DAV-C990
DVD Dream™ System
• 5-Disc DVD/SACD/CD Changer with Progressive DVD Output
• 600 Watts Total System Power
- Floor Standing Front Speaker: 100 Watts Per Channel x 2 (3 ohms, 1kHz, 10% THD)
- Center Speaker: 100 Watts Per Channel x 1 (3 ohms, 1kHz, 10% THD)
- Floor Standing Rear Speaker: 100 Watts Per Channel x 2 (3 ohms, 1kHz, 10% THD)
- Subwoofer: 100 Watts Per Channel x 1 (3 ohms, 100Hz, 10% THD)
• Dolby® Digital, dts®, Dolby® Pro Logic® II, MP3 Decoding
• CD-R/CD-RW, Super Audio CD (Multi & 2 Channel), MP3 Playback
• S-Master Digital Amplifier
General Features
• Slot-In Disc Loading
Mechanism for Slim Design
• Play Exchange Function -
Change a Disc while
playing another Disc
• Progressive Scan Output
480P
• Tuner with 20 FM + 10 AM
Station Presets
• Magnetically Shielded
Speakers
• CD-R/CD-RW Playback
• Color Fluorescent Display
• 1/4" Headphone Jack
Audio Features
• S-Master Digital Amplifier
• Digital Cinema Sound™
System
• Dolby® Digital, dts®,Dolby®
Pro Logic® II, MP3 Decoding
• MP3 Playback - from MP3
Encoded CD-R/CD-RW
Discs
• Super Audio CD Playback
(2 Channel &Multi-Channel)
• Surround Sound Fields
(Auto Decoding, Normal
Surround, Hall, Jazz Club,
Live Concert, Game, 2Ch
Stereo)
• Digital Cinema Sound™
System (Cinema Studio EX
A, Cinema Studio EX B,
Cinema Studio EX C)
Inputs and Outputs
• Headphone Jack 1/4"
• 2 Audio Inputs (RCA Type):
Video 1/Video 2
• Optical Digital Input (Toslink
Type): Video 2
• 2 Video Inputs (Composite
RCA Type): Video 1
• Audio Output (RCA Type):
Video 1
• Video Output (Composite
RCA Type)
• S-Video Output
• Component Video Output
Convenience Features
• Color Coded Speaker
Connections
• Glow Key Remote
Commander
• On-Screen Display for MP3
Playback
• On-Screen Display for
Speaker and TV Setup
• Custom Parental Control
(for DVD)
• Radio Station Preset
Naming (up to 8 characters)
• Selectable Component
Video Output
(Interlace/Progressive)
KEY FEATURES
ADDITIONAL FEATURES
Product Information
Color Coded Speaker Connections Connecting a
full 5.1 Channel surround system requires no less than
SIX connections to be made from the receiver to the
speakers (Front Left and Right, Center, Rear Left and
Right and Subwoofer). With color coded connections, a
user simply has to match green with green, etc. to finish
connecting a full 5.1 channel surround system.
ADDITIONAL FEATURES
KEY TECHNOLOGY
Product Information
Specifications
Amplifier Section
• Floor Standing Front
Speaker: 100W x 2 (3
ohms, 1kHz, 10%THD
• Center Speaker: 100W x 1
(3 ohms, 1kHz, 10% THD)
• Floor Standing Rear
Speaker: 100W x 2 (3
ohms, 1kHz, 10% THD)
• Subwoofer: 100W x 1 (3
ohms, 100Hz, 10% THD)
• Input Sensitivity/Impedance:
Inputs Video 1&2 Analog
Audio: 150mV/50kohm
Inputs Video 2 Digital Audio
Inputs Video 1 and Video 2
Composite Video: 1Vp-p 75
ohms
• Output Impedance:
Composite Video Outputs:
1Vp-p 75ohms
S-Video Output: (Y) 1Vp-p
75ohms (C) 0.286Vp-p
75ohms
Component Video Output:
(Y) 1Vp-p 75ohms (Pb/Cr,
Pr/Cr) 0.7Vp-p 75ohms
Phones (Stereo Mini-Pin
Jack): Accepts Low and
High Impedance
Headphones
DVD/SACD/CD Player
Section
• Laser (Semiconductor
Laser):
780 nm CD/650 nm
SACD/DVD
• Frequency Response:
DVD: 2Hz - 22kHz (±1dB)
CD: 2Hz - 20kHz (±1dB)
• Signal to Noise Ration:
>80dB (Video 1 (Audio)
connectors only)
• Harmonic Distortion: <.03%
Tuner Section
• PLL Quartz-Locked Digital
Synthesizer System
• FM Tuner Section:
Tuning Range:
87.5-108.0 MHZ
Antenna: FM Lead Antenna
Antenna Terminals:
75 ohms unbalanced
• AM Tuning Section:
Tuning Range:
530-1,710 kHz
Antenna: AM Loop Antenna
Antenna Terminals:
External Antenna Terminal
Speaker Overview
Front & Rear Speakers
• Speaker System:
2 Way/5 Unit Bass Reflex
Magnetically Shielded Type
• Speaker Units: (4) 2"
Woofers and 1" Balance
Dome Tweeter
• Nominal Impedance:
3 ohms
• Approx. Dimensions
(W/H/D): 25/8" x 413/8" 3"
• Approx. Weight: 7 lbs. 3 oz.
Center Speaker
• Speaker System:
2 Way/5 Unit Bass Reflex
Magnetically Shielded Type
• Speaker Units: (4) 2"
Woofers, 1" Balance Dome
Tweeter
• Nominal Impedance:
3 ohms
• Approx. Dimensions
(W/H/D): 185/8" x 23/4" 3"
• Approx. Weight: 2 lbs.12 oz.
Subwoofer Speaker
• Speaker System:
Subwoofer
• Speaker Units: 71/8"
• Nominal Impedance:
3 ohms
• Approx. Dimensions
(W/H/D): 85/8" x 157/8" x 85/8"
• Approx. Weight: 14 lbs.2 oz.
Main Unit Overview
• Approx. Dimensions
(W/H/D): 14" x 27/8" 15"
• Approx. Weight: 9lbs.12 oz.
General
• Power Requirements:
AC120V, 60Hz
• Power Consumption (in
Operation): 140 W
Accessories
Supplied Accessories
• Instruction Manual
• Speakers Connection and
Installation Card
• Remote Commander®
Remote Control RM-SS990
• Batteries AA x 2
• AM Loop Antenna
• FM Lead Antenna
• Video Cable x 1
• Rear Speaker Cord x 2
(50 ft)
• Front/Center/Subwoofer
Cords x 4 (17 ft)
• Foot Pads (20)
