a support or the self timer to

avoid blurred photos.

To record a video clip

1Press .

2Press fully down to start recording.

3To stop recording, press fully down. The video is

saved automatically.

More camera features

You can touch a point on the screen to choose where the

camera should focus. The image stabiliser reduces the

impact from vibrations.

To change settings

•Activate the camera and tap .

To view information about a setting

•Tap a setting and tap .

Face detection

You can use face detection to bring an off-centre face into

focus. The camera automatically detects one face,

indicated by a white frame. The frame becomes green when

focus is locked. Focus is set to the face closest to the

camera.

To set face detection

1To activate the camera, press .

2Tap > .

Face detection is not available in Landscape,

Document or Twilight landscape scenes.

Smile detection

Smile detection is a technology that detects a person’s

smile and automatically takes the photo.

To use smile detection

1To activate the camera, press .

2Tap > .

3To start smile detection, press . blinks.

4When the face in the viewfinder smiles, stops blinking

and the photo is taken automatically.

Panorama

The panorama feature helps you take wide panorama

photos automatically. Three photos are taken sequentially

in a row and connected to each other to form a seamless

wide photo.

To take a panorama photo

1To activate the camera, press .

2Tap > . appears at the top of the

screen.

3To take the first photo, press .

4To take the second photo, move the camera left or right

until the indicator fits into and becomes fully green.

The photo is taken automatically and the direction of the

panorama is now fixed.

5To take the third photo, move the camera in the same

direction as the previous shot until the indicator fits into

and becomes fully green. The photo is taken

automatically.

Touch capture

In touch capture mode, you can touch the screen to focus

and capture a photo. A white border in the viewfinder

indicates the touchable area.

To take a photo in touch capture mode

1To activate the camera, press .

2Tap > .

3Tap within the white border to select the focus point. A

photo is then taken automatically.

Do not touch the viewfinder until you want to take a

photo.

Image stabiliser

The image stabiliser compensates for small movements of

the hand to ensure steady photos. When you turn on this

function, appears in the viewfinder.

To activate the image stabiliser

1Activate the camera.

2Tap .

3Select Photo > Image stabiliser > On.

Messaging

Text and multimedia messages

Messages can contain text, pictures, sound effects, video

clips and presentations. You can also create and use

templates for your messages.

When sending messages, the phone automatically selects

the most suitable method to use (either a text or multimedia

message) for sending the message.

To create and send a message

1Select Menu > Messaging > New message.

2Tap the To field and select a contact name from

Contacts.

3Tap OK.

4Tap the text field and enter your text.

5Select Options > Add content and add a picture, video

clip or sound.

6To send the message, select .

When you enter the phone numbers of multiple

recipients manually, use a semicolon to separate their

numbers.

Internet

Before you use the Internet, you may need to define

an access point. To see how to create a new access

point, see the Extended User guide on the memory

card. You can also access this document at

www.sonyericsson.com/support

To start the Internet browser

1Select Menu > Internet.

2Tap , and enter a web address.

3Select Go to.

Location services

Your phone has a GPS receiver that uses satellite signals to

calculate your location. You can get help to find your way

to a destination and save your favourite locations. With

information from mobile towers near you, you may be able

to view your approximate location on a map.

To access location services

•Select Menu > Location services, and select an

application.

Sony Ericsson does not warrant the accuracy of any

location services, including but not limited to

navigational services.

Using GPS

Your location can be found when you have a clear view of

the sky. If your location is not found after a few minutes,

move to another location. To help the search, stand still and

do not cover the GPS antenna, which is located in the upper

right part of the phone.

Some GPS features use the Internet. Data rates and

charges may apply.

Locks

SIM card lock

This lock only protects your subscription. Your phone will

work with a new SIM card. If the lock is on, you have to enter

a PIN.

The PIN2 is required to access some network services, and

your SIM card must support these services.

If you enter your PIN incorrectly three times in a row, the SIM

card is blocked and you need to enter your PUK (Personal

Unblocking Key). Your PIN, PIN2 and PUK are supplied by

your network operator.

To unblock your SIM card

1When PIN blocked. Enter PUK: appears, enter your

PUK and select OK.

2Enter a new four-to-eight-digit PIN and select OK.

3Re-enter the new PIN and select OK.

To turn on the SIM card lock

1Select Menu > Settings > Phone > Phone

management > Security > Phone and SIM card > PIN

code request > On.

2Enter your PIN and select OK.

To edit your PIN

1Select Menu > Settings > Phone > Phone

management > Security > Phone and SIM card > PIN

code.

2Follow the instructions to enter your old PIN once and

new PIN twice.

Phone lock

You can stop unauthorised use of your phone. The default

phone lock code is 0000. You can change the phone lock

code to any four-to-eight-digit personal code.

When the touch screen and keys are locked, the touch

screen and the keys are inactive.

It is important that you remember your new code. If you

forget it, you need to take your phone to your local

Sony Ericsson retailer.

To turn on the phone lock

1Select Menu > Settings > Phone > Phone

management > Security > Phone and SIM card >

Phone autolock period > User defined.

2To automatically lock your phone when you do not use it

for a defined time, tap the text input field under Lock after

(minutes): and enter the time-out period.

3Enter your phone lock code and select OK.

4To unblock the phone, press and follow the

instructions that appear.

To edit your phone lock code

1Select Menu > Settings > Phone > Phone

management > Security > Phone and SIM card > Lock

code.

2Follow the instructions to enter your old lock code once

and your new lock code twice.

Legal information

Sony Ericsson Vivaz™ pro U8i/U8a

This User guide is published by Sony Ericsson Mobile Communications

AB or its local affiliated company, without any warranty. Improvements

and changes to this User guide necessitated by typographical errors,

inaccuracies of current information, or improvements to programs and/

or equipment, may be made by Sony Ericsson Mobile Communications

AB at any time and without notice. Such changes will, however, be

incorporated into new editions of this User guide.

©Sony Ericsson Mobile Communications AB, 2010

Publication number: 1234-4886.1

Your mobile phone has the capability to download, store and forward

additional content, e.g. ringtones. The use of such content may be

restricted or prohibited by rights of third parties, including but not limited

to restriction under applicable copyright laws. You, and not

Sony Ericsson, are entirely responsible for additional content that you

download to or forward from your mobile phone. Prior to your use of any

additional content, please verify that your intended use is properly

licensed or is otherwise authorized. Sony Ericsson does not guarantee

the accuracy, integrity or quality of any additional content or any other

third party content. Under no circumstances will Sony Ericsson be liable

in any way for your improper use of additional content or other third party

content.

This User guide may reference services or applications provided by third

parties. Use of such programming or services may require separate

registration with the third party provider and may be subject to additional

website, please review such website’s terms of use and applicable

the availability or performance of any third-party websites or offered

services.

Bluetooth is a trademark or a registered trademark of Bluetooth SIG Inc.

and any use of such mark by Sony Ericsson is under license.

The Liquid Identity logo, Vivaz, PlayNow and TrackID are trademarks or

registered trademarks of Sony Ericsson Mobile Communications AB.

TrackID™ is powered by Gracenote Mobile MusicID™. Gracenote and

Gracenote Mobile MusicID are trademarks or registered trademarks of

Gracenote, Inc.

SyncML is a trademark or registered trademark of the Open Mobile

Alliance, Ltd.

Twitter and the Twitter T are trademarks or registered trademarks of

Twitter, Inc.

Sony and make.believe are trademarks or registered trademarks of Sony

Corporation.

Media Go is a trademark or registered trademark of Sony Media Software

and Services.

Wi-Fi is a trademark or a registered trademark of the Wi-Fi Alliance.

DLNA is a trademark or registered trademark of the Digital Living Network

Alliance.

Google™, Google Maps™, YouTube and the YouTube logo are

trademarks or registered trademarks of Google, Inc.

Ericsson is a trademark or registered trademark of Telefonaktiebolaget

LM Ericsson.

Microsoft, Windows and Vista are registered trademarks or trademarks

of Microsoft Corporation in the United States and/or other countries.

microSD is a trademark or a registered trademark of SanDisk

Corporation.

RoadSync is a trademark or registered trademark of DataViz, Inc.

Quickoffice is a registered trademark of Quickoffice, Inc.

Wisepilot is a registered trademark of Appello Systems AB.

Adobe and Flash are trademarks or registered trademarks of Adobe

Systems Incorporated in the United States and/or other countries.

This product is protected by certain intellectual property rights of

Microsoft. Use or distribution of such technology outside of this product

is prohibited without a license from Microsoft.

Other product and company names mentioned herein may be the

trademarks of their respective owners.

Any rights not expressly granted herein are reserved.

All illustrations are for illustration only and may not accurately depict the

actual phone.

www.sonyericsson.com

Sony Ericsson Mobile Communications AB

SE-221 88 Lund, Sweden

1234-4886.1

www.sonyericsson.com

Sony Ericsson Mobile Communications AB

SE-221 88 Lund, Sweden

April 13, 2010 18:27:33

1235-6329.1

Important Information

United States & Canada

THIS PHONE MODEL HAS BEEN CERTIFIED IN COMPLIANCE

WITH THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE

TO RADIO WAVES.

The Series mobile phones have been designed to comply with

applicable safety requirements for exposure to radio waves. Your

wireless phone is a radio transmitter and receiver. It is designed to

not exceed the limits* of exposure to radio frequency (RF) energy

set by governmental authorities. These limits establish permitted

levels of RF energy for the general population. The guidelines are

based on standards that were developed by international scientific

organizations through periodic and thorough evaluation of

scientific studies. The standards include a safety margin designed

to assure the safety of all individuals, regardless of age and

health.

The radio wave exposure guidelines employ a unit of

measurement known as the Specific Absorption Rate (SAR). Tests

for SAR are conducted using standardized methods with the

phone transmitting at its highest certified power level in all used

frequency bands. While there may be differences between the SAR

levels of various phone models, they are all designed to meet the

relevant guidelines for exposure to radio waves. For more

information on SAR, please refer to the safe and efficient use

chapter in the User Guide.

The highest SAR value as reported to the authorities for this

phone model when tested for use by the ear is 1.05 W/kg*, and

when worn on the body is 0.59 W/kg* for speech and 0.94 W/kg*

for data calls. Body worn measurements are made while the phone

is in use and worn on the body with a Sony Ericsson accessory

supplied with or designated for use with this phone. It is therefore

recommended that only Ericsson and Sony Ericsson original

accessories be used in conjunction with Sony Ericsson phones.

**Before a phone model is available for sale to the public in the

US, it must be tested and certified by the Federal Communications

Commission (FCC) that it does not exceed the limit established by

April 13, 2010 18:27:32

Renseignements importants

États-Unis et Canada

CE MODÈLE DE TÉLÉPHONE A ÉTÉ CERTIFIÉ CONFORME AUX

EXIGENCES GOUVERNEMENTALES RELATIVES À L'EXPOSITION

AUX ONDES RADIOÉLECTRIQUES.

Les téléphones mobiles ont été conçus pour répondre aux

normes de sécurité en vigueur en matière d'exposition aux ondes

radioélectriques. Votre téléphone sans fil est un émetteur et un

récepteur radio. Il est conçu de manière à ne pas dépasser les

limites* d'exposition aux signaux radiofréquences (RF) établies par

les autorités gouvernementales. Ces limites fixent les niveaux

maximaux d'énergie radiofréquence auxquels peut être soumis le

grand public. Ces lignes directrices sont basées sur des normes

qui ont été élaborées par des organisations scientifiques

internationales par le biais d'évaluations périodiques et

approfondies des études scientifiques. Ces normes prévoient une

marge de sécurité visant à assurer la protection de toutes les

personnes, quels que soient leur âge et leur état de santé.

Les lignes directrices relatives à l'exposition aux ondes

radioélectriques utilisent une unité de mesure appelée "Débit

d'absorption spécifique" (SAR). Les tests de SAR sont effectués

selon des méthodes standardisées dans lesquelles le téléphone

émet dans toutes les bandes de fréquences utilisées, à la plus

forte puissance pour laquelle il a été homologué. Bien que le débit

d'absorption spécifique puisse être différent d'un modèle de

téléphone à un autre, tous les appareils sont conçus pour

respecter les lignes directrices relatives aux ondes

radioélectriques. Pour en savoir plus sur le débit d'absorption

spécifique, reportez-vous au chapitre sur l'utilisation efficace et

sans danger de ce présent guide.

Le débit d'absorption spécifique le plus élevé relevé par les

autorités pour ce modèle de téléphone est de 1,05 W/kg* lorsqu'il

est testé en utilisation près de l'oreille, et de 0,59 W/kg* (pour les

appels vocaux) et de 0,94 W/kg* (pour les appels de données)

lorsqu'il est porté sur le corps. Lors des mesures de port sur le

corps, le téléphone était maintenu par un accessoire Sony

April 13, 2010 18:27:32

Información importante

Estados Unidos y Canadá

ESTE MODELO DE TELÉFONO HA SIDO CERTIFICADO Y

CUMPLE CON LOS REQUISITOS GUBERNAMENTALES DE

EXPOSICIÓN A LAS ONDAS DE RADIO.

El teléfono móvil ha sido diseñado para cumplir con los

requisitos de seguridad aplicables de exposición a las ondas de

radio. El teléfono inalámbrico es un transmisor y receptor de radio.

Está diseñado para no superar los límites* de exposición a la

energía de radiofrecuencia (RF) establecidos por las autoridades

gubernamentales. Estos límites establecen los niveles permitidos

de energía de RF para la población en general. Las

especificaciones se basan en los estándares desarrollados por

organizaciones científicas internacionales mediante una

evaluación periódica y minuciosa de estudios científicos. Estos

estándares incluyen un margen de seguridad destinado a

garantizar la seguridad de todas las personas,

independientemente de su edad y condición de salud.

Las especificaciones de exposición a las ondas de radio

emplean una unidad de medición conocida como Tasa específica

de absorción (SAR). Las pruebas de SAR se realizan usando

métodos estandarizados mientras el teléfono transmite al nivel de

potencia más alto certificado en todas las bandas de frecuencia

utilizadas. Si bien puede haber diferencias entre los niveles de SAR

de diversos modelos de teléfono, todos los teléfonos han sido

diseñados para cumplir con las especificaciones pertinentes de

exposición a las ondas de radio. Para obtener más información

acerca de SAR, consulte el capítulo sobre uso seguro y eficaz en la

Guía del usuario.

El mayor valor SAR según lo informado a las autoridades para

este teléfono cuando se evaluó para su uso cerca del oído fue de

1,05 W/kg*, y cuando se utilizó cerca del cuerpo fue de 0,59 W/kg*

para llamadas de voz y 0,94 W/kg* para llamadas de datos. Las

mediciones para el uso cerca del cuerpo se realizan mientras el

teléfono está en uso y ubicado cerca del cuerpo con un accesorio

Sony Ericsson proporcionado con el teléfono o diseñado para su

April 13, 2010 18:27:32

FCC Statement

Declaration of Conformity

Sony Ericsson U8i

UMTS HSPA band 1 8 GSM GPRS/EDGE 850/900/1800/1900

April 13, 2010 18:27:32

the government-adopted requirement for safe exposure*. The

tests are performed in positions and locations (i.e., by the ear and

worn on the body) as required by the FCC for each model. The FCC

has granted an Equipment Authorization for this phone model with

all reported SAR levels evaluated as in compliance with the FCC RF

exposure guidelines. While there may be differences between the

SAR levels of various phones, all mobile phones granted an FCC

equipment authorization meet the government requirement for

safe exposure. SAR information on this phone model is on file at

the FCC and can be found under the Display Grant section of

http://www.fcc.gov/oet/fccid after searching on FCC

ID PY7A3880077. Additional information on SAR can be found on

the Cellular Telecommunications & Internet Association (CTIA)

website at http://www.phonefacts.net.

* In the United States and Canada, the SAR limit for mobile

phones used by the public is 1.6 watts/kilogram (W/kg) averaged

over one gram of tissue. The standard incorporates a margin of

safety to give additional protection for the public and to account

for any variations in measurements.

**This paragraph is only applicable to authorities and customers

in the United States.

April 13, 2010 18:27:32

Ericsson fourni avec ce téléphone ou conçu pour être utilisé avec

l'appareil. Il est par conséquent recommandé de n'utiliser que les

accessoires authentiques Ericsson et Sony Ericsson avec les

téléphones Sony Ericsson.

**Avant qu'un modèle de téléphone ne soit offert au public aux

États-Unis, la FCC (Federal Communications Commission) doit le

tester et certifier qu'il respecte les limites fixées dans les exigences

gouvernementales d'exposition sans danger*. Pour chaque

modèle, les tests sont effectués en position et aux endroits

d'usage (c'est-à- dire près de l'oreille et porté sur le corps), tel que

l'exige la FCC. La FCC a accordé une autorisation d'équipement

(Equipment Authorization) pour ce modèle de téléphone, après

que tous les débits d'absorption spécifique indiqués aient été

évalués et considérés conformes aux lignes directrices de la FCC

en matière d'exposition aux radiofréquences. Même s'il peut y

avoir des différences entre les niveaux de SAR des différents

téléphones, tous les téléphones mobiles auxquels la FCC a

accordé une autorisation d'équipement répondent aux normes

gouvernementales en matière d'exposition sans danger. La FCC

conserve dans ses dossiers l'information relative aux débits

d'absorption spécifique relevés pour ce modèle de téléphone.

Vous pouvez la consulter au http://www.fcc.gov/oet/fccid, sous la

rubrique "Display Grant ", après avoir effectué une recherche sur

FCC ID PY7A3880077 . Vous trouverez des renseignements

supplémentaires concernant le débit d'absorption spécifique

(SAR) sur le site Web de la Cellular Telecommunications & Internet

Association (CTIA) au http://www.phonefacts.net.

*Aux États-Unis et au Canada, la limite de débit d'absorption

spécifique (SAR) des téléphones mobiles utilisés par le public est

de 1,6 watt/kg (W/kg) en moyenne sur un gramme de tissus. Cette

norme comporte une marge importante de sécurité afin d'assurer

une protection supplémentaire et de tenir compte de toute

variation dans les mesures.

**Ce paragraphe ne concerne que les autorités et les clients des

États-Unis.

April 13, 2010 18:27:32

uso con este teléfono. Por lo tanto, se recomienda utilizar sólo

accesorios originales Ericsson y Sony Ericsson en conjunto con los

teléfonos Sony Ericsson.

**Antes de que un modelo de teléfono esté disponible para la

venta al público en los EE.UU., se debe probar y certificar ante la

Comisión Federal de Comunicaciones (FCC) que no supera el

límite establecido por los requisitos gubernamentales de

exposición segura*. Las pruebas se realizan en las posiciones y

lugares (es decir, en el oído y cerca del cuerpo) exigidos por la FCC

para cada modelo. La FCC ha otorgado una Autorización de

equipo para este modelo de teléfono con todos los niveles SAR

informados y que han sido evaluados en cumplimiento con las

especificaciones de exposición de RF de la FCC. Si bien puede

haber diferencias en los niveles SAR entre distintos modelos de

teléfonos móviles, todos los teléfonos móviles que han recibido

una autorización de equipo de la FCC cumplen con los requisitos

gubernamentales de exposición segura. La información de SAR

acerca de este modelo de teléfono está archivada en la FCC y se

puede encontrar en la sección Display Grant de

http://www.fcc.gov/oet/fccid luego de buscar en FCC

ID PY7A3880077. Si desea información adicional acerca de SAR,

puede encontrarla en el sitio Web de la Asociación de

Telecomunicaciones Celulares e Internet (CTIA, Cellular

Telecommunications & Internet Association) en la dirección

http://www.phonefacts.net.

* En los Estados Unidos y Canadá, el límite SAR para teléfonos

móviles utilizados por el público es de 1,6 watts/kilogramo (W/kg)

promediado sobre un gramo de tejido. El estándar incorpora un

margen de seguridad para entregar protección adicional al público

y para representar las variaciones en las mediciones.

**Este párrafo sólo es aplicable a las autoridades y clientes en

los Estados Unidos.

April 13, 2010 18:27:32

April 14, 2010 09:59:49

Important Information

Latin & South America

Radio wave exposure and Specific Absorption Rate (SAR)

information

The Series mobile phones have been designed to comply with

applicable safety requirements for exposure to radio waves. These

requirements are based on scientific guidelines that include safety

margins designed to assure the safety of all persons, regardless of

age and health.

The radio wave exposure guidelines employ a unit of

measurement known as the Specific Absorption Rate, or SAR.

Tests for SAR are conducted using standardised methods with the

phone transmitting at its highest certified power level in all used

frequency bands.

While there may be differences between the SAR levels of

various phone models, they are all designed to meet the relevant

guidelines for exposure to radio waves.

For more information on SAR, please refer to the safety chapter

in the User Guide.

SAR data information for residents in countries that have

adopted the SAR limit recommended by the International

Commission on Non-Ionizing Radiation Protection (ICNIRP), which

is 2 W/kg averaged over ten (10) gram of tissue (for example

European Union, Japan, Brazil and New Zealand):

The highest SAR value for this model phone when tested by

Sony Ericsson for use at the ear is 1.03 W/kg (10g).

April 13, 2010 18:27:33

Informação importante

América do Sul e Latina

Informações sobre SAR (Taxa de Absorção Específica) e

exposição à radiofreqüência

O celular foi projetado para cumprir os requisitos de segurança

aplicáveis para exposição à radiofreqüência. Esses requisitos têm

como base diretrizes científicas que incluem as margens de

segurança para garantir a segurança de todas as pessoas,

independentemente da idade e da saúde.

As diretrizes de exposição à radiofreqüência usam uma unidade

de medida conhecida como SAR ou Taxa de Absorção Específica.

Os testes de SAR são conduzidos por métodos padronizados com

a transmissão telefônica em seu nível certificado de energia mais

alto em todas as faixas de freqüência usadas.

Embora possa haver diferenças entre os níveis de SAR de vários

modelos de telefone, todos foram projetados para atender as

diretrizes relevantes de exposição à radiofreqüência.

Para obter mais informações sobre SAR, consulte o capítulo de

segurança do Guia do Usuário.

Informações sobre os dados de SAR para moradores de países

que adotaram o limite SAR recomendado pelo ICNIRP

(International Commission on Non-Ionizing Radiation Protection)

que é o limite médio de 2 W/kg em dez (10) gramas de tecido (por

exemplo, União Européia, Japão, Brasil e Nova Zelândia).

Quando testado pela Sony Ericsson, o valor de SAR mais alto

para este modelo de telefone para uso junto ao ouvido foi de

1,03 W/kg (10g).

April 13, 2010 18:27:33

Industry Canada Statement

This device complies with RSS-210 of Industry Canada.

Operation is subject to the following two conditions: (1) this

device may not cause interference, and (2) this device must accept

any interference, including interference that may cause undesired

operation of the device.

This Class B digital apparatus complies with Canadian

ICES-003.

Cet appareil numérique de la classe B est conforme à la norme

NMB-003 du Canada.

April 13, 2010 18:27:33

�� 8� 201016�38�49

Información importante

Latinoamérica y América del Sur

Información acerca de la exposición a ondas de radio y la

Tasa específica de absorción (SAR)

El teléfono móvil ha sido diseñado para cumplir con los

requisitos de seguridad aplicables de exposición a las ondas de

radio. Dichos requisitos se basan en directrices científicas que

establecen márgenes de seguridad con el fin de evitar perjuicos a

todas las personas, independientemente de su edad o estado de

salud.

Las directrices de exposición a ondas de radio utilizan una

unidad de medida denominada coeficiente de absorción específica

o SAR. Las pruebas de SAR se líevan a cabo utilizando métodos

normalizados, con el teléfono transmitiendo en el nivel más

elevado de potencia autoridado en todas las bandas de frecuencia

utilizadas.

Aunque puede existir diferencias entre los niveles de SAR de

diferentes modelos de teléfono, todos han sido diseñados para

cumplir las directrices pertinentes sobre exposición a ondas de

radio.

Para obtener más información sobre el SAR, consulte el capítulo

sobre seguridad en la guía del usuario.

Información sobre datos de SAR para residentes de países en

los que se haya adoptado el limite de SAR recomendado por la

International Commission on Non-Ionizing Radiation Protection

(ICNIRP, Comisión internacional de protección contra la radiación

no ionizantes (ICNIRP, International Commission on Non-Ionizing

Radiation Protection), es 2 W/kg promedio por cada

diez (10) gramos de tejido (por ejemplo, la Unión Europea, Japón,

Brasil y Nueva Zelanda):

El valor de SAR más elevado para este modelo de teléfono

cuando Sony Ericsson realizó la prueba para su uso en la oreja era

de 1,03 W/kg (10g).

April 13, 2010 18:27:33

FCC Statement

This device complies with Part 15 of the FCC rules.

Operation is subject to the following two conditions: (1)

This device may not cause harmful interference, and (2)

This device must accept any interference received, including

interference that may cause undesired operation.

Any change or modification not expressly approved by Sony

Ericsson may void the user's authority to operate the equipment.

This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a

particular installation.

If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from

that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for

help.

April 13, 2010 18:27:33

Declaration of Conformity for U8i

We, Sony Ericsson Mobile Communications AB of

Nya Vattentornet

SE-221 88 Lund, Sweden

declare under our sole responsibility that our product

Sony Ericsson type AAD-3880077-BV

and in combination with our accessories, to which this declaration

relates is in conformity with the appropriate standards EN 301

511:V9.0.2, EN 301 908-1:V3.2.1, EN 301 908-2:V3.2.1, EN 300

440-2:V1.3.1, EN 300 328:V1.7.1, EN 301 489-7:V1.3.1, EN 301

489-17:V2.1.1, EN 301 489-24:V1.4.1, EN 301 489-3:V1.4.1 and

EN 60 950-1:2006 following the provisions of, Radio Equipment

and Telecommunication Terminal Equipment directive 1999/5/EC.

Lund, April 2010

Dan Redin,

Corporate Vice President, Head of Development

We fulfil the requirements of the R&TTE Directive (1999/5/EC).

Ce produit est conforme aux directives de R&TTE (1999/5/EC).

Cumplimos con los requisitos de la Directiva R&TTE – Normas

sobre equipos de terminales de radio y telecomunicaciones (1999/

5/EC).

Atendemos aos requisitos da Diretriz R&TTE (1999/5/EC).

April 13, 2010 18:27:33

�� 8� 201016�38�49

April 14, 2010 09:59:50

Important information

Sony Ericsson Consumer Web site

At www.sonyericsson.com/support there is a support section

where help and tips are only a few clicks away. Here you will find

the latest computer software updates and tips on how to use

your product more efficiently.

Service and support

You have access to a portfolio of exclusive service advantages

such as:

•Global and local Web sites providing support.

•A global network of Contact Centers.

•An extensive network of Sony Ericsson service partners.

•A warranty period. Learn more about the warranty conditions in

theLimited warrantysection.

At www.sonyericsson.com/support, you can find the latest

support tools and information. For operator-specific services and

features, please contact your network operator.

You can also contact our Contact Centers. If your country/

region is not represented in the list below, please contact your

local dealer. (Calls are charged according to national rates,

including local taxes, unless the phone number is a toll-free

number.)

If your product needs service, please contact the dealer from

whom it was purchased, or one of our service partners. For

warranty claims, save proof of purchase.

Guidelines for Safe and Efficient Use

Please follow these guidelines. Failure to do so might

entail a potential health risk or product malfunction. If in

doubt as to its proper function, have the product

checked by a certified service partner before charging

or using it.

Recommendations for care and safe use of our products

•Handle with care and keep in a clean and dust-free place.

•Warning! May explode if disposed of in fire.

•Do not expose to liquid or moisture or excess humidity.

•For optimum performance, the product should not

be operated in temperatures below -10°C(+14°F) or

above +45°C(+113°F). Do not expose the battery to

temperatures above +60°C(+140°F).

•Do not expose to flames or lit tobacco products.

•Do not drop, throw or try to bend the product.

•Do not paint or attempt to disassemble or modify the

product. Only Sony Ericsson authorised personnel

should perform service.

•Consult with authorised medical staff and the

instructions of the medical device manufacturer

before using the product near pacemakers or other medical

devices or equipment.

•Discontinue use of electronic devices, or disable the radio

transmitting functionality of the device, where required or

requested to do so.

•Do not use where a potentially explosive atmosphere exists.

•Do not place the product, or install wireless equipment, in the

area above an air bag in a car.

•Caution: Cracked or broken displays may create sharp edges

or splinters that could be harmful upon contact.

•Do not use the Bluetooth Headset in positions where it is

uncomfortable or will be subject to pressure.

Children

Warning! Keep out of the reach of children. Do not

allow children to play with mobile phones or

accessories. They could hurt themselves or others.

Products may contain small parts that could become detached

and create a choking hazard.

Power supply (Charger)

Connect the charger to power sources as marked on the

product. Do not use outdoors or in damp areas. Do not alter or

subject the cord to damage or stress. Unplug the unit before

cleaning it. Never alter the plug. If it does not fit into the outlet,

have a proper outlet installed by an electrician. When a power

supply is connected there is a small drain of power. To avoid this

small energy waste, disconnect the power supply when the

product is fully charged. Use of charging devices that are not

Sony Ericsson branded may pose increased safety risks.

Battery

New or idle batteries can have short-term reduced capacity.

Fully charge the battery before initial use. Use for the intended

purpose only. Charge the battery in temperatures between

+5°C(+41°F) and +45°C(+113°F). Do not put the battery into

your mouth. Do not let the battery contacts touch another metal

object. Turn off the product before removing the battery.

Performance depends on temperatures, signal strength, usage

patterns, features selected and voice or data transmissions. Only

Sony Ericsson service partners should remove or replace built-in

batteries. Use of batteries that are not Sony Ericsson branded

may pose increased safety risks. Replace the battery only with

another Sony Ericsson battery that has been qualified with the

product per the standard IEEE-1725. Use of an unqualified

battery may present a risk of fire, explosion, leakage or other

hazard.

Personal medical devices

Mobile phones may affect implanted medical equipment. Reduce

risk of interference by keeping a minimum distance of

15 cm(6 inches) between the phone and the device. Use the

phone at your right ear. Do not carry the phone in your breast

pocket. Turn off the phone if you suspect interference. For all

medical devices, consult a physician and the manufacturer.

Driving

Some vehicle manufacturers forbid the use of phones in their

vehicles unless a handsfree kit with an external antenna supports

the installation. Check with the vehicle manufacturer's

representative to be sure that the mobile phone or Bluetooth

handsfree will not affect the electronic systems in the vehicle.

Full attention should be given to driving at all times and local

laws and regulations restricting the use of wireless devices while

driving must be observed.

GPS/Location based functions

Some products provide GPS/Location based functions. Location

determining functionality is provided “As is” and “With all faults”.

Sony Ericsson does not make any representation or warranty as

to the accuracy of such location information.

Use of location-based information by the device may not be

uninterrupted or error free and may additionally be dependent on

network service availability. Please note that functionality may be

reduced or prevented in certain environments such as building

interiors or areas adjacent to buildings.

Caution: Do not use GPS functionality in a manner which

causes distraction from driving.

Emergency calls

Calls cannot be guaranteed under all conditions. Never rely

solely upon mobile phones for essential communication. Calls

may not be possible in all areas, on all networks, or when certain

network services and/or phone features are used.

Antenna

Use of antenna devices not marketed by Sony Ericsson could

damage the phone, reduce performance, and produce SAR

levels above the established limits. Do not cover the antenna

with your hand as this affects call quality, power levels and can

shorten talk and standby times.

Radio Frequency (RF) exposure and Specific Absorption

Rate (SAR)

When the phone or Bluetooth handsfree is turned on, it emits

low levels of radio frequency energy. International safety

guidelines have been developed through periodic and thorough

evaluation of scientific studies. These guidelines establish

permitted levels of radio wave exposure. The guidelines include a

safety margin designed to assure the safety of all persons and to

account for any variations in measurements.

Specific Absorption Rate (SAR) is used to measure radio

frequency energy absorbed by the body when using a mobile

phone. The SAR value is determined at the highest certified

power level in laboratory conditions, but because the phone is

designed to use the minimum power necessary to access the

chosen network, the actual SAR level can be well below this

value. There is no proof of difference in safety based on

difference in SAR value.

Products with radio transmitters sold in the US must be

certified by the Federal Communications Commission (FCC).

When required, tests are performed when the phone is placed at

the ear and when worn on the body. For body-worn operation,

the phone has been tested when positioned a minimum of

15 mm from the body without any metal parts in the vicinity of

the phone or when properly used with an appropriate

Sony Ericsson accessory and worn on the body.

For more information about SAR and radio frequency

exposure, go to: www.sonyericsson.com/health.

Flight mode

Bluetooth and WLAN functionality, if available in the device, can

be enabled in Flight mode but may be prohibited onboard aircraft

or in other areas where radio transmissions are prohibited. In

such environments, please seek proper authorisation before

enabling Bluetooth or WLAN functionality even in Flight mode.

Malware

Malware (short for malicious software) is software that can harm

the mobile phone or other computers. Malware or harmful

applications can include viruses, worms, spyware, and other

unwanted programs. While the device does employ security

measures to resist such efforts, Sony Ericsson does not warrant

or represent that the device will be impervious to the introduction

of malware. You can however reduce the risk of malware attacks

by using care when downloading content or accepting

applications, refraining from opening or responding to messages

from unknown sources, using trustworthy services to access the

Internet, and only downloading content to the mobile phone from

known, reliable sources.

Accessories

Use only Sony Ericsson branded original accessories and

certified service partners. Sony Ericsson does not test third-party

accessories. Accessories may influence RF exposure, radio

performance, loudness, electric safety and other areas. Third-

party accessories and parts may pose a risk to your health or

safety or decrease performance.

Accessible Solutions/Special Needs

In the US, compatible Sony Ericsson phones may offer

compatibility with TTY terminals (with use of necessary

accessory). For more information call the Sony Ericsson Special

Needs Center on 877 878 1996 (TTY) or 877 207 2056 (voice),

or go to www.sonyericsson-snc.com.

Disposal of old electrical and electronic

equipment

Electronic equipment and batteries should not be

included as household waste but should be left at an

appropriate collection point for recycling. This helps prevent

potential negative consequences for the environment and human

health. Check local regulations by contacting your local city

office, your household waste disposal service, the shop where

you purchased the product or calling a Sony Ericsson Contact

Center. Do not attempt to remove internal batteries. Internal

batteries shall be removed only by a waste treatment facility or

trained service professional.

Disposing of the battery

Check local regulations or call a Sony Ericsson Contact

Center for information. Never use municipal waste.

Memory card

If the product comes complete with a removable memory card, it

is generally compatible with the handset purchased but may not

be compatible with other devices or the capabilities of their

memory cards. Check other devices for compatibility before

purchase or use. If the product is equipped with a memory card

reader, check memory card compatibility before purchase or use.

Memory cards are generally formatted prior to shipping. To

reformat the memory card, use a compatible device. Do not use

the standard operating system format when formatting the

memory card on a PC. For details, refer to the operating

instructions of the device or contact customer support.

Warning!

If the device requires an adapter for insertion into the handset or

another device, do not insert the card directly without the

required adapter.

Precautions on memory card use

•Do not expose the memory card to moisture.

•Do not touch terminal connections with your hand or any metal

object.

•Do not strike, bend, or drop the memory card.

•Do not attempt to disassemble or modify the memory card.

•Do not use or store the memory card in humid or corrosive

locations or in excessive heat such as a closed car in summer,

in direct sunlight or near a heater, etc.

•Do not press or bend the end of the memory card adapter with

excessive force.

•Do not let dirt, dust, or foreign objects get into the insert port

of any memory card adapter.

•Check you have inserted the memory card correctly.

•Insert the memory card as far as it will go into any memory

card adapter needed. The memory card may not operate

properly unless fully inserted.

•We recommend that you make a backup copy of important

data. We are not responsible for any loss or damage to content

you store on the memory card.

•Recorded data may be damaged or lost when you remove the

memory card or memory card adapter, turn off the power while

formatting, reading or writing data, or use the memory card in

locations subject to static electricity or high electrical field

emissions.

Protection of personal information

Erase personal data before disposing of the product. To delete

data, perform a master reset. Deleting data from the phone

memory does not ensure that it cannot be recovered.

Sony Ericsson does not warrant against recovery of information

and does not assume responsibility for disclosure of any

information even after a master reset.

Loudness warning!

Avoid volume levels that may be harmful to your hearing.

End User Licence Agreement

Software delivered with this device and its media is owned by

Sony Ericsson Mobile Communications AB, and/or its affiliated

companies and its suppliers and licensors.

Sony Ericsson grants you a non-exclusive limited licence to

use the Software solely in conjunction with the Device on which

it is installed or delivered. Ownership of the Software is not sold,

transferred or otherwise conveyed.

Do not use any means to discover the source code or any

component of the Software, reproduce and distribute the

Software, or modify the Software. You are entitled to transfer

rights and obligations to the Software to a third party, solely

together with the Device with which you received the Software,

provided the third party agrees in writing to be bound by the

terms of this Licence.

This licence exists throughout the useful life of this Device. It

can be terminated by transferring your rights to the Device to a

third party in writing.

Failure to comply with any of these terms and conditions will

terminate the licence immediately.

Sony Ericsson and its third party suppliers and licensors retain

all rights, title and interest in and to the Software. To the extent

that the Software contains material or code of a third party, such

third parties shall be beneficiaries of these terms.

This licence is governed by the laws of Sweden. When

applicable, the foregoing applies to statutory consumer rights.

In the event Software accompanying or provided in

conjunction with your device is provided with additional terms

and conditions, such provisions shall also govern your

possession and usage of the Software.

Export regulations

Export regulations: This product, including any software or

technical data contained in or accompanying the product, may

be subject to import and export regulations of the European

Union, the United States and other countries. The user and any

possessor of the product agrees to comply strictly with all such

regulations and acknowledges that it is their responsibility to

obtain any required licenses to export, re-export, or import this

product. Without limiting the foregoing, and as an example, the

user and any possessor of the product: (1) must not knowingly

export or re-export Products to destinations identified pursuant

to Articles in Chapter II of European Council Regulation (EC)

1334/2000; (2), must comply with U.S. government Export

Administration Regulations ("EAR", 15 C.F.R. §§ 730-774, http://

www.bis.doc.gov/ ) administered by Department of Commerce,

Bureau of Industry and Security; and (3) must comply with

economic sanctions regulations (30 C.F.R. §§ 500 et. seq.,.,

http://www.treas.gov/offices/enforcement/ofac/) administered by

the U.S. Department of Treasury, Office of Foreign Assets

Control. The user and any possessor of the product may not

transport or deliver the product, its accessories or separate

software to any country, region, entity or person prohibited by

these regulations.

Limited Warranty

Sony Ericsson Mobile Communications AB, SE-221 88 Lund,

Sweden, (Sony Ericsson) or its local affiliated company, provides

this Limited Warranty for your mobile phone, original accessory

delivered with your mobile phone, and/or your mobile computing

product (hereinafter referred to as “Product”).

Should your Product need warranty service, please return it to

the dealer from whom it was purchased, or contact your local

Sony Ericsson Contact Center (national rates may apply) or visit

www.sonyericsson.com to get further information.

Our warranty

Subject to the conditions of this Limited Warranty, Sony Ericsson

warrants this Product to be free from defects in design, material

and workmanship at the time of its original purchase by a

consumer. This Limited Warranty will last for a period of two (2)

years as from the original date of purchase of the Product for

your mobile phone, and for a period of one (1) year following the

original purchase date of the Product for all original accessories

(such as the battery, charger or handsfree kit) which may be

delivered with your mobile phone.

What we will do

If, during the warranty period, this Product fails to operate under

normal use and service, due to defects in design, materials or

workmanship, Sony Ericsson authorised distributors or service

partners, in the country/region* where you purchased the

Product, will, at their option, either repair or replace the Product

in accordance with the terms and conditions stipulated herein.

Sony Ericsson and its service partners reserve the right to

charge a handling fee if a returned Product is found not to be

under warranty according to the conditions below.

Please note that some of your personal settings, downloads

and other information may be lost when your Sony Ericsson

Product is repaired or replaced. At present, Sony Ericsson may

be prevented by applicable law, other regulation or technical

restrictions from making a backup copy of certain downloads.

Sony Ericsson does not take any responsibility for any lost

information of any kind and will not reimburse you for any such

loss. You should always make backup copies of all the

information stored on your Sony Ericsson Product such as

downloads, calendar and contacts before handing in your

Sony Ericsson Product for repair or replacement.

Conditions

1. This Limited Warranty is valid only if the original proof of

purchase for this Product issued by a Sony Ericsson authorised

dealer specifying the date of purchase and serial number**, is

presented with the Product to be repaired or replaced.

Sony Ericsson reserves the right to refuse warranty service if

this information has been removed or changed after the original

purchase of the Product from the dealer.

2. If Sony Ericsson repairs or replaces the Product, the repair for

the defect concerned, or the replaced Product shall be

warranted for the remaining time of the original warranty period

or for ninety (90) days from the date of repair, whichever is

longer. Repair or replacement may involve the use of

functionally equivalent reconditioned units. Replaced parts or

components will become the property of Sony Ericsson.

3. This warranty does not cover any failure of the Product due to

normal wear and tear, or due to misuse, including but not

limited to use in other than the normal and customary manner,

in accordance with the Sony Ericsson instructions for use and

maintenance of the Product. Nor does this warranty cover any

failure of the Product due to accident, software or hardware

modification or adjustment, acts of God or damage resulting

from liquid.

A rechargeable battery can be charged and discharged more

than a hundred times. However, it will eventually wear out –

this is not a defect and corresponds to normal wear and tear.

When the talk-time or standby time is noticeably shorter, it is

time to replace the battery. Sony Ericsson recommends that

you use only batteries and chargers approved by

Sony Ericsson.

Minor variations in display brightness and colour may occur

between phones. There may be tiny bright or dark dots on the

display. These are called defective pixels and occur when

individual dots have malfunctioned and can not be adjusted.

Two defective pixels are deemed acceptable.

Minor variations in camera image appearance may occur

between phones. This is nothing uncommon and is not

regarded as a defective camera module.

4. Since the cellular system on which the Product is to operate is

provided by a carrier independent from Sony Ericsson,

Sony Ericsson will not be responsible for the operation,

availability, coverage, services or range of that system.

5. This warranty does not cover Product failures caused by

installations, modifications, or repair or opening of the Product

performed by a non-Sony Ericsson authorised person.

6. The warranty does not cover Product failures which have been

caused by use of accessories or other peripheral devices which

are not Sony Ericsson branded original accessories intended

for use with the Product.

Sony Ericsson disclaims any and all warranties, whether

express or implied, for failures caused to the Product or

peripheral devices as a result of viruses, trojan horses,

spyware, or other malicious software. Sony Ericsson strongly

recommends that you install appropriate virus protection

software on your Product and any peripheral devices

connected to it, as available, and update it regularly, to better

protect your device. It is understood, however, that such

software will never fully protect your Product or its peripheral

devices and Sony Ericsson disclaims all warranties, whether

express or implied, in case of failure by such antivirus software

to fulfil its intended purpose.

7. Tampering with any of the seals on the Product will void the

warranty.

8. THERE ARE NO EXPRESS WARRANTIES, WHETHER WRITTEN

OR ORAL, OTHER THAN THIS PRINTED LIMITED WARRANTY.

ALL IMPLIED WARRANTIES, INCLUDING WITHOUT

LIMITATION THE IMPLIED WARRANTIES OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR

PURPOSE, ARE LIMITED TO THE DURATION OF THIS LIMITED

WARRANTY. IN NO EVENT SHALL SONY ERICSSON OR ITS

LICENSORS BE LIABLE FOR INCIDENTAL OR

CONSEQUENTIAL DAMAGES OF ANY NATURE WHATSOEVER,

INCLUDING BUT NOT LIMITED TO LOST PROFITS OR

COMMERCIAL LOSS TO THE FULL EXTENT THOSE DAMAGES

CAN BE DISCLAIMED BY LAW.

Some countries/states do not allow the exclusion or limitation of

incidental or consequential damages, or limitation of the duration

of implied warranties, so the preceding limitations or exclusions

may not apply to you.

The warranty provided does not affect the consumer’s

statutory rights under applicable legislation in force, nor the

consumer’s rights against the dealer arising from their sales /

purchase contract.

*Geographical scope of the warranty

If you have purchased your Product in a country member of the

European Economic Area (EEA) or in Switzerland or the Republic

of Turkey, and such Product was intended for sale in the EEA or

in Switzerland or in Turkey, you can have your Product serviced

in any EEA country or in Switzerland or in Turkey, under the

warranty conditions prevailing in the country in which you require

servicing, provided that an identical Product is sold in such

country by an authorised Sony Ericsson distributor. To find out if

your Product is sold in the country you are in, please call the

local Sony Ericsson Contact Center. Please observe that certain

services may not be available outside the country of original

purchase, for example, due to the fact that your Product may

have an interior or exterior which is different from equivalent

models sold in other countries. Please note in addition that it

may sometimes not be possible to repair SIM-locked Products.

** In some countries/regions additional information (such as a

valid warranty card) may be requested.

Trademarks and acknowledgements

The Liquid Identity logo and Xperia are trademarks or registered

trademarks of Sony Ericsson Mobile Communications AB.

Sony is a trademark or a registered trademark of Sony

Corporation.

Ericsson is a trademark or registered trademark of

Telefonaktiebolaget LM Ericsson.

Bluetooth is a trademark or a registered trademark of Bluetooth

SIG Inc. and any use of such mark by Sony Ericsson is under

license.

Other product and company names mentioned herein may be the

trademarks of their respective owners.

Any rights not expressly granted herein are reserved.

Support

Anguilla 1-800-080-9518

(Toll Free)

questions.CO@support.sonyericsson.com

Antigua and

Barbuda

1-800-081-9518

(Toll Free)

questions.CO@support.sonyericsson.com

Argentina 0800-333-7427

(número gratuito)

questions.CO@support.sonyericsson.com

Australia 1300 650-050

(Toll Free)

questions.AU@support.sonyericsson.com

The Bahamas 1-800-205-6062

(Toll Free)

questions.CO@support.sonyericsson.com

Barbados 1-800-082-9518

(Toll Free)

questions.CO@support.sonyericsson.com

Belgique/

België

02-0745 1611 questions.BE@support.sonyericsson.com

Belize AN 815, PIN 5597

(Toll Free)

questions.CO@support.sonyericsson.com

Bermuda 1-800-083-9518

(Toll Free)

questions.CO@support.sonyericsson.com

Bolivia 800-100-542

(número gratuito)

questions.CO@support.sonyericsson.com

Brasil 4001-0444

(ligação gratuita)

questions.BR@support.sonyericsson.com

Canada 1 866 766 9374

(Toll Free / sans

frais)

questions.CA@support.sonyericsson.com

Cayman

Islands

1-800-084-9518

(Toll Free)

questions.CO@support.sonyericsson.com

Central and

Southern

Africa

+27 11 506 0123 questions.CF@support.sonyericsson.com

Česká

republika

844 550 055 questions.CZ@support.sonyericsson.com

Chile 800-646-425

(número gratuito)

questions.CO@support.sonyericsson.com

Colombia 01800-0966-080

(número gratuito)

questions.CO@support.sonyericsson.com

Costa Rica 0 800 011 0400

(número gratuito)

questions.CO@support.sonyericsson.com

Danmark 3331 2828 questions.DK@support.sonyericsson.com

Deutschland 0180 534 2020

(ortsübliche

Gebühren)

questions.DE@support.sonyericsson.com

Dominica 1-800-085-9518

(Toll Free)

questions.CO@support.sonyericsson.com

Ecuador 1-800-0102-50

(número gratuito)

questions.CO@support.sonyericsson.com

Eesti 06 032 032 questions.EE@support.sonyericsson.com

Egypt/ مصر 16727 questions.EG@support.sonyericsson.com

Ελλάδα 801 11 810 810

+30 210 899 19

19 (από κινητό

τηλέφωνο)

questions.GR@support.sonyericsson.com

El Salvador 800-6323 (número

gratuito)

questions.CO@support.sonyericsson.com

España 902 180 576

(tarifa local)

questions.ES@support.sonyericsson.com

France 09 69 32 21 21

09 69 32 21 22

(Xperia™

uniquement)

questions.FR@support.sonyericsson.com

Guatemala 1-800-300-0057

(número gratuito)

questions.CO@support.sonyericsson.com

Haïti/Ayiti AN 193, PIN 5598

(numéro gratuit /

nimewo gratis)

questions.CO@support.sonyericsson.com

Honduras AN 8000122, PIN

5599 (número

gratuito)

questions.CO@support.sonyericsson.com

Hong Kong/香

港

+852 8203 8863 questions.HK@support.sonyericsson.com

Hrvatska 062 000 000 questions.HR@support.sonyericsson.com

India/भारत 1800 11 1800 (Toll

Free)

+91 (011)

39011111

questions.IN@support.sonyericsson.com

Indonesia 021 2701388 questions.ID@support.sonyericsson.com

Ireland 1850 545 888

(Local rate)

questions.IE@support.sonyericsson.com

Italia 06 48895206

(tariffa locale)

questions.IT@support.sonyericsson.com

Jamaica 1-800-442-3471

(Toll Free)

questions.CO@support.sonyericsson.com

Κύπρος/

Kıbrıs

0800 90 909 questions.CY@support.sonyericsson.com

Latvija 67 21 43 01 questions.LV@support.sonyericsson.com

Lietuva 8 700 55030 questions.LT@support.sonyericsson.com

Magyarország 01 880 47 47 questions.HU@support.sonyericsson.com

Malaysia 1800-88-9900

(Toll Free / bebas

tol)

questions.MY@support.sonyericsson.com

Maroc/

المغرب

+212 2 2958 344 questions.MA@support.sonyericsson.com

México 0 1800 000 4722

(número gratuito)

questions.MX@support.sonyericsson.com

Nederland 0900 8998318 questions.NL@support.sonyericsson.com

Nederlandse

Antillen

001-866-509-8660

(gratis nummer)

questions.CO@support.sonyericsson.com

New Zealand 0800-100-150

(Toll Free)

questions.NZ@support.sonyericsson.com

Nicaragua AN 1800-0166,

PIN 5600 (número

gratuito)

questions.CO@support.sonyericsson.com

Norge 815 00 840

(lokaltakst)

questions.NO@support.sonyericsson.com

Österreich 0810 200 245 questions.AT@support.sonyericsson.com

Pakistan/

پاکستان

021 - 111 22 55 73 questions.PK@support.sonyericsson.com

Panamá 00800-787-0009

(número gratuito)

questions.CO@support.sonyericsson.com

Paraguay 009 800 54 20032

(número gratuito)

questions.CO@support.sonyericsson.com

Perú 0800-532-38

(número gratuito)

questions.CO@support.sonyericsson.com

Philippines/

Pilipinas

+63 2 7891860 questions.PH@support.sonyericsson.com

Polska +48 22 22 77 444 questions.PL@support.sonyericsson.com

Portugal 808 204 466

(chamada local)

questions.PT@support.sonyericsson.com

República

Dominicana

1-800-751-3370

(número gratuito)

questions.CO@support.sonyericsson.com

România +40 21 401 0401 questions.RO@support.sonyericsson.com

Saint Kitts

and Nevis

1-800-087-9518

(Toll Free)

questions.CO@support.sonyericsson.com

Saint Vincent

and the

Grenadines

1-800-088-9518

(Toll Free)

questions.CO@support.sonyericsson.com

Schweiz/

Suisse/

Svizzera

0848 824 040 questions.CH@support.sonyericsson.com

Singapore +65 6744 0733 questions.SG@support.sonyericsson.com

Slovenia 01 600 5000 questions.SI@support.sonyericsson.com

Slovensko 02 5443 6443 questions.SK@support.sonyericsson.com

South Africa 0861 632222 questions.ZA@support.sonyericsson.com

South Κorea/

대한민국

(+82) 1588 4170 questions.KO@support.sonyericsson.com

Suomi 09 299 2000 questions.FI@support.sonyericsson.com

Sverige 013 24 45 00

(lokal taxa)

questions.SE@support.sonyericsson.com

Trinidad and

Tobago

1-800-080-9521

(Toll Free)

questions.CO@support.sonyericsson.com

Türkiye +90 212 473 77 77 questions.TR@support.sonyericsson.com

United

Kingdom

08705 237 237

(Local rate)

questions.GB@support.sonyericsson.com

United States 1 866 766 9374 questions.US@support.sonyericsson.com

Uruguay 000-401-787-013

(número gratuito)

questions.CO@support.sonyericsson.com

Venezuela 0-800-1-00-2250

(número gratuito)

questions.CO@support.sonyericsson.com

Việt Nam 1900 1525 (miễn

phí)

questions.VN@support.sonyericsson.com

Беларусь 8 82 00 361 0001 questions.BY@support.sonyericsson.com

България 0800 1 8778 questions.BG@support.sonyericsson.com

Россия +7 (495) 7870986 questions.RU@support.sonyericsson.com

Україна (+380) 44 590

1515

questions.UA@support.sonyericsson.com

الأردن +971 4 3919 880 questions.JO@support.sonyericsson.com

الإمارات العربية المتحدة

+971 4 3919 880

(UAE)

questions.AE@support.sonyericsson.com

الكويت +971 4 3919 880 questions.KW@support.sonyericsson.com

المملكة العربية السعودية

800-8200-727 questions.SA@support.sonyericsson.com

中国 +86 400 810 0000 questions.CN@support.sonyericsson.com

台灣 +886 2 25625511 questions.TW@support.sonyericsson.com

ไทย 02 2483 030 questions.TH@support.sonyericsson.com

www.sonyericsson.com

Sony Ericsson Mobile Communications AB

SE-221 88 Lund, Sweden

1222-9269.2

Sony A3880077 GSM 850/900/1800/1900 GPRS / EDGE / UMTS FDD1&8 / HSPA mobile phone with Bluetooth, WLAN 802.11bg, GPS, FM receiver User Manual Sony Ericsson Mobile Communications AB

Sony Mobile Communications Inc GSM 850/900/1800/1900 GPRS / EDGE / UMTS FDD1&8 / HSPA mobile phone with Bluetooth, WLAN 802.11bg, GPS, FM receiver Sony Ericsson Mobile Communications AB

Contents

08 user manual all parts

Navigation menu

Namespaces

Views

Navigation
