1Contents
Contents
Getting started ................... 4
SIM card, battery, turning on, help,
calls, Toolbar, PC Suite software,
camera, blog.
Getting to know
the phone ............................ 8
Keys, menus, navigation, entering
letters, My Files, memory card.
Calling ............................... 17
Calls, video calls, contacts, call list,
voice control, groups, business cards.
Messaging ........................ 24
Text messaging, picture messaging,
email, Vodafone Messenger.
Imaging ............................. 31
Camera, video, blog, pictures.
Entertainment ................... 34
Music and Video player, ringtones.
Connectivity ..................... 35
Vodafone live!, Internet, synchronising,
Bluetooth, USB cable, update service.
More features ................... 42
Alarm clock, calendar.
Important information ...... 44
Index ................................. 52
www.sonyericsson.com/support
At Sony Ericsson Product Support
there is more information and help
to get the most out of your product:
User guide with additional information,
troubleshooting, tips and tricks,
software, settings for Internet and
messaging.
V630i-SHUG-Vodafone-R1A-EN.book Page 1 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
2Contents
Sony Ericsson
UMTS 2100 GSM 900/1800/1900
This user guide is published by Sony Ericsson
Mobile Communications AB, without any warranty.
Improvements and changes to this user guide
necessitated by typographical errors, inaccuracies
of current information, or improvements to
programs and/or equipment, may be made
by Sony Ericsson Mobile Communications AB
at any time and without notice. Such changes will,
however, be incorporated into new editions of this
user guide.
All rights reserved.
©Sony Ericsson Mobile Communications AB, 2006
Please note:
Some of the services in this user guide are not
supported by all networks. This also applies to
the GSM International Emergency Number 112.
Please contact your network operator or service
provider if you are in doubt whether you can use
a particular service or not.
Please read the Guidelines for safe and efficient use
and the Limited warranty chapters before you use
your mobile phone.
Your mobile phone has the capability to download,
store and forward additional content, e.g.
ringtones. The use of such content may be
restricted or prohibited by rights of third parties,
including but not limited to restriction under
applicable copyright laws. You, and not
Sony Ericsson, are entirely responsible for
additional content that you download to or forward
from your mobile phone. Prior to your use of any
additional content, please verify that your intended
use is properly licensed or is otherwise authorized.
Sony Ericsson does not guarantee the accuracy,
integrity or quality of any additional content or any
other third party content. Under no circumstances
will Sony Ericsson be liable in any way for your
improper use of additional content or other third
party content.
The Bluetooth word mark and logos are owned by
the Bluetooth SIG, Inc. and any use of such marks
by Sony Ericsson is under license.
MusicDJ, PhotoDJ and VideoDJ are trademarks or
registered trademarks of Sony Ericsson Mobile
Communications AB.
Memory Stick Micro™ and M2™ are registered
trademarks of Sony Corporation.
Real is a trademark or a registered trademark
of RealNetworks, Inc. RealPlayer® for Mobile
is included under license from RealNetworks,
Inc. Copyright 1995-2004, RealNetworks, Inc.
All rights reserved.
Adobe® Photoshop® Album Starter Edition
is a registered trademark of Adobe Systems
Incorporated.
Microsoft, Windows and PowerPoint are either
registered trademarks or trademarks of Microsoft
Corporation in the U.S and other countries.
Mac OS is a trademark of Apple Computer, Inc.,
registered in the U.S. and other countries.
T9™ Text Input is a trademark or a registered
trademark of Tegic Communications. T9™ Text
Input is licensed under one or more of the
following: U.S. Pat. Nos. 5,818,437, 5,953,541,
5,187,480, 5,945,928, and 6,011,554; Canadian
Pat. No. 1,331,057, United Kingdom Pat.
No. 2238414B; Hong Kong Standard Pat.
No. HK0940329; Republic of Singapore Pat.
No. 51383;
Euro.Pat. No. 0 842 463(96927260.8) DE/DK, FI,
FR, IT, NL, PT, ES, SE, GB; and additional patents
are pending worldwide.
Java and all Java based trademarks and logos are
trademarks or registered trademarks of Sun
Microsystems, Inc. in the U.S. and other countries.
V630i-SHUG-Vodafone-R1A-EN.book Page 2 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
Publication number: EN/LZT 108 8568 R2A
3Contents
End-user license agreement for Sun™ Java™
J2ME™.
1Restrictions: Software is confidential copyrighted
information of Sun and title to all copies is retained
by Sun and/or its licensors. Customer shall not
modify, decompile, disassemble, decrypt, extract,
or otherwise reverse engineer Software. Software
may not be leased, assigned, or sublicensed,
in whole or in part.
2Export Regulations: Software, including technical
data, is subject to U.S. export control laws,
including the U.S. Export Administration Act and
its associated regulations, and may be subject
to export or import regulations in other countries.
Customer agrees to comply strictly with all such
regulations and acknowledges that it has the
responsibility to obtain licenses to export,
re-export, or import Software. Software may not be
downloaded, or otherwise exported or re-exported
(i) into, or to a national or resident of, Cuba, Iraq,
Iran, North Korea, Libya, Sudan, Syria (as such
listing may be revised from time to time) or any
country to which the U.S. has embargoed goods;
or (ii) to anyone on the U.S. Treasury Department's
list of Specially Designated Nations or the U.S.
Commerce Department's Table of Denial Orders.
3Restricted Rights: Use, duplication or disclosure
by the United States government is subject to the
restrictions as set forth in the Rights in Technical
Data and Computer Software Clauses in DFARS
252.227-7013(c) (1) (ii) and FAR 52.227-19(c) (2)
as applicable.
Part of the software in this product is copyright ©
SyncML initiative Ltd. (1999-2002). All rights
reserved.
Other product and company names mentioned
herein may be the trademarks of their respective
owners.
Any rights not expressly granted herein are reserved.
All illustrations are for illustration only and may not
accurately depict the actual phone.
Instruction symbols
The following appear in the user guide:
Note
A service or function is network-
or subscription-dependent.
Contact your network operator
or visit www.vodafone.com
for details.
%See also page...
}Use a selection or navigation
key to scroll and select
%12 Navigation.
Press the navigation key centre.
Press the upper part of the
navigation key.
Press the lower part of the
navigation key.
Press the left part of the
navigation key.
Press the right part of the
navigation key.
V630i-SHUG-Vodafone-R1A-EN.book Page 3 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
4Getting started
Getting started
SIM card, battery, turning on, help,
calls, Toolbar, PC Suite software,
camera, blog.
SIM card and battery
To insert SIM card and battery
1Remove the battery cover by pressing
and sliding it as shown in the picture.
2Slide the SIM card into its holder with
the contacts facing down.
3Insert the battery with the label side up
and the connectors facing each other.
4Slide the battery cover into place.
To charge the battery
1Connect the charger plug to the phone
with the symbol facing upwards.
2It may take up to 30 minutes before
the battery icon appears.
3Wait approximately 2.5 hours or until
the battery icon indicates a full charge.
Press a key to activate the screen.
4Pull out the charger plug.
Turning on your phone
Make sure the phone is charged and
a SIM card inserted before turning
the phone on. After turning on, use
the setup wizard to quickly and easily
prepare for use.
V630i-SHUG-Vodafone-R1A-EN.book Page 4 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
5Getting started
To turn on the phone
1Press and hold . The first start-up
may take a few minutes.
2Select to use the phone in:
•Normal – full functionality or
•Flight mode – limited functionality
with network and Bluetooth™
transceivers off.
3Enter your SIM card PIN, if requested.
4At first start-up, select the language
for your phone menus.
5}Yes for the setup wizard to help you.
6Follow instructions to complete setup.
Standby
After you have turned the phone on
and entered your PIN, the name of the
network operator will appear on the
display. This is called standby mode.
Help in your phone
Help and information is available
in your phone at any time.
To use the setup wizard
}Settings }the General tab
}Setup wizard and select an option:
•Settings download
•Basic setup
•Tips and tricks
To view information about functions
Scroll to a function }More }Info,
if available.
To view the phone demonstration
}Entertainment }Demo tour.
Making calls
The phone must be in normal mode
(not flight mode).
To make a call
1Enter a phone number (with
international prefix and area code
if applicable).
Predefined settings exist in your phone.
You should already have access to all
relevant services in your network. If you
need more settings and use Settings
download, you must accept to register
the phone at Sony Ericsson. A text
message is sent. No personal data will
be transferred to or processed
by Sony Ericsson.
Contact your network operator or
service provider for more information.
V630i-SHUG-Vodafone-R1A-EN.book Page 5 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
6Getting started
2Press to make a voice call, or
}More }Make video call to make
a video call.
3}More for options during the call.
4Press to end the call.
To join two calls into a conference
1Call the first person to include in the
conference.
2}More }Hold to hold the ongoing call.
3Call the second person.
4}More }Join calls.
Toolbar
Use the toolbar to handle new events,
such as notification of incoming
messages, access bookmarks and
Internet, manage functions running
in the background and shortcuts.
To use the toolbar
1}Toolbar and use or to select
atab.
2Scroll or to select an option.
Pop-ups
New events can also be set to appear
as pop-up text instead.
To select the toolbar or pop-ups
}Settings }General }Toolbar and
select Toolbar or Pop-up.
PC Suite software
Enhance the experience of your phone
by installing the PC Suite software on
your computer. This allows you to,
for example, synchronise your phone
calendar with a computer calendar,
transfer files between your phone and
a computer, or access the Internet
using the mobile phone modem.
To install the PC Suite software
1Turn on your computer and insert
the CD that came with your phone
into the CD drive of your computer.
The CD starts automatically and the
installation window opens.
2Computer: Select a language and
click OK.
3Computer: Click Install in the PC Suite
section and follow the instructions on
the screen. When the installation is
complete, the PC Suite icon appears
on the desktop of your computer.
Depending on the network coverage,
the modem speed to the Internet is up
to 384 kbit/s.
For the latest version of PC Suite, visit
www.sonyericsson.com/support.
V630i-SHUG-Vodafone-R1A-EN.book Page 6 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
7Getting started
Take pictures or record video
clips
To take a picture or record video
1From standby, press and hold
to activate the camera.
2Use the navigation key to
switch between camera and
video recorder.
3Camera: Press to take
apicture.
Video: Press to start recording.
To stop recording, press again.
Your pictures and video clips are
automatically saved in My Files
}Camera album.
4To t ak e an ot her pi cture or record
another video clip, press
to return to the viewfinder.
To stop using the camera or video
recorder, press and hold .
Your personal Web page
Publish your pictures on a Web page.
The phone creates the Web page
for you.
To blog a photo
1Take a photo }More }Blog this.
2Follow the instructions for first time use.
3Add title and text }OK }Publish.
4You will receive a text message with
your Web address and log-in data.
Zoom in
or out
Take pictures
Record video
Screen options
(top right)
Screen options
(bottom right)
Switch camera/video or
Adjust brightness or
Delete
Back
V630i-SHUG-Vodafone-R1A-EN.book Page 7 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
8Getting to know the phone
Getting to know the phone
Keys, menus, navigation, entering letters, My Files, memory card.
Phone overview
1
2
3
4
5
6
7
8
19
2
12
16
16
917
18
10
11
12
13
14
15
V630i-SHUG-Vodafone-R1A-EN.book Page 8 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
9Getting to know the phone
1Power on/off button
2Play/stop button
3Screen
4Selection key
5Call key (green)
6Back key
7Navigation key/Music player control
8Memory Stick Micro™ (M2™) slot
9Keylock key
10 Ear speaker
11 Video call camera
12 Volume, camera digital zoom buttons
13 Selection key
14 End key (red)
15 Clear key
16 Camera button
17 Silent key
18 Connector for charger, handsfree and USB cable
19 Camera lens
For more information %12 Navigation
V630i-SHUG-Vodafone-R1A-EN.book Page 9 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
10 Getting to know the phone
Menu overview
Entertainment Vodafone live!* Music Player
My Games
Online services*
Video player
MusicDJ™
PhotoDJ™
VideoDJ™
live! intro
Remote control
Record sound
Demo tour
Now playing
Artists
Tracks
Playlists
Camera Messaging My Files**
Create new
Inbox
Email
Messenger*
Call voicemail
Drafts
Outbox
Sent messages
Saved messages
Templates
live! Studio
Settings
Camera album
Pictures
Music
Games
Videos
Applications
Themes
Web pages
Other
Organiser & Tools Contacts Calls**
My Applications
Alarms
Calendar
Calculator
Synchronisation
Tasks
Record sound
Notes
Timer
Stopwatch
Remote control
Code memo
New contact All
Answered
Dialled
Missed
V630i-SHUG-Vodafone-R1A-EN.book Page 10 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
11Getting to know the phone
Online services***/Alarms Video call
Settings**
General
Profiles
Time & date
Language
Voice control
Ticker
Toolbar
Shortcuts
Flight mode
Security
Setup wizard
Phone status
live! intro
Master reset
Sounds & alerts
Ring volume
Ringtone
Silent mode
Increasing ring
Vibrating alert
Message alert
Key sound
Display
Wallpaper
Themes
Start-up screen
Screen saver
Clock size
Brightness
Sleep mode clock
Edit line names***
Calls
Divert calls
Switch to line 2***
Manage calls
Time & cost*
Show/hide my no.
Handsfree
Connectivity***
Bluetooth
USB
Synchronisation
Mobile networks
Data comm.
Internet settings
Streaming settings
Accessories
* Vodafone live!. Offline webpage with direct links to online services.
** Use the navigation key to move across tabs in submenus. For more information %12 Navigation.
*** This service is not available in all countries.
V630i-SHUG-Vodafone-R1A-EN.book Page 11 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
12 Getting to know the phone
Navigation
The main menus are shown as icons.
Some submenus include tabs. Scroll
to a tab by pressing the left or right
part of the navigation key.
Key
Go to the main menus or select highlighted items.
Move through the menus and tabs.
Select options shown above these keys on the screen.
Go back one level in the menus. Press and hold to return to standby
or to end a function.
Delete items, such as pictures, sounds and contacts.
During a call, press and hold to mute the microphone.
Reject or end calls, return to standby.
Accept calls, call a contact or send an item, call list from standby.
Open or minimize the Music Player.
Press and hold to take a picture or record a video clip.
Press and hold to call your voicemail service (if set).
- Press and hold any of these keys to reach a contact beginning with
a specific letter.
- Press a number key and then to speed dial.
V630i-SHUG-Vodafone-R1A-EN.book Page 12 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
13Getting to know the phone
View a shortcut guide when using the camera.
Press and then }Lock keys or Unlock to lock or unlock the phone
keys.
Turn off the ringtone when receiving a call.
Press and hold to set the phone to silent. The alarm signals even
if the phone is set to silent.
View status information in standby.
Increase the volume during a call, or when using the Music Player.
Zoom out when using the camera or viewing pictures.
Press and hold to go back one music track.
Press twice to reject a call.
Press and hold to voice dial, alternatively say your magic word (if set)
%23 Voice dialling.
Decrease the volume during a call, or when using the Music Player.
Zoom in when using the camera or viewing pictures.
Press and hold to go forward one music track.
Press and hold to voice dial, alternatively say your magic word (if set)
%23 Voice dialling.
}Info Find more information, explanations or tips about selected features,
menus or functions available in your phone %5 Help in your phone.
}More Enter a list of options. There are different alternatives in the list
of options depending on where you are in the menus.
V630i-SHUG-Vodafone-R1A-EN.book Page 13 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
14 Getting to know the phone
Entering letters
Enter letters in one of the following
ways (text input methods), for
example, when writing messages:
•Multitap text input
•T9™ Text Input
To change the text input method
Before, or when entering letters, press
and hold to change the method.
To change the writing language
Before, or when entering letters, press
and hold and select another
writing language.
Options when entering letters
}More for options when writing
a message.
To enter letters using multitap input
•Press - repeatedly until
the desired character appears.
•Press to shift between capital
and lower-case letters.
•Press and hold - to enter
numbers.
•Press to delete letters or numbers.
•Press for the most common
punctuation marks.
•Press to add a space.
T9™ Text Input
The T9 Text Input method uses a built-
in dictionary to recognize the most
commonly used word for each
sequence of key presses. This way,
you press each key only once, even if
the letter you want is not the first letter
on the key.
To enter letters using T9 Text Input
1To enter text, you have to be in a
function where text input is possible,
for example, }Messaging
}Write new }Text message.
2For example, to write the word “Jane”,
press , , , .
3If the word shown is the one you want,
press to accept and add a
space. To accept a word without
adding a space, press . If the word
shown is not the one you want, press
or repeatedly to view alternative
words. Accept a word and add
a space by pressing .
4Continue writing the message.
To enter a mark, press and
then or repeatedly, press
to accept and add a space.
V630i-SHUG-Vodafone-R1A-EN.book Page 14 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
15Getting to know the phone
To add words to the T9 Text Input
dictionary
1When entering letters }More
}Spell word.
2Edit the word by using multitap input.
Use and to move the cursor
between the letters. To delete a
character, press . To delete the
entire word, press and hold .
When you have edited the word
}Insert. The word is added to the
T9 Text Input dictionary. Next time you
enter this word using T9 Text Input,
it appears in alternative words.
Next word prediction
When writing a message, you can use
T9 Text Input to predict the next word,
if previously used in a sentence.
To turn next word prediction on/off
When entering letters }More
}Writing options }Nxt word pred.
To use next word prediction
When entering letters, press
to accept or continue.
My Files
Use My Files to handle items such as
pictures, videos, music, themes, Web
pages, games and applications saved
in the phone memory or on the
Memory Stick Micro™ (M2™) memory
card.
You can also move and copy files
between a computer and the memory
card.
Create subfolders to move or copy
files to. Games and applications can
be moved within the Games and
Applications folders. Unrecognized
files are saved in the Other folder.
When handling files, you can select
several or all files in a folder at the
same time for all items except Games
and Applications.
Memory status
If all available memory is full, you
cannot save any files until content is
removed. Check the memory status
for your phone and memory card by
highlighting a folder }More
}Memory status.
V630i-SHUG-Vodafone-R1A-EN.book Page 15 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
16 Getting to know the phone
My Files menu tabs
My Files is divided into three tabs,
and icons are included to indicate
where the files are saved.
•All files - all content in the phone
memory and on the memory card.
•On Memory Stick - all content on
the memory card.
•In phone - all content in the phone
memory.
File information
View file information by highlighting
it }More }Information.
To use a file from My Files
1}My Files and open a folder.
2Scroll to a file }More.
To move or copy files to a computer
%39 Transferring files using the USB
cable.
To create a subfolder
1}My Files and open a folder.
2}More }New folder and enter
a name for the folder.
3}OK to save the folder.
To select several files
1}My Files and open a folder.
2}More }Mark }Mark several.
3Scroll to select files }Mark or
Unmark.
To select all files in a folder
}My Files and open a folder }More
}Mark }Mark all.
To delete a file or a subfolder from
My Files
1}My Files and open a folder.
2Scroll to a file }More }Delete.
V630i-SHUG-Vodafone-R1A-EN.book Page 16 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
17Calling
Calling
Calls, video calls, contacts, call list,
voice control, groups, business cards.
Making and receiving calls
Before you can make or receive any
calls, you must turn on your phone
and be within range of a network.
%4 Turning on your phone. To make
a video call %18 Video call.
Networks
When you turn on the phone, it
automatically selects your home
network if this is within range. If it is
not within range, you may use another
network, provided your network
operator has an agreement that allows
you to do so. This is called roaming.
Select the network to use, or you can
add a network to your preferred
networks. You can also change the
order in which networks are selected
during an automatic search.
To view available network options
}Settings and use or to scroll
to the Connectivity tab }Mobile
networks.
To make a call
1Enter a phone number (with
international country code and area
code, if applicable).
2Press to make a voice call or
}More to view options, such as
Make video call %18 Video call.
3Press to end the call.
To make international calls
1Press until a + sign appears.
2Enter the country code, area code
(without the first zero) and phone
number. Press to make a voice call,
or }More }Make video call to make
a video call.
To re-dial a number
If a call connection fails and Retry?
appears }Yes.
To answer or reject a call
Press or .
You can call numbers from your contacts
and call list %20 Contacts, and
%23 Call list.
Do not hold the phone to your ear when
waiting. When the call connects,
the phone gives a loud signal.
V630i-SHUG-Vodafone-R1A-EN.book Page 17 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
18 Calling
To turn off the microphone
1Press and hold .
2To resume the conversation press and
hold again.
To turn the loudspeaker on or off
during a voice call
}Turn on speaker or
Turn off speaker.
To change the ear speaker volume
Press to increase or to
decrease the ear speaker volume
during a call.
Missed calls
When the toolbar is set to default,
missed calls appear in the New events
tab in standby. If pop-up is set to
default Missed appears in standby
%6Toolbar.
To check missed calls from standby
•If toolbar is set to default, }Toolbar
and use or to scroll to the
New events tab. Scroll or to
select a number and press to call.
•If pop-up is set to default, press
and use or to scroll to the
Missed tab. Scroll or to select
a number and press to call.
Emergency calls
Your phone supports international
emergency numbers, for example,
112, 911. These numbers can
normally be used to make emergency
calls in any country, with or without
a SIM card inserted, if a 3G (UMTS)
or GSM network is within range.
To make an emergency call
Enter 112 (the international emergency
number) and press .
To view your local emergency
numbers
}Contacts }More }Options
}Special numbers
}Emergency nos.
Video call
See a person on screen during calls.
Before you start
To make a video call, both you and
the person you are calling need a
subscription that supports the 3G
(UMTS) service, and you need to be
Do not hold the phone to your ear when
using the loudspeaker. This could
damage your hearing.
In some countries, other emergency
numbers may also be promoted. Your
network operator may therefore have
saved additional local emergency
numbers on the SIM card.
V630i-SHUG-Vodafone-R1A-EN.book Page 18 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
19Calling
within range of a 3G (UMTS) network.
3G (UMTS) service is available when
the 3G icon appears in the status bar.
Video call demo mode
You can use most video call functions
without making a call, for example, to
prepare a camera view before calling.
}Video call.
To make a video call
When 3G (UMTS) service is available,
you can make a video call in one of
the following ways:
•Enter a phone number (international
prefix and area code if applicable)
}More }Make video call.
•Contacts and select the contact to
call. Use or to select a number
}More }Make video call.
•Video call }Call... }Contacts
to retrieve a phone number or enter
a phone number. Press .
To zoom the outgoing video in or out
Press to zoom in the outgoing
video and press to zoom out.
To accept an incoming video call
Press or }Answer.
To end a video call
Press .
Video call options
}More for the following options:
•Switch camera – to switch between
the main and video call cameras. Use
the main camera to show a full image
of your surroundings to the recipient.
•Stop camera/Start camera – turn the
video camera off or on. An alternative
picture is shown when off.
•Save picture – save the image shown
in the large view, for example,
the incoming caller image.
•Camera – options
•Brightness – adjust the level for
the outgoing picture.
•Turn on night m. – use when
lighting conditions are poor. This
setting affects the outgoing video.
•Sound – options during a video call
•Turn off speaker/Turn on speaker
– incoming sound.
•Mute microphone/Unmute mic. –
microphone off or on.
•Transfer sound – to and from
Bluetooth handsfree equipment.
•Layout – options
•Switch pictures – show incoming
or outgoing video in full size view.
•Hide small pic./Show small pic.
•Mirror image – show the outgoing
camera picture.
V630i-SHUG-Vodafone-R1A-EN.book Page 19 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
20 Calling
•Settings – when answering
•Answer mode – set the video call
camera to on or off.
•Alternative pic. – set a picture
to show to the recipient when
the camera is off.
•Audio options – select if
microphone, speaker phone,
or both should be on or off.
•Video quality – select picture
quality for video calls. Changes do
not take effect during an ongoing call.
Contacts
You can save your contact information
in the phone memory or on a SIM card.
Choose which contact information –
Phone contacts or SIM contacts –
is shown as default.
For useful information and settings
}Contacts }More }Options.
Default contact
If Phone contacts is selected as
default, your contacts show all the
information saved in Contacts. If you
select SIM contacts as default, your
contacts show information depending
on the SIM card.
To select default contacts
1}Contacts }More }Options
}Advanced }Default contacts.
2}Phone contacts or SIM contacts.
Phone contacts
Save contacts in the phone with
names, phone numbers and personal
information. You can also add pictures
and ringtones to contacts. Use , ,
and to scroll between tabs and
their information fields.
To add a phone contact
1If Phone contacts is selected as
default, }Contacts }New contact
}Add.
2Enter the name }OK.
3Enter the number }OK.
4Select a number option.
5Scroll between tabs and select the
fields to add information. To enter
symbols such as @, }More
}Add symbol and select a symbol
}Insert.
6When all information is added }Save.
SIM contacts
Save contacts on your SIM card.
V630i-SHUG-Vodafone-R1A-EN.book Page 20 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
21Calling
To add a SIM contact
1If SIM contacts is selected as default,
}Contacts }New contact }Add.
2Enter the name }OK.
3Enter the number }OK and select a
number option. Add more information,
if available }Save.
To delete a contact
1}Contacts and scroll to a contact.
2Press and select Yes.
To delete all phone contacts
}Contacts }More }Options
}Advanced }Delete all contacts
}Yes and }Yes. Names and numbers
on the SIM card are not deleted.
To automatically save names and
phone numbers on the SIM card
}Contacts }More }Options
}Advanced }Auto save on SIM
and select On.
Memory status
The number of contacts you can save
in the phone or on the SIM card
depends on available memory.
To view memory status
}Contacts }More }Options
}Advanced }Memory status.
Using contacts
Contacts can be used in many ways.
Below you can see how to:
•call phone and SIM contacts.
•send phone contacts to another
device.
•copy contacts to phone and
SIM card.
•add a picture or a ringtone
to a phone contact.
•edit contacts.
•synchronise or save your contacts
within your private network space.
For more information, please
contact Vodafone Customer
Services or visit www.vodafone.com.
To call a phone contact
1}Contacts. Scroll to, or enter the first
letter or letters of the contact.
2When the contact is highlighted press
or to select a number. Press
to make a voice call, or }More
}Make video call to make a video call.
To call a SIM contact
•If SIM contacts is default }Contacts
and when the contact is highlighted
press or to select a number.
Press to make a voice call,
or }More }Make video call to make
a video call.
V630i-SHUG-Vodafone-R1A-EN.book Page 21 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
22 Calling
•If Phone contacts is set as default
}Contacts }More }Options
}SIM contacts and select the
contact. Press to make a voice call,
or }More }Make video call to make
a video call.
To send a contact
}Contacts and select a contact
}More }Send contact and select
atransfer method.
To send all contacts
}Contacts }More }Options
}Advanced }Send all contacts
and select a transfer method.
To copy names and numbers
to the SIM card
1}Contacts }More }Options
}Advanced }Copy to SIM.
2Select one of the alternatives.
To copy names and numbers
to phone contacts
1}Contacts }More }Options
}Advanced }Copy from SIM.
2Select one of the alternatives.
To add a picture, ringtone sound
or video to a phone contact
1}Contacts and select the contact
}More }Edit contact.
2Select the relevant tab and then select
Picture or Ringtone }Add.
3Select an option and an item }Save.
To edit a phone contact
1}Contacts and select a contact
}More }Edit contact.
2Scroll to the relevant tab and select
the field to edit }Edit.
3Edit the information }Save.
To edit a SIM contact
1If SIM contacts is default }Contacts
and select the name and number
to edit. If phone contacts is default
}Contacts }More }Options
}SIM contacts and select the name
and number to edit.
2}More }Edit contact and edit
the name and number.
To select the sort order for contacts
}Contacts }More }Options
}Advanced }Sort order.
When copying all contacts from the
phone to the SIM card, all existing
SIM card information is replaced.
If your subscription supports Calling Line
Identification (CLI) service, you can
assign personal ringtones to contacts.
V630i-SHUG-Vodafone-R1A-EN.book Page 22 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
23Calling
Call list
Information about most recent calls.
To call a number from the call list
1From standby, press and select
atab.
2Scroll to the name or number to call.
Press to make a voice call, or
}More }Make video call to make
a video call.
To add a call list number to contacts
1From standby, press and select
atab.
2Scroll to the number to add }More
}Save number.
3}New contact to create a new
contact, or select an existing contact
to add the number to.
To clear the call list
Press and select the All tab }More
}Delete all.
Voice control
Manage calls with your voice by
creating voice commands.
Before voice dialling
Activate the voice dialling function and
record your voice commands. An icon
appears next to a phone number that
has a voice command.
To activate voice dialling and
record names
1}Settings }the General tab
}Voice control }Voice dialling
}Activate }Yes }New voice and
select a contact.
2If the contact has more than one
number, use and to view the
numbers. Select the number to add
the voice command to. Record a voice
command such as “John mobile”.
3Instructions appear. Wait for the tone
and say the command to record. The
voice command is played back to you.
4If the recording sounds OK }Yes.
If not }No and repeat step 3.
To record another voice command for
a contact }New voice }Add again
and repeat steps 2-4 above.
Voice dialling
Start voice dialling from standby.
To make a call
1From standby, press and hold one
of the volume keys.
2Wait for the tone and say a recorded
name, for example “John mobile”.
The name is played back to you and
the call is connected.
V630i-SHUG-Vodafone-R1A-EN.book Page 23 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
24 Messaging
Groups
Create a group of numbers and email
addresses to send messages to
several recipients at the same time
%24 Messaging.
To create a group of numbers and
email addresses
1}Contacts }More }Options
}Groups }New group }Add.
2Enter a name for the group
}Continue.
3}New }Add to find and select a
contact number or email address.
4Repeat step 3 to add more numbers
or email addresses. }Done.
Business cards
Add your own business card as
a contact.
To add your own business card
}Contacts }More }Options
}My business card and add
information for your business card
}Save.
To send your business card
}Contacts }More }Options
}My business card }Send my card
and select a transfer method.
Messaging
Text messaging, picture messaging,
email, Vodafone Messenger.
Your phone supports various
messaging services. Please contact
your network operator about the
services you can use, or for more
information, visit www.vodafone.com
or www.sonyericsson.com/support.
Text messaging (SMS)
Text messages can contain simple
pictures, sound effects, animations,
and melodies. You can also create
and use templates for your messages.
Before you start
The number to your service centre
is already predefined in your phone
settings. However, you can enter
the number of your service centre
yourself.
To set a service centre number
1}Messaging }Settings }SMS
}Service centre. If the service centre
number is saved on the SIM card it
is shown.
2If there is no number shown }Edit
}New ServiceCentre and enter the
number, including the international “+”
prefix and country/region code }Save.
If you send a text message to a group,
you will be charged for each member.
V630i-SHUG-Vodafone-R1A-EN.book Page 24 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
25Messaging
Sending text messages
For information about entering letters
%14 Entering letters.
To write and send a text message
1}Messaging }Create new }SMS.
2Write your message }Continue. (You
can save a message for later in Drafts
by pressing }Save message.)
3}Enter phone no. and enter a
number, or }Contacts look-up to
retrieve a number or a group from
Contacts, or }Enter email addr.
or select from last used recipients
}Send.
To copy and paste text in a message
1When writing your message }More
}Copy & paste.
2}Copy all or }Mark & copy and use
the navigation key to scroll and mark
text in your message.
3}More }Copy & paste }Paste.
To insert an item in a text message
1When writing your message }More
}Add item.
2Select an option and then an item,
for example, a picture.
To delete a message
1}Messaging and select a folder.
2Select the message to delete and
press .
To set default text message options
}Messaging }Settings }SMS and
select the options to change.
Some language-specific characters use
more space. For some languages you
can deactivate National chars. to save
space.
To send a message to an email address,
you need to set an email gateway
number, }Messaging }Settings }SMS
}Email gateway. The number is
supplied by Vodafone Customer
Services, or you can receive it from
www.vodafone.com.
You can convert your text message
to a picture message. When writing
your message }More }To MMS and
continue creating a picture message,
%26 Picture messaging (MMS).
V630i-SHUG-Vodafone-R1A-EN.book Page 25 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
26 Messaging
Postcard
As part of Vodafone live! you can have
a message with picture and text
delivered as a postcard to a street
address.
To send a postcard
1}Messaging }Create new
}live! Postcard.
2}Take picture to include a new
picture or select a picture from
Pictures or Camera album.
3Write message to accompany
the picture.
4}Continue }Address to enter name
and address, or Contacts look-up
to retrieve a number or a group from
Contacts, or select from the last used
recipients list.
}OK }Send }As postcard.
The picture and message will be
printed on a postcard and sent
to the address that you select.
Picture messaging (MMS)
Picture messages can contain text,
pictures, camera pictures, slides,
sound recordings, video clips,
signatures and attachments. You can
send picture messages to a mobile
phone or an email address.
Before you start
Both you and the recipient must have
subscriptions that support picture
messaging.
If no Internet profile or message server
exists, you can receive all the settings
for MMS automatically from your
network operator, www.vodafone.com
or from www.sonyericsson.com/
support.
Before sending a picture message,
you can check:
The address of your message server
and an Internet profile are set
}Messaging }Settings }MMS
}MMS profile and select a profile.
}More }Edit }Message server and
}More }Edit }Internet profile.
To create and send a picture message
1}Messaging }Create new }MMS
}More to view a list of items to add
to your message. Select an item.
2}More to add more items to the
message. For specific item options,
select the item }More and select
the option type to edit.
Please check with your network operator
if you can send Postcards from your
phone or visit www.vodafone.com.
V630i-SHUG-Vodafone-R1A-EN.book Page 26 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
27Messaging
3When ready to send }Continue.
4}Enter email addr. or
}Enter phone no. or
}Contacts look-up to retrieve a
number or group in Contacts or select
from last used recipients }Send.
To create your own signature
for picture messages
1}Messaging }Settings }MMS.
2}Signature }New signature and
create your signature as a picture
message.
To set default picture message
options
}Messaging }Settings }MMS and
select options to change.
Email
Read your email messages in your
phone at any time. The email address
that you use on your computer can
also be used in your phone. To do this,
your phone needs the same email
settings as used by your computer for
email address. To use your computer
email address in your phone, do one
of the following:
•Receive settings automatically
The easiest way is to have settings
sent directly to your phone. Use
Internet on your computer to go to
www.vodafone.com or
www.sonyericsson.com/support.
•Enter settings manually
•Ask your email provider for settings
information. An email provider is the
person or company who provided
your email address, for example,
your IT administrator at work or an
Internet provider, or
•you may have a document at home
from your email provider with the
settings information, or
•you may find the information in your
computer email program settings.
What information do I need?
The minimum you need is the
following:
When writing and editing picture
messages you can use the copy and
paste functionality %25 To copy and
paste text in a message.
Setting types Examples
Connection type POP3 or IMAP4
Email address joe.smith@example.com
Incoming server mail.example.com
Username jsmith
Password zX123
Outgoing server mail.example.com
V630i-SHUG-Vodafone-R1A-EN.book Page 27 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
28 Messaging
There are also setup instructions and
help information as you enter settings.
To enter email settings
1}Messaging }Email }Settings.
2After settings are entered, }Inbox
}More }Send & receive to access
your email.
When settings are entered, your
phone can connect to an email server
to send and receive email messages.
For more information, contact your
email provider, visit www.vodafone.com
or see the User guide with additional
information at www.sonyericsson.com/
support.
Push email
Receive a notification in your phone
from your email server that you have
new email, if supported by your email
provider.
To turn on push email notification
•When using send & receive, }Yes
to turn on, if required or
•}Messaging }Email }Settings.
Select an account to edit }More
}Edit account }Advanced settings
}Push email and select an option.
Vodafone Messenger
Connect and log in to the Messenger
server to communicate online with
your favourite friends. If your
subscription supports instant
messaging and presence services,
you can send and receive messages
and see contact status if online. If no
settings exist in your phone, you need
to enter server settings.
To log in to your Messenger server
}Messaging }Messenger }Log in.
To log out
}More }Log out.
To add a contact to the list
}Messaging }Messenger }the
Contacts tab }More }Add contact.
To send a chat message from
Messenger
1}Messaging }Messenger }the
Contacts tab and select a contact
from the list.
2}Chat and type your message }Send.
There are many different email providers.
Their terminology and required information
may differ. Not all service providers allow
email access.
Contact your network operator for more
information.
You can also continue a chat conversation,
use or to scroll to the
Conversations tab.
V630i-SHUG-Vodafone-R1A-EN.book Page 28 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
29Messaging
Status
Show your status to your contacts
only or show it to all users on the
Messenger server.
To set status
1}Messaging }Messenger }More
}Settings and select
Show my status.
2Choose To all or Only to contacts
}Select.
To change your own status
}Messaging }Messenger }the
My status tab and update your status
information. Use or to scroll
between the status fields.
Chat group
A chat group can be started by your
service provider, by an individual
Messenger user or by yourself. You
can save chat groups by saving a chat
invitation or by searching for a specific
chat group.
To start a chat group
1}Messaging }Messenger
}the Chat groups tab }More
}Add chat group }New chat group.
2Select who to invite to the chat group
from your contacts list }Continue.
3Enter a short invitation text }Continue
}Send.
To add a chat group
1}Messaging }Messenger
}the Chat groups tab }More
}Add chat group.
2}By group ID to enter chat group ID
directly or }Search to search for
achat group.
To save a conversation
}Messaging }Messenger
}the Conversations tab and open
aconversation }More }Save conv.
To view a saved conversation
}Messaging }Messenger
}the Conversations tab }More
}Saved conv.
To view watching users
}Messaging }Messenger
}the Contacts tab }More
}Watching users. A list of users
on the Messenger server watching
my status info appears.
Conversation history is preserved
between log in and log out to let you
return to chat messages from old
conversations.
V630i-SHUG-Vodafone-R1A-EN.book Page 29 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
30 Messaging
To view or edit settings
}Messaging }Messenger }More
}Settings and select an option:
•Show my status:
•Sort contacts:
•IM alert:
•Server settings:
•Auto-login:
•Allow connection:
Contact your network operator for more
information.
V630i-SHUG-Vodafone-R1A-EN.book Page 30 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
31Imaging
Imaging
Camera, video, blog, pictures.
Camera and video recorder
Take pictures and record video clips
to save, view and send in messages
%7 Take pictures or record video
clips.
Camera settings
When you are in the viewfinder
}Settings for options to adjust and
enhance your pictures and video clips
before taking or recording them.
To use the zoom
Use volume buttons to zoom in and out.
To adjust brightness
Use the navigation key to increase
or decrease brightness.
Camera and video options
When the camera or video is activated
}Settings for the following options:
•Switch to video camera to record
a video clip or Switch to still camera
to take a picture.
•Shoot mode (camera):
•Normal – no frame.
•Panorama – join several pictures
into one.
•Frames – add a frame to your
picture.
•Burst – take a rapid sequence
of pictures.
•Shoot mode (video):
•For MMS
•High quality video
•Picture size (camera) – select from:
•2MP (1600x1200 pixels)
•1MP (1280x960)
•VGA (640x480)
•Turn on night mode – adapt to poor
lighting conditions.
•Turn on self-timer (camera) – take
a picture a few seconds after pressing
the camera button.
•Effects – select from:
•Off – no effect.
•Black & white – no colour.
•Negative – reversed colours.
•Sepia – brown tint.
•White balance – adjust colours to
lighting conditions. Select from Auto,
Daylight, Cloudy, Fluorescent
or Incandescent.
•Picture quality (camera):
•Normal
•Fine
•Turn off mic. (video) – set microphone.
If you try to record with a strong light
source such as direct sunlight or a lamp
in the background, the screen may black
out or the picture may be distorted.
V630i-SHUG-Vodafone-R1A-EN.book Page 31 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
32 Imaging
•Shutter sound (camera) – select
different shutter sounds.
•Turn on time and date (camera) – add
time and date to a picture to appear as
red text in the lower right corner. View
in 1:1 size or use zoom when viewing
a picture to see the text.
•Reset file number – reset the file
number counter.
•Save to – select to save to
Memory Stick or Phone memory.
Camera shortcuts
When using the camera, you can also
use keys as shortcuts to common
options. Press for a camera key
guide.
Transferring pictures
Transfer to your computer
Using the USB cable, you can drag
and drop camera pictures to a
computer %39 Transferring files using
the USB cable.
To further enhance and organize
camera pictures on a computer,
Windows® users can install Adobe®
Photoshop® Album Starter Edition,
included on the CD with phone or visit
www.sonyericsson.com/support.
Blog on the Internet
Send pictures to publish in a blog
if your subscription supports it.
To send camera pictures to a blog
1When viewing a picture you have just
taken }More }Blog this.
2Follow the instructions that appear for
first-time use, for example, approve
terms and conditions.
3Add title and text }OK }Publish
to send a picture to your blog.
A text message is sent to your phone
with your Web address and log-in
information. You can forward the text
message for others to access your
Web page photos.
To send pictures to a blog
1}My Files and select a picture
in a folder.
2}More }Send }To blog.
3Add title and text }OK }Publish.
To visit a blog address in a contact
}Contacts and select a contact Web
address }Go to.
Using blogging Web services may
require a separate license agreement
between you and your service provider.
Please check with your network operator
if you can send a picture from your phone
to your blog, or visit www.vodafone.com.
V630i-SHUG-Vodafone-R1A-EN.book Page 32 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
33Imaging
Pictures
View and use pictures.
To view and use pictures
1}My Files }Pictures.
2Select a picture }View or }More
}Use as and select an option.
To send a picture
}My Files }Pictures and scroll to
apicture. }More }Send and select
atransfer method.
To receive a picture
}Settings }Connectivity and select
atransfer method.
live! Studio
With Vodafone live! you can save
pictures in a Web-based album.
This is useful if you are running out
of phone memory, or if you wish to
share your pictures with friends in
a virtual album that you can access
on the Web. You can upload a picture
in the following ways.
To upload a picture
•}My Files }Pictures select a picture
}More }Send }live! Studio.
•From the camera, take a picture
}Send }live! Studio
You can also upload a message by
selecting a folder in Messaging,
highlight a message }More
}live! Studio.
Some phones cannot receive large
picture sizes.
Visit www.vodafone.com for details. This
service is not available in all countries.
V630i-SHUG-Vodafone-R1A-EN.book Page 33 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
34 Entertainment
Entertainment
Music and Video player, ringtones.
Music and video player
Your phone supports, for example, the
following file types: MP3, MP4, M4A,
3GPP, AMR, MIDI, iMelody, eMelody,
WMA, WMV, WAV (16 kHz maximum
sample rate) and Real®8. The phone
also supports streamed files that are
3GPP compatible.
To play music and videos
1}Music Player or }Entertainment
}Video player. A player browser
opens.
2Browse for music by artist or track,
or in playlists. You can also browse
for video clips. Select a list }Open.
3Highlight a title }Play.
The following options are available:
•Press to play or stop during
playback.
•Press to stop the playback. Press
again to resume playing.
•Press to go to the next music file.
•Press to go to the previous music file.
•Press and hold or to fast forward
or rewind when playing music files or
video clips.
•Press Play to select a highlighted file.
•When in Now playing, press
to go to the music player browser.
•When playing music, }More for
options, for example, Minimize to use
in the background.
•Press and hold to exit.
Ringtones and melodies
You can exchange music, sounds and
tracks, for example, using one of the
available transfer methods.
To select a ringtone
}Settings }and scroll to the
Sounds & alerts tab }Ringtone.
To turn the ringtone on or off
Press and hold from standby
or }Settings }the Sounds & alerts
tab for more options. All signals
except the alarm signal are affected.
To set ringtone volume
1}Settings }and scroll to the
Sounds & alerts tab }Ring volume
and press or to decrease or
increase the volume.
2}Save.
You are not allowed to exchange
some copyright-protected material.
A copyright-protected file has a key
symbol.
V630i-SHUG-Vodafone-R1A-EN.book Page 34 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
35Connectivity
To set the vibrating alert
}Settings }the Sounds & alerts tab
}Vibrating alert and select an option.
Sounds and alerts options
From Settings }the Sounds & alerts
tab, you can set:
•Message alert – select how to be
notified of an incoming message.
•Key sound – select what sound
to hear when you press the keys.
Connectivity
Vodafone live!, Internet, synchronising,
Bluetooth, USB cable, update service.
live! intro
You can view an introduction to
Vodafone live! services and Vodafone
live! content such as ringtones, videos
and trial games, free of charge. The
live! intro function automatically opens
the Internet browser without
connecting to the Internet. The
browser displays pages that are saved
on the memory card.
To start live! intro
}Entertainment }live! intro.
To end live! intro
}More }Exit browser.
To deactivate live! intro
}Settings }the General tab
}live! intro and select Off.
If you delete live! intro, or format the
memory card, live! intro will no longer
be available.
V630i-SHUG-Vodafone-R1A-EN.book Page 35 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
36 Connectivity
Vodafone live!
Vodafone live! has everything you
need, full of information, games,
music, ringtones and other
entertainment. It is easy to use and
can be “always on”, so there is no wait
for dialling up. You pay only for data
you send or receive, not for how long
you are connected.
Your phone has already been
customized to give access to
Vodafone live! – Vodafone’s mobile
Internet portal. You should already be
registered, and do not need to change
or configure any settings.
If you have problems connecting to
Vodafone live!, the Internet or using
email, please contact your network
operator or visit www.vodafone.com.
Your network customer care can
provide you with the correct settings
via SMS. Settings are also available
at www.sonyericsson.com/support.
To download settings
1On your computer, browse to
www.sonyericsson.com/support.
2Select a region and a country
or Global support area.
3Select the Phone setup tab, and select
a phone model.
4Select which setting to download to
your phone.
Connect to Vodafone live!
Go to the Vodafone live! offline Web
page }Vodafone live!. This menu is
offline, so you will not be connected
until you choose a link.
From standby, you can also }Toolbar
and scroll for Internet options.
To exit, press and hold .
The following describes some of the
services you can choose:
Vodafone live! services
•Download sounds and ringtones,
pictures, animations and wallpaper,
new game, video and music clips
(or stream them) and themes for a new
look to menus.
•Live! Studio – online storage for your
pictures and sounds.
•Vodafone Mail – a single mailbox for all
your email messages, voicemail and
faxes.
•Vodafone Messenger – instant
messaging on your mobile phone.
•News – get the latest news reports
and weather forecasts.
•Sport – news, results, and latest
scores.
•Search – find what you need
in Vodafone live!.
V630i-SHUG-Vodafone-R1A-EN.book Page 36 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
37Connectivity
To download from the Vodafone live!
Portal
1}Vodafone live! and select a link.
2Browse the Web page, select a file to
download and follow the instructions
that appear.
Ticker
Use the Vodafone Ticker for news,
weather updates, sports and other
information depending on your
preferred information channel
selection.
To use Ticker
From standby, }Ticker.
To view Ticker settings
When using Ticker, }More }Settings
and select an option. You can also
view Ticker settings from standby,
}Settings }the General tab }Ticker.
For more information, visit
www.vodafone.com.
Synchronising
Synchronise phone contacts,
appointments, tasks and notes via
Bluetooth wireless technology,
Internet services or the USB cable
included with the phone.
Synchronisation with a computer
Install synchronisation software for
your computer found in the
Sony Ericsson PC Suite on the CD,
included with the phone. The software
includes help information. You can
also visit www.sonyericsson.com/
support to download the software or
the document Getting Started Guide
for synchronization.
Remote synchronisation via Internet
Synchronise online via an Internet
service.
Before you start
•Register a synchronisation account
online.
•Enter remote synchronisation
settings.
To enter remote synchronisation
settings
1}Organiser & Tools
}Synchronisation }New account
}Yes to create a new account.
2Enter a name for the new account
}Continue.
Vodafone live! is growing and kept up
to date on a daily basis, so these options
may vary. Keep checking it out to see
what´s new. Questions about Vodafone
live! products and services should be
directed to Vodafone Customer Services.
V630i-SHUG-Vodafone-R1A-EN.book Page 37 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
38 Connectivity
3Enter the following:
•Server address – server URL.
•Username – account username.
•Password – account password.
•Connection – select an Internet
profile.
•Applications – mark applications
to synchronise.
•App. settings – select an
application and enter a database
name, and if required, username
and password.
•Sync. interval – set how often
to synchronise.
•Remote initiation – select to always
accept, never accept or always ask
when starting synchronisation from
a service.
•Remote security – insert a server ID
and a server password.
4}Save to save your new account.
To start remote synchronisation
}Organiser & Tools
}Synchronisation and select
an Bluetooth™ wireless technology
The Bluetooth function makes wireless
connection to other Bluetooth devices
possible.
Before you start
•Turn on the Bluetooth function to
communicate with other devices.
•Add Bluetooth devices to your
phone to communicate with.
To turn the Bluetooth function on
}Settings }the Connectivity tab
}Bluetooth }Turn on.
Adding devices to your phone
Enter a passcode to set up a secure
link between your phone and the
device. Enter the same passcode on
the device when prompted. A device
with no user interface, such as a
handsfree, will have a predefined
passcode. Consult the device User
guide for more information.
We recommend a range within 10 metres,
with no solid objects in between,
for Bluetooth communication.
Please check if local laws or regulations
restrict the use of Bluetooth wireless
technology. If Bluetooth wireless
technology is not allowed, you must
ensure that the Bluetooth function is
turned off. The maximum allowed
Bluetooth radio output power in the
phone is automatically adjusted
according to possible local restrictions.
This means range may vary.
Make sure that the device you want to
add has the Bluetooth function activated
and is visible.
V630i-SHUG-Vodafone-R1A-EN.book Page 38 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
39Connectivity
To add a device to your phone
1}Settings }the Connectivity tab
}Bluetooth }My devices
}New device to search for available
devices. Make sure the other device
is visible.
2Select a device from the list.
3Enter a passcode, if required.
To allow connection or edit your
device list
1}Settings }the Connectivity tab
}Bluetooth }My devices and select
a device from the list.
2}More to view a list of options.
To add a Bluetooth handsfree
1}Settings }the Connectivity tab
}Bluetooth }Handsfree.
2}Yes if you are adding a Bluetooth
handsfree for the first time or
}My handsfree }New handsfree
}Add if you are adding another
Bluetooth handsfree. Ensure that your
handsfree is in the correct mode.
Consult the device User guide for
more information.
Phone name
Enter a name for your phone to be
shown as when other devices find it.
To enter a phone name
}Settings }the Connectivity tab
}Bluetooth }Phone name.
Visibility
Choose to make your phone visible to
other Bluetooth devices or not. If your
phone is set to hide, only devices in
}Settings }the Connectivity tab
}Bluetooth }My devices are able to
find your phone via Bluetooth wireless
technology.
To show or hide your phone
}Settings }the Connectivity tab
}Bluetooth }Visibility
}Show phone or Hide phone.
Transferring files using the
USB cable
Connect your phone to a computer,
via the USB cable, to use your phone
in one of the following: File transfer
or Phone mode.
File transfer
Drag and drop files between your
memory card and computer in
Microsoft Windows Explorer.
Use Sony Disc2Phone (music transfer)
or Adobe Photoshop Album Starter
Edition (picture transfer/storage).
V630i-SHUG-Vodafone-R1A-EN.book Page 39 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
40 Connectivity
These applications are found on the
CD that come with the phone or at,
and can only be used with file transfer
mode.
To use file transfer mode
1Connect the USB cable to the phone
and the computer.
2Phone: Select File transfer or
}Settings }the Connectivity tab
}USB }USB connection
}File transfer. The phone shuts
down.
3Wait until your memory card appears
as an external disk in Windows
Explorer. You can use:
•Windows Explorer to drag and drop
files between your memory card
and computer.
•Sony Disc2Phone to transfer music
to your memory card.
•Adobe Photoshop Album Starter
Edition, to transfer and organize
your pictures on your computer.
To disconnect the USB cable safely
1When using file transfer mode,
right-click the removable disk icon
in Windows Explorer and select Eject.
2Remove the USB cable from your
phone.
Phone mode
Synchronise contacts and calendar,
transfer files, use the phone as modem
and more from your computer.
Applications supported in phone
mode include: Synchronisation,
My Files and Mobile Networking
Wizard. For other applications,
use the file transfer mode.
You need to install and use
Sony Ericsson PC Suite, included on
the CD that came with the phone or
found at www.sonyericsson.com/
support.
Only use the USB cable that comes with
the phone, and connect the USB cable
directly to your computer. Do not remove
the USB cable from the phone or
computer during file transfer as this
may corrupt the memory card.
V630i-SHUG-Vodafone-R1A-EN.book Page 40 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
41Connectivity
To use phone mode
1Computer: Install the Sony Ericsson
PC Suite from the CD that came with
your phone.
2Computer: Start PC Suite from Start/
Programs/Sony Ericsson/PC Suite.
3Connect the USB cable to the phone
and the computer.
4Phone: Select Phone mode
or }Settings }the Connectivity
tab }USB }USB connection
}Phone mode.
5Computer: Wait while Windows
installs the required drivers.
6Computer: When PC Suite has found
your phone you are notified.
All applications that you can use
with your connected phone are
found in the Sony Ericsson PC Suite.
Update service
Always keep your phone updated
with the latest software to improve
performance. You do not lose
personal or phone information, for
example messages or settings during
an update.
•over the air via your phone.
•via the provided USB cable and an
Internet-connected computer.
To use Update service over the air
1}Settings }the General tab
}Update service.
2}Search for update to search for the
latest available software.
3Start the update process by following
the installation instructions, or
}Software version to show the
current software in your phone,
or }Reminder to set when to search
for new software.
To use Update service
1Visit www.sonyericsson.com/support.
2Select a region and country.
3Enter the product name.
4Select Sony Ericsson Update Service
and follow the instructions.
Your computer needs to have one of the
following operating systems to be able
to use this feature: Windows 2000 with
SP3/SP4, Windows XP (Pro and Home)
with SP1/SP2.
USB drivers are installed automatically
with the PC Suite software.
The update service requires data access
(GPRS). Your operator will provide you
with a subscription with data access and
price information.
V630i-SHUG-Vodafone-R1A-EN.book Page 41 Thursday, May 4, 2006 2:36 PM
There are two ways to update your
phone:
PPreflighted byreflighted byPreflighted by ( )( )( )
42 More features
More features
Alarm clock, calendar.
Alarms
Set an alarm for a specific time
or specific days to recur on.
To use alarms
1}Organiser & Tools }Alarms and
select an alarm to set }Edit.
2Time: }Edit and set a time }OK.
Select more options, if required:
•Recurrent: }Edit and set a day
or days }Mark }Done.
•Alarm signal: }Edit and select
a sound.
•Press to edit text, pictures and
the silent mode for alarms.
3}Save.
To turn an alarm signal off when
it sounds
Press any key. If you do not want
to repeat the alarm }Turn off.
To cancel an alarm
}Organiser & Tools }Alarms and
select an alarm, }Turn off.
Calendar
You can use the calendar to keep
track of important meetings. The
calendar can be synchronised with a
computer calendar or with a calendar
on the Web %37 Synchronising.
Appointments
Add new appointments or use existing
appointments as templates.
To add a new appointment
1}Organiser & Tools }Calendar and
select a date }Select
}New appointm. }Add.
2Select from the following options and
confirm each entry, if required:
•General tab - subject, start time,
duration, reminder, start date.
•Details tab - location, description,
all day, recurrence.
3}Save.
To view an appointment
1}Organiser & Tools }Calendar and
select a day (appointment days
marked with frames).
2Select an appointment }View.
To view a calendar week
}Organiser & Tools }Calendar
}More }View week.
V630i-SHUG-Vodafone-R1A-EN.book Page 42 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
43More features
To set when reminders should sound
1}Organiser & Tools }Calendar
}More }Advanced }Reminders.
2}Always for a reminder to sound even
when the phone is turned off or set to
silent. When the reminder sounds
}Yes to read the appointment or }No
to turn off the reminder. A reminders
option set in the calendar affects
a reminders option set in tasks.
Navigating in your calendar
Use the navigation key to move
between days or weeks. In the
monthly and weekly views, you can
also use the keypad as follows.
Calendar settings
}Organiser & Tools }Calendar
}More to select an option:
•View week – view the week’s
appointments.
•New appointm. – add a new
appointment.
•Change date – go to another date
in the calendar.
•Advanced – find an appointment,
set reminders or select a start day
for the week.
•Delete – delete old or all
appointments.
•Help – for more information.
Exchanging appointments
Exchange appointments using
a transfer method. You can also
synchronise appointments with
acomputer
%37 Synchronising.
To send an appointment
Select an appointment in the list for a
certain day }More }Send and select
a transfer method.
Today’s date
Back a week Next week
Back a month Next month
Back a year Next year
V630i-SHUG-Vodafone-R1A-EN.book Page 43 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
44 Important information
Important information
Sony Ericsson Consumer Web site
On www.sonyericsson.com/support is
a support section where help and tips
are only a few clicks away. Here you
will find the latest computer software
updates and tips on how to use your
product more efficiently.
Service and support
From now on you will have access to a portfolio
of exclusive service advantages such as:
•Global and local websites providing support.
•A global network of Call Centers.
•An extensive network of Sony Ericsson service
partners.
•A warranty period. Learn more about the warranty
conditions in this user guide.
On www.sonyericsson.com, under the support
section in the language of your choice, you will find
the latest support tools and information, such as
software updates, Knowledge base, phone setup
and additional help when you require it.
For operator-specific services and features, please
contact your network operator for more
information.
You can also contact our Call Centers. See the
phone number for the nearest Call Center in the list
below. If your country/region is not represented in
the list, please contact your local dealer. (The
phone numbers below were correct at the time of
going to print. On www.sonyericsson.com you can
always find the latest updates.
In the unlikely event that your product needs
service please contact the dealer from whom it was
purchased or one of our service partners. Save
your original proof of purchase, you will need it if
you need to claim warranty.
For a call to one of our Call Centers you will be
charged according to national rates, including local
taxes, unless the phone number is a toll-free
number.
Country Phone number Email address
Australia 1-300 650 050 questions.AU@support.sonyericsson.com
Argentina 800-333-7427 questions.AR@support.sonyericsson.com
Austria 0810 200245 questions.AT@support.sonyericsson.com
Belgium 02-7451611 questions.BE@support.sonyericsson.com
Brazil 4001-0444 questions.BR@support.sonyericsson.com
Canada 1-866-766-9374 questions.CA@support.sonyericsson.com
Central Africa +27 112589023 questions.CF@support.sonyericsson.com
Chile 123-0020-0656 questions.CL@support.sonyericsson.com
China 4008100000 questions.CN@support.sonyericsson.com
Colombia 18009122135 questions.CO@support.sonyericsson.com
Croatia 062 000 000 questions.HR@support.sonyericsson.com
Czech Republic 844 550 055 questions.CZ@support.sonyericsson.com
Denmark 33 31 28 28 questions.DK@support.sonyericsson.com
Finland 09-299 2000 questions.FI@support.sonyericsson.com
V630i-SHUG-Vodafone-R1A-EN.book Page 44 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
45Important information
France 0 825 383 383 questions.FR@support.sonyericsson.com
Germany 0180 534 2020 questions.DE@support.sonyericsson.com
Greece 801-11-810-810
210-89 91 919 (from mobile phone) questions.GR@support.sonyericsson.com
Hong Kong 8203 8863 questions.HK@support.sonyericsson.com
Hungary +36 1 880 47 47 questions.HU@support.sonyericsson.com
India 1800 11 1800 (Toll free number)
39011111 (from mobile phone) questions.IN@support.sonyericsson.com
Indonesia 021-2701388 questions.ID@support.sonyericsson.com
Ireland 1850 545 888 questions.IE@support.sonyericsson.com
Italy 06 48895206 questions.IT@support.sonyericsson.com
Malaysia 1-800-889900 questions.MY@support.sonyericsson.com
Mexico 01 800 000 4722
(national toll free number) questions.MX@support.sonyericsson.com
Netherlands 0900 899 8318 questions.NL@support.sonyericsson.com
New Zealand 0800-100150 questions.NZ@support.sonyericsson.com
Norway 815 00 840 questions.NO@support.sonyericsson.com
Philippines 02-6351860 questions.PH@support.sonyericsson.com
Poland 0 (prefix) 22 6916200 questions.PL@support.sonyericsson.com
Portugal 808 204 466 questions.PT@support.sonyericsson.com
Romania (+4021) 401 0401 questions.RO@support.sonyericsson.com
Russia 8(495) 787 0986 questions.RU@support.sonyericsson.com
Singapore 67440733 questions.SG@support.sonyericsson.com
Slovakia 02-5443 6443 questions.SK@support.sonyericsson.com
South Africa 0861 632222 questions.ZA@support.sonyericsson.com
Spain 902 180 576 questions.ES@support.sonyericsson.com
Sweden 013-24 45 00 questions.SE@support.sonyericsson.com
Switzerland 0848 824 040 questions.CH@support.sonyericsson.com
Taiwan 02-25625511 questions.TW@support.sonyericsson.com
Thailand 02-2483030 questions.TH@support.sonyericsson.com
Turkey 0212 47 37 777 questions.TR@support.sonyericsson.com
Ukraine (+380) 44 590 1515 questions.UA@support.sonyericsson.com
United Arab Emirates 43 919880 questions.AE@support.sonyericsson.com
United Kingdom 08705 23 7237 questions.GB@support.sonyericsson.com
United States 1-866-766-9374 questions.US@support.sonyericsson.com
Venezuela 0-800-100-2250 questions.VE@support.sonyericsson.com
V630i-SHUG-Vodafone-R1A-EN.book Page 45 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
46 Important information
Guidelines for Safe and Efficient Use
Please read this information before
using your mobile phone.
These instructions are intended for
your safety. Please follow these
guidelines. If the product has been
subject to any of the conditions listed
below or you have any doubt as to its proper
function make sure you have the product checked
by a certified service partner before charging or
using it. Failure to do so might entail a risk of
product malfunction or even a potential hazard
to your health.
Recommendations for safe use
of product (mobile phone, battery,
charger and other accessories)
•Always treat your product with care and keep
it in a clean and dust-free place.
•Warning! May explode if disposed of in fire.
•Do not expose your product to liquid or moisture
or humidity.
•Do not expose your product to
extremely high or low temperatures.
Do not expose the battery to
temperatures above +60°C (+140°F).
•Do not expose your product to open
flames or lit tobacco products.
•Do not drop, throw or try to bend your product.
•Do not paint your product.
•Do not attempt to disassemble or
modify your product. Only
Sony Ericsson authorized personnel
should perform service.
•Do not use your product near medical
equipment without requesting
permission from your treating physician or
authorized medical staff.
•Do not use your product when in, or around
aircraft, or areas showing the sign “turn off two-way
radio”.
•Do not use your product in an area
where a potentially explosive
atmosphere exists.
•Do not place your product or install
wireless equipment in the area above
an air bag in your car.
CHILDREN
KEEP OUT OF CHILDRENS REACH.
DO NOT ALLOW CHILDREN TO PLAY
WITH YOUR MOBILE PHONE OR ITS
ACCESSORIES. THEY COULD HURT
THEMSELVES OR OTHERS, OR
COULD ACCIDENTALLY DAMAGE THE MOBILE
PHONE OR ACCESSORY. YOUR MOBILE PHONE
OR ITS ACCESSORY MAY CONTAIN SMALL
PARTS THAT COULD BECOME DETACHED AND
CREATE A CHOKING HAZARD.
Power supply (Charger)
Connect the AC power adapter only to designated
power sources as marked on the product. Make
sure the cord is positioned so that it will not be
subjected to damage or stress. To reduce risk
of electric shock, unplug the unit from any power
source before attempting to clean it. The AC power
adapter must not be used outdoors or in damp
areas. Never alter the cord or plug. If the plug does
not fit into the outlet, have a proper outlet installed
by a qualified electrician.
Use only Sony Ericsson branded original chargers
intended for use with your mobile phone. Other
chargers may not be designed to the same safety
and performance standards.
Battery
We recommend that you fully charge the battery
before you use your mobile phone for the first time.
A new battery or one that has not been used for a
long time could have reduced capacity the first few
times it is used. The battery should only be charged
in temperatures between +5°C (+41°F) and +45°C
(+113°F).
V630i-SHUG-Vodafone-R1A-EN.book Page 46 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
47Important information
Use only Sony Ericsson branded original batteries
intended for use with your mobile phone. Using
other batteries and chargers could be dangerous.
Talk and standby times depend on several different
conditions such as signal strength, operating
temperature, application usage patterns, features
selected and voice or data transmissions when
the mobile phone is being used.
Turn off your mobile phone before removing the
battery. Do not put the battery into your mouth.
Battery electrolytes may be toxic if swallowed.
Do not let the metal contacts on the battery touch
another metal object. Doing this could short-circuit
and damage the battery. Use the battery for the
intended purpose only.
Personal medical devices
Mobile phones may affect the operation of
pacemakers and other implanted equipment.
Please avoid placing the mobile phone over the
pacemaker, e.g. in your breast pocket. When using
the mobile phone, use it at the ear on the opposite
side of the body to the pacemaker. If a minimum
distance of 15 cm (6 inches) is kept between
the mobile phone and the pacemaker, the risk
of interference is limited. If you have any reason
to suspect that interference is taking place,
immediately turn off your mobile phone. Contact
your cardiologist for more information.
For other medical devices, please consult your
physician and the manufacturer of the device.
Driving
Please check if local laws and regulations restrict
the use of mobile phones while driving or require
drivers to use handsfree solutions. We recommend
that you use only Sony Ericsson handsfree
solutions intended for use with your product.
Please note that because of possible interference
to electronic equipment, some vehicle
manufacturers forbid the use of mobile phones
in their vehicles unless a handsfree kit with
an external antenna has been installed.
Always pay full attention to driving and pull off
the road and park before making or answering
a call if driving conditions so require.
Emergency calls
Mobile phones operate using radio signals, which
cannot guarantee connection in all conditions. You
should therefore never rely solely upon any mobile
phone for essential communications (e.g. medical
emergencies).
Emergency calls may not be possible in all areas,
on all cellular networks, or when certain network
services and/or mobile phone features are in use.
Check with your local service provider.
Antenna
This phone contains a built-in antenna. Use of
antenna devices not marketed by Sony Ericsson
specifically for this model could damage your
mobile phone, reduce performance, and produce
SAR levels above the established limits (see below).
Efficient use
Hold your mobile phone as you would any other
phone. Do not cover the top of the phone when it
is in use, as this affects call quality and may cause
the phone to operate at a higher power level than
needed, thus shortening talk and standby times.
Radio frequency (RF) exposure and
Specific Absorption Rate (SAR)
Your mobile phone is a low-power radio transmitter
and receiver. When it is turned on, it emits low
levels of radio frequency energy (also known
as radio waves or radio frequency fields).
Governments around the world have adopted
comprehensive international safety guidelines,
developed by scientific organizations, e.g. ICNIRP
V630i-SHUG-Vodafone-R1A-EN.book Page 47 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
48 Important information
(International Commission on Non-Ionizing
Radiation Protection) and IEEE (The Institute of
Electrical and Electronics Engineers Inc.), through
periodic and thorough evaluation of scientific
studies. These guidelines establish permitted levels
of radio wave exposure for the general population.
The levels include a safety margin designed to
assure the safety of all persons, regardless of age
and health, and to account for any variations
in measurements.
Specific Absorption Rate (SAR) is the unit of
measurement for the amount of radio frequency
energy absorbed by the body when using a mobile
phone. The SAR value is determined at the highest
certified power level in laboratory conditions, but
the actual SAR level of the mobile phone while
it is operating can be well below this value. This
is because the mobile phone is designed to use
the minimum power required to reach the network.
Variations in SAR below the radio frequency
exposure guidelines do not mean that there are
variations in safety. While there may be differences
in SAR levels among mobile phones, all
Sony Ericsson mobile phone models are designed
to meet radio frequency exposure guidelines.
For phones sold in the U.S, before a phone model
is available for sale to the public, it must be tested
and certified by the Federal Communications
Commission (FCC) that it does not exceed the limit
established by the government-adopted
requirement for safe exposure. The tests are
performed in positions and locations (that is,
at the ear and worn on the body) as required by
the FCC for each model. For body-worn operation,
this phone has been tested and meets FCC RF
exposure guidelines when the handset is
positioned a minimum of 15 mm from the body
without any metal parts in the vicinity of the phone
or when used with the original Sony Ericsson
accessory intended for this phone and worn on
the body. Use of other accessories may not ensure
compliance with FCC RF exposure guidelines.
A separate leaflet with SAR information on/about
this mobile phone model is included with the
material accompanying this mobile phone. This
information can also be found, together with more
information on radio frequency exposure and SAR,
on: www.sonyericsson.com/health.
Accessible Solutions/Special Needs
For phones sold in the US, you can use your TTY
terminal with your Sony Ericsson mobile phone
(with the necessary accessory). For information on
Accessible Solutions for individuals with special
needs call the Sony Ericsson Special Needs Center
on 877 878 1996 (TTY) or 877 207 2056 (voice),
or visit the Sony Ericsson Special Needs Center
at www.sonyericsson-snc.com.
Disposal of old electrical &
electronic equipment
This symbol on the product or on its
packaging indicates that this product
shall not be treated as household
waste. Instead it shall be left at the
appropriate collection point for recycling of
electrical and electronic equipment. By ensuring
this product is disposed of correctly, you will help
prevent potential negative consequences for the
environment and human health, which could
otherwise be caused by inappropriate waste
handling of this product. The recycling of materials
will help to conserve natural resources. For more
detailed information about recycling this product,
please contact your local city office, your
household waste disposal service or the shop
where you purchased the product.
Disposing of the battery
Please check local regulations for
disposal of batteries or call your local
Sony Ericsson Call Center for
information.
The battery should never be placed in municipal
waste. Use a battery disposal facility if available.
V630i-SHUG-Vodafone-R1A-EN.book Page 48 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
49Important information
End User Licence Agreement
This wireless device, including without limitation
any media delivered with the device, (“Device”)
contains software owned by Sony Ericsson Mobile
Communications AB and its affiliated companies
(“Sony Ericsson”) and its third party suppliers and
licensors (“Software”).
As user of this Device, Sony Ericsson grants you
a non-exclusive, non-transferable, non-assignable
license to use the Software solely in conjunction
with the Device on which it is installed and/or
delivered with. Nothing herein shall be construed
as a sale of the Software to a user of this Device.
You shall not reproduce, modify, distribute, reverse
engineer, decompile, otherwise alter or use any
other means to discover the source code of the
Software or any component of the Software. For
avoidance of doubt, you are at all times entitled to
transfer all rights and obligations to the Software
to a third party, solely together with the Device with
which you received the Software, provided always
that such third party agrees in writing to be bound
by these rules.
You are granted this license for a term of the useful
life of this Device. You can terminate this license
by transferring all your rights to the Device on
which you have received the Software to a third
party in writing. If you fail to comply with any of
the terms and conditions set out in this license,
it will terminate with immediate effect.
Sony Ericsson and its third party suppliers and
licensors are the sole and exclusive owner of and
retain all rights, title and interest in and to the
Software. Sony Ericsson, and, to the extent that
the Software contains material or code of a third
party, such third party, shall be entitled third party
beneficiaries of these terms.
The validity, construction and performance of this
license shall be governed by the laws of Sweden.
The foregoing shall apply to the full extent
permitted by, when applicable, statutory consumer
rights.
Limited Warranty
Sony Ericsson Mobile Communications AB,
S-221 88 Lund, Sweden, (Sony Ericsson), provides
this Limited Warranty for your mobile phone and
original accessory delivered with your mobile
phone (hereinafter referred to as “Product”).
Should your Product need warranty service, please
return it to the dealer from whom it was purchased,
or contact your local Sony Ericsson Call Center
(national rates may apply) or visit
www.sonyericsson.com to get further information.
OUR WARRANTY
Subject to the conditions of this Limited Warranty,
Sony Ericsson warrants this Product to be free
from defects in design, material and workmanship
at the time of its original purchase by a consumer,
and for a subsequent period of one (1) year.
WHAT WE WILL DO
If, during the warranty period, this Product fails
to operate under normal use and service, due
to defects in design, materials or workmanship,
Sony Ericsson authorised distributors or service
partners, in the country/region* where you
purchased the Product, will, at their option, either
repair or replace the Product in accordance with
the terms and conditions stipulated herein.
Sony Ericsson and its service partners reserve the
right to charge a handling fee if a returned Product
is found not to be under warranty according to the
conditions below.
Please note that some of your personal settings,
downloads or other information may be lost when
your Sony Ericsson Product is repaired or replaced.
At present Sony Ericsson may be prevented by
applicable law, other regulation or technical
restrictions from making a backup copy of certain
downloads. Sony Ericsson does not take any
responsibility for any lost information of any kind
and will not reimburse you for any such loss.
V630i-SHUG-Vodafone-R1A-EN.book Page 49 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
50 Important information
You should always make backup copies of all the
information stored on your Sony Ericsson Product
such as downloads, calendar and contacts before
handing in your Sony Ericsson Product for repair
or replacement.
CONDITIONS
1The warranty is valid only if the original proof
of purchase issued to the original purchaser by
a Sony Ericsson authorised dealer, specifying
the date of purchase and serial number**, for this
Product, is presented with the Product to be
repaired or replaced. Sony Ericsson reserves the
right to refuse warranty service if this information
has been removed or changed after the original
purchase of the Product from the dealer.
2If Sony Ericsson repairs or replaces the Product,
the repaired or replaced Product shall be warranted
for the remaining time of the original warranty
period or for ninety (90) days from the date of
repair, whichever is longer. Repair or replacement
may involve the use of functionally equivalent
reconditioned units. Replaced parts or components
will become the property of Sony Ericsson.
3This warranty does not cover any failure of the
Product due to normal wear and tear, or due to
misuse, including but not limited to use in other
than the normal and customary manner, in
accordance with the Sony Ericsson instructions
for use and maintenance of the Product. Nor does
this warranty cover any failure of the Product due
to accident, software or hardware modification or
adjustment, acts of God or damage resulting from
liquid.
A rechargeable battery can be charged and
discharged hundreds of times. However, it will
eventually wear out – this is not a defect. When
the talk-time or standby time is noticeably shorter,
it is time to replace your battery. Sony Ericsson
recommends that you use only batteries and
chargers approved by Sony Ericsson.
Minor variations in display brightness and color
may occur between phones. There may be tiny
bright or dark dots on the display. These are called
defective pixels and occur when individual dots
have malfunctioned and can not be adjusted.
Two defective pixels are deemed acceptable.
Minor variations in the appearance of the camera
image may occur between phones. This is not
uncommon in digital cameras and does not mean
that the camera is defective in any way.
4Since the cellular system on which the Product
is to operate is provided by a carrier independent
from Sony Ericsson, Sony Ericsson will not be
responsible for the operation, availability, coverage,
services or range of that system.
5This warranty does not cover Product failures
caused by installations, modifications, or repair
or opening of the Product performed by
a non-Sony Ericsson authorised person.
6The warranty does not cover Product failures which
have been caused by use of accessories or other
peripheral devices which are not Sony Ericsson
branded original accessories intended for use with
the Product.
7Tampering with any of the seals on the Product will
void the warranty.
8THERE ARE NO EXPRESS WARRANTIES,
WHETHER WRITTEN OR ORAL, OTHER THAN
THIS PRINTED LIMITED WARRANTY. ALL IMPLIED
WARRANTIES, INCLUDING WITHOUT LIMITATION
THE IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED TO
THE DURATION OF THIS LIMITED WARRANTY.
IN NO EVENT SHALL Sony Ericsson OR ITS
LICENSORS BE LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES OF ANY NATURE
WHATSOEVER, INCLUDING BUT NOT LIMITED
TO LOST PROFITS OR COMMERCIAL LOSS;
TO THE FULL EXTENT THOSE DAMAGES
CAN BE DISCLAIMED BY LAW.
V630i-SHUG-Vodafone-R1A-EN.book Page 50 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
51Important information
Some countries/states do not allow the exclusion
or limitation of incidental or consequential
damages, or limitation of the duration of implied
warranties, so the preceding limitations or
exclusions may not apply to you.
The warranty provided does not affect the
consumer's statutory rights under applicable
legislation in force, nor the consumer’s rights
against the dealer arising from their sales /
purchase contract.
*EUROPEAN UNION (EU)
If you have purchased your Product in an EU
country you can have your Product serviced, under
the conditions set out above, within the warranty
period in any EU country where an identical
Product is sold by an authorised Sony Ericsson
distributor. To find out if your Product is sold in
the EU country you are in, please call the local
Sony Ericsson Call Center. Please observe that
certain services may not be possible elsewhere
than in the country of original purchase, for
example due to the fact that your Product may
have an interior or exterior which is different from
equivalent models sold in other EU countries. It
may not be possible to repair SIM-locked Products.
** In some countries/regions additional information
is requested. If so, this is clearly shown on the valid
proof of purchase.
FCC Statement
This device complies with Part 15 of
the FCC rules. Operation is subject
to the following two conditions:
(1) This device may not cause
harmful interference, and
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
Bluetooth wireless technology
Bluetooth™ Qualified Design ID is B011122.
Declaration of Conformity
We, Sony Ericsson Mobile Communications AB of
Nya Vattentornet
S-221 88 Lund, Sweden
declare under our sole responsibility that our
product
and in combination with our accessories, to which
this declaration relates is in conformity with the
appropriate standards 3GPP TS 51.010-1,
EN 301908-1, EN 301489-7, EN 301489-24,
EN 300328, EN 301489-17 and EN 60950,
following the provisions of, Radio Equipment and
Telecommunication Terminal Equipment directive
99/5/EC with requirements covering EMC directive
89/336/EEC, and Low Voltage directive
73/23/EEC.
We fulfil the requirements of the R&TTE Directive
(99/5/EC).
Lund, April 2006
Shoji Nemoto,
Head of Product Business Unit GSM/UMTS
V630i-SHUG-Vodafone-R1A-EN.book Page 51 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
Sony Ericsson type AAD-3022042-BV
52 Index
Index
A
alarms .................................................. 42
appointments ....................................... 42
automatic redialling .............................. 17
B
battery
inserting and charging ................... 4
use and care ................................ 46
blog ...................................................... 32
Bluetooth wireless technology ............. 38
business cards ..................................... 24
buttons ............................................. 8, 12
C
calendar ..........................................42–43
call list .................................................. 23
calls
answering and rejecting ............... 17
emergency ................................... 18
international ................................. 17
making and receiving ............... 5, 17
video ............................................ 18
camera ............................................. 7, 31
contacts
adding phone contacts ................ 20
default contacts ........................... 20
groups of ...................................... 24
synchronising ............................... 37
E
email ......................................................27
entering letters ......................................14
H
handsfree ................................................9
help .........................................................5
I
instant messaging See Messenger .......28
K
keypad lock ...........................................13
keys ...................................................8, 12
L
live! intro ................................................35
live! Studio ............................................33
M
M2™ .......................................................9
memory card .........................................15
memory status ......................................15
menu overview ......................................10
Messenger ............................................28
microphone ...........................................18
MMS See picture messages .................26
music player ..........................................34
My Files .................................................15
V630i-SHUG-Vodafone-R1A-EN.book Page 52 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
53Index
N
navigating menus ................................. 12
networks ............................................... 17
P
phone overview ...................................... 8
picture messages ................................. 26
picture sizes ......................................... 31
pictures ................................................ 33
postcard ............................................... 26
R
ringtones ........................................ 34–35
S
safety guidelines .................................. 46
sending
appointments and tasks .............. 43
business cards ............................. 24
pictures ........................................ 33
setup wizard ........................................... 4
SIM card
contact numbers .......................... 20
copying to/from ............................ 22
SMS See text messages ...................... 24
SOS See emergency numbers ............. 18
standby .................................................. 5
synchronising ....................................... 37
T
T9™ Text Input .................................... 14
text messages ...................................... 24
Ticker ................................................... 37
Toolbar ................................................... 6
transferring
camera pictures ........................... 32
files ............................................... 39
U
Update service ..................................... 41
USB cable ............................................ 39
V
video player .......................................... 34
video recorder ...................................... 31
Vodafone live! ....................................... 36
voice dialling ........................................ 23
volume
ear speaker .................................. 18
ringtone ........................................ 34
W
warranty ............................................... 49
Z
zoom .................................................... 31
V630i-SHUG-Vodafone-R1A-EN.book Page 53 Thursday, May 4, 2006 2:36 PM
PPreflighted byreflighted byPreflighted by ( )( )( )
PPreflighted byreflighted byPreflighted by ( )( )( )
PPreflighted byreflighted byPreflighted by ( )( )( )
PPreflighted byreflighted byPreflighted by ( )( )( )
