Video Hi8™ Recording
Records outstanding picture quality up
to 400 lines of horizontal resolution with
Hi-Fi sound on affordable Hi8 and 8mm
tapes.
1/4" CCD Imager, 320K Pixels Gross
1/4" CCD imager with 200K (effective)
pixels provides great detail and clarity, with
exceptional analog video performance.
➤
20X Optical/560X Digital Zoom
The optical zoom helps to bring the action
up close from far away. In addition, the
digital zoom interpolation means that
extreme digital zooming is clearer, with
less distortion than previous types of
digital zooms.
➤
3.0" Color SwivelScreen™ LCD Display
(123K Pixels)
Provides excellent viewing clarity with
improved resolution. The 123K pixels
LCD rotates up to 270-degrees for
multiple viewing angles providing a
sharp detailed image for monitoring
or playback.
SteadyShot®Picture Stabilization System
Picture stabilization system that
uses motion sensors to detect
and compensate for camera
“shake”without compromising
picture quality like some other digital
stabilization systems.
➤
USB Streaming
Stay connected with family and friends
by broadcasting live video with audio, via
the internet with the USB interface.
You can even playback your favorite
recorded scene stored on tape. It’s like
having your own web camera and video
conferencing system.
➤
USB Interface
USB interface provides an easy way to
connect the Digital Handycam camcorder
to computers.
InfoLithium®Battery with AccuPower™
Meter System
Charge the battery at any time
because unlike NiCad (Nickel
Cadmium) batteries Sony’s
rechargeable Lithium-Ion batteries are not
subjected to a life shortening “memory
effect”. Sony’s exclusive AccuPower™
meter displays the battery time remaining
in minutes, in the viewfinder or the
LCD screen.
Easy Dubbing
Connect the Handycam camcorder to a
VCR deck to make VHS copies of your
home videos quickly and easily. Camcorder
will control up to 59 brands of VCRs.
NightShot®Infrared System
With Sony’s NightShot®Infrared
system you can capture video
even when shooting in total
darkness (0 lux) up to 10 feet away
using the built-in infrared system.
Stamina®Power Management System
Using the optional NP-FM91
InfoLithium®battery the
CCD-TRV608 can record up to
15.5 hours on one complete charge,
providing extra long battery life.
Program AE (Auto Exposure) Modes
Program AE modes make recording
easy even when filming in challenging
situations. Choose from Portrait, Beach
& Ski, Sports, Landscape, Spotlight,
Sunset & Moon modes.
Picture Effects
Get creative when recording or playing
back videos with Sony’s Picture Effect
modes. Effects available in Camera
mode: Negative Art, Sepia, Black &
White, Solarize, Slim, Stretch, Pastel, and
Mosaic. Effects available in Playback
mode: Negative Art, Sepia, Black &
White, and Solarize.
End Search
Advances the video tape to the last 5
seconds of the most recently recorded
scene. This prevents accidentally
recording over previous recorded videos.
Fader Effects
Enhance your personal videos by adding
professional looking fader effects. Choose
from Black, Mosaic, Black & White,
Bounce and Stripe.
Titling
Add professional looking titles to your
videos, select from 8 preset or 2
customized titles with up to 22
characters.
FEATURES
➤
STEP-UP FEATURE
CCD-TRV608
Analog
Handycam®Camcorder
OPTIONAL ACCESSORIES
SPECIFICATIONS
Imaging Device: 1/4", 320K Gross Pixels CCD
Video Actual: 200K Pixels
Still Actual: N/A
F: 1.4 – 2.9
Focal Distance: 3.6 – 72mm
35mm Conversion: 41 – 820mm
Filter Diameter: 37mm
Optical Zoom: 20X
Digital Zoom: 560X
Focusing: Full Range Auto/Manual (Dial)
Minimum Illumination: 0.4 Lux (0 Lux with NightShot®
Infrared System)
Video Light: Built-in (3 watt)
NightShot Infrared System: Yes
Shutter Speed: 1/60 -1/4000 (AE Mode)
Viewfinder: Black and White (113K)
LCD: 3.0" Color, 123K Pixels
Accessory Shoe: N/A
Video Input/Output: No/Yes (S-Video/Mini)
Audio Input/Output: No/Yes (Mono)
USB Terminal: Yes
USB Streaming: Yes, 320 x 240 (up to 30 frames/sec.)
Headphone Jack: N/A
Mic-Input: N/A
White Balance: Auto
Exposure: Yes, Dial (24 Steps)
Software OS Compatibility: USB Streaming Only,
Microsoft®Windows®98SE, 2000, Me, XP
Power Consumption (VF/LCD/VF+LCD): 1.9W/3.1W/3.3W
Dimensions (WHD): 3 5/8" x 4 1/8" x 7 7/8"
(90mm x 102mm x 197mm)
Weight: 2 lbs 1 oz (935g) w/Battery
Supplied Accessories: AC-L10 Power Adaptor/In Camera
Charger, NP-FM30 InfoLithium Rechargeable Battery,
Mono A/V Cable, Lens Cap, Shoulder Strap, USB
Cable, CD-ROM with USB Driver (PIXELA
ImageMixer Ver. 1.0)
©2002 Sony Electronics Inc.
Reproduction in whole or in part without written permission is prohibited. All rights reserved.
Sony, AccuPower, Handycam, Hi8, InfoLithium, Memory Stick, NightShot, Stamina, SteadyShot,
SwivelScreen and Worry Free are trademarks of Sony. Microsoft and Windows are registered trademarks of
Microsoft Corporation. All other trademarks are property of their respective owners. Features and specifica-
tions subject to change without notice. Non-metric weights and measures are approximate.
Battery* Rec Time
Playback Time
(Fully charged) VF/LCD/VF+LCD LCD/VF
NP-FM30 165/100/90 min 100/175 min
NP-FM50 265/160/150 min 160/280 min
NP-FM70 540/335/310 min 335/570 min
NP-QM71 640/390/365 min 390/675 min
NP-FM91 955/585/550 min 585/1010 min
NP-QM91 955/585/550 min 585/1010 min
*Results may vary
BATTERY LIFE
AC-SC950D AC Quick Charger for
Super Quick batteries
AC-VQ850D AC/DC Adapter
Quick Charger
PC-VM50 Portable AC Charger
DCC-L50 Car Battery Adapter
Cable
LCS-VA2 Carrying Case
LCS-VA1 Carrying Case
ACC-KITFM50 Handycam
Camcorder Starter Kit
VCL-0637H Wide Angle Lens
VCL-HG0737X High Grade Wide
Angle Lens
VCL-ES06A Wide Angle Lens
VCL-ES20A Telephoto Lens
VCL-R2037X High Grade
Telephoto Lens
VF-R37K Neutral Density
Filter Kit
VF-37PK Polarizing Filter Kit
VCT-670RM Remote Control
Tripod
VCT-570RM Remote Control
Tripod
VCT-R610 Lightweight Tripod
VCT-TK1 Pocket Tripod
Sony Electronics Inc.
16765 West Bernardo Drive
San Diego, CA 92127
www.sony.com/di
CCD-TRV608
