Sony CMT MX700Ni User Manual Marketing Specifications CMTMX700NI Mksp

User Manual: Sony CMT-MX700Ni Marketing Specifications

Open the PDF directly: View PDF PDF.
Page Count: 5

Get everything you need to enjoy your music with this compact, user-friendly micro
shelf system with built-in Wi-Fi®. Stream internet music, dock your iPod®, play a CD
and more.
Specications
CMT-MX700NI Sony® CMT-MX700Ni Music System and Wi-Fi Internet Radio
Bullets
Internet radio music services from Slacker® and vTuner™1
Stream songs stored on your computer, wirelessly2
Works with iPhone® / Made for iPod®3
Single Disc CD Player; CD, CD-R/RW, and MP3 Playback
100 Watts with 2-way Bass reex speaker system4
Expand to more rooms with Sonys family of HomeShare® Network speakers5
Audio In for use with MP3 Players, PC and other audio sources
Charge your iPhone® or iPod® while docked3
Remote controls iPhone®/iPod® playlist navigation and other functions3
FM radio with programmable presets
Clock with sleep and wake timers, bass boost, EQ and more
Amplier
Features
Listen to Internet Music Services
Enjoy Slacker®, and thousands of internet radio stations with vTuner™1
Wirelessly listen to music stored on your computer through the MX700Ni
Easily connect the MX700Ni to your home network and listen to your music library stored on your
computer.2
Party Streaming™ Mode
Sync the MX700Ni with Sony’s HomeShare® multi-room products to expand the listening experience
into other rooms.6 Once connected, music being played from the system can also be played on a
HomeShare speaker simultaneously, creating a perfect environment for a party.
Expand to more rooms
No room should be a quiet zone. Purchase additional HomeShare network speakers or docks and
expand your music enjoyment into every room of the home.5
DLNA® (Digital Living Network Alliance)
The music system will work with DLNA® compatible computers and storage devices.
Works with iPhone®
Allows you to play & control music and video content stored on your iPhone®, and charge it while it’s
docked
Made for iPod®
Allows you to play & control music and video content stored on your iPod®, and charge it while it’s
docked3
Audio-in
Allows you to easily connect other audio sources including PCs, MP3 players, and more
Inputs and Outputs Analog Audio Input(s) 1
Function Audio In1 Yes
Power Auto Standby Mode Yes
Convenience Features Backlight Yes
Sound Features Bass Boost function DSGX (Bass Boost)
Function CD Yes
Display Specs Color Black & White
Convenience Features Demo Mode Yes
Sound Features Equalizer Bass/Treble
Function FM Yes
Audio Power Output Front (RMS) 50Wx2
Function
Home Network Yes
iPod & iPhone Yes
Music Services Yes
Power Consumption Power Consumption (in Operation) 43W
Power Consumption (in Standby) 0.5W
Audio Power Output RMS Total 100W
Inputs and Outputs Speaker Output(s) Front 1
General Features Type S-Master(R) (Full Digital)
Function USB1 Yes
Carton
Weight and Measurements Dimensions (WxHxDcm)(Approx.) 389 x 481 x 362 mm
Weight (kg)(Approx.) 8kg
Common Item
General Features Carton qty 1
Power Requirement 120V AC, 60Hz
Direct Dock for iPod
Power Charge Yes
DVD/SA-CD/VCDCD Player
Playable Discs for Audio
8cm Disc (CD) Yes
CD Yes
CD-R Yes
CD-RW Yes
Decoding Format(s) for Sound
(Playback) MP3 Yes
Text Information MP3 File name Yes
General Tray Lock Yes
General
Supplied Accessories
Quick Set up Guide Yes
Quick Set up Guide Yes
Quick Set up Guide Yes
Network
DLNA Digital Media Player (DMP) Music
Digital Media Renderer (DMR) Music
Music Services Service Provider vTuner, Slacker
Connection Wired Yes
Accessories
Accessories
Supplied Accessories FM AntennaSpeaker padsx 8iPhone adaptor x 3Speaker Cable x 2Remote Control x 1Battery - AA/Manganese x
2Operating InstructionsQuick Set up GuideWarranty Card
Supplied Accessories FM AntennaSpeaker padsx 8iPhone adaptor x 3Speaker Cable x 2Remote Control x 1Battery - AA/Manganese x
2Operating InstructionsQuick Set up GuideWarranty Card
Supplied Accessories FM AntennaSpeaker padsx 8iPhone adaptor x 3Speaker Cable x 2Remote Control x 1Battery - AA/Manganese x
2Operating InstructionsQuick Set up GuideWarranty Card
Supplied Accessories FM AntennaSpeaker padsx 8iPhone adaptor x 3Speaker Cable x 2Remote Control x 1Battery - AA/Manganese x
2Operating InstructionsQuick Set up GuideWarranty Card
Supplied Accessories FM AntennaSpeaker padsx 8iPhone adaptor x 3Speaker Cable x 2Remote Control x 1Battery - AA/Manganese x
2Operating InstructionsQuick Set up GuideWarranty Card
Supplied Accessories FM AntennaSpeaker padsx 8iPhone adaptor x 3Speaker Cable x 2Remote Control x 1Battery - AA/Manganese x
2Operating InstructionsQuick Set up GuideWarranty Card
Supplied Accessories FM AntennaSpeaker padsx 8iPhone adaptor x 3Speaker Cable x 2Remote Control x 1Battery - AA/Manganese x
2Operating InstructionsQuick Set up GuideWarranty Card
Remote Commander
General Model Number RM-AMU096
Weights & Dimensions
Master Carton Height 19.69
Master Carton Length 15.51
Master Carton Volume 2.561
Master Carton Weight 22.05
Master Carton Width 14.49
Package Height 19.69
Package Length 15.51
Package Volume 2.561
Package Weight 22.05
Package Width 14.49
Sub Carton Height 19.69
Sub Carton Length 15.51
Sub Carton Volume 2.561
Sub Carton Weight 22.05
Sub Carton Width 14.49
Master Carton Height 19.69
Master Carton Length 15.51
Master Carton Volume 2.561
Master Carton Weight 22.05
Master Carton Width 14.49
Package Height 19.69
Package Length 15.51
Package Volume 2.561
Package Weight 22.05
Package Width 14.49
Sub Carton Height 19.69
Sub Carton Length 15.51
Sub Carton Volume 2.561
Sub Carton Weight 22.05
Sub Carton Width 14.49
Wireless Connection
WiFi IEEE802.11b/g/n Yes/Yes
IEEE802.11b/g/n Yes/Yes
Accessories
Accessories Supplied Accessories
FM Antenna
Speaker padsx 8
iPhone adaptor x 3
Speaker Cable x 2
Remote Control x 1
Battery - AA/Manganese x 2
Operating Instructions
Quick Set up Guide
Warranty Card
1 - Premium content may require additional fees and/or PC registration.
2 - Requires 802.11 home network and content stored on a DLNA® compliant PC or server, or HomeShare® source product. See dlna.org for compatibility.
3 - Compatible with iPhone, iPhone 3G, iPhone 3GS, iPod touch® 1st – 2nd generations, iPod nano® 1st-5th generation, iPod classic®, iPod® 4th & 5th generation, iPod mini®.
4 - Unit audio output tested at 6 ohms in frequency range 120 Hz to 10 kHz with a Total Harmonic Distortion of no more than 10 percent.
5 - Requires home network (802.11 for wireless streaming).
6 - Requires home network (802.11 for wireless streaming) and HomeShare® network speaker, dock, or Blu-ray Disc™ home theater system, sold separately.
© 2010 Sony Electronics Inc. All rights reserved. Reproduction in whole or in part without written permission is prohibited. Sony is a trademark of Sony. iPod is a trademark of Apple Computers, Inc. All other trademarks
are trademarks of their respective owners. Features and specications are subject to change without notice. Non-metric weights and measures are approximate and may vary.
