WARNING
About These Operating Instructions
Unpacking
- Preparing the remote
Index to Parts and Controls
Getting Started
Playback
Sound Adjustment
Tuner
- Listening to the Radio
  - Presetting radio stations
  - Selecting the preset station
Other Operations
Settings and Adjustments
Additional Information

BDV-E280/BDV-T28

4-265-162-11 (1)

Blu-ray Disc/DVD

Home Theatre

System

Operating Instructions

2US

Do not install the appliance in a

confined space, such as a bookcase

or built-in cabinet.

To reduce the risk of fire, do not

cover the ventilation opening of the

apparatus with newspapers,

tablecloths, curtains, etc. Do not

place the naked flame sources such

as lighted candles on the apparatus.

Do not expose batteries or

apparatus with battery-installed to

excessive heat such as sunshine,

fire or the like.

To prevent injury, this apparatus

must be securely attached to the

floor/wall in accordance with the

installation instructions.

Indoor use only.

CAUTION

The use of optical instruments with

this product will increase eye

hazard. As the laser beam used in

this Blu-ray Disc / DVD Home

Theatre System is harmful to eyes,

do not attempt to disassemble the

cabinet.

Refer servicing to qualified

personnel only.

This appliance is classified as a

CLASS 3R LASER product.

Visible and invisible laser radiation

is emitted when the laser protective

housing is opened, so be sure to

avoid direct eye exposure.

This marking is located on the laser

protective housing inside the

enclosure.

This appliance is classified as a

CLASS 1 LASER product. This

marking is located on the rear

exterior.

For the customers in

the U.S.A.

To reduce the risk of fire

or electric shock, do not

expose this apparatus to

rain or moisture.

These following indications are

located on the rear exterior.

This symbol is intended to

alert the user to the

presence of uninsulated

“dangerous voltage” within the

product’s enclosure that may be of

sufficient magnitude to constitute a

risk of electric shock to persons.

This symbol is intended to

alert the user to the

presence of important

operating and maintenance

(servicing) instructions in the

literature accompanying the

appliance.

Owner’s Record

The model and serial numbers are

located on the rear exterior of the

unit. Record these numbers in the

space provided below. Refer to

them whenever you call upon your

Sony dealer regarding this product.

Model No. BDV-E280/BDV-T28

Serial No.______________

The following FCC statement

applies only to the version of this

model manufactured for sale in the

U.S.A. Other versions may not

comply with FCC technical

regulations.

NOTE:

This equipment has been tested and

found to comply with the limits for

a Class B digital device, pursuant to

Part 15 of the FCC Rules. These

limits are designed to provide

reasonable protection against

harmful interference in a residential

installation. This equipment

generates, uses, and can radiate

radio frequency energy and, if not

installed and used in accordance

with the instructions, may cause

harmful interference to radio

communications. However, there is

no guarantee that interference will

not occur in a particular

installation. If this equipment does

cause harmful interference to radio

or television reception, which can

be determined by turning the

equipment off and on, the user is

encouraged to try to correct the

interference by one or more of the

following measures:

– Reorient or relocate the receiving

antenna (aerial).

– Increase the separation between

the equipment and receiver.

– Connect the equipment into an

outlet on a circuit different from

that to which the receiver is

connected.

– Consult the dealer or an

experienced radio/TV technician

for help.

CAUTION

You are cautioned that any changes

or modifications not expressly

approved in this manual could void

your authority to operate this

equipment.

Properly shielded and grounded

cables and connectors must be used

for connection to host computers

and/or peripherals in order to meet

FCC emission limits.

WARNING

3US

Important Safety

Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near

water.

6) Clean only with dry cloth.

7) Do not block any ventilation

openings. Install in accordance

with the manufacturer’s

instructions.

8) Do not install near any heat

sources such as radiators, heat

registers, stoves, or other

apparatus (including

amplifiers) that produce heat.

9) Do not defeat the safety

purpose of the polarized or

grounding-type plug. A

polarized plug has two blades

with one wider than the other. A

grounding type plug has two

blades and a third grounding

prong. The wide blade or the

third prong are provided for

your safety. If the provided

plug does not fit into your

outlet, consult an electrician for

replacement of the obsolete

outlet.

10) Protect the power cord from

being walked on or pinched

particularly at plugs,

convenience receptacles, and

the point where they exit from

the apparatus.

11) Only use attachments/

accessories specified by the

manufacturer.

12) Use only with the cart, stand,

tripod, bracket, or table

specified by the manufacturer,

or sold with the apparatus.

When a cart is used, use caution

when moving the cart/

apparatus combination to avoid

injury from tip-over.

13) Unplug this apparatus during

lightning storms or when

unused for long periods of time.

14) Refer all servicing to qualified

service personnel. Servicing is

required when the apparatus

has been damaged in any way,

such as power-supply cord or

plug is damaged, liquid has

been spilled or objects have

fallen into the apparatus, the

apparatus has been exposed to

rain or moisture, does not

operate normally, or has been

dropped.

For the customers in

Canada, Mexico, and

Latin America

To reduce the risk of fire or electric

shock, do not expose this apparatus

to dripping or splashing, and do not

place objects filled with liquids,

such as vases, on the apparatus.

Precautions

On power sources

• The unit is not disconnected from

the mains as long as it is

connected to the AC outlet, even

if the unit itself has been turned

off.

• As the main plug is used to

disconnect the unit from the

mains, connect the unit to an

easily accessible AC outlet.

Should you notice an abnormality

in the unit, disconnect the main

plug from the AC outlet

immediately.

On watching 3D video

images

Some people may experience

discomfort (such as eye strain,

fatigue, or nausea) while watching

3D video images. Sony

recommends that all viewers take

regular breaks while watching 3D

video images. The length and

frequency of necessary breaks will

vary from person to person. You

must decide what works best. If you

experience any discomfort, you

should stop watching the 3D video

images until the discomfort ends;

consult a doctor if you believe

necessary. You should also review

(i) the instruction manual and/or the

caution message of any other

device used with, or Blu-ray Disc

contents played with this product

and (ii) our website (http://

esupport.sony.com/) for the latest

information. The vision of young

children (especially those under six

years old) is still under

development. Consult your doctor

(such as a pediatrician or eye

doctor) before allowing young

children to watch 3D video images.

Adults should supervise young

children to ensure they follow the

recommendations listed above.

Copy Protection

Please be advised of the advanced

content protection systems used in

both Blu-ray DiscTM and DVD

media. These systems, called

AACS (Advanced Access Content

System) and CSS (Content

Scramble System), may contain

some restrictions on playback,

analog output, and other similar

features. The operation of this

product and the restrictions placed

may vary depending on the date of

purchase, as the governing board of

the AACS may adopt or change its

restriction rules after the time of

purchase.

Copyrights and

Trademarks

• This system incorporates with

Dolby* Digital and Dolby Pro

Logic (II) adaptive matrix

surround decoder and the DTS**

Digital Surround System.

* Manufactured under license

from Dolby Laboratories.

Dolby, Pro Logic, and the

double-D symbol are

trademarks of Dolby

Laboratories.

** Manufactured under license

under U.S. Patent #’s:

5,451,942; 5,956,674;

4US

5,974,380; 5,978,762;

6,226,616; 6,487,535;

7,212,872; 7,333,929;

7,392,195; 7,272,567 &

other U.S. and worldwide

patents issued & pending.

DTS, DTS-HD and the

Symbol are registered

trademarks, & DTS-HD

Master Audio, and the DTS

logos are trademarks of

DTS, Inc. Product includes

software. © DTS, Inc. All

Rights Reserved.

• This system incorporates High-

Definition Multimedia Interface

(HDMITM) technology.

HDMI, the HDMI logo and High-

Definition Multimedia Interface

are trademarks or registered

trademarks of HDMI Licensing

LLC in the United States and

other countries.

• Java is a trademark of Oracle and/

or its affiliates.

• “BD-LIVE” and

“BONUSVIEW” are trademarks

of Blu-ray Disc Association.

• “Blu-ray Disc” is a trademark.

• “Blu-ray Disc,” “DVD+RW,”

“DVD-RW,” “DVD+R,” “DVD-

R,” “DVD VIDEO,” and “CD”

logos are trademarks.

• “Blu-ray 3D” and “Blu-ray 3D”

logo are trademarks of Blu-ray

Disc Association.

• “BRAVIA” is a trademark of

Sony Corporation.

• “AVCHD” and the “AVCHD”

logo are trademarks of Panasonic

Corporation and Sony

Corporation.

• , “XMB,” and “xross media

bar” are trademarks of Sony

Corporation and Sony Computer

Entertainment Inc.

• “PLAYSTATION” is a trademark

of Sony Computer Entertainment

Inc.

• The Wi-Fi CERTIFIED™ Logo

is a certification mark of the

Wi-Fi Alliance.

• The Wi-Fi Protected Setup™

Mark is a mark of the Wi-Fi

Alliance.

• “Wi-Fi CERTIFIED™” and “Wi-

Fi Protected Setup™” are

trademarks of the Wi-Fi Alliance.

• “PhotoTV HD” and the “PhotoTV

HD” logo are trademarks of Sony

Corporation.

• MPEG Layer-3 audio coding

technology and patents licensed

from Fraunhofer IIS and

Thomson.

• iPhone, iPod, iPod classic, iPod

nano, and iPod touch are

trademarks of Apple Inc.,

registered in the U.S. and other

countries.

• “Made for iPod,” and “Made for

iPhone” mean that an electronic

accessory has been designed to

connect specifically to iPod or

iPhone, respectively, and has been

certified by the developer to meet

Apple performance standards.

Apple is not responsible for the

operation of this device or its

compliance with safety and

regulatory standards. Please note

that the use of this accessory with

iPod or iPhone may affect

wireless performance.

• Windows Media is either a

registered trademark or trademark

of Microsoft Corporation in the

United States and/or other

countries.

This product contains technology

subject to certain intellectual

property rights of Microsoft. Use

or distribution of this technology

outside of this product is

prohibited without the appropriate

license(s) from Microsoft.

Content owners use Microsoft

PlayReady™ content access

technology to protect their

intellectual property, including

copyrighted content. This device

uses PlayReady technology to

access PlayReady-protected

content and/or WMDRM-

protected content. If the device

fails to properly enforce

restrictions on content usage,

content owners may require

Microsoft to revoke the device’s

ability to consume PlayReady-

protected content. Revocation

should not affect unprotected

content or content protected by

other content access technologies.

Content owners may require you

to upgrade PlayReady to access

their content. If you decline an

upgrade, you will not be able to

access content that requires the

upgrade.

• All other trademarks are

trademarks of their respective

owners.

• Other system and product names

are generally trademarks or

registered trademarks of the

manufacturers. ™ and ® marks

are not indicated in this document.

5US

About These

Operating

Instructions

• The instructions in these

Operating Instructions

describe the controls on the

remote. You can also use the

controls on the unit if they

have the same or similar

names as those on the remote.

• In this manual, “disc” is used

as a general reference for

BDs, DVDs, Super Audio

CDs, or CDs unless otherwise

specified by the text or

illustrations.

• The instructions in this

manual are for BDV-E280

and BDV-T28. BDV-E280 is

the model used for

illustration purposes. Any

difference in operation is

clearly indicated in the text,

for example, “BDV-E280

only.”

• Some illustrations are

presented as conceptual

drawings, and may be

different from the actual

products.

• The items displayed on the

TV screen may vary

depending on the area.

• The default setting is

underlined.

6US

Table of Contents

About These Operating Instructions .......5

Unpacking...............................................7

Index to Parts and Controls.....................8

Getting Started

Step 1: Installing the System.......13

Step 2: Connecting the System...14

Step 3: Connecting to the

Network ....................................20

Step 4: Performing the Easy

Setup ........................................22

Step 5: Selecting the Source .......23

Step 6: Enjoying Surround

Sound .......................................24

Playback

Playing a Disc ....................................... 27

Playing from a USB Device..................28

Enjoying an iPod/iPhone....................... 29

Playing via a Network...........................31

Available Options .................................32

Sound Adjustment

Selecting the Effect to Suit

the Source ....................................... 34

Selecting the Audio Format, Multilingual

Tracks, or Channel.......................... 34

Enjoying Multiplex Broadcast

Sound .............................................. 35

Tuner

Listening to the Radio...........................36

Other Operations

Using the Control for HDMI Function for

“BRAVIA” Sync ............................ 38

Setting the Speakers.............................. 39

Using the Sleep Timer .......................... 40

Deactivating the Buttons on

the Unit ........................................... 40

Controlling Your TV with the Supplied

Remote............................................ 41

Changing the Brightness of the Front

Panel Display..................................41

Saving Power in Standby Mode............41

Browsing Websites ...............................42

Setting up the Network ......................... 43

Settings and Adjustments

Using the Setup Display ....................... 47

[Network Update]................................. 47

[Screen Settings]................................... 48

[Audio Settings].................................... 49

[BD/DVD Viewing Settings] ............... 50

[Parental Control Settings] ................... 50

[Music Settings].................................... 51

[System Settings].................................. 51

[Network Settings]................................ 51

[Easy Setup].......................................... 52

[Resetting] ............................................ 52

Additional Information

Precautions ........................................... 53

Notes about the Discs ........................... 54

Troubleshooting.................................... 55

Playable Discs ...................................... 60

Playable Types of Files ........................ 61

Supported Audio Formats..................... 62

Specifications ....................................... 63

Language Code List.............................. 64

Index ..................................................... 65

7US

Unpacking

BDV-E280/BDV-T28

Insert two R6 (size AA) batteries (supplied) by matching the 3 and # ends on the batteries to the

markings inside the compartment.

• Front speakers (2)

• Surround speakers (2)

• Center speaker (1)

• Subwoofer (1)

• FM wire antenna (aerial) (1)

• Video cord (1) (U.S. and

Canada models only)

• Remote commander

(remote) (1)

• R6 (size AA) batteries (2)

• HDMI cable (1)

(Mexican and Latin

American models of BDV-

E280 and U.S. and Canada

models of BDV-T28 only)

• HDMI cable (2)

(Mexican and Latin

American models of BDV-

T28 only)

• Dock for iPod/iPhone

(TDM-iP30) (1) (U.S. and

Canada models only)

• USB cable (1) (U.S. and

Canada models only)

• Operating Instructions

• Quick Setup Guide

• Speaker Installation Guide

• Software License

Information

Preparing the remote

8US

Index to Parts and Controls

For more information, refer to the pages indicated in parentheses.

ADisc tray (page 27)

BRemote sensor

CFront panel display

D (USB) port (page 28) (Mexican and

Latin American models only)

Used for connecting a USB device.

EPlay operation buttons

Z (open/close) (page 27)

Opens or closes the disc tray.

N (play)

Starts or re-starts playback (resume play).

Plays a slideshow when a disc containing

JPEG image files is inserted.

x (stop)

Stops playback and remembers the stop

point (resume point).

The resume point for a title/track is the last

point you played or the last photo for a

photo folder.

FUNCTION

Selects the playback source.

VOLUME +/–

Adjusts the system’s volume.

F"/1 (on/standby)

Turns on the unit, or sets it to standby mode.

Front panel

VOLUM E

FUNCTION

9US

About the indications in the front panel display

ADisplays the system’s playing status.

BLights up when repeat play is

activated.

CLights up when stereo sound is

received. (Radio only)

DLights up when the HDMI (OUT) jack is

correctly connected to an HDCP (High-

bandwidth Digital Content Protection)-

compliant device with HDMI or DVI

(Digital Visual Interface) input.

ELights up when muting is on.

FDisplays the system’s status, such as

radio frequency, etc.

GLights up when outputting 720p/1080i/

1080p video signals from the HDMI

(OUT) jack.

Front panel display

10US

ASPEAKERS jacks (page 14)

B (USB) port (page 28)

CAUDIO (AUDIO IN L/R) jacks (page 17)

DANTENNA (FM COAXIAL 75Ω) jack

(page 19)

ETV (DIGITAL IN OPTICAL) jack (page

15)

FLAN (100) terminal (page 20)

GHDMI (IN 2) jack (page 17)

HHDMI (IN 1) jack (page 17)

IHDMI (OUT) jack (page 15)

JVIDEO OUT jack (page 15)

Rear panel

VIDEO OUT

OPTICAL

DIGITAL IN

LAN (100)

AUDIO IN

AUDIO

COAXIAL

ANTENNA

FRONT R FRONT L SUBWOOFER CENTER SUR R

ONLY FOR SS-TSB105

SPEAKERS

ONLY FOR

SS-WSB103 ONLY FOR

SS-CTB102

SUR L

ONLY FOR SS-TSB105

ARC

OUT

IN 1 IN 2

11US

Number 5, AUDIO, VOL +, and N buttons

have a tactile dot. Use the tactile dot as a

reference when operating the remote.

• : For TV operations

(For details, see “Controlling Your TV with

the Supplied Remote” (page 41).)

AZ (open/close)

Opens or closes the disc tray.

SPEAKERS TVyAUDIO

Selects whether TV sound is output from

the system’s speakers or the TV’s

speaker(s). This function works only when

you set [Control for HDMI] to [On]

(page 51).

TV "/1 (on/standby) (page 41)

Turns on the TV or sets it to standby mode.

"/1 (on/standby) (pages 22, 36)

Turns on the system or sets it to standby

mode.

BNumber buttons (pages 37, 41)

Enters the title/chapter numbers, preset

station number, etc.

AUDIO (pages 34, 35)

Selects the audio format/track.

SUBTITLE (page 50)

Selects the subtitle language when

multilingual subtitles are recorded on a BD-

ROM/DVD VIDEO.

CColor buttons (yellow/blue/red/green)

Short cut keys for selecting items on some

BD menus (can also be used for Java

interactive operations on BDs).

DTOP MENU

Opens or closes the BD’s or DVD’s Top

Menu.

POP UP/MENU

Opens or closes the BD-ROM’s Pop-up

Menu, or the DVD’s menu.

OPTIONS (pages 24, 32. 42)

Displays the options menu on the TV screen

or in the front panel display. (The location

differs based on the selected function.)

RETURN

Returns to the previous display.

C/X/x/c

Moves the highlight to a displayed item.

(enter)

Enters the selected item.

ESOUND MODE +/– (page 34)

Selects the sound mode.

HOME (pages 22, 36, 39, 42, 43, 47)

Enters or exits the system’s home menu.

Remote control

PRESET

SLEEP

FUNCTION

DIMMER

AUDIO SUBTITLE

GREENREDBLUE

DISPLAY

MUTING

REPLAY ADVANCE

TUNING

PLAY

STOP

TV INPUT

TV VOL

VOL

PAUSE

YELLOW

TOP MENU

POP UP/ MENU

RETURN OPTIONS

SOUND MODE

HOME

SOUND MODE

FAVORITES

SPEAKERS

AUDIO

564

231

PRESET

TUNING

BRAVIA Sync

12US

FPlayback operation buttons

See “Playback” (page 27).

./> (previous/next)

Skip to the previous/next chapter, track, or

file.

(replay/advance)

Briefly replay the current scenes for 10

seconds./Briefly fast forwards the current

scenes for 15 seconds.

m/M (fast/slow/freeze frame)

Fast reverse/fast forward the disc during

playback. Each time you press the button,

the search speed changes.

Activates slow-motion play when pressed

for more than one second in pause mode.

Plays one frame at a time when pressed in

pause mode.

Slow-motion and single-frame playback are

not available for Blu-ray 3D Discs.

N (play)

Starts or re-starts playback (resume play).

Activates One-Touch Play (page 38) when

the system is on and set to the “BD/DVD”

function.

X (pause)

Pauses or re-starts playback.

x (stop)

Stops playback and remembers the stop

point (resume point). The resume point for

a title/track is the last point you played or

the last photo for a photo folder.

Radio operation buttons

See “Tuner” (page 36).

PRESET +/–

TUNING +/–

GMUTING

Turns off the sound temporarily.

VOL +/– (page 36)

Adjusts the volume.

TV VOL +/–

Adjusts the TV volume.

TV INPUT

Switches the TV’s input source between the

TV and other input sources.

HDISPLAY (pages 27, 31, 42)

Displays playback and web browsing

information on the TV screen.

Displays the preset radio station, frequency,

etc., in the front panel display.

Displays the stream information/decoding

status in the front panel display when the

function is set to other than “BD/DVD.”

When the system is set to the “HDMI1,”

“HDMI2,” or “TV” function, the stream

information/decoding status appears only

when a digital signal is input.

The stream information/decoding status

may not appear depending on the stream or

item being decoded.

IDIMMER (page 41)

Changes the brightness of the front panel

display.

SLEEP (page 40)

Sets the sleep timer.

FUNCTION (pages 23, 36)

Selects the playback source.

FAVORITES

Displays the Internet contents added to the

Favorites List. You can save 18 favorite

Internet contents.

13US

Getting Started

Step 1: Installing the System

Install the system by referring to the illustration below.

• Use caution when placing the speakers and/or speaker stands attached to the speakers on a specially treated (waxed,

oiled, polished, etc.) floor, as staining or discoloration may result.

• Do not lean or hang on a speaker, as it may fall down.

• You can install the speakers on a wall. For details, refer to the supplied “Speaker Installation Guide.”

Getting Started

How to position the system

A Front speaker (L (left))

B Front speaker (R (right))

C Center speaker

D Surround speaker (L (left))

E Surround speaker (R (right))

F Subwoofer

G Unit

14US

Getting Started

Step 2: Connecting the System

For connecting the system, read the information on the following pages.

Do not connect the AC power cord (mains lead) of the unit to a wall outlet (mains) until all the other

connections are made.

• When you connect another component with a volume control, turn down the volume of the other components to a

level where sound is not distorted.

To connect speaker cords to the unit

Connect the speaker cords to match the color of the SPEAKERS jacks of the unit.

When connecting to the unit, insert the connector until it clicks.

Connecting the speakers

FRONT R FRONT L SUBWOOFER CENTER SUR R

ONLY FOR SS-TSB105

SPEAKERS

ONLY FOR

SS-WSB103 ONLY FOR

SS-CTB102

SUR L

ONLY FOR SS-TSB105

Green

(Center speaker)

Purple

(Subwoofer)

White

(Front left

speaker (L))

Red

(Front right

speaker (R))

Gray

(Surround right

speaker (R))

Blue

(Surround left

speaker (L))

Rear panel of the unit

15US

Getting Started

Connect the system to your TV to display the image of the system on your TV, and listen to TV sound

via the system’s speakers.

Depending on the jacks and functions on your TV, select the connection method.

• When your TV has an HDMI jack that is marked “ARC1)”: Connection A

• When your TV has an HDMI jack: Connections A and C

• When your TV does not have HDMI jacks: Connections B and C

1)Audio Return Channel. For details, see “About Audio Return Channel” (page 16).

2)The HDMI cable is supplied with Mexican and Latin American models and BDV-T28 only.

3)Available only when your TV is compatible with the Audio Return Channel function.

Connecting the TV

AB C

HDMI cable2)

Image quality

Video connections

Video cord

(not supplied)

Digital optical cord

(not supplied)

Audio connection

VIDEO IN DIGITAL OUT

OPTICAL

HDMI IN

VIDEO OUT

OPTICAL

DIGITAL IN

ARC

OUT

IN 1 IN 2

AB C

Rear panel of the unit

Yellow

: Video signal

: Audio signal

Signal flow

16US

Getting Started

A HDMI cable connection

If your TV has an HDMI jack, connect to the TV with an HDMI cable. This will provide better image

quality compared to other types of connections.

When connecting with an HDMI cable, you need to select the type of output signal when performing

the Easy Setup (page 22).

For further HDMI settings, see “[HDMI Settings]” (page 51).

About Audio Return Channel

If your TV is compatible with the Audio Return Channel function, an HDMI cable connection also

sends a digital audio signal from the TV. You do not need to make a separate audio connection for

listening to TV sound. For setting the Audio Return Channel function, see [Audio Return Channel]

(page 51).

B Video cord connection

If your TV does not have an HDMI jack, make this connection.

C Digital optical cord connection

This connection sends an audio signal to the system from the TV. To listen to TV sound via the system,

perform this connection. With this connection, the system receives a Dolby Digital multiplex broadcast

signal and you can enjoy multiplex broadcast sound.

• You can enjoy the TV sound by selecting the “TV” function (page 23).

• If your TV does not have a digital optical output jack, you can connect the unit and your TV with an audio cord for

listening to TV sound via the system. For connection details, see “Connecting the other components” (page 17).

17US

Getting Started

When a component you wish to connect to the system has an HDMI

(OUT) jack

You can connect a component that has an HDMI (OUT) jack such as a set-top box/digital satellite

receiver or PLAYSTATION®3, etc., with an HDMI cable. An HDMI cable connection can send both

video and audio signals. By connecting the system and the component using an HDMI cable, you can

enjoy high-quality digital picture and sound via the HDMI (IN 1) or HDMI (IN 2) jack.

• Video signals from the HDMI (IN 1/2) jacks are sent to the HDMI (OUT) jack only when the “HDMI1” or

“HDMI2” function is selected.

• To send an audio signal from the HDMI (IN 1/2) jacks to the HDMI (OUT) jack, you may need to change the audio

output setting. For details, see [Audio Output] in [Audio Settings] (page 49).

Connecting the other components

HDMI OUT

ARC

OUT

IN 1 IN 2

To the HDMI OUT jack of the set-top box/

digital satellite receiver or

PLAYSTATION®3, etc.

HDMI cable (supplied with Mexican and Latin

American models of BDV-T28 only)

Use HDMI (IN 1) or HDMI (IN 2).

Rear panel of the unit

18US

Getting Started

When the component does not have an HDMI OUT jack

Connect the system so that video signals from the system and other component are sent to the TV, and

audio signals from the component are sent to the system as follows.

If the component plays sound only, connect the audio output of the component to the system.

• If you make connection above, set [Control for HDMI] in [HDMI Settings] of [System Settings] to [Off] (page 51).

• You can enjoy component sound by selecting the “AUDIO” function (page 23).

System

Signal flow

: Audio signal

: Video signal

Component

Video out

Audio out

AUDIO OUT

L R

AUDIO IN

AUDIO

To the audio out jacks of the VCR, digital

satellite receiver, PlayStation, or portable

audio source, etc.

Audio cord (not supplied)

Rear panel of the unit

Red

White

Red

White

: Signal flow

19US

Getting Started

• Be sure to fully extend the FM wire antenna (aerial).

• After connecting the FM wire antenna (aerial), keep it as horizontal as possible.

• If you have poor FM reception, use a 75-ohm coaxial cable (not supplied) to connect the unit to an outdoor FM

antenna (aerial).

Connecting the antenna (aerial)

COAXIAL

ANTENNA

or FM wire antenna (aerial)

(supplied)

Rear panel of the unit

20US

Getting Started

Step 3: Connecting to the Network

• To connect the system to your network, you need to make network settings that suit your usage environment and

components. For details, see “Setting up the Network” (page 43) and “[Network Settings]” (page 51).

Select the method based on your LAN (Local Area Network) environment.

1 Wired Setup

Use a LAN cable to connect to the LAN (100) terminal on the unit.

2 USB Wireless Setup

Use a wireless LAN via the USB Wireless LAN Adapter (Sony UWA-BR100* only).

The USB Wireless LAN Adapter may not be available in some regions/countries.

* As of November 2010.

Turn the unit off before connecting the extension cable or inserting the USB Wireless LAN Adapter.

After inserting the USB Wireless LAN Adapter to the base and connecting the extension cable to the

(USB) port (front or rear), turn the unit on again.

LAN 1 LAN 2 LAN 3 LAN 4WANETHER

LAN (100)

ADSL modem/

cable modem Broadband router

LAN cable

(not supplied)

Internet

Rear panel of the unit

USB

Wireless LAN

Adapter

(not supplied)

21US

Getting Started

• The placement distance between the USB Wireless LAN Adapter and your wireless LAN router differs based on

your usage environment. If the system cannot connect to the network or the network connection is unstable, move

the USB Wireless LAN Adapter to a different position or place the USB Wireless LAN Adapter and the wireless

LAN router closer to each other.

• You can also get information for network settings from the following Sony support page:

For customers in the U.S.:

http://www.sony.com/support

For customers in Canada:

English: http://www.sony.ca/support

French: http://fr.sony.ca/support

For customers in Mexico and Latin America:

http://esupport.sony.com/LA

22US

Getting Started

Step 4: Performing the

Easy Setup

Before performing Step 4

Make sure all connections are secure, and then

connect the AC power cord (mains lead).

Follow the Steps below to make the basic

adjustments for using the system.

Displayed items vary depending on the country

model.

1Turn on the TV.

2Press [/1.

3Switch the input selector on your TV so

that the signal from the system

appears on the TV screen.

The Easy Setup Display for OSD language

selection appears.

4Perform the [Easy Setup]. Follow the

on-screen instructions to make the

basic settings using C/X/x/c, and .

Depending on the connection method

(page 15), perform the following setting.

• HDMI cable connection: Follow the

instructions that are displayed on the TV

screen.

• Video cord connection: Select [16:9] or

[4:3] so that the picture is displayed

correctly.

To recall the Easy Setup Display

1Press HOME.

The home menu appears on the TV screen.

2Press C/c to select [Setup].

3Press X/x to select [Easy Setup], then

press .

4Press C/c to select [Start], then press

The Easy Setup Display appears.

564

231

C/X/x/c,

HOME

"/1

23US

Getting Started

Step 5: Selecting the

Source

You can select the playback source.

Press FUNCTION repeatedly until the

desired function appears in the front panel

display.

Each time you press FUNCTION, the function

changes as follows.

“BD/DVD” t “FM” t “HDMI1” t

“HDMI2” t “TV” t “AUDIO” t “BD/

DVD” t …

Function Source

“BD/DVD” Disc, USB device, iPod/iPhone, or

network device to be played by the

system

“FM” FM radio (page 36)

“HDMI1”/

“HDMI2”

Component that is connected to

the HDMI (IN 1) or HDMI (IN 2)

jack on the rear panel (page 17)

“TV” Component (TV, etc.) that is

connected to the TV (DIGITAL

IN OPTICAL) jack on the rear

panel, or a TV compatible with the

Audio Return Channel function

that is connected to the HDMI

(OUT) jack on the rear panel

(page 15)

“AUDIO” Component that is connected to

the AUDIO (AUDIO IN L/R)

jacks on the rear panel (page 17)

564

231

FUNCTION

24US

Getting Started

Step 6: Enjoying Surround Sound

After performing the previous Steps and starting playback, you can easily enjoy surround sound. You

can also select pre-programmed surround settings that are tailored to different kinds of sound sources.

They bring the exciting and powerful sound of movie theaters into your home.

The setting method differs depending on the function.

When playing via the “BD/DVD”* or “FM” function

1Press OPTIONS.

The option menu appears on the TV screen.

2Press X/x to select [Surround Setting], then press .

3Press X/x repeatedly until the surround setting you want appears on the TV screen.

See the table below for surround sound setting descriptions.

4Press .

The setting is made.

* Surround sound settings do not apply to Internet content.

When playing via the “HDMI1,” “HDMI2,” “TV,” or “AUDIO” function

1Press OPTIONS.

The option menu appears in the front panel display.

2Press X/x repeatedly until “SUR. SET” appears in the front panel display, then press

or c.

3Press X/x repeatedly until the surround setting you want appears in the front panel

display.

See the table below for surround sound setting descriptions.

4Press .

The setting is made.

5Press OPTIONS.

The option menu in the front panel display turns off.

Selecting surround settings based on your listening preference

564

231

X/x/c,

OPTIONS

25US

Getting Started

• When the home menu is displayed on the TV screen, this setting can be changed by selecting the surround setting

via [Surround Setting] in [Audio Settings] of [Setup] (page 49).

About speaker output of each surround setting

The table below describes the options when you connect all the speakers to the unit.

The default setting is [A.F.D. Multi] (“A.F.D. MULTI”).

• When you select [A.F.D. Multi] (“A.F.D. MULTI”), depending on the disc or source, the beginning of the sound

may be cut off while the optimum mode is automatically selected. To avoid cutting the sound, select [A.F.D.

Standard] (“A.F.D. STD”).

• When bilingual broadcast sound is input, [Dolby Pro Logic] (“PRO LOGIC”) and [Dolby PL II Movie] (“PLII

MOVIE”) are not effective.

Sound from Surround setting Effect

Depending on the source. [A.F.D. Standard]

“A.F.D. STD”

(AUTO FORMAT

DIRECT STANDARD)

The system discriminates the sound format of the source and

presents sound as it was recorded/encoded.

[A.F.D. Multi]

“A.F.D. MULTI”

(AUTO FORMAT

DIRECT MULTI)

• 2 channel source: The system simulates surround sound

from 2 channel sources and outputs sound from the 5.1

channel speakers by duplicating 2 channel source sound

across each speaker.

• Multi-channel source: The system outputs sound from the

speakers depending on the number of channels of the

source.

• [Dolby Pro Logic]

“PRO LOGIC”

• [Dolby PL II Movie]

“PLII MOVIE”

• 2 channel source: The system simulates surround sound

from 2 channel sources and outputs sound from the 5.1

channel speakers.

– [Dolby Pro Logic] (“PRO LOGIC”) performs Dolby Pro

Logic decoding.

– [Dolby PL II Movie] (“PLII MOVIE”) performs Dolby

Pro Logic II movie mode decoding.

• Multi-channel source: The system outputs sound from the

speakers depending on the number of channels of the

source.

• [DTS Neo:6

Cinema]

“NEO6 CIN”

• [DTS Neo:6 Music]

“NEO6 MUS”

• 2 channel source: The system simulates surround sound

from 2 channel sources and produces 6.1 channel sound.

– [DTS Neo:6 Cinema] (“NEO6 CIN”) performs DTS

Neo:6 Cinema mode decoding.

– [DTS Neo:6 Music] (“NEO6 MUS”) performs DTS

Neo:6 Music mode decoding.

• Multi-channel source: The system outputs sound from the

speakers depending on the number of channels of the

source.

[2ch Stereo]

“2CH ST.”

The system outputs the sound from the front speakers and

subwoofer regardless of sound format or number of channels.

Multi-channel surround formats are downmixed to 2

channels.

26US

Getting Started

• Depending on the input stream, the surround settings may not be effective.

• When you play a Super Audio CD, surround settings are not activated.

• You can also select the surround setting in [Surround Setting] of [Audio Settings] (page 49).

• For functions other than “BD/DVD,” you can check whether [Dolby Pro Logic] (“PRO LOGIC”), [Dolby PL II

Movie] (“PLII MOVIE”), or the DTS Neo:6 mode is activated by pressing DISPLAY repeatedly so that the stream

information/decoding status appears in the front panel display.

Playback

27US

Playing a Disc

For playable discs, see “Playable Discs”

(page 60).

1Switch the input selector on your TV so

that the signal from the system

appears on your TV screen.

2Press Z, and place a disc on the disc

tray.

3Press Z to close the disc tray.

appears on the home menu and playback

starts.

If playback does not start automatically,

select in the [Video], [Music], or

[Photo] category, and press .

Some BD-ROMs with “BD-LIVE Logo*” have

bonus content and other data that can be

downloaded for enjoyment.

1Connect the USB device to the

(USB) port on the rear of the unit.

For local storage, use a 1 GB or larger USB

memory.

2Prepare for BD-LIVE (BD-LIVE only).

• Connect the system to a network

(page 20).

• Set [BD Internet Connection] to [Allow]

(page 50).

3Insert a BD-ROM with BONUSVIEW/

BD-LIVE.

The operation method differs depending on

the disc. Refer to the operating instructions

of the disc.

• To delete data in the USB memory, select [Erase BD

Data] in [Video], and press . All data stored in

the buda folder will be deleted.

You can enjoy Blu-ray 3D Discs with the 3D

logo*.

1Prepare for Blu-ray 3D Disc playback.

• Connect the system to your 3D-

compatible TV using a High-Speed

HDMI cable (supplied with Mexican and

Latin American models and BDV-T28

only).

• Set [3D Output Setting] and [TV Screen

Size Setting for 3D] in [Screen Settings]

(page 48).

2Insert a Blu-ray 3D Disc.

The operation method differs depending on

the disc. Refer to the operating instructions

supplied with the disc.

• Refer also to the operating instructions of your 3D-

compatible TV.

Playback

Enjoying BONUSVIEW/BD-LIVE

USB memory

Rear panel

Enjoying Blu-ray 3D

28US

You can check the playback information, etc.,

by pressing DISPLAY.

The displayed information differs depending on

the disc type and system status.

Example: when playing a BD-ROM

AOutput resolution/Video frequency

BTitle number or name

CThe currently selected audio setting

DAvailable functions ( angle, audio,

subtitle)

EPlayback information

Displays play mode, playing status bar, disc

type, video codec, bit rate, repeat type, elapsed

time, total playing time

FChapter number

GThe currently selected angle

Playing from a USB

Device

You can play video/music/photo files on the

connected USB device.

For playable types of files, see “Playable Types

of Files” (page 61).

1Connect the USB device to the

(USB) port on the unit.

Refer to the operating instructions of the

USB device before connecting.

* Mexican and Latin American models only.

2Press HOME.

The home menu appears on the TV screen.

3Press C/c to select [Video],

[Music], or [Photo].

4(For U.S. and Canada models)

Press X/x to select [USB device],

then press .

(For Mexican and Latin American

models)

Press X/x to select [USB device

(front)] or [USB device (rear)], then

press .

• Do not remove the USB device during

operation. To avoid data corruption or damage

to the USB device, turn the system off when

connecting or removing the USB device.

Displaying the play information

USB device

Rear panel

USB device*

Front panel

Playback

29US

Enjoying an iPod/iPhone

You can enjoy the music/video*/photo* and

charge the battery of an iPod/iPhone via the

system.

* U.S. and Canada models only.

Compatible iPod/iPhone models

The compatible iPod/iPhone models are as

follows. Update your iPod/iPhone with the latest

software before using with the system.

Made for iPod classic, iPod 5th generation

(video), iPod nano 6th generation, iPod nano 5th

generation (video camera), iPod nano 4th

generation (video), iPod nano 3rd generation

(video), iPod nano 2nd generation (aluminum),

iPod nano 1st generation, iPod touch 4th

generation, iPod touch 3rd generation, iPod

touch 2nd generation, iPod touch 1st generation,

iPhone 4, iPhone 3GS, iPhone 3G, iPhone

To enjoy an iPod/iPhone via the

system

1(For U.S. and Canada models)

Connect the Dock for iPod/iPhone

(supplied) to the (USB) port on the

unit, then place the iPod/iPhone onto

the Dock for iPod/iPhone.

When you play a video/photo file, connect

the video out jack of the Dock for iPod/

iPhone to the video input jack of your TV

with a video cord (supplied) before placing

the iPod/iPhone onto the Dock for iPod/

iPhone.

(For other models)

Connect the iPod/iPhone to the

(USB) port on the unit with the iPod/

iPhone’s USB cable.

2Press HOME.

The home menu appears on the TV screen.

USB

VIDEO IN

Dock for

iPod/iPhone

Video cord (supplied)

Rear panel

USB cable (supplied)

Rear panel

USB cable that is connected

to the iPod/iPhone

Front panel

USB cable that is connected

to the iPod/iPhone

30US

3Press C/c to select [Video]*,

[Music], or [Photo]*.

* U.S. and Canada models only.

4(For U.S. and Canada models)

Press X/x to select [iPod], then

press .

(For Other models)

Press X/x to select [iPod (front)] or

[iPod (rear)], then press .

xIf you selected [Video]* or [Music] in

Step 3

The video/music files are listed on the TV

screen. Go to the next Step.

xIf you selected [Photo] in Step 3*

[Please change the TV input to the video

input...] appears on the TV screen. Switch

the input selector on your TV so that the

signal from the iPod/iPhone appears on

your TV screen. Then, start the slideshow

by operating the iPod/iPhone directly.

* U.S. and Canada models only.

5Press C/X/x/c and to select the file

that you want to play.

The sound from the iPod/iPhone is played

on the system.

When you play a video file, switch the input

selector on your TV so that the signal from

the iPod/iPhone appears on your TV screen.

(U.S. and Canada models only)

You can operate the iPod/iPhone using the

buttons on the remote.

For operation details, refer to the operating

instructions of the iPod/iPhone.

• To change a system setting, such as the surround

setting, while viewing images from your iPod/iPhone

on your TV, select the input on your TV for this

system before operating the system. (U.S. and

Canada models only.)

To operate the iPod/iPhone using

the remote

You can operate the iPod/iPhone using the

buttons on the remote. The following table

shows an example of buttons that can be used.

(Depending on the iPod/iPhone model, the

operation may be different.)

For [Video]*/[Music]

For [Photo]*

* U.S. and Canada models only.

• The iPod/iPhone is charged when connected to the

system while the system is turned on.

• You cannot transfer songs onto the iPod/iPhone from

this system.

• Sony cannot accept responsibility in the event that

data recorded to iPod/iPhone is lost or damaged when

using an iPod/iPhone connected to this unit.

• This product has been designed specifically to work

with iPod/iPhone and has been certified to meet

Apple performance standards.

Press Operation

NStarts play.

XPauses play.

xStops play.

m or MFast reverses or forwards.

. or >Goes to the previous/next file or

chapter (if any).

Press Operation

N, XStarts/pauses play.

When you press and hold either of

these buttons for several seconds,

the connected iPod/iPhone enters

sleep mode.

xPauses play.

m or MFast reverses or forwards.

. or >Goes to the previous/next file.

When you press and hold either of

these buttons, the connected iPod/

iPhone fast reverses or fast forwards.

DISPLAY Turns the backlight on (or extends it

for 30 seconds).

OPTIONS, CReturns to previous display/folder

hierarchy.

X/xSelects the previous/next item.

, cEnters the selected item.

Playback

31US

• Do not remove the iPod/iPhone during operation. To

avoid data corruption or damage to the iPod/iPhone,

turn the system off when connecting or removing the

iPod/iPhone.

• The system only recognizes iPods/iPhones that have

previously been connected to the system (Mexican

and Latin American model only).

• The System Audio Control function does not work

while playing video/photo files via the iPod/iPhone

(U.S. and Canada models only).

• When you connect an iPod that is not compatible with

the video output function and select [iPod] in

[Video] or [Photo], an alert message appears on the

TV screen (U.S. and Canada models only).

• The system can recognize up to 3,000 files (including

folders).

Playing via a Network

BRAVIA Internet Video serves as a gateway

delivering selected Internet content and a variety

of on-demand entertainment straight to your

unit.

• For customers in the U.S. and Canada:

Some Internet content requires registration via a PC

before it can be played. For further details, visit the

following website:

http://www.sony.com/bluraysupport/

1Prepare for BRAVIA Internet Video.

Connect the system to a network (page 20).

2Press C/c to select [Video],

[Music], or [Photo].

3Press X/x to select an Internet content

provider icon, then press .

If the Internet content list has not been

retrieved, it will be represented by an

unacquired icon or a new icon.

To use the control panel

The control panel appears when the video file

starts playing. The displayed items may differ

depending on Internet content providers.

To display again, press DISPLAY.

AControl display

Press C/X/x/c or for playback operations.

BPlaying status bar

Status bar, cursor indicating the current

position, playing time, duration of the video

file

CNetwork condition indicator

Indicates signal strength for a wireless

connection.

Indicates a wired connection.

DNetwork transmission speed

EThe next video file name

FThe currently selected video file name

Streaming BRAVIA Internet

Video

32US

Available Options

Various settings and playback operations are

available by pressing OPTIONS. The available

items differ depending on the situation.

Common options

[Video] only

[Music] only

[Photo] only

Items Details

[Surround Setting] Changes the surround setting

(page 24).

[Repeat Setting] Sets repeat playback.

[3D Menu] [3D Depth Adjustment]:

Adjusts the depth of 3D

images.

[Favorites List] Displays the Favorites List.

[Play/Stop] Starts or stops playback.

[Play from beginning] Plays the item from the

beginning.

[Add to Favorites] Adds an Internet content item

to the Favorites List.

[Remove from

Favorites]

Erases an Internet content

item from the Favorites List.

Items Details

[A/V SYNC] Adjusts the gap between

picture and sound. For

details, see “Adjusting the

delay between the picture and

sound” (page 33).

[3D Output Setting] Sets whether or not to output

3D video automatically.

• 3D video from the HDMI

(IN 1) or HDMI (IN 2) jack

is output regardless of this

setting.

[Video Settings] • [Picture Quality Mode]:

Selects the picture settings

for different lighting

environments.

• [FNR]: Reduces the random

noise appearing in the

picture.

• [BNR]: Reduces the

mosaic-like block noise in

the picture.

• [MNR]: Reduces minor

noise around the picture

outlines (mosquito noise).

[Pause] Pauses playback.

[Top Menu] Displays the BD’s or DVD’s

Top Menu.

[Menu/Popup Menu] Displays the BD-ROM’s

Pop-up Menu or DVD’s

menu.

[Title Search] Searches for a title on BD-

ROMs/DVD VIDEOs and

starts playback from the

beginning.

[Chapter Search] Searches for a chapter and

starts playback from the

beginning.

[Angle] Switches to other viewing

angles when multi-angles are

recorded on BD-ROMs/DVD

VIDEOs.

[IP Content Noise

Reduction]

Adjusts the video quality for

Internet content.

Items Details

[Add Slideshow

BGM]

Registers music files in the

USB memory as slideshow

background music (BGM).

[Shuffle Setting]

(iPod/iPhone only)

Sets shuffle playback.

Items Details

[Slideshow] Starts a slideshow.

[Slideshow Speed] Changes the slideshow speed.

[Slideshow Effect] Sets the effect when playing a

slideshow.

Items Details

Playback

33US

When the sound does not match the pictures on

the TV screen, you can adjust the delay between

the picture and sound.

The setting method differs depending on the

function.

• Depending on the input stream, A/V SYNC may not

be effective.

When playing video content via

the “BD/DVD” function

1Press OPTIONS.

The option menu appears on the TV screen.

2Press X/x to select [A/V SYNC], then

press .

3Press C/c to adjust the delay between

the picture and sound.

You can adjust from 0 ms to 300 ms in 25

ms increments.

4Press .

The setting is made.

When playing via the “HDMI1,”

“HDMI2,” “TV,” or “AUDIO”

function

1Press OPTIONS.

The option menu appears in the front panel

display.

2Press X/x repeatedly until “A/V SYNC”

appears in the front panel display, then

press or c.

3Press X/x to adjust the delay between

the picture and sound.

You can adjust from 0 ms to 300 ms in 25

ms increments.

4Press .

The setting is made.

5Press OPTIONS.

The option menu in the front panel display

turns off.

[Slideshow BGM] • [Off]: Turns off the

function.

• [My Music from USB]: Sets

the music files registered in

[Add Slideshow BGM].

• [Play from Music CD]: Sets

the tracks on CD-DAs

(music CDs).

[Rotate Left] Rotates the photo

counterclockwise by

90 degrees.

[Rotate Right] Rotates the photo clockwise

by 90 degrees.

[View Image] Displays the selected picture.

Adjusting the delay between

the picture and sound

(A/V SYNC)

Items Details

34US

Selecting the Effect to

Suit the Source

You can select a suitable sound mode for movies

or music.

Press SOUND MODE +/– repeatedly during

playback until the desired mode appears in

the front panel display.

• “AUTO”: The system selects “MOVIE” or

“MUSIC” automatically to produce the sound

effect depending on the disc or sound stream.

• “MOVIE”: The system provides the sound for

movies.

• “MUSIC”: The system provides the sound for

music.

• “SPORTS”: The system adds reverberation for

sports programs.

• “GAME ROCK”: The system provides the

sound for music/rhythm games.

• Depending on the disc or source, when you select

“AUTO,” the beginning of the sound may be cut off

as the system selects the optimum mode

automatically. To avoid cutting the sound, select

other than “AUTO.”

• Depending on the input stream, the sound mode may

not be effective.

• When you play a Super Audio CD, this function does

not work.

Selecting the Audio

Format, Multilingual

Tracks, or Channel

When the system is playing a BD/DVD VIDEO

recorded in multiple audio formats (PCM,

Dolby Digital, MPEG audio, or DTS) or

multilingual tracks, you can change the audio

format or language.

With a CD, you can select the sound from the

right or left channel and listen to the sound of the

selected channel through both the right and left

speakers.

Press AUDIO repeatedly during playback to

select the desired audio signal.

The audio information appears on the TV

screen.

xBD/DVD VIDEO

Depending on the BD/DVD VIDEO, the choice

of language varies.

When 4 digits are displayed, they indicate a

language code. See “Language Code List”

(page 64) to confirm which language the code

represents. When the same language is

displayed two or more times, the BD/DVD

VIDEO is recorded in multiple audio formats.

Sound Adjustment

564

231

SOUND

MODE +/–

564

231

AUDIO

Sound Adjustment

35US

xDVD-VR

The types of sound tracks recorded on a disc are

displayed.

Example:

• [ Stereo]

• [ Stereo (Audio1)]

• [ Stereo (Audio2)]

•[ Main]

•[ Sub]

• [ Main/Sub]

• [ Stereo (Audio1)] and [ Stereo (Audio2)] do not

appear when only one audio stream is recorded on the

disc.

xCD

•[ Stereo]: The standard stereo sound.

• [ 1/L]: The sound of the left channel

(monaural).

• [ 2/R]: The sound of the right channel

(monaural).

• [ L+R]: The sound of both the left and right

channels output from each individual speaker.

Enjoying Multiplex

Broadcast Sound

(DUAL MONO)

You can enjoy multiplex broadcast sound when

the system receives or plays a Dolby Digital

multiplex broadcast signal.

• To receive the Dolby Digital signal, you need to

connect a TV or other component to the unit with a

digital optical cord (page 15). If your TV is

compatible with the Audio Return Channel function

(pages 15,51), you can receive a Dolby Digital signal

via an HDMI cable.

Press AUDIO repeatedly until the desired

signal appears in the front panel display.

•“MAIN”: Sound of the main language will be

output.

• “SUB”: Sound of the sub language will be

output.

• “MAIN/SUB”: Mixed sound of both the main

and sub languages will be output.

564

231

AUDIO

36US

Listening to the Radio

You can enjoy radio sound with the system’s

speakers.

1Press FUNCTION repeatedly until “FM”

appears in the front panel display.

2Select the radio station.

Automatic tuning

Press and hold TUNING +/– until the auto

scanning starts.

[Auto Tuning] appears on the TV screen.

Scanning stops when the system tunes in a

station.

To stop the automatic tuning manually,

press TUNING +/– or x.

Manual tuning

Press TUNING +/– repeatedly.

3Adjust the volume by pressing

VOL +/–.

If an FM program is noisy

If an FM program is noisy, you can select

monaural reception. There will be no stereo

effect, but reception will improve.

1Press OPTIONS.

The option menu appears on the TV screen.

2Press X/x to select [FM Mode], then

press .

3Press X/x to select [Monaural].

• [Stereo]: Stereo reception.

• [Monaural]: Monaural reception.

4Press .

The setting is made.

To turn off the radio

Press "/1.

You can preset up to 20 stations. Before tuning,

make sure to turn down the volume to minimum.

1Press FUNCTION repeatedly until “FM”

appears in the front panel display.

2Press and hold TUNING +/– until the

auto scanning starts.

Scanning stops when the system tunes in a

station.

3Press OPTIONS.

The option menu appears on the TV screen.

4Press X/x to select [Preset Memory],

then press .

5Press X/x to select the preset number

you want, then press .

6Repeat Steps 2 to 5 to store other

stations.

To change the preset number

Select the desired preset number by pressing

PRESET +/–, then perform the procedure from

Step 3.

Tuner

564

231

PRESET +/–

VOL +/–

TUNING +/–

C/X/x/c,

HOME

"/1

Number

buttons

FUNCTION

OPTIONS

FM 07

88.00

MHz

Current preset number

Current station Presetting radio stations

Tuner

37US

1Press FUNCTION repeatedly until “FM”

appears in the front panel display.

The last received station is tuned in.

2Press PRESET +/– repeatedly to select

the preset station.

The preset number and frequency appear on

the TV screen and front panel display.

Each time you press the button, the system

tunes in one preset station.

• You can select the preset station number directly

by pressing the number buttons.

• Each time you press DISPLAY, the display in

the front panel display changes as follows:

Frequency t Preset number t

Stream information/Decoding status* t

Frequency t …

* Does not appear depending on the setting of

[Surround Setting].

Selecting the preset station

38US

Using the Control for

HDMI Function for

“BRAVIA” Sync

This function is available on TVs with the

“BRAVIA” Sync function.

By connecting Sony components that are

compatible with the Control for HDMI function

via an HDMI cable, operation is simplified.

• Some functions can only be used if the connected TV

is compatible, and require prior setting via the TV.

Refer to the operating instructions of the TV.

• To use the System Audio Control function, you need

to make an audio connection between the system and

TV (page 15).

Control for HDMI - Easy Setting

You can set the system’s [Control for HDMI]

function automatically by enabling the

corresponding setting on the TV.

For details about the Control for HDMI

function, see “[HDMI Settings]” (page 51)

System Power Off

You can turn the system off in sync with the TV.

• The system does not turn off automatically while

playing music or when set to the “FM” function.

One-Touch Play

When you press N on the remote, the system

and your TV turn on, and your TV’s input is set

to the HDMI input to which the system is

connected.

System Audio Control

You can simplify operation to enjoy sound from

the TV or other components.

You can use the System Audio Control function

as follows:

• When the system is turned on, the sound of the

TV or other components can be output from

the speakers of the system.

• When sound from the TV or other components

is output via the speakers of the system, you

can change the speakers to which TV sound is

output by pressing

SPEAKERS TVyAUDIO.

• When sound from the TV or other components

is output via the speakers of the system, you

can adjust the volume and turn off the sound of

the system by operating the TV.

• While the TV is in PAP (picture and picture) mode,

or the system is playing video/photo files from the

iPod/iPhone, the System Audio Control function will

not work.

• Depending on the TV, when you adjust the unit’s

volume, the volume level appears on the TV screen.

In this case, the volume level that appears on the TV

screen and the unit’s front panel display may differ.

Audio Return Channel

You can enjoy TV sound via the system by using

just one HDMI cable. For details of the setting,

see “Connecting the TV” (page 15).

Remote Easy Control

You can control the basic functions of the

system via the TV remote when the system’s

video output is displayed on the TV screen.

Language Follow

When you change the language for the on-screen

display of the TV, the system’s on-screen

display language is also changed after turning

the system off and on.

Routing Control

When you perform One-Touch Play on the

connected component, the system turns on and

sets the system’s function to “HDMI1” or

“HDMI2” (depending on the HDMI input jack

in use), and your TV’s input is automatically set

to the HDMI input to which the system is

connected.

Other Operations

Using “BRAVIA” Sync

Other Operations

39US

• Make sure that the component is connected to the

system via an HDMI cable, and the Control for

HDMI function of the connected component is set to

on.

Setting the Speakers

[Speaker Settings]

To obtain the best possible surround sound, set

connection of the speakers and their distance

from your listening position. Then use the test

tone to adjust the level and the balance of the

speakers to the same level.

1Press HOME.

The home menu appears on the TV screen.

2Press C/c to select [Setup].

3Press X/x to select [Audio Settings],

then press .

4Press X/x to select [Speaker Settings],

then press .

The [Speaker Settings] display appears.

5Press X/x to select the item, then press

Check the following settings.

x[Connection]

If you do not connect center or surround

speakers, set the parameters for [Center] and

[Surround]. Since the front speaker and

subwoofer settings are fixed, you cannot change

them.

[Front]

[Yes]

[Center]

[Yes]: Normally select this.

[None]: Select this if no center speaker is used.

[Surround]

[Yes]: Normally select this.

[None]: Select this if no surround speaker is

used.

[Subwoofer]

[Yes]

x[Distance]

When you move the speakers, be sure to set the

parameters of the distance (A) from the

listening position to the speakers.

You can set the parameters from 0 to 23 feet (0.0

to 7.0 meters).

The speakers in the illustration correspond to the

following:

1Center speaker

2Front left speaker (L)

3Front right speaker (R)

4Subwoofer

5Surround left speaker (L)

6Surround right speaker (R)

[Front Left/Right] 10 ft/3.0 m: Set the front

speaker distance.

[Center]* 10 ft/3.0 m: Set the center speaker

distance.

[Surround Left/Right]* 10 ft/3.0 m: Set the

surround speaker distance.

[Subwoofer] 10 ft/3.0 m: Set the subwoofer

distance.

* This item appears when you set it to [Yes] in the

[Connection] setting.

• Depending on the input stream, [Distance] may not

be effective.

• You can change measurement units (feet or meters)

by pressing the color button (RED).

x[Level]

You can adjust the sound level of the speakers.

You can set the parameters from –6.0 dB to +6.0

40US

dB. Be sure to set [Test Tone] to [On] for easy

adjustment.

[Front Left/Right] 0.0 dB: Set the front speaker

level.

[Center]* 0.0 dB: Set the center speaker level.

[Surround Left/Right]* 0.0 dB: Set the surround

speaker level.

[Subwoofer] 0.0 dB: Set the subwoofer level.

* This item appears when you set it to [Yes] in the

[Connection] setting.

x[Test Tone]

The speakers will emit a test tone to adjust

[Level].

[Off]: The test tone is not emitted from the

speakers.

[On]: The test tone is emitted from each speaker

in sequence while adjusting level. When you

select one of the [Speaker Settings] items, the

test tone is emitted from each speaker in

sequence.

Adjust the sound level as follows.

1Set [Test Tone] to [On].

2Press X/x to select [Level], then press

3Press X/x to select the desired speaker

type, then press .

4Press C/c to select the left or right

speaker, then press X/x to adjust the

level.

5Press .

6Repeat Steps 3 to 5.

7Press RETURN.

The system returns to the previous display.

8Press X/x to select [Test Tone], then

press .

9Press X/x to select [Off], then press

• The test tone signals are not output from the HDMI

(OUT) jack.

• To adjust the volume of all the speakers at one time,

press VOL +/–.

Using the Sleep Timer

You can set the system to turn off at a preset

time, so you can fall asleep listening to music.

The time can be preset in intervals of 10

minutes.

Press SLEEP.

Each time you press SLEEP, the minutes display

(the remaining time) in the front panel display

changes by 10 minutes.

When you set the sleep timer, the remaining

time appears every 5 minutes.

When the remaining time is less than 2 minutes,

“SLEEP” flashes in the front panel display.

To check the remaining time

Press SLEEP once.

To change the remaining time

Press SLEEP repeatedly to select the desired

time.

Deactivating the Buttons

on the Unit

(Child Lock)

You can deactivate the buttons on the unit

(except for "/1) for preventing misoperation,

such as child mischief (child lock function).

Press x on the unit for more than 5

seconds.

“LOCKED” appears in the front panel display.

The child lock function is activated and the

buttons on the unit are locked. (You can operate

the system by using the remote.)

To cancel, press x for more than 5 seconds so

that “UNLOCK” appears in the front panel

display.

• When you operate the buttons on the unit while the

child lock function is on, “LOCKED” flashes in the

front panel display.

Other Operations

41US

Controlling Your TV with

the Supplied Remote

By adjusting the remote signal, you can control

your TV with the supplied remote.

• When you replace the batteries of the remote, the

code number may reset itself to the default (SONY)

setting. Reset the appropriate code number.

Press and hold TV "/1 while entering your

TV’s manufacturer’s code (see the table)

using the number buttons. Then release TV

"/1.

If the setting is unsuccessful, the currently

registered code is not changed. Re-enter the

code number.

Code numbers of controllable

TVs

If more than one code number is listed, try

entering them one at a time until you find the

code that works with your TV.

Changing the Brightness

of the Front Panel

Display

Press DIMMER.

Each time you press DIMMER, the brightness of

the front panel display is changed.

Saving Power in Standby

Mode

Check that the following settings are both made:

– [Control for HDMI] in [HDMI Settings] is set

to [Off] (page 51).

– [Quick Start Mode] is set to [Off] (page 51).

Preparing the remote for

controlling the TV

Manufacturer Code number

SONY 01 (default)

LG 02

PANASONIC 05

SAMSUNG 02, 06

SHARP 03

TOSHIBA 04

VIZIO 07

42US

Browsing Websites

You can connect to the Internet and enjoy

websites like the Sony homepage using the

system.

1Prepare for Internet browsing.

Connect the system to a network (page 20).

2Press HOME.

The home menu appears on the TV screen.

3Press C/c to select [Network].

4Press X/x to select [Internet Browser],

then press .

The [Internet Browser] display appears.

• Some websites may not display correctly, or not

function.

To enter a URL

Select [URL entry] from the options menu.

Enter the URL using the software keyboard,

then select [Enter].

To set the default start page

While the page you want to set is displayed,

select [Set as start page] from the options menu.

To quit Internet Browser

Press HOME.

You can check website information by pressing

DISPLAY. The display information differs

depending on the website and page status.

APage title

BCursor

Move by pressing C/X/x/c. Place the cursor

on the link you want to view, then press .

The linked website is displayed.

CPage address

DSSL icon

Appears when the linked URL is secured.

ESignal strength indicator

Appears when the system is connected to a

wireless network.

FProgress bar/Loading icon

Appears when the page is being read, or during

file download/transfer.

GText input field

Press , then choose [Input] from the options

menu to open the software keyboard.

HScroll bar

Press C/X/x/c to move the page display left,

up, down, or right.

Various settings and operations are available by

pressing OPTIONS.

The available items differ depending on the

situation.

Internet Browser display

Available options

Items Details

[Browser Setup] Displays the Internet Browser

settings.

• [Zoom]: Increases or

decreases the size of the

displayed contents.

• [JavaScript Setup]: Sets

whether to enable or disable

JavaScript.

• [Cookie Setup]: Sets

whether or not to accept

browser cookies.

• [SSL Alarm Display]: Sets

whether to enable or disable

SSL.

[Input] Displays the software

keyboard to enter characters

while browsing a website.

[Break] Moves the cursor to the next

line in the text input field.

Other Operations

43US

Setting up the Network

[Internet Settings]

Before setting, connect the system to the

network. For details, see “Step 3: Connecting to

the Network” (page 20).

To open the setting display

1Press HOME.

The home menu appears on the TV screen.

2Press C/c to select [Setup].

3Press X/x to select [Network Settings],

then press .

[Delete] Erases one character on the

left side of the cursor during

text input.

[Window List] Displays a list of all currently

opened websites.

Allows you to return to a

previously displayed website

by selecting the window.

[Bookmark List] Displays the bookmark list.

[Character encoding] Sets the character code.

[Previous page] Moves to a previously

displayed page.

[Next page] Moves to the previously

displayed next page.

[Cancel loading] Stops loading a page.

[Reload] Reloads the same page.

[URL entry] Allows you to enter a URL

when the software keyboard

is displayed.

[Add to Bookmark] Adds the currently displayed

website to the bookmark list.

[Set as start page] Sets the currently displayed

website as the default start

page.

[Open in new

window]

Opens a link in a new

window.

[Display certificate] Displays server certificates

sent from pages that support

SSL.

Items Details

564

231

HOME

44US

4Press X/x to select [Internet Settings],

then press .

The [Internet Settings] display appears.

• The [Internet Settings] items are necessary to connect

to the Internet. Enter the respective (alphanumeric)

values for your broadband router or Wireless LAN

router. The items that need to be set may differ,

depending on the Internet service provider or the

router. For details, refer to the instruction manuals

that have been provided by your Internet service

provider or supplied with the router.

• For more information, go to the following URL.

For customers in the U.S.:

http://www.sony.com/support

For customers in Canada:

English: http://www.sony.ca/support

French: http://fr.sony.ca/support

For customers in Mexico and Latin America:

http://esupport.sony.com/LA

Follow the Steps below for connecting to a LAN

(Local Area Network).

Auto setting

1Press X/x to select [Wired Setup] on

the [Internet Settings] display, then

press .

2Press X/x to select [Auto], then press

The system performs the network setting

automatically, and internet settings appear

on the TV screen.

3Press c.

4Press X/x to select [Save & Connect],

then press .

The system starts checking the network

connection.

5Check that the message [Internet

Settings is now complete.] appears,

then press .

The setup is finished. If the message does

not appear, follow the on-screen messages.

Manual setting

1Press X/x to select [Wired Setup] on

the [Internet Settings] display, then

press .

2Press X/x to select [Custom], then

press .

3Press X/x to select the network setting

type, then press .

• [Auto]: The system sets the IP address

automatically, and the [DNS Settings]

display appears.

When you select [Auto] and press , the

system sets the DNS setting

automatically.

When you select [Specify IP address] and

press , enter the DNS settings

manually.

Press C/X/x/c and the number buttons to

set the following items, then press .

– [Primary DNS]

– [Secondary DNS]

• [Specify IP address]: Enter the network

settings manually according to your

network environment.

Press C/X/x/c and the number buttons to

set the following items, then press .

–[IP Address]

– [Subnet Mask]

– [Default Gateway]

– [Primary DNS]

– [Secondary DNS]

When connecting to the LAN

with a LAN cable

Other Operations

45US

4Press X/x to select the proxy server

setting, then press .

• [No]: A proxy server is not used.

• [Yes]: Enter the proxy server setting.

Press C/X/x/c and the number buttons,

then press .

The value of the internet settings appears on

the TV screen.

5Press c.

6Press X/x to select [Save & Connect],

then press .

The system starts checking the network

connection.

7Check that the message [Internet

Settings is now complete.] appears,

then press .

The setup is finished. If the message does

not appear, follow the on-screen messages.

Follow the Steps below for connecting to a

wireless LAN (Local Area Network).

When your wireless router is

compatible with the WPS

function

1Press X/x to select [USB Wireless

Setup] on the [Internet Settings]

display, then press .

2Press X/x to select [Wi-Fi Protected

Setup (WPS)], then press .

3Activate the WPS function of your

wireless router, press X/x to select

[Start], then press .

For details about activating the WPS

function, see the operating instructions of

your router.

4Check that the message [Wi-Fi

Protected Setup was successful.]

appears, then press c.

Setup of wireless LAN connectivity and the

IP address is finished.

Next, enter the proxy server setting. Follow

Steps 4 to 7 of “Manual setting” in “When

connecting to the LAN with a LAN cable”

above.

When your wireless router is not

compatible with the WPS

function

1Press X/x to select [USB Wireless

Setup] on the [Internet Settings]

display, then press .

2Press X/x to select [Scan], then press

The system searches for available wireless

LANs, then the list of wireless LANs

appears.

3Press X/x to select the wireless LAN

name, then press .

xWhen the selected wireless LAN is

unsecured

Setup of wireless LAN connectivity is

finished. Next, enter the IP address settings

by following the Steps of “Auto setting” or

“Manual setting” in “When connecting to

the LAN with a LAN cable” above.

xWhen the selected wireless LAN is

secured

The display for entering a WEP or WPA

key appears. Go to Step 5.

xTo specify the wireless LAN name

Select [Manual Entry].

The input display appears. Enter the

wireless LAN name by following the on-

screen messages, then press c.

When connecting to the

wireless LAN with the USB

Wireless LAN Adapter

46US

4Press X/x to select the security mode,

then press .

• [None]: Select this if the wireless LAN is

unsecured. Setup of wireless LAN

connectivity is finished. Next, enter the IP

address settings by following the Steps of

“Auto setting” or “Manual setting” in

“When connecting to the LAN with a

LAN cable” above.

• [WEP]: The wireless LAN is protected by

a WEP key.

• [WPA/WPA2-PSK]: The wireless LAN is

protected by a WPA-PSK or WPA2-PSK.

• [WPA2-PSK]: The wireless LAN is

protected by a WPA2-PSK.

5Enter the WEP key/WPA key by

following the on-screen messages,

then press c.

Setup of wireless LAN connectivity is

finished. Next, enter the IP address settings

by following the Steps of “Auto setting” or

“Manual setting” in “When connecting to

the LAN with a LAN cable” above.

Since communication via the wireless LAN

function is established by radio waves, the

wireless signal may be susceptible to

interception. To protect wireless

communication, this system supports various

security functions. Be sure to correctly

configure the security settings in accordance

with your network environment.

No Security

Although you can easily make settings, anyone

can intercept wireless communication or intrude

into your wireless network, even without any

sophisticated tools. Keep in mind that there is a

risk of unauthorized access or interception of

data.

WEP

WEP applies security to communications to

prevent outsiders from intercepting

communications or intruding into your wireless

network. WEP is a legacy security technology

that enables older device which do not support

TKIP/AES to be connected.

WPA-PSK (TKIP), WPA2-PSK

(TKIP)

TKIP is a security technology developed in

response to the deficiencies of WEP. TKIP

assures a higher security level than WEP.

WPA-PSK (AES), WPA2-PSK (AES)

AES is a security technology that uses an

advanced security method distinct from WEP

and TKIP.

AES assures a higher security level than WEP or

TKIP.

About wireless LAN security

Settings and Adjustments

47US

Using the Setup Display

You can make various adjustments of items such

as picture and sound.

Select (Setup) on the home menu when you

need to change the settings of the system.

The default settings are underlined.

• Playback settings stored in the disc take priority over

the Setup Display settings and not all the functions

described may work.

1Press HOME.

The home menu appears on the TV screen.

2Press C/c to select [Setup].

3Press X/x to select the setup category

icon to change, then press .

Example: [Screen Settings]

You can setup the following options.

[Network Update]

You can update and improve the functions of the

system.

For information about update functions, refer to

the following website:

For customers in the U.S.:

http://www.sony.com/support

For customers in Canada:

English: http://www.sony.ca/support

French: http://fr.sony.ca/support

Settings and Adjustments

Icon Explanation

[Network Update] (page 47)

Updates the software of the

system.

[Screen Settings] (page 48)

Makes the screen settings

according to the type of

connecting jacks.

[Audio Settings] (page 49)

Makes the audio settings

according to the type of

connecting jacks.

[BD/DVD Viewing Settings]

(page 50)

Makes detailed settings for BD/

DVD playback.

[Parental Control Settings]

(page 50)

Makes detailed settings for the

Parental Control function.

[Music Settings] (page 51)

Makes detailed settings for

Super Audio CD playback.

[System Settings] (page 51)

Makes the system-related

settings.

[Network Settings] (page 51)

Makes detailed settings for

Internet and network.

[Easy Setup] (page 52)

Re-runs the Easy Setup to make

the basic settings.

[Resetting] (page 52)

Resets the system to the factory

settings.

Icon Explanation

48US

For customers in Mexico and Latin America:

http://esupport.sony.com/LA

During a software update, “UPDATING”

appears in the front panel display. After the

update completes, the main unit automatically

turns off. Please wait for the software update to

complete; do not turn the main unit on or off, or

operate the main unit or TV.

[Screen Settings]

x[3D Output Setting]

[Auto]: Normally select this.

[Off]: Select this to display all contents in 2D.

• 3D video from the HDMI (IN 1) or HDMI (IN 2) jack

is output regardless of this setting.

x[TV Screen Size Setting for 3D]

Sets the screen size of your 3D compatible TV.

• This setting does not apply to 3D video from the

HDMI (IN 1) or HDMI (IN 2) jack.

x[TV Type]

[16:9]: Select this when connecting to a wide-

screen TV or a TV with a wide-mode function.

[4:3]: Select this when connecting to a 4:3

screen TV without a wide-mode function.

x[Screen Format]

[Original]: Select this when connecting to a TV

with a wide-mode function. Displays a 4:3

screen picture in 16:9 aspect ratio even on a

wide-screen TV.

[Fixed Aspect Ratio]: Changes the picture size

to fit the screen size with the original picture

aspect ratio.

x[DVD Aspect Ratio]

[Letter Box]: Displays a wide picture with black

bands on the top and bottom.

[Pan & Scan]: Displays a full-height picture on

the entire screen, with trimmed sides.

x[Cinema Conversion Mode]

[Auto]: Normally select this. The unit

automatically detects whether the material is

video-based or film-based, and switches to the

appropriate conversion method.

[Video]: The conversion method suited for

video-based material will always be selected

regardless of the material.

x[Output Video Format]

[HDMI]: Normally select [Auto]. Select

[Original Resolution] to output the resolution

recorded on the disc. (When the resolution is

lower than SD resolution, it is scaled up to SD

resolution.)

[Video]: Automatically sets the lowest

resolution.

x[BD/DVD-ROM 1080/24p Output]

[Auto]: Outputs 1920 × 1080p/24 Hz video

signals only when connecting a 1080/24p-

compatible TV using the HDMI (OUT) jack.

[Off]: Select this when your TV is not

compatible with 1080/24p video signals.

x[YCbCr/RGB (HDMI)]

[Auto]: Automatically detects the type of

external device, and switches to the matching

color setting.

[YCbCr (4:2:2)]: Outputs YCbCr 4:2:2 video

signals.

[YCbCr (4:4:4)]: Outputs YCbCr 4:4:4 video

signals.

Settings and Adjustments

49US

[RGB]: Select this when connecting to a device

with an HDCP-compliant DVI jack.

x[HDMI Deep Color Output]

[Auto]: Normally select this.

[16bit], [12bit], [10bit]: Outputs 16bit/12bit/

10bit video signals when the connected TV is

compatible with Deep Color.

[Off]: Select this when the picture is unstable or

colors appear unnatural.

x[Pause Mode] (BD/DVD VIDEO/DVD-R/

DVD-RW only)

[Auto]: The picture, including subjects that

move dynamically, is output with no jitter.

Normally select this position.

[Frame]: The picture, including subjects that do

not move dynamically, is output in high

resolution.

[Audio Settings]

x[BD Audio MIX Setting]

[On]: Outputs the audio obtained by mixing the

interactive audio and secondary audio to the

primary audio.

[Off]: Outputs the primary audio only.

x[Audio DRC]

You can compress the dynamic range of the

sound track.

[Auto]: Performs playback at the dynamic range

specified by the disc (BD-ROM only).

[On]: The system reproduces the sound track

with the kind of dynamic range that the

recording engineer intended.

[Off]: No compression of dynamic range.

x[Attenuate - AUDIO]

Distortion may occur when you listen to a

component connected to the AUDIO (AUDIO

IN L/R) jacks. You can prevent distortion by

reducing the input level on the unit.

[On]: Attenuates the input level. The output

level is changed.

[Off]: Normal input level.

x[Audio Output]

You can select the output method where the

audio signal is output.

[Speaker]: Outputs multi-channel sound from

the system’s speakers only.

[Speaker + HDMI]: Outputs multi-channel

sound from the system’s speakers and 2-channel

linear PCM signals from the HDMI (OUT) jack.

[HDMI]: Outputs sound from the HDMI (OUT)

jack only. Sound format depends on the

connected component.

• When [Control for HDMI] is set to [On] (page 51),

[Audio Output] is set to [Speaker + HDMI]

automatically and this setting cannot be changed.

• When [Audio Output] is set to [HDMI], the output

signal format for the “TV” function is 2-channel

linear PCM.

x[Sound Effect]

You can set the system’s sound effects (SOUND

MODE and [Surround Setting]) to on/off.

[On]: Enables all of the system’s sound effects.

The upper limit of sampling frequency is set to

48 kHz.

[Off]: The sound effects are disabled. Select this

when you do not want to set the upper limit of

sampling frequency.

x[Surround Setting]

You can select the surround setting. For details,

see “Step 6: Enjoying Surround Sound”

(page 24)

x[Speaker Settings]

To obtain the best possible surround sound, set

the speakers. For details, see “Setting the

Speakers” (page 39).

50US

[BD/DVD Viewing

Settings]

You can make detailed settings for BD/DVD

playback.

x[BD/DVD Menu]

You can select the default menu language for

BD-ROMs or DVD VIDEOs.

When you select [Select Language Code], the

display for entering the language code appears.

Enter the code for your language by referring to

“Language Code List” (page 64).

x[Audio]

You can select the default track language for

BD-ROMs or DVD VIDEOs.

When you select [Original], the language given

priority in the disc is selected.

When you select [Select Language Code], the

display for entering the language code appears.

Enter the code for your language by referring to

“Language Code List” (page 64).

x[Subtitle]

You can select the default subtitle language for

BD-ROMs or DVD VIDEOs.

When you select [Select Language Code], the

display for entering the language code appears.

Enter the code for your language by referring to

“Language Code List” (page 64).

x[BD Hybrid Disc Playback Layer]

[BD]: Plays BD layer.

[DVD/CD]: Plays DVD or CD layer.

x[BD Internet Connection]

[Allow]: Normally select this.

[Do not allow]: Prohibits Internet connection.

[Parental Control

Settings]

x[Password]

Set or change the password for the Parental

Control function. A password allows you to set

a restriction on BD-ROM, DVD VIDEO, or

Internet video playback. If necessary, you can

differentiate the restriction levels for BD-ROMs

and DVD VIDEOs.

x[Parental Control Area Code]

Playback of some BD-ROMs or DVD VIDEOs

can be limited according to the geographic area.

Scenes may be blocked or replaced with

different scenes. Follow the on-screen

instructions and enter your four-digit password.

x[BD Parental Control]

Playback of some BD-ROMs can be limited

according to the age of the users. Scenes may be

blocked or replaced with different scenes.

Follow the on-screen instructions and enter your

four-digit password.

x[DVD Parental Control]

Playback of some DVD VIDEOs can be limited

according to a predetermined level such as the

age of the users. Scenes may be blocked or

replaced with different scenes. Follow the

on-screen instructions and enter your four-digit

password.

x[Internet Video Parental Control]

Playback of some Internet videos can be limited

according to the age of the users. Scenes may be

blocked or replaced with different scenes.

Follow the on-screen instructions and enter your

four-digit password.

x[Internet Video Unrated]

[Allow]: Allows the playback of unrated

Internet videos.

[Block]: Blocks the playback of unrated Internet

videos.

Settings and Adjustments

51US

[Music Settings]

You can make detailed settings for Super Audio

CD playback.

x[Super Audio CD Playback Layer]

[Super Audio CD]: Plays the Super Audio CD

layer.

[CD]: Plays the CD layer.

x[Super Audio CD Playback Channel]

[DSD 2ch]: Plays the 2ch area.

[DSD Multi]: Plays the multi-channel area.

[System Settings]

You can make the system-related settings.

x[OSD]

You can select your language for the system on-

screen displays.

x[HDMI Settings]

[Control for HDMI]

[On]: On. You can operate mutually between

components that are connected with an HDMI

cable.

[Off]: Off.

[Audio Return Channel]

This function is available when you connect the

system and TV that is compatible with the Audio

Return Channel function.

[Auto]: The system can receive the digital audio

signal of the TV automatically via an HDMI

cable.

[Off]: Off.

• This function is available only when [Control for

HDMI] is set to [On].

x[Quick Start Mode]

[On]: Shortens the startup time from standby

mode. You can operate the system quickly after

turning it on.

[Off]: The default setting.

x[Auto Standby]

[On]: Turns on the [Auto Standby] function.

When you do not operate the system for about

30 minutes, the system enters standby mode

automatically.

[Off]: Turns off the function.

x[Auto Display]

[On]: Automatically displays information on the

screen when changing the viewing titles, picture

modes, audio signals, etc.

[Off]: Displays information only when you

press DISPLAY.

x[Screen Saver]

[On]: Turns on the screen saver function.

[Off]: Off.

x[Software Update Notification]

[On]: Sets the system to inform you of newer

software version information (page 47).

[Off]: Off.

x[System Information]

You can display the system’s software version

information and the MAC address.

[Network Settings]

You can make detailed settings for Internet and

network.

x[Internet Settings]

Connect the system to the network beforehand.

For details, see “Step 3: Connecting to the

Network” (page 20).

x[Network Connection Diagnostics]

You can run the network diagnostic to check if

the network connection has been made properly.

52US

[Easy Setup]

Re-runs the Easy Setup to make the basic

settings. Follow the on-screen instructions.

[Resetting]

x[Reset to Factory Default Settings]

You can reset the system settings to the factory

default by selecting the group of settings. All the

settings within the group will be reset.

x[Initialize Personal Information]

You can erase your personal information stored

in the system.

Additional Information

53US

Precautions

On safety

• To prevent fire or shock hazard, do not place objects

filled with liquids, such as vases, on the system, or

place the system near water, such as near a bathtub or

shower room. Should any solid object or liquid fall

into the cabinet, unplug the system and have it

checked by qualified personnel before operating it

any further.

• Do not touch the AC power cord (mains lead) with

wet hands. Doing so may cause an electric shock.

On power sources

• Unplug the unit from the wall outlet (mains) if you do

not intend to use it for an extended period of time. To

disconnect the cord, pull it out by the plug, never by

the cord.

On placement

• Place the system in a location with adequate

ventilation to prevent heat build-up in the system.

• At high volume, over long periods of time, the cabinet

becomes hot to the touch. This is not a malfunction.

However, touching the cabinet should be avoided. Do

not place the system in a confined space where

ventilation is poor as this may cause overheating.

• Do not block the ventilation slots by putting anything

on the system. The system is equipped with a high

power amplifier. If the ventilation slots are blocked,

the system can overheat and malfunction.

• Do not place the system on surfaces (rugs, blankets,

etc.) or near materials (curtains, draperies) that may

block the ventilation slots.

• Do not install the system in a confined space, such as

a bookshelf or similar unit.

• Do not install the system near heat sources such as

radiators, air ducts, or in a place subject to direct

sunlight, excessive dust, mechanical vibration, or

shock.

• Do not install the system in an inclined position. It is

designed to be operated in a horizontal position only.

• Keep the system and discs away from components

with strong magnets, such as microwave ovens, or

large loudspeakers.

• Do not place heavy objects on the system.

On operation

• If the system is brought directly from a cold to a warm

location, or is placed in a very damp room, moisture

may condense on the lenses inside the unit. Should

this occur, the system may not operate properly. In

this case, remove the disc and leave the system turned

on for about half an hour until the moisture

evaporates.

• When you move the system, take out any disc. If you

do not, the disc may be damaged.

• If anything falls into the cabinet, unplug the unit and

have it checked by qualified personnel before

operating it any further.

On adjusting volume

• Do not turn up the volume while listening to a section

with very low level inputs or no audio signals. If you

do, the speakers may be damaged when a peak level

section is suddenly played.

On cleaning

• Clean the cabinet, panel, and controls with a soft cloth

slightly moistened with a mild detergent solution. Do

not use any type of abrasive pad, scouring powder or

solvent such as alcohol or benzine.

If you have any questions or problems concerning

your system, please consult your nearest Sony dealer.

On cleaning discs, disc/lens

cleaners

• Do not use cleaning discs or disc/lens cleaners

(including wet or spray types). These may cause

the apparatus to malfunction.

On replacement of parts

• In the events that this system is repaired, repaired

parts may be collected for reuse or recycling

purposes.

On your TV’s color

• If the speakers should cause the TV screen to have

color irregularity, turn off the TV then turn it on after

15 to 30 minutes. If color irregularity should persist,

place the speakers further away from the TV set.

Additional Information

IMPORTANT NOTICE

Caution: This system is capable of holding a still

video image or on-screen display image on your

television screen indefinitely. If you leave the still

video image or on-screen display image displayed

on your TV for an extended period of time you risk

permanent damage to your television screen.

Projection televisions are especially susceptible to

this.

54US

On moving the system

• Before moving the system, make sure that there is no

disc inserted, and remove the AC power cord (mains

lead) from the wall outlet (mains).

Notes about the Discs

On handling discs

• To keep the disc clean, handle the disc by its

edge. Do not touch the surface.

• Do not stick paper or tape on the disc.

• Do not expose the disc to direct sunlight or

heat sources such as hot air ducts, or leave it in

a car parked in direct sunlight as the

temperature may rise considerably inside the

car.

• After playing, store the disc in its case.

On cleaning

• Before playing, clean the disc with a cleaning

cloth.

Wipe the disc from the center out.

• Do not use solvents such as benzine, thinner,

commercially available cleaners, or anti-static

spray intended for vinyl LPs.

This system can only play a standard circular

disc. Using neither standard nor circular discs

(e.g., card, heart, or star shape) may cause a

malfunction.

Do not use a disc that has a commercially

available accessory attached, such as a label or

ring.

Additional Information

55US

Troubleshooting

If you experience any of the following difficulties while using the system, use this troubleshooting

guide to help remedy the problem before requesting repairs. Should any problem persist, consult your

nearest Sony dealer.

Note that if service personnel changes some parts during repair, these parts may be retained.

General

Messages

Symptom Problems and solutions

The power is not turned on. • Check that the AC power cord (mains lead) is connected securely.

The remote does not function. • The distance between the remote and the unit is too far.

• The batteries in the remote are weak.

The disc tray does not open and

you cannot remove the disc even

after you press Z.

• Try the following: 1 Press and hold N and Z on the unit for more than 5

seconds to open the disc tray. 2 Remove the disc. 3 Disconnect the AC power

cord (mains lead) from the wall outlet (mains), then reconnect after several

minutes.

The system does not work

normally.

• Disconnect the AC power cord (mains lead) from the wall outlet (mains), then

reconnect after several minutes.

Symptom Problems and solutions

[A new software version is

available. Please go to the

“Setup” section of the menu and

select “Network Update” to

perform the update.] appears on

the TV screen.

• See [Network Update] (page 47) to update the system to a newer software

version.

“PROTECTOR” and “PUSH

PWR” appear alternately in the

front panel display.

Press "/1 to turn off the system, and check the following items after

“STANDBY” disappears.

• Are the + and – speaker cords short-circuited?

• Are you using only the specified speakers?

• Is anything blocking the ventilation holes of the system?

• After checking the above items and fixing any problems, turn on the system. If

the cause of the problem cannot be found even after checking all the above

items, consult your nearest Sony dealer.

“LOCKED” appears in the front

panel display.

• Set the child lock function to off (page 40).

“DEMO LOCK” appears in the

front panel display.

• Contact your nearest Sony dealer or local authorized Sony service facility.

“Exxxx” appears in the front

panel display.

• Contact your nearest Sony dealer or local authorized Sony service facility and

give the error code.

appears without any

messages on the entire TV

screen.

• Contact your nearest Sony dealer or local authorized Sony service facility.

56US


Symptom Problems and solutions

There is no picture. • Check the output method on your system (page 15).

There is no picture when you

make an HDMI cable

connection.

• The unit is connected to an input device that is not HDCP (High-bandwidth

Digital Content Protection) compliant (“HDMI” on the front panel does not

light up) (page 15).

3D images from the HDMI (IN

1) or HDMI (IN 2) jack do not

appear on the TV screen.

• Depending on the TV or video component, 3D images may not appear.

No picture appears when the

video output resolution selected

in [Output Video Format] is

incorrect.

• Press and hold N and VOLUME – on the unit for more than 5 seconds to reset

the video output resolution to the lowest resolution.

The dark area of the picture is too

dark/the bright area is too bright

or unnatural.

• Set [Picture Quality Mode] to [Standard] (default) (page 32).

The picture is not output

correctly.

• Check the [Output Video Format] settings in [Screen Settings] (page 48).

• If the analog and digital signals are output at the same time, set [BD/DVD-

ROM 1080/24p Output] in [Screen Settings] to [Off] (page 48).

• For BD-ROMs, check the [BD/DVD-ROM 1080/24p Output] settings in

[Screen Settings] (page 48).

Picture noise appears. • Clean the disc.

• If the picture output from your system goes through your VCR to get to your

TV, the copy-protection signal applied to some BD/DVD programs could affect

picture quality. If you still experience problems even when you connect your

unit directly to your TV, try connecting your unit to the other input jacks.

An image is not displayed on the

entire TV screen.

• Check the setting of [TV Type] in [Screen Settings](page 48).

• The aspect ratio on the disc is fixed.

Color irregularity occurs on the

TV screen.

• If the speakers are used with a CRT-based TV or projector, install the speakers

at least 1.0 ft (0.3 meters) from the TV set.

• If the color irregularity persists, turn off the TV set once, then turn it on after 15

to 30 minutes.

• Make sure that no magnetic object (magnetic latch on a TV stand, health care

device, toy, etc.) is placed near the speakers.

There is no picture after playing

a video/photo file on the iPod/

iPhone. (U.S. and Canada

models only.)

• Select the input on your TV for this system.

Additional Information

57US

Sound

Tuner

Symptom Problems and solutions

There is no sound. • The speaker cord is not connected securely.

• Check the speaker settings (page 39).

The Super Audio CD sound of a

component that is connected to

the HDMI (IN 1) or HDMI (IN

2) jack is not output.

• HDMI (IN 1) and HDMI (IN 2) does not accept an audio format that contains

copy protection. Connect the analog audio output of the component to the

AUDIO (AUDIO IN L/R) jacks of the unit.

There is no sound from the TV

via the HDMI (OUT) jack when

using the Audio Return Channel

function.

• Set [Control for HDMI] in [HDMI Settings] of [System Settings] to [On]

(page 51). Also, set [Audio Return Channel] in [HDMI Settings] of [System

Settings] to [Auto] (page 51).

• Make sure that your TV is compatible with the Audio Return Channel function.

• Make sure that an HDMI cable is connected to a jack on your TV that is

compatible with the Audio Return Channel function.

The system does not output

sound correctly when connected

to a set-top box.

• Set [Audio Return Channel] in [HDMI Settings] of [System Settings] to [Off]

(page 51).

Severe hum or noise is heard. • Move your TV away from the audio components.

• Clean the disc.

The sound loses stereo effect

when you play a CD.

• Select stereo sound by pressing AUDIO (page 34).

The sound comes from the center

speaker only.

• Depending on the disc, the sound may come from the center speaker only.

No sound or only a very low-

level sound is heard from the

surround speakers.

• Check the speaker connections and settings (pages 14, 39).

• Check the surround setting (page 24).

• Depending on the source, the effect of the surround speakers may be less

noticeable.

• A 2 channel source is being played.

Distortion occurs in the sound of

a connected component.

• Reduce the input level for the connected component by setting [Attenuate -

AUDIO] (page 49).

Symptom Problems and solutions

Radio stations cannot be tuned

in.

• Check that the antenna (aerial) is connected securely. Adjust the antenna

(aerial) or connect an external antenna (aerial) if necessary.

• The signal strength of the stations is too weak (when tuning in with automatic

tuning). Use manual tuning.

58US

Playback

USB device

BRAVIA Internet Video

Symptom Problems and solutions

The disc does not play. • The region code on the BD/DVD does not match the system.

• Moisture has condensed inside the unit and may cause damage to the lenses.

Remove the disc and leave the unit turned on for about half an hour.

• The system cannot play a recorded disc that is not correctly finalized (page 60).

File names are not displayed

correctly.

• The system can only display ISO 8859-1-compliant character formats. Other

character formats may be displayed differently.

• Depending on the writing software used, the input characters may be displayed

differently.

A disc does not start playing

from the beginning.

• Resume play has been selected. Press OPTIONS and select [Play from

beginning], then press .

Playback does not start from the

resume point where you last

stopped playing.

• The resume point may be cleared from memory depending on the disc when

– you open the disc tray.

– you disconnect the USB device.

– you play other content.

– you turn off the unit.

The language for the soundtrack/

subtitle or angles cannot be

changed.

• Try using the BD’s or DVD’s menu.

• Multi-lingual tracks/subtitles or multi-angles are not recorded on the BD or

DVD being played.

Bonus contents or other data that

are contained in a BD-ROM

cannot be played.

• Try the following: 1 Remove the disc. 2 Turn the system off. 3 Remove and

reconnect the USB device (page 28). 4 Turn the system on. 5 Insert the BD-

ROM with BONUSVIEW/BD-LIVE.

Symptom Problems and solutions

The USB device is not

recognized.

• Try the following: 1 Turn the system off. 2 Remove and reconnect the USB

device. 3 Turn the system on.

• Make sure that the USB device is securely connected to the (USB) port.

• Check if the USB device or a cable is damaged.

• Check if the USB device is on.

• If the USB device is connected via a USB hub, disconnect it and connect the

USB device directly to the unit.

Symptom Problems and solutions

The picture/sound is poor/certain

programs display with a loss of

detail, especially during fast-

motion or dark scenes.

• Picture/sound quality may be poor depending on Internet content providers.

• Picture/sound quality may be improved by changing the connection speed.

Sony recommends a connection speed of at least 2.5 Mbps for standard-

definition video and 10 Mbps for high-definition video.

• Not all videos contain sound.

The picture is small. • Press X to zoom in.

Additional Information

59US

“BRAVIA” Sync ([Control for HDMI])

Network connection

USB wireless LAN connection

Symptom Problems and solutions

The [Control for HDMI]

function does not work

(“BRAVIA” Sync).

• Check that [Control for HDMI] is set to [On] (page 51).

• If you change the HDMI connection, turn the system off and on again.

• If power failure occurs, set [Control for HDMI] to [Off], then set [Control for

HDMI] to [On] (page 51).

• Check the following and refer to the operating instructions supplied with the

component.

– the connected component is compatible with the [Control for HDMI]

function.

– the connected component’s setting for the [Control for HDMI] function is

correct.

Symptom Problems and solutions

The system cannot connect to the

network.

• Check the network connection (page 20) and the network settings (page 51).

Symptom Problems and solutions

You cannot connect your PC to

the Internet after [Wi-Fi

Protected Setup (WPS)] is

performed.

• The wireless settings of the router may change automatically if you use the

Wi-Fi Protected Setup function before adjusting the settings of the router. In

this case, change the wireless settings of your PC accordingly.

You cannot connect the system

to your wireless LAN router.

• Check if the wireless LAN router is on.

• Depending on the usage environment, including the wall material, radio wave

reception conditions, or obstacles between the system and the wireless LAN

router, the possible communication distance may be shortened. Move the

system and the wireless LAN router closer to each other.

• Devices that use a 2.4 GHz frequency band, such as a microwave, Bluetooth, or

digital cordless device, may interrupt the communication. Move the unit away

from such devices, or turn off such devices.

The desired wireless router is not

detected even if [Scan] is

performed.

• Press RETURN to return to the previous screen, and try [Scan] again. If the

desired wireless router is still not detected, press RETURN to select [Manual

registration].

The system cannot connect to the

network or the network

connection is unstable.

• The distance between the unit and the wireless LAN router is too far (page 20).

60US

Playable Discs

1)Since the Blu-ray Disc specifications are new and

evolving, some discs may not be playable depending

on the disc type and the version. Also, the audio

output differs depending on the source, connected

output jack, and selected audio settings.

2)BD-RE: Ver.2.1

BD-R: Ver.1.1, 1.2, 1.3 including organic pigment

type BD-R (LTH type)

BD-Rs recorded on a PC cannot be played if

postscripts are recordable.

3)A CD or DVD disc will not play if it has not been

correctly finalized. For more information, refer to the

operating instructions supplied with the recording

device.

Discs that cannot be played

• BDs with cartridge

• BDXLs

•DVD-RAMs

• HD DVDs

• DVD Audio discs

• PHOTO CDs

• Data part of CD-Extras

• Super VCDs

• Audio material side on DualDiscs

• For U.S. and Canada models: A disc recorded

in a color system other than NTSC, such as

PAL

(This system conforms to the NTSC color

system.)

Notes on discs

This product is designed to play back discs that

conform to the Compact Disc (CD) standard.

DualDiscs and some music discs encoded with

conform to the Compact Disc (CD) standard.

Therefore, these discs may not be compatible

with this product.

Note on playback operations of a

BD/DVD

Some playback operations of a BD/DVD may be

intentionally set by software producers. Since

this system plays a BD/DVD according to the

disc contents the software producers designed,

some playback features may not be available.

Note about double-layer BDs/

DVDs

The playback picture and sound may be

momentarily interrupted when the layers switch.

Region code (BD-ROM/DVD

VIDEO only)

Your system has a region code printed on the

rear of the unit and will only play a BD-ROM/

DVD VIDEO (playback only) labeled with

identical region codes or .

Blu-ray Disc BD-ROM1)

BD-R/BD-RE2)

DVD3) DVD-ROM

DVD-R/DVD-RW

DVD+R/DVD+RW

CD3) CD-DA (Music CD)

CD-ROM

CD-R/CD-RW

Super Audio CD

ALL

Additional Information

61US

Playable Types of Files

Video

Music


1)The system does not play files encoded with DRM.

2)The system plays AVCHD-format files that are

recorded via a digital video camera, etc. To watch

AVCHD-format files, the disc with AVCHD-format

files on it must be finalized.

3)The system does not play files encoded with

Lossless, etc.

• Some files may not play depending on the file format,

the file encoding, or the recording condition.

• Some files edited on a PC may not play.

• The system can recognize the following files or

folders in BDs, DVDs, CDs and USB devices:

– up to folders in the 5th tree

– up to 500 files in a single tree

• Some USB devices may not work with this system.

• The system can recognize Mass Storage Class (MSC)

devices (such as flash memory or an HDD), Still

Image Capture Devices (SICDs), and 101-key

keyboards (front (USB) port only). (Mexican and

Latin American models only.)

• To avoid data corruption or damage to USB memory

or other devices, turn the system off before

connecting or removing USB memory or other

devices.

• The system may not play high bit rate video files from

a DATA CD smoothly. It is recommended to play

high bit rate video files using a DATA DVD.

File format Extensions

MPEG-1 Video/PS1)

MPEG-2 Video/PS, TS1)

“.mpg,” “.mpeg,” “.m2ts,”

“.mts”

Xvid “.avi”

MPEG4/AVC1) “.mkv,” “.mp4,” “.m4v,”

“.m2ts,” “.mts”

WMV91) “.wmv,” “.asf”

AVCHD 2)

File format Extensions

MP3 (MPEG-1 Audio

Layer III)

“.mp3”

AAC1)3) “.m4a”

WMA9 Standard1)3) “.wma”

LPCM “.wav”

File format Extensions

JPEG “.jpg,” “.jpeg”

GIF “.gif”

PNG “.png”

62US

Supported Audio Formats

Audio formats supported by this system are as follows.

a: Supported format.

–: Unsupported format.

• HDMI (IN 1) and HDMI (IN 2) do not input sound in the case of an audio format that contains copy protections

such as Super Audio CD or DVD-Audio.

• For the LPCM 2ch format, the supported sampling frequency of the digital signal is up to 96 kHz when using the

“HDMI1” or “HDMI2” function, and 48 kHz when using the “TV” function.

Function

Format

LPCM 2ch LPCM 5.1ch

LPCM 7.1ch

Dolby Digital Dolby

TrueHD,

Dolby Digital

Plus

DTS DTS-ES

Discrete 6.1,

DTS-ES

Matrix 6.1,

DTS96/24

DTS-HD

High

Resolution

Audio

DTS-HD

Master

Audio

“BD/DVD”

aaaaaaaa

“HDMI1”

“HDMI2”

a–a–a–––

“TV”

(DIGITAL IN)

a–a–a–––

Additional Information

63US

Specifications

Amplifier Section

U.S.models:

AUDIO POWER SPECIFICATIONS

POWER OUTPUT AND TOTAL HARMONIC

DISTORTION:

(FTC)

Front L + Front R: With 3 ohms loads, both

channels driven, from 180

- 20,000 Hz; rated 60 watts

per channel minimum

RMS power, with no more

than 1% total harmonic

distortion from 250 milli

watts to rated output.

Other models:

POWER OUTPUT (rated)

Front L/Front R: 108 W + 108 W (at 3 ohms,

1 kHz, 1% THD)

POWER OUTPUT (reference)

Front L/Front R/Center/Surround L/Surround R:

167 W (per channel at

3 ohms, 1 kHz)

Subwoofer: 165 W (at 3 ohms, 80 Hz)

Inputs (Analog)

AUDIO (AUDIO IN) Sensitivity: 450/250 mV

Inputs (Digital)

TV (Audio Return Channel/OPTICAL)

Supported formats: LPCM

2CH (up to 48 kHz), Dolby

Digital, DTS

HDMI (IN 1)/HDMI (IN 2)

Supported formats: LPCM

2CH (up to 96 kHz), Dolby

Digital, DTS

Video Section

Outputs VIDEO: 1 Vp-p 75 ohms

HDMI Section

Connector Type A (19pin)

BD/DVD/Super Audio CD/CD System

Signal format system

U.S. and Canada models: NTSC

Other models: NTSC/PAL

USB Section

(USB) port: Type A (For connecting

USB memory, memory

card reader, digital still

camera, and digital video

camera)

LAN Section

LAN (100) terminal 100BASE-TX Terminal

FM Tuner Section

System PLL quartz-locked digital

synthesizer

Tuning range

U.S. and Canada models: 87.5 MHz - 108.0 MHz

(100 kHz step)

Other models: 87.5 MHz - 108.0 MHz (50

kHz step)

Antenna (aerial) FM wire antenna (aerial)

Antenna (aerial) terminals 75 ohms, unbalanced

Speakers

Front/Surround (SS-TSB105)

Dimensions (approx.) 85 mm × 220 mm × 95 mm

(3 3/8 in × 8 3/4 in ×

3 3/4 in) (w/h/d)

Mass (approx.) 0.6 kg (1 lb 6 oz)

Center (SS-CTB102)

Dimensions (approx.) 315 mm × 54 mm × 55 mm

(12 1/2 in × 2 1/4 in ×

2 1/4 in) (w/h/d)

Mass (approx.) 0.4 kg (15 oz)

Subwoofer (SS-WSB103)

Dimensions (approx.) 260 mm × 265 mm × 270

mm (10 1/4 in × 10 1/2 in ×

10 3/4 in) (w/h/d)

Mass (approx.) 6.0 kg (13 lb 4 oz)

General

Power requirements

U.S. and Canada models: 120 V AC, 60 Hz

Argentine models: 220 V - 240 V AC,

50/60 Hz

Other models: 110 V - 240 V AC,

50/60 Hz

Power consumption On: 160 W

Standby: 0.3 W (at the

Power Saving mode)

Dimensions (approx.) 400 mm × 65 mm × 315

mm (15 3/4 in × 2 5/8 in ×

12 1/2 in) (w/h/d) incl.

projecting parts

Mass (approx.) 3.3 kg (7 lb 5 oz)

Design and specifications are subject to change

without notice.

• Standby power consumption 0.3W.

• Over 85% power efficiency of amplifier block is

achieved with the full digital amplifier, S-Master.

64US

Language Code List

The language spellings conform to the ISO 639: 1988 (E/F) standard.

Parental Control/Area Code List

65US

Index

Numerics

3D 27

3D Output Setting 48

A/V SYNC 33

Attenuate - AUDIO 49

Audio 50

Audio DRC 49

Audio Output 49

Audio Return Channel 51

Audio Settings 49

Auto Display 51

Auto Standby 51

BD Audio MIX Setting 49

BD Hybrid Disc Playback

Layer 50

BD Internet Connection 50

BD Parental Control 50

BD/DVD Menu 50

BD/DVD Viewing Settings 50

BD/DVD-ROM 1080/24p

Output 48

BD-LIVE 27

BONUSVIEW 27

BRAVIA Internet Video 31

BRAVIA Sync 38

CD 60

Child Lock 40

Cinema Conversion Mode 48

Control for HDMI 38, 51

Dolby Digital 34

DTS 34

DVD 60

DVD Aspect Ratio 48

DVD Parental Control 50

Easy Setup 22, 52

FM Mode 36

Front panel 8

Front panel display 9

HDMI

YCbCr/RGB (HDMI) 48

HDMI Deep Color Output 49

Initialize Personal Information

Internet content 31

Internet Settings 43, 51

Internet Video Parental Control

Internet Video Unrated 50

Language Code List 64

Multiplex broadcast sound 35

Music Settings 51

Network Connection

Diagnostics 51

Network Settings 51

Network Update 47

OSD 51

Output Video Format 48

Parental Control Area Code 50

Parental Control Settings 50

Password 50

Pause Mode 49

Play information 28

Playable discs 60

Quick Start Mode 51

Rear panel 10

Region code 60

Remote control 11

Reset to Factory Default

Settings 52

Resetting 52

Screen Format 48

Screen Saver 51

Screen Settings 48

SLEEP 40

Slideshow 32

Sound Effect 49

Speaker Settings 39, 49

Connection 39

Distance 39

Level 39

Subtitle 50

Super Audio CD Playback

Channel 51

Super Audio CD Playback

Layer 51

Surround Setting 49

System Information 51

Test Tone 40

TV Screen Size Setting for 3D

TV Type 48

Update 47

USB 28

WEP 46

WPA2-PSK (AES) 46

WPA2-PSK (TKIP) 46

WPA-PSK (AES) 46

WPA-PSK (TKIP) 46

The software of this system may be updated in the future. To find out details on any

available updates, please visit the following URL.

For customers in the U.S.:

http://www.sony.com/support

For customers in Canada:

English: http://www.sony.ca/support

French: http://fr.sony.ca/support

For customers in Mexico and Latin America:

http://esupport.sony.com/LA

Sony BDV E280 E280/BDV T28 User Manual Operating Instructions BDVE280

BDVE280_T28 Sony BDV-E280 Operating Instructions | Manual Device

User manual BDVE280_T28 Sony BDV-E280 Blu-ray Disc Home Theater Systems user guide User Manuals and Instruction Guides

Navigation menu

Versions of this User Manual:

Views

Navigation
